product sheet
41086086
SCHUKO socket outlet with overvoltage protection with labelling field, Screw terminals, Berker
Q.1/Q.3/Q.7/Q.9, anthracite velvety, lacquered
Technical features
Architecture
Design according to DIN 49440
Controls and indicators
41086086
- with acoustic fault signal
Main electrical features
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Voltage
Overvoltage protection according to EN 61643 and VDE 0675-6-11
Cover, door
- Central cover plate
Materials
RAL colour RAL 7021 - Black grey
Colour of design line anthracite
Colour anthracite charcoal grey
Colour anthracite
Material / workmanship lacquered
Material thermoplastic
Surface appearance velvety
Dimensions
Insertion depth 32 mm
Installation, mounting
- with spreader claws
Connection
Connection terminals according to IEC 60884-1
Connection terminals according to VDE 0620-1
- with screw terminals
Equipment
- with indicator LED for On/Error
Use
- with labelling field
- Screw terminals
Technical subject to change
product sheet
41086086
Safety
Protection index IP IP20
IK protection code against mecanical impacts 05
- without enhanced contact protection
Identification
Main design line Berker Q.1/Q.3/Q.7/Q.9
Secondary design line(s) Berker Q.1, Berker Q.3
Instructions
- Labelling field height arranged for P-touch strips 6 mm.
