USER MANUAL

LCD-Monitor

[ ]

Belinea 10 19 10

BELINEA PREMIUM SERVICE

The three-year return to base warranty for your Belinea monitor includes all parts and labour. In

English

Deutsch

Français

Country Phone number Additional swap out service
Land Telefonnummer Zusätzlicher Austausch-Service
Pays Numéro de téléphone Service supplémentaire d’échange sur site

addition many countries offer a free of charge swap out warranty programme. This does not affect
your Statutory Rights. Please visit http://www.belinea.com or call the numbers below for further
warranty or service information.

Please have the serial and model number ready when calling.

Die Garantie für Ihren Belinea-Monitor beträgt drei Jahre und umfasst alle Bauteile. Darüber
hinaus bieten wir in vielen Ländern einen zusätzlichen, kostenlosen Austausch-Service an.
Von dieser o. g. Garantie bleiben etwaige gesetzliche Gewährleistungsrechte unberührt.
Nähere Informationen zu Garantie- und Servicefragen erhalten Sie im Internet unter
http://www.belinea.com sowie unter den u. g. Rufnummern.

Bitte halten Sie für Ihren Anruf Serien- und Modellnummer bereit.

La garantie internationale de trois ans sur les écrans Belinea s’entend pièces et main d’œuvre. Pour
obtenir plus d’informations sur la garantie et le service après-vente contactez-nous sur Internet
http://www.belinea.com ou aux numéros de téléphone ci-dessous. Vous pouvez obtenir également
plus de détails sur les possibilités d’échange gratuit, service offert dans de nombreux pays.

Pour votre appel, tenez les numéros de série et d’article à portée de main.

Belgie/Belgique 0900 10630 (0,45 €/min) 3 year on-site warranty (swap out)

Deutschland 02365 952 1010 3 Jahre Garantie-Austausch-Service

Česká republika [phone] Záruka 3 roky

España 090 21 96 497 3 años de garantia con intercambio a domicilio

Ελλαδα 210 48 05 800 Εγγυηση 3 χρονια επιτοπου αντικατασταση

France 0820 091820 3 ans de garantie avec échange standard sur site

Hrvatska [phone] 3 godine jamstva

Italia 199 156 169 3 anni di Garanza di sostituzione a domicilio

Ireland 00 353 12861343 3 year on-site warranty (swap out)

Luxemburg/Luxembourg 0900 74235 (0,45 €/min) 3 year on-site warranty (swap out)

Magyarország 01 340 99 51/53 3 év helyi szerviz

Nederland 0900 BELINEA (02354632) 3 year on-site warranty (swap out)
(0,70 €/Gesprek)

Österreich 01 277 89 88 3 Jahre Vor-Ort-Austausch-Garantie

Polska 071 337 19 55/022 863 27 77 3 lata gwarancji (door to door)

Portugal 090 21 96 497 3 Anos de Troca em Garantia On-Site

Россия [phone]

Трехлетняя гарантия с заменой на рабочем месте

Schweiz 0900 575 111 (2,13 CHF/min) 3 Jahre Vor-Ort-Austausch-Service

Slovenija [phone] 3 leta garancije

United Kingdom 01344 788920 3 year on-site swap out warranty
(UK mainland only)

All other countries
Alle anderen Länder [phone]
Les autres pays

ENGLISH

INTRODUCTION

This manual will familiarize you with the installation and
use of your Belinea monitor. Please take the time to
look through these instructions even if you are familiar
with monitors.

We have taken all possible care to ensure that this
manual contains correct, accurate information. However,
the manufacturer cannot assume liability for any possible
errors. In addition, the manufacturer cannot guarantee
that the hardware will meet the purpose you require. We
would appreciate reports of any errors, suggestions or
criticism.

© Copyright 2005
MAXDATA Systeme GmbH
45768 Marl, Germany
www.maxdata.com

Editing, DTP and translation by think’Z GmbH,
www.thinkz.de.

All rights reserved. No part of this manual may be
reproduced, processed or distributed in any form (print,
photocopy, microfi lm or any other process) or processed
by an electronic system without prior written permission
from the manufacturer.

We reserve the right to make changes according to technical
progress. Belinea is an internationally registered trademark.
Other brand names may be registered trademarks and must
be treated as such.

TABLE OF CONTENTS

INTRODUCTION ........................................................ 2

IMPORTANT INFORMATION .....................................3

CARING FOR YOUR LCD MONITOR ........................ 3

WALL MOUNTING ......................................................3

UNPACKING .............................................................. 4

CONNECTING ........................................................... 4

STARTUP ...................................................................4

CONFIGU RATION ...................................................... 5

BASIC SETUP ............................................................5

IMAGE SETTINGS USING THE OSD MENU ............ 5

OSD MENU FUNCTIONS ........................................... 6

TROUBLESH OOTING ................................................ 7

TECHNICAL SPECIFICATIONS .................................7

DEFINITION OF THE MAXDATA WARRANTY .........8

Information about Environ­mentally Sound Waste
Management

Important Safety Instructions

Some Belinea monitor models come with 2 power cords.
Please ensure you use the UK plug (3 pin) in the UK and
not the European plug (2 pin).

Do not place the monitor in very hot or cold, nor damp or
dusty surroundings. Do not put vases etc. on the monitor,
water may cause short circuits. Do not block or cover the
ventilating openings. All products that produce magnetic
fi elds, i.e., laser printers, loud-speakers, etc., must not
be placed close to the monitor. Do not install this monitor
in areas where too much light or sunshine might directly
hit the screen, otherwise the brightness of the picture
will be poor due to refl ections. Refer all servicing and
maintenance to authorised service personnel only!

CAUTION

Do not remove the cover!
Serious electrical shock hazards exist inside
this monitor.

NOTE

Removal of cover invalidates your warranty.

Belinea monitors are designed to be environmentally
sound according to TCO guidelines. Please direct any
questions you may have regarding the disposal of your
monitor to our European waste management affi liate:

Hellmann Process Management GmbH & Co. KG
Adolf-Köhne-Str. 11
49090 Osnabrück, Germany
Tel: [phone]

For more information about recycling monitors, please
see:

http://LQP2.de.hellmann.net/monitor-recycling

Guide to Symbols

The symbols below are used in this manual to indicate
where there is risk of injury or damaging devices or to
indicate especially useful information:

DANGER! Indicates risk of injury. When not
following instructions, severe injury or death
may result.

ATTENTION! Indicates possible damage
to devices. When not following instructions,
devices may be heavily damaged.

IMPORTANT! Indicates hints on operation
and other useful information.

We are all responsible for the environment: this manual was printed from front to back on
paper that was produced without chlorine.

Belinea 10 19 10 - Operating Instructions - 2

IMPORTANT INFORMATION

ENGLISH

Note on monitor placement

• The setup location must not be extremely hot,
cold, humid or dusty. Heat and cold can impair
the functionality of the monitor. Humidity and dust
can cause the monitor to fail.

• Don’t place the monitor near heaters such as
radiators or the like. Don’t expose the monitor to
mechanical vibrations or jarring.

• Position the monitor so that no direct light or sun
strikes the screen, which could cause refl ections
that reduce the quality of the image.

Notes on power connection

Only use the power cord designated for use in

your country.

The wall outlet should be within easy reach. Pull-

ing the power plug is the only way to disconnect
the monitor from the power source.

• This monitor is ENERGY STAR
MAXDATA is an ENERGY STAR
guarantees that this device complies with the
ENERGY STAR
consumption.

®

guidelines for optimizing power

®

-compatible.

®

partner and

Safety instructions for operation

The power cord must not be damaged. Do not

place any objects on the power cord and make
sure it does not have any knots. To unplug the
cord, alway s pu ll on the pl ug an d not on t he cable
itself. Damage to the power cord may result in fi re
or cause electric shocks.

• Avoid covering the ventilation slots. Air circula­tion is necessary to prevent the monitor from
overheating. If the air circulation is restricted it
could cause fi re or damage the monitor.

• Do not use any solvents to clean the monitor, as
the housing could be damaged. For more infor­mation about cleaning the monitor, please see
“Caring for Your LCD Monitor”.

Never open the monitor housing yourself. There

is a danger of electric shock and other hazards.
The monitor may only be opened and serviced
by qualifi ed professionals.

Note on resolution

All resolutions provided by the graphics card that

deviate form the physical resolution of the panel
ar e adjusted by interpolati on. T his c an im pair the
image quality.

Notes on ergonomics

To protect your eyes, neck and shoulder muscles

when working with a computer, we recommend
that you maintain a viewing distance of between
50 and 75 cm from the monitor. Furthermore, you
should regularly focus on an object around 6 m
aw ay f rom yo u to h elp y our eyes re lax. Er gonom i­cally, your posture is best when elbows, pelvis,
knees and ankles are all at right angles.

CARING FOR YOUR LCD MONITOR

• First, unplug the power cord from the wall socket.

• If the LCD screen is extremely dirty, clean it with a
moist cloth. Use only warm water and then wipe the
monitor dry. Solvents or harsh cleaners can damage
the housing. Clean the display surface only with a
soft cloth, otherwise you may damage the display’s
coating.

• If the monitor is only slightly dirty, clean it using a
soft, dry and antistatic cloth.

• The LCD monitor’s screen surface is very sensitive.
Please avoid any contact with the surface (fi nger,
pencil, etc.) and be especially cautious during
transportation since jolts and shocks can cause the
screen to become scratched (always use the original
packaging).

WALL MOUNTING

The Belinea monitor is shipped with the standard desktop confi guration. However, you can optionally mount the
device on a wall or on a monitor swivel arm (optional accessory). Please follow the corresponding instructions
(4-hole assembly with a spacing of 4 × 4 inches (100 × 100 mm) according to the international VESA FDMI stan­dard).

Belinea 10 19 10 - Operating Instructions - 3
