Benq 56E10 Users Manual
BenQ S670C
Mobile Phone User’s Manual
Copyright
© 2004. BENQ Corporation. All rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a
retrieval system or translated into any language or computer language, in
any form or by any means, electronic, mechanical, magnetic, optical,
chemical, manual or otherwise, without the prior written permission of
BENQ Corporation.
* This publication includes images from CorelDRAW® 9 which are
protected by the copyright laws of the U.S., Canada and elsewhere. Used
under license.
Disclaimer
BENQ Corporation makes no representations or warranties, either
expressed or implied, with respect to the contents hereof and specifically
disclaims any warranties, merchantability or fitness for any particular
purpose. Further, BENQ Corporation reserves the right to revise this
publication and to make changes from time to time in the contents hereof
without obligation of BENQ Corporation to notify any person of such
revision or changes.
Safety Information
Max. SAR measurement:
EU : GSM900: 1.25 W/kg; DCS1800: 0.104 W/kg.
USA : PCS1900: 1.09 W/kg.
• Specific operating restrictions,no metallic component allowed in
body-worn accessories
For your safety, please read the guidelines below carefully
before you use your phone:
Exposure to Radio Frequency Signals
Your wireless handheld portable telephone is a low power transmitter and
receiver. When it is ON, it receives and also sends out radio frequency
(RF) signals.
European and international agencies have set standards and
recommendations for the protection of public exposure to RF
electromagnetic energy.
• International Commission on Non-Ionizing Radiation Protection
(ICNIRP) 1996
• Verband Deutscher Elektringenieure (VDE) DIN- 0848
• Directives of the European Community, Directorate General V in
Matters of Radio Frequency Electromagnetic Energy
• National Radiological Protection Board of the United Kingdom, GS 11,
1988
• American National Standards Institute (ANSI) IEEE. C95.1- 1992
• National Council on Radiation Protection and Measurements (NCRP).
Report 86
• Department of Health and Welfare Canada. Safety Code 6
These standards are based on extensive scientific review. For example,
over 120 scientists, engineers and physicians from universities,
government health agencies and industry reviewed the available body of
research to develop the updated ANSI Standard.
The design of your phone complies with these standards when used
normally.
Safety Information i
Antenna Care
Use only the supplied or approved replacement antenna. Unauthorized
antennas, modifications or attachments may damage the phone and
violate FCC regulations.
Phone Operation
Normal Position: Hold the phone as you would any other telephone with
the antenna pointed up and over your shoulder.
For your phone to operate most efficiently, do not touch the antenna
unnecessarily when the phone is in use. Contact with the antenna affects
call quality and may cause the phone to operate at higher power level than
otherwise needed.
Batteries
All batteries can cause property damage, injury or burns if a conductive
material such as jewelry, keys or beaded chains touches exposed terminals.
The material may complete electrical circuit and become quite hot. To
protect against such unwanted current drain, exercise care in handling any
charged battery, particularly when placing it inside your pocket, purse or
other container with metal objects. When battery is detached from the
phone, your batteries are packed with a protective battery cover; please
use this cover for storing your batteries when not in use.
Driving
Check the laws and regulations on the use of wireless telephones in the
areas where you drive. Always obey them. Also, if using your phone while
driving, please:
• Give full attention to driving--driving safety is your first responsibility.
• Use hands-free operation, if available.
• Pull off the road and park before making or answering a call if driving
conditions so require.
ii Safety Information
Electronic Devices
Most modern electronic equipment is shielded from RF signals. However,
certain electronic equipment may not be shielded against the RF signals
from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6") inches be maintained between a handheld
wireless phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with the independent
research by and recommendations of Wireless Technology Research.
Persons with pacemakers:
• Should ALWAYS keep the phone more than six inches from their
pacemaker when the phone is turned ON.
• Should not carry the phone in a breast pocket.
• Should use the ear opposite the pacemaker to minimize the potential for
interference.
If you have any reason to suspect that the interference is taking place, turn
your phone OFF immediately.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference you may want to consult your hearing aid
manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of
your device to determine if they are adequately shielded from external RF
energy. Your physician may be able to assist you in obtaining this
information.
Turn your phone OFF in health care facilities when any regulations posted
in these areas instruct you to do so. Hospitals or health care facilities may
be using equipment that could be sensitive to external RF energy.
Safety Information iii
Ve h i c l es
RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also consult the
manufacturer of any equipment that has been added to your vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted notice so requires.
Aircraft
FCC regulations prohibit using your phone while in the air. Switch OFF
your phone before boarding an aircraft.
Blasting Areas
To avoid interfering with blasting operations, turn your phone OFF when
in a “blasting area” or in area posted “TURN OFF TWO-WAY RADIO.”
Obey all signs and instructions.
Potentially Explosive Atmospheres
Turn your phone OFF and do not remove the battery when in any area
with a potentially explosive atmosphere and obey all signs and
instructions. Sparks, from your battery, in such areas could cause an
explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always
clearly marked. They include fueling areas such as gasoline stations; below
deck on boats; fuel or chemical transfer or storage facilities; vehicles using
liquefied petroleum gas (such as propane or butane); areas where the air
contains chemicals or particles, such as grain, dust, or metal powders; and
any other area where you would normally be advised to turn off your
vehicle engine.
iv Safety Information
For Vehicles Equipped with an Air Bag
An air bag inflates with great force. DO NOT place objects, including both
installed or portable wireless equipment, in the area over the air bag or in
the air bag deployment area. If in-vehicle wireless equipment is
improperly installed and the air bag inflates, serious injury could result.
Safety Information v
vi Safety Information
Table of Contents
Safety Information ...........................................................i
1. Preparing Your Phone For Use................................... 1
Inserting a SIM Card............................................................ 1
Installing a Battery and Charging the Phone ...................... 2
Turning the Phone On ......................................................... 5
2. Getting to Know Your Phone ..................................... 7
Your Phone at a Glance........................................................ 7
Active Flip Feature.............................................................. 10
Status Indicator Light......................................................... 10
Standby Screen.................................................................... 11
External Display .....................................................................11
Icons in the External Display's Status Bar.............................12
Main Screen ............................................................................14
Icons in the Main Display's Status Bar.................................. 16
Using the Keys in the Standby Mode ....................................18
Menu Navigation................................................................ 23
3. Using Your Phone ..................................................... 33
Making a Phone Call ..........................................................33
Ending a Phone Call........................................................... 33
Answering a Phone Call .....................................................34
Rejecting an Incoming Call................................................ 35
Turning Off the Ring Tone
for an Incoming Call .......................................................... 35
Making an International Call............................................. 35
viiTable of Contents
Making an Emergency Call ................................................ 36
Dialing an Extension Number ........................................... 36
Speed Dialing ...................................................................... 36
Voice Dialing ...................................................................... 36
Listening to Voicemails...................................................... 37
Phone Book......................................................................... 38
Adding Contacts to the Phone Book.....................................38
Finding Contacts in the Phone Book .................................... 42
Using a Location Number to Access a Contact's Data ......... 45
Last Missed, Dialed, and Received Calls............................ 46
Operations During a Call................................................... 48
Call Menu ........................................................................... 49
Using the Silent Profile....................................................... 52
Camera Function................................................................ 53
Shortcuts Menu ..................................................................58
Setting Function Shortcuts ....................................................58
Setting Phone Number Shortcuts..........................................60
Using Function and Phone Number Shortcuts ....................61
Messages Menu................................................................... 62
Create ......................................................................................64
Short Message.............................................................................. 64
MMS ............................................................................................67
SIM Folder ..............................................................................72
Inbox .......................................................................................73
Template .................................................................................78
SMS Template .............................................................................78
MMS Template ........................................................................... 78
viii Table of Contents
Outbox ....................................................................................78
Drafts.......................................................................................79
Voicemail ................................................................................80
Message Settings .....................................................................80
Cleanup Messages...................................................................85
Memory Status .......................................................................85
Voice Memo........................................................................ 86
Input Modes ....................................................................... 87
Changing the Text Input Mode.............................................87
Letter Input Mode (ABC) ......................................................88
Numeric Input Mode (123)................................................... 88
Predictive Input Mode (iTap) ...............................................88
Symbol Input Mode ...............................................................90
Direct Connection to URLs ...............................................91
4. Menus.........................................................................93
Phone Book......................................................................... 93
Find .........................................................................................93
Add..........................................................................................93
Edit ..........................................................................................93
Copy ........................................................................................94
Delete ......................................................................................94
Caller Groups..........................................................................94
Privacy Manager.....................................................................96
Business Card .........................................................................97
Activate ...................................................................................98
My Number ............................................................................ 98
SIM Status...............................................................................98
ixTable of Contents
Call Records ........................................................................ 99
Missed Calls ............................................................................99
Received Calls .........................................................................99
Dialed Calls.............................................................................99
Delete All.................................................................................99
Call Duration........................................................................100
Call Cost................................................................................101
Messages............................................................................ 102
Organizer .......................................................................... 103
Calendar................................................................................103
To Do List .............................................................................105
Note.......................................................................................106
Tools.................................................................................. 106
Camera..................................................................................106
Alarm Clock..........................................................................107
Shortcuts ...............................................................................108
Voice Memo .........................................................................108
Calculator..............................................................................109
Currency Converter .............................................................109
Stopwatch .............................................................................111
Countdown Timer ...............................................................111
Memory Status .....................................................................112
Service Number ....................................................................112
SIM Toolkit Menu................................................................112
Games................................................................................ 113
Champion Soccer .................................................................113
Dragon Fight.........................................................................118
x Table of Contents
Internet.............................................................................. 119
WAP Service .........................................................................119
Start Browser ............................................................................. 120
WAP Message............................................................................126
Enter Address ............................................................................126
Resume ......................................................................................126
Clear Cache ............................................................................... 126
WAP Settings............................................................................. 126
JAVA .....................................................................................130
Multimedia ....................................................................... 134
Picture...................................................................................134
Animation............................................................................. 135
Melody ..................................................................................135
My Melodies..............................................................................135
Composer ..................................................................................137
Help ........................................................................................... 140
Album ...................................................................................140
Settings .............................................................................. 145
Date & Time .........................................................................145
Time...........................................................................................145
Format .......................................................................................145
Secondary Time........................................................................ 146
Power On/Off .......................................................................146
Profiles ..................................................................................147
Display ..................................................................................151
Theme........................................................................................151
Wallpaper ..................................................................................151
Welcome Message..................................................................... 152
Contrast..................................................................................... 153
Brightness ..................................................................................153
xiTable of Contents
Backlight Setting ....................................................................... 153
OLED Duration......................................................................... 153
OLED Animation Setting ......................................................... 154
Audio.....................................................................................154
Power Saving Mode..............................................................154
Call Settings ..........................................................................155
Call Divert ................................................................................. 155
Call Barring ............................................................................... 156
Call Waiting............................................................................... 157
Auto Redial................................................................................157
Show Number ...........................................................................157
Fixed Dial Number ...................................................................158
Active Line.................................................................................158
Connect Alert ............................................................................158
Minute Beep ..............................................................................159
Network ................................................................................159
Mode Selection..........................................................................159
Available List .............................................................................159
Band Setting .............................................................................. 160
Connection Mode .....................................................................160
Security .................................................................................160
PIN Code................................................................................... 160
Phone Lock................................................................................161
SIM Lock ................................................................................... 161
Screen Lock ............................................................................... 162
Language ...............................................................................163
Input Mode...........................................................................163
Flip Activate..........................................................................163
User Group ...........................................................................163
Restore ..................................................................................164
xii Table of Contents
5. Care and Maintenance ............................................ 165
6. Troubleshooting...................................................... 166
xiiiTable of Contents
xiv Table of Contents
Preparing Your Phone For Use
Inserting a SIM Card
1. Turn the phone over, and release the battery latch. Lift the battery off
the phone.
Battery latch
Do not remove the battery when the phone is on. Doing so could
cause you to lose personal settings or data stored either on your SIM
card or in the phone's memory.
2. Slide the SIM card in under the metal plate in the SIM card slot, with
the SIM card's metal contacts facing down and the cut corner at the
top right.
Metal plate
SIM card
A SIM card can be easily damaged if its metal contacts become
scratched. Therefore, take special care when holding or inserting it.
Preparing Your Phone For Use 1
If you wish to remove the SIM card, you
/
must first press down the stay, then push
the SIM card out of the slot.
SIM card
Stay
Installing a Battery and Charging the Phone
1. With the battery's metal contacts facing down, align the protruding
tabs on the end with the holes in the battery bay of the phone. Then
push the battery toward the end of the bay to insert the battery's tabs
into the holes. Press down to click the battery in place.
2 Preparing Your Phone For Use
2. Insert the charger connector into the charger socket on the bottom of
the phone. Make sure that the connector is inserted in the correct
orientation (with the arrow pointing up).
Charger socket
Charger connector
3. Insert the charger into a power outlet.
4. Once the phone is fully charged, remove the charger from both the
power outlet and the phone.
Preparing Your Phone For Use 3
• Charging requires approximately 4 hours.
/
• When charging the phone while it is turned off, the external and
main displays will be activated, and the status indicator light will
flash blue (during the charging process, the external display will
show the time and cycle through 3 animations, then turn off
temporarily. This is normal.
• During charging, in the external display's battery indicator ,
the lines showing the battery power level will scroll until the battery
is fully charged.
• When charging while the phone is turned off, the main display
shows the animation. If the charging is performed while the
phone is on, the main display shows the icon. The lines
showing the battery power level will scroll until the battery is fully
charged.
• After the battery is fully charged, the status indicator light will flash
purple.
• When the battery is out of power, the phone will play an alert sound
to remind you to recharge it and then will automatically turn off.
Do not remove the battery while the phone is charging.
4 Preparing Your Phone For Use
Tur n in g th e Ph one On
1. Open the phone's flip.
2. Press and hold to turn the phone on. The
phone will display the welcome animation.
• You can select and set a welcome animation, image, or message
/
that will display when you turn on your phone, as well as the music
that will be played. Go to the menu: Settings → Display →
Welcome Message. For details, please refer to page 152.
• If the welcoming music goes on too long, once the standby screen
comes up, you can press to stop playback.
3. Enter your PIN1 number. If you enter the PIN1 number incorrectly,
press (Clear) to delete the incorrect numerals. Press and
hold to delete all numerals that have been entered. After
completing entry of your PIN1 number, press to confirm.
8 The PIN (Personal Identification Number) is a password provided by
a network operator with a SIM card. You need this password in order
to use the SIM card.
If you enter the PIN incorrectly 3 times in a row, the SIM card will lock
down and no longer be usable. If this happens, you must enter the
PUK (Personal Unblocking Key) for that SIM card in order to unlock
it. Please contact your network operator to obtain a PUK.
To cancel PIN password authentication, go to the menu Settings →
/
Security → PIN Code → PIN1 Code. Please see page 160.
4. When the PIN code entered has been accepted, the phone will
Preparing Your Phone For Use 5
automatically search for the designated network. This search process
may take a few seconds.
5. The phone will then ask you whether you wish to
activate the phone book stored in the phone's
memory or on your SIM card. Press to
highlight the desired phone book and then press
to open the phone book you have selected.
6. After you open the phone book on the SIM card, any data you
browse, store, or delete will be from the SIM card's phone book. If
you open the phone book in the phone's memory, any data that you
view, store, or delete will be from the phone's phone book.
If at some later point, you wish to switch phone books, go to the
/
following menu Phone Book → Activate.
7. The standby screen will be displayed, as well as network signal
strength and the name of the network operator. You can now use the
phone.
8 If the phone cannot detect the network, the on-screen signal strength
meter will show no bars.
8 If the phone links to a network that you are not authorized to use, the
signal strength meter will show a level of zero. You will only be able to
make emergency calls.
6 Preparing Your Phone For Use
Getting to Know Your Phone
Your Phone at a Glance
The figure below shows the main parts of your phone:
Front v iew 1
Antenna
Status indicator light
External display
External speaker
Getting to Know Your Phone 7
Front view 2
Earpiece
Main display
OK key
Left soft key
Dial/Answer key
Messages menu key
Microphone
8 Getting to Know Your Phone
Scroll key
Right soft key
Power on/off key
Alphanumeric keys
Side and back views
Hands-free headset/Data cable jack
Volume k e y
Neck strap
socket
Mirror used to take
self photos
DC lens
Getting to Know Your Phone 9
Active Flip Feature
Opening the flip allows you to answer an incoming call. Closing the flip
ends a call, cancels dialing, or rejects an incoming call.
You can turn the active flip feature on or off. To do so, go to the menu:
/
Settings → Flip Activate.
Status Indicator Light
The status indicator light has the following functions:
• Flashes blue when the phone detects a network or is charging.
• Flashes purple when the battery is fully charged.
• Flashes blue rapidly when there is an incoming call.
8 To turn off the status indicator light, you must start up the power
saving mode. Go to this menu: Settings → Power Saving Mode.
10 Getting to Know Your Phone
Standby Screen
External Display
When the flip is closed, the external display's status bar will show icons
for network signal strength, battery power, and alarm (if active). The
current time and an animation will appear in sequence. The external
display can also alert you to incoming calls, text messages, and missed
calls.
• If you wish to set the time shown on the external display, go to the
/
menu Settings → Date & Time → Time. See page 145.
• In the default setting, the external display will show the time and
several animations in sequence for one cycle. The external display
will then temporarily power off. After it has powered off, you can turn
it back on by pressing either the up or down arrow on the volume
key located on the left side of the phone.
• You can set the external display's cycling mode by using the menu
Settings → Display → OLED Duration. See page 153.
• You can choose the animations to be shown on the external display
by using the menu: Settings → Display → OLED Animation
Setting. See page 154.
• You can go to the menu Settings → Profiles → Personal to
change the name of the profile to your own user name. When this
profile is activated and the phone's flip is opened, your own name
will appear on the external display. For details, see page 148.
Getting to Know Your Phone 11
Icons in the External Display's Status Bar
Icon Function Description
Signal strength
Battery status
Text message
Voicemail
Alarm
Vibrating alert
Normal
Meeting Shows that the Meeting profile is in use.
Signal strength of the network. The more
bars indicated, the stronger the signal.
Shows the current level of battery power.
The more bars indicated, the more power
that remains. Four bars: fully charged. No
bars: immediate charging needed. When
charging the phone, the icon will scroll
through the bars until the battery is fully
charged.
Shows that a text message is being received
or that there are unread text messages. If
the icon flashes, this indicates that the
SIM card's text message memory is full. For
information about the text message function,
see page 62, "Messages Menu".
Indicates that there are voicemails (this icon
will only appear if the function is supported
by your network vendor).
The alarm is turned on. To set the alarm, go
to the menu Tools → Alarm Clock. See
page 107.
In the standby screen, press and hold down
the key to activate the vibrating alert.
See page 52, "Using the Silent Profile".
Shows that the Normal profile is in use. To
set the profile, go to this menu: Settings →
Profiles. See page 147.
12 Getting to Know Your Phone
Icon Function Description
Outdoors Shows that the Outdoors profile is in use.
Personal Shows that the Personal profile is in use.
Handsfree Shows that the Handsfree profile is in use.
Shows that the call divert function is
Divert
Roaming
active.To set the call divert function go to the
menu Settings → Call Settings → Call
Divert. See page 155.
Roaming has been activated (not your
regular network)
Getting to Know Your Phone 13
Main Screen
Status bar
Time and date
Name of netwo rk
operator
Soft key bar
Press to enter
the Phone Book
Press to enter
the main menu.
14 Getting to Know Your Phone
Wal l pa pe r
Press to use the
camera function.
Loading...
