Benq BAF51 Users Manual

right page (1) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Table of Contest 1

Table of Contest

See also In­dex at the end of this User Guide
Legal notices ......................................2
Safety precautions ............................. 4
Antenna care ...................................5
Electronic devices ............................6
Overview of the phone ......................9
Display symbols ................................ 11
Getting started .................................12
Switch on/off, PIN .............................13
General instructions .........................14
Standard functions ...........................15
Security ............................................15
Codes ............................................15
Calling ..............................................16
Text entry ......................................... 18
Preferred directory ...........................20
Phonebook .......................................21
<New entry> ..................................21
Call (search for an entry) ................ 21
Change entry .................................21
Address book .................................... 21
<New entry> ..................................21
Change entry .................................21
Call (search for an entry) ................ 22
Voice dialing ..................................22
Groups ..........................................22
Records .............................................22
Dur./charges .....................................23
Voice message/ mailbox .................. 23
CB services ........................................24
SMS ...................................................24
MMS .................................................25
Message lists/settings ......................26
Ring tones ........................................26
Alarm clock .......................................27
Fast access key .................................28
Surf & fun .........................................28
Games & more ...............................29
Setup ................................................ 30
See also Index at the end of this User Guide
Extras ............................................... 36
SIM services (optional) .................. 36
Organizer ...................................... 36
Calculator ...................................... 37
Stopwatch ..................................... 38
Countdown ................................... 38
Voice comm. ................................. 38
Remote sync. ................................. 38
Own stuff ......................................... 39
Customer Care ................................. 40
Care and maintenance ..................... 41
Product data ..................................... 42
Accessories ...................................... 43
SAR ................................................. 44
U.S. FDA ........................................... 45
FCC/Industry Canada Notice ............ 49
Intellectual property ........................ 50
Ten Driving Safety Tips .................... 51
End user license agreement ............ 53
Index ................................................ 56
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (2) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Legal notices2

Legal notices

The mobile phone described in this guide is approved for use on the GSM and GPRS net­works operating on the GSM 900, 1800 (DCS/PCN) and 1900 (PCS) bands. It is approved for use in the country where it was originally sold and may be approved for use in other countries.
© 2006 BenQ Corporation.
All rights reserved.
BenQ and the AF51 model phone are trademarks or registered trademarks of BenQ and/or its affiliates in the United States and/or other countries.
T9® is a registered trademark of America Online, Inc. in the United States. Java and all Java-based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S and other countries. The names of actual companies and products mentioned herein may be the trademarks of their respective owners.
Disclaimer
The information contained in the User Guide is written for the AF51 phone. BenQ reserves the right to make chang- es and improvements to the products and any of the features of the products de­scribed in this document without prior no­tice. The contents of the user guide are pro­vided "AS IS". Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of mer­chantability and fitness for a particular pur­pose, are made in relation to the accuracy, reliability or contents of this document. BenQ reserves the right to revise the user guide or withdraw it at any time with­out prior notice. Under no circumstances shall BenQ be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howso­ever caused.
Export Information
The mobile phone may be subject to export regulation of the United States and other countries. Diversion contrary to law is pro­hibited. You must comply with all applica­ble export laws, restrictions and regulations of the United States foreign agencies or au­thorities, and may not export, or transfer for the purpose of re-export, the mobile phone or any part of the phone in violation of any applicable restrictions, laws or regu­lations, or without all necessary approvals.
Network Services
A number of features included in this guide are called Network Services. They are special services provided by wireless service providers. In order to use any of these Network Services, you must sub­scribe to these service(s) from your ser­vice provider and obtain instructions for their use. Some of these Network Servic­es may not be available when roaming on a network other than your home network.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (3) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
3Legal notices
Standby and Talk Time Information
The mobile phone incorporates features that are new to the mobile phone world. These may include color displays and lighting, graphic games, music reproduc­tion and browsing the Internet. The way you use the display and the features will affect the performance of the battery and how long it lasts between charge cycles. The quoted standby times and talk times show the minimum and maximum per­formance that can be expected from the battery under normal network conditions and with the default settings as set by the factory. However, playing games (particu­larly with the backlight continuously switched on) and listening to music will shorten the time available for standby and to make and receive telephone calls. Operation times also vary depending on network conditions, SIM settings, charg­ing and battery condition, how you use your phone and other factors.
Memory
The mobile phone contains an internal memory device that stores the software required to operate the mobile phone, communicate with the GSM/GPRS net­work and provide the user interface. Some features in the internal memory run additional devices and some addition­al games and utilities. The amount of memory available in the mobile phone is finite and may be insufficient to store large numbers of applications and files.
Warning!
Remember to back up your data and to do so fre­quently. Always back up all data and programs before sending the mobile phone in for repair.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (4) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Safety precautions4

Safety precautions

Information for parents
Please read the operating instructions and safety precautions carefully before use. Explain the content and the hazards associated with using the phone to your children.
Remember to comply with le­gal requirements and local re­strictions when using the phone. For example in aeroplanes, petrol stations, hospitals or while driving.
Cellular phones can interfere with the functioning of medi­cal devices such as hearing aids or pacemakers. Keep at least 9 inches (20 cm) between phone and pace­maker. When using the cell phone hold it to the ear which is farthest from the pacemak­er. For more information con­sult your doctor.
The ringtone (p. 26), info tones and speakerphone talk­ing are reproduced through the loudspeaker. Do not hold the phone to your ear when it rings or when you have switched on the speaker­phone function (p. 17). Oth­erwise you risk serious, permanent damage to your hearing.
Only use original batteries (100 % mercury-free) and – charging devices. Otherwise you risk serious damage to health and property. The bat­tery could explode, for in­stance.
Small parts such as the SIM card, sealing stop, lens ring and lens cap can be disman­tled and swallowed by small children. The phone must therefore be stored out of the reach of small children.
The mains voltage specified on the power supply unit (V) must not be exceeded. Other­wise the charging device may be destroyed.
The power supply must be plugged into an easily accessi­ble AC mains power socket when charging the battery. The only way to turn off the charging device after charg­ing the battery is to unplug it.
Do not use a handheld while driving.
Do not look at the LED (e.g. ac­tivated infrared port, flash LED) with optical magnifiers be­cause of the risk of radiation.
This product complies with IEC/EN 60825-1 2 2Safety of Laser Products2 for LED Class 1M products; such prod­ucts are safe under reason­ably foresee-able operating conditions.
Do not place the phone near to electromagnetic data carri­ers such as credit cards and floppy disks. Information stored on them could be lost.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (5) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
5Safety precautions
You may only open the phone to replace the battery (100 % mercury-free) or SIM card. You must not open the bat­tery under any circumstances. All other changes to this de-
text below may not be applicable.
Important:
Use only original accessories. This will avoid potential risks to health or proper­ty and ensure compliance with all rele­vant regulations.
Improper use will invalidate the guaran­tee! These safety instructions also apply to original accessories.
Product attributes are subject to chang­es in technology, design and availability. BenQ reserves the right to modify prod­ucts without prior notice.
This cellular phone offers a range of Leather Case: For body worn operation, functions, it can be used in positions this phone has been tested and meets the other than the head, such as on the FCC RF exposure guidelines when used body. In this case, separation distance of with the BenQ accessories supplied or
belt clip or holder is used for body-worn accessories may not ensure compliance
operation, it should not contain metal with FCC RF exposure guidelines. and should position the device the Please only use BenQ designated Leather , above-stated distance from your body. Case (in Page 43). You should only put front side
to body when device is used in Leather Case.
0.6 cm is required. When a carry case, designated for this product. Use of other
vice are strictly prohibited and will invalidate the guarantee.
Please dispose of unwanted batteries and phones as per­mitted by the laws in your country.
The phone may cause inter­ference in the vicinity of TV sets, radios and PCs.
Important
Read this information before using your wireless handheld phone.
As this mobile phone is equipped with a fixed antenna, some paragraphs in the

Antenna care

Use only the supplied or an approved re­placement antenna. Unauthorized anten­nas, modifications, or attachments could damage the phone and may violate FCC regulations.

Phone operation

Normal position
Hold the phone as you would any other telephone with the antenna pointed up and over your shoulder.
Tips on efficient operation
For your phone to operate most efficiently:
• Extend your antenna fully (if applicable).
• Do not touch the antenna unnecessari­ly when the phone is in use. Contact with the antenna affects call quality and may cause the phone to operat e at a higher power level than otherwise needed.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (6) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Safety precautions6
Driving
Laws pertaining to the use of mobile phones while driving vary significantly from state to state and sometimes even from lo­cality to locality within states. For example, some areas may allow persons to use their mobile phones only if they employ a hands­free device, and some areas may prohibit the use of cell phones entirely. Accordingly, BenQ recommends that persons check the laws for the areas in which they drive or will be driving. For areas where the use of mo­bile phones while driving is permitted, BenQ encourages persons to use their phones responsibly and to employ hands­free devices. Also, if using your phone while driving, please:
• Give full attention to driving – driving safely is your first responsibility;
• Use hands-free operation, if available;
• Pull off the road and park before mak­ing or answering a call, if driving condi­tions so require.
For vehicles equipped with air bags
An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deploy­ment area. If in-vehicle wireless equipment is improperly installed and the air bag in­flates, serious injury could result.

Electronic devices

Most modern electronic equipment is shielded from radio frequency (RF) sig­nals. However, certain electronic equip­ment may not be shielded against the RF signals from your wireless phone.
Pacemakers
The Health Industry Manufacturers' Associ­ation recommends that a minimum separa­tion of six inches (6") be maintained be­tween a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommenda­tions are consistent with the independent research by and recommendations of Wire­less Technology Research.
Persons with pacemakers
• should ALWAYS keep the phone more than six inches from their pacemaker when the phone is turned ON;
• should not carry the phone in a breast pocket;
• should use the ear opposite the pace­maker to minimize the potential for in­terference;
• should turn the phone OFF immediate­ly if there is any reason to suspect that interference is taking place.
Hearing aids
Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider or your hearing aid manufacturer to discuss alter­natives.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (7) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
7Safety precautions
Other medical devices
If you use any other personal medical de­vices, consult the manufacturers of your devices to determine if they are ade­quately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.
Turn your phone OFF in health care facili­ties when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equip­ment that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately shielded electronic sys­tems in motor vehicles. Check with the manufacturer or its representative regard­ing your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.
Posted facilities
Turn your phone OFF in any facility where posted notices so require.
Airplanes
FCC and Airline Regulations prohibit using your phone while in the air. Turn your phone OFF when requested by the airline.
Check and comply with the policy of your airline regarding the use of your phone while the airplane is on the ground.
Blasting areas
To avoid interfering with blasting opera­tions, turn your phone OFF when in a “blasting area” or in areas posted: “Turn off two-way radio.” Obey all signs and in­structions.
Potentially explosive atmospheres
Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an ex­plosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmo­sphere are often but not always clearly marked. They include: fueling areas such as gasoline stations; below deck on boats; fuel or chemical transfer or storage facili­ties; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or parti­cles, such as grain, dust or metal pow­ders; and any other area where you would normally be advised to turn off your vehicle engine.
Emergency calls (SOS)
Your wireless phone can be used to make emergency calls. You can make an emer­gency call from the main display screen. Enter the local emergency number such as 911 and then press the
This phone, like any wireless phone, oper­ates using radio signals, wireless and landline networks, and user-pro­grammed functions. Because of this, con­nections in all conditions cannot be guar­anteed. Therefore, you should never rely solely on any wireless phone for essential communications (for example, medical emergencies). Remember – to make or receive any calls, the phone must be switched on and be used in a service area that has adequate signal strength. Emer­gency calls might not be possible on all wireless phone networks or when certain network services or phone features are in use. Check with local service providers re­garding their network features.
A
key.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (8) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Safety precautions8
Always make certain that your phone is properly charged before attempting any emergency calls. If you allow your battery to discharge, you will be unable to receive or make calls, including emergency calls. You must then wait a few minutes after the charging begins to place any emergency calls.
When making an emergency call, remember to give all of the necessary in­formation as accurately as possible. Re­member that your wireless phone might be the only means of communication at the scene of an accident, therefore you should not terminate the call until given permission to do so.
Batteries and Chargers
Only use original batteries (100% mer­cury-free) and charging devices. Use of non-original batteries and/or charging devices may cause explosion resulting in serious injury and/or property damage. Use original accessories in order to avoid possible injury and property damage and to ensure compliance with applicable laws and regulations. Improper use invali­dates the warranty.
Battery safety precautions
To reduce the risk of fire, injury or electric shock, and to properly dispose of batter­ies, please read and understand the fol­lowing instructions. CONTAINS LITHIUM­ION OR NICKEL-METAL HYDRIDE BATTERY. BATTERY MUST BE RECYCLED OR DIS­POSED OF PROPERLY. DO NOT DISPOSE IN MUNICIPAL WASTE.
1. Only use the batteries specified for use with this mobile phone.
2. Do not use batteries of different sizes or from different manufacturers in this mobile phone.
3. Do not dispose of the battery in a fire; it may explode. Dispose of used batteries and phones in accordance with applica­ble laws and safety regulations. Do not expose battery to water. Check with local codes for special disposal instructions.
4. Do not open or mutilate the battery. Doing so may cause damage to the eyes or skin.
5. Exercise care in handling the battery in order not to short the battery with con­ducting materials such as rings, brace­lets, and keys. The battery or conduct­ing material may overheat and cause burns or fire.
6. Charge the battery provided with, or identified for use with, this product only in accordance with the instruc­tions and limitations specified in the User's Guide. Do not attempt to charge the battery by any means other than those specified in the User's Guide.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (9) of AF51 DTC FCC us-en

Overview of the phone

Display indicators
1
Signal strength/GPRS/battery level.
A
Call key
2
Dial displayed phone number or name, accept calls. In standby mode: Display the last calls.
B
On/Off/End key
3
• Switching on/off: press and hold.
• During a conversation or in an
application: press briefly to finish.
• In menus: press briefly to go back a level. Press and hold to return to standby mode.
• In standby mode: Press and hold to switch off phone.
Navi-key
4
In lists and menus:
GScroll up and down.
Function call.
D
Back a menu level.
C
During a call:
Open call menu.
D GAdjust volume.
In standby mode:
EVoice comm. (press and hold). F
Open Addressbook/Phonebook.
DOpen menu. CNew SMS.
_ ª g
Service provider
17.12.2005 09:15
New SMS
Menu
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
9Overview of the phone
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (10) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Overview of the phone10
Softkeys
1
Press the softkey to call up the function that is displayed as grey fields above the key.
Plug socket
2
For charger, headset.
Press and hold
3
*
• In standby mode: switch on/off all signal tones (except alarm).
• For incoming calls: only switch off ring tones.
Press and hold
4
In standby mode: switch key lock on/off.
LED
5
Two LEDs for Dynamic light (p. 31) are located under lift cover.
2nd display
6
Displays time, incoming calls, screensaver and certain other information when the clamshell is closed.
When Open clamshell (p. 32) is activated a call can be accepted by opening the clamshell. A call can be ended by simply closing the clamshell.
§Text§ or icon on the
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (11) of AF51 DTC FCC us-en

Display symbols

Display symbols (selection)
_
Signal strength
Charging
h
Battery charge level, e.g. 50%
d
Address book/Phonebook
è
Call records
Z
Surf & fun/Service provider portal
É
Alarm clock
Messages
]
Ring tones
Extras
Own stuff
Ñ
Setup
m
Call(s) is/are diverted
n
Ringer off
j
Short ring (beep) only
k
Ringtone only, if the caller is stored in
l
the Addressbook/Phonebook
Ø
Alarm set
Alarm clock activated
Ö
µ
Keypad locked
Message memory full
T ²
No network access
ABC/
Indicates whether upper or lower-case letters are active
Abc/abc
Text input with T9
T9Abc
Activated and available
«
Registered
ª
Temporarily interrupted
Internet online
Ê
Internet via GPRS online
Ë
Internet no network
Ì
Auto answer feature on
±
Organiser symbols (selection)
Memo
u
Call
v
Meeting
w
{
Birthday
Anniversary
È
Access with left softkey (selection)
Message received
MMS notification received
Û
Voice message received
\
Unanswered call
Depending on the service provider, some of the symbols shown here may vary from those in the phone.
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
11Display symbols
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (12) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Getting started12

Getting started

Using the SIM card/battery
Your phone's display is delivered with a protective film. Remove this film before getting started. The service provider supplies you with a SIM card on which all the important data for your account is stored. If the SIM card is credit card-sized, snap out the smaller segment and trim any rough edges.
Always switch off phone before removing the battery!
Only 3V and 1.8V SIM cards are supported. Please contact your service provider if you have an older card.
Release and open battery cover
1
2
Remove battery
3
Open SIM card holder, insert SIM card, and close holder
5
4
Insert battery and close cover
6
7
8
Charge battery
The battery is not fully charged when delivered. Plug charger cable into the bottom of the phone, plug power supply unit into a mains power socket and charge for at least two hours. The power supply unit heats up when used for long periods. This is normal and not dangerous.
When charging is in progress displayed.
h is
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (13) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
13Switch on/off, PIN
Charging time
An empty battery is fully charged after about 2 hours. Charging is only possible within a temperature range of +5 °C to +40 °C (+41°F to +104°F). If the tempera­ture rises/falls 5°C above/below this, i.e drops to 32°F or rises to 113°F, the charge symbol flashes a warning. The mains volt­age specified on the power supply unit must not be exceeded (Operating time, p. 42).
Charge icon not visible
If the battery has been discharged fully the charge icon is not immediately visible when the power supply unit is plugged in. It will appear after up to two hours. In this case the battery is fully charged after 3–4 hours.
Only use the power supply unit provided! Display while in service
Charge level display during operation (empty – full):
A beep sounds when the battery is nearly empty. The charge level of the battery is only displayed correctly after an unin­terrupted charging/discharging cycle. You should therefore not remove the battery
unnecessarily and where possible not terminate the charging process early.
adg.

Switch on/off, PIN

Switch on/off
Press and hold the On/Off/End key B to switch on or off.
Enter PIN
The SIM card can be protected with a 4- to 8-digit PIN.
Open keypad. Enter the PIN using the number keys. The characters to ensure nobody can read your PIN on the display. Correct errors with
Confirm your input with to the network will take a few seconds.
Emergency number (SOS)
Only to be used in real emergencies!
By pressing the softkey an emergency call on any network without a SIM card and without entering a PIN (not available in all countries).
§SOS§ you can make
Switching on your phone for the first time
Time/date
Set the clock to the right time once at start-up.
Open keypad. Press date (day/month/year), then the time (24 hours, including seconds). Press The time and date are updated.
If the battery is removed for longer than 30 seconds, the clock will be reset.
§Yes§. First enter the
appear
****
§Clear§.
§OK§. Logging on
§OK§.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (14) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
General instructions14
Time zones
Set the time zone for your area. Select the required time zone from list
with
G. Apply with §Set§.
Phonebook or Addressbook
You can choose whether you want to use the Phonebook on the SIM card or the inter­nal Addressbook as standard.
You can copy the SIM card Phonebook to the Addressbook on the phone. Please do not interrupt this procedure. During this time do not accept incoming calls. Follow instructions in the display.
To copy data on the SIM card at a later time, highlight entries (see p. 15) and copy these with the function Copy to (Phonebook options menu).
You can change the default book at any time (p. 20).
Signal strength
_
Strong reception signal.
^ A weak signal reduces the call
quality and may lead to loss of the connection. Change your location.

General instructions

User guide
The following symbols are used to explain operation:
Enter numbers or letters.
J
On/Off/End key.
B A
Call key.
Press navigation key on the
D
§Menu§
L
side indicated.
Displays a soft-key function.
Function depends on the
service provider, special registration may be necessary.
Without SIM card
If you switch on the phone without a SIM card you can still use some phone functions.
Press
§Menu§. The functions are displayed
(e.g. Emergency, SOS).
Menu control
9
The steps needed to reach a function are shown in a condensed form in this user guide.
E.g. to display call list for missed calls: Press
§Menu§ ¢
Z
¢ Missed calls
¢ §Selection§.
This comprises the following steps: Open main menu, select
the function Missed calls. You have to con-
§Selection§.
firm with
Standby mode
Very often function descriptions begin in standby mode.
The phone is in standby mode and is ready for use when the name of the service provider appears on the display. If you now close the keypad, the phone remains in standby mode.
Press and hold the On/Off/End key to return to standby mode from any situation.
Z, then select
B
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (15) of AF51 DTC FCC us-en

Standard functions

Option menus
Menu functions are made available in options menus. A selection of functions that occur frequently is shown here.
Press
§Options§ to open menu.
Edit
Capacity
View
Delete /
Delete all New entry
Send MMS
Send via...
Save
Sort
Text input
(p. 18)
Rename
Highlighting mode
With some applications (e.g. Phonebook) one or more entries in a list can be highlighted to perform multiple functions at once.
Press Press
entry.
Open the entry to edit.
Display available capacity.
Display entry.
Delete entry/delete all entries after confirmation.
Create new entry.
Send entry as MMS message.
Select transmission service and medium for sending or printing.
Store entry.
Set sort criteria (alphabetical, type, time).
T9 preferred: Activate/
deactivate T9 input.
Input language: Select
language for text.
Rename selected entry.
§Options§ ¢ Mark text.
§Mark text§ to highlight an unmarked
Press
§Unmark§ to unmark a highlighted
entry. Additional highlighting functions:
Mark all
Unmark all
Delete marked
Highlight all entries.
Delete highlighting on all marked entries.
All selected entries are deleted.
Menu speed dialling
All menu functions are numbered internally. A function may be selected directly by entering these numbers in sequence.
Example: Press
§Menu§. Press e.g. 2 for Records or
1 for Missed calls.

Security

§Menu§ ¢ m ¢ Security
¢ Select function.
The phone and SIM card are protected against misuse by several security codes.
Keep these confidential numbers in a safe place where you can access them again if required.

Codes

PIN control
You can stop the PIN prompt being activated when the phone is switched on, but you then risk unauthorised use of the phone.
§Change§. Enter PIN and confirm
Press
§OK§.
with
Change PIN
You can change the PIN to any 4- to 8-digit number you find easier to remember.
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
15Standard functions
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (16) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Calling16
Enter current PIN and confirm with §OK§. Enter new PIN twice and confirm each time with
Change PIN2
(Display only if PIN2 is available). Proceed as with Change PIN.
Chg.phonecode
You define the phone code (4–8 digits) when you call up a protected function for the first time. It is then valid for all phone­code protected functions. If the wrong code is entered three times then the phone will be locked. Contact Customer Care for instructions on how to unlock your pone.
§OK§.
Clear SIM card barring
If the PIN is entered incorrectly three times, the SIM card is barred. Enter the PUK (MASTER PIN), provided by your service provider with the SIM card, according to instructions. If the PUK (MASTER PIN) has been lost, please contact your service provider.
Preventing accidental activation
Even if PIN control is deactivated confirmation is required to switch on the phone.
This prevents the phone from being switched on accidentally, e. g. when carried in a pocket or whilst you are on an aircraft.
Press and hold the On/Off/End key and confirm with switches on.
§OK§. The phone
B

Calling

Dialling with number keys
The phone must be switched on (standby mode). Dial number (always with area code, if necessary with international dialling code). To dial international dialling code press and hold displayed. Press try.
Short press long press clears the entire phone
number. To dial press the Call key
§Country§ and select coun-
§Clear§ to clear the last digit, a
End call
Press the End key B briefly or simply close the clamshell. Press this key even if the person on the other end of the line has hung up first.
Set volume
Adjust volume with navigation
G during conversation.
key If a Car Kit is used, its volume setting will
not affect the usual setting on the phone.
Redial
To redial numbers that were dialled previously, press the Call Key pick up the required phone number from the list with
G, then press A again.
If the number is busy
Press §Auto dial§ for automatically dialling the phone number ten times at increasing time intervalls or press
§Call back§ (L) for phone ringing when
the busy number is free. Press a beep reminds you to redial the dispayed phone number after 15 minutes.
0 until a "+" is
A.
A once,
§Prompt§ and
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (17) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
17Calling
Accept call
The phone must be switched on (standby mode). An incoming call will interrupt any other use of the phone. Press
A. When Open clamshell (see p. 32) is
or activated a call can be answered by simply opening the clamshell.
Please make sure you have accepted the call before holding the phone to your ear. This will avoid damage to your hearing from loud ring tones!
A phone number transmitted by the network is displayed or the corresponding name if it is contained in the Phonebook (p. 21) or Addressbook (p. 21). A picture may also appear (settings p. 21).
§Answer§
Reject call
§Reject§ or B press briefly.
Handsfree
You can put the phone aside during a call. You can then hear the caller via the loudspeaker.
Activate handsfree function with and switch on with
Adjust the volume with
§Handsfr.§ switches off "handsfree talking".
Always switch off "handsfree talking" before holding the phone to your ear! This will avoid damage to your hearing!
§Yes§.
§Handsfr.§
G. Pressing
Swapping between 2 calls b
Make a new connection during a call with
§y§Menu§
new phone number). With
¢
between both calls.
¢
Toggle you can swap back and forth
Hold
¢
J
§y§Menu§
(dial a
If you are called during a phone call and you can hear the "call waiting tone" (p. 31), you can accept the waiting call with
§Toggle§,putting the current call on
hold to do so. Swap back and forth between the calls
see above or end the current call with and accept the new call with
§Answer§.
B
Conference b
Call up to 5 parties and link them togeth­er in a conference call. Make a new con­nection during a call with
¢
(dial a new phone number). The
J
current call is set on hold. With
¢ Conference you can join the held call
when the connection is established. Repeat this procedure until all
participants are linked together. All calls in the conference are ended si-
multaneously when the End key pressed or the clamshell is closed.
§y§Menu§ ¢ Hold
§y§Menu§
B is
Babysitter
If this is active, only one number can be dialled.
§Menu§ ¢ m ¢ Security ¢ Babysitter
D and enter phone code. The
Press phone code (4- to 8-digits) is set by you and entered at the first security setting. Please note this code down (see also p. 15)! Confirm code input with
§Change§ and enter number (press · to
select phone number from the Adress­book p. 21 or Phonebook p. 21). Confirm "On" with
To dial, press and hold the right softkey. To switch direct call off, press and hold
Enter phone code and confirm with Press
§OK§.
§Change§ and Confirm Off with §OK§.
§OK§. Press
.
§OK§.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (18) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Text entry18

Text entry

Text entry without T9
Press number key repeatedly until the re­quired letter appears. After a brief interval the cursor will advance. Example:
Press once briefly to type the let-
2
ter a, twice to type b, etc. Press and hold to write the number.
Umlauts and numbers are dis-
Ä,ä,1-9
played after the relevant letters. Press briefly to delete the letter
§Clear§
before the cursor, press and hold to erase the whole word.
Move the cursor
/G
H
(forwards/back). Press briefly: Swap between abc,
Abc, T9abc, T9Abc, T9ABC, 123.
Status shown in top line of display.
Press and hold: All inputvariants are displayed.
Press briefly: Special characters
*
are shown. Press and hold: Open input
menu. Press once/repeatedly:
0
. , ? ! ’ " 0 - ( ) @ / : _
Press and hold: Writes Writes blank.
1
Press twice =jumpsa line.
0.
Special characters
Press * briefly. The character map is displayed:
1)
¿¡_;.,?!+
-"’: $
£ } %~<=>| ^§ Γ Θ Λ Ξ Π Σ Φ Ψ
1) Line break
Navigate to characters with
§Selection§.
press
*/()
€@\ &#[] {
¤¥
G,H and
Input menu
Press and hold* with text input. The input menu ist displayed:
Text format (SMS only), Input language, Mark text, Copy/Add
Text entry with T9
"T9" deduces the correct word from the individual key entries by making compari­sons with an extensive dictionary.
Activate, deactivate T9
§Menu§ ¢ ] ¢ Msg. setup
¢ T9 preferred ¢ §Change§ (activate/
deactivate T9).
Select Input language
Select the language in which you want to compose your message.
§Menu§ ¢ ] ¢ Msg. setup
¢ Input language ¢ §Selection§ (the new
language is set) Languages with T9 support are marked
with the T9 symbol.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (19) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
19Text entry
Write a word using T9
Since the display changes as you proceed, it is best if you finish a word without looking at the display.
Simply press the keys once only where the relevant letter is located. For "hotel", for example:
Press briefly
46835and 1 (the blank ends
aword). Do not use special characters such as Ä
but rather use the standard characters, e.g. A; T9 will do the rest for you.
Additional information
0
D 
* Press briefly: Select special
T9
for
Abc then
Set a full stop. A word is conclud­ed if it is followed by a space. Within a word, a full stop repre­sents an apostrophe or hyphen:
§provider.s§ = provider’s.
e.g. Go to the right. Ends a word. Press briefly: Swap between:
abc, Abc, T9abc, T9Abc, 123. Status
shown in top line of display. Press and hold: All input modes
are displayed.
characters (p. 18). Press and hold: Open input
menu.
T9 word suggestions
If several options are found in the dictionary for a key sequence (a word), the most probable is displayed first. If the word you want has not been recognised, the next suggestion from T9 may be correct.
The word must be
». The displayed word is replaced
with a different word. If this word is also incorrect, repeat until the correct word is displayed.
To add a word to the dictionary, select
§Learn§. Now write the word without
T9-support and accept with the dictionary.
§highlighted§. Then press
§Save§ into
Correct a word
Words written with T9: With
H move left or right, word
by word, until the required word is
§highlighted§.
» scroll through the T9 word
With suggestions again. acter to the left of the cursor and displays a new possible word!
Words not written with T9:
H
move letter by letter to the left/
With
§Clear§ deletes the letter to the left of
right. the cursor. New characters are inserted at the cursor position.
§Clear§ deletes the char-
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (20) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Preferred directory20
®
Text Input is licensed under one or more of
T9 the following: U.S. Pat. Nos. 5,187,480, 5,818,437, 5,945,928, 5,953,541, 6,011,554, 6,286,064, 6,307,548, 6,307,549, 6,636,162 and 6,646,573; Australian Pat. Nos. 727539, 746674 and 747901; Canadian Pat. Nos. 1,331,057, 2,302,595 and 2,227,904; Japan Pat. No. 3532780, 3492981; United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK1010924; Republic of Singa­pore Pat. No. 51383, 66959, and 71979; European Pat. Nos. 0 842 463 (96927260.8), 1 010 057 (98903671.0), 1 018 069 (98950708.2); Republic of Korea Pat. Nos. KR201211B1 and KR226206B1. People’s Republic of China Pat. Application Nos. 98802801.8, 98809472.X and
96196739.0; Mexico Pat. No. 208141; Russian Federation Pat. No. 2206118; and additional pat­ents are pending worldwide.
Text modules
Text modules can be stored in the phone for adding to your messages (SMS, MMS).
Write text modules
§Menu§ ¢ ] ¢ Text modules
¢ <New entry> ¢ J (write text
¢ §Save§ (Accept the default
module) name or give it a new name, then save
§OK§).
with
Use text modules
J
(write message text)
Text modules
¢
module from the list) Text module)
The predefined text is inserted into the text to the left of the cursor.
¢
¢ §OK§.
G
(select text
¢
§Options§
¢
D (confirm

Preferred directory

§Menu§ ¢ è ¢ Select function.
Show entries
Entries in the standard directory (Addressbook or Phonebook) are shown for selection.
Select a name by entering the first letter
J and/or scroll G. To dial press the
Call key
A.
<New entry>
Create new entry in standard directory.
Phonebook, Address book (see p. 21).
Default book
Select the Phonebook (only one phone number possible per entry) or the Addressbook as your standard directory (default book). Your preference should be for the Addressbook, because more entries and functions (e.g. pictures, birthdays, several phone numbers per entry, etc.) are possible.
F
¢ Phonebook / Address book
¢
(set as standard)
D
Groups
(see p. 22)
Business card
Create your own business card. Send it as an SMS/MMS to another GSM-phone.
If no business card has been created yet, you will be asked for your input.
G Move from field to field to put in
your details. Press
Information numbers
Information numbers are stored here in accordance with the respective service provider.
§Save§.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (21) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
21Phonebook

Phonebook

Entries in the Phonebook (on the SIM card) are managed separately from those in the Addressbook. You can, however, exchange data between the Phonebook and the Addressbook.

<New entry>

If the Phonebook is set as standard (Addressbook as standard, p. 20):
Open Phonebook (in standby mode)
F
¢ <New entry> ¢ Select entry field
(The maximum number of characters available is displayed at the top of the screen)
Number: Always enter phone number with
dialling code.
Name: Enter first and/or last names. Group: Phone numbers may be assigned
to the VIP group.
Location: Select the storage location SIM
or SIM protected (PIN2 required).
Record no.: Is automatically assigned to
the entry.
§Save§ to store the new entry.
Press

Call (search for an entry)

Open phonebook F, select name and and press the Call key

Change entry

F
¢ Select entry ¢D ¢ Change
¢ Make changes ¢ §Save§.
<Special books>
<Own numbrs>: enter personal phone
numbers, <VIP numbers>: assign important numbers to group, <SIM phonebook>,
<Protected SIM>, <Info numbers>.
A.

Address book

The Addressbook can store up to 500 entries that are managed in the phone memory.

<New entry>

If the Addressbook has been selected as standard:
Open Addressbook (in standby mode)
F
¢D ¢J (enter first and/or
last name)
¢ Make further entries ¢ §Save§.
Group
Entries can be organized by groups. Select with
Press Addressbook entry. It is displayed if you are called by the corresponding phone number.
Birthday
After entering the date of birth, the "reminder box" can be activated. You can now enter the time for the reminder. The phone will then remind you with an accoustic tone and also with a display one day before the birthday and on the birthday.
All fields
Press display was previously reduced (
Field setup).

Change entry

F
¢ Make changes ¢ §Save§.
¢ Select entry field
§Change§.
§Selection§. Assign a picture to an
§Selection§. Show all input fields if the
§Options§,
¢ Select entry ¢ §View§ ¢ §Edit§
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (22) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Records22

Call (search for an entry)

Open Addressbook F, select name and and select phone number (if the entry has several numbers stored) press
A.

Voice dialing

Dial numbers by voice command. Up to 20 recorded names for voice dialling or voice commands (p. 38) can be saved on the mobile (not on the SIM card).
Record
Open Addressbook (in standby mode).
F ¢ Select entry (first letter and/or
scroll)
¢ §Options§ ¢ Voice dialing
¢ Select phone numbers if there are
more than one A short signal sounds. Now speak the
name. After a second beep and message in the display, repeat the name. A beep now confirms the recording, which is saved automatically.
Apply voice dialling
Press and hold E (in standby mode). Now speak the name. The number is dialled.
¢ §Record§ ¢ §Start§.

Groups

Nine groups are specified in your phone to enable you to arrange your Address­book entries clearly.
You can rename seven groups: Open Addressbook (in standby mode)
F
¢ <Groups> (the number of entries
is listed behind the group name)
¢ Select group ¢ D ¢ Rename group
Additional information
No group: Contains all Addressbook en-
tries that do not belong to a group (name cannot be changed).
Received: Contains vCard Addressbook
entries received by SMS (name cannot be changed).
Group symbol
Assign to a group a symbol that appears on the display when one of its members calls you.
Select group
¢ Select symbol ¢ §OK§.
¢
D
¢ Group symbol

Records

Your phone stores the phone numbers of calls for convenient redialling.
§Menu§ ¢ Z ¢ §Selection§ ¢ Select call
list and confirm
¢ A.
Missed calls b
The phone numbers of calls that you have received but not answered are stored for call back purposes. display for missed calls in standby mode.
¢ Select phone number
is shown on the
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (23) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
23Dur./charges
Calls received b
Accepted calls are listed.
Calls dialed
In standby mode you have access to the last numbers dialled with
Delete records
The records are deleted.
Call list menu
§Options§ ¢ Edit entries.
A.

Dur./charges

Display charge details and the duration of different types of calls while you speak, as well as setting a unit limit for outgoing calls. Note that charge information dis­played is indicative only and might vary from you phone bill.
§Menu§ ¢ Z ¢ Dur./charges
Select function: Last call, All outg. calls, All
incoming calls, Remain. units
§Selection§ Display data.
§Reset§ Clear display.
§OK§ End display.
Charge setting
§Menu§ ¢ Z ¢ Dur./charges
¢ Charge setting
Currency (PIN2 prompt) b
Currency for charge display.
Charge/Unit (PIN2 prompt) b
Charges per unit/period.
Account limit (PIN2 prompt) b
Fix a credit/usage period on a special SIM card.
Auto display
Display duration and charge automatical­ly at end of each call.
Voice message/ mailbox
§Menu§ ¢ ] ¢ Msg. setup
¢ Voice message
Most service providers offer a mailbox, in which a caller may leave a voice message for you
• if your phone is switched off or not ready to receive,
• if you do not want to answer,
• if you are making a phone call (and Call
waiting is not activated, p. 31).
You may have to register for this service with the service provider and enter the settings manually.
Settings b
The service provider supplies you with two phone numbers:
Save mailbox number
Call this phone number to listen to the voice messages left for you.
§Menu§ ¢ ] ¢ Msg. setup
Voice message
¢
mailbox number)
Save call divert number
Calls are diverted to this phone number (see also p. 31).
§Menu§ ¢ m ¢ Phone setup ¢ Divert
¢ e.g., Unanswered ¢ Set ¢ J
divert number) at the network). Divert will after a few seconds
J (enter
¢
§OK§.
¢
§OK§ (register number
¢
be confirmed
(see also p. 31).
b
(dial
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (24) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
SMS24
Listening to message
A new voice message can be announced as follows: An a text message announces a new voice mail or you receive a call with an automatic announcement. Dial into your mailbox and listen to your message(s).
Press and hold box number once only). Confirm with
§Mailbox§ depending on your service
and provider.
\ icon with beep or
1 (if necessary enter mail-
§OK§

CB services b

§Menu§ ¢ ] ¢ Msg. setup
¢ CB services
Some service providers offer information services (info channels). If reception is activated, your "Topic list" will supply you with messages on the activated topics.
SMS
You can transmit and receive very long messages (up to 760 characters) on your phone. They are automatically composed of several "normal" SMS messages (note higher charges). Using special letters in some languages reduces the maximum possible length of an SMS. If you do not wish to use these letters, please change the input language in the options menu.
Additionally you can insert pictures and sounds in an SMS.
Depending on the service provider, e-mails and faxes can also be sent and e-mails received via SMS (change setting if necessary, p. 26).
Writing and sending
§Menu§ ¢ ] ¢ New SMS ¢ J (write
text)
¢A ¢
number or select from Addressbook/ Phonebook)
The SMS is sent to the service centre for transmission.
For Text input using "T9", p. 19. Press
§Clear§ briefly to delete letter by letter, press
and hold to delete an entire word.
Special functions
SMS to group
You can send an SMS message as a "circular" to a recipient group.
§Options§ ¢ Send ¢ §Group§ ¢ Select
group
¢ Select group members and
send SMS.
Picture&sound
Insert pictures and sounds into message.
§Options§ ¢ Picture&sound ¢ select
section and entry. The menu contains:
Def animations, Def. sounds, Own anim., Own pictures, Own sounds
· /
¢ §OK§.
J
(enter phone
Receive/read SMS
An arrival of a new SMS is announced on display with left softkey.
With by line. Select
. To read the SMS, press
G you scroll through message line
§Reply§ for a direct reply.
SMS archive
§Menu§ ¢ ] ¢ SMS archive
The list of SMS messages stored in the phone is displayed.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (25) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
25MMS
MMS
The Multimedia Messaging Service enables you to send texts, pictures (also photos) and sounds in a combined message to another mobile phone or to an e-mail address. All elements of an MMS message are merged to form a "slide show".
Depending on your phone's settings, you will receive either the complete message automatically or notification that an MMS has been saved in the network, giving sender and size details. You may then download it to your phone to read it.
Ask your service provider whether this service is available. You may need to register for this service separately.
Writing/sending MMS messages
An MMS consists of the address header and the content.
§Menu§ ¢ ] ¢ New MMS
Input fields:
·/J Phone number/
To:
e-mail address of recipient(s).
Subject: Enter MMS heading (up to
40 characters).
§Insert§. The picture list is opened
Picture:
for selection.
Text:
§Edit§. Write text with the help
of T9.
Sound:
§Insert§. Select a melodie (p. 39) or
record a new melody (see below).
Slide duration
Enter length of display for individual pages (minimum 0.1 seconds).
New recording
The phone records via its microphone.
§Insert§ in the Sound: field when
Press completing the input fields. Select New
ring tone. Press
ing duration and available time remaining are displayed. To end recording press
§Stop§.
Press To give the recording its own name, the description
Attach extra pages
§Options§ ¢ New slide
Attach business card
§Options§ ¢ Extras ¢
Business card
Attach appointment
§Options§ ¢ Extras ¢
Appointments
§Record§. The current record-
§Play§ to replay recording. Press §Save§.
§Clear§. Confirm with §OK§.
G
Scroll to
¢ ·.
G
Scroll to
¢ ·.
Send MMS
§Options§ ¢ Send
Receive/read MMS
An arrival of a new MMS/notification of an MMS is announced on display with
/ Û. Press the left softkey to read
the MMS or notification. Depending on the setting, (p. 26) the
• complete MMS is received
• or the notification is opened. Press
§Receiving§ to receive the complete MMS,
§Play§ automatic presentation of
with the MMS. Cancel using any key.
•Open attachments using
Attachments.
• Open images and tones using and Content.
§Options§ and
§Options§
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (26) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Message lists/settings26

Message lists/settings

All SMS and MMS messages are saved in four different lists:
Inbox
§Menu§ ¢ ] ¢ Inbox ¢ MMS/SMS
The list of SMS, MMS and CB messages received is displayed. To receive an MMS subsequently, open notification and
§Receiving§.
press
Draft
§Menu§ ¢ ] ¢ Draft ¢ MMS/SMS
The list of stored drafts is displayed.
Unsent
§Menu§ ¢ ] ¢ Unsent ¢ MMS/SMS
The list of MMS messages not yet successfully sent or not yet completely sent concatenated SMS messages is displayed.
Sent
§Menu§ ¢ ] ¢ Sent ¢ MMS/SMS
The list of sent SMS or MMS messages is displayed.
SMS profiles, MMS profiles
§Menu§ ¢ ] ¢ Msg. setup
¢ SMS profiles/MMS profiles
Profiles have to be created for SMS and MMS. The transmission characteristics are defined in these. The data for these may already have been entered. If not, you can obtain this from your service provider. Additional information is available in the comprehensive operating instructions on the Internet:
www.BenQ-Siemens.com/af51

Ring tones

§Menu§ ¢ ¢ Select function.
You can set the ring tone separately for call types/functions. You can download new ringtones from the internet via
Download new.
Ringer setting
Activate/deactivate the ring tone or reduce it to a short beep.
Silent alert
Activate/deactivate silent alert (also in addition to the ring tone). The silent alert is activated if the highest volume is set for the ring tone.
Volume
Set the volume for the ring tones.
Please make sure you have accepted the call before holding the phone to your ear. This will avoid damage to your hearing from loud ring tones.
d Call tone, Group call tones,
Other call tone, Alarm tone, SMS/MMS tone
You can set the tones to match your needs.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (27) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
27Alarm clock
More tones...
Here you can set the ring tone separately for other functions.
Call screening
Only calls from numbers that are in the Addressbook/Phonebook or in a predefined group are signalled. Other calls are only displayed. If you do not accept these calls, they are diverted to your mailbox (if set, p. 31). If call screening ist active, standby mode.
Key tones
Type of acoustic key tone: Click or Tone or
Silent
Opening tone
Set signal to acknowledge opening the clamshell.
Closing tone
Set signal to acknowledge closing the clamshell.
Minute beep
During a call, you will hear a beep after each minute.
Information tones
Set service and alarm tones.
CBS tone, Start melody, End melody.
l is displayed in

Alarm clock

§Menu§ ¢
The alarm will ring at the time set by you, even when the phone is switched off. If the phone has been switched off in Air­plane mode the alarm is only shown on the display and is not indicated by sound.
Setting
Set the time for the alarm call (hh:mm). Confirm with
Press alarm.
§OK§.
§On/off§ to activate/deactivate the
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (28) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Fast access key28

Fast access key

The left softkey and the number keys 2 to 9 (speed dialling numbers) can each be assigned an important phone number or a function. The phone number can then be dialled or the function started at the touch of a button.
Left softkey
Assign a function/phone number to the left softkey for fast access.
Change in standby mode (example)
§New SMS§ Press briefly ¢ §Change§ ¢
¢
scroll to the applications
G
(e.g., Internet, Phone number)
Apply in standby mode (example)
Key assigned with Phone number/name. Press and hold
§Carol§.
Speed dialling keys
Only possible for keys 2 to 9. Key 1 is reserved for the mailbox.
Set in standby mode
J
Press an unassigned numberkey
(2–9) (e.g. New SMS., Phone number, Bookmarks)
¢ §Selection§.
Apply in standby mode
Press and hold assigned numberkey, e.g.
§Set§ scroll to the applications
¢
3.
¢ §Selection§.

Surf & fun

§Menu§ ¢ É ¢ Select function.
Get the latest information from the Internet that is specifically adapted to the display options of your phone. In addition, you can download games and applications to your phone. Internet access may require registration with the service provider.
Home b
A connection is established with the Internet provider’s portal (may be specified/ configured by default by your service pro­vider).
Bookmarks
List of URLs for fast access.
Internet
The browser is activated as soon as you call up the function. The functions of the softkeys vary, depending on the internet page. The contents of the option menus are also variable. If necessary, set the way in which Internet access should be made:
APress. The browser menu is open
¢ More ... ¢ Setup ¢ Start with...
Select required function in the start menu and confirm with
End connection
Press and hold B to close the browser. After GPRS/CSD lingertime (WAP param.) the connection will also be ended.
Additional information
Í É
Ê Ë Ì
§Selection§.
Browser menu. Offline. Online. GPRS Online. No network.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (29) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
29Surf & fun
Select special characters, such as
*
@, ~, \ , see p. 18.
Press repeatedly for:
0
. , ? ! ’ " 0 - ( ) @ / : _
Profiles
§Menu§ ¢ É ¢ Internet ¢ Profiles
Activate profile
You can change the current profile each time you access the Internet. For this, select profile, then profile is selected.
Set profile
Up to 5 profiles can be configured (may be barred by your provider). The entries may vary depending on the service provider. Select profile, then fill in the data fields.
To select the connection profile, see p. 33.
§Selection§. The current
§Edit§ and

Games & more

Download games and other applications. You are advised about relevant applications on the Internet. Once you have selected a game or application you can start to download it immediately. Then you can use the application. Most applications include instructions.
Applications and games can be found at
wap.siemens.com or on the Internet at www.BenQ-Siemens.com/af51
Games and applications
Stored applications and links are found under:
§Menu§ ¢ É ¢ Games & more
Different functions are available depending on which entry is highlighted:
£ Download new
§Internet§ The selected Internet page is
loaded.
§ Use game/application offline
Runnable application can be
§Selection§
started immediately.
¦ Load game/application online
Only description file; application
§Selection§
has still to be loaded.
Additional information
You can use the browser to download applications (e.g. ringtones, games, pictures, animations) from the Internet. BenQ Mobile excludes all warranty and liability claims in respect of or in connection with any applications subsequently installed by the customer and any software not included in the original delivery package. This also applies to functions enabled subsequently at the customer's instigation. The purchaser bears sole risk for the loss of, damage to, and any defects arising in, this device or the applications and for any direct damage or conse­quential damage of whatever nature re sulting from the use of this application. For technical reasons, such applications and subsequent enabling of certain functions are lost in the event of the device being replaced/re-supplied and may be lost if it is repaired. In such cases, the buyer is required to download or enable the application again. Please ensure that your phone has Digital Rights Manage­ment (DRM) so that downloaded applications are protected from unauthorised reproduction. The se applications are then exclusively intended for your phone and cannot be transferred from this even to create a backup. BenQ Mobile offers no warranty or guarantee nor does it accept any liability for the customer's ability to download or enable applica­tions again or to do so free of charge. We recom­mend that you carry out a backup from time to time of the applications on your Windows ing the Mobile Phone Manager Software. You can download the latest version from the Internet:
www.BenQ-Siemens.com/af51
®
PC us-
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (30) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Setup30

Setup

Profiles
§Menu§ ¢ m ¢ Profiles
Several settings can be stored in a phone profile in order, for example, to adapt the phone to the surrounding level of noise.
• Five standard profiles are provided with default settings. They can be changed however: Normal envi., Quiet environ.,
Noisy environ., Car Kit, Headset.
• You can set two personal profiles (<Empty>).
• The special profile Airplane mode is permanent and cannot be changed.
Switch on
Select default profile or personal profile
¢ D.
Setup
Select profile or personal profile, then
¢ §Options§ ¢ Change sett.
The list of available functions is displayed.
Car Kit
If a original Car Kit is used, the profile is activated automatically as soon as the phone is inserted into the cradle (p. 35).
Headset
If an original headset is used, the profile is activated automatically as soon as the headset is in operation.
Airplane mode
Sound for all alarms (appointments, alarm clock) are deactivated. Alarms are only indicated on the display. This profile cannot be modified. The phone will switch off if you select the profile Airplane mode. Confirm a security promt.
Normal mode
When you switch on your phone again, the previously set profile will be reactivated automatically.
Display
§Menu§ ¢ m ¢ Display
¢ Select function.
Language
Set the language of the display text. When "automatic" is set, the language of your service provider is used. Reset to this language in standby mode:
 0 0 0 0  A
*
Text input
See also p. 18.
T9 preferred
Activate/deactivate intelligent text entry.
Input language
Select language for text entry. Languages with T9 support are marked with the T9 symbol.
Wallpaper
Set background graphic for display.
Logo
Choose picture to be displayed instead of the provider logo.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (31) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
31Setup
Color scheme
Select colour scheme for the entire user interface.
Screensaver
The screensaver shows a picture in the display when a period set by you has elapsed. An incoming call, pressing any key or opening the clamshell will end the function except if the safety function is activated. With code protection, the PIN must be entered.
Start up anim.
Shown when phone is switched on.
Shutdn anim.
Shown when phone is switched off.
Greeting
Enter greeting to be displayed when phone is switched on.
Large letters
You can choose between two font sizes for the display.
Illumination
Set display illumination to brighter/ darker. The darker the setting the longer the standby time.
Dynamic light
§Menu§ ¢ m ¢ Dynamic light
¢ Select function.
Two LEDs for Dynamic light are located under lift cover.
It is us ed to ind icat e vis ual ly di ffe rent even ts and functions, as well as the current phone status (e.g. network searching).
You can determine the visual signal (LEDs) on the phone for certain functions and events. The LEDs then flash in different rhythms depending on the current func­tion.
Show light effects
This enables you to switch the visual signal on and off centrally for all functions and events.
Play demo
All flash rhythms are displayed in sequence. End with flash rhythm with
§Cancel§. Show next
§Next§.
Group calls
You can assign different flash rhythms to each group.
More light...
Set the flash rhythm for other functions or events.
Call setup
§Menu§ ¢ m ¢ Call setup
¢ Select function.
Hide ID b
When you make a call, your phone number can be displayed on the recipient's display (depending on the service providers).
Call waiting b
If you are registered for this service, you can check whether it is set and you can activate/deactivate it (see also p. 17).
Divert b
You can specify when calls should be diverted to your mailbox or other numbers.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (32) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Setup32
Set up call divert (example)
The most common condition for call divert is, for example:
Unanswered
Includes the conditions Not reachable,
No reply, Busy, see p. 32. Unanswered
the phone number, to which the call should be diverted)
After a short pause, the setting is confirmed by the network.
All calls
All calls are diverted. top line of the display in standby mode.
Other possibilities for divert:
Not reachable, No reply, Busy
Status check
You can check the current divert status for all conditions.
After a short pause, the current situation is transmitted by the network and displayed.
¢ D ¢ Set ¢
¢ §OK§.
J
(enter
n is shown in the
p Condition set. o Not set. s Display if status is unknown
(e.g. with a new SIM card).
Clear all
All set diverts are cleared.
Open clamshell
Incoming calls can be accepted by opening the clamshell.
Minute beep
During a call, you will hear a beep after each minute as a reminder of the time elapsed. The recipient does not hear this beep.
Clock
§Menu§ ¢ m ¢ Clock ¢ Select function.
Time/date
The clock must be set to the right time once at start-up.
§Change§ ¢ Enter the date first, then
the time.
Time zones
Set the time zone for your area.
Time format
Select 24h or 12h.
Date format
DD.MM.YYYY or MM/DD/YYYY
Buddhist year
Switch to the Buddhist year (not on all phone models).
Show clock
Activate/deactivate time display in stand-by mode.
Automatic switch off
The phone switches off each day at the set time.
Activate:
§Time§ ¢ J Enter time (24-hour-clock)
¢ §OK§.
Deactivate:
§Manual§ ¢ §OK§
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (33) of AF51 DTC FCC us-en
Connectivity
§Menu§ ¢ m ¢ Connectivity
¢ Select function.
GPRS b
§Yes§ / §No§ Switch GPRS function on/off.
GPRS info
Display of information on connection status.
Authentication
D Activate or deactivate encrypted
Internet dial-up (CSD connections only).
Data services
§Menu§ ¢ m ¢ Connectivity
¢ Select function.
For the MMS, WAP and HTTP applications at least one connection profile must be set up and activated.
The default for the phone depends on each service provider:
• The settings have already been implemented by the provider. You can start immediately.
• Access profiles have already been created by your provider. Then select and activate profile.
• The access profiles must be configured manually.
If necessary, check with your service provider for details. If necessary enter
CSD settings and GPRS settings (your
service provider will supply you with information on this if necessary or
www.BenQ-Siemens.com/ mobilephonescustomercare
in the FAQ section).
D
¢
Select profile
¢ §Options§ ¢ §Edit§ ¢ (Enter data)
¢ Change sett.
¢ §Save§.
HTTP profile
Select profile with G. Enter or modify settings. If necessary, check with your service provider for details.
Fax/data
Rec fax/data b
The call is signalled by a special ringtone and the type of call (fax or data) is displayed. Now start the communication program in your PC to receive the fax/data.
Send voice/fax
To switch from voice mode to fax mode, set the function on the phone before transmission.
Rec voice/fax b
After starting the PC communication program, activate the function during a call.
End transmission
End transmission with PC software and/or press
b
B.
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
33Setup
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (34) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Setup34
Security
§Menu§ ¢ m ¢ Security
¢ Select function.
Babysitter
(Phone-code protected) Only one phone number can be dialled.
Only b
(PIN2 protected) Restrict calls to SIM-protected numbers in
the Phonebook.
Last 10 only
(Phone-code protected) Restrict calls to the list of
"dialled numbers" (p. 22).
Codes
PIN control, Change PIN, Change PIN2, Chg.phonecode, (p. 15).
This SIM only b
(Phone-code protected) Your phone is prevented from being used
with a different SIM card.
Barring
Network barring restricts the use of your SIM card.
All outgoing: Outgoing calls, except
emergency numbers, are barred.
Outgo internat: Only national calls can be
made.
Out.int.x home: International calls are not
permitted apart from calls to your home country.
All incoming: The phone is barred for all
incoming calls.
When roaming: You will not receive calls
when outside your home network.
Status check: Status check for network
barring.
Clear all: Clear all barrings.
Phone identity
The phone identity number (IMEI) is displayed. This information may be useful for customer service.
Alternative input in standby mode:
 0 6 
*
File system
Format
The file system memory (p. 39) is formatted and all data that has been saved is deleted, including e.g. ringtones, images, games etc..
Clean up
The file system is defragmented.
Master reset
The phone is reset to the default values (factory setting) (does not apply to SIM card or network settings).
Alternative input in standby mode:
 9 9 9 9  A
*
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (35) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
35Setup
Network
§Menu§ ¢ m ¢ Network
¢ Select function.
Line b
To select/bar a telephone number, two independent telephone numbers have to
be registered.
Network info
The list of GSM networks currently available is displayed.
Auto network selection
If activated, the next network is dialled in the order of your "preferred networks".
Choose network
Network search is restarted.
Preferred network
Set the service providers you prefer when you leave your home network.
Band selection b
Select either GSM 900, GSM 1800 or GSM 1900.
Fast search
Network reconnection is speeded up.
User group b
Depending on service provider, you can create groups with this service. These can have access to internal (company) information, for example, or special tariffs apply. Please check with your service provider for details.
Accessories
§Menu§ ¢ m ¢ Accessories
¢ Select function.
Car Kit
Auto answer
Calls are accepted automatically after a few seconds.
Headset
Accept call with Call key or ptt key (push to talk), even when the keylock is activated.
Auto answer
Calls are accepted automatically after a few seconds.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (36) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Extras36

Extras

¢¢ Select function.
§Menu§

SIM services (optional) b

Your service provider may offer special applications such as mobile banking, share prices, etc. via the SIM card.
If you have such a SIM card, the SIM services will appear in the main menu under "Extras" or directly above the left softkey with symbol
Where there are several applications, these are displayed in a SIM services menu.
With the SIM services menu, your phone is ready to support future additions in your service provider's user package. For further information, please contact your service provider.

Organizer

Calendar
You can enter appointments in the calendar. Time and date must be set for the calendar to work correctly (p. 32).
Page between days with briefly to page between weeks, press
G to page between months.
and hold Calendar days in bold face indicate appointments on this day.
Agenda
Press §Agenda§ to call up from the monthly overview. Appointments for each individual day are shown in the agenda in chronological order.
}.
H. Press G
Appointments
ç
§Menu§ ¢
All appointment entries are displayed in chronological order. If an alarm is missed it appears in the list of missed appointments (p. 37).
Enter new appointment
Press
Type:
Press required type:
Memo Text input for description. Call Enter phone number. Shown
Meeting Text input for description. Birthday Enter name and date. Anniversary
Then make further entries field by field:
Description:
Description of the appointment.
Date:
Date of appointment.
Time:
Time of appointment.
Alarm:
Activate alarm with (enter start time of the alarm before the appointment)
Hours, Days).
Recurrence:
Select a timeframe for repeating the appointment: No, Daily, Weekly, Monthly,
Annual.
Enter a parameter for repeating: Forever,
Until, Events (number).
If Weekly is selected, certain weekdays can be highlighted.
¢ Appointments
D.
H repeatedly to select the
with alarm.
Enter name and date.
§ON§
¢ J
¢ §Change§ (select Minute,
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (37) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
37Extras
Alarm
When the set date and time are reached there is an audible and a visual alarm.
Alarm type Memo/Meeting: the text is shown in the display.
Alarm type Call: The phone number is displayed and can be dialled immediately.
Alarm type Birthday and Anniversary: you will be notified one day before the event and on the birthday/ anniversary itself.
§Pause§. The alarm stops for
Press 5 minutes. Press
§Off§ to stop the alarm.
Notes
ç
§Menu§ ¢
T9 support (p. 18) makes writing short notes such as shopping lists easier. Save confidential notes with the phone code (p. 34). Please note that with the aid of suitable programs it is possible for confidential notes to be read from the phone when connected to a PC.
¢ Notes
Missed alarms
¢ç ¢ Missed alarms
§Menu§
Events with an alarm to which you have not reacted are listed for reading.
Time zones
ç
§Menu§ ¢
Set the time zone for your area.
¢ Time zones
Calend. setup
ç
§Menu§ ¢
Start of week
You can set which weekday is listed first on the left in the monthly and weekly overviews.
¢ Calend. setup

Calculator

§Menu§ ¢
number (up to 8 digits) calculator function.
Repeat procedure with other numbers. Press
Calculator functions
§.§=§+§-§*§/§ Press right softkey repeatedly.
± Toggle between "+" and "–". % Convert to percentage.
Ï,,/Ð Save /Retrieve number.
e Exponent (max. two digits).
Special keys:
* Set decimal point. 0
¢ Calculator ¢ Enter
to display result.
Add (press and hold).
¢ §.§=§+§-§*§/§ Select

Currency conv

§Menu§ ¢
Calculate the exchange rates. You can enter three currencies.
If no currency has yet been entered, press
§OK§ for the first input.
Otherwise:
§Options§
for the currencies exchange rate and
Convert
Any combination of calculations can then be carried out between the currencies entered.
Select a currency combination. Confirm with 12 digits). Press
Press using different data.
¢ Currency conv
New entry ¢ Enter symbols
¢
§OK§.
§Selection§ and enter amount (up to
§Repeat§ to start another conversion
¢ §OK§ ¢ Enter
¢ Save with §Options§
to display result.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (38) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Extras38
Calculator functions
§.§=§ Press right softkey repeatedly.
Retrieve a saved number
Ð
from the calculator.

Stopwatch

§Menu§ ¢
Two intermediate times can be recorded and saved.
Press Intermediate time. Press watch. Press
When clamshell is closed an icon on the 2nd display indicates an active stopwatch.
¢ Stopwatch
for Start/stop. Press * for
§Reset§ to reset stopwatch.
§Start§ to start stop-

Countdown

§Menu§ ¢
A set time elapses. The last 3 seconds are indicated by a beep. At the end a special beep sounds.
§Set§ Set period of time.
§Start§ Start counter.
§Stop§ Interrupt counter.
§Change§ Change period of time.
§Reset§ Reset counter to starting time.
When clamshell is closed an icon on the 2nd display indicates an active countdown.
¢ Countdown

Voice comm.

§Menu§ ¢
Functions can be started by a voice command. Up to 20 voice recordings can be saved in the phone for voice dialling or voice commands (not on SIM card!).
¢ Voice comm.
Record
§Menu§ ¢
A list with the functions available is displayed.
§Record§. Confirm selected function with
§Yes§. Press §Start§ to start recording.
A short signal sounds. Now say the command corresponding to the function and repeat it when prompted.
¢ Voice comm.
G Select function. Press
Apply
Press and hold E (in standby mode). A short signal (beep) sounds and a
prompt appears in the display. Now say the function. Noisy environments
may affect voice recognition.

Remote sync.

§Menu§ ¢
You can use this function remotely to access externally filed data (addresses, calendar, etc.) and synchronise these with the data on your phone. The data can, for example, be saved on a company computer.
Synchronize
§Start§ Computer is selected and
Sync. setup
§Setup§ Profile list is opened. Select a
§Options§ Change settings.
¢ Remote sync.
synchronisation started.
profile and
§Activate§.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (39) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
39Own stuff

Own stuff

§Menu§ ¢ Ñ
Files and folders are displayed. The following folders are provided for organising your files: Pictures, Sounds, Colour scheme, Data inbox.
You can scroll through these lists using the navigation key:
G scroll up and down.
jump back from a folder.
C
Open folder or execute file using
D
related application.
Index structure
The file system assigns special folders to different data types.
Folders Contents Format
Picture Images, Animations. *.bmp
Sounds Ring tones, melodies,
Color scheme
Data inbox Business cards,
sounds
Colour schemes *.col
appointments
*.bmx *.bmz *.gif *.jpg *.jpeg *.png
*.amr *.mid *.wav
*.vcf *.vcs
The following folders are also included in
Sounds or Picture:
Download new
New ring tone
EMS Files that can be received per
This enables you to download new files from the Internet.
This enables you to record your own ringtones (in Sounds folder only).
SMS/MMS.
Sending files
Press A to send a highlighted picture, sound, animation etc.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (40) of AF51 DTC FCC en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 051104
Customer Care40

Customer Care

We offer fast, individual advice! You have several options:
Our online support on the Internet:
www.BenQ-Siemens.com/ mobilephonescustomercare
We can be reached any time, any place. You are given 24 hour support on all aspects of our pro­ducts. Here you will find an interactive fault-finding system, a compilation of the most frequently asked questions and answers, plus user guides and current software updates to download.
When calling customer service, please have ready your receipt and the phone iden tity number (IMEI, to display press (to display, press able, your Service customer number.
Qualified employees are waiting to offer you expert information about our products and installation.
In some countries repair and replace services are impossible where the products are not sold through our authorised dealers.
If repair work is necessary, please contact one of our service centres:
Abu Dhabi .........................................0 26 42 38 00
Argentina .....................................0 81 02 22 66 24
Australia..........................................13 00 66 53 66
Austria.............................................05 17 07 50 04
Bahrain .................................................... 40 42 34
Bangladesh.......................................0 17 52 74 47
Belgium.............................................0 78 15 22 21
Bolivia ...............................................0 21 21 41 14
Bosnia Herzegovina..........................0 33 27 66 49
Brunei ..................................................02 43 08 01
Bulgaria................................................02 73 94 88
Cambodia ............................................12 80 05 00
Canada ........................................1 88 87 77 02 11
Chile..................................................8 00 53 06 62
China ..............................................40 08 88 56 56
Colombia....................................01 80 07 00 66 24
Croatia ..............................................0 16 10 53 81
Czech Republic.................................2 33 03 27 27
Denmark ..............................................35 25 86 00
Dubai ................................................0 43 96 64 33
#06#), the software version
*
#06#, then §Info§) and if avail-
*
Ecuador ..........................................18 00 10 10 00
Egypt.................................................0 23 33 41 11
Estonia.................................................. 6 30 47 97
Finland ............................................09 22 94 37 00
France.............................................01 56 38 42 00
Germany ......................................0 90 01 00 77 00
Greece ............................................80 11 11 11 16
Hong Kong.......................................... 28 61 11 18
Hungary ..........................................06 14 71 24 44
Iceland .................................................. 5 11 30 00
India.............................22 24 98 70 00 Extn: 70 40
Indonesia .....................................0 21 46 82 60 81
Ireland.............................................18 50 77 72 77
Italy .................................................02 24 36 44 00
Ivory Coast.......................................... 05 02 02 59
Jordan...............................................0 64 39 86 42
Kenya.................................................... 2 72 37 17
Kuwait ................................................... 2 45 41 78
Latvia .................................................... 7 50 11 18
Lebanon.............................................. 01 44 30 43
Libya ...............................................02 13 50 28 82
Lithuania ...........................................8 70 07 07 00
Luxembourg........................................ 43 84 33 99
Macedonia ........................................0 23 13 14 84
Malaysia....................................+ 6 03 77 12 43 04
Malta .......................................+ 35 32 14 94 06 32
Mauritius ............................................... 2 11 62 13
Mexico .......................................01 80 07 11 00 03
Morocco .............................................. 22 66 92 09
Netherlands .................................0 90 03 33 31 00
New Zealand...................................08 00 27 43 63
Nigeria ..............................................0 14 50 05 00
Norway................................................ 22 70 84 00
Oman ....................................................... 79 10 12
Pakistan ..........................................02 15 66 22 00
Paraguay ..........................................8 00 10 20 04
Peru ..................................................0 80 05 24 00
Philippines ........................................0 27 57 11 18
Poland.............................................08 01 30 00 30
Portugal ............................................8 08 20 15 21
Qatar................................................... 04 32 20 10
Romania .........................................02 12 09 99 66
Russia..........................................8 80 02 00 10 10
Saudi Arabia .....................................0 22 26 00 43
Serbia .............................................01 13 07 00 80
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (41) of AF51 DTC FCC en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 051104
41Care and maintenance
Singapore ............................................62 27 11 18
Slovak Republic ..............................02 59 68 22 66
Slovenia............................................0 14 74 63 36
South Africa ....................................08 60 10 11 57
Spain.................................................9 02 11 50 61
Sweden.............................................0 87 50 99 11
Switzerland .....................................08 48 21 20 00
Taiwan ............................................02 23 96 10 06
Thailand............................................0 27 22 11 18
Tunisia .................................................71 86 19 02
Turkey..........................................0 21 64 59 98 98
Ukraine ........................................8 80 05 01 00 00
United Arab Emirates........................0 43 66 03 86
United Kingdom ...........................0 87 05 33 44 11
Uruguay ..........................................00 04 05 46 62
USA .............................................1 88 87 77 02 11
Venezuela....................................0 80 01 00 56 66
Vietnam...........................................84 89 20 24 64
Zimbabwe ............................................04 36 94 24

Care and maintenance

Your phone has been designed and manufactured to the highest of standards and should be treated with great care. The suggestions below will help you to enjoy your phone for many years.
• Protect your phone from moisture and humidity. Precipitation, humidity and liquids contain min­erals that will corrode electronic circuits. Never­theless, should your phone become wet, disconnect it immediately from the power supply to avoid electric shock. Do not place your phone (even to dry it) on/in a source of heat such as a microwave oven, oven or radiator. The phone may become overheated and possibly explode.
• Do not use or store the phone in dusty, dirty areas. Its moving parts may be damaged and the casing may become deformed and discoloured.
• Do not store your phone in hot environments (e.g. vehicle instrument panel in the summer). High temperatures can shorten the life of elec­tronic devices, damage batteries and warp or melt certain plastics.
• Do not store your phone in cold environments. When the phone warms up again (to its normal ambient temperature), moisture can form inside the phone, which may damage electronic circuit boards.
• Do not drop, knock or shake your phone. Rough handling can damage internal circuit boards!
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the phone!
The suggestions given above apply equally to your phone, battery, charger and all accessories. If any of these parts is not working properly, obtain fast and reliable help at our service centres.
Battery quality statement
The capacity of your mobile phone battery will re­duce each time it is charged/emptied. Storage at too high or low temperatures will also result in a gradual capacity loss. As a result the operating time of your mobile phone may be considerably re­duced, even after a full recharge of the battery.
Regardless of this, the battery has been designed and manufactured so that it can be recharged and used for six months after the purchase of you mobile phone. After six months, if the battery is clearly suf­fering from loss of performance, we recommend that you replace it. Please buy only original batteries.
Display quality declaration
For technological reasons, a few small dots with different colours may appear in the display in ex­ceptional cases.
Just remember that the appearance of brighter or darker dots generally does not mean that a fault has occurred.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (42) of AF51 DTC FCC en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 051104
Product data42

Product data

Declaration of conformity
BenQ Mobile hereby declares that the phone described in this user guide is in compliance with the essential requirements and other relevant provisions of European Directive 1999/5/EC (R&TTE). The relevant declaration of conformity (DoC) has been signed. Please call the company hotline if you require a copy of the original:
www.BenQMobile.com/conformity
Technical data
GSM class: 4 (2 watt)
Frequency range: 880 –960 MHz
GSM class: 1 (1 watt)
Frequency range: 1,710 –1,880 MHz
GSM class: 1 (1 watt)
Frequency range: 1,850 –1,990 MHz
Weight: 80 g (2,8 oz)
Size: 79x 41x 19.5 mm
Li-ion battery: 600 mAh
Operating temperature:
SIM card: 3.0 V or 1.8 V
(63 ccm)
–10 °C … +55 °C (14°F to 131°F)
Phone ID
You will need the following details if you lose your phone or SIM card:
the number of the SIM card (on the card):
..............................................................
15-digit serial number of the phone (under the battery):
..............................................................
the customer service number of the service provider:
..............................................................
Lost phone
If you lose your phone or SIM card contact your service provider immediately to prevent misuse.
Operating time
The operating time depends upon usage. Extreme temperatures considerably reduce the phone’s stand­by time. You should therefore avoid the leaving the phone in the sun or on a radiator.
Talk time: 120 to 300 minutes. Standby time: 50 to 220 hours.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (43) of AF51 DTC FCC en

Accessories

Available Accessories are:
Fashion & Carry
Leather Case FCL-100
Energy
Li-Ion Battery EBA-120 (600 mAh) Travel Charger EU ETC-100 Travel Charger UK ETC-110 Car Charger Plus ECC-100
Handsfree portable
Headset Basic HHS-100 Headset HHS-110 Headset Purestyle HHS-120
Office
Data Cable DCA-100
Car Solutions
Car Kit Portable HKP-100 Mobile Holder HMH-100
Products can be obtained in specialist shops or you can visit the BenQ Mobile Store online:
Original Accessories
www.BenQMobile.com/shop
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 051104
43Accessories
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (44) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
SAR 44
SAR
INFORMATION ON RF EXPOSURE / SPECIF­IC ABSORPTION RATE (SAR)
THIS MODEL MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES
Your cellular phone is a radio transmitter and receiver. It is designed to meet the re­quirements for exposure to radio waves established by the Federal Communica­tions Commission (FCC, USA) and by Health Canada. These requirements in­clude safety margins designed to assure the protection of all persons, regardless of age and health. They use a unit of mea­surement known as the Specific Absorp­tion Rate (SAR). The SAR limit is 1.6 W/kg averaged over one gram of tissue.
The highest SAR value for this device when tested at the ear was 0.62 W/kg. In positions other than the head, such as on the body, a separation distance of 0.6 cm is required. The highest SAR value in this case was 1.05 W/kg.
Information about this device model can be found at http://www.fcc.gov/oet/fccid by searching the equipment authorization system using FCC ID: JVPBAF51.
As SAR is measured utilizing the device’s highest transmitting power, the actual SAR of this device while operating is typi­cally below that indicated above. This is due to automatic changes to the power level of the device to ensure it only uses the minimum level required to reach the
For body worn operation, this phone has been tested and meets the FCC RF exp­ osure guidelines when used with the BenQ accessories supplied or designated for this product. Use of other accessories may not ensure compliance with FCC RF exposure guidel n
network.
Additional Information can be found on the websites of the World Health Organization (http://www.who.int/emf), the Cellular Telecommunications Industry Association (CTIA) web-site at www.phonefacts.net, the Canadian Wireless Telecommunications Association (CWTA) website www.cwta.ca or BenQ Mobile (www.BenQMobile.com).
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (45) of AF51 DTC FCC us-en

U.S. FDA

The U.S. Food and Drug Administration's (FDA) Center for Devices and Radiologi­cal Health Consumer Update on Mobile Phones
FDA has been receiving inquiries about the safety of mobile phones, including cellular phones and PCS phones. The fol­lowing summarizes what is know – and what remains unknown – about whether these products can pose a hazard to health, and what can be done to mini­mize any potential risk. This information may be used to respond to questions.
Why the concern?
Mobile phones emit low levels of radio frequency energy (i.e., radio frequency radiation) in the microwave range while being used. They also emit very low levels of radio frequency energy (RF), consid­ered non-significant, when in the stand­by mode. It is well known that high levels of RF can produce biological damage through heating effects (this is how your microwave oven is able to cook food). However, it is not known whether, to what extent, or through what mecha­nism, lower levels of RF might cause ad­verse health effects as well. Although some research has been done to address these questions, no clear picture of the bi­ological effects of this type of radiation has emerged to date. Thus, the available science does not allow us to conclude that mobile phones are absolutely safe, or that they are unsafe. However, the avail­able scientific evidence does not demon­strate adverse health effects associated with the use of mobile phones.
What kinds of phones are in question?
Questions have been raised about hand­held mobile phones, the kind that have a built-in antenna that is positioned close to the user's head during normal tele­phone conversation. These types of mo­bile phones are of concern because of the short distance between the phone's an­tenna – the primary source of the RF – and the person's head. The exposure to RF from mobile phones in which the an­tenna is located at greater distances from the user (on the outside of a car, for ex­ample) is drastically lower than that from hand-held phones, because a person's RF exposure decreases rapidly with distance from the source. The safety of so-called “cordless phones,” which have a base unit connected to the telephone wiring in a house and which operate at far lower power levels and frequencies, has not been questioned.
How much evidence is there that hand-held mo­bile phones might be harmful?
Briefly, there is not enough evidence to know for sure, either way; however, re­search efforts are on-going. The existing scientific evidence is conflicting and many of the studies that have been done to date have suffered from flaws in their research methods. Animal experiments investigating the effects of RF exposures characteristic of mobile phones have yielded conflicting results. A few animal studies, however, have suggested that low levels of RF could accelerate the de­velopment of cancer in laboratory ani­mals. In one study, mice genetically al­tered to be predisposed to developing one type of cancer developed more than twice as many such cancers when they were exposed to RF energy compared to controls. There is much uncertainty among scientists about whether results obtained from animal studies apply to the use of mobile phones. First, it is uncertain how to apply the results obtained in rats and mice to humans. Second, many of the studies showed increased tumor de-
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
45U.S. FDA
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (46) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
U.S. FDA46
velopment used animals that had already been treated with cancer-causing chemi­cals, and other studies exposed the ani­mals to the RF virtually continuously – up to 22 hours per day.
For the past five years in the United States, the mobile phone industry has supported research into the safety of mo­bile phones. This research has resulted in two findings in particular that merit addi­tional study:
1. In a hospital-based, case-control study, researchers looked for an association be­tween mobile phone use and either glio­ma (a type of brain cancer) or acoustic neuroma (a benign tumor of the nerve sheath). No statistically significant associ­ation was found between mobile phone use and acoustic neuroma. There was also no association between mobile phone use and gliomas when all types of gliomas were considered together. It should be noted that the average length of mobile phone exposure in this study was less than three years.
When 20 types of glioma were considered separately, however, an association was found between mobile phone use and one rare type of glioma, neuroepithel­liomatous tumors. It is possible with mul­tiple comparisons of the same sample that this association occurred by chance. Moreover, the risk did not increase with how often the mobile phone was used, or the length of the calls. In fact, the risk ac­tually decreased with cumulative hours of mobile phone use. Most cancer causing agents increase risk with increased expo­sure. An ongoing study of brain cancers by the National Cancer Institute is expect­ed to bear on the accuracy and repeat­ability of these results.
2. Researchers conducted a large battery of laboratory tests to assess the effects of exposure to mobile phone RF on genetic material. These included tests for several kinds of abnormalities, including muta­tions, chromosomal aberrations, DNA
1
strand breaks, and structural changes in the genetic material of blood cells called lymphocytes. None of the tests showed any effect of the RF except for the micro­nucleus assay, which detects structural ef­fects on the genetic material. The cells in this assay showed changes after exposure to simulated cell phone radiation, but only after 24 hours of exposure. It is pos­sible that exposing the test cells to radia­tion for this long resulted in heating. Since this assay is known to be sensitive to heating, heat alone could have caused the abnormalities to occur. The data al­ready in the literature on the response of the micronucleus assay to RF are conflict­ing. Thus follow-up research is necessary.
FDA is currently working with govern­ment, industry, and academic groups to ensure the proper follow-up to these in­dustry-funded research findings. Collabo­ration with the Cellular Telecommunica­tions Industry Association (CTIA) in particular is expected to lead to FDA pro­viding research recommendations and sci­entific oversight of new CTIA-funded re­search based on such recommendations.
Two other studies of interest have been reported recently in the literature:
• Two groups of 18 people were exposed
• In a study of 209 brain tumor cases and
2
to simulated mobile phone signals un­der laboratory conditions while they performed cognitive function tests. There were no changes in the subjects' ability to recall words, numbers, or pic­tures, or in their spatial memory, but they were able to make choices more quickly in one visual test when they were exposed to simulated mobile phone signals. This was the only change noted among more than 20 variables compared.
425 matched controls, there was no in­creased risk of brain tumors associated with mobile phone use. When tumors did exist in certain locations, however,
3
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (47) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
47U.S. FDA
they were more likely to be on the side of the head where the mobile phone was used. Because this occurred in only a small number of cases, the increased likelihood was too small to be statisti­cally significant.
In summary, we do not have enough in­formation at this point to assure the pub­lic that there are, or are not, any low inci­dent health problems associated with use of mobile phones. FDA continues to work with all parties, including other federal agencies and industry, to assure that re­search is undertaken to provide the nec­essary answers to the outstanding ques­tions about the safety of mobile phones.
What is known about cases of human cancer that have been reported in users of hand-held mobile phones?
Some people who have used mobile phones have been diagnosed with brain cancer. But it is important to understand that this type of cancer also occurs among people who have not used mobile phones. In fact, brain cancer occurs in the U.S. population at a rate of about 6 new cases per 100,000 people each year. At that rate, assuming 80 million users of mobile phones (a number increasing at a rate of about 1 million per month), about 4800 cases of brain cancer would be ex­pected each year among those 80 million people, whether or not they used their phones. Thus it is not possible to tell whether any individual's cancer arose be­cause of the phone, or whether it would have happened anyway. A key question is whether the risk of getting a particular form of cancer is greater among people who use mobile phones than among the rest of the population. One way to an­swer that question is to compare the us­age of mobile phones among people with brain cancer with the use of mobile phones among appropriately matched people without brain cancer. This is called a case-control study. The current case­control study of brain cancers by the Na­tional Cancer Institute, as well as the fol-
4
low-up research to be sponsored by in­dustry, will begin to generate this type of information.
What is FDA's role concerning the safety of mobile phones?
Under the law, FDA does not review the safety of radiation emitting consumer products such as mobile phones before marketing, as it does with new drugs or medical devices. However, the agency has authority to take action if mobile phones are shown to emit radiation at a level that is hazardous to the user. In such a case, FDA could require the manufactur­ers of mobile phones to notify users of the health hazard and to repair, replace or recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory actions at this time, FDA has urged the mobile phone in­dustry to take a number of steps to assure public safety. The agency has recom­mended that the industry:
• Support needed research into possible biological effects of RF of the type emit­ted by mobile phones;
• Design mobile phones in a way that minimizes any RF exposure to the user that is not necessary for device func­tion; and
• Cooperate in providing mobile phone users with the best possible informa­tion on what is known about possible effects of mobile phone use on human health.
• At the same time, FDA belongs to an in­teragency working group of the federal agencies that have responsibility for different aspects of mobile phone safe­ty to ensure a coordinated effort at the federal level. These agencies are:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (48) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
U.S. FDA48
• Occupational Health and Safety Administration
• National Telecommunications and In­formation Administration
The National Institutes of Health also par­ticipates in this group.
In the absence of conclusive information about any possible risk, what can concerned individ­uals do?
If there is a risk from these products – and at this point we do not know that there is – it is probably very small. But if people are concerned about avoiding even po­tential risks, there are simple steps they can take to do so. For example, time is a key factor in how much exposure a per­son receives. Those persons who spend long periods of time on their hand-held mobile phones could consider holding lengthy conversations on conventional phones and reserving the hand-held models for shorter conversations or for situations when other types of phones are not available.
People who must conduct extended con­versations in their cars every day could switch to a type of mobile phone that plac­es more distance between their bodies and the source of the RF, since the expo­sure level drops off dramatically with dis­tance. For example, they could switch to:
• a mobile phone in which the antenna is located outside the vehicle,
• a hand-held phone with a built-in an­tenna connected to a different antenna mounted on the outside of the car or built into a separate package, or
• a headset with a remote antenna to a mobile phone carried at the waist.
Where can I find additional information?
For additional information, see the fol­lowing websites:
• Federal Communications Commission (FCC) RF Safety Program (select “Infor­mation on Human Exposure to RF Fields from Cellular and PCS Radio Transmitters”):
www.fcc.gov/oet/rfsafety
• World Health Organization (WHO) In­ternational Commission on Non-Ioniz­ing Radiation Protection (select Qs & As):
www.who.int/emf
• United Kingdom, National Radiological Protection Board:
www.nrpb.org.uk
• Cellular Telecommunications Industry Association (CTIA):
www.wow-com.com
• U.S. Food and Drug Administration (FDA) Center for devices and Radiolog­ical Health:
www.fda.gov/cdhr/consumer/
1
Muscat et al. Epidemiological Study of Cellular Telephone Use and Malignant Brain Tumors. In: State of the Science Symposium; 1999 June 20; Long Beach, California.
2
Tice et al. Tests of mobile phone signals for activ­ity in genotoxicity and other laboratory assays. In: Annual Meeting of the Environmental Mutagen So­ciety; March 29, 1999, Washington, DC; and per­sonal communication, unpublished results.
3
Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K, Butler, S, Lim, E, and Varey, A. Effect of a 915­MHz simulated mobile phone signal on cognitive function in man. Int. J. Radiat. Biol., April 8, 1999.
4
Hardell, L, Nasman, A, Pahlson, A, Hallquist, A and Mild, KH. Use of cellular telephones and the risk for brain tumors; a case-control study. Int. J. Oncol, 15: 113-116, 1999.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (49) of AF51 DTC FCC us-en

FCC/Industry Canada Notice

Your phone may cause TV or radio inter­ference (for example, when using a tele­phone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your tele­phone if such interference cannot be eliminated. If you require assistance, please contact your local service facility.
This device complies with part 15 of the FCC rules. Operation is subject to the con­dition that this device does not cause harmful interference.
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
49FCC/Industry Canada Notice
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (50) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Intellectual property50

Intellectual property

Intellectual Property Restrictions
All Intellectual Property, as defined below, which is owned by or otherwise the proper­ty of BenQ Corporation ( "BenQ Mobile"), its affiliates, partners or suppliers, relating to the Phone, including but not lim­ited to accessories, parts or software relat­ing thereto (the “Phone System”), is propri­etary under federal laws, state laws and International treaty provisions. Intellectual Property includes, but is not limited to, in­ventions (patentable or unpatentable), pat­ents, trade secrets, copyrights, software, computer programs, and related documen­tation and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) disassemble, decom­pile, reverse engineer, prepare derivative works from, modify or make any other ef­fort to create source code from the soft­ware. No title to ownership in the Intellec­tual Property is transferred to you through purchase or possession of the Phone or its components. All applicable rights of the In­tellectual Property shall remain with BenQ Mobile, its affiliates, partners or suppliers.
BenQ Mobile will have no liability with re­spect to any claim of patent infringement which is based upon the combination of the Product or parts furnished hereunder with software, apparatus or devices not furnished by BenQ Mobile, nor will BenQ Mobile have any liability for the use of an­cillary equipment or software not fur­nished by BenQ Mobile which is attached to or used in connection with the Product, The foregoing states the entire liability of BenQ Mobile with respect to infringement of patents by the Product or any parts thereof.
Laws in the United States and other coun­tries preserve for BenQ Mobile certain ex­clusive rights for copyrighted BenQ Mobile software, such as the exclusive rights to reproduce and distribute copies of such BenQ Mobile software. BenQ Mobile soft­ware may be used only in the Product in which the software was originally embod­ied when purchased, and such software in such Product may not be replaced, copied, distributed. modified in any way, or used to produce any derivative thereof. No oth­er use including, without limitation, alter­ation, modification, reproduction, distri­bution. or reverse engineering of such BenQ Mobile software or exercise of rights in such BenQ Mobile software is permit­ted. No license is granted by implication, estoppel or otherwise under BenQ Mobile patent rights or copyrights.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (51) of AF51 DTC FCC us-en

Ten Driving Safety Tips

Your BenQ wireless phone gives you the power to communicate by voice – almost anywhere, anytime. But an important re­sponsibility accompanies the benefits of wireless phones, one that every user must uphold.
When driving a car, driving is your first re­sponsibility. When using your wireless phone behind the wheel of a car, practice good common sense and remember the following tips:
Get to know your phone and its features such as speed dial and redial.
Carefully read your instruction manual and learn to take advantage of valuable features most phones offer including, au­tomatic redial and memory dial – most phones can store up to 99 numbers in memory dial. Also, work to memorize the phone keypad so you can use the speed dial function without taking your atten­tion off the road.
When available, use a hands-free device.
A number of hands-free wireless phone accessories are readily available today. Whether you choose an installed mount­ed device for your phone or a speaker phone accessory, take advantage of these devices if they are available to you.
Position your phone within easy reach.
Make sure you place your wireless phone within easy reach and where you can grab it without removing your eyes from the road. If you get an incoming call at an inconvenient time, let your voicemail an­swer it for you.
Suspend conversations during hazardous driv­ing conditions or situations.
Let the person you are speaking to know you are driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions. Rain, sleet, snow and ice can be hazardous, but so is heavy traffic. As a driver, your first responsibility is to pay at­tention to the road.
Do not take notes or look up phone numbers while driving.
If you are reading an address book or business card while driving a car, or writ­ing a “to do” list, then you are not watch­ing where you are going. It’s common sense. Don’t get caught in a dangerous situation because you are reading or writ­ing and not paying attention to the road or nearby vehicles.
Dial sensibly and assess the traffic.
If possible, place calls when you are not moving or before pulling into traffic. Try to plan your calls before you begin your trip, or attempt to coincide your calls with times you may be stopped at a stop sign, red light or otherwise stationary. But if you need to dial while driving, follow this sim­ple tip – dial only a few numbers, check the road and your mirrors, then continue.
Do not engage in stressful or emotional conver­sations that may be distracting.
Stressful or emotional conversations and driving do not mix – they are distracting and even dangerous when you are be­hind the wheel. Make people you are talk­ing with aware you are driving and if nec­essary, suspend phone conversations that have the potential to divert your attention from the road.
Use your phone to call for help.
Your wireless phone is one of the greatest tools you can own to protect yourself and your family in dangerous situations – with your phone at your side, help is only three numbers away. Dial 9-1-1 in the case of fire, traffic accident, road hazard, or medical emergency. Remember, it is a free call on your wireless phone.
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
51Ten Driving Safety Tips
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (52) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Ten Driving Safety Tips52
Use your phone to help others in emergencies.
Your wireless phone provides you a per­fect opportunity to be a “good Samaritan” in your community. If you see an auto ac­cident, crime in progress or other serious emergencies where lives are in danger, call 9-1-1, as you would want others to do for you.
Call roadside assistance or a special wireless non-emergency assistance number when nec­essary.
Certain situations you encounter while driving may require attention, but are not urgent enough to merit a call to 9-1-1. But you can still use your wireless phone to lend a hand. If you see a broken-down vehicle posing no serious hazard, a bro­ken traffic signal, a minor traffic accident where no one appears injured, or a vehi­cle you know to be stolen, call roadside assistance or other special non-emergen­cy wireless numbers.
“The wireless industry reminds you to use your phone safely when driving.”
For more information, please call 1 (888) 901-SAFE, or visit our Web site at: www.wow-com.com
Provided by the Cellular Telecommunications In­dustry Association (CTIA)
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (53) of AF51 DTC FCC us-en

End user license agreement

This Software License Agreement ("Agreement") is between You and BenQ Corporation and/or one of its affiliates ("Licensor"). The Agreement au­thorizes You to use the Software specified in Clause 1 below, which may be included on Your phone, stored on a CD-ROM, sent to You by electronic mail, downloaded from Licensor's Web pages or servers or from other sources under the terms and conditions set forth below. This is an agreement on end user rights and not an agreement for sale. Licensor continues to own the copy of the Software and any other copy that You are authorized to make pursuant to this Agreement. Read this Agreement carefully before installing, downloading or using the Software. Fur­ther, by installing, downloading and/or using the Software, You agree to the terms and conditions of this Agreement.
1. Software.
As used in this Agreement, the term "Soft­ware" means, collectively:
(i) all the software in Your phone, all of the contents of the disk(s), CD-ROM(s), electronic mail and its file attachments, or other media with which this Agreement is provided;
(ii) related Licensor or third party software; (iii) digital images, stock photographs, clip
art or other artistic works ("Stock Files"); (iv) related explanatory written materials
("Documentation"); (v) fonts; (vi) upgrades, modified versions, up-
dates, additions and copies of the Soft­ware, if any, licensed to You by Licensor (collectively "Updates") and
(vii) any other possible documentation re­lated thereto.
2. End user rights and use.
Licensor grants to You a non-exclusive, non-transferable end user right to install the Software or use the Software installed on the phone. The Software is licensed with the phone as a single integrated product and may be used with the phone only as set forth in these licensing terms.
3. Limitations on end user rights.
(a) You may not copy, distribute, or make derivative works of the Software.
(b) You may not use, modify, translate, re­produce or transfer the right to use the Software or copy the Software except as expressly provided in this Agreement.
(c) You may not resell, sublicense, rent, lease or lend the Software; except You may permanently transfer all of Your rights as set forth in the Agreement only as part of a permanent sale or transfer of the phone, provided the recipient agrees to the terms of this Agreement.
(d) You may not reverse engineer, reverse compile, disassemble or otherwise attempt to discover the source code of the Software (except to the extent that this restriction is expressly prohibited by law) or create deriv­ative works based on the Software.
(e) You shall not display, modify, reproduce or distribute any of the Stock Files included with the Software.
(f) You shall not display, modify, repro­duce or distribute any of the pre-loaded content included with the software unless permitted as stated in the User Guide or in the prompts in the Software. In the event that You are allowed to display, modify, re­produce or distribute certain parts of the pre-loaded content, You shall review the "Readme" files associated with the pre­loaded content (contained on the CD) to ascertain what rights You have with re­spect to such materials. Pre-loaded con­tent may not be used in the production of libelous, defamatory, fraudulent, infring-
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
53End user license agreement
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (54) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
End user license agreement54
ing, lewd, obscene or pornographic mate­rial or in any otherwise illegal manner. You agree that You shall only use the pre­loaded content in a manner that complies with all applicable laws, including, but not limited to, applicable restrictions concern­ing copyright and other intellectual prop­erty rights. You may not register or claim any rights in the pre-loaded content or de­rivative works there of.
(g) You agree that You shall only use the Software in a manner that complies with all applicable laws in the jurisdiction in which You use the Software, including, but not limited to, applicable restrictions concerning copyright and other intellec­tual property rights.
4. Copyright.
Licensor and/or its software suppliers and their respective affiliates own the Soft­ware and all rights, including without limi­tation including proprietary rights therein, are protected by international treaty provi­sions and other applicable national laws of the country in which it is being used. The structure, organization and code of the Software are the valuable trade se­crets and confidential information.
5. Multiple copies/updates.
If the Software supports multiple plat­forms or languages, if You receive the Software on multiple media, of if You oth­erwise receive multiple copies of the Soft­ware, the number of phones on which all versions of the Software are installed shall be one phone. If the Software is an Update to a previous version of the Soft­ware, You must possess a valid end user right to such previous version in order to use the Update and You may use the pre­vious version for ninety (90) days after You receive the Update in order to assist You in the transition to the Update. After such time You no longer have a right to use the previous version, except for the sole purpose of enabling You to install the Update.
6. Commencement & termination.
This Agreement is effective from the first date You use or install the Software. Your end user rights automatically and imme­diately terminate without notice from Li­censor if You fail to comply with any pro­vision of this Agreement. In such event, You must immediately delete, destroy or return at Your own cost and expense, and without entitlement to any refund of the purchase price, the phone and the Soft­ware, and all related material to Licensor.
7. Except as expressly provided in the limited warranty for the phone, you acknowledge the Software is provided "as is" without warranty of any kind express or implied. To the maximum extent per­mitted by applicable law neither Licensor, Licensor's Software suppliers or their re­spective affiliates, nor the copyright hold­ers make any representations or warran­ties, express or implied, including but not limited to the warranties of merchantabil­ity or fitness for a particular purpose or that the Software will not infringe any third party patents, copyrights, trade­marks or other rights. There is no warran­ty by Licensor or by any other party that the functions contained in the Software will meet your requirements or that the operation of the Software will be uninter­rupted or error free.
8. Not fault tolerant.
The Software may contain technoloy that is not fault tolerant and is not designed, manufactured, or intended for use in en­vironments or applications in which the failure of the licensed Software could lead direclty to death, personal injury, or severe physical or environmental damage or financial loss.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (55) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
55End user license agreement
9. Limitation of liability.
To the maximum extent permitted by ap­plicable law, in no event shall Licensor or Licensor's Software suppliers or their re­specitve affiliates and employees be liable for any lost profits, revenue, sales, data or costs of procurement of substitute goods or services, property damage, personal injury, interruption of business, loss of business information or for any special, direct, indirect, incidental, economic, cov­er, punitive, special or consequential damages, however caused and whether arising under contract, tort, negligence, or other theory of liability arising out of the use of or inability to use the Software, even if Licensor or its Software suppliers are advised of the possibility of such dam­ages. Because some countries/states/ju­risdictions do not allow the exclusion or limitation of liability, but may allow liabili­ty to be limited, in such cases, the liability of Licensor, its Software suppliers and their respective affiliates and employees shall be limited to, at Licensor's option, ei­ther (a) return of the price paid less a rea­sonable amount for usage, or (b) repair or replacment of the Software that does not meet the limited warranty provided with the phone and which is returned in accor­dance with the requirements of the limit­ed warranty.
Nothing contained in this Agreement shall prejudice the statutory rights of any party dealing as a consumer. Nothing contained in this Agreement limits Licen­sor's liability to You in the event of death or personal injury resulting from Licen­sor's negligence if law prohibits such a limitation. Licensor is acting on behalf of its software suppliers and their respective employees and affiliates for the purpose of disclaiming, excluding and/or restrict­ing obligations, warranties and liability as provided in this clause 9, but in no other respects and for no other purpose.
10. Technical support.
Licensor has no obligation to furnish You with technical support except as agreed in writing between You and Licensor in the Limited Warranty provided with the phone.
11. Export control.
The Software may be subject to export regulations of the United States and other countries. You agree that You shall com­ply with all applicable export laws, restric­tions and regulations of the United States or foreign agencies or authorities, and shall not export, or transfer for the pur­pose of re-export, any Software, product or technical data received under this Agreement or any Software or product produced by use of such technical data, including processes and services, in viola­tion of any applicable restrictions, laws or regulations, or without all necessary approvals.
12. Applicable law & general provisions.
This Agreement shall be governed by and construed in accordance with the laws of the State of California without regard to its conflicts of laws rules. This is the entire agreement between Licensor and You re­lating to the Software and it supersedes any prior representations, discussions, undertakings, end user agreements, com­munications or advertising relating to the Software.
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (56) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Index56

Index

A
Accessories.........................................43
Account limit ...................................... 23
Addressbook.......................................21
Agenda...............................................36
Alarm
Alarm clock.....................................27
Appointment..................................36
Type............................................... 37
All calls (call time/charge) ...................23
All calls (diversion)..............................32
Application, download........................29
Appointments.....................................36
Archive (SMS).....................................24
Audio .................................................31
Authentication....................................33
Auto display
Clock..............................................32
Duration/charges............................ 23
Auto. redial.........................................16
B
Background ........................................30
Band selection ....................................35
Battery
Charge ........................................... 12
insert..............................................12
Operating time ............................... 42
quality declaration.......................... 41
Big letters (message on display) .......... 31
Birthday
Addressbook...................................21
Appointments.................................36
Bookmarks..........................................28
Business card......................................20
Busy number ......................................16
C
Calculator...........................................37
Calendar............................................. 36
Call
Accept/end .....................................17
Barring ...........................................34
Charges..........................................23
Conference.....................................17
Divert .............................................31
End ................................................16
Reject............................................. 17
Swap (change)............................... 17
Call back............................................. 16
Call divert........................................... 31
Calling................................................ 16
Calling images (Addressbook) ............. 21
Calls dialled (call list) .......................... 23
Calls received (call list)........................ 23
Care of phone .................................... 40
Carkit ................................................. 35
Cell Broadcast (CB) ............................. 24
Charges.............................................. 23
Charging the battery .......................... 13
Clock.................................................. 32
Codes................................................. 15
Colour schemes.................................. 31
Command (voice command)............... 38
Conference ........................................ 17
Connection profile.............................. 33
Countdown ........................................ 38
Currency converter............................. 37
D
Data exchange (settings).................... 33
Date format........................................ 32
Dialling code ...................................... 16
Dialling with number keys .................. 16
Dial-up access (connection)................ 33
Direct call........................................... 17
Display
Big letters....................................... 31
Colour schemes.............................. 31
Illumination ................................... 31
Symbols......................................... 11
Display (settings)................................ 30
Divert................................................. 31
Driving safety..................................... 51
Duration/charges................................ 23
Dynamic light..................................... 31
E
Emergency number ............................ 13
End user license agreement................ 53
Entry no. (phonebook) ....................... 21
Extras................................................. 36
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
right page (57) of AF51 DTC FCC us-en
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
57Index
F
Factory settings ..................................34
Fast access..........................................28
Fast network search............................35
Filter...................................................27
G
Games & More....................................29
Games (download) .............................29
Group................................................. 22
H
Handsfree talking................................17
Headset..............................................35
Hide ID ...............................................31
Highlighting mode..............................15
Hold call ............................................. 17
Hotline ............................................... 40
HTTP-Profile........................................33
I
Identity number (IMEI)........................ 34
Illumination (display) ..........................31
IMEI number.......................................34
Inbox..................................................26
Info tones........................................... 27
Input language (T9) ............................18
L
Last 10 only........................................34
Legal notices.........................................2
Limit (call time/charge) .......................23
Logo, provider logo.............................30
Loss of phone, SIM card ......................42
M
Mailbox ..............................................23
Maintenance of phone........................41
Menu
Control...........................................14
Speed dialling................................. 15
Message
MMS ..............................................25
SMS................................................24
Minute beep .......................................27
Missed alarms.....................................37
Missed calls (call list)...........................22
MMS
Lists................................................26
Profile ............................................ 26
Receive .......................................... 25
Write.............................................. 25
N
Network
Barring........................................... 34
Line ............................................... 35
Settings ......................................... 35
Notes ................................................. 37
O
Only ............................................. 34
Only this SIM...................................... 34
Operating times (battery) ................... 42
Organiser ........................................... 36
Own files............................................ 39
Own greeting..................................... 31
Own stuff........................................... 39
P
Phone (settings)................................. 31
Phone data......................................... 42
Phone identity number (IMEI) ............. 34
Phone number transmission on/off ..... 31
Phonebook......................................... 21
Picture (Addressbook)......................... 21
PIN
Change .......................................... 15
Control .......................................... 15
Enter.............................................. 13
Preferred directory.............................. 20
Preventing accidental activation ......... 16
Product data....................................... 42
Profiles
HTTP .............................................. 33
Internet.......................................... 29
MMS .............................................. 26
Phone ............................................ 30
Provider logo...................................... 30
R
Records ........................................ 15, 22
Redial................................................. 16
Reminder ........................................... 16
Remote sync....................................... 38
Ringer setting..................................... 26
S
Safety precautions................................ 4
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
left page (58) of AF51 DTC FCC us-en,
Template: X75, Version 2.1; VAR Language: am; VAR issue date: 050711
Index58
Screensaver ........................................31
Security ........................................15
Service tones ......................................27
Set time/date ......................................32
Settings
Accessories.....................................35
Audio .............................................31
Clock..............................................32
Data connection .............................33
Display ........................................... 30
Divert .............................................31
Network .........................................35
Phone.............................................31
Profiles...........................................30
Security..........................................34
Short message (SMS)..........................24
Shut down animation .........................31
Signal strength ...................................14
Silent alert ..........................................26
SIM card
Clear barring...................................16
Insert..............................................12
SIM services (optional)........................ 36
SMS
Archive........................................... 24
Read...............................................24
T9 input .........................................18
Write ..............................................24
SOS ................................................7
Special characters ............................... 18
Speech time (battery) .........................42
Speed dialling keys .............................28
Standard values .................................. 34
Standby mode ....................................14
Standby time: .....................................42
Start animation...................................31
Start up animation.............................. 31
Stopwatch ..........................................38
Surf & fun...........................................28
Swap ..................................................17
Switch off phone
Automatic ......................................32
Manual........................................... 13
Switch on ...........................................13
Symbols..............................................11
, 34
, 13
T
T9
Text entry.......................................18
Word suggestions........................... 19
Technical data.................................... 42
Text entry with T9 .............................. 18
Text entry without T9 ......................... 18
Text module....................................... 20
Time zones................................... 14
Tones................................................. 27
, 32
U
Unanswered calls ............................... 31
Upper and lowercase letters ............... 18
User group ......................................... 35
V
Voice command ................................. 38
Voice dialling...................................... 22
Voice message (mailbox).................... 23
Volume
Handset volume............................. 16
Profiles........................................... 30
Ringer............................................ 26
© \\Itl.eu\cottbus\Projekte_30\BenQ_Mobile\AF51_Quail\output\SUG\AF51_QUAIL_1_FCC_us-
Loading...
