Page 1
General Owner’s Information
Vehicle Identification Number (VIN):
Owner Name:
Address:
Phone:
General Owner’s Information
Your satisfaction is our #1 goal. If you
have questions or concerns about your
vehicle, we suggest you follow these
steps:
1. Contact your Sales Representative or
Service Advisor at your selling/servicing
dealership.
2. If the inquiry or concern remains
unresolved, contact the Sales Manager or
Service Manager at the dealership.
3. If the inquiry or concern cannot be
resolved at the dealership level, please
contact the Ford Customer Assistance
Center.
In the US, contact:
Ford Motor Company
Customer Assistance Center
16800 Executive Plaza Drive
P.O. Box 6248
Dearborn, Michigan 48126
1-800-392-3673 (FORD)
TDD for the hearing impaired:
1-800-232-5952
In Canada, contact:
Customer Assistance Center
Ford Motor Company of Canada,
Limited
P.O. Box 2000
Oakville, Ontario L6J 5E4
1-800-565-3673 (FORD)
Outside the US or Canada, contact:
Ford Motor Company
Worldwide Direct Market Operations
1555 Fairlane Drive
Allen Park, Michigan 48101 U.S.A.
Telephone: (313) 594-4857
Fax: (313) 390-0804
1
Page 2
Find Your Way
Table of Contents
General Owner’s Information ............ 1
Find Your Way .......................... 2
Find Your Way
General Maintenance Information ........ 4
Owner Checks and Services .............. 7
Normal Schedule ........................ 9
Mileage Intervals ................... 10
Exceptions ......................... 33
Special Operating Conditions ........... 35
Maintenance and Service Record ........ 37
All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by
any information storage and retrieval system or translation in whole or part is not permitted without written authorization
from Ford Motor Company.
CopyrightR1999 Ford Motor Company
2
Page 3
Symbol Key
Find Your Way
Find Your Way
Cars and Minivans
Light Trucks, Sport Utilities, and Vans
4x4 Vehicles
Diesel
Natural Gas Vehicles (NGV) and Propane
Towing a trailer or using a camper or car-top
carrier
Extensive idling and/or low-speed driving for long
distances as in heavy commercial use such as
delivery, taxi, patrol car or livery
Operating in dusty conditions such as unpaved or
dusty roads
Off-road operation
3
Page 4
General Maintenance Information
Why Maintain Your Vehicle?
This guide describes the scheduled maintenance required for your vehicle.
Carefully following this schedule helps protect against major repair expenses resulting
from neglect or inadequate maintenance and may also help to increase the
value of your vehicle when you sell or trade it.
It is your responsibilty to see that all scheduled maintenance is performed and
that the materials used meet Ford engineering specifications. Failure to perform
scheduled maintenance specific in this guide will invalidate warranty coverage
on parts affected by the lack of maintenance. Be sure receipts for completed
maintenance are kept with the vehicle and confirmation of the work
General Maintenance Information
performed is always recorded in this guide.
Your Ford or Lincoln Mercury dealer, or Ford or Lincoln Mercury Auto Care service
center has factory trained technicians who can perform the required
maintenance using genuine Ford parts. They are committed to meeting your
service needs and to assuring your continuing satisfaction.
Protecting Your Investment
Maintenance is an investment that will pay dividends in the form of improved
reliability, durability and resale value. To assure the proper performance of your
vehicle and its emission control systems, it is imperative that scheduled
maintenance be completed at the designated intervals.
Ford strongly recommends the use of genuine Ford replacement parts. Parts other
than Ford, Motorcraft or Ford authorized remanufactured parts that are used
for maintenance replacement or for the service of components affecting emission
control must be equivalent to genuine Ford Motor Company parts in
performance and durability. It is the owner’s responsibility to determine the
equivalency of such parts. Please consult your Warranty Guide for complete warranty
information.
4
Page 5
General Maintenance Information
PCV Valve Replacement
The PCV valve is a critical emission component. For the 2000 model year Ranger
light truck equipped with 2.5L 4 cylinder engine, the dealer will replace the
PCV valve free of charge at 60,000 miles except in Canada, on California certified
vehicles registered in California, and on California certified vehicles registered
in states that have adopted California standards. The valve should be replaced again
at 120,000 miles, but this will be at the owner’s expense.
For all passenger cars and light trucks under 6,000 Gross Vehicle Weight (GVW),
regardless of engine the PCV valve should be replaced at 100,000 miles.
This replacement will be at the owner’s expense.
For all light trucks over 6,000 GVW, regardless of engine, the PCV valve should
be replaced at 120,000 miles. This replacement will be at the owner’s
expense.
If you are unsure about your engine type or GVW ask your dealer.
Which Maintenance Schedule Should You
Follow?
General Maintenance Information
Normal Schedule
The Normal Schedule applies to those who operate their vehicle under typical,
everyday driving conditions. The maintenance frequency represented in this schedule
typifies what the vast majority of vehicle operators will require. The listed
services should be performed at specified mileage intervals.
5
Page 6
General Maintenance Information
Special Operating Conditions
If you operate your Ford/Lincoln/Mercury primarily in one of the more
demanding “Special Operating Conditions” listed below, you will need to
have some items maintained more frequently, see page 35. If you only occasionally
operate your vehicle under these conditions, it is not necessary to perform the
additional maintenance. For specific recommendations, see your dealership service
advisor or qualified service professional.
These special operating conditions are:
• Towing or carrying heavy loads
• Extensive idling and/or driving at low-speeds for long distances
General Maintenance Information
• Driving in dusty conditions
• Off-road operation
Exceptions
In addition, there are several exceptions to the Normal Schedule for specific
vehicles or special applications on page 33.
These exceptions are:
• Natural Gas Vehicles - replace the gas tank(s)
• Class A Motorhome - change the brake fluid
• Normal vehicle axle - maintenance and lubrication
• Police and Taxi vehicle axles - maintenance and lubrication
If you have any questions about your driving conditions, or for further
clarification, please see your dealer.
6
Page 7
Owner Checks and Services
Refer to Mileage Intervals for Additional
Checks and Services
Certain basic maintenance checks and inspections should be performed by the
owner or a service technician at the intervals indicated. Service information and
supporting specifications are provided in the Owner’s Guide.
Any adverse condition should be brought to the attention of your dealer or
qualified service technician as soon as possible for the proper service advice. The
owner maintenance service checks are generally not covered by warranties so
you may be charged for labor, parts or lubricants used.
Owner Checks and Services
✔
Check Every Month for All Vehicles:
O Check function of all interior and exterior lights
O Check tires for wear and proper air pressure
O Check engine oil fluid level
O Check windshield washer solvent fluid level
Check and drain fuel/water separator (diesel vehicles)
O
7
Page 8
Owner Checks and Services
Owner Checks and Services
✔
✔
Check Every Six Months for All Vehicles:
O Check lap/shoulder belts and seat latches for wear and function
O Check air pressure in spare tire
O Check power steering fluid level
O Check washer spray, wiper operation, and clean all wiper blades
O Check parking brake for proper operation
O Check and lubricate all hinges, latches and outside locks
O Check and lubricate door rubber weatherstrips
O Check and clean body and door drain holes
O Check safety warning lamps (brake, ABS, air bag, safety belt) for operation
O Check cooling system fluid level and coolant strength
O Check battery water level (non-maintenance free)
O Check battery connections and clean if necessary
O Check clutch fluid level, if equipped
Every 5,000 miles
O Adjust clutch by lifting pedal (manual transmission Mustang only)
8
Page 9
Normal Schedule
The following section contains the “Normal Schedule.” This schedule is presented
at specific mileage intervals with exceptions noted. In addition, those items
listed in italic type are additional services that only the noted vehicles require.
Additional Information Available on the Web
To learn more about the importance of routine and dealer-performed maintenance
on your vehicle, please visit the Ford Customer Service website. You’ll also
find important warranty information, customer assistance, technical expertise,
frequently asked questions and much more. The website location is at:
www.ford.com/customerservice/
Normal Schedule
9
Page 10
5,000 miles
Normal Schedule
O Change engine oil and replace oil filter
O Inspect tires for wear and rotate
O Check air filter minder, replace filter as required
10,000 miles
Normal Schedule
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
Additional services for: Diesel
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
10
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
Additional services for: Diesel
O Check air filter minder, replace filter as required
Page 11
Normal Schedule
15,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect automatic transmission fluid level, if equipped with dipstick
O Inspect brake pads/shoes/rotors/drums, brake lines & hoses, and parking brake
system
O Inspect engine cooling system and hoses
O Inspect steering linkage, suspension, and if equipped driveshaft and ball joints
O Inspect tires for wear and rotate
O Replace cabin air filter, if equipped
Additional services for: Light Trucks,
Sport Utilities, and Vans
O Inspect and lubricate 4X2 ball joints (except F-450/F-550)
O
Inspect and lubricate steering linkage (E and F Series, Expedition, Navigator,
Excursion)
Normal Schedule
Additional services for: Diesel
O Check air filter minder, replace filter as required
O Replace fuel filter
O Add 8 to 10 oz. of FW16 coolant conditioner to cooling system
11
Page 12
20,000 miles
Normal Schedule
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
O Check air filter minder, replace filter as required
25,000 miles
Normal Schedule
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
Additional services for: Diesel
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
12
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
Additional services for: Diesel
O Check air filter minder, replace filter as required
Page 13
Normal Schedule
30,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect brake pads/shoes/rotors/drums, brake lines & hoses, and parking brake
system
O Inspect engine cooling system and hoses
O Inspect exhaust system and heat shields
O Inspect steering linkage, suspension, and if equipped driveshaft and ball joints
O Inspect tires for wear and rotate
O Replace engine air filter
O Replace fuel filter
O Replace cabin air filter, if equipped
Inspect accessory drive belt(s) (Villager)
O
O
Change automatic transmission/transaxle fluid on all vehicles equipped with AX4S,
AX4N, 4R70W, 4R100, 4F27E. Inspect automatic transmission fluid level on all
other vehicles, if equipped with dipstick. Consult your dealer for your particular
requirements.
O
Replace climate-controlled seat filters (Navigator, if equipped)
*
Normal Schedule
Additional services for: Light Trucks,
Sport Utilities, and Vans
O Inspect and lubricate 4X2 ball joints (except F-450/F-550)
O
Inspect and lubricate steering linkage (E and F Series, Expedition, Navigator,
Excursion)
*
If vehicle is registered in California, the California Air Resources Board has determined that the failure to perform this
maintenance item will not nullify the emission warranty or limit recall liability prior to the completion of the vehicle’s useful
life. We, however, urge that all recommended maintenance services be performed at the indicated intervals and the
maintenance be recorded.
13
Page 14
O Check air filter minder, replace filter as required
O Replace fuel filter
O Add 8 to 10 oz. of FW16 coolant conditioner to cooling system
Normal Schedule
O Inspect NGV tanks
35,000 miles
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
Normal Schedule
Additional services for: Diesel
Additional services for: Natural Gas Vehicles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
14
Additional services for: Diesel
O Check air filter minder, replace filter as required
Page 15
Normal Schedule
40,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
Additional services for: Diesel
O Check air filter minder, replace filter as required
45,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
Normal Schedule
O Change engine oil and replace oil filter
O Inspect automatic transmission fluid level, if equipped with dipstick
O Inspect brake pads/shoes/rotors/drums, brake lines & hoses, and parking brake
system
O Inspect engine cooling system and hoses
O Inspect steering linkage, suspension, and if equipped driveshaft and ball joints
O Inspect tires for wear and rotate
O Replace cabin air filter, if equipped
O Change green engine coolant, if equipped
15
Page 16
O Inspect and lubricate 4X2 ball joints (except F-450/F-550)
Normal Schedule
O
O Check air filter minder, replace filter as required
O Replace fuel filter
O Add 8 to 10 oz. of FW16 coolant conditioner to cooling system
50,000 miles
Normal Schedule
Additional services for: Light Trucks,
Sport Utilities, and Vans
Inspect and lubricate steering linkage (E and F Series, Expedition, Navigator,
Excursion)
Additional services for: Diesel
16
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
Additional services for: Diesel
O Check air filter minder, replace filter as required
Page 17
Normal Schedule
55,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
Additional services for: Diesel
O Check air filter minder, replace filter as required
60,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
Normal Schedule
O Change engine oil and replace oil filter
O Inspect brake pads/shoes/rotors/drums, brake lines & hoses, and parking brake
system
O Inspect engine cooling system and hoses
O Inspect exhaust system and heat shields
O Inspect steering linkage, suspension, and if equipped driveshaft and ball joints
O Inspect tires for wear and rotate
O Replace engine air filter
17
Page 18
Normal Schedule
O Replace fuel filter
O Replace cabin air filter, if equipped
O
O
Normal Schedule
O
O
O Inspect and lubricate 4X2 ball joints (except F-450/F-550)
O Lubricate 4X2 wheel bearings, replace grease seals, and adjust bearings
O Change manual transmission fluid
O
*
Inspect drive belt (Villager)
Replace PCV valve (All 4 cylinder Ranger light trucks. See page 5.)
Change automatic transmission/transaxle fluid on all vehicles equipped with AX4S,
AX4N, 4R70W, 4R100, 4F27E. Inspect automatic transmission fluid level on all
other vehicles, if equipped with dipstick. Consult your dealer for your particular
requirements.
Replace climate-controlled seat filters (Navigator, if equipped)
Additional services for: Light Trucks,
Sport Utilities, and Vans
Inspect and lubricate steering linkage (E and F Series, Expedition, Navigator,
Excursion)
Additional services for: Diesel
O Check air filter minder, replace filter as required
O Replace fuel filter
O Add 8 to 10 oz. of FW16 coolant conditioner to cooling system
*
If vehicle is registered in California, the California Air Resources Board has determined that the failure to perform this
maintenance item will not nullify the emission warranty or limit recall liability prior to the completion of the vehicle’s useful
life. We, however, urge that all recommended maintenance services be performed at the indicated intervals and the
maintenance be recorded.
18
Page 19
Normal Schedule
Additional services for: Natural Gas Vehicles
O Inspect NGV tanks
65,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
Additional services for: Diesel
Normal Schedule
O Check air filter minder, replace filter as required
70,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
19
Page 20
O Check air filter minder, replace filter as required
Normal Schedule
75,000 miles
O Change engine oil and replace oil filter
O Inspect automatic transmission fluid level, if equipped with dipstick
O Inspect brake pads/shoes/rotors/drums, brake lines & hoses, and parking brake
O Inspect engine cooling system and hoses
O Inspect steering linkage, suspension, and if equipped driveshaft and ball joints
O Inspect tires for wear and rotate
O Replace cabin air filter, if equipped
O Change green engine coolant, if equipped
Normal Schedule
Additional services for: Diesel
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
system
20
Additional services for: Light Trucks,
Sport Utilities, and Vans
O Inspect and lubricate 4X2 ball joints (except F-450/F-550)
Inspect and lubricate steering linkage (E and F Series, Expedition, Navigator,
O
Excursion)
Page 21
Normal Schedule
Additional services for: Diesel
O Check air filter minder, replace filter as required
O Replace fuel filter
O Add 8 to 10 oz. of FW16 coolant conditioner to cooling system
80,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
Additional services for: Diesel
Normal Schedule
O Check air filter minder, replace filter as required
85,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
21
Page 22
Normal Schedule
Additional services for: Diesel
O Check air filter minder, replace filter as required
Normal Schedule
90,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect brake pads/shoes/rotors/drums, brake lines & hoses, and parking brake
system
O Inspect engine cooling system and hoses
O Inspect exhaust system and heat shields
O Inspect steering linkage, suspension, and if equipped driveshaft and ball joints
O Inspect tires for wear and rotate
O Replace engine air filter
O Replace fuel filter
O Replace cabin air filter, if equipped
Inspect drive belt (Villager)
O
O
Change automatic transmission/transaxle fluid on all vehicles equipped with AX4S,
AX4N, 4R70W, 4R100, 4F27E. Inspect automatic transmission fluid level on all
other vehicles, if equipped with dipstick. Consult your dealer for your particular
requirements.
O
Replace climate-controlled seat filters (Navigator, if equipped)
*
If vehicle is registered in California, the California Air Resources Board has determined that the failure to perform this
maintenance item will not nullify the emission warranty or limit recall liability prior to the completion of the vehicle’s useful
life. We, however, urge that all recommended maintenance services be performed at the indicated intervals and the
maintenance be recorded.
22
*
Page 23
Normal Schedule
Additional services for: Light Trucks,
Sport Utilities, and Vans
O Inspect and lubricate 4X2 ball joints (except F-450/F-550)
O
Inspect and lubricate steering linkage (E and F Series, Expedition, Navigator,
Excursion)
Additional services for: Diesel
O Check air filter minder, replace filter as required
O Replace fuel filter
O Add 8 to 10 oz. of FW16 coolant conditioner to cooling system
Additional services for: Natural Gas Vehicles
O Inspect NGV tanks
Normal Schedule
95,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
23
Page 24
O Check air filter minder, replace filter as required
Normal Schedule
100,000 miles
O Change engine oil and replace oil filter
O Inspect accessory drive belt(s)
O Inspect tires for wear. Rotation recommended for optimal tire life.
O Replace spark plugs
O
Normal Schedule
Additional services for: Diesel
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
Replace the PCV on all passenger cars and light trucks under 6,000 Gross Vehicle
Weight. (See page 5.)
24
Additional services for: Diesel
O Check air filter minder, replace filter as required
Page 25
Normal Schedule
105,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect automatic transmission fluid level, if equipped with dipstick
O Inspect brake pads/shoes/rotors/drums, brake lines & hoses, and parking brake
system
O Inspect engine cooling system and hoses
O Inspect steering linkage, suspension, and if equipped driveshaft and ball joints
O Inspect tires for wear and rotate
O Replace cabin air filter, if equipped
O Change green engine coolant, if equipped
Replace camshaft belt (Villager)
O
Normal Schedule
Additional services for: Light Trucks,
Sport Utilities, and Vans
O Inspect and lubricate 4X2 ball joints (except F-450/F-550)
Inspect and lubricate steering linkage (E and F Series, Expedition, Navigator,
O
Excursion)
Additional services for: Diesel
O Check air filter minder, replace filter as required
O Replace fuel filter
O Add 8 to 10 oz. of FW16 coolant conditioner to cooling system
25
Page 26
110,000 miles
Normal Schedule
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
O Check air filter minder, replace filter as required
115,000 miles
Normal Schedule
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
Additional services for: Diesel
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
26
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
Additional services for: Diesel
O Check air filter minder, replace filter as required
Page 27
Normal Schedule
120,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect brake pads/shoes/rotors/drums, brake lines & hoses, and parking brake
system
O Inspect engine cooling system and hoses
O Inspect exhaust system and heat shields
O Inspect steering linkage, suspension, and if equipped driveshaft and ball joints
O Inspect tires for wear and rotate
O Replace engine air filter
O Replace fuel filter
O Replace cabin air filter, if equipped
Inspect drive belt (Villager)
O
O
Replace PCV valve on all light trucks over 6,000 Gross Vehicle Weight and
Rangers with 4 cylinder engines. (See page 5.)
O
Change automatic transmission/transaxle fluid on all vehicles equipped with AX4S,
AX4N, 4R70W, 4R100, 4F27E. Inspect automatic transmission fluid level on all other
vehicles, if equipped with dipstick. Consult your dealer for your particular
requirements.
O
Inspect camshaft belt on all 2.0L, 4 cylinder engines (Escort, Tracer, Contour,
Mystique, Cougar, and ZX2)
O
Replace climate-controlled seat filters (Navigator, if equipped)
*
Normal Schedule
*
If vehicle is registered in California, the California Air Resources Board has determined that the failure to perform this
maintenance item will not nullify the emission warranty or limit recall liability prior to the completion of the vehicle’s useful
life. We, however, urge that all recommended maintenance services be performed at the indicated intervals and the
maintenance be recorded.
27
Page 28
O Change manual transmission fluid
Normal Schedule
O Lubricate 4X2 wheel bearings (except F-450/F-550)
O Inspect and lubricate 4X2 ball joints (except F-450/F-550)
O
O
O Check air filter minder, replace filter as required
O Replace fuel filter
O Add 8 to 10 oz. of FW16 coolant conditioner to cooling system
Normal Schedule
Additional services for: Light Trucks,
Sport Utilities, and Vans
Inspect camshaft belt on 4 cylinder engine (2.5L Ranger)
Inspect and lubricate steering linkage (E and F Series, Expedition, Navigator,
Excursion)
Additional services for: Diesel
Additional services for: Natural Gas Vehicles
28
O Drain coalescent fuel filter bowl and replace filter
O Inspect NGV tanks
125,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
Page 29
Normal Schedule
Additional services for: Diesel
O Check air filter minder, replace filter as required
130,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
Additional services for: Diesel
O Check air filter minder, replace filter as required
Normal Schedule
135,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect automatic transmission fluid level, if equipped with dipstick
O Inspect brake pads/shoes/rotors/drums, brake lines & hoses, and parking brake
system
29
Page 30
O Inspect engine cooling system and hoses
O Inspect steering linkage, suspension, and if equipped driveshaft and ball joints
O Inspect tires for wear and rotate
O Replace cabin air filter, if equipped
Normal Schedule
O Replace green engine coolant, if equipped
O Inspect and lubricate 4X2 ball joints (except F-450/F-550)
O
O Check air filter minder, replace filter as required
O Replace fuel filter
O Add 8 to 10 oz. of FW16 coolant conditioner to cooling system
Normal Schedule
Additional services for: Light Trucks,
Sport Utilities, and Vans
Inspect and lubricate steering linkage (E and F Series, Expedition, Navigator,
Excursion)
Additional services for: Diesel
30
140,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
Page 31
Normal Schedule
Additional services for: Diesel
O Check air filter minder, replace filter as required
145,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect tires for wear. Rotation recommended for optimal tire life.
Additional services for: Diesel
O Check air filter minder, replace filter as required
Normal Schedule
150,000 miles
Cars, Minivans, Light Trucks, Sport Utilities,
Vans, 4x4, Natural Gas, Propane, and Diesel
Vehicles
O Change engine oil and replace oil filter
O Inspect brake pads/shoes/rotors/drums, brake lines & hoses, and parking brake
system
O Inspect engine cooling system and hoses
31
Page 32
O Inspect exhaust system and heat shields
O Inspect steering linkage, suspension, and if equipped driveshaft and ball joints
O Inspect tires for wear and rotate
O Replace engine air filter
Normal Schedule
O Replace fuel filter
O Replace cabin air filter, if equipped
O Replace orange engine coolant, if equipped
O Change automatic transmission/transaxle fluid and filter
O
O
O
O Inspect and lubricate 4X2 ball joints (except F-450/F-550)
O Replace 4x2 wheel bearings, grease seals, lubricate and adjust bearings
O
Normal Schedule
*
Replace rear axle lubricant on all rear wheel drive (RWD) vehicles.
Inspect drive belt (Villager)
Replace climate-controlled seat filters (Navigator, if equipped)
Additional services for: Light Trucks,
Sport Utilities, and Vans
Inspect and lubricate steering linkage (E and F Series, Expedition, Navigator,
Excursion)
Additional services for: 4x4 Vehicles
O Change front axle lubricant
O Change transfer case fluid
Additional services for: Diesel
O Check air filter minder, replace filter as required
O Replace fuel filter
O Add 8 to 10 oz. of FW16 coolant conditioner to cooling system
*
If vehicle is registered in California, the California Air Resources Board has determined that the failure to perform this
maintenance item will not nullify the emission warranty or limit recall liability prior to the completion of the vehicle’s useful
life. We, however, urge that all recommended maintenance services be performed at the indicated intervals and the
maintenance be recorded.
32
Page 33
Normal Schedule
Additional services for: Natural Gas Vehicles
O Inspect NGV tanks
Exceptions
In addition, there are several exceptions to the Normal Schedule. They are listed below:
Natural Gas and Propane Vehicles
O Every 15 years - Replace NGV or propane fuel tank(s)
Class A Motorhome
O Every two years - Change brake fluid
O Every 30,000 miles - Change automatic transmission fluid
Normal Schedule
Normal Vehicle Axle Maintenance
O Rear axles containing synthetic lubricant and light duty trucks equipped with
Ford-design axles are lubricated for life. These lubricants are not to be checked
or changed unless a leak is suspected, service is required or the axle
assembly has been submerged in water. The axle lubricant should be changed
anytime the axle has been submerged in water.
Non-synthetic rear axle lubricants should be replaced every 3,000 miles or
3 months, whichever occurs first, during extended trailer tow operation above
21 Celsius (70 degrees Fahrenheit) ambient and wide open throttle for extended
periods above 45 mph. The 3,000 mile lube change interval may be waived
33
Page 34
Normal Schedule
O Replace rear axle lubricant every 160,000 km (100,000 miles). Rear axle
Normal Schedule
if the axle was filled with 75W140 synthetic gear lubricant meeting Ford
specification WSL-M2C192-A, part number F1TZ-19580-B or equivalent. Add four
ounces of additive friction modifier C8AZ-19B546-A (EST-M2C118-A) or
equivalent for complete refill of Traction-Lok rear axles. The rear axle lubricant
should be changed anytime the axle has been submerged in water.
Police and Taxi Vehicle Axle Maintenance
lubricant change may be waived if the axle was filled with 75W140 synthetic
gear lubricant meeting Ford specification WSL-M2C192-A, part number FITZ-19580-B
or equivalent. Add four ounces of additive friction modifier C8AZ-19B546-A
(EST-M2C118-A) or equivalent for complete refill of Traction-Lok rear axles. The
rear axle lubricant should be changed anytime the axle has been
submerged in water.
34
F-450 and F-550 Axle Maintenance
O Replace rear axle lubricant every 100,000 miles under normal driving conditions
on all F-450 and F-550 commercial applictions. For F-450 and F-550 trucks
operated at or near maximum Gross Vehicle Weight Ratings, the rear axle lubricant
should be replaced every 50,000 miles. In addition, this 50,000 mile schedule
should be observed when the vehicles are operated under the Special Operating
Conditions, where noted, beginning on page 36.
Page 35
Special Operating Conditions
Items Needing Special Attention
If you operate your Ford/Lincoln/Mercury primarily in one of the more
demanding “Special Operating Conditions” listed below, you will need to
have some items maintained more frequently. If you only occasionally operate
your vehicle under these conditions, it is not necessary to perform the
additional maintenance. For specific recommendations, see your dealership service
advisor or qualified service professional.
Towing a trailer or using a camper or car-top carrier
Every 3,000 miles or 3 months Change engine oil and replace oil filter
Every 30,000 miles Change automatic transmission fluid
Every 60,000 miles Change transfer case fluid
As required Change manual transmission fluid
As required Inspect and lubricate U-joints
Extensive idling and/or low-speed driving for long distances as in heavy
commercial use such as delivery, taxi, patrol car or livery
Special Operating Conditions
Every 3,000 miles or 3 months Change engine oil and replace oil filter
Lube front lower control arm ball joints with zerk
fittings, if equipped
Every 5,000 miles Inspect brake system
Every 15,000 miles Replace fuel filter
Every 30,000 miles Change automatic transmission fluid
Lubricate 4x2 wheel bearings, replace grease seals, and
adjust bearings
Every 60,000 miles Replace spark plugs
Change transfer case fluid
As required Replace cabin air filter
35
Page 36
Special Operating Conditions
Operating in dusty conditions such as unpaved or dusty roads
Every 3,000 miles or 3 months Change engine oil and replace oil filter
Every 15,000 miles Replace fuel filter
Every 30,000 miles Change automatic transmission fluid
Every 50,000 miles Change rear axle lubricant (F-450 and F-550 only)
Special Operating Conditions
Every 60,000 miles Change transfer case fluid
As required Replace engine air filter
As required Replace cabin air filter
Off-road operation
Every 30,000 miles Change automatic transmission fluid
Every 50,000 miles Change rear axle lubricant (F-450 and F-550 only)
Every 60,000 miles Change transfer case fluid
As required Replace cabin air-filter
As required Inspect and lubricate U-joints
36
Page 37
Maintenance and Service Record
See An Authorized Dealer
This section of the guide is designed to allow your Ford or Lincoln Mercury
dealer, or Ford or Lincoln Mercury Auto Care service center or other qualified service
technician to record that the recommended service was completed at the
appropriate mileage intervals. Be sure to ask your service provider to record the
type of service rendered (Normal or Special Operating Conditions — SOC)
each time service is performed.
Maintenance and Service Record
Date:
Mileage:
Normal
n
SOC n
See corresponding mileage in maintenance schedule for services performed.
Date:
Mileage:
Normal
n
SOC n
See corresponding mileage in maintenance schedule for services performed.
Date:
Mileage:
Normal
n
SOC n
Dealer’s Stamp:
Dealer’s Stamp:
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
37
Page 38
Maintenance and Service Record
Date:
Mileage:
Normal
SOC n
Date:
Mileage:
Normal
Maintenance and Service Record
SOC n
Date:
Mileage:
Normal
SOC n
Dealer’s Stamp:
n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
n
38
Date:
Mileage:
Normal
n
SOC n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Page 39
Date:
Mileage:
Normal
n
SOC n
Maintenance and Service Record
Maintenance and Service Record
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Date:
Mileage:
Normal
n
SOC n
Date:
Mileage:
Normal
n
SOC n
Date:
Mileage:
Normal
n
SOC n
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
39
Page 40
Maintenance and Service Record
Date:
Mileage:
Normal
SOC n
Date:
Mileage:
Normal
Maintenance and Service Record
SOC n
Date:
Mileage:
Normal
SOC n
Dealer’s Stamp:
n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
n
40
Date:
Mileage:
Normal
n
SOC n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Page 41
Date:
Mileage:
Normal
n
SOC n
Maintenance and Service Record
Maintenance and Service Record
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Date:
Mileage:
Normal
n
SOC n
Date:
Mileage:
Normal
n
SOC n
Date:
Mileage:
Normal
n
SOC n
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
41
Page 42
Maintenance and Service Record
Date:
Mileage:
Normal
SOC n
Date:
Mileage:
Normal
Maintenance and Service Record
SOC n
Date:
Mileage:
Normal
SOC n
Dealer’s Stamp:
n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
n
42
Date:
Mileage:
Normal
n
SOC n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Page 43
Date:
Mileage:
Normal
n
SOC n
Maintenance and Service Record
Maintenance and Service Record
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Date:
Mileage:
Normal
n
SOC n
Date:
Mileage:
Normal
n
SOC n
Date:
Mileage:
Normal
n
SOC n
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
43
Page 44
Maintenance and Service Record
Date:
Mileage:
Normal
SOC n
Date:
Mileage:
Normal
Maintenance and Service Record
SOC n
Date:
Mileage:
Normal
SOC n
Dealer’s Stamp:
n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
n
44
Date:
Mileage:
Normal
n
SOC n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Page 45
Date:
Mileage:
Normal
n
SOC n
Maintenance and Service Record
Maintenance and Service Record
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Date:
Mileage:
Normal
n
SOC n
Date:
Mileage:
Normal
n
SOC n
Date:
Mileage:
Normal
n
SOC n
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
45
Page 46
Maintenance and Service Record
Date:
Mileage:
Normal
SOC n
Date:
Mileage:
Normal
Maintenance and Service Record
SOC n
Date:
Mileage:
Normal
SOC n
Dealer’s Stamp:
n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
n
46
Date:
Mileage:
Normal
n
SOC n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Page 47
Date:
Mileage:
Normal
n
SOC n
Maintenance and Service Record
Maintenance and Service Record
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Date:
Mileage:
Normal
n
SOC n
Date:
Mileage:
Normal
n
SOC n
Date:
Mileage:
Normal
n
SOC n
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
47
Page 48
Maintenance and Service Record
Date:
Mileage:
Normal
SOC n
Date:
Mileage:
Normal
Maintenance and Service Record
SOC n
Date:
Mileage:
Normal
SOC n
Dealer’s Stamp:
n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
n
48
Date:
Mileage:
Normal
n
SOC n
See corresponding mileage in maintenance schedule for services performed.
Dealer’s Stamp:
See corresponding mileage in maintenance schedule for services performed.
Loading...
