product sheet
30763505
30763505
Change-over switch surface-mounted Berker W.1, grey/light grey matt
Technical features
Main electrical features
Nominal voltage 250 V
Rated voltage 250 V AC
Electric current
Switching current 10 AX
Materials
RAL colour RAL 7011 - Iron grey
Colour of design line grey/light grey
Colour dark grey
Material thermoplastic
Surface appearance matt
Dimensions
Depth 61,5 mm
Height 76 mm
Width 76 mm
Connection
- with two clip-in places for Wago 2-wire connection terminals in the housing floor
- with Wago clip-in 2-wire connection terminal for wiring
- with plug-in terminals
Cable
- with one entry for 2 cables and one entry for cable and tube
Equipment
- with full-face sealing on the rear side of housing for cable entry and surface adjustment on the backside
Use conditions
Operating temperature -40 … 30 °C
Storage/transport temperature -50 … 50 °C
Identification
Powered by TCPDF (www.tcpdf.org)
Application, usage Surface-mounted wet-room installation
Main design line Berker W.1
Instructions
- Pins of quick-release lock made of ZAMAK
Technical subject to change
