Page 1
600W • 450W • 350W • 300W
HIGHLIGHTSIDEAL APPLICATIONS
Office applications
Gaming systems
Low-budget and quiet PC builds
80PLUS
DC-to-DC technology
Multi-GPU support
®
Bronze efficiency
Quiet operation
Proven Reliability and Good Efficiency
The be quiet! System Power B9 (bulk) series offers renowned be quiet! reliability and quietness for price-conscious PC builders.
Highlights »
▪ Production-optimized bulk packaging
▪ Rock-solid stability with two strong 12V-rails
▪ DC-to-DC technology for tight voltage regulation (600W and 450W)
▪ Multi-GPU support with up to two PCIe connectors
▪ Temperature-controlled 120mm fan reduces system noise
▪ Stand-by drain of less than 0.15 watts
▪ 80PLUS
®
Bronze efficiency (up to 89%)
▪ Attractive black sleeved cables (600W)
▪ Complete suite of top safety features
▪ Meets latest Intel
®
C6/C7, ErP and Energy Star 6.1 guidelines
▪ 3-year manufacturer’s warranty
▪ Product conception, design and quality control in Germany
System Power B9 »
Simply the best price-conscious choice for stability, performance and quietness.
*According to the yearly PC Games Hardware‘s „Manufacturer of the year“ election (2006-2017) and market data from GfK (2007-2017)
Page 2
Technical Data »
Model
Article no.
EAN code
Voltage ( Vac) / Frequency (Hz)
Dimensions (L x W x H)
ATX 12V 2.4 / EP S 12V 2.92
High-quality fan (mm)
Noise level (dB(A)) at 20 / 50 / 100% load
12V-rail s
IN GENERAL
PFC
Efficiency (%) at 230V
Energy Star 6.1 compatible
ErP ready / Power in stand-by ( W)
OC P, OV P, U V P, S C P, O P P, OT P
Lifetime of PSU at 25°C (h)
Black-coated PSU case
No. of cables
Maximum cable length (cm)
Length of ATX-connection cable (cm)
CABLES
Sleeved cables
ATX motherboard (20+4-pin)
PCI express (6+2-pin)
P8-/P4-connector
S-ATA (5-pin)
CONNECTORS
P-ATA (4-pin)
600W 450W 350W 300W
BN209 BN208 BN207 BN206
4260052186015 4260052186008 4260052185995 4260052185988
200-240 / 50 200-240 / 50 200-240 / 50 200-240 / 50
140 x 150 x 86 140 x 150 x 86 140 x 150 x 86 140 x 150 x 86
/ / - / - / -
120 120 120 120
9.2 / 12.8 / 31.2 8.9 / 11 / 24 12.1 / 12.3 / 24.9 11.6 / 12.1 / 23.1
2 2 2 2
active active active active
®
80PLUS
Bronze 23 0V EU
internal / up to 89%
/
0.15
80PLUS® Bronze 23 0V EU
internal / up to 89%
/
0.15
80PLUS® 230V EU internal /
up to 87%
/
0.13
80PLUS® 230V EU internal /
up to 87%
100,000 100,000 100,000 100,000
- - -
5 5 5 4
95 95 85 85
55 55 45 45
- - -
2 2 1 -
1x P4+4 1x P4+4 1x P4+4 1x P4
6 6 4 4
2 2 2 2
/
0.13
Output Data »
SYST EM
POWE R B9
600W
SYST EM
POWE R B9
450W
AC Input 200–240Vac 5 0Hz 6A
DC Output 3.3V 5V 12V 1 12V 2 -12V 5VSB
Max. Current 24A 15A
Max. C om-
120 W 576W 3.6W 15W
bined Power
28A 22A
48A
600W
0.3A 3A
AC Input 200–240Vac 5 0Hz 4A
DC Output 3.3V 5V 12V 1 12V 2 -12V 5VSB
Max. Current 24A 15 A
Max. C om-
110W 420W 3.6W 15W
bined Power
23A 19A
35A
450W
0.3A 3A
SYST EM
POWE R B9
350W
SYST EM
POWE R B9
300W
AC Input 200–240Vac 5 0Hz 3A
DC Output 3.3V 5V 12V 1 12V 2 -12V 5VSB
Max. Current 19A 15A
Max. C om-
103W 324W 3.6W 12.5W
bined Power
20A 16A
27A
350W
0.3A 2.5A
AC Input 200 –240Vac 50Hz 2.5A
DC Output 3.3V 5V 12V 1 12V 2 -12V 5VSB
Max. Current 17A 15 A
Max. C om-
103W 276W 3.6W 12.5W
bined Power
18A 14A
23A
300W
0.3A 2.5A
Version: 01/2018
We do not take responsibility for typographical errors. Similar Image.
bequiet.com
Page 3
Cables »
4-pin
20-pin
Cable length to fi rst connector
600W 450W 350W 300W
24-pin
550mm 550mm 450mm 450mm
12V P4-connector
12V P4-connector
12V P4-connector
PCIe (6+2-pin)
150 mm
PCIe (6+2-pin)
S-ATA
S-ATA S-ATA
S-ATA
150mm 150mm 150mm
S-ATA HDD
S-ATA
S-ATA
12V P8connector
PCIe (6+2-pin)
HDD
S-ATA
600mm 600mm 450mm -
- - - 450mm
500mm 500mm - -
- - 450mm -
500mm 500mm 400mm 400mm
500mm 500mm -
- - 400mm 400mm
-
Dimensions (mm) »
150.0
86.0
Version: 01/2018
We do not take responsibility for typographical errors. Similar Image.
140.0
Certifi cations »
Contact »
Service Hotline: +49 40 7367 686 44 (Mo-Fr. 9:00-17:30)
Mail: [email protected]
bequiet.com
