BenQ PW02 User Manual

Virtual Interactive Whiteboard

PointWrite PW02 module

Model name PW02

Compatible projector BenQ 0.6ST series model

Technology Infrared

Multi pen supported Up to 4 Pens

Response time 0.016Sec

Refresh Rate 60 Frames/Sec

Calibration Auto/ Manual

Connection to PC USB 2.0

Power supply 5V 500mA, USB Power/Type mini B

Power consumption Max 250mA

Working area Max 150" projection size.

USB cable distance Max 15meter (5meter USB cable + Repeater)

Dimension 71*29*86.3mm

Weight 32g

PointWrite Pen

Battery type 1.5v 3A Battery x2

Dimension 153mm(L) x 14.5mm(R)

Weight 80g(Battery included)

Packing

PointWrite module *1, PointWrite Pen *2, screw *2(fix to Projector),

AAA battery *4, , alternative pen nib*5 ,USB cable *1(5m, minB to A), CD*1(UM,

PointWrite, Qwrite,Qplayer), Quick installation quide*1, Wrist strip*2

QSG(21 languages)

Arabic, Czech, German, English, European Spanish, European French, Italian, Japanese,

Korean, Dutch, Polish, European Portuguese, Russian, Simplified Chinese, Swedish,

Traditional Chinese, Thai, Turkish, Finnish, Norwegian, Romanian.

User's manual(26 languages)

Arabic, Czech, German, English, European Spanish, European French, Italian, Japanese,

Korean, Dutch, Polish, European Portuguese, Russian, Simplified Chinese, Swedish,

Traditional Chinese, Thai, Turkish, Bulgarian, Greek, Croatian, Hungarian, Indonesian,

Romanian, Finnish, Norwegian

PointWrite

* the speed of auto calibration will depends on CPU power of computer

Key features

• Supports up to 4 pens/fingers writing simultaneously

• Dual screen tuoch for ultra wide working space.

• Effortless setup with only 1 second auto calibration*

• An ultra-fast 0.016-second response time for a smooth writing experience

• Optional finger touch capability

• Win8 gesture and multitouch supported.

Software information

Calibration software

Interactive software

Windows XP, Vista, Win7, Win8, Win8.1

MAC OSX 10.6, 10.7, 10.8, 10.9

Linux ubunto

10.4, 12.04, 14.04 *Touch function dose not

Languages supported(21)

Certification.

Purchase information

PointWrite Virtual Interactive Whiteboard

software

connection

dimension

**QWrite will be simple version in Mac and Linux.

English, Japanese, Simple Chinese, Traditional Chinese, Danish, German, European Spanish,

European French, Italian, Bulgarian Polish Portuguese Persian Russian Indonesian Korean Czech,

Finnish, Norwegian, Swedish,Romanian

CPU: Pentium/ RAM: 512MB/ Hard Disk: 20MB/ USB: USB 2.0

CE/FCC/IC/BSMI/KCC

Operating system supported
Min. system requirements

PontWrite kit (10kit/Carton)

PN: 5J.J9A26.12E

PontWrite Pen only (20Pen/Carton)

PN: 5J.J9A26.001
Pen*1, Wrist strip*1, Pen nib*5, AAA Battery*2

86.3mm

29mm

15.5mm

71mm

PointWrite

QWrite

Q

QPlayer
