or
Projection dimensions
Screen size
<H>
<W>
Vertical offset
The screen aspect ratio is 4:3 and the projected picture is 4:3
Screen
Center of lens
Projection distance
Screen size
Diagonal
Inch mm
80 2032 1219 1626 988 183
100 2540 1524 2032 1235 229
120 3048 1829 2438 1481 274
150 3810 2286 3048 1852 343
180 4572 2743 3658 2222 411
200 5080 3048 4064 2469 4
220 5588 3353 4470 2716 503
240 6096 3658 4877 2963 549
270 6858 4115 5486 3333 617
300 7620 4572 6096 3704 686
H
(mm)W(mm)
Distance from screen
(mm)
Vertical offset
(mm)
57
All measurements are approximate and may vary from the actual sizes.
BenQ recommends that if you intend to permanently install the projector, you should physically test the
projection size and distance using the actual projector in situ before you permanently install it, so as to make
allowance for this projector's optical characteristics. This will help you determine the exact mounting position
so that it best suits your installation location.
Ceiling Mount screw: M4
(Max L = 25 mm; Min L = 20 mm)
207.6
76.5
34.5
199.6
127.7
77
66.1
626.6
577.7
537.9
117.5
180.1
320.5
125.6
241.1
Wall mount installation
Minimum installation requirements
Computer
Resolution: XGA
Resolution: XGA
Image Diagonal (inches)
Image Height (mm)
Image Width (mm)
Distance from floor to
bottom of image (mm)
Distance from screen
surface to projector
rear case (mm)
Distance from top case
to the top of image
(mm)
Distance from top of
wall mount to ceiling
(mm)
Minimum Ceiling Height
(mm)
Computer Resolution:
WXGA
Image Resolution: WXGA
Image Diagonal (inches)
Diagram
Reference
SMART
Smart
Board
660
Diagram
Reference
Board
680
Promethean
ActivBoard
164
SMART
Board
685
Promethean
ActivBoard
178
Promethean
ActivBoard
387
RM
ClassBoard2
77.5
Hitachi
FX-TRIO88W
Hitachi
StarBoard
FX-63
D 87 87 88 88
StarBoard
FX-77
Hitachi
FX-DUO88W
Image Height (mm)
Image Width (mm)
Distance from floor to
bottom of image (mm)
Distance from screen surface
to projector lens (mm)
Distance from top case to
the top of image (mm)
Distance from top of wall
mount to ceiling (mm)
Minimum Ceiling Height
(mm)
H 1171 1171 1181 1181
W 1874 1874 1887 1887
f 900 900 900 900
a 916 916 926 926
b 6.8 6.8 7.5 7.5
c 50 50 50 50
e 2461.8 2461.8 2472.5 2472.5
Wall mount installation
Minimum Ceiling Height (mm) = f+H+b+60+274+c
c
60
274
b
H
a
232.6
screen
Ceiling
D
Projection
area
e
20
Wall plate
W
Distance from floor to
f
bottom of image
• The dimensions are based on the BenQ wall mount (P/N: 5J.J4R10.001).
• All measurements are approximate and may vary from the actual sizes. BenQ recommends that if you
intend to permanently install the projector, you should physically test the projection size and distance
using the actual projector in situ before you permanently install it, so as to make allowance for this
projector's optical characteristics. This will help you determine the exact mounting position so that it best
suits your installation location.
• The dimensions supplied are offered as
any specific installation.
• The dimensions are based on the projector being configured with zero keystone correction.
• The dimensions assume that the wall mount arm is positioned 90° from the bottom case of projector and
screen surface.
a guide only and may differ depending on several factors relating to
floor
60
150
180
1
2
ON
3
4
5
2
1
1
OFF
2
X2
DX818ST_DX819ST-QSG-2L.fm Page 10 Wednesday, July 3, 2013 1:16 PM
(EN)
Specifications
All specifications are subject to change without notice.
Optical
Resolution
1024 x 768 XGA
Display system
1-CHIP DMD
Lens F/Number
F = 2.6
Lamp
190 W lamp
Electrical
Power supply
AC100–240V, 2.8 A, 50-60 Hz
(Automatic)
Power consumption
280 W (Max); < 0.5 W (Standby)
Mechanical
Weight
2.6 Kg (5.73 lbs)
Output terminals
RGB output
D-Sub 15-pin (female) x 1
Speaker
(Stereo) 10 watt x 1
Audio signal output
PC audio jack x 1
Control
RS-232 serial control
9 pin x 1
IR receiver x 2
USB port (Mini-B x 1)
Input terminals
Computer input
RGB input
D-Sub 15-pin (female) x 2
Video signal input
S-VIDEO
Mini DIN 4-pin port x 1
VIDEO
RCA jack x 1
SD/HDTV signal input
Analog - Component RCA jack x 3
(through RGB input)
Digital - HDMI V1.4 x 1
Audio signal input
Audio in
PC audio jack x 2
RCA audio jack (L/R) x 2
Environmental Requirements
Operating temperature
0°C–40°C at sea level
Operating relative humidity
10%–90% (without condensation)
Operating altitude
0–1499 m at 0°C–35°C
1500–3000 m at 0°C–30°C (with
High Altitude Mode on)
For further information, please refer to the enclosed user manual.
10
DX818ST_DX819ST-QSG-2L.fm Page 11 Thursday, July 4, 2013 11:14 AM
规格
所有规格如有更改，恕不另行通知。
(SC)
光学
分辨率
1024 x 768 XGA
显示系统
1-CHIP DMD
镜头焦距 / 编号
F = 2.6
灯泡
190 W 灯泡
电气
电源
AC100-240V， 2.8 A， 50-60 Hz （自动）
功耗
280 W （最大）； <0.5 W （待机）
机械
重量
2.6 千克 （5.73 磅）
输出端子
RGB 输出
D-Sub 15 针（母）x 1
扬声器
（立体声） 10 瓦 x 1
音频信号输出
PC 音频插孔 x 1
控制
RS-232 串口控制
9 针 x 1
红外接收器 x 2
USB 端口 （Mini-B x 1）
输入端子
电脑输入
RGB 输入
D-Sub 15 针 （母） x 2
视频信号输入
S- 视频
Mini DIN 4 针端口 x 1
视频
RCA 插孔 x 1
SD/HDTV 信号输入
模拟 - 分量 RCA 插孔 x 3
( 通过 RGB 输入 )
数字 - HDMI V1.4 x 1
音频信号输入
音频输入
PC 音频插孔 x 2
RCA 音频插口 （左 / 右） x 2
环境要求
操作温度
海平面时 0°C-40°C
工作相对湿度
10%-90% （无冷凝）
操作高度
0°C-35°C 时 0-1499 米
0°C-30°C 时 1500-2000 米
（高海拔模式开启）
若需进一步讯息，请参考随机所附的用户指南。
11
