Laptop Power Adapter for home/office
User Manual
Introduction
Congratulations and thank you for purchasing the Laptop Power Adapter for
home /office from Belkin. This new Adapter provides a single source of power for
users with more than one electronic device. It is also great for users that work in
more than one location and don’t want to carry their adapter(s) from place
to place.
Through the use of patente d power-tip technology, this Adapter will not only
charge the most popular laptops (11 tips are included ), it will also charge the
latest digital devices, including cell phones, digital cameras, camcorder s,
portable DVD playe rs, MP3 players, and more.
Product Registration and Warranty
For terms and conditions, to activate your warranty, and to register your
Laptop Power Adapter, please visit w ww.belkin.com/powersupply.
Important: Safety Information
Before use, please read the following import ant safet y information.
Following these simple guidelines will ensure trouble-free operation and
optimal per formance of the L aptop Power Adapter and compatible
electronic devices.
1. Avoid pulling on the cords and cables. Always grip plugs firmly when
unplugging from power source and when disconnecting cables. Never force
a power tip into an electronic device.
2. Before use, completely review power-tip compatibility information found in
the instructions, or at www.belkin.com/powersupply.
WARNIN G: Using the wro ng power tip may damage your elect ronic
devic e or cause it to mal function.
3. To avoid electrical hazard, be sure to unplug the Adapter from its external
power source before attaching the power tip.
4. For indoor use only. Avoid exposure to external heat sources; direct,
prolonged sunlight; dust; corrosive chemicals; and moisture.
5. It is normal for power adapters to become warm during use. Avoid
touching the device during use. Avoid placing in direct sunlight or near
heat-sensitive materials.
6. Do not drop or subject the Laptop Power Adapter to undue shock.
7. Do not place anything on top of the Laptop Power Adapter.
8. Always use the supplied cables and connectors as shown. Use of cables,
connectors, or accessories not supplie d with this product constitute s
misuse and may result in injur y or damage.
9. Do not at tempt to ser vice or disassemble. The unit is not user-ser viceable.
Attempting to disassemble or service the unit can result in electrical hazard,
including death from exposure to high voltage. If you experience problems
with the unit, discontinue use and contact Belkin for assistance. Attempting
to open or service the unit voids all warranties, express or implied.
Using the Laptop Power Adapter
AC Wall Outlets : The Laptop Power Adapter for home/office can be operated
from any standard wall outlet using the attached AC powe r cord. After attaching
the appropriate power tip (see the “Tip Selection” section ) to the output cable
of the power supply, insert or at tach the tip to your device to begin charging.
Power will imme diately be delivered to your device whether it is powered on or
not. Generally, if your unit is not powered on, the battery will begin to charge. It
is normal for power supplies to be warm during use. Avoid placing it near heat
sources, direct sunlight, or heat-sensitive materials.
Air/Auto /Boat /RV : If a DC input is required, we recommend the Belkin L aptop
Power Adapter for travel, which supports both AC and DC input.
Technical Specifications
Input Voltage (AC) 100–240V
Output Voltage 16–24V
Output Current 5A (max)
Output Power 69W
USB Output 5V @ 0 to 0.5A
Unit Dimensions 152 x 66 x 32mm
Weight 433.7g
AC Input Cable 635mm
DC Power Output Cable 172.7cm
Storage Temperature -40 to 85° C
Operating Tempe rature 0 to 40° C
Relative Humidity (non-condensing) 95%, max
Built-In Circuit Protection Overvoltage, undervoltage,
over temperature
Getting Connected
Belkin has made life easy for you by providing your new Laptop Power Supply
with eleven (11) power tips for vir tually any PC-based laptop.*
To get going, follow these easy steps :
Unplug power supply
Choose power tip (see section the “Tip Selection” and
Power-Tip Compatibility List)
Connect tip to output cable
Plug tip into laptop
Plug in power supply
If you wish to connect to a device using the built-in USB connector, the steps
are similar:
Unplug power supply
Connect device cable to USB port
Plug cable into device
Plug in power supply
Tip Selection
Each laptop has a specific tip that can be used for power. These tips have
different dimensions a nd deliver different levels of current and voltage. It is
impor tant that you choose the correct tip for your laptop.
Belkin has provided eleven (11) of the most popular laptop tips with this device
(see table below ). The tips can be used with laptops from major manufacturers
that include HP
Power-Tip Compatibilit y List
Tip # Laptop Ma nufacturer
1 Acer
3 Gateway®, Acer, IBM
4 IBM
5 Hewlett-Packard
6 Panasonic
7 Sony
8 Toshiba
11 Compaq
36 Dell
87 Dell
129 Hewlett-Packard
*Laptop Guarantee : If we didn’t include a tip for your laptop, tell us at
www.belkin.com/powersupply and we’ll ship your fir st tip free !
(Excludes Apple® laptops)
®
, IBM®, Toshiba®, Sony®, Dell®, and others.
®
®
, NEC®, Toshiba
®
, Sony
®
Troubleshooting
If your device is not charging or operating properly, take the following steps:
1. Disconnect the Laptop Power Adapter from its power source.
2. Verify that the correct power tip has been installed by checking the Power-
Tip Compatibility List. NEVER force a power tip into an electronic device.
3. Reconne ct the Laptop Power Adapter. Check that all connections
are secure.
4. Plug the correct power tip into your elec tronic device. The device should
begin charging regardless of whether it is powered on or not.
5. Note that if the green power-indicator LED does not light, it may have simply
burned out.
6. If you are still experiencing problems, please contact Belkin.
Information
CE Declar ation of Confo rmity
We, Belkin International, Inc., declare under our sole re sponsibility that
the F5L014, to which this de claration relates, is in conformity with Generic
Emissions Standard EN 55022 and with Generic Immunity Standard EN 55024
and LVD 1998.
Belkin In ternational, Inc ., Limited Lifetime Product Warr ant y
What this warrant y covers.
Belkin International, Inc. (“Belkin”) warrants to the original purchaser of this
Belkin product that the product shall be free of defects in design, assembly,
material, or workmanship.
What the period of coverage i s.
Belkin warrants the Belkin product for the lifetime of the product.
What will we do to correc t proble ms?
Belkin will repair or replace, at its option, any defective product free of charge
(except for shipping charges for the product) .
What is not covered by this warranty?
All above warranties are null and void if the Belkin product is not provided to
Belkin for inspection upon Belkin’s request at the sole expense of the purchaser,
or if Belkin determines that the Belkin product has been imprope rly installed,
altered in any way, or tampered with. The Belkin Product Warranty does not
protect against acts of God such as flood, earthquake, lightning, war, vandalism,
theft, normal-use wear and tear, erosion, depletion, obsolescence, abuse,
damage due to low voltage disturbances (i.e. brownouts or sags),
non-authorized program, or system equipment modification or alteration.
Information
How to get service.
To get ser vice for your Belkin product you must take the following steps :
1. Contact Belkin International, Inc., at 501 W. Walnut St., Compton CA
90220, Attn: Customer Service, or call (80 0) -223-5546, within 15 days of the
Occurrence. Be prepared to provide the following information:
a. The part number of the Belkin product.
b. Where you purchased the product.
c. When you purchased the product.
d. Copy of original receipt.
2. Your Belkin Customer Service Representative will then instruct you on how to
forward your receipt and Belkin product and how to proceed with your claim.
Belkin reserves the right to review the damaged Belkin product. All costs of
shipping the Belkin product to Belkin for inspection shall be borne solely by the
purchaser. If Belkin determines, in its sole discretion, that it is impractical to ship
the damaged equipment to Belkin, Belkin may designate, in its sole discretion,
an equipment repair facility to inspect and estimate the cost to repair such
equipment. The cost, if any, of shipping the equipme nt to and from such repair
facility and of such estimate shall be borne solely by the purchaser. Damaged
equipment must remain available for inspection until the claim is finalized.
Whenever claims are settled, Belkin reserves the right to be subrogated unde r
any existing insurance policie s the purchaser may have.
Information
How st ate law relates to the warra nty.
THIS WARRANTY CONTAINS THE SOLE WARRA NTY OF BELKIN. THERE ARE
NO OTHER WARRANTIES, EXPRESSED OR, EXCEPT AS REQUIRED BY L AW,
IMPLIED, INCLUDING THE IMPLIED WARRANTY OR CONDITION OF QUALIT Y,
MERCHANTABILIT Y OR FITNESS FOR A PARTICUL AR PURPOSE, AND SUCH
IMPLIED WARRANTIES, IF ANY, ARE LIMITED IN DURATION TO THE TERM OF
THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so
the above limitations may not apply to you.
IN NO E VENT SHALL BELKIN BE LIABLE FOR INCIDENTAL, SPECIAL , DIRECT,
INDIRECT, CONSEQUENTIAL OR MULTIPLE DAMAGES SUCH AS, BUT NOT
LIMITED TO, LOST BUSINESS OR PROFITS ARISING OUT OF THE SALE OR
USE OF ANY BELKIN PRODUCT, EVEN IF ADVISED OF THE POSSIBILIT Y OF
SUCH DAMAGES.
This wa rranty gives you specific le gal rights, and you may also have other rights,
which may var y from state to state. Some states do not allow the exclusion
or limitation of incidental, consequential, or other damages, so the above
limitations may not apply to you.
Belki n Tech Sup por t
US: 8 00-2 23-55 46, ex t. 226 3
310-898 -110 0, ext. 2263
UK: 08 45 607 77 87
Austr alia : 1800 23 5 546
New Zea land : 0800 235 546
Singa pore : 65 6 4857620
Europe : ww w.belk in.com /suppor t
Belki n Inter natio nal, I nc.
501 West Walnut Stree t
Los An gele s, CA 9 0220, U SA
310-898 -110 0
310-898 -1111 fax
Express Bu siness Par k, Shi pton Way
Rushd en, NN10 6 GL, United K ingdo m
1119 PH S chiph ol-R ijk, T he Net herla nds
