Benq HT4050 User Manual

Projection dimensions

Floor Installation Ceiling Installation

<A>

<B>

<F>

<G>

<A>

<B>

<E>

<D>

<C>

<F>: Screen <G>: Center of lens

<E>

<D>

<C>

<F>: Screen <G>: Center of lens

The screen aspect ratio is 16:9 and the projected picture is 16:9.

Screen dimensions Projection distance <D> [mm]

Diagonal <A>

[inch (mm)]

36.4
40
50
60
70
80
90

100
110
120
130
140
150
160
170
180
190

196.4

(925)
(1016)
(1270)
(1524)
(1778)
(2032)
(2286)
(2540)
(2794)
(3048)
(3302)
(3556)
(3810)
(4064)
(4318)
(4572)
(4826)
(4989)

Height

<B>

[mm]

454
498
623
747
872

996
1121
1245
1370
1494
1619
1743
1868
1992
2117
2241
2366
2446

Width

<C>

[mm]

806

886
1107
1328
1550
1771
1992
2214
2435
2657
2878
3099
3321
3542
3763
3985
4206
4348

Min distance

(with max zoom)

-

1018
1273
1528
1782
2037
2291
2546
2800
3055
3310
3564
3819
4073
4328
4583
4837
5000

avg

(with min zoom)

-

1333
1666
1999
2332
2665
2999
3332
3665
3998
4331
4664
4998
5331
5664
5997
6330

-

Max

distance

1500
1647
2059
2471
2882
3294
3706
4118
4529
4941
5353
5765
6177
6588
7000
7412
7824

-

<G>

<F>

Lowest/

Highest

lens position

<E>[mm]

(min.) (max.)

68
75

93
112
131
149
168
187
205
224
243
262
280
299
318
336
355
367

125
137
171
205
240
274
308
342
377
411
445
479
514
548
582
616
651
673

The above numbers are approximate and may be slightly different from the actual
measurements. Only the recommended screen sizes are listed.
If your screen size is not in the table above, please contact your dealer for assistance.
