Manuale di Istruzione
Instruction Manual
Mode d’Emploi
Manual de Instrucciones
2
Fig. 5
Fig. 7
Fig. 9
Fig. 6
Fig. 8
Fig. 10
Fig. 12Fig. 11
3
Fig. 13
Fig. 15
Fig. 17
Fig. 14
Fig. 16
Fig. 18
Fig. 20Fig. 19
CANE DISARMATO
HAMMER DECOCKED
CHIEN DESARME
MARTILLO DESARMADO
46
ALWAYS KEEP THIS MANUAL WITH YOUR FIREARM. INCLUDE IT
WITH THE CARBINE WHEN IT CHANGES OWNERSHIP OR WHEN
IT IS LOANED OR PRESENTED TO ANOTHER PERSON.
Notice: The Manufacturer and/or its Local Official Distributors
assume no responsibility for product malfunction or for physical
injury or property damage resulting in whole or in part from
criminal or negligent use of the product, improper or careless
handling, unauthorized modifications, use of defective, improper,
hand-loaded, reloaded or remanufactured ammunition*,
customer abuse or neglect of the product, or other influences
beyond manufacturer's direct and immediate control.
* See paragraph “Ammunition”.
WARNING: ALL FIREARMS HAVE LETHAL POTENTIAL. READ THE
BASIC SAFETY RULES CAREFULLY AND UNDERSTAND THEM
FULLY BEFORE ATTEMPTING TO USE THIS FIREARM.
In addition to the Basic Safety Rules, there are other Safety
Rules pertaining to the loading, unloading, disassembly,
assembly and use of this firearm, located throughout this
manual.
WARNING: READ THE ENTIRE MANUAL CAREFULLY BEFORE
USING THIS FIREARM. MAKE SURE THAT ANY PERSON USING
OR HAVING ACCESS TO THIS FIREARM READS AND
UNDERSTANDS ALL OF THIS MANUAL PRIOR TO USE OR
ACCESS.
!
!
Illustrations on pages
2, 3, 54, 55, 170, 171
ENGLISH ITALIANO
pagina 4
FRANÇAIS
page 86
ESPAÑOL
página
128
We recommend the use of original Beretta spare parts and
accessories. The use of other manufacturer’s spare parts
and accessories could cause malfunctions and/or breakages
that will not be covered by the Beretta Warranty.
47
CONTENTS
Page
BASIC SAFETY RULES 48
NOMENCLATURE 54
DESCRIPTION 56
SAFETY FEATURES 56
OPERATIONAL AND ANATOMICAL FEATURES 58
SPECIFICATIONS 60
GENERAL OPERATION 61
LOAD CHECK 61
OBSTRUCTION CHECK 63
DISASSEMBLY 63
REASSEMBLY 65
AMMUNITION 66
LOADING AND FIRING 68
UNLOADING 71
ADJUSTING THE SIGHTS AND SIGHTING 72
FIRING 74
PICATINNY RAILS 77
MOUNTING THE STOCK SPACERS 77
REVERSING THE CONTROLS 79
MAINTENANCE 81
STORAGE 84
This instruction manual consisting of 171 pages.
48
BASIC SAFETY RULES
WARNING: PLEASE READ THIS MANUAL BEFORE HANDLING
YOUR FIREARM.
WARNING: FIREARMS CAN BE DANGEROUS AND CAN
POTENTIALLY CAUSE SERIOUS INJURY, DAMAGE TO PROPERTY
OR DEATH, IF HANDLED IMPROPERLY. THE FOLLOWING SAFETY
RULES ARE AN IMPORTANT REMINDER THAT FIREARM SAFETY IS
YOUR RESPONSIBILITY.
1. NEVER POINT A FIREARM AT SOMETHING THAT IS NOT
SAFE TO SHOOT.
Never let the muzzle of a firearm point at any part of your body
or at another person. This is especially important when
loading or unloading the firearm. When you are shooting at a
target, know what is behind it. Some bullets can travel over a
mile. If you miss your target or if the bullet penetrates the
target, it is your responsibility to ensure that the shot does
not cause unintended injury or damage.
2. ALWAYS TREAT A FIREARM AS
IF IT WERE LOADED.
Never assume that a firearm is
unloaded. The only cer tain way
to ensure that a firearm has the
chamber(s) empty is to open
the chamber and visually and
physically examine the inside to
see if a round is present.
!
!
49
Removing or unloading the magazine will not guarantee that
a firearm is unloaded or cannot fire. Shotguns and rifles can
be checked by cycling or removing all rounds and by then
opening and inspecting the chamber so that a visual
inspection of the chamber for any remaining rounds can be
made.
3. STORE YOUR FIREARM SO THAT CHILDREN CANNOT GAIN
ACCESS TO IT.
It is your responsibility to ensure that children under the age
of 18 or other unauthorized persons do not gain access to
your firearm. To r educe the risk of accidents involving
children, unload your firearm, lock it and store the
ammunition in a separate locked location. Please note that
devices intended to prevent accidents - for example, cable
locks, chamber plugs, etc, - may not prevent use or misuse of
your firearm by a determined person. Firearm storage in a
steel gun safe may be more appropriate to reduce the
likelihood of intentional misuse of a firearm by an
unauthorized child or person.
50
4. NEVER SHOOT AT WATER OR AT A HARD SURFACE.
Shooting at the surface of water or at
a rock or other hard surface
increases the chance of ricochets or
fragmentation of the bullet or shot,
which can result in the projectile
striking an unintended or peripheral
target.
5. KNOW THE SAFETY FEATURES OF THE FIREARM YOU ARE
USING, BUT REMEMBER: SAFETY DEVICES ARE NOT A
SUBSTITUTE FOR SAFE HANDLING PROCEDURES.
Never rely solely on a safety device to prevent an accident. It
is imperative that you know and use the safety features of the
particular firearm you are handling, but accidents can best be
prevented by following the safe handling procedures
described in these safety rules and elsewhere in the product
manual. To further familiarize yourself with the proper use of
this or other firearms, take a Firearms Safety Course taught
by an expert in firearms use and safety procedures.
6. PROPERLY MAINTAIN YOUR FIREARM.
Store and carr y your firearm so that
dirt or lint does not accumulate in
the working parts. Clean and oil your
firearm, following the instructions
provided in this manual, after each
use to prevent corrosion, damage to
the barrel or accumulation of
impurities which can prevent use of
the gun in an emergency. Always
check the bore and chamber(s) prior
to loading to ensure that they are clean and free from
obstructions. Firing with an obstruction in the barrel or
chamber can rupture the barrel and injure you or others
nearby. In the event you hear an unusual noise when
shooting, stop firing immediately, engage the manual safety
and unload the firearm. Make sure the chamber and barrel
51
are free from any obstruction, like a bullet blocked inside the
barrel due to defective or improper ammunition.
7. USE PROPER AMMUNITION.
Only use factory-loaded, new ammunition manufactured to
industry specifications: CIP (Europe and elsewhere), SAAMI
(U.S.A.). Be certain that each round you use is in the proper
caliber or gauge and type for the particular firearm. The
caliber or gauge of the firearm is clearly marked on the barrels
of shotguns and on the slide or barrel of pistols. The use of
reloaded or remanufactured ammunition can increase the
likelihood of excessive cartridge pressures, case-head
ruptures or other defects in the ammunition that can cause
damage to your firearm and injur y to yourself or others nearby.
8. ALWAYS WEAR PROTECTIVE GLASSES AND EARPLUGS
WHEN SHOOTING.
The chance that gas, gunpowder or
metal fragments will blow back and
injure a shooter who is firing a gun
is rare, but the injury that can be
sustained in such circumstances
can be severe, including the
possible loss of eyesight. A
shooter must always wear impact
resistant shooting glasses when
firing any firearm. Earplugs or other
high-quality hearing protectors help reduce the chance of
hearing damage from shooting.
9. NEVER CLIMB A TREE, FENCE OR
OBSTRUCTION WITH A LOADED
FIREARM.
Open and empty the chamber(s) of
your firearm and engage the
manual safety before climbing or
descending a tree or before
climbing a fence or jumping over a
ditch or other obstruction. Never
52
pull or push a loaded firearm toward yourself or another
person. Always unload a firearm, visually and physically
check to see that the magazine, loading mechanism and
chamber are unloaded, and action is open before handing it
to another person. Never take a firearm from another
person unless it is unloaded, visually and physically checked
to confirm it is unloaded, and the action is open.
10. AVOID ALCOHOLIC BEVERAGES OR JUDGMENT / REFLEX
IMPAIRING MEDICATION WHEN SHOOTING.
Do not drink and shoot. If you take
medication that can impair motor
reactions or judgment, do not
handle a firearm while you are
under the influence of the
medication.
11. NEVER TRANSPORT A LOADED FIREARM.
Unload a firearm before putting it in a vehicle (chamber
empty, magazine empty). Hunters and target shooters
should load their firearm only at their destination, and only
when they are ready to shoot. If you carr y a firearm for selfprotection, leaving the chamber unloaded can reduce the
chance of an unintentional discharge.
12. LEAD WARNING.
Discharging firearms in poorly ventilated areas, cleaning
firearms, or handling ammunition may result in exposure to
lead and other substances known to cause birth defects,
reproductive harm, and other serious physical injur y. Have
adequate ventilation at all times. Wash hands thoroughly
after exposure.
53
It is YOUR responsibility to know and abide by Federal, State and
Local laws governing the sale, transportation and use of
firearms in your area.
Especially for U.S. consumers:
For information about Firearm Safety Courses in your area,
please visit the National Rifle Association’s web site at
www
.nra.org.
WARNING: This firearm has the capability of taking your life or
the life of someone else! Always be extremely careful with your
firearm. An accident is almost always the result of not following
basic firearm safety rules.
!
54
NOMENCLATURE
A Barrel
B Cocking handle
C Manual safety button
D Bolt release lever
E Stock spacer
F Recoil pad
G Side sling swivel
H Rear sling swivel
I Magazine release button
L Trigger
M Disassembly latch
N Front sling swivel
O Loaded chamber indicator
P Peep rearsight
Q Ejection port
R Front sight
S Front rail
T Side rail seat
U Magazine
V Stock (lower receiver)
Z Sight key
X Bolt assembly
Y Receiver/barrel assembly
(upper receiver)
Fig. 1
A B C D E
F
G
H
ILMN
55
P
Q
O
R
ST
M
C
G
Fig. 2
Fig. 3
Fig. 4
X
B
M
Z
V
U
Y
56
DESCRIPTION
The Beretta Cx4 Storm semiautomatic carbine is a sporting or
personal defense firearm with a particularly captivating
appearance and simplicity of use. The blowback type locking
system and the bolt safety ensure reliability, great stability and
precision in follow up shots. The extractor, the ejector and the
cocking handle are easily reversible for right and left hand use.
The manual safety button and the magazine release button can
also be reversed from one side of the carbine to the other*.
The cold hammer forged barrel is chrome lined and made of high
resistance steel for maximum resistance to corrosion and
increased barrel life.
Extensive use of technopolymers has allowed the development
of a light and technically advanced firearm as well as equipping
it with very modern an ergonomic lines.
Rounded forms are snag free, facilitating handling and rapid
shouldering and aiming.
*
This operation should be carried out by a gunsmith
SAFETY FEATURES
Notice: The figure numbers noted below refer to the photographs
on pages 2, 3, 54, 55, 170, 171.
Manual safety button (reversible) (Fig.1/2 - C). The Cx4 Storm
features a manual safety that blocks the trigger. The manual
safety can be engaged when the hammer is in the decocked or
cocked position, or when the bolt is open or closed. The manual
safety button is reversible for right or left hand use.
Automatic Firing Pin Block. The Cx4 Storm has a blocking
device that prevents forward movement of the firing pin unless
the trigger is pulled. This feature is intended to prevent
discharge if the carbine is dropped or if the hammer is
unintentionally dropped without pulling the trigger.
57
Loaded chamber indicator (Fig. 2-O). The loaded chamber
indicator is a small tab that protrudes from the bolt when a round
is in the chamber. The tab is located on the ejector of the carbine
and can be both seen and felt, allowing the user to check the
chamber for the increased protrusion of the tab. Please note:
The most certain way to check whether a carbine is loaded is to
pull back on the bolt and visually inspect the chamber for a
round. Loaded chamber indicators are designed primarily to
allow noiseless inspection of the carbine to ensure that it is
loaded in situations when it may be dangerous to operate the
bolt (the action of pulling back on the bolt may make noise and
will temporarily render the carbine inoperable) or when it is dark.
The loaded chamber indicator is reversible for right or left hand
use.
WARNING: In order to permit the use of the Cx4 Storm in
emergency situations, even in the case of involuntary dropping
or loss of the magazine, these models are NOT provided with a
magazine safety. They are therefore capable of firing, if a round
is chambered, even if the magazine has not been inserted or if
it has been removed or if it has been dislodged from its seat.
Bolt release lever (Fig. 1-D). The bolt release lever allows the
closing of the bolt which remains in the open position after the
last round from the magazine has been fired (magazine
inserted). This permits the user to immediately determine that
the carbine does not have a round in the chamber or in the
magazine.
Bolt travel stop. This safety system is an inertia device which
avoids the complete opening of the bolt in case the carbine is
dropped, preventing the accidental introduction of the round into
the chamber or the ejection of the chambered cartridge.
Safety on the hammer. The hammer features a device that
prevents the disengaging of the hammer itself. This safety is
intended to reduce the possibility of discharge of the carbine if it
is dropped.
!
58
OPERATIONAL AND
ANATOMICAL FEATURES
Semiautomatic firing. The Cx4 Storm carbine will automatically
reload after each round is fired, as long as there are car tridges
in the magazine.
The blowback type locking system and the bolt safety ensure
reliability, great stability and precision in follow up shots.
Single action. The short and light single action trigger pull allows
for faster, more accurate discharge of subsequent rounds.
Removable magazine (Fig. 3). The Beretta Cx4 Storm carbine
has a quickly removable, high capacity magazine which allows
rapid reloading and extended use in emergency situations.
The capacity of magazine for Cx4 Storm models is as follows*:
cal. 9mm Parabellum**– 10,15, 20 rounds, staggered magazine
cal. 9mm x 21 IMI - 10, 15 rounds, staggered magazine
cal. 40 S&W**- 10, 11 rounds, staggered magazine
cal. 45 ACP (Auto) – 8 rounds, staggered magazine
*
Consult local authorities for maximum magazine capacity restrictions
that may apply in your locale.
**
Commercial carbines sold in the US market are supplied with 10-round
magazines in accordance with US Federal Guidelines for Commercial
Sales.
Specific calibers, may not be available in you market.
Where permitted by law the Cx4 Storm is able to utilize the
same magazines as the 92/96/98 and 8000/8040/8045
Cougar pistol series through the assembly of an adapter in the
magazine seat.
Reversible controls. The extractor, the ejector, the cocking
handle, the ejection port cover, the magazine release button and
the manual safety button are reversible for right or left hand use.
59
Simple field stripping and cleaning (Fig. 1/2-M). The
disassembly mechanism consists of a latch found below the
cocking handle. It is designed to allow an extremely quick and
simple field stripping of the carbine and also to avoid casual or
involuntary disassembly. A firearm which can be easily field
stripped can be more readily cleaned. Simple cleaning makes it
easier for the user to properly maintain your carbine, which helps
ensure continued reliability.
Technopolymer frame. (Fig. 4–V/Y). The extensive use of
technopolymers has allowed the development of a light and
technically advanced firearm as well as equipping it with ver y
modern, extremely captivating and ergonomic lines. The
technopolymer also guarantees corrosion resistance and color
consistency (the color will never wear or scratch off).
Sights (Fig. 2-P/R). The front sight is fully adjustable for
windage and elevation while the peep rearsight has long and
short range apertures. Both sights may be folded down when
optics are used.
Adjustable stock (Fig. 1-E). Special stock spacers (up to three)
allow the lengthening of the stock. Each spacer increases the
length of the stock by 15 mm (0.60 in.). A spacer is already
supplied (mounted on the stock) with your Beretta Cx4 Storm
carbine.
Picatinny rails. In addition to the standard extractable Picatinny
type rail found underneath the barrel and the side rail supplied
in the case, top and bottom Picatinny rails are also available on
request.
Swivels for carrying sling (Fig. 1-N/H). On the front and rear
part of the stock, swivels are mounted for the optional carr ying
sling. The rear part of the stock features a side, vertical slot type
swivel. (Fig. 1/2-G).
NOTICE: There are numerous Beretta special parts and
accessories that allow the personalization of your carbine. To
request this extensive line of parts and accessories, please
contact your local Beretta dealer.
60
SPECIFICATIONS
Caliber 9mmx19 9mmx21 IMI 40 S&W 45 ACP
(Parabellum (Auto)
or Luger)
Magazine capacity
(rounds)
*
10, 15, 20 10, 15 10, 11 8
Pitch 250 mm 250 mm 400 mm 406 mm
Rifling R.H., 6 grooves
Operation Semiautomatic, it fires from the closed bolt position.
Locking system Blowback type
Action Single action only
Sights Fully adjustable front sight for windage and elevation,
foldable. 2-position peep rearsight, foldable.
Safeties Manual safety on the frame: it can be applied with
hammer cocked or decocked, bolt open or closed.
Automatic firing pin blocking device.
Bolt travel stop.
Safety on the hammer.
Frame/Receiver In technopolymer
Bolt In steel
Barrel In steel, cold hammer forged, chrome lined.
Overall length (mm/in)
755/29.7 - 800/31.5 with 0 to 3 stock spacers
Barrel length (mm/in) 422.5/16.6
Overall width (mm/in) 63/2.5
Overall height (mm/in) 190/7.5
Sight radius (mm/in) 327/12.9
Weight unloaded
(without magazine)
(gr/oz) (approx.) 2575/90.8
*
Commercial carbines sold in the US market are supplied with 10-round magazines
in accordance with US Federal Guidelines for Commercial Sales.
61
GENERAL OPERATION
The Beretta Cx4 Storm is a semiautomatic blowback type
firearm. Upon firing, the pressure developed by the combustion
gases pushes the bolt back which, during its rearward
movement, extracts and ejects the fired cartridge case, cocks
the hammer and compresses the recoil spring.The bolt will then
automatically move forward towards the closed position, feeding
the next cartridge from the magazine into the chamber. The bolt
is designed to stay open after the last round has been fired and
ejected.
LOAD CHECK
At various points in this manual you will be instructed to “visually
check to be certain your Beretta Cx4 Storm carbine is unloaded.”
This should become second nature to you, as you should:
•Never assume that a firearm is unloaded (even a gun that is
new and in its original packaging).
•Never point or push a firearm toward yourself or another
person.
•Always visually check to see that the chamber is unloaded.
•Remove the magazine, engage the manual safety and block the
bolt in the open position before handing the carbine to another
person.
•Never take or pull this carbine from another person unless the
safety is engaged, the magazine is removed, the bolt is open,
and the chamber has been visually checked to confirm it is
unloaded.
To visually check to be certain your Beretta Cx4 Storm carbine is
unloaded, carefully follow the steps below.
WARNING: Keep your finger OFF THE TRIGGER and the barrel
pointed in a SAFE direction.
!
62
•Engage the manual safety by pushing the manual safety button
until the red band completely disappears. (Fig. 5)
WARNING: When the safety button shows the red band, the
safety is disengaged and the firearm is in the FIRE position.
•Remove the magazine by pushing the magazine release button.
(Fig. 6)
•Retract the cocking handle to open the bolt (Fig. 7) (Releasing
the bolt when a magazine is not in the carbine will
automatically close the bolt). Always keep your finger away
from the ejection port. To keep the bolt in the open position,
without the magazine in the carbine, press the bolt release
lever upwards with your thumb (Fig. 8) and release the cocking
handle. The bolt will be blocked in the open position.
The bolt remains open when an empty magazine is inserted or
when the bolt release lever is pressed upwards.
•Check the cartridge chamber to be certain it is empty.
If the carbine is unloaded, proceed to the following step,
otherwise refer to the procedure: Unloading the carbine.
•Holding the cocking handle, press the bolt release lever
downwards with your thumb and gently take the bolt to the
closed position.
WARNING: Always keep your finger away from the ejection port.
WARNING: THE HAMMER IS COCKED. With the barrel pointed in
a safe direction, decock the hammer by pulling the trigger.
Notice: The hammer can be decocked only when the bolt is in
the closed position.
!
!
!
63
OBSTRUCTION CHECK
Check the barrel to be sure there are no obstructions in the
chamber and bore. This is extremely important because if
another cartridge is fired into an obstructed barrel, a
catastrophic failure can result.
To visually check to be sure there are no obstructions in the
barrel, follow the disassembly steps below:
DISASSEMBLY
WARNING: Always be certain that the carbine is unloaded.
Please refer to the instructions given in the ”load check”
paragraph.
Notice: It is advisable to carr y out the field stripping operations
over a table to catch components should they drop.
CAUTION: Before disassembling the parts, carefully observe
and memorize the position of the components to facilitate their
correct reassembly.
•Remove the magazine by pushing the magazine release button.
(Fig. 6)
•To facilitate disassembly, it is advisable to cock the hammer.
Retract the bolt by means of the cocking handle and gently take
the bolt to the closed position. (Fig. 7)
WARNING: By retracting the cocking handle when an empty
magazine is inserted in the carbine, the bolt remains in the open
position. To close the bolt press the bolt release lever
downwards. Always keep your fingers away from the ejection
port.
•Push the disassembly latch out the frame of the carbine.
(Fig. 9) The disassembly latch can be removed from either
side.
!
!
64
•Slide the front part of the carbine (receiver/barrel assembly)
from the stock. (Fig. 10)
•Fully retract the cocking handle until it corresponds with the
opening (circular part) of the port. (Fig. 11)
•Remove the cocking handle by pulling it forcefully. (Fig. 12)
WARNING: At this stage, the bolt is not blocked into position by
the cocking handle and could therefore fall out. Handle with care
all disassembled parts.
•Remove the bolt from the barrel. (Fig. 13)
Look down the barrel from the muzzle (or front) end so that you
can see completely through the barrel to make sure no
obstruction exists.
If an obstruction in the barrel is detected, a qualified gunsmith
must remove the obstruction and inspect the carbine before it
can be fired.
WARNING: If another cartridge is fired into an obstructed barrel,
a catastrophic failure can result.
!
!
65
REASSEMBLY
•Check that the hammer is cocked. If not, completely pull the
trigger and keep it depressed, draw back the hammer and
release the trigger. The hammer will be blocked in the cocked
position (fully retracted). (Fig. 14 and 15)
•Reassemble the bolt on the barrel corresponding the lower
guides of the bolt with the lower guides of the receiver.
(Fig. 16)
•Line up the hole found on the bolt body with the rear part of the
cocking port (circular part). (Fig. 12)
•Insert the cocking handle (with the concave part facing the
barrel) into the seat pushing it into the hole of the bolt.
•Push the cocking handle completely forwards until it stops.
•Reassemble the stock by engaging the side rails of this last
part with the side rails of the receiver/barrel/bolt assembly.
(Fig. 17)
•Slide the receiver/barrel/bolt assembly onto the stock until it
stops.
•Insert and push the disassembly latch in the seat while holding
the stock and receiver/barrel/bolt assembly together.
•Pull the trigger to decock the hammer.
66
AMMUNITION
AMMUNITION (CARTRIDGE) NOTICE: Beretta specifically
disclaims responsibility for any damage or injury whatsoever
occurring in connection with, or as the result of, the use in
Beretta Cx4 Storm carbine of faulty, or non-standard, or
“remanufactured,” or hand-loaded (reloaded) ammunition, or
cartridges other than those for which the firearm was originally
chambered.
Use only high-quality, commercially-manufactured ammunition
that is manufactured in accordance with CIP (Europe and
elsewhere) or SAAMI (USA) standards. Be certain that the
ammunition is the appropriate caliber and loading for the firearm
and is clean, dry, and in good condition. The cartridge
designation for your carbine is marked on the side of the barrel
and in front of the cocking handle (visible when drawn back).
WARNING: Carefully inspect each cartridge before it is loaded in
the magazine. Be certain the cartridge cases are not split,
deformed, or the cartridges do not possess any other dents or
defects (this applies even to factory ammunition).
Do not fire old ammunition in this firearm. Primers, powder,
cartridge cases, and bullets can deteriorate with time and cause
damage to the firearm, or injur y to the shooter or others.
WARNING: Do not use reloaded or handloaded ammunition.
Beretta assumes no liability for incidents occurring through the
use of reloaded ammunition. Use of reloaded ammunition will
void the manufacturer’s warranty.
WARNING: The extended use of +P, +P+ ammunition may
decrease the minor components service life expectancy.
DO NOT use sub-machine gun ammunition because the chamber
pressure may reach or exceed proof load pressure.
Lead bullets have a tendency to cause bore leading, which may
dramatically increase the discharge pressure.
Make sure to remove all chamber and bore lead accumulation
after each use.
!
!
!
67
DO NOT ever shoot cartridges with jacketed bullets through a
barrel previously fired with lead bullets before the bore is
thoroughly deleaded.
DRY FIRING/”DUMMY” ROUNDS
Dry firing is defined as firing a firearm with no ammunition in the
chamber. Long term dry firing your Beretta Cx4 Storm carbine
may result in damage to the action. “Snap caps” (inert chamber
inserts that allow a firearm to be dr y-fired without damaging the
action) are available at most gun stores for those who wish to
practice firing without live ammunition.
CAUTION: If you want to practice shooting your carbine without
using live ammunition (called “dry firing”), insert an appropriate
“snap cap” into the chamber to cushion the fall of the firing pin
and reduce the chance of firing pin breakage. “Snap cap”
cartridges with spring loaded “primers” are ideal.
“DUMMY” cartridges with empty primer pockets are good for
loading/unloading practice but DO NOT protect the firing pin
during dry firing.
68
LOADING AND FIRING
Notice: The figure numbers noted below refer to the photographs
on pages 2, 3, 54, 55, 170, 171.
WARNING: Beretta assumes no responsibility for any injury or
property damage resulting from improper or careless handling,
intentional or accidental discharge of the firearm.
WARNING: This carbine can have a live round in the chamber
and can fire even if the magazine is empty or has been removed.
WARNING: Before loading the firearm, become familiar with the
following loading procedures without the use of ammunition.
Never handle a loaded firearm until you are fully familiar with the
loading procedures. Always point the firearm in a safe direction.
WARNING: Always keep your finger away from the trigger
whenever you do not intend to fire.
Make sure the carbine is not already loaded by removing the
magazine and retracting the bolt in order to check that the
chamber is empty.
WARNING: Be sure that you have the correct cartridges for your
carbine.
WARNING: Be sure that the obstruction check has been
completed prior to loading.
CAUTION: Always wear protective glasses and earplugs when
shooting (See point 8 of the BASIC SAFETY RULES).
LOADING THE MAGAZINE
•To load the magazine, remove it from the carbine by pushing
the magazine release button. (Fig. 6)
•Hold the magazine in one hand. With the other hand place a
cartridge on the magazine follower in front of the lips at the top
of the magazine. Press the cartridge down onto the follower
!
!
!
!
!
!
69
!
!
!
!
and slide the cartridge completely under the lips until it is
lodged fully inside the magazine body. (Fig. 18)
•Repeat process until magazine is fully loaded. Holes on the
back of the magazine allow for visual counting of cartridges.
(Fig. 3)
CAUTION: Do not tr y to force more than the maximum number
of rounds indicated for your particular carbine into the magazine.
An overloaded magazine may not function properly.
LOADING THE CARBINE AND THE FIRING CHAMBER
WARNING: Point the firearm in a safe direction. Do not touch the
trigger until you are ready to shoot and are sure of your target
and backstop.
The firing chamber of the carbine is the portion of the barrel
into which the cartridge is fed. The firing chamber may be loaded
in one of two ways:
1. LOADING FROM MAGAZINE
•Engage the manual safety by pushing the manual safety button
until the red band disappears. (Fig. 5)
WARNING: When the safety button shows the red band, the
safety is disengaged and the firearm is in the FIRE position.
WARNING: The manual safety is merely a mechanical device and
is in no way a substitute for the Basic Safety Rules of firearm
handling.
•Completely push the loaded magazine into the carbine grip to
ensure catch engagement.
•Pull back the bolt and release it. The bolt will automatically
pick up a cartridge from the top of the magazine and feed it into
the chamber.
WARNING: THE CARBINE IS NOW CHAMBER LOADED, COCKED
AND READY TO FIRE BY PULLING THE TRIGGER. Keep your finger
away from the trigger whenever you do not intend to fire.
70
2. THIS CARBINE WHICH IS LOADED AND FIRED WILL
AUTOMATICALLY PICK UP THE NEXT ROUND AND FEED IT
INTO THE FIRING CHAMBER AS LONG AS THERE IS
AMMUNITION IN THE MAGAZINE.
Notice: The manufacturer assumes no responsibility for any
injury or property damage resulting from improper or careless
handling, intentional or accidental discharge of the firearm.
Notice: The Beretta Cx4 Storm carbine is equipped with an
automatic safety which prevents firing pin protrusion beyond the
breech face. This safety is overcome only by trigger pull.
If you want to replace the round which has been chambered from
the magazine (remember that you are handling a loaded firearm
with a live round in the chamber):
•Check the manual safety is engaged.
•Remove the magazine from the carbine by pushing the
magazine release button.
•Insert one more cartridge into the magazine.
•Completely push the loaded magazine into the carbine grip to
ensure catch engagement.
WARNING: REMEMBER THAT YOU ARE HANDLING A LOADED
FIREARM, WITH A LIVE ROUND IN THE CHAMBER. Keep your
finger away from the trigger whenever you do not intend to fire.
!
71
UNLOADING
WARNING: Be certain the carbine is pointed in a SAFE direction.
WARNING: Do not place your finger on the trigger or inside the
trigger guard.
•Engage the manual safety (Fig. 5).
•Pointing the firearm in safe direction, remove the loaded
magazine from the grip.
•Fully retract the bolt by means of the cocking handle to remove
the chambered cartridge.
WARNING: Always visually inspect the firing chamber to ensure
that it is empty. The chamber is empty when no cartridge is
visible when looking into the open chamber.
WARNING: If you are ejecting unfired cartridges, use extreme
care to be sure they are ejected onto an appropriate sur face.
Never attempt to catch cartridges or fired cartridge cases as
they fall.
WARNING: Never allow anything to come in contact with the
primer of unfired ammunition. Doing so could cause the
ammunition to explode.
•When sure that the chamber is empty and the cartridge has
been ejected, release the bolt.
WARNING: Depressing the slide release lever when a loaded
magazine is in the carbine will feed a cartridge into the carbine’s
firing chamber. Having the hammer cocked, the carbine will be
in the condition of being able to fire immediately.
To increase the ser vice life of the hammer spring, it is advisable
to decock the hammer by pulling the trigger.
WARNING: Always unload the firearm immediately after shooting
is completed.
!
!
!
!
!
!
!
72
ADJUSTING THE SIGHTS
AND SIGHTING
WARNING: Always be certain that the carbine is unloaded before
adjusting the sights. Please refer to the instructions given in the
”Load check” paragraph.
WARNING: Make sure the carbine is pointed in a safe direction.
The Beretta Cx4 Storm features a fully adjustable front sight for
elevation and windage and an adjustable peep rearsight for long
and short range distances. Both sights may be folded down
when optics are used.
The upper part of the carbine is designed to accept the mounting
of optional Picatinny rails for the application of scopes and
aiming systems on request.
FRONT SIGHT – WINDAGE ADJUSTMENT
To move the point of impact to the right:
Using the supplied tool (Fig. 4-Z) loosen the screw on the right
of the front sight (as viewed from the rear) clockwise in the
direction of the arrow (R= right). Proceed one click at a time.
(Fig. 19)
To move the point of impact to the left:
Using the supplied tool (Fig. 4-Z) loosen the screw on the right
of the front sight (as viewed from the rear) counterclockwise in
the opposite direction of the arrow. Proceed one click at a time.
(Fig. 19)
!
!
UNLOADING THE MAGAZINE
•To unload the magazine, grasp it with one hand around the
magazine box, bottom down and front end forward. With the tip
of the thumb firmly press down on the cartridge rim and push
towards the front of magazine box. As the cartridge moves
forward, tip it slightly upward with the index finger.
•Repeat until the magazine is unloaded.
73
FRONT SIGHT - ELEVATION ADJUSTMENT
To raise the point of impact:
Using the supplied tool (Fig. 4-Z) loosen the front sight
clockwise. Proceed one click at a time. (Fig. 20)
To lower the point of impact:
Using the supplied tool (Fig. 4-Z) loosen the front sight
counterclockwise. Proceed one click at a time. (Fig. 20)
To fold the front sight, rotate it downwards.
PEEP REARSIGHT
For long range shooting, vertically position the rearsight leaf with
the letters LR (Long Range) with your finger. For short range
shooting, rotate the LR leaf downwards to raise the rearsight leaf
with the letters SR (Short Range).
To completely fold the rearsight leaves, rotate them down
towards the barrel.
SIGHTING
Point the carbine at the target you intend to shoot and aim by
focusing the front sight through the hole of the rearsight leaf.
Place the front sight on your target. The front sight should be in
focus while the target slightly blurred or out of focus.
Notice: It is recommended to hold the front sight during the
adjustment in windage to avoid the front sight folding during the
loosening of the screw.
74
FIRING
WARNING: Only point a firearm at something safe to shoot. Never
put your finger on the trigger unless you intend to shoot. Never
disengage the safety on a firearm unless you intend to shoot.
WARNING: Always wear high-quality eye and ear protection when
firing any firearm. Be certain that others near-by are wearing
high-quality eye and ear protection and are to the rear of the
shooter, when firing any firearm.
WHEN READY TO FIRE:
•Load the firearm using the loading procedures above.
•Point the carbine at the intended target.
•Release the manual safety by simply pushing the manual
safety button until the red band appears.
WARNING: When the red band on the manual safety button is
exposed, indicates that the safety is off and the firearm is ready
to FIRE!
•When the sights are aligned on a SAFE target, place your index
finger inside the trigger guard and gently squeeze the trigger,
being careful not to upset the alignment of the front sight and
the target. THE CARBINE WILL FIRE.
The discharge will cause the bolt to recoil which, in turn, will eject
the fired cartridge case, cock the hammer and compress the
recoil spring. Then the bolt will automatically close, feeding the
next cartridge from the magazine into the chamber.
•After the first shot is fired, repeat this process to fire additional
cartridges, or proceed to the unloading instructions.
WARNING: THE CARBINE IS STILL CHAMBER LOADED, COCKED
AND READY TO FIRE AGAIN. Keep your finger away from the
trigger whenever you do not intend to fire and immediately
engage the manual safety.
!
!
!
!
75
•When the last round has been fired the bolt remains open.
If you have completed shooting, engage the manual safety,
remove the magazine and holding the cocking handle, press the
bolt release lever downwards with your thumb and gently take
the bolt to the closed position. Pull the trigger to decock the
hammer.
•To fire again, remove the empty magazine and insert a loaded
one.
•If the bolt is in the open position press the bolt release lever
downwards to insert the round in the chamber. If the bolt has
been closed, retract it by means of the cocking handle and
immediately release the bolt to insert the cartridge in the
chamber.
WARNING: THE CARBINE IS NOW CHAMBER LOADED, COCKED
AND READY TO FIRE AGAIN. Keep your finger away from the
trigger whenever you do not intend to fire and immediately
engage the manual safety.
WARNING: Always unload the firearm immediately after shooting
is completed. Never store a loaded firearm. To store the carbine
see the dedicated paragraph (Storing).
If while firing the trigger is pulled and the firearm does not
immediately fire:
CEASE FIRING IMMEDIATELY!
•Keep the firearm pointed in a SAFE direction in the event a
“hang-fire” has occurred. A hang-fire occurs when there is a
delay in a cartridge’s ignition.
•With the carbine pointed in a SAFE direction, wait one (1) full
minute.
•After one (1) full minute has elapsed, completely unload the
firearm by following the unloading instructions in this manual.
•Carefully inspect your ammunition.
•Immediately refer to a qualified gunsmith if the firing pin indent
on a fired cartridge’s primer is light, off-center or does not
exist.
!
!
76
•Using the disassembly instructions in the beginning of this
manual under Obstruction Check, remove the frame-barrel/bolt
assembly from the stock and visually check to be sure there
are no obstructions in the barrel. If a barrel obstruction is
detected, a qualified gunsmith must remove the obstruction
and inspect the carbine before it can be fired.
WARNING: If another cartridge is fired into an obstructed barrel,
a catastrophic failure can result.
WARNING: Never attempt to fire ammunition that did not fire the
first time.
If, while firing, you hear a change in the sound a fired cartridge
makes, or feel a change in the amount of recoil of a fired
cartridge, or detect any other irregularity:
CEASE FIRING IMMEDIATELY!
•Keep the firearm pointed in a SAFE direction. A “squib load”
may have occurred. A “squib” occurs when a car tridge fires,
but with insufficient force to drive the bullet out of the barrel.
This can result in a dangerous bore obstruction.
WARNING: If another cartridge is fired into an obstructed barrel,
a catastrophic failure can result.
•With the gun pointed in a SAFE direction, completely unload the
firearm by following the unloading instructions in this manual.
•Using the disassembly instructions remove the framebarrel/bolt assembly from the stock and visually check to be
sure there are no obstructions in the barrel. If a barrel
obstruction is detected, a qualified gunsmith must remove the
obstruction and inspect the carbine before it can be fired.
•Carefully inspect your ammunition.
WARNING: Never attempt to reuse or fire ammunition that did
not fire the first time. Dispose of unfired or damaged
ammunition properly, per the ammunition manufacturer’s
recommendation.
!
!
!
!
77
WARNING: Always unload the firearm immediately after shooting
is completed. Never store a loaded firearm. To store the firearm
see the dedicated paragraph (Storing).
!
!
!
!
!
PICATINNY RAILS
WARNING: Always be certain that the carbine is unloaded.
Please refer to the instructions given in the ”Load check”
paragraph.
WARNING: Make sure the carbine is pointed in a safe direction.
Under the barrel, inside the fore-end of the upper receiver, the
standard Picatinny type rail supplied with your carbine can be
extracted. (Fig. 2-S) To do so, push the front sling swivel and
simultaneously extract the internal rail (Fig. 21).
To mount the side Picatinny type rail included with your carbine,
it is sufficient to attach it with the two screws supplied into their
respective seats. (Fig. 2-T) The rail can be mounted on both
sides of the receiver (Fig. 22). Other optional Picatinny rails to
mount on the top of the frame (MIL-STD-1913) (Fig. 23) and
under the barrel (Fig. 24) are available on request.
MOUNTING THE STOCK SPACERS
WARNING: Always be certain that the carbine is unloaded.
Please refer to the instructions given in the ”Load check”
paragraph.
WARNING: Make sure the carbine is pointed in a safe direction.
Notice: It is advisable to disassemble the stock from the
receiver/barrel/bolt assembly (see paragraph regarding
disassembly).
If you wish to mount additional spacers (available on request) on
the stock in order to increase the length or to remove the one
already mounted in order to decrease the length of the stock,
proceed as follows:
78
•Remove the rubber recoil pad from the rear of the stock
(Fig. 25).
•Unscrew in a counter clockwise direction the rear screw from
the stock with a 7 mm blade screwdriver (Fig. 26).
•Completely remove the screw.
•Remove the mounted spacer if you wish to shorten the stock
or add more spacers (available on request) to lengthen the
stock.
CAUTION: once the screw has been removed from the stock, the
rear sling swivel (Fig.1/2-G) is not fixed to the stock. Take care
not to lose it.
•To remount the screw make sure to correctly centre the screw
with the respective seat of the sling swivel.
•Using the screwdriver, completely screw and tighten the screw
in a clockwise direction on the stock.
•Reassemble the rubber recoil pad.
79
REVERSING THE CONTROLS
WARNING: Always be certain that the carbine is unloaded.
Please refer to the instructions given in the ”Load check”
paragraph.
WARNING: Make sure the carbine is pointed in a safe direction.
EXTRACTION, EJECTION AND COCKING HANDLE
Notice: It is advisable to carr y out the field stripping and the
assembly operations over a table to catch components should
they drop.
CAUTION: Before disassembling the parts, carefully observe
and memorize the position of the components to facilitate their
correct reassembly.
•Disassemble the bolt from the barrel sliding it from the receiver
(See paragraph on disassembly).
•Remove the retaining spring clip from the spring/spring guide
assembly (Fig. 27). The operation can be facilitated by levering
the spring/spring guide upwards.
•Remove the ejector from its seat (Fig. 28).
•On the opposite side, remove the extractor (Fig. 29).
CAUTION: In order to invert the ejection from one side to the
other, it is necessary to also invert the position of the ejection
port cover located on the opposite side of the extractor.
•To ease the procedure of inverting the position of the controls,
it is advisable to also remove the spring/spring guide assembly
(Fig. 30).
•Using a drift-punch or similar, gently push the cover from the
open side of the ejection port (Fig. 31) until the cover is
completely removed.
WARNING: The cover MUST always be mounted on the opposite
side of the extractor in order to avoid possible mis-ejection of the
case.
!
!
80
•To remount the ejection por t cover on the side desired, take
care to correctly inser t the two upper protrusions of the cover
in their respective recesses on the bolt.
•Mount the extractor on the opposite side paying attention to
insert its rear protrusion into the seat of the bolt (Fig. 32).
•Insert the ejector on the opposite side to the extractor as
shown in Fig. 33.
•Remount the spring/spring guide assembly if previously
disassembled.
•Push the retaining spring clip down into its seat (Fig. 34).
•Once the bolt is reassembled onto the barrel line up the hole
found on the bolt body with the rear part of the cocking port
(circular part) (Fig. 12) and insert the cocking handle (with the
concave part facing the barrel) into the seat pushing it into the
hole (right or left side) of the bolt.
•Proceed with the rest of the reassembly as indicated in the
dedicated chapter.
MANUAL SAFETY BUTTON,
MAGAZINE RELEASE BUTTON
The above mentioned controls can be reversed from one side of
the carbine to the other for right or left hand use.
WARNING: Please contact a qualified gunsmith to reverse the
manual safety and the magazine release buttons.
WARNING: Do not attempt to alter the internal parts of your
carbine’s firing mechanism. Alterations to the hammer, trigger,
springs, sear or other internal parts can result in a very
dangerous situation.
WARNING: Altering the internal par ts of your carbine’s firing
mechanism voids the manufacturer’s warranty.
!
!
!
81
MAINTENANCE
The firearm should be cleaned as soon as possible after firing.
Use only high-quality, commercially-available firearm cleaning
solvents and cleaning equipment.
WARNING: Never store a loaded firearm.
WARNING: The firearm should not be disassembled for cleaning
beyond what is described below. Only a qualified gunsmith who
is familiar with these firearms should conduct further
disassembly.
WARNING: Do not attempt to alter the internal parts of your
carbine’s firing mechanism. Alterations to the hammer, trigger,
springs, sear or other internal parts can result in a very
dangerous situation.
WARNING: Altering the internal par ts of your carbine’s firing
mechanism voids the manufacturer’s warranty.
WARNING: Do not attempt to make repairs to any firearm
without proper knowledge or training. Do not alter parts or use
substitute parts not made by Beretta. Any alterations or
adjustments that may be necessary to the operating mechanism
should be performed by the Manufacturer or by its Local Official
Distributor.
DISASSEMBLY
WARNING: Always be certain that the carbine is unloaded.
Please refer to the instructions given in the ”Load check”
paragraph.
Notice: It is advisable to carr y out the field stripping and the
assembly operations over a table to catch components should
they drop.
CAUTION: before disassembling the parts, carefully observe and
memorize the position of the components to facilitate their
correct reassembly.
To disassemble the carbine, please refer to the instructions
given in the disassembly paragraph in the “obstruction check”
section.
!
!
!
!
!
!
82
CLEANING
WARNING: Excess oil and grease obstructing the bore, even
partially, is very dangerous when firing and may cause barrel
rupture and serious injur y to the shooter and bystanders. Never
spray or apply oil to the cartridges. Use lubricants properly. You
are responsible for the proper care and maintenance of your
firearm.
BARREL
•Spray a brush with Beretta oil or a good grade gun oil. Inser t
the brush into the barrel by means of a rod from the chamber
and scrub the chamber and bore thoroughly. If necessary, first
clean the bore with a gun solvent.
•Dry the chamber and bore by pushing a cotton patch through
the chamber and bore with the rod. Change the patch until it
emerges clean.
WARNING: Check the barrel to be sure there are no obstructions
in the chamber and bore.
•Lightly oil the inside of the barrel by passing through it a clean
cotton patch soaked in Beretta oil or a good grade gun oil.
•Lightly oil the outside of the barrel.
BOLT
•Clean the bolt with a patch and Beretta oil or a good grade gun
oil, paying special attention to the breech face, extractor,
ejector and to the bolt guides. If necessary, use the brush.
Wipe bolt surfaces with a clean patch.
•Lightly oil the bolt.
RECOIL SPRING AND SPRING GUIDE
•Lightly oil the recoil spring and spring guide with Beretta oil or
a good grade gun oil. After long use it could be necessary to
first scour these parts using a brush.
!
!
83
RECEIVER AND STOCK
•Using a synthetic wire brush clean all areas covered by
gunpowder residue and dirt.
•Wipe outer receiver and stock sur faces clean and lightly
lubricate the rails and moving parts. Lightly oil the disassembly
latch, magazine catch, travel slide stop, trigger system,
hammer and the levers between the hammer and the trigger
system (Fig. 35 - see arrows).
CAUTION: Do not apply excess oil.
MAGAZINE
•Make sure the magazine is thoroughly clean and the follower
slides easily downward if pressed.
•If necessary, lightly oil with Beretta oil or a good grade gun oil
the internal walls of the magazine box.
•Run a dry patch through the box. Do not leave lubricant inside
the magazine box.
CAUTION: Do not apply excess oil. Accumulation of oil attracts
dirt and dust, which can interfere with the functioning and
reliability of the firearm.
REASSEMBLY
To reassemble the carbine, please refer to the instructions given
in the reassembly paragraph in the “obstruction check” section.
84
STORAGE
WARNING: The carbine should be stored UNLOADED, with the
bolt in closed position, the safety engaged and the hammer
decocked (to decock the hammer pull the trigger).
WARNING: Store firearms and ammunition separately, each in
its own locked container, and away from children and
unauthorized adults!
WARNING: Be certain your firearm is unloaded before shipping
or taking it to the dealer.
CAUTION: It is recommended to store the firearm in the supplied
case. Before storage, always check the conditions of the carbine
and its case. Make sure that they are perfectly dry.
CAUTION: Do not store your carbine in a leather, fabric or canvas
holster or case. These materials attract moisture, even though
they may appear to be perfectly dry.
!
!
!
85
NOTES
170
Fig. 21
Fig. 23
Fig. 25
Fig. 22
Fig. 24
Fig. 26
Fig. 28Fig. 27
171
Fig. 29
Fig. 31
Fig. 33
Fig. 30
Fig. 32
Fig. 34
Fig. 35
Le illustrazioni e descrizioni di questo opuscolo si intendono fornite a titolo
indicativo. La Casa si riserva pertanto il diritto di apportare ai suoi modelli, in
qualsiasi momento e senza preavviso, quelle modifiche che ritenesse utili per
migliorarli o per qualsiasi esigenza di carattere costruttivo e commerciale.
The illustrations and descriptions given in this brochure are intended as a general
guide only, and must not be taken as binding. The Company, therefore, reserves the
right to make, at any moment and without prior notice, any changes it thinks
necessary to improve its models or to meet any requirements of manufacturing or
commercial nature.
Les illustrations et les descriptions contenues dans ce prospectus ne sont données
qu’à titre indicatif. La Maison se réserve le droit de modifier, à tout moment et sans
préavis, ses modèles pour les améliorer ou pour n’importe quelle exigence de
caractère constructif et commercial.
Las ilustraciones y descripciones de este folleto tienen un valor puramente
indicativo. La Casa se reserva por lo tanto el derecho de aportar a sus modelos, en
todo momento y sin previo aviso, cuantas modificaciones considere útiles al fin de
mejorarlos o por cualquier exigencia de construcción o de oportunidad comercial.
Printed in Italy
batan - Gardone V.T.
Beretta Pubblicità - C61724
10/03
Fabbrica d'Armi
Pietro Beretta S.p.A.
Via Pietro Beretta, 18
25063 GARDONE V.T.
(Brescia) Italia
Tel. (030) 8341.1
www.beretta.com
Loading...
