Page 1
outlet speaker
Page 2
Product Overview
Thank you for purchasing the be¯m wireless Outlet Speaker. Our
speaker will bring you a new found freedom from wires while
delivering an incredible sound. The Outlet Speaker is compatible with
all devices enabled with Bluetooth© technology... which is currently
a lot of devices!
Make sure to read through the following directions and perform the
initial Bluetooth© syncing process. You should be up and running in
no time. If you have any problems stop on by bemwireless.com for
the answers to all your questions.
Package Contents
Outlet speaker main unit x 1
Aux cable x 1
User manual x 1
Compatibility
• All devices enabled with Bluetooth© technology including:
iPhones, iPads, iPods, Smartphones, Laptops, Tablets and more.
• Also compatible with any device that has a standard 3.5mm
earphone jack such as MP3 players, PSP, Outlet phones, etc
2 3
Product Interface
1. Speaker Unit
2. Outlet Plug
3. Power Button
4. Aux In
auxi in usb aux out
5. USB Charging Port
6. Aux Out
7. Rubber Pad
Page 3
Getting Started
We know you’re excited to experience your new be¯m wireless Outlet
Speaker. These two easy steps will get you up and running quickly.
Step 1: Plug It In
Flip down the plug on the back of the speaker and connect your
Outlet Speaker to a standard edison electrical outlet. Once the unit is
plugged in press the power button to turn the speaker on and it will
automatically go into Bluetooth© pairing mode.
4 5
Step 2: Connect It
There are two options for connecting to your Outlet Speaker wirelessly by Bluetooth© or wired using the included aux cable.
• Connect Wirelessly
Once the Outlet Speaker is powered on the Bluetooth©
indicator will light and tone confirming that the unit is currently
in Bluetooth© pairing mode will sound. Go to the Bluetooth©
settings on your Outlet phone,
tablet or computer to find the
device named "Outlet Speaker".
A tone will sound to confirm the
device has paired successfully.
Next time the Outlet Speaker
and connected device will pair
automatically.
• Direct Connection
The Outlet Speaker can also be
connected to any device that has a headphone jack or line out
using the included aux cable.
operates when connected via Bluetooth©.
.
Please note the play/pause button only
aux in usb aux out
Page 4
Operation Details
Power on / Power off
Press the power button to turn the Outlet Speaker on. The
Bluetooth© indicator will light up to signify the unit is on and ready
to be paired. Press the power button again to turn off the unit and
the Bluetooth© indicator light will go out.
Please note, if the unit is not being used after 5 minutes the Outlet
Speaker will automatically shut down to save battery power.
Play modes
Bluetooth mode: play an audio signal from the connected Bluetooth©
device.
AUX mode: play an audio signal from the connected "wired" device.
Please note, if an Aux cable is connected to the speaker it will not
play music from Bluetooth© connected devices.
Audio Use
Follow the above connection steps to pair a Bluetooth© device with
the Outlet Speaker. At this point you can send any kind of audio
signal to your speaker (music, video, gaming, etc.). Just use your
device as normal and the audio will play through your Outlet Speaker.
Controls
Controlling the volume, play and pause of your audio signal is done
completely through your connected device. There are no controls on
the Outlet Speaker.
6 7
Connection
Laptop / notebook / PC
As the Bluetooth© versions for these types of devices varies greatly,
the connection methods will differ as well. If you can not connect
with the Outlet Speaker using the previous method instructed you
may need to install a new version of the Bluetooth© driver. Please
reference the instructions of device for details.
AUX out
The Outlet Speaker can also be used as a "bridge" to wirelessly
connect you devices to other speakers not enabled with Bluetooth©.
Plug one end of the supplied Aux cable to the “AUX OUT” port in the
back of unit and plug the other end of the cable to an “AUX IN” or
"Line In" port on any other speaker system
USB charge
The Outlet Speaker can also be used to charge your iPhone, iPad,
Smartphone, Tablet or other USB chargeable devices.
1. Plug the speaker into wall outlet.
2. Press the power button to turn the speaker on.
3. Plug one end of a USB charging cable (not included) into the USB
port on the unit.
4. Plug the other end of the cable into your chargeable device to
begin charging the connected device.
Page 5
Troubleshooting Maintenance
Issue: Pairing is unsuccessfully after multiple attempts
Solution:
• Check if the Bluetooth© indicator light is on. If the indicator
light is off, please press the power button to turn the unit on.
If the Bluetooth© indicator light still doesn’t come on after
pressing the power button, please charge the unit.
• Check for other Bluetooth© devices around the surroundings
that may interfere with searching and turn devices off.
• Power off and then power on the unit to restart the Bluetooth©
function of the unit or your Bluetooth device
• Unplug any cables plugged into the AUX IN, restart all devices
and then attempt pairing again.
Issue: Interference or static during playback
Solution:
• Avoid using the device between concrete or other building
structures that may interfere with the signal.
• Please check if the battery level of the unit and the Bluetooth©
device and charge if necessary.
For more troubleshooting help go to http://bemwireless.com
Please follow the instructions below for cleaning your Outlet Speaker
8 9
• Power off the unit
• Use a soft, dry, lint-free cloth and wipe gently
• Do not use alcohol, benzene, thinners or other chemical
detergents as these can cause the casing to be warped or
discolored
Storage
• Power off the Outlet Speaker If the unit will not be used for an
extended period of time.
• Do not set the unit in a damp environment, high temperatures
or in direct sunlight.
Page 6
More Info FCC STATEMENT
For questions, comments or to purchase more be¯m wireless products
go to: bemwireless.com
You can also follow us at:
facebook.com/bemwireless
twitter.com/bemwirelessco
youtube.com/bemwireless
For information on your product's warranty go to:
bemwireless.com/support
10 11
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received,
including interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
Page 7
Technical Parameters
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
be¯ m wireless
http://bemwireless.com/
be¯ m wireless LLC.
1725 Kilkenny Ct.
Woodstock, IL. USA
Made in China
12 13
Note: All specifications are subject to change without notice.
Product Name: Outlet speaker
Model: HL2018A
Input: 100-240V~50/60HZ 0.5A
Output: 1.5W x 2 RMS
Bluetooth Profile Supported: A2DP, AVRCP
Working range: Approximately 25ft, 8m
Working atmosphere: 0˚C-40˚C / 20%-90%RH
Page 8
Safety Instructions
This product is specially designed based on the full attention to
safety; in order to make sure the accident-free operation, please
abide the guidelines listed below:
• Always position the unit on a stable and level surface. Unstable
surface can cause the unit to topple and fall, resulting in
possible damage or injury
• Do not drop, unpack, open, beat, curve, prink and burn the unit
• Avoid using the unit nearby basins or sinks where it may come
in contact with water
• Do not place any ware with full water on the top of the unit,
such as vase, glass, pot, and please avoid placing candle on the
speaker surface as well
• Protect the using of the unit from any overheating devices
(such as radiator, heating installation, cooking stove or other
heating devices)
• Regardless of what reasons cause the unit damage, please ask
for the maintenance personnel to repair
• If you want to do the cleaning, please turn off the unit and
unplug the power cable from the outlet first
• Set the volume properly to prevent injury to the unit and your
personal health
Safety Instructions (cont.)
Correct Disposal of this product. This marking
indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent
possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly
to promote the sustainable reuse of material resources.
To return your used device, please use the return and
collection systems or contact the retailer where the
product was purchased. They can take this product for
environmental safe recycling.
WARNING:
• The battery (battery or batteries or battery pack) shall not be
exposed to excessive heat such as sunshine, fire or the like.
• No naked flame sources, such as lighted candles, should be
placed on the apparatus.
• CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
14 15
