Formula Blue Medium-Duty Disc Pads
High Performance Brake Pads For Hydraulic Brake Fleet Applications
Uncompromising Performance, Outstanding Value
Today, many medium-duty truck fleets are exploring new ways to better manage margins and overall cost without sacrificing performance and quality. Formula Blue Spicer Foundation Brake were developed to address this need.
Formula Blue medium-duty pads use only proven friction material formulations that raise the bar on value and performance. Available all the key industry-standard Friction Materials Standards Institute (FMSI) styles, Formula Blue pads easily meet the needs of medium-duty vehicles on the road today.
®
disc pads from Bendix
®
Long-Wearing, Quiet­Running Durability
Advanced engineering allows Formula Blue medium-duty disc pads to provide you higher levels of performance and cost-effectiveness. Two formulations of friction materials – the 109 and 111 series products – cater to a wide range of vehicle applications.
The 109 Series (Premium) friction material is recommended for commercial vehicles where quiet operation is a key requirement. Our Formula Blue 111 series (Heavy-Duty) friction material is suggested for vocations where vehicles make repeated or significant sustained braking applications. Both are proven to perform equal to or better than competitive-brand Premium and Heavy-Duty pads.
®
Formula Blue® Medium-Duty Pads Offer a Competitive Price and Top Quality Performance
FEATURES BENEFITS
Available in all the key industry-standard FMSI styles
Broad coverage for commercial vehicle fleets
Two advanced formulations of friction pads
Long-wearing friction available for both premium and heavy-duty pads
Superior stopping power
Unique pad-to-plate mechanical anchoring design
Kind to rotors
Long-wearing and quiet-running designs suited for any Fleet’s performance and value needs
Enables long intervals between pad changes, thereby lowering Fleet’s operating costs
Provides solid brake feel, eliminating the need for excessive brake pedal force
More robust friction performance in demanding vocations with less friction lift-off during the winter driving season
Saves time and money by reducing rotor wear
Thoroughly Tested, Proven Performance
Two formulations of Formula Blue® friction products were compared against competitive-brand brake pads geared toward the same respective applications in three testing scenarios. The results con­firm that Formula Blue superior performance versus competitive brands in terms of fade and recovery, rotor and pad wear, and braking effectiveness.
®
medium-duty disc pads feature equivalent to
The backing teeth “bite” into the friction material, forming a solid mechanical adhesion between the plate and the friction material.
What you don’t see can make all the difference.
Take a look at this cutaway of a Formula Blue® disc pad and you’ll see something unique.
The hook shaped teeth, found only on the Formula Blue duty disc pad design, creates a rock-solid connection between the friction material and the backing plate. That’s a major difference between Formula Blue
®
pads and the other materials available in the market today... one that enhances and extends the durability and performance life when it’s on your vehicle.
The long-lasting, hard-working construction of a Formula Blue medium-duty disc pad helps to enhance the pad’s sheer strength and keeps the friction material stabilized, in place and on the job.
The backing teeth “bite” into the friction material, forming a solid mechanical adhesion between the plate and the friction material that can stand up to the most demanding application environments where bonded only friction fails due to separation.
®
medium-
®
Background of Analysis
The pad comparison and analysis method used, was jointly developed by Bendix Spicer Foundation Brake LLC and Link Testing Laboratories Inc. of Detroit.
Friction pad analysis was conducted on a dynamometer at Link Testing Laboratories between April 2003 and February 2004. AlliedSignal originally developed the “Hydraulic Pad Test UI-169­Modified” in the 1980s. In the charts found on each of the next few pages, brands “A, B and C” represent premium pad types, and brands “X, Y and Z” represent heavy-duty pad types.
Only the teeth – found exclusively on Formula Blue
®
medium-duty disc pads – provide long life integration between the backing plate and the friction material, binding the friction material to the plate for the entire useful life of the pad.
Find out more. Talk to your Bendix account manager today.
Rotor and Pad Wear
Braking Effectiveness
The rotor wear and pad loss tests measures the difference in pad/ rotor thickness from the beginning to the end of the dynamometer evaluation. Rotor thickness and pad loss were measured in inches, and the best performers had the lower measurements in each test.
The Formula Blue
®
Medium-Duty 109 series premium pad proved to be kind to rotors, producing rotor wear equal to or less than other premium brands. The 111 series heavy-duty pad also performed better than, or equal to, the other heavy-duty offerings tested.
And similar results were found in the pad loss test. The 109 series pad performed extremely well in comparison to the premium competitors tested, as did the 111 series compared to other heavy­duty brands.
By optimizing pad and rotor wear, Formula Blue pads are able to deliver the delicate balance of stopping performance and brake life to lower the operating cost in the widest variety of hydraulic brake applications.
Rotor Wear Comparisons: Premium and Heavy-Duty
Brands
Formula Blue
111Series
Brand Z
Brand Y
Brand X
Brand C2*
Brand C1
Brand B
Brand A
Formula Blue
109 Series*
Less is Better
SOURCE: Link Engineering; Test method #: UI-169 “Modified” (except where noted*; UI-169-”Full”)
0.001 0.0020.000 0.003 0.004 0.005 0.006 0.007
Rotor Wear (in.)
Formula Blue® 111 Series Pads
Display Equivalent-to-Superior Rotor Wear
Pad Loss Comparisons: Premium and Heavy-Duty
Brake pad effectiveness was determined by measuring the ratio between the pad-to-rotor output torque and the pressure applied to the brake pedal. Traditionally, this is called the “coefficient of friction.” The brake effectiveness ratio is summarized as an average and a standard deviation of the three dynamometer effectiveness test segments.
For hydraulic disc brakes, brake effectiveness should be a value between 0 and 1 (the higher the better), with the typical range being between 0.25 and 0.35. The ideal standard deviation score is zero.
The 109 series pad scored the highest in brake effectiveness among the four competitors tested and the second-best in standard deviation. Results for the 111 series were even more impressive. The 111 series pad scored best in both brake effectiveness and had the lowest deviation as compared to other brand-name heavy­duty pads tested.
Talk to your Account Manager for additional details or answers to any questions you may have about the comprehensive testing program.
Rotor Wear Comparisons: Premium and Heavy-Duty
Brake Effectiveness ratio between pad-to-rotor output and the pressure applied to the brake pedal
0 35
0.29
0 30
0 25
0 20
0 15
0 10
Average Brake Effectiveness
0.06
0 05
0 00
Formula Blue
109 Series*
Averages based on summarized pre and post burninsh and post fade test segment values; St Dev: Based on variation between test segments SOURCE: Link Engineering; Test method(s) #: UI-169 “Modified” (except where noted*; UI-169-”Full”)
Average Effectiveness (Higher is Better) Std Dev (Lower is Better)
0.27
0.26
0.25
0.10
0.09
0.03
Brand A Brand B Brand C1 Brand C2* Formula Blue
0.32
0.27
0.07
0.27
0.02
111Series
0.10
Brand X Brand Y Brand Z
0.31
0.30
0.09
0.04
Brands
Formula Blue
111Series
Brand Z
Brand Y
Brand X
Brand C2*
Brand C1
Brand B
Brand A
Formula Blue
109 Series*
Less is Better
SOURCE: Link Engineering; Test method #: UI-169 “Modified” (except where noted*; UI-169-”Full”)
0.05 0.15 0.25 0.35
HD-Inner Pad Loss (in.)
Formula Blue® 109 and 111 Series
Display Equivalent Pad Loss
Medium-Duty Formula Blue® 111 and 109 Series Disc Pads
Display Equivalent-to-Superior Brake Effectiveness
Fade and Recovery
During brake fade analysis, we tested to quantify the amount of decrease in a lining’s braking torque as a function of temperature and/or speed at a constant application force. The recovery test assesses the ability of a brake lining to recover braking torque as compared to the torque registered before the fade test.
In this analysis, the best performers have the least amount of fade and achieve the torque values closest to 100 percent of the pre-test values. Comparing the 109 series Formula Blue
®
pads against four
other premium-brand medium-duty pads, the results clearly favor
Fade and Recovery Comparisons: Premium Pads
Competitive Analysis - PREM Pads: Brake Fade Comparisons
60%
50%
43%
40%
Percent Fade: Lower is Better
30%
20%
10%
0%
Formula Blue-109 Series
57%
Brand A Brand B Brand C1 Brand C2
54%
57%
45%
the Formula Blue
®
disc pad. The 109 series registered the lowest fade number (43 percent) and the second-best recovery figure (103 percent) among the pads tested.
The same analysis was performed with the heavy-duty 111 series Formula Blue
®
pads and resulted in similar conclusions. The 111 series pad scored best in recovery (96 percent) and second best in fade (23 percent) compared to three major brand competitors.
Fleets need brake pads that they can count on stop after stop; Formula Blue delivers this peace of mind.
Fade and Recovery Comparisons: Heavy-Duty Pads
70%
60%
50%
40%
Percent Fade: Lower is Better
30%
20%
10%
0%
Competitive Analysis - HD Pads: Brake Fade Comparisons
65%
56%
25%
Formula Blue-111 Series
Brand X Brand Y Brand Z
17%
Competitive Analysis - PREM Pads: Brake Recovery Comparisons
110%
105%
100%
95%
Percent Recovery: Goal = 100%
90%
85%
97%
Formula Blue-109 Series
Display Equivalent-to-Superior
Fade and Recovery Performance
106%
100%
92%
Brand A Brand B Brand C1 Brand C2
Formula Blue® 109 Series
106%
120%
115%
110%
105%
100%
95%
Percent Recovery: Goal = 100%
90%
85%
104%
Formula Blue-111 Series
Display Equivalent-to-Superior
Fade and Recovery Performance
Competitive Analysis - HD Pads: Brake Recovery Comparisons
108%
Brand X Brand Y Brand Z
Formula Blue
114%
®
111 Series
95%
Limited Warranty
Formula Blue® medium-duty disc pads are covered under the standard Bendix Spicer Foundation Brake limited warranty for a period of 12 months, 12,000 miles or 1,000 operational hours, whichever occurs first.
ISO TS16949 Certified Process
Formula Blue® medium-duty disc pads are quality made and built using ISO TS16949 certified processes. They feature a unique pad­to-plate mechanical anchoring design and are field-proven through millions of miles of on-the-road experience in a variety of vocations and environments.
Applications
The “111” (Heavy-Duty) friction material for heavy-duty applications is ideal for municipal service vehicles, in-town delivery trucks, bus applications or where steep grades are regularly experienced. The “109” (Premium) friction material is recommended for straight trucks used in over-the-road applications, service vehicles or other vehicles where quiet operation is a prime concern.
Check for the Formula Blue® name on the label to ensure you‘re getting the pads with long-wearing durability and field proven performance.
These popular part numbers are just part of our broad line of medium-duty pads. Refer to them when placing your next order.
Medium-Duty Formula Blue
Series 111 Series 109 (Heavy-Duty) (Premium) Application
E111-0184-0 E109-0184-0 Twin Piston 2.60” Bendix. Freightliner/Thomas Built/Chevrolet/GMC/International/Workhorse applications. E111-0224-0 E109-0224-0 Twin Piston 2.5” Meritor. GM/Ford/Isuzu applications. E111-0225-0 E109-0225-0 Twin Piston 2.88” Bendix. International/Freightliner/Thomas Built/Bluebird/Chevrolet/GMC/Isuzu applications. E111-0236-0 E109-0236-0 Twin Piston 2.88” Meritor. GM/Ford applications. E111-0786-0 E109-0786-0 Twin Piston 73mm Bosch. International/Freightliner/Thomas Built/Sterling/Kenworth/Peterbilt/Workhorse applications. E111-0786-1 E109-0786-1 Twin Piston 66mm Bosch. International/Freightliner/Thomas Built/Sterling/Kenworth/Peterbilt/Workhorse applications. E111-0769-0 Quadralic 64mm and 70mm Meritor. GM/Freightliner/Thomas Built/Sterling/International applications.
®
Disc Pads
Quality, Value, and Outstanding Performance Are Just Part of the Formula Blue
Superior stopping power, advanced engineering and proven performance. Discover how Formula Blue disc pads can save you time and money without sacrificing quality. Talk to your Account Manager, call 1-866-610-9709 and follow the prompts (2-3-1) for the Formula Blue Tech Line, or visit www.foundationbrakes.com today.
®
Disc Pad Promise.
TO LEARN MORE ABOUT FORMULA BLUE® DISC PADS,
ALONG WITH OUR FULL LINE OF LIGHT- AND MEDIUM-DUTY HYDRAULIC
BRAKE PARTS, TALK TO YOUR BENDIX ACCOUNT MANAGER, CALL US
AT 1-866-610-9709 AND FOLLOW THE PROMPTS (2-3-1) FOR THE
FORMULA BLUE TECH LINE, OR VISIT WWW.FOUNDATIONBRAKES.COM.
®
FORMULABLUE
HYDRAULIC BRAKE PARTS
901 Cleveland Street • Elyria, Ohio 440351-866-610-9709 • www.foundationbrakes.com
BW7294 ©2010 Bendix Spicer Foundation Brake LLC • 11/10 • All Rights Reserved • Printed in U.S.A.
