We recommend the use of original Beretta spare parts and accessories. The use of other manufacturer’s spare parts and accessories could cause malfunctions and/or breakages that will not be covered by the Beretta Warranty.

Series

CONTENTS

Page

BASIC SAFETY RULES 49 DESCRIPTION 57 SAFETY FEATURES 57 OPERATIONAL AND ANATOMICAL FEATURES 59 SPECIFICATIONS 62 GENERAL OPERATION 63 LOAD CHECK 63 HOW TO LOWER THE COCKED HAMMER 65 OBSTRUCTION CHECK 67 AMMUNITION 68 LOADING 69 UNLOADING 72 FIRING 74 FIELD STRIPPING 78 MAINTENANCE 78 RE-ASSEMBLY 81 STORAGE 81 INTERCHANGEABLE SIGHTS 82 HOW TO ADJUST THE TRIGGER 83 HOW TO REVERSE THE MAGAZINE RELEASE BUTTON 83 TROUBLESHOOTING 84 WARRANTY AND EXTENSION OF THE WARRANTY REPAIR

PERIOD 85

This instruction manual consists of 176 pages.

BASIC SAFETY RULES

WARNING: PLEASE READ THIS MANUAL BEFORE HANDLING YOUR FIREARM.

WARNING: FIREARMS CAN BE DANGEROUS AND CAN POTENTIALLY CAUSE SERIOUS INJURY, DAMAGE TO PROPERTY OR DEATH, IF HANDLED IMPROPERLY. THE FOLLOWING SAFETY RULES ARE AN IMPORTANT REMINDER THAT FIREARM SAFETY IS YOUR RESPONSIBILITY.

1. NEVER POINT A FIREARM AT SOMETHING THAT IS NOT SAFE TO SHOOT.

Never let the muzzle of a firearm point at any part of your body or at another person. This is especially important when loading or unloading the firearm. When you are shooting at a target, know what is behind it. Some bullets can travel over a mile. If you miss your target or if the bullet penetrates the target, it is your responsibility to ensure that the shot does not cause unintended injury or damage.

2. ALWAYS TREAT A FIREARM AS IF IT WERE LOADED.

Never assume that a firearm is unloaded. The only cer tain way

to ensure that a firearm has the chamber(s) empty is to open the chamber and visually and physically examine the inside to see if a round is present.

! !

Series

Removing or unloading the magazine will not guarantee that a firearm is unloaded or cannot fire. Shotguns and rifles can

be checked by cycling or removing all rounds and by then opening and inspecting the chamber so that a visual inspection of the chamber for any remaining rounds can be made.

3. STORE YOUR FIREARM SO THAT CHILDREN CANNOT GAIN ACCESS TO IT.

It is your responsibility to ensure that children under the age of 18 or other unauthorized persons do not gain access to your firearm. To reduce the risk of accidents involving

children, unload your firearm, lock it and store the ammunition in a separate locked location. Please note that

devices intended to prevent accidents - for example, cable locks, chamber plugs, etc, - may not prevent use or misuse of your firearm by a determined person. Firearm storage in a steel gun safe may be more appropriate to reduce the likelihood of intentional misuse of a firearm by an unauthorized child or person.

4. NEVER SHOOT AT WATER OR AT A HARD SURFACE.

Shooting at the surface of water or at a rock or other hard surface increases the chance of ricochets or fragmentation of the bullet or shot, which can result in the projectile striking an unintended or peripheral target.

5. KNOW THE SAFETY FEATURES OF THE FIREARM YOU ARE USING, BUT REMEMBER: SAFETY DEVICES ARE NOT A SUBSTITUTE FOR SAFE HANDLING PROCEDURES.

Never rely solely on a safety device to prevent an accident. It is imperative that you know and use the safety features of the particular firearm you are handling, but accidents can best be prevented by following the safe handling procedures described in these safety rules and elsewhere in the product manual. To further familiarize yourself with the proper use of this or other firearms, take a Firearms Safety Course taught by an expert in firearms use and safety procedures.

6. PROPERLY MAINTAIN YOUR FIREARM.

Store and carr y your firearm so that dirt or lint does not accumulate in the working parts. Clean and oil your firearm, following the instructions provided in this manual, after each use to prevent corrosion, damage to the barrel or accumulation of impurities which can prevent use of the gun in an emergency. Always check the bore and chamber(s) prior to loading to ensure that they are clean and free from obstructions. Firing with an

obstruction in the barrel or chamber can rupture the barrel and injure you or others nearby. In the event you hear an unusual

noise when shooting, stop firing immediately, engage the manual safety and unload the firearm. Make sure the chamber and barrel are free from any obstruction, like a bullet blocked inside the barrel due to defective or improper ammunition.

Series

7. USE PROPER AMMUNITION.

Only use factory-loaded, new ammunition manufactured to industry specifications: CIP (Europe and elsewhere), SAAMI (U.S.A.). Be certain that each round you use is in the proper caliber or gauge and type for the particular firearm. The caliber or gauge of the firearm is clearly marked on the barrels of shotguns and on the slide or barrel of pistols. The use of reloaded or remanufactured ammunition can increase the likelihood of excessive cartridge pressures, case-head ruptures or other defects in the ammunition that can cause damage to your firearm and injur y to yourself or others nearby.

8. ALWAYS WEAR PROTECTIVE GLASSES AND EARPLUGS WHEN SHOOTING.

The chance that gas, gunpowder or metal fragments will blow back and injure a shooter who is firing a gun is rare, but the injury that can be sustained in such circumstances can be severe, including the possible loss of eyesight. A shooter must always wear impact resistant shooting glasses when firing any firearm. Earplugs or other high-quality hearing protectors help reduce the chance of hearing damage from shooting.

9. NEVER CLIMB A TREE, FENCE OR OBSTRUCTION WITH A LOADED FIREARM.

Open and empty the chamber(s) of your firearm and engage the manual safety before climbing or descending a tree or before climbing a fence or jumping over a ditch or other obstruction. Never pull or push a loaded firearm toward yourself or another person. Always unload a firearm, visually and physically check to see that the magazine, loading mechanism and chamber

are unloaded, and action is open before handing it to another person. Never take a firearm from another person unless it is unloaded, visually and physically checked to confirm it is unloaded, and the action is open.

10. AVOID ALCOHOLIC BEVERAGES OR JUDGMENT/REFLEX IMPAIRING MEDICATION WHEN SHOOTING.

Do not drink and shoot. If you take medication that can impair motor reactions or judgment, do not handle a firearm while you are under the influence of the medication.

11. NEVER TRANSPORT A LOADED FIREARM.

Unload a firearm before putting it in a vehicle (chamber empty, magazine empty). Hunters and target shooters should load their firearm only at their destination, and only when they are ready to shoot. If you carr y a firearm for selfprotection, leaving the chamber unloaded can reduce the chance of an unintentional discharge.

12. LEAD WARNING.

Discharging firearms in poorly ventilated areas, cleaning firearms, or handling ammunition may result in exposure to lead and other substances known to cause birth defects, reproductive harm, and other serious physical injur y. Have adequate ventilation at all times. Wash hands thoroughly after exposure.

Series

WARNING: It is YOUR responsibility to know and abide by Federal, State and Local laws governing the sale, transportation and use of firearms in your area.

Especially for U.S. consumers:

For information about Firearm Safety Courses in your area, please visit the National Rifle Association’s web site at www

.nra.org.

WARNING: This firearm has the capability of taking your life or the life of someone else! Always be extremely careful with your firearm. An accident is almost always the result of not following basic firearm safety rules.

Fig. 1

Fig. 2

decocked hammer-safety disengaged decocked hammer-safety engaged

Fig. 3 Fig. 4

Series

cocked hammer-safety engaged

Fig. 5

half-cocked hammer

safety disengaged

single/double action mod. only

half-cocked hammer

safety engaged

single/double action mod. only

Fig. 8 Fig. 9

Fig. 7

Fig. 6

cocked hammer-safety disengaged

SAFETY FEATURES

NOTICE: The figure numbers noted below refer to the photographs on pages 2, 55, 56, 173.

Frame mounted safety (Fig. 1-5/A). All 92/98/96 Steel I pistols feature an ambidextrous manual safety on the frame that locks the sear and the slide in the closed position. The manual safety can be engaged when the hammer is in decocked or cocked position (Fig. 4 and 7). On the single/double action versions the safety can be also engaged with the hammer in halfcocked position (Fig. 9). The manual safety cannot be engaged with the slide in the open position.

DESCRIPTION

The new Beretta 92/98/96 Steel I is the synthesis of the longstanding experience of the model 92, manufactured in well over two million units and reconfirms Beretta’s tradition of steel framed pistols. Designed with extreme attention to details the Beretta 92/98/96 Steel I pistol is created with the true connoisseurs, the expert marksmen and collectors in mind. This exclusive 92 model sports numerous special features, like its steel frame, the slim lines of its “vertical” grip, the “flush” barrel, the recoil-reducing slide, already tested in the Brigadier, Stock, Combat and Billennium models, the ambidextrous, framemounted safety and the skeletonized hammer. Other features are the Novak rear sight with white dots, the thin dual textured grips and the Beretta satin/polished grey finish, which is a special nickel-alloy based plating that ensures an extraordinary resistance to punishing and harsh weather conditions and gives the pistol its unmatched look. The Beretta 92/98/96 Steel I is available in calibers 9mm x 19 Parabellum (Luger), 9mm x 21 IMI and .40 S&W, both in a traditional single/double action and a single action only version. The single action only model features a micrometric adjustment of the trigger’s pre and over travel. The Beretta 92/98/96 Steel I is qualified to compete in the IDPA competitions.

Series

Automatic Firing Pin Block (Fig. 1/B). The 92/98/96 Steel I pistols have a blocking device that prevents forward movement of the firing pin unless the trigger is pulled. This feature is intended to prevent discharge if the pistol is dropped or if the hammer is unintentionally dropped without pulling the trigger.

Loaded chamber indicator (Fig. 2). The loaded chamber indicator is a small red tab (extractor) that protrudes fur ther from the slide when a round is in the chamber. The tab is located on the right side of the pistol’s slide, near the cartridge chamber, and can be both seen and felt, allowing the user to check the chamber at night by feel or during the day by checking for the increased protrusion of the red tab.

Note: The most certain way to check whether a pistol is loaded is to pull back on the slide and visually inspect the chamber for a round. Loaded chamber indicators are designed primarily to allow noiseless inspection of the pistol to ensure that it is loaded in situations when it may be dangerous to operate the slide (the action of pulling back on the slide may make noise and will temporarily render the pistol inoperable) or when it is dark.

WARNING: In order to permit the use of the pistol in emergency situations, even in the case of involuntary dropping or loss of the magazine, these models are NOT provided with a magazine safety. They are therefore capable of firing, when a round is chambered, even if the magazine has not been inserted or if it has been removed or if it has been dislodged from its seat.

Slide catch (Fig. 1/C). The slide catch is a lever that holds the slide open and rearward after the last round is fired. This allows the user to immediately determine that the pistol does not have a round in the chamber or in the magazine.

Slide overtravel stop. The hammer pin head has been enlarged to enter a matching groove cut into the slide rail to stop slide breech recoil overtravel.

External hammer (Fig. 1/D). The external hammer allows the user to visually and immediately determine that the hammer is cocked or lowered.
