BenQ EL71 User Guide
EL71
0
Table of Contents
Phone overview ..................................1
Safety precautions ............................. 2
Getting started ...................................4
Inserting battery/SIM card/
MicroSD card ...................................4
Charging the battery ........................5
Entering the PIN ............................... 5
Emergency number (SOS) ................5
General instructions ...........................6
User guide .......................................6
Slider ...............................................6
Main menu ......................................6
Centre key .......................................6
Navigation keys ...............................6
Tabs ................................................7
Mark mode ......................................7
Digital Rights Mgmt. (DRM) .............. 7
PIN, PUK, Phonecode .......................... 7
Text input with T9 .............................. 8
Calling ................................................ 9
Last number redial ........................... 9
Call options ...................................10
Direct call ......................................10
Contacts ...........................................10
All contacts ....................................10
Groups ..........................................11
Distribution list ..............................11
SIM ................................................11
Online status .................................11
Filter ..............................................11
General functions ..........................11
Call records .......................................11
Durat./charges ...............................11
Camera .............................................12
Take a picture ................................12
Record video ..................................12
Flash .............................................12
SMS ...................................................13
MMS .................................................13
Voice mailbox ...................................15
Internet ............................................ 16
Settings ............................................ 17
Profiles .......................................... 17
Ringtones ...................................... 17
Themes ......................................... 17
Display .......................................... 17
Vibration ....................................... 17
Connectivity .................................. 17
Shortcuts ...................................... 17
Call settings .................................. 18
Phone settings .............................. 18
Clock ............................................. 18
Security ......................................... 18
Network ........................................ 18
Accessories ................................... 18
Organiser ......................................... 19
Calendar ....................................... 19
Appointments ............................... 19
Tasks ............................................. 19
Notes ............................................ 19
Dictat.machine .............................. 19
Time zones .................................... 19
Remote synchronisation ................ 19
Extras ............................................... 19
SIM services (optional) .................. 19
My applications ............................. 19
Online status ................................. 19
Sound recorder ............................. 20
My menu ...................................... 20
Alarm clock ...................................... 20
Media player .................................... 20
My stuff ............................................ 21
Mobile Phone Manager ................... 22
Customer Care ................................. 22
Care and maintenance ..................... 23
Product data ..................................... 24
SAR ................................................... 25
Guarantee certificate (UK) ............... 25
Guarantee certificate (IRL) ............... 26
Licence Agreement .......................... 27
This is a summarised version of the User Guide. The complete
version can be found on the Internet at this address:
www.BenQ-Siemens.com/el71
Phone overview
1 Loudspeaker
2 Standby indicator LED
LED indicates that the phone is still on, when
phone display is switched off.
3 Status indicator line
4 x Fast dialling key (p. 17)
5
Camera key
X
6 [ / \ Volume control
7 Plug socket
8
Softkeys
The current functions of these keys are
§text§/ symbols (e.g.
shown as
9 ACall key
Dial displayed/highlighted phone
numbers/names, accepts calls.
= BOn/Off/End key
• During a conversation or in an application:
press briefly to end.
• In menus: return to standby mode.
• In standby mode, slider closed:
Press briefly to lock keypad. Press
briefly and confirm with
the keypad.
! ?Media player key
Key for activating the media player.
" @Play/Pause key
§ Centre key
Press the centre key to open the main menu
and to start an application or function (p. 6).
$ Navigation keys (p. 6)
%
Ringtone
*
• Press and hold in standby mode:
switch all acoustic signals on/off
(except alarm clock).
• Press and hold during incoming call:
switch off ringtone for this call only.
p
§OK§ to unlock
Phone overview
¨
Key lock
#
• Press and hold in standby mode:
activate/deactivate key lock.
1
© Camera lens
ª Flash/torch
Press and hold to switch torch on/off.
X
á £ ß
).
28.04.2006 10:10
Service provider
InboxíMy menu
2
Safety precautions
Safety precautions
Information for parents
Please read the operating instructions and safety precautions carefully before use.
Explain the content and the hazards associated with using the phone to your children.
Remember to comply with legal requirements and local restrictions
when using the phone. For example
in aeroplanes, petrol stations, hospitals or whilst driving.
Mobile phones can interfere with the
functioning of medical devices such
as hearing aids or pacemakers.
Keep a distance of at least 20cm/
9 inches between the phone and
pacemaker. Whilst using the mobile
phone, hold it to the ear furthest
away from the pacemaker. For more
information consult your doctor.
Tones, music and handsfree talking
are reproduced through the loudspeaker. Do not hold the phone to
your ear when it rings or when you
have switched on the handsfree
function. Otherwise you risk serious
permanent damage to your hearing.
Only use original batteries (100 %
mercury-free) and – charging devices. Otherwise you risk serious damage to health and property. For
instance, the battery may explode.
Small parts such as the SIM card,
dust cap, lens ring and lens cap can
be dismantled and swallowed by
small children. The phone must
therefore be stored out of the reach
of small children.
Do not place the phone near to electromagnetic data carriers such as
credit cards and floppy disks. Information stored on them could be lost.
Do not look at the LED (e.g. activated infrared port, flash LED) with optical magnifiers because of radiation.
This product complies with IEC/EN
60825-1 “Safety of Laser Products”
for LED Class 1M products; such
products are safe under reasonably
foreseeable operating conditions.
Permanent hearing loss may occur if
you use ear- or headphones at high
volume.You can adapt over time to a
higher volume, which may sound
normal but can be damaging to your
hearing. Set your volume to a safe
level. If you experience ringing in
your ears, reduce the volume or discontinue use of your system.
The mains voltage specified on the
power supply unit (V) must not be
exceeded. Otherwise the charging
device may be destroyed.
The power supply must be plugged
into an easily accessible AC mains
power socket when charging the
battery. The only way to turn off the
charging device after charging the
battery is to unplug it.
You may only open the phone to replace the battery (100 % mercuryfree) or SIM card. You must not open
the battery under any circumstances. All other changes to this device
are strictly prohibited and will invalidate the guarantee.
Safety precautions
3
All electrical and electronic products
should be disposed of separately
from the municipal waste stream via
designated collection facilities appointed by the government or the local authorities.
This crossed-out wheelie bin symbol
on the product means the product is
covered by the European Directive
2002/96/EC.
The correct disposal and separate
collection of your old appliance will
help prevent potential negative consequences for the environment and
human health. It is a precondition for
re-use and recycling of used electrical and electronic equipment.
For more detailed information about
disposal of your old appliance,
please contact your local council,
waste disposal service or the shop
where you purchased the product.
The phone may cause interference
in the vicinity of TV sets, radios and
PCs.
Use only original accessories. This
will avoid potential risks to health or
property and ensure compliance
with all relevant regulations.
Improper use will invalidate the guarantee!
These safety instructions also apply to original
accessories.
As mobile devices offer a range of functions, they
can be used in positions other than the head,
such as on the body. In this case, separation distance of 1.5 cm is required.
Bluetooth
Your phone has a Bluetooth interface. This makes
it possible to establish a wireless connection with
your phone and a headset of a car kit, or other
Bluetooth-enabled devices.
In order to establish a secure link between the devices and to prevent a third party from having access to your phone, you should observe the
following points:
• The initial connection between two devices,
• Both devices must be able to identify them-
• An automatic connection acceptance ("connec-
• In general, only trustworthy devices should be
• You should restrict the "visibility" of your phone
• The name of your phone is transmitted in
• If Bluetooth is not needed, this function should
Before using Bluetooth accessories, or a mobile
phone inside a vehicle, check the vehicle user
guide for any limitations on the use of these
products.
®
what is called "pairing", should take place in familiar surroundings.
selves one time by using a password/PIN. To
ensure sufficient security, you should choose a
16-digit number combination for a password
that would be difficult to guess (if a PIN has not
been assigned).
tion without confirmation") should only be used
in exceptional cases.
linked in order to minimize security risks.
if possible. This will make it much more difficult
for unknown devices to establish a connection
with your phone. To do this, in the Bluetooth
menu, set the option Visib.to others to Always
visible to Not visible.
a Bluetooth connection. The factory default is
the "Bluetooth ID". The first time Bluetooth is
activated, or later in the Bluetooth menu, you
can change this name (My BT name).
be deactivated.
The Bluetooth® word mark and logos are owned
by Bluetooth
marks by BenQ Corp. is under licence. Other
trademarks and trade names are those of their
respective owners. Bluetooth QDID
(Qualified Design ID): B02422
®
SIG, Inc. and any use of such
4
Getting started
Getting started
Your phone's display is
covered with a protective
film. Remove this before
using the phone.
In rare cases static discharge can cause temporary discolouration in the
display. However, this will
disappear within approx.
10 minutes.
Inserting battery/SIM card/ MicroSD card
The service provider supplies you with a
SIM card on which all the important data
for your line is stored. If the SIM card has
been delivered in credit-card size, snap
the smaller segment out and remove any
rough edges. Please follow the instructions in the diagrams when inserting SIM
card, MicroSD card (optional) and battery.
Insert SIM card
Ensure that the cut-off corner is in the
correct position.
1
Insert MicroSD card (optional)
2
Insert battery
4
3
Close battery cover
6
5
7
• To remove the battery cover, press the
release button
cover.
Additional information
Please switch off your phone before removing the
battery! Do not remove the SIM card as long as
the battery is inserted. If the battery is removed
for longer than 30 seconds, the clock must be
reset.
, then lift the battery
7
Getting started
5
Charging the battery
The battery is not
fully charged when
delivered. Plug the
charger cable into
the side of the
power supply unit into a mains power
socket and charge for at least two hours
(for charging via USB, see p. 18). Do not
interrupt the charging procedure
prematurely.
Display when charging is in
à
progress.
Charging time
An empty battery is fully charged after
about 2 hours. Charging is only possible
within a temperature range of +5 °C to
+45 °C. If the temperature rises/falls 5 °C
above/below this, the charge symbol
flashes a warning. The mains voltage
specified on the power supply unit must
not be exceeded.
Operating time
The operating time depends upon the respective conditions of use. Extreme temperatures considerably reduce the
phone’s standby time. You should therefore avoid leaving the phone in the sun
or on a radiator.
Talktime: up to 250 minutes
Standby time: up to 280 hours
Charge icon not visible
If the battery has been discharged fully,
the charge icon is not immediately visible
when the power supply is plugged in.
It will appear after up to two hours. In
this case the battery is fully charged after
3 to 4 hours.
Only use the plug-in power supply unit
included in delivery!
phone, plug the
Display during operation
Charge level display during operation
(empty–full):
A beep sounds when the battery is nearly
empty. The charge level of the battery is
only displayed correctly after an uninterrupted charging/discharging cycle. You
should therefore not remove the battery un-
necessarily and where possible not terminate the charging process before completion.
The power supply unit heats up when used for
long periods. This is normal and not dangerous.
Ý Þ ß
Switching on/off
Press and hold the On/Off/End
B
key. Press briefly to open the
"Switch off menu".
Entering the PIN
The SIM card can be protected with
a4to8-digit PIN.
Open slider. Enter the PIN using
J
the number keys. The characters
appear in the display to en-
****
sure nobody can read your PIN.
Correct with
§OK§ Press the left softkey to confirm.
Logging on to the network will
take a few seconds.
Set the clock once after getting started (p. 18)
].
Emergency number (SOS)
Only to be used in real emergencies!
By pressing the left softkey
make an emergency call on any network
without a SIM card and without entering a
PIN (not available in all countries).
§SOS§ you can
6
General instructions
General instructions
User guide
The following symbols are used to explain
operation:
§Menu§
Displays a softkey function.
Function dependent on
=
the service provider.
Standard functions which appear repeatedly in the options menu are not listed in
this short user guide. The complete description can be found on the CD ROM or
the Internet at this address:
www.BenQ-Siemens.com/el71
Slider
Open slider completely
• Display light on.
• Keypad unlocked.
• The call is accepted.
• Alarm sound off (appointment, alarm).
Close slider completely
• Keypad locked in standby mode if no
application except Media Player is
running (if set).
• The call is ended (only if headset is not
connected).
• An incoming call is rejected.
• Alarm sound off (appointment, alarm).
Main menu
Call up from standby mode using
í
the centre key.
§Options§
Open menu.
Search
Illumination
List output of the menu. You can
use the search option to directly
access any menu item just by
browsing for the keyword.
Set display light brighter/darker.
Centre key
The symbol in the centre of the lower line
of the display shows the current function
when the centre key is pressed.
í
ì
ñ
ð
ü
÷
ú
ù
Main menu
OK, confirm
Change
Call
Edit
Insert
Options
Camera
ý
ö
û
ò
ô
ó
õ
ø
Send
View
Save
Play
Record
Pause
Stop
Zoom
Navigation keys
In standby mode/during conversation:
Open contacts.
H
Start Profiles.
G
Open inbox.
E
Start the camera.
D
PIN, PUK, Phonecode
7
Tabs
The handy tabs offer you fast access to
information and functions.
23
1
Switch between the individual
F
tabs.
If an input field is activated on a tab, it is
only possible to navigate within the field
using the navigation key.
2
31
Mark mode
For some applications (e.g. deleting several SMS messages) you can mark several
entries on the tab in order to perform
multiple functions at once.
§Options§ Open menu.
Mark Activate mark mode.
I
Select entry/entries.
Mark or unmark.
ñ
Additional mark mode functions:
§Options§ Open menu.
Mark all
Unmark all
Delete marked
Mark all entries.
Unmark all marked entries.
All marked entries are deleted.
Digital Rights Mgmt. (DRM)
Remember that your phone has Digital
Rights Management. The use of downloaded pictures, sounds or applications
can be restricted by the suppliers, e.g.
copy protection, use for a limited period
of time only, number of times it can be
used etc.
PIN, PUK, Phonecode
í
¢T¢Security
¢PIN codes¢Select function.
The phone and SIM card are protected
against misuse by several security codes.
Keep these security codes in a safe place
where you can access them again if required.
PIN codes
PIN
Personal Identification Number. Provided by service provider. Protects
your SIM card. If PIN is entered incorrectly three times, SIM card is barred.
Unbar with PUK.
PIN2
Provided by service provider to
access additional functions on special
SIM cards.
PUK
Master PIN. Provided by service pro-
PUK2
vider. Used to unlock SIM cards after
PIN is entered incorrectly more than
three times. If PUK has been lost,
please contact your service provider.
Phone-
Defined by you (4-8 digits) the first
code
time you call up a phone-code protected function (e.g. Direct call, p. 10). If
phone code is entered incorrectly
three times, access to the phone code
and the functions that use it is denied.
For your reference please note your
phone code here: ________________
8
Text input with T9
PIN control
The PIN is usually requested each time
the phone is switched on. You can deactivate this feature but you risk unauthorised use of the phone. If PIN use is deactivated confirmation is required to switch
on the phone. This prevents the phone
from being switched on accidentally, e.g.
when carried in a pocket or whilst you are
on an aircraft.
ñ
Edit, enter PIN.
Confirm entry.
ì
Change PIN/Change PIN2
You can change the PIN to any 4 to 8-digit
number you find easier to remember.
ñ
Edit, enter current PIN.
ì
Confirm, enter new PIN.
ì
Confirm, repeat new PIN.
Confirm.
ì
Chg.phonecode
You define the phone code (4-8 digit
number) the first time you call up a
phone-code protected function
(e.g. Direct call, p. 18). It is then valid for
all phone-code protected functions.
If the phone code is entered incorrectly
three times, access to the phone code
and the functions that use it is denied. If
this happens please contact the Service
Centre (see p. 22).
Text input with T9
"T9" uses various key entries to deduce
the correct word.
#
Activate/deactivate T9.
Writing with T9
It is best if you finish a word without looking at
the display.
Simply press the keys where the relevant
letter is located once.
/
E
1
A blank space or moving to the
right ends a word.
Do not use special characters such as Ä.
Use standard characters only, e.g. A. T9
will do the rest.
T9 word suggestions
If several options are found in the dictionary for a word, the most probable is
displayed first.
Press. If this word is incorrect,
^
press again until the correct
word is displayed.
Learning function
To enter a word in the dictionary:
§Spell§ Select and enter the word
without T9, then
Correcting a word
Move left or right, word by
F
word, until the required word
§highlighted§.
is
Scroll through the T9 word
^
suggestions again.
Deletes the character to the left
]
of the cursor and displays a new
possible word.
§Save§.
Loading...
