product sheet
41150002
41150002
SCHUKO socket outlet with screw-in lift terminals, Berker Arsys, white glossy
Technical features
Architecture
Design according to DIN 49440
Main electrical features
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Cover, door
- Central cover plate
Materials
RAL colour RAL 1013 - Oyster white
Colour of design line white
Colour white
Colour white
Material duroplastic
Surface appearance glossy
Dimensions
Insertion depth 32 mm
Installation, mounting
- with spreader claws
Connection
Connection terminals according to IEC 60884-1
Connection terminals according to VDE 0620-1
- with screw-in lift terminals
Use
- with screw-in lift terminals
Safety
Protection index IP IP20
IK protection code against mecanical impacts 02
- without enhanced contact protection
Identification
Powered by TCPDF (www.tcpdf.org)
Main design line Berker Arsys
Technical subject to change
