Page 1
Boom Box
Page 2
Product Overview
Thank you for purchasing the be¯m wireless Boom Box. Our speaker
will bring you a new found freedom from wires while delivering
an incredible sound. The Boom Box is compatible with all devices
enabled with Bluetooth© technology... which is currently a lot of
devices!
Make sure to read through the following directions, fully charge your
device and perform the initial Bluetooth© syncing process and you
should be up and running in no time. If you have any problems stop
on by bemwireless.com for the answers to all your questions.
Package Contents
Boom Box main unit x 1
Aux cable x 1
Power adapter x 1
User manual x 1
Compatibility
• All devices enabled with Bluetooth© technology including:
iPhones, iPads, iPods, Smartphones, Laptops, Tablets and more.
• Also compatible with any device that has a standard 3.5mm
earphone jack such as MP3 players, PSP, Mobile phones, etc
2 3
Product Interface
1. Volume Up
2. Play / Pause
3. Volume Down
4. Bluetooth
5. Power Button
©
Indicator
6. Aux Out
7. Aux In
8. DC in 12V
9. Charging Indicator
Page 3
Getting Started
We know you’re excited to experience your new be¯m wireless Boom
Box. These two easy steps will get you up and running quickly.
Step 1: Charge It
Connect your Boom Box to an outlet using the included power
adapter. The red LED light will slowly flash during charging and turn
green when it has reached a complete charge (Approx. 10 hours).
4 5
Step 2: Connect It
There are two options for connecting to your Boom Box - wirelessly
by Bluetooth© or wired using the included aux cable.
• Connect Wirelessly
Once the Boom Box is powered on the Bluetooth© indicator
will light and tone confirming that the unit is currently in
Bluetooth© pairing mode will sound. Go to the Bluetooth©
settings on your mobile phone, tablet or computer to find the
device named "Boom Box". A tone will sound to confirm the
device has paired successfully. Next
time the Boom Box and connected
device will pair automatically.
• Direct Connection
The Boom Box can also be
connected to any device that has a
headphone jack or line out using the
included aux cable.
pause button only operates when connected via
Bluetooth©.
Please note the play/
Page 4
Operation Details
Power on / Power off
Slide the power switch to turn on the Boom Box. The Bluetooth©
indicator will light up to signify the unit is on and ready to be paired.
Slide the power switch again to turn off the unit and the Bluetooth©
indicator light will go out.
Please note, if the unit is not being used after 5 minutes the Boom
Box will automatically shut down to save battery power.
Play modes
Bluetooth mode: play an audio signal from the connected Bluetooth©
device.
AUX mode: play an audio signal from the connected "wired" device.
Please note, if an Aux cable is connected to the speaker it will not
play music from Bluetooth© connected devices.
Audio Use
Follow the above connection steps to pair a Bluetooth© device with
the Boom Box. At this point you can send any kind of audio signal
to your speaker (music, video, gaming, etc.). Just use your device as
normal and the audio will play through your Boom Box.
Controls
Press the Play/Pause button to play or pause the music when using a
music player through your Bluetooth© connected device
Pressing the + and - buttons will increase or decrease the volume on
6 7
the Boom Box. Please note that this will not effect the volume levels
on the connected device.
Connection
Laptop / notebook / PC
As the Bluetooth© versions for these types of devices varies greatly,
the connection methods will differ as well. If you can not connect
with the Boom Box using the previous method instructed you
may need to install a new version of the Bluetooth© driver. Please
reference the instructions of device for details.
AUX out
The Boom Box can also be used as a "bridge" to wirelessly connect
you devices to other speakers not enabled with Bluetooth©.
Plug one end of the supplied Aux cable to the “AUX OUT” port in the
back of unit and plug the other end of the cable to an “AUX IN” or
"Line In" port on any other speaker system
Please note, volume + & volume - on the Boom Box lose function
on this occasion and only the connected Bluetooth© device or the
connected speaker itself can control the volume.
Charging
Connect your Boom Box to an outlet using the supplied power
adaptor.
Page 5
Operation Details (cont.)
The charging indicator on the Boom Box will light up while charging
It will take about 10 hours to fully charge the Boom Box
Charging Indicator Light Modes
• Red LED / Flashing Fast: Battery is low, charge the unit soon.
• Red LED / Flashing Slow: Boom Box is charging
• Green LED: Battery is fully charged
Note: if the unit has not been used in the past 7 days please charge
for 10 minutes before using the Boom Box.
Battery level detection
Press “Volume -“ and “Volume +” together at the same time to enter
the indicator working mode:
4 LEDs turn on : the balance battery 76%-100%
3 LEDs turn on : the balance battery 51%-75%
2 LEDs turn on : the balance battery 26%-50%
1 LED turns on : the balance battery 1%-25%, the user should charge
the unit soon.
Troubleshooting
Issue: Pairing is unsuccessfully after multiple attempts
Solution:
• Check if the Bluetooth© indicator light is on. If the indicator
light is off, please slide the power switch to turn the unit on.
If the Bluetooth© indicator light still doesn’t come on after
sliding the power switch, please charge the unit.
• Check for other Bluetooth© devices around the surroundings
that may interfere with searching and turn devices off.
• Power off and then power on the unit to restart the Bluetooth©
function of the unit or your Bluetooth device
• Unplug any cables plugged into the AUX IN, restart all devices
and then attempt pairing again.
Issue: Interference or static during playback
Solution:
• Make sure the working distance is approximately 25 ft.
• Avoid using the device between concrete or other building
structures that may interfere with the signal.
• Please check if the battery level of the unit and the Bluetooth©
device and charge if necessary.
For more troubleshooting help go to http://bemwireless.com
8 9
Page 6
Maintenance
Please follow the instructions below for cleaning your Boom Box
• Power off the unit
• Use a soft, dry, lint-free cloth and wipe gently
• Do not use alcohol, benzene, thinners or other chemical detergents
as these can cause the casing to be warped or discolored
Storage
More Info
For questions, comments or to purchase more be¯m wireless products
go to: bemwireless.com
You can also follow us at:
facebook.com/bemwireless
twitter.com/bemwirelessco
• Power off the Boom Box If the unit will not be used for an
extended period of time.
• Do not set the unit in a damp environment, high temperatures or
in direct sunlight.
For information on your product's warranty go to:
bemwireless.com/support
youtube.com/bemwireless
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received,
including interference that may cause undesired operation.
2. Changes or modifications not expressly approved by
the party responsible for compliance could void the user's
authority to operate the equipment.
10 11
Page 7
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
FCC STATEMENT (cont.)
This equipment generates uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
Technical Parameters
Note: All specifications are subject to change without notice.
Product Name: Boom box
Model Name：HL2021A
Power Supply: 12V 2A
Battery capacity: 7.4V 8000mAh
Output power: 4.5W X 2 speaker+8W X 1 subwoofer
Bluetooth Profile Supported: A2DP, AVRCP
Working range: Approximately 25ft, 8m
Working atmosphere: 0˚C-40˚C / 20%-90%RH
be¯ m wireless
http://bemwireless.com/
be¯ m wireless LLC.
1725 Kilkenny Ct.
Woodstock, IL. USA
Made in China
12 13
Page 8
Safety Instructions
This product is specially designed based on the full attention to
safety; in order to make sure the accident-free operation, please
abide the guidelines listed below:
• Always position the unit on a stable and level surface. Unstable
surface can cause the unit to topple and fall, resulting in
possible damage or injury
• Do not drop, unpack, open, beat, curve, prink and burn the unit
• Avoid using the unit nearby basins or sinks where it may come
in contact with water
• Do not place any ware with full water on the top of the unit,
such as vase, glass, pot, and please avoid placing candle on the
speaker surface as well
• Protect the using of the unit from any overheating devices
(such as radiator, heating installation, cooking stove or other
heating devices)
• Regardless of what reasons cause the unit damage, please ask
for the maintenance personnel to repair
• If you want to do the cleaning, please turn off the unit and
unplug the power cable from the outlet first
• Set the volume properly to prevent injury to the unit and your
personal health
WARNING:
• The battery (battery or batteries or battery pack) shall not be
• No naked flame sources, such as lighted candles, should be
• CAUTION: Danger of explosion if battery is incorrectly
14 15
Correct Disposal of this product. This marking
indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent
possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly
to promote the sustainable reuse of material resources.
To return your used device, please use the return and
collection systems or contact the retailer where the
product was purchased. They can take this product for
environmental safe recycling.
exposed to excessive heat such as sunshine, fire or the like.
placed on the apparatus.
replaced. Replace only with the same or equivalent type.
