INSTALLATION & O PE RATION
INSTRUCTIONS
45cm Freestanding Dishwasher
Model No.
BDW96W
BDW96W-F FINELINE: 5104010 Aus/NZ
BDW96X
BDW96X-F
FINELINE: 5104011 Aus/NZ
V.4 SEPT17
Page 2
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Thank you
Thank you for choosing Bellini Appliances.
Bellini prides itself on ‘affordable living’ making sure there is
no compromise in your favourite room … The Kitchen
All Bellini appliances carry a 3 year In Home warranty,
be sure to retain your installation and user manual and
receipt.
For all warranty and technical queries please contact
1300 373 199
Page 3
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Content
Safety instructions-----------------------------2
Operation description------------------------4
Start using your appliance--------------------5
Maintenance ------------------------------------15
Warranty------------------------------------------23
Page 4
Important Safety Instructions
This manual explains the proper installation and use of your the appliance, please r
ead it carefully
before using even if y
ou are familiar with the product. The manual should be kept in a safe place for
future reference. In case of failure, only the Authorised Technical Service may repair this
dishwasher. Otherwise the guarantee will be null and void. All Bellini Appliances are for domestic
use only.
General Warnings
Und
er cert
ain conditions, Hydrogen gas may be
produced in a hot-water system that has not been
used for two weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot-water system has not
been used for such a period, before using the
dishwasher turn on all hot-water faucets and le
t
the water flow from each for several minutes. This
will release any accumulated hydrogen gas. As
the gas is flammable, do not smoke or use an
open flame during this time.
If the supply cord is damaged, the cord must be
replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a
hazard.
This product has not been designed for any uses
other than those specified in this booklet
.
Do not use the appliance in the event of a
technical fault. Any faults must be fixed by an
appropriately qualified and authorised person.
In the event of any incident caused by a technical
fault, disconnect the power and report the fault to
the service centre to be repaired.
The rules and provisions contained in this
instruction manual should be strictly observed.
Do not allow anybody who is not familiar with the
conte
nts of this instruction manual to operate the
appliance.
Do not abuse, sit on, or stand on the door or dish
basket of the dishwasher.
Do not touch the heating element during or
immediately after use.
Do not place any heavy objects or stand on the
door when it is open. The appliance could tip
forward.
Child Safety
This a
ppliance is not inten
ded for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they’ve been given supervision
or instruction concerning use of the appliance by a
person
responsible for their safety.
Children should be supervised to ensu
re that they
do not play with the appliance.
Avoid contact with skin and eyes, and keep
children away from the dishwasher when the door
is open.
Dishwasher detergent is corrosive! Take care to
keep it out of reach of children.
Accessible parts will also become hot when in use.
To avoid burns and scalds children should be kept
away
.
Installation, Cleaning & Servicing
The a
ppliance must be installed only by an
authorised person in compliance with the
instructions provided. Incorrect installation may
cause harm to persons, animals or may damage
property.
Before using the appliance, ensure that all packin
g
materials are removed from the appliance.
The unit's power cord must be connected to a
properly grounded and protected, 220-240V
electrical outlet. Always use ground fault protection
where required by the electrical code.
When transporting or storing the unit, keep it in a
dry location, free from dust, excessive vibration or
other factors, which may damage the unit.
Do not operate the appliance with a damaged cord,
plug o
r if the appliance has malfunctioned or ha
s
been dropped or damaged in any manner.
Return the appliance to authorised service facility
for repair.
2
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 5
Only authorised personnel shoul
d carry out
servicing. (Certificate of Compliance to be
retained)
Always ensure the appliance is switched off
before cleaning or replacing parts.
THIS APPLIANCE MUST BE EARTHE
D.
To maintain safe operation, it is recommended
that the product be inspected every five years by
an authorised service person.
During installation, the power supply must not be
excessively or dangerously bent or flattened.
Do not tamper with controls.
The appliance is to be connected to the water
mains using new hose sets, and the old hose-sets
should not be reused.
Never use a spray cleaner to clean the door panel,
it could damage the door lock and electrical
components.
Do not use the abrasive agent or some pape
r
towel because of the risk of scratching or leaving
spots on the stainless steel surface.
The appliance
Do not op
erate your dishwasher unless all
enclosure panels are properly in place. Open the
door very carefully if the dishwasher is operating.
There is a risk of water squirting out.
When loading items to be washed:
- Locate sha
rp items so that they are not likely to
damage the door seal;
- Load sharp knives with the handles up to reduce
the risk of cut-type injuries;
Warning: Knives and other utensils with sharp
points must be loaded in the basket
with their
points down or placed in a horizontal position.
When using your dishwasher, you should prevent
plastic items from contacting with heating
element.
Check that the detergent receptacle is empty af
ter
completion of the wash cycle.
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic
items not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives designed
for an automatic dishwasher. Never use soap,
laundry detergent, or hand washing detergent in
your dishwasher.
Other means for disconnection from the supply
must be inco
rporated in the fixed wiri
ng with at
least 3mm contact separation in all poles.
Dishwasher detergents are strongly alkaline. They
can be extremely dangerous if swallowed.
The door should not be left in the open position
since this could present a tripping hazard.
To avoid an accident, ensure that the appliance
shelves and fittings are always inserted into the
appliance in accordance with the instructions.
Do not use the door as a shelf.
Do not push down when the appliance doo
r is
open.
Indoor use only.
Environmental Hints
Packaging material could be dangerous for
children!
For disposing of package and the appliance
please go to a recycling centre. Cut off the power
supply cable and make the door closing device
unusabl
e.
Cardboard packaging is manufactured from
recycled paper and should be disposed in the
waste paper collection for recycling.
By ensuring this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this product.
For more detailed information about recycling of
this
product, please contact your local city office
and your household waste disposal service
This product must not be disposed together with
domestic waste. This product has to be disposed
at an authorised place for recycling of electrical
and electronic appliances.
By collecting and recycling waste,
you help save natural resources, and
make sure the product is disposed in
an environmental friendly and
healthy way.
3
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 6
3. Operation Instruction
3
Control Panel
1
7
8
13
2
3
12
6
11
14
15
5
ProgramProgram
PowerPower
DelayDelay
Start/PauseStart/Pause
3 in13 in1
1 Power switch: To turn on/off the power supply.
2 Program : Press the to scroll through the wash cycles. The corresponding
programme light will be ON to indicate which WASH CYCLES has been selected.
3D :
Child lock button: Press the two buttons for 3 seconds, the appliance could be locked
and any button can not be used. Press the two buttons for 3 seconds to unlock.
Program indicator light When you select a washing programme, the corresponding
light will display.
button button
elay button The DELAY START will allow you to delay the start time of any cycle
automatically up to 24hours.
4 Dry+ button: Press this button you can choose or cancel the Dry+ function.
5 3 in 1 button: Press this button you can choose or cancel the “3 in 1" function.
6 Start/Pause button: The appliance will start or pause the expected washing cycle.
7
8
9
Child lock :
13 Washing light: To come on when the dishwasher is washing.
Dry+ indicator: The indicator will be available when the Dry+ button is selected. An
increased temperature will improve the drying process during the final rinse stage.
10 Rinse aid refill indicator: The indicator lights up when dispenser needs to be refilled.
11 indicator The "Child Lock" will be available when you press the "Child Lock"
buttons for 3 seconds, and the "Child Lock" will be available when you press the "Child
lock"indicator lights up after flashing 6 times.
12 3 in 1 indicator: The indicator lights up when the additional function be selected.
14 Drying light: To come on when the dishwasher is drying.
15 Digital display: To display the running time remain, Malfunction codes and delay timer.
The function can be perform when you choose Intensive, Heavy, Normal.
9
Dry+Dry+
4
10
Bellini
4
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 7
Prior Using for the First Time
Dishwasher Features
Before using your dishwasher for the first time:
A. Fill the rinse aid dispenser
B. Function of detergent
A. Fill the Rinse Aid Dispenser
Function of Rinse Aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, spot and streak
free drying.
Attention!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other
substances (e.g. dishwasher cleaning agent, liquid detergent). This would damage the appliance.
When to Refill the Rinse Aid Dispenser
You can judge the amount of rinse-aid by the colour of the optical level indicator "D" located next to
the cap. When the rinse-aid container is full, the whole indicator will be dark .As the rinse aid
diminishes, the size of the dark dot decreases. You should never let the rinse aid get below 1 / 4 full.
As the rinse aid diminishes, the size of the
black dot on the rinse aid level indicator
changes, as illustrated below.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate spotting
Empty
D (Rinse-Aid indicator)
1
2
3
4
5
6
MAX
Front View
1 Upper Basket
2 Spray Arms
3 Lower Basket
4 Filters
5 Detergent Dispenser
6 Rinse Aid Dispenser
7 Cutlery basket
1
2
3
4
5
7
6
4
5
Accessory Name
1 User Manual
2 Drain hose hanger
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.bellinia
ppliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 8
To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, be careful not to overfill.
Replace the cap by inserting it aligned with "open" arrow and turning it to the "closed" (right)
arrow.
The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes
that can leave spots and streaks. It also improves drying by allowing water to sheet off the dishes.
Your dishwashers are designed to use liquid rinse aids. The rinse aid dispenser is located inside the
door next to the detergent dispenser.
To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator
turns completely black. The volume of the rinse aid container is about 140ml.
Be careful not to overfill the dispenser, because this could cause over sudsing. Wipe away any spills
with a damp cloth. Don't forget to replace the cap before you close dishwasher door.
Attention!
Clean up any rinse aid split during filling with an absorbent cloth to avoid excess foaming during the
next wash.
Adjusting Rinse Aid Dispenser
NOTE: Increase the dose if there are drops of water or lime spots on the dishes after washing.
Reduce it if there are sticky whitish streaks on the dishes or a bluish film on glassware or knife
blades.
The rinse aid dispenser has four or six settings. Always start
With the dispenser set on "4" If spots and poor drying are
Problems, increase the amount of rinse aid dispensed
by removing the dispenser lid and rotating the dial to "5”.
If the dishes still are not drying properly or are spotted,
adjust the dial to the next higher number until your dishes
are spot-free. The dose is factory set in position 5.
1
2
3
Adjust lever
(Rinse)
RINSE AID DISPENSER
22
11
33
1
2
3
4
5
6
MAX
B. Function of Detergent
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and transport it out
of the dishwasher. Most of commercial quality detergents are suitable for this purpose.
6
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.bellinia
ppliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 9
Concentrated Detergent
Based on their chemical composition, dishwasher can be split in two basic types:
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
The use of "normal" washing programme in conjunction with concentrated detergents reduces
pollution and is good for your dishes; these washing programmes are specially matched to the dirtdissolving properties of the enzymes of the concentrated detergent. For this reason"normal"
washing programme in which concentrated detergents are used can achieve the same results that
can otherwise only be achieved using"intensive" programme.
Detergent Tablets
Detergent tablets of different brands dissolve at different speeds. For this reason some detergent
cannot dissolve and develop their full cleaning power during short programmes. Therefore please
use long programmes when using detergent tablets, to ensure the complete removal of detergent
residuals.
Detergent Dispenser
The dispenser must be refilled before the start of each washing cycle following the instructions
provided in the Wash Cycle Table. Your dishwashers use less detergent and rinse aid than
conventional dishwashers. Generally, only one tablespoon of detergent is needed fora normal wash
load. Also, more heavily soiled items need more detergent. Always add the detergent just before
starting dishwasher, otherwise it could get damp and will not dissolve properly.
Amount of Detergent to Use
2
1
NOTE:
If the lid is closed: press release button. The lid springs open.
Always add the detergent just before starting each wash cycle. Only use branded detergent aid
for dishwasher.
WARNING!
Dishwasher detergent is corrosive! Take care to keep it out of reach of children
Use only detergent specifically made for use in dishwashers. Keep your detergent fresh and dry.
Don't put powder detergent into the dispenser until you're ready to wash dishes.
11 22
7
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 10
7
Fill in the detergent
Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on the right:
The place of main wash cycle detergent placed,
MIN means approximately 20g of detergent.
The place of pre-wash cycle detergent placed ,
approximately 5g of detergent.
""
2
1
Please observe the manufacturer's dosing and storage recommendations as stated on the
detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional detergent dose in the pre-wash detergent
chamber. This detergent will take effect during the pre-wash phase.
NOTE:
You find information about the amount of detergent for the single programme on the last page.
Please be aware that according to the level soiling and the specific hardness of water, differences
are possible.
Please observe the manufacturer's recommendations on the detergent packaging.
Use of "3 in 1" Detergent Tablets
General Advice
1. Before using these products you should first check that the water hard-ness in your supply is
compatible with the use of these products as the detergent manufacturers instructions (on the
product packaging).
2. These products should be strictly used according to the detergent manufacturers instructions.
3. If you encounter problems when using "3 in 1" products for the first time then please contact the
detergent manufacturers care line (the telephone number is given on the product packaging).
These products are detergents with integrated and combined detergent/rinse aid functions.
Before using these products you should first check that the water hardness in your supply is
compatible with the use of these products as per the detergent manufacturers (on the product
packaging).
1
2
3
4
5
6
MAX
2
1
To select "3in1" function:
To cancel "3in1" function:
Follow the 'Cancelling a programme in progress' instructions.
If you decide to switch to the use of a standard detergent system we advise that you:
1. Refill the rinse aid compartments.
2. Switch the water hardness setting to the highest possible position and run for three normal cycles
without load.
3. Readjust the water hardness setting again according to the conditions for your region (For more
information please refer to your instruction manual).
1. close the door and select the 3in1 washing cycle by pressing the option button until
the "3in1"indicator lights.
2. The 3in1 washing cycle will be available after pressing the start/pause button,and the
.
" 3in1"
" 3in1"
indicator lights
8
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 11
Adjusting the Upper Basket
If required, the height of the upper basket can be adjusted in order to create more space for large
utensils either in the upper basket or lower basket. The upper basket can be adjusted for height by
putting wheels of different height into the rails. Long items, serving cutlery, salad servers or knives
should be placed on the shelf so that they do not obstruct the rotation of the spray arms. The shelf
can be folded back or removed when not be required for use.
5 Loading the Dishwasher Baskets
For best performance of the dishwasher, follow these loading guidelines. Features and appearance
of baskets and Cutlery tray may vary from your model.
Attention before or after Loading the Dishwasher Baskets
1. Scrape off any large amounts of leftover food. It is not necessary to rinse the dishes under
running water. Place objects in the dishwasher in the following way:
A. Items such as cups, glasses, pots/pans, etc. are stood upside down.
B. Curve items, or those with recesses, should be at a slant so that water can run off.
C. They are stacked securely and can not tip over.
D. They do not prevent the spray arms from rotating while washing takes place.
2. Very small items should not be washed in the dishwasher as they could easily fall out of the
Baskets.
3. The upper and lower baskets can not be pull out in the same time when the dishwasher is loading,
or it may lead to dumping.
Removing the Dishes
To prevent water dripping from the upper basket into the lower basket, we recommend that you
empty the lower basket first and then the upper basket.
Loading the Upper Basket
The upper basket is designed to hold more
Delicate and lighter dishware such as
glasses, coffee and tea cup and
saucers, as well as plates,
small bowls and shallow
pans (as long as they are
not too dirty). Position the
dishes and cookware so
that they do not get
Moved by the
Spray of water.
Upper Basket
Upper basket
Type
Item
Cup
Glass
Saucer
A
B
C
C1
C9
B1
B9
A1
A9
A
B
C
9
Notice:
To avoid the poor cleaning,we
recommend that you load the cups or
saucers not beyond the steel wire limits
on the edge of basket.
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 12
9
Lower basket
Type
Item
Dessert plate
G
H
I
Dinner plate
Soup plate
Dessert plate
Upper and Lower basket Folding racks
Folding racks consisting of two parts
that are located on the upper and lower
basket of your machine are designed in
order to let you place big items easier
as pots, pans, etc. If requested, each
part can be folded separately, or all of
them can be folded and larger can be
obtained. You can use folding racks by
rasing then upwards, or by folding.
For optional
Upper Baske
t
Lower Basket
2
1
1
2
Basket height adjustment mechanism on the upper basket of your machine is designed
to let you adjust the height of your upper basket upwards or downwards,without
removing it from your machine when it is full,and create large spaces at the top or
bottom area of your machine as needed.Basket of your machine is set to lower position
in factory settings.
1. To lower the upper basket, press the levers located at the left and right sides of the
upper basket and push the upper basket downwards slightly at the same time.
2. To raise the upper basket, just pull the upper basket upwards without operating any
levers.
NOTE In loaded basket adjustment mechanism, make sure that both sides are in the
same position(up or down).
Upper Basket Height Adjustment
To lower position
To upper position
1
2
H9 H1
G9 G2
I9
I2
G1
I1
10
Upper ba
sket can be adjusted for height by putting
wheels of different height into the rails. Long items,
serving cutlery, salad servers or knives should be
placed on the shelf so that they do not obstruct the
rotation of the spray arms.
Attention:
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 13
For washing in the dishwasher the following cutlery/dishes
Are not suitable
Cutlery with wooden, horn china or
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that is not
temperature resistant
Bonded cutlery items or dishes
Pewter or cooper items
Lead crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibre
WARNING!
Do not let any item extend through bottom
Are of limited suitability
Some types of glasses can become
dull after a large number of washes
Silver and aluminium parts have a
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
NOTE: Do not put in items that are dirty of cigarette ash, candle wax, lacquer or paint. If you buy
new dishes please make sure that they are suitable for dishwashers.
Cutlery tray
Arrange the cutlery in the tray as shown. Cutlery should be placed to ensure that water
runs off freely.
Door side
Cutlery basket
Door side
Cutlery basket
Type
Item
T
ea spoons
Dessert spoons
Soup spoons
Forks
Knives
1
2
3
4
5
1 2
3
4
5
11
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ,
BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 14
NOTE: Please do not overload your dishwasher. There is only space for 9 standard dishes. Do not
use dish that is not suitable for dishwashers. This is important for good results and for reasonable
energy consumption.
Before loading the dishes, you should:
Remove large left-over
Soften remnants of burnt food in pans
Loading Cutlery and Dishes
When Loading the Dishes and Cutlery, Please Note:
Dishes and cutlery must not impede the rotation of the spray arms.
Load hollow items such as cups, glasses, pans etc. with the opening downwards so that water cannot
collect in the container or a deep base.
Dishes and items of cutlery must not lie inside one another, or cover each other
To avoid damage to glasses, they must not touch
Load large items which are most difficult to clean into the lower basket
The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee and
tea cups
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned horizontally in the upper
basket
Attention!
Damage to Glassware and other Dishes
Possible causes:
Type of glass or manufacturing process. Chemical composition of detergent.
Water temperature and duration of dishwasher programme.
Suggested remedy:
Use glassware or porcelain dishes that have been marked dishwasher-proof by the manufacturer.
Use a mild detergent that is described as kind of dishes. If necessary, seek further information from
detergent manufacturers.
Select a programme with a low temperature.
To prevent damage, take glass and cutlery out of the dishwasher as soon as possible after the
programme has ended.
At the End of the Wash
When the working cycle has finished, the buzzer of dishwasher will ring for 6 times, then stop. Turn
off the appliance using the " Power " button, shut off the water supply and open the door of the
dishwasher. Wait a few minutes before unloading the dishwasher to avoid handling the dishes and
utensils while they are still hot and more susceptible to breakage. They will also dry better.
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
12
Page 15
6. Starting a Washing Programme
Wash cycle table
Program
Cycle Selection
Information
Description
of Cycle
Detergent
Pre/main
Running
Time
(min)
Energy
(kWh)
Water
(L)
Intensive
Heavy
For the heaviest soiled loads,
such as pots, pans, casserole
dishes and dishes that have
been sitting with dried food
on them for a while.
For normally soiled loads,
such as pots, plates, glasses
and lightly soiled pans.
standard daily cycle.
Rapid
Soak
A shorter wash for lightly
soiled loads that do not
need drying.
To rinse dishes that you
plan to wash later that day
Starting a wash cycle...
Draw out the lower and upper basket, load the dishes and
1. push them back. It is recommended to load the lower basket first, then the upper one (see the
section entitled "Loading the Dishwasher"). Pour in the detergent .
Turning on the Appliance
AS/NZS 2007.1:This programme is the test cycle. The information for comparability test
in accordance with AS/NZS.2007.1, as follows:
- Capacity: 9 settings
- Position of Upper basket: Low position
- Rinse aid setting:5 or 4 for four setting dispenser)
Pre-wash(40 )
Main wash(55 )
Rinse1
Rinse2
Hot rinse(65 )
Drying
Main wash(60 )
Rinse 1
Rinse 2
Hot rinse(65 )
Drying
Main wash(44 )
Rinse
Hot rinse(46 )
Drying
Main wash(40 )
Hot rinse(50 )
Pre-wash
15g
137
122
110
43
8
0.56
15.0
11.5
9.4
6.0
3.3
Normal
(AS/NZS 2007.1)
NOTE:
For heavy soiled loads,
such as pots, plates, glasses
and lightly soiled pans.
standard daily cycle.
We recommend you open the door slightly 50mm to assist in drying of the dishes
after every wash.
1.10
1.00
0.48
0.01
/
Rinse
Pre-wash
Hot rinse(70 )
Drying
60
0.69
6.0
For dishes that need to be
rinsed and dried only
4/22g
(Or 3 in 1)
4/22g
(Or 3 in 1)
4/22g
(Or 3 in 1)
4/22g
13
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 16
NOTE: If all the lights begin to glimmer, that indicates the machine is out of order, please turn off the
main power and water supply before calling a service.
Forget to Add Dish
A forgotten dish can be added any time before the detergent cup opens.
1 Open the door a little to stop the washing.
2 After the spray arms stop working, you can open the door completely.
3 Add forgotten dishes.
4 Close the door, the dishwasher will work after ten seconds.
WARNING!
It is dangerous to open the door when washing, because the hot water may scald you.
Switch Off the Dishwasher
The digital display appears "---” and the buzzer rings 6 times, only in this case the programme
has ended.
1.Switch off the dishwasher by pressing the " Power " button.
2.Turn off the water tap!
Open the door carefully. Hot steam may escape when the door is opened!
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down around
15 minutes before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In
this way they will be cooler and the drying will be improved.
Unloading the dishwasher
It is normal that the dishwasher is wet inside.
Empty the lower basket first and then the upper one. This will avoid water dripping from the upper
basket onto the dishes in the lower one.
Change the Programme.
Premise: A cycle that is underway can only be modified if it has only been running for a short time.
Otherwise, the detergent may have already been released, and the appliance may have already
drained the wash water. If this is the case, the detergent dispenser must be refilled (see the section
entitled " Fill in the Detergent " ).
Open the door, Press current programme button more than three seconds to cancel the programme,
then you can change the programme to the desired cycle setting (see the section entitled "Starting a
wash cycle. . . " ). Then, close the door.
NOTE: If you open the door when washing, the machine pauses and warning alarm rings, the display
appears E1. When you close the door, the machine will keep on working after 10 seconds.
The 6 programme lights show the state of the dishwasher:
a) All program lights off --> stand by
b) One of the program lights on --> cycle running
c) One of the program lights blinking --> pause
NOTE: A click could be heard when the door is closed perfectly.
When the washing is over, you can shut off the switch by pressing " Power " button.
13
Make sure that the water supply is turned on to full pressure. Open the door, press the " Power "
button, Press the "program." button to select a desired "Wash cycle". (See the section entitled "Wash
Cycle Table".)
With a little force to ensure the door is properly closed.
2. Insert the plug into the socket. The power supply is 220-240V AC 50 Hz, the specification of the
socket is 12 A 250 VAC.50 Hz.
14
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 17
15
Filtering System
The filter is used to avoid the big remnants and other sundries getting inside
the pump. The residue can obstruct the filter in sometime.
The filter system consists of a coarse filter, a flat
(Main filter) and a micro filter (fine filter).
1 Flat filter
Food and debris will be trapped by a special jet
on the lower spray arm.
2 Coarse filter
Big debris, such as bone and glass that could clog the
drain will be trapped in the coarse filter.
To remove an item caught in this filter, gently squeeze
the taps on the top of this filter and lift it out.
3 Micro filter
This filter holds soil and food residue in the sump area
and prevents it from being redeposit on the dishes
during a cycle.
- Inspect the filters for obstructions every time the
dishwasher has been used.
- By unscrewing the coarse filter, you can remove
the filter system. Remove any food remnants and
clean the filters under running water.
Step 1 contrarotate the
Coarse filter ,and then lift it up;
Step 2 lift the Flat filter up
7. Maintenance and cleaning
NOTE: If operate from step 1 to step 2, the filter system will be removed; while operate from step 2
to step 1, the filter system will be installed .
Filter assembly
For best performance and results, the filter assembly must be cleaned. The filter efficiently removes
food particles from the wash water, allowing it to be recirculated during the cycle. For this reason, it
is a good idea to remove the larger food particles trapped in the filter after each wash cycle by rinsing
the semicircular filter and cup under running water. To remove the filter assembly, pull on the cup
handle in the upward direction. The entire filter assembly should be cleaned once a week. To clean
the coarse filter and the micro filter, use a cleaning brush. Then, reassemble the filter parts as shown
in the figures above and reinsert the entire assembly in the dishwasher, positioning in its seat and
pressing downward. The dishwasher must never be used without the filters. Improper replacement
of the filter may reduce the performance level of the appliance and damage dishes and utensils.
3
3
1 2
1
3
2
GSM Sales Pty Lt
d ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 18
WARNING!
Never run the dishwasher without the filters in place. When cleaning the filters, don't knock on them.
Otherwise, the filters could be contorted and the performance of dishwasher could be debased.
Cleaning the Spray Arms
It is necessary to clean the spray arms regularly for hard
water chemicals will clog the spray arm jets and bearings.
To remove the spray arms, screw off the nut clockwise to
take out the washer on top of the spray arm and remove the
arm. Wash the arms in soapy and warm water and use a soft
brush to clean the jets. Replace them after rinsing thoroughly.
Caring for the Dishwasher
To clean the control panel, use a lightly dampened cloth then
dry thoroughly.
To clean the exterior, use a good appliance polish wax.
Never use sharp objects, scouring pads or harsh cleaners
on any part of the dishwasher.
Protect Against Freezing
If your dishwasher is left in an unheated place during the winter, ask a service technical to:
1.Cut off electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain water from the inlet pipe and water valve. (Use a pan to catch the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter in the tub and the bottom and use a sponge to use up water in sump
Cleaning the Door
To clean the edge around the door, you should use only a soft warm, damp rag. To prevent
penetration of water into the door lock and electrical components, do not use a spray cleaner of any
kind.
Also, never use abrasive cleaners or scouring pads on the outer surfaces because they will scratch
the finish. Some papers towels can also scratch or leave marks on the surface.
WARNING!
Never use a spray cleaner to clean the door panel for it could damage the door lock and electrical
components. It is not allowed to use the abrasive agent or some paper towel because of the risk of
scratching or leaving spots on the stainless steel surface.
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
16
Page 19
How to Keep Your Dishwasher in Shape
After Every Wash
After every wash, turn off the water supply
to the appliance and leave the door slightly
ajar so that moisture and odors are not
trapped inside.
Remove the Plug
Before cleaning or performing
maintenance, always remove the plug from
the socket. Do not run risks.
No Solvents or Abrasive Cleaning
To clean the exterior and rubber parts of
the dishwasher, do not use solvents or
abrasive cleaning products. Use only a
cloth and warm soapy water. To remove
spots or stains from the surface of the
interior, use a cloth dampened with water
and a little white vinegar, or a cleaning
product made specifically for dishwashers.
When You Go on holiday
When you go on holiday, it is
recommended that you run a wash cycle
with the dishwasher empty and then
remove the plug from the socket, turn off
the water supply and leave the door of the
appliance slightly ajar. This will help the
seals last longer and prevent odors from
forming in the appliance.
Moving the Appliance
If the appliance must be moved, try to keep
it in the vertical position. If absolutely
necessary, it can be positioned on its back.
Seals
One of the factors that cause odors to form
in the dishwasher is food that remains
trapped in the seals. Periodic cleaning with
a damp sponge will prevent this.
Attention:
The installation of the pipes
and electrical equipments
should be done by professionals.
Electrical Shock Hazard!
Disconnect electrical power before
installing dishwasher.
Failure to do so can result in death or
electrical shock.
Warning
8. Installation
Keep this instruction manual in a safe place for future reference. If the appliance is sold, given
away or moved, please ensure the manual is kept with the machine, so that the new owner may
benefit from the advice contained within it.
Please read this instruction manual carefully: it contains important information regarding the safe
installation, use and maintenance of the appliance.
If the appliance must be moved at any time, keep it in an upright position; if absolutely necessary,
it may be tilted onto its back.
Positioning and leveling
1. Remove the appliance from all packaging and check that it has not been damaged during
transportation. If it has been damaged, contact the retailer and do not proceed and further with the
installation process.
2. Check the dishwasher by placing it so that its sides or back panel are in contact with the adjacent
cabinets or even with the wall. This appliance can also be recessed under a single worktop (see the
Assembly instruction sheet).
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
17
Page 20
3. Position the dishwasher on a level and sturdy floor. If the floor is uneven, the front feet of the
appliance may be adjusted until it reaches a horizontal position (the angle of inclination must not
exceed 2 degrees). If the appliance is levelled correctly, it will be more stable and much less likely to
move or cause vibrations and noise while it is operation.
Connection to the water and electricity supplies should only be performed by a qualified
technician.
The dishwasher should not stand on top of the water hoses or the electricity supply cable
The appliance must be connected to the water supply network using new piping. Do not use old
piping.
Connecting the water inlet hose
Fit the drainage hose of your machine to the drainage pipe
without bending.
If the length of the hose is not sufficient, apply to the
authorized service for an extension made from the same
material as the original. Remember that the length of the
hose should not exceed 4meters even when with an
extension.
If the drainage hose is longer the 4 m. the dishes will not
be cleaned properly secure your hose firmly to the drainage
pipe to avoid it coming off during the washing process.
Connecting the water outlet hose
Electrical connection
Before inserting the plug into the electrical socket, make sure that:
the socket is earthed and complies with current regulations;
the socket can withstand the maximum load of the appliance, which is indicated on the data plate
located on the inside of the door(see description of the appliance);
the power supply voltage falls within the values indicated on the data plate on the inside of the door;
the socket is compatible with the plug of the appliance. If this is not the case, ask an authorised
technician to replace the plug (see assistance); do not use extension cables or multiple sockets.
Connecting the water and electricity supplies
Max1000mm
Min400mm
min
120mm
min 40mm
For optional
Connect the cold water supply hose to a threaded 3/4(inch)
connector and make sure that it is fastened tightly in place.
If the water pipes are new or have not been used for an
extended period of time, let the water run to make sure that
the water is clear and free of impurities. If this precaution is
not taken, there is a risk that the water inlet can get blocked
and the appliance could be damaged.
18
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 21
13
19
Once the appliance has been installed, the power supply cable and the electrical socket should
be easily accessible.
The cable should not be bent or compressed.
If the power supply cable is damaged, it must be replaced by the manufacturer or its Technical
Assistance Service in order to prevent all potential hazards.(See Assistance)
The company shall not be held responsible for any incidents that occur if these regulations are
not observed.
Advice regarding the first wash cycle
After the appliance has been installed, immediately before running the first wash cycle, completely
fill the dispenser of Rinse (see Rinse aid ).
Positioning the Appliance
Position the appliance in the desired location. The back should rest against the wall behind it, and
the sides, along the adjacent cabinets or wall. The dishwasher is equipped with water supply and
drain hoses that can be positioned to the right or the left to facilitate proper installation.
Leveling the Appliance
Once the appliance is positioned, adjust the feet (screwing them in or out) to adjust the height of the
dishwasher, making it level. In any case, the appliance should not be inclined more than 2 .
NOTE: The maximum adjustment height of the feet is 20 mm.
How to Drain Excess Water From Hoses
If the sink is 1000mm higher from the floor, the excess water in hoses cannot be drained directly
into the sink. It will be necessary to drain excess water from hoses into a bowl or a suitable
container that is held outside and lower than the sink.
Water Outlet
Connect the water drain hose. The drain hose must be correctly fitted to avoid water leaks.
Ensure that the water inlet hose is not kinked or squashed.
Extension Hose
If you need a drain hose extension, observe to use a similar drain hose..
It must be no longer than 4 metres; otherwise the cleaning effect of the dishwasher could be
reduced.
Syphon Connection
The waste connection must be at a height of between 50cm (minimum) and 100cm (maximum)
from the bottom of the dish. The water drain hose should be fixed by a hose clip.
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.bellinia
ppliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 22
13
20
19
9. Troubleshooting Tips
ERROR CODES
When some malfunctions happen, the appliance will display error codes to warn you.
WARNING!
If overflow occurs, turn off the main water supply before calling a service. If there is water in the base
pan because of an overfill or small leak, the water should be removed before restarting the
dishwasher.
Codes
Meanings
Possible Causes
Water drainage malfunction
E1
E2
E3
E4
E5
E6
E7
Door open
Water inlet
Water drainage
Temperature sensor
Overflow/leakage
Water leakage
Heating element
The door is opened when the
dishwasher is operating
Water inlet malfunction
Temperature sensor malfunction
Overflow occurs/Water leakage occurs
Water leakage occurs
Abnormal heating
Attention
The followings should be checked before starting the dishwasher:
1 Whether the dishwasher is level and fixed
2 Whether the inlet valve is opened
3 Whether there is leakage at the connections of the conducts
4 Whether the wires are tightly connected
5 Whether the power is switched on
6 Whether the inlet and drain hoses are knotted
7 All packing materials and printings should be taken out from the dishwasher
After installation, please put this manual into the bags of printings.
The content of this manual is very helpful to the users.
Start of Dishwasher
Technical information
WDH
448mm 600mm 845mm
Voltage connected load:
Water pressure:
See rating label
0.04--1.0MPa
Power supply:
see rating label
Capacity:
9 Place settings
Hot water connection:
Max 60
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.bellinia
ppliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 23
21
Problem Possible Causes What To Do
Dishwasher
doesn't run
Fuse blo
wn, or
th
e circuit breaker acted
Replace fuse or
reset circuit breaker. Remove any other appliances
sharing the same
circuit
with the dishwasher.
Power supply
is not turned on
Make sure the
dishwasher is turned on and the door is closed securely.
Make sure the power cord is prope
rly plugged into the wall socket.
Wa
ter press
ure is low
Check that the water
supply is connected properly and the water is turned
on.
Drain pump
doesn't stop
Overfl
ow
The system is
designed to detect an overflow. When it does, it shuts off
the circulation pump and turns on
the drain pump.
Noise
Some audible sounds are normal Sound from dete
rgent cup opening.
Utensils are not s
ecure in the baskets or
something small has drop
ped into the
basket
To ensure everything is secured in the dishwasher
.
Motor hums
Dishwa
sher
has not been used regularly. If you do not use it often,
remember to set
it to fill and pump out every week, which will help keep
the
seal
moist.
Suds in the tub
Imprope
r deter
ge
nt
Use only the sp
ecial dishwasher detergent to avoid suds. If this occurs,
open the dishw
asher
and let suds evaporate. Add 1 gallon of cold water
to the tub. Clos
e and latch the dishwasher, then start the "soak" wash
cycle
to dr
ain out the water... Repeat if necessary.
S
p
illed
rinse
agent
Alw
ays
wipe up rinse agent spills immediately.
Stained tub
interior
Detergent
with colorant
was used
Make sure that the deterg
ent is the one wi
thout colorant.
Dishes and
flatware not
clean
Improper
program Improper
basket
loading
Make sure that t
he action of the detergent dispenser and spray arms are
not blocked by
large dishw
are. Select a stronger programme.
Spots and filming
on glasses and
flatware
Extremely hard
water
Lo
w inlet temperature
Overloading the dishwa
sher
Improper loading
Old or damp powder deter
gent
Empty rinse agent dispenser
Incorrect dosage
of detergent
To
remo
ve spots from glassware:
1.
Take
out all metal utensils out of the dishwasher.
2. Do not add
detergent.
3. Choose
the longest
cycle.
4. Start the
dishwasher and allow it to run for about 18 to 22 minutes,
then it will be
in the main wash.
5.
Open the door
to pour 2 cups of white vinegar into the bottom of the
dishwasher.
6. Close
the door and
let the dishwasher complete the cycle. If the
vinegar does not
work: Repeat as above, except use 1/4 cup (60
ml)of
citric
acid
cr
ystals instead of vinegar.
Cloudiness
on
glassware
Combination of
soft wate
r and too much
detergent
Use less detergent if
y
ou have soft water and select a shortest cycle to
wash the glassware and to get th
em clean.
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 24
22
Yellow or bro
wn
film on inner
surfaces
Tea o
r coffee stains
Using a soluti
on of 1/2 cup of bleach and 3 cups of warm water to remove
the stains by
hand.
WARNING!
You have to w
ait for 20 minutes after a cycle to let the heating elements
cool down before cleaning interior; otherw
ise, burns will happen.
Iron deposits in w
ater can cause an
overall film
You have to call
a water softener company for a special filter.
White film on
inner surfac
e
Hard water miner
als
To clean the
interior, use a damp sponge with dishwasher detergent and
wear rubber
gloves. Never use any other cleaner than dishwasher
detergent for the risk of foaming or suds.
Detergent
dispenser lid
can’t be closed
properly
Clogged detergent
residue is blocking
the catch
Clean the detergent from the catch.
Detergent left in
dispenser c
ups
Dishes block detergent
Cups
Re-loading the dishes correctly.
Steam
This is nor
mal
There is
some
s
team coming through the vent by the door latch during
drying and
water draining.
Black or gray
marks on dishes
Aluminum
utensils
have
rubbed
against
dishes
Use a mild abrasive
cleaner to eliminate those marks.
Water in the
bottom of the tub
This is nor
mal
A small amount of
clean water around the outlet on the tub bottom keeps
the water seal lubricated.
Dishwa
sher
leaks
Overfill dispenser or
rinse aid spills
Be careful no
t to overfill the rinse aid dispenser. Wipe away any spills with
a damp
cloth.
Dishwasher
isn't placed horizontally
Make sure the di
shwasher is in a horizontal position.
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 25
23
WARRA
NTY
1.1 In this warranty:
1.1.1
Australian Consumer Law means the law as set out in Schedule 2 of the Competition and
Consumer Act 2010;
1.1.2 Company means GSM Sales Pty Ltd ABN 53 007 682 475 of 142-144 Fullarton Road, Rose
Park SA 5067. Email [email protected]
;
Australia 1300 373 199 or
New Zealand 0508
123 108
1.1.3 Consumer means a “consumer” as that term is defined in Section 3 of the Australian Consumer
Law as the original purchaser of a Bellini product;
1.1.4 Consumer Guarantees means the guarantees under the Australian Consumer Law;
1.1.5 You means the Consumer.
1.2 Nothing in this warranty affects any person’s rights under the Australian Consumer Law. The benefits to
any Consumer under this warranty are in addition to the rights and remedies available under any
Consumer Guarantees.
1.3 Subject to the other clauses of this warranty, the Company warrants to the Consumer that the Bellini
product will be free of manufacturing defects and will perform to the Company’s specifications.
1.4 The benefit of this warranty extends only to the Consumer as original purchaser of a Bellini product which
is installed in a residential property.
1.5
This warranty commences on the date of purchase of the Bellini product by the Consumer and
continues for the benefit only of the Consumer until the expiry of three (3) years (Warranty Period).
1.6 If within the Warranty Period a manufacturing defect is discovered in the Bellini product or it fails to perform
to the Company’s specifications as a result of some defect in materials, components or workmanship
(Defect) then the Company will, at its option, repair the Bellini product or supply a replacement Bellini
product free of charge. A replacement Bellini product may differ from the original product purchased by the
Consumer.
1.7 This warranty will not apply to any Bellini product:
1.7.1 Installed by any person other than a qualified tradesperson; or
1.7.2 Subjected to misuse, neglect, negligence or accidental damage; or
1.7.3 Operated in any way contrary to any operating or maintenance instructions; or
1.7.4 Improperly handled, installed or maintained; or
1.7.5 Altered or modified prior to or after installation; or
1.7.6 Damaged directly or indirectly by power surges, electrical storm damage or connection to incorrect
power supply
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY THE
CONSUMER MUST CALL 1300 373 199 (AUSTRALIA) OR 0508 123 108
(NEW ZEALAND) TO CONNECT TO THE NEAREST AUTHORISED CENTRE
TheAustralianConsumerLawrequiresth
einclusionofthefollowingstatement
withthiswarranty:
Our goods come with guaranteed that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a major failure.
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Page 26
24
1.8 You must pr
ovide proof of your purchase of the Bellini product and the date of purchase in order to obtain
the benefit of this warranty.
1.9 If you live outside the service area of the Company or one of its service agents, this warranty does not
cover the cost of transport of the Bellini product for service nor the service agent’s traveling co sts to and
from your home.
1.10 If you are required to transport the Bellini product to the Company or its service agent, you must ensu re it is
safely disconnected by a qualified tradesman and securely packed and insured. The Company does not
accept any responsibility for loss or damage of the Bellini product prior to it being received by the Company
or its service agent.
1.11 You will be responsible for all costs of returning a Bellini product to the Company and for redelivery of the
Bellini product by the Company (whether it is the original or a repaired and/or a replacement Bellini product)
and for any other expenses you incur in claiming under this warranty.
1.12 The Company or its service agent will examine any Bellini product and if the Company dete rmines t hat it is
defective through no fault of the Owner and is otherwise undamaged, the Compan y will repair or replace
the Bellini product in accordance with this warranty.
DO NOT SEND IN THIS WARRANTY
Fill out the following details and file with your purchase invoice.
RETAIN & FILE WITH YOUR RECEIPT
Your Purchase Receipt/Invoice is proof of date of purchase. If you are unable to establish the date of purchase,
or if the fault is not covered by this warranty, or if the product is found to be in working order, you will be requi red
to bear all service call charges.
GSM Sales Pty Ltd reserves the right to discontinue items, modify designs and change specifications without
incurring obligation.
Whilst every effort is made to ensure that descriptions, specifications and other information in this publication is
correct, no warranty is given in respect thereof and the company shall not be liable for any errors therein.
Purchased from:
Co. Name:
Address:
Date of Purchase:
Serial number:
NOTE: Consistent with our continuing product development policy, improvements may have been made
which render the contents of this packaging sli ghtly different to that shown.
FOR WARRANTY
SERVICE CALL 1300 373 199 (AUSTRALIA)
OR 0508 123 108 (NEW ZEALAND) TO CONNECT YOU TO THE NEAREST
AUTHORISED SERVICE CENTRE
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0508123108 NZ www.belliniappliances.com.au
Model: BDW96W-F FINELINE: 5104010 Aus/NZ, BDW96X-F FINELINE: 5104011 Aus/NZ 45cm Freestanding Dishwasher
Loading...
