bem wireless SPEAKER MOJO, mojo HL2739 User Manual
Product Overview
In order to make sure you get the best possible results from your
new Speaker Mojo, please thoroughly read and carefully follow all
instructions in this User’s Manual or on the product. Keep this User’s
Manual in a convenient location for future reference.
Package contents:
Speaker Mojo x 1
Power cradle x 1
Power adapter x 1
Micro USB charging cable x 1
Aux cable x 1
User’s Manual x 1
If any of these were missing or damaged, please visit
bemwirelesss.com to obtain replacement.
Compatibility
All devices enabled with Bluetooth technology, including iPhones,
iPads, iPods, smartphones, laptops, tablets and more.
Also compatible with any device that has a standard 3.5mm
earphone jack such as MP3 players, PSP, mobile phones, etc.
Meet the Speaker Mojo
Before learning about your Speaker Mojo, take a moment to look it
over and familiarize yourself with its features.
2
Product Interface
Speaker Mojo
1. Microphone
2. Volume +
3. Volume –
4. Play / Pause
5. Power Cradle
6. On/ Off switch
7. Bluetooth© indicator
8. Aux in
9. Micro USB power port
10. Power indicator
Power Cradle
11. USB port
12. Power Indicator
13. Charging switch
14. Micro USB power port
3
Getting Started
We know you are excited to experience your new Speaker Mojo.
These two easy steps will get you up and running quickly.
Step 1: Charge It
Connect your Speaker Mojo to an outlet using the USB charging
cable and power adapter. The red LED light will slowly flash
during charging and turn green when it has reached a complete
charge (Approx. 2 hours).
You can also put your speaker mojo onto the power cradle, and
connect it to an outlet using the USB charging cable and power
adapter to charge them both.
Step 2: Connect it
There are two options for connecting to your Speaker Mojo —
wirelessly by Bluetooth© or wired using the included aux cable.
Connect Wirelessly
Once the Speaker Mojo has entered Bluetooth mode, the
Bluetooth icon will light up and tone conrming that the unit
is currently in Bluetooth pairing mode will sound. Go to the
Bluetooth settings on your mobile phone, tablet or computer
to nd the device named “Speaker Mojo”. A tone will sound
to conrm the device has paired successfully. Next time the
Speaker Mojo and connected device will pair automatically.
Holding the Play/Pause button for 5 seconds will disconnect the
connected device and enter pairing mode for pairing a new device.
4
Step 2: Connect it (continued)
Direct Connection
The Speaker Mojo can also be connected to any device that has
a headphone jack or line out using the included aux cable.
Please note the play/pause button only operates when
connected via Bluetooth.
Operation Details
Power on / Power off
Slide the power switch to “on” to turn on the Speaker Mojo. The
Bluetooth indicator will light up to signify the unit is on and ready
to be paired.
Slide the power switch to “off” to turn off the unit and the
Bluetooth indicator light will go out.
Play modes
• Bluetooth mode: play an audio signal from the connected
Bluetooth device.
• AUX mode: play an audio signal from the connected
“wired” device.
Please note, if an Aux cable is connected to the speaker it will not
play music from Bluetooth© connected devices.
5
