USER GUIDE
3
4 Product Overview
10 Pairing
11 Technical Specs
12 Maintenance & Troubleshooting
13 FCC Statement
14 Safety Instructions
16 Warranty
54
Product Overview
Meet your New Amp 1 Bluetooth
Speaker
Thanks for purchasing the Bēm Range Amp Series 1 Bluetooth
speaker! The Amp 1 Bluetooth Speaker looks and feels unlike any
other speaker. This Bluetooth speaker delivers rich and precision
tuned sound. It is not only a Bluetooth speaker but it delivers your
music other ways. Including an FM Radio, AUX In, Micro SD slot and
USB. Also includes a mic input to sing along to your favorite tunes!
Please keep this User Guide in a convenient location for future
reference and visit bemwireless.com for additional information.
Package Contents
Amp 1 Speaker x 1
Power Adapter x 1
Remote x 1
Microphone x 1
AUX Cable x 1
User Guide x 1
Strap x 1
If any items are missing or damaged, please call bem wireless customer support at 1-855839-8616 or email support@bemwireless.com to arrange for replacements.
Before operating your Amp 1 Speaker, take a moment to look it
over and familiarize yourself with the device.
76
Meet your New Amp 1 Bluetooth
Speaker (cont.)
Meet your New Amp 1 Bluetooth
Speaker
Button Function
1. Rec Mic
Make sure you are near the mic to record
2. Record Button
Insert the USB/ TF card, press to record. When
recording, press again to stop the recording and it will
automatically play the recorded content.
3. Mode
Short press to switch to USB, TF/Micro SD, FM
function, AUX-IN, Bluetooth
4. Next
Short press for next song, in FM mode short press for
next channel.
5. Play/Pause
Short press to play/ pause, in FM mode short press to
search channel automatically; Long press to Enter/Exit
play recording les
6. Previous
Short press for previous song, in FM mode short press
for previous channel.
7. Aux In
Aux in input for devices
8. LED Display Screen
Displays current state
9. 3.5mm input
Input jack for wired microphone
10. LED Indicator
Indicator changes to red when charging. Turns blue
when done charging
11. Micro SD/TF
Insert Micro SD or TF card to record. Play music from
card also
12. USB Insert
Insert USB ash drive to record. Play music from USB
also
13 14 15 16 17 18
1 2 3 4 5 6 7 9 10 11 12
8
Amp 1 Top View
98
13. 6.5mm input
1/4" jack for microphone
14. Echo Volume
Knob to turn microphone reverberation volume up
or down
15. Microphone Volume
Knob to turn microphone volume up or down
16. Master Volume
Knob to turn volume up or down
17. On/Off Switch
Switch to turn speaker On or Off
18. Charger Input
Input to charge speaker
Meet your New Amp 1 Bluetooth
Speaker (cont.)
Meet your New Amp 1 Bluetooth
Speaker (cont.)
LED Display
00:00
1 2 3 4
5 6 7
LED Display Icon
1. Full Battery
2. USB le is currently playing
3. Time Display
4. FM Radio is currently playing
5. Half Battery, blinking means
low battery
6. TF le is currently playing
7. Recording
1. Record
2. Mute
3. Volume -
4. Repeat Mode
5. 0-9 Number Key
6. Mode
7. Play/Pause
8. Channel -
9. Channel +
10. Volume +
11. Previous
12. Next
1. Functions to record voice
2. Mute Audio
3. Press button for Volume down
4. Repeat one song or all songs
5. Choose song or FM Program by
entering number key
6. Enter FM/Bluetooth/SD Card/AUX
7. Play or Pause song. Search channel
automatically on FM radio. Long press to
enter/exit recordings
8. Press for previous radio station
9. Press for next radio station
10. Press button for Volume up
11. Press for previous song
12. Press for next song
REC
MODE
CH- CH+
VOL- VOL+
1 7
2 9
10
12
4
5
3
6
8
11
Remote Control
1110
1. Press Mode button on Amp 1 speaker until Bluetooth appears on
LED Display
3. Activate the Bluetooth feature on your device, and search for
Bluetooth devices (check your device’s manual if you’re unsure
how to do this).
4. Select ‘Amp Series 1’ from list of found devices.
5. After pairing successfully, you can then listen to your music.
Pairing your speaker with a
bluetooth device
Technical Specications
Product name Range Amp Series 1 Speaker
Model Number RG72370
Bluetooth Version 2.1 EDR
Bluetooth Range Up to 40ft
Play time Up to 4 hours
Charge time Up to 8 hours
Charge port 9V DC Adaptor
Battery Type Lithium Ion Rechargable
1312
Maintenance
Troubleshooting
• Do not use liquid to clean the speaker or other devices.
• Do not use abrasive cleaners to clean the speaker
• Dispose of the battery and the speaker according to local
regulations. Do not dispose of them as household waste.
If you cannot connect the speaker to your device, please try the
following:
– Ensure that the speaker is charged, switched on, paired with and
connected to your device
– Check the speaker is within 30 feet of your device and that
there are no obstructions (such as walls or other electronic devices)
between the speaker and the device.
– Only one device may be paired to the speaker one at a time, so
please ensure there are no conicting Bluetooth devices trying to
connect to the speaker
FCC Statement
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
2. Changes or modications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
1514
FCC Statement (cont)
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
Safety Instructions
This product is specially designed based on full attention to safety;
in order to encourage accident-free operation, please follow the
guidelines listed below:
• Never allow children to play with the speaker - small parts may
become a choking hazard
• Observe all signs and displays that require an electrical device or RF radio
product to be switched off in designated areas
• Do not drop, unpack, open, hit, bend, puncture, burn or otherwise
attempt to damage/modify the speaker
• Avoid using the speaker in the rain or near basins or sinks where
parts may come in contact with water
• Set the volume properly to prevent damage to the unit and
personal injury
• Do not attempt to modify the speaker
• Do not use the speaker outdoors in the rain or in stormy
conditions under way
• Do not clean the speaker while it is being charged
• Do not attempt to force open housings
• Only charge the speaker built in battery in accordance with the
instructions described in this user guide.
• Do not leave the speaker in direct sunlight for an extended
period of time
• Do not leave the speaker near open ames
• Do not dispose of the speaker in a re, as it will result in
explosion.
Safety Instructions (cont)
Correct Disposal of this Product
This marking indicates that this product should not be disposed of
with other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse
of material resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was purchased.
Retailers can take this product for environmentally safe recycling.
1716
bēm wireless warranties this product against defects in materials
and/or workmanship under normal use for a period of NINETY
(90) DAYS from the date of purchase by the original purchaser
(“Warranty Period”). If a defect arises and a valid claim is received
within the Warranty Period, at its option bēm wireless will either
1) Repair the defect at no charge, using new or refurbished
replacement parts or 2) Replace the product with a new product
that is at least functionally equivalent to the original product.
A replacement product or part, including a user-installable part
installed in accordance with instructions provided by bēm wireless,
assumes the remaining warranty of the original product. When a
product or part is exchanged, any replacement item becomes your
property and the replaced item becomes bēm wireless’s property.
Obtaining Service: To obtain warranty service, call bēm wireless
at 1-855-839-8616 or e-mail support@bemwireless.com. Please be
prepared to describe the product that needs service and the nature
of the problem. A purchase receipt will be required. All repairs and
replacements must be authorized in advance. Service options, parts
availability and response times will vary. You are responsible for
delivery including the cost of delivery of the product or any parts to
the authorized service center for replacements, per our instructions.
Limits and Exclusions: Coverage under this Limited Warranty is
limited to the United States of America, including the District of
Columbia and the U.S. Territories of Guam, Puerto Rico and U.S.
90-Day Limited Warranty
Virgin Islands. This warranty gives you specic legal rights and
you may also have other rights which vary from state to state. This
Limited Warranty applies only to products manufactured by or for
bēm wireless that can be identied by the bēm wireless trademark,
trade name, or logo afxed to them or its packaging. The Limited
Warranty does not apply to any non-bēm wireless products.
bēm wireless
Algonquin , IL 60102 USA
www.bemwireless.com
©2016 bēm wireless All Rights Reserved.
Made in China
1918
Stay in Touch!
For questions, comments, or to purchase additional bēm wireless products,
go to: bemwireless.com.
You can also follow us at:
facebook.com/bemwireless
youtube.com/bemwireless
bemwireless.com
