product sheet
16966086
Rocker with large labelling field, Lens, Berker Q.1/Q.3/Q.7/Q.9, anthracite velvety, lacquered
Technical features
Controls and indicators
- also for KNX applications: push-button, 1gang, and group push-button, 1gang
- for change-over/intermediate switch
- for rocker push-buttons
16966086
Materials
RAL colour RAL 7021 - Black grey
Colour of design line anthracite
Colour anthracite charcoal grey
Colour anthracite
Material / workmanship lacquered
Material duroplastic
Surface appearance velvety
Dimensions
Height 58 mm
Width 58 mm
Labelling field (W x H) 54,8 x 42,8 mm
Installation, mounting
- clamp fastening
Equipment
- for lighting and monitoring circuit
Use
- with large labelling field
- Lens
Identification
Application, usage Light control, Flush-mounted wet-room installation,
KNX - operating systems
Main design line Berker Q.1/Q.3/Q.7/Q.9
Secondary design line(s) Berker Q.3, Berker Q.1
Instructions
- For labelling with names, notes etc.
Labelling field height designed for two 18 mm P-touch strips.
- The IP44 degree of protection can only be achieved in conjunction with the appropriate neon,
incandescent or LED lamp unit, as well as a sealing set for switches/push-buttons.
