Bel Canto Design PL-1, PL-1A User Manual

Page 1

Rev.3 3/22/04

Page 2

TABLE OF CONTENTS

Table of Contents Page 1 General Information: General Info. & Safety Precautions Page 2-5 Before You Start: Features, Disc Compatibility Page 6-8 Front Panel: Front Panel Controls and Functions Page 9 Rear Panel: Controls and Connections Page 10 Remote Control/Display: Description and Functions Page 11-13 Getting Started: On-screen Displays, Setup Navigator Page 14-16 Playing Discs Page 17-19 FAQ: Frequently Asked Questions Page 20-21 Disc Navigator: Introduction and Use Page 22-23 Playing Discs: Scanning, Using the Multi Dial Page 24 Slow Motion, Frame Advance, Looping Page 25-26 Repeat and Random Play Page 27-28 Programming Page 29-31 Disc Search Page 32 Switching Subtitles/DVD/Video Language Page 33 Switching DVD-RW/CD/MP3 Audio Channels Page 34 Displaying Disc Information Page 35 Audio Settings: Audio DRC, Virtual Surround Page 36-37 Set Speaker Distance Page 38 Video Settings: Video Adjust Page 39-40 Initial Settings Menu: Using Settings, Digital Audio Out Page 41-42 Video Out, Language and Display Settings Page 43-47 Options, Parental Lock, Setting Country Code Page 47-50 Bonus Group, Auto Disc Menu Page 50 Group Playback, DVD, SACD Playback Page 51 CD Playback, Audio output Mode Page 52 Speaker Installation, Distance Page 52-54 Additional Information: Care of the Player and Discs Page 55-56 Screen Sizes and Disc Formats Page 57 Audio Output Setting Variations Page 58 Language and Country Code List - Selecting Page 59-60 Glossary Page 60-61 Troubleshooting Page 62-65

Specifications Page 66

Appendix: RS-232 Protocol and Control Details Page 67-72

Page 3

CONGRATULATIONS

You have just acquired the finest player available for the playback of digitally encoded source material for both audio and video formats

IMPORTANT

Save all packaging in a dry place away from fire hazards. Your Bel Canto player is a precision electronic instrument and should be properly packaged any time shipment is made. In the unlikely event that you have to return your unit to the factory for service, or if you send it to us for updating, the original packaging will best protect the unit from shipping damage or delay. In order to achieve the fullest flexibility and enjoyment from your player, we at Bel Canto recommend that you read this manual in full before connecting the unit to your audio/video system.

WARRANTY REGISTRATION

Complete and return by fax or mail your warranty document enclosed in product box for extended warranty coverage. Please return this document to Bel Canto within 30 days of original purchase.

Bel Canto Design offers a 90-day factory warranty from the date of purchase that can be extended to 2 year LIMITED WARRANTY. The original owner can obtain the LIMITED WARRANTY, by returning a completed warranty form along with a copy of the original sales receipt from your authorized Bel Canto Dealer. The extended LIMITED WARRANTY coverage extends the warranty to a period of 1 year on the Laser and Loader (mechanical portion of the unit and 2 years on the electronics, from the date of purchase by the original owner and includes all parts and workmanship. The warranty automatically commences on the date of purchase or I year from the date of shipment to an authorized Bel Canto dealer, which ever comes first, and terminates 3 years from date of shipment to an authorized Bel Canto dealer. Units purchased from a source other than an authorized dealer are not covered by this warranty. Warranty is void if damage is due to abuse, neglect or unauthorized modification. Cost associated with the return of this product is the sole responsibility of the owner. All repair work must be done by an authorized Bel Canto repair center. Work done by unauthorized persons will void all warranty coverage. Bel Canto Design products are uniquely identified with a serial number on the back panel of each unit. This number is required to validate your warranty. Please reference your serial number if service is required. If you have any questions, comments or if we can be of service, please contact us Monday through Friday 9:00a.m. - 5:00p.m., Central Time in the United States.

Bel Canto Design, Ltd. 212 3rd Avenue North, Minneapolis, MN 55401 USA Tel: 612-317-4550  2003 FLC - Bel Canto/LFM

Page 4

IMPORTANT

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

CAUTION:

TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

IMPORTANT SAFETY INSTRUCTIONS

READ INSTRUCTIONS — All the safety and

operating instructions should be read before the product is operated.

RETAIN INSTRUCTIONS — The safety and

operating instructions should be retained for future reference.

HEED WARNINGS — All warnings on the

product and in the operating instructions should be adhered to.

FOLLOW INSTRUCTIONS — All operating and

use instructions should be followed.

CLEANING — Unplug this product from the wall

outlet before cleaning. The product should be cleaned only with a polishing cloth or a soft dry cloth. Never clean with furniture wax, benzine, insecticides or other volatile liquids since they may corrode the cabinet.

ATTACHMENTS — Do not use attachments not

recommended by the product manufacturer as they may cause hazards.

WATER AND MOISTURE — Do not use this

product near water — for example, near a bathtub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.

ACCESSORIES — Do not place this product on

an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

CART — A product and cart

combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.

VENTILATION — Slots and openings in the

cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

POWER SOURCES — This product should be

operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company.

LOCATION – The appliance should be installed

in a stable location.

NONUSE PERIODS – The power cord of the

appliance should be unplugged from the outlet when left unused for a long period of time.

GROUNDING OR POLARIZATION

• If this product is equipped with a polarized alternating current line plug (a plug having one blade wider than the other), it will fit into the outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

• If this product is equipped with a three-wire grounding type plug, a plug having a third (grounding) pin, it will only fit into a grounding type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding type plug.

H002_En

Page 5

POWER-CORD PROTECTION — Power-supply

cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

OUTDOOR ANTENNA GROUNDING — If an

outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. See Figure A.

LIGHTNING — For added protection for this

product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

POWER LINES — An outside antenna system

should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

OVERLOADING — Do not overload wall outlets,

extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

OBJECT AND LIQUID ENTRY — Never push

objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

SERVICING — Do not attempt to service this

product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

DAMAGE REQUIRING SERVICE — Unplug this

product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

• When the power-supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen into the product.

• If the product has been exposed to rain or water.

• If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.

• If the product has been dropped or damaged in any way.

• When the product exhibits a distinct change in performance — this indicates a need for service.

REPLACEMENT PARTS — When replacement

parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

SAFETY CHECK — Upon completion of any

service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

WALL OR CEILING MOUNTING — The product

should not be mounted to a wall or ceiling.

HEAT — The product should be situated away

from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

ANTENNA

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

Fig. A

LEAD IN WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

NEC — NATIONAL ELECTRICAL CODE

WARNING: TO PREVENT FIRE OR SHOCK

HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. H001_En

[For U.S. model] IMPORTANT NOTICE

The serial number for this equipment is located on the rear panel. Please write this serial number on your enclosed warranty card and keep it in a secure area. This is for your security.

H006A_En

Page 6

ADDITIONAL SAFTEY REQUIREMENTS

Please carefully read each item of the operating instructions and safety precautions before using this product. Use extra care to follow the warnings written on the product itself and/or in the operating instructions. Keep the operating instructions and safety precautions for future reference.

Caution: to reduce the risk of electrical shock, do not remove any of the cover panels.

No user-serviceable parts inside. Refer all servicing to qualified service personnel only.

To prevent fire or shock hazard, do not allow liquids to spill or objects to fall into any openings of the product.

This unit is supplied with a 3 pin grounded AC plug. Always insert the ac plug into a grounded outlet. Do not remove the ground pin or d isable the gro und for any purpo s e.

Before making any connections to the unit, first turn off the power and then disconnect the ac power cord.

When installing the unit in your system, make certain to allow a minimum of 1½ inches of ventilation on each side of the unit. Also allow at least 2½ inches of ventilation space above the unit. Improper ventilation of the unit may cause overheating, which may damage the unit and it to fail. Place the unit on a solid surface only. i.e. not on carpet, etc.

Do not place the unit near heat sources such as direct sunlight, stoves, heat registers, radiators or other heat producing equipment.

To prevent damage to the digital or analog output circuitry, be certain not to short the output signal pin(s) to ground. E nsure that your outp ut cables do not have any internal shorts before connecting them.

IMPORTANT NOTICE

Due to the computer-based circuitry used in this product, it is imperative that the player be connected to a ground via its three-wire AC power cord. It is important that the AC power outlet, which the unit is plugged into, is actually grounded. Failure to do so will severely compromise the performance, reliability and safety o f use of the unit.

It is also important to prevent contact with static electricity when connecting other components and cables to the unit. When connecting cables, simply place one hand on top of the player and then grasp the metal “barrel” of the cable with the other hand and plug (unplug) the cable into (from) the appropriate jack on the unit.

At times a snapping sound may o ccur or the unit may “lockup” and fail to operate. This is NOT A MALFUNCTION of the unit. This is normally caused by exposure to static electricity and can be cured by turning off the power amplifier(s) and then turning the unit off and then on with the rear mounted power switch.

Ventilation is an important issue when placing the unit in a system. Make certain that the unit is in a wellventilated area or rack unit.

Please take note, that some power line conditioners defeat the AC power ground on their outlets. If the intention is to plug the unit into a line conditioner, check with your dealer to make certain that the particular conditioner that is intended for use DOES NOT DEFEAT THE AC GROUND on its AC outlets.

DO NOT remove the cover from the player, as there are no user serviceable components inside. Refer servicing and updating to qualified service personnel only.

Page 7

Before You Start01

Features

DVD-Audio and SACD compatible

Experience the super high-quality audio performance of DVD-Audio and Super Audio CD (SACD).

The on-board 24-bit/192kHz DAC means that this player is fully compatible with high sampling-rate discs, capable of delivering exceptional sound quality in terms of dynamic range, low-level resolution and high-frequency detail.

Built-in Dolby*1 Digital and DTS* decoding with multichannel outputs

Logos: 1 This player features multichannel analog

outputs for connection to an AV amplifier to give you stunning surround sound from Dolby Digital, DTS and multichannel DVDAudio discs.

TruSurround*3 and Virtual Dolby Digital

Logo: TruSurround/Virtual Dolby Digital creates a

realistic surround-sound effect from any Dolby Digital source using just two speakers.

Super Fine Focus digital filter

This improves the quality of the video output by reducing video noise and increasing the horizonatal resolution to 540 lines.

MP3 compatibility

This player is compatible with CD-R, CD-RW and CD-ROM discs that contain MP3 audio tracks.

Graphical on-screen displays

Setting up and using your DVD player is made very easy using the graphical onscreen displays.

*1 Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

*2 “DTS” and “DTS Digital Surround” are registered trademarks of Digital Theater Systems, Inc.

*3 TruSurround and the of SRS Labs, Inc. TruSurround technology is incorporated under license from SRS Labs, Inc.

® symbol are trademarks

PureCinema progressive scan

When connected to a progressive scan- compatible TV or monitor using the compo- nent video outputs, you can enjoy extremely stable, flicker free images, with the same frame refresh rate as the original movie (see

page 50).

Page 8

Before You Start01

Disc / Content Format Playback Compatibility

General Disc Compatibility

• This player was designed and engineered to be compatible with software containing one or more of the following logos.

DVD-Video DVD-R DVD-RWDVD-Audio

Audio CD CD-R

• Other formats, including but not limited to the following, are not playable in this player:

Photo CD / DVD-RAM / DVD-ROM / CD-ROM

(except those that contain MP3 files formatted as specified in the “Com-

pressed Audio Compatibility” section)

• DVD-R/RW and CD-R/RW discs (Audio

CDs and Video CDs) recorded using a DVD Recorder, CD Recorder or Personal Computer may not be playable on this machine. This may be caused by a number of possibilities, including but not limited to: the type of disc used; the type of recording; or damage, dirt or condensation on either the disc or the player’s pick-up lens.

Special note about particular formats or software follows below:

Video CD

Super Audio CD

CD-RW

CD-R/RW Compatibility

• This unit will play CD-R and CD-RW discs recorded in CD Audio, Video CD, or MP3 audio formatting. However, any other content may cause the disc not to play, or create noise/distortion in the output.

• This unit cannot record CD-R or CD-RW discs.

• Un-finalized CD-R/RW discs recorded in CD Audio can be played, but not all Table of Contents (playing time, etc..) will be displayed.

DVD-R/RW Compatibility

• This unit will play DVD-R/RW discs that were recorded using the DVD Video format.

• This unit will play DVD-RW discs that were recorded using the Video Recording format.

• This unit cannot record DVD-R/RW discs.

• Un-finalized DVD-R/RW discs cannot be played in this player.

Compressed Audio Compatibility

• This unit will play compressed audio files formatted in the MPEG-1 Audio Layer 3 format (MP3) with a 44.1 or 48kHz fixed bit rate. Incompatible files will not play and “UNPLAYABLE” will be displayed on the unit.

• Variable Bit-Rate (VBR) files are playable, but playing time may not be shown correctly.

• The CD-ROM used to compile your MP3 files must be ISO 9660 Level 2 compliant.

• CD physical format: Mode1, Mode2 XA Form1.

• This player only plays tracks that are named with the file extension “.mp3” or “.MP3”.

Page 9

Before You Start

• This player is compatible with multisession discs, but only plays sessions that are closed.

• Use CD-R or CD-RW media for recording your MP3 files.

• This player can recognize a maximum of 250 folders or 250 tracks. Discs containing more than 250 folders or 250 tracks will play, but only the first 250 folders / tracks.

• Folder and track names (excluding the “.mp3” extension) are displayed.

• There are many different recording bit-

rates available to encode your MP3 files. This unit was designed to be compatible with all of them. Audio encoded at 128Kbps should sound close to regular CD Audio quality. This player will play lower bit-rate MP3 tracks, but please note that the sound quality becomes noticeably worse at lower bit-rates.

PC Created Disc Compatibility

• If you record a disc using a Personal Computer, even if it is recorded in a “compatible format” as listed above, there will be cases in which the disc may not be playable in this machine due to the setting of the application software used to create the disc. In these particular incidences, check with the software publisher for more detailed information.

• DVD-R/RW and CD-R/RW software disc boxes also have additional compatibility information.

Titles, chapters, Groups and tracks

DVD-Video discs are generally divided into one or more titles. Titles may be further subdivided into chapters.

Title 1 Title 2 Title 3

Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 1 Chapter 2

DVD-Audio discs are divided into one or more groups that can each contain a number of tracks.

Group 1 Group 2 Group 3

Track 1 Track 2 Track 3 Track 1 Track 1

Track 2

CDs, SACDs and Video CD are divided into tracks.

Track 1 Track 2 Track 3 Track 4 Track 5 Track 6

CD-ROMs containing MP3 files are divided into folders and tracks. Folders may also contain further subfolders.

mp3

Folder A Folder B Folder C

Track 1 Track 2 Track 3 Track 1 Track 1

Track 2

DVD-Video regions

All DVD-Video discs carry a region mark on the case somewhere that indicates which region(s) of the world the disc is compatible with. Your DVD player also has a region mark, which you can find on the rear panel. Discs from incompatible regions will not play in this player. Discs marked ALL will play in any player.

The diagram below shows the various DVD regions of the world.

Page 10

Page 11

Page 12

Controls and Displays

Display

3 5 76 8 9 10 11

1516 1214 13

1 5.1CH

Lights when analog 5.1 channel output is selected.

2V-PART

Lights when playing a video part of a DVD disc

3 PRGSVE

This indicator is not used on this player. See Section for front panel controls.

Lights during multi-angle scenes on a DVD disc.

5 GUI (Graphical User Interface)

Lights when a menu is displayed on-screen

6GRP

Indicates that the character display is showing a DVD-Audio group number

7 TITLE

Indicates that the character display is showing a DVD-Video title number

Lights when 2V/TruSurround is active.

9 TRK

Indicates that the character display is showing a track number

10 CHP

Indicates that the character display is showing a DVD chapter number

11 REMAIN

Lights when the character display is showing the time or number of tracks/titles/chapters remaining

12 Character display 13 8

Lights when a disc is paused

14 3

Lights when a disc is playing

15 2D

Lights when a Dolby Digital soundtrack is playing

16 DTS

Lights when a DTS soundtrack is playing

Page 13

Controls and Displays

Remote control

• Buttons 6 thru 9 and 20 thu 22 glow slightly in the dark for ease of use.

OPEN /

1 2

1 (STANDBY/ON)

Press to switch the player on or into standby

2 DISPLAY

Press to display information about the disc playing (page 46)

3 AUDIO

Press to select the audio channel or language.

4 SETUP

Press to display (or exit) the on-screen display

DISPLAY AUDIO SUBTITLE ANGLE

SETUP

RETURN

4¢ 1 ¡

PLAY MODE SURROUND

– MULTI SPEED +

ENTER

VIDEO ADJUST DIMMER

V.ADJ

TV CONTROL

VOLUME

CHANNEL

–

TOP MENU

FL JOG

–

JOG MODE

CLEAR

ENTER

873

C321

E654

0987

FUNC

14 15

20 22 23

27 28

5 ENTER & Joystick

Use to navigate on-screen displays and menus. Press ENTER to select an option or execute a command

(RETURN)

Press to return to a previous menu screen

7 V.ADJ (VIDEO ADJUST )

Press to display the Video Adjust menu.

8 7

Press to stop the disc (you can resume playback by pressing 3 (play))

9 3

Press to start or resume playback 10 4 ¢

Press to jump to the start of the previous / next chapter / track

11 PLAY MODE

Press to display the Play Mode menu. (You can also get to the Play Mode menu by pressing SETUP and selecting Play Mode)

12 Number buttons 13 MENU

Press to display a DVD disc menu, or the Disc Navigator if a DVD-RW, CD, Video CD or MP3 disc is loaded

14 0 OPEN/CLOSE

Press to open or close the disc tray

15 ANGLE

Press to change the camera angle during DVD multi-angle scene playback.

16 SUBTITLE

Press to select a subtitle display.

17 TOP MENU

Press to display the top menu of a DVD disc

Page 14

Controls and Displays

18 MULTI DIAL

Use for scanning and slow motion control.

19 Jog indcator

Lights when multi dial is in jog mode .

20 JOG (JOG MODE)

Press to put switch jog mode on/off. When on, use the MULTI DIAL to advance or reverse frames.

21 FL (DIMMER)

Press to change the display brightness

22 8

Press to pause playback; press again to restart

23 1 and

/ ¡ and

Use for reverse / forward slow motion playback, frame reverse / advance and reverse / forward scanning.

24 SURROUND

Press to activate/switch off 2V/TruSurround.

25 CLEAR

Press to clear a numeric entry

26 ENTER

Press to select an option or execute a command

27 TV CONTROL buttons VOLUME

Use to adjust the volume

CHANNEL

Use to select TV channel

FUNC

Press FUNC to select the TV for remote control operation

2152

Press

TV to turn the TV’s power on or put

in to standby

Setting up the Remote Control to TV

This most be set to use buttons 27 and 28.

1. Input the Manufacturer code.

While holiding down the CLEAR button, input the two digit code from the table next page that corresponds to the make of your TV.

For example, If you have a Pioneer TV, press and hold CLEAR, then press 0, 0 on the remote control.

2. Confirm that the TV is responding to the programmed code.

On the remote, press the

TV button. If the TV swithches on (or into standby if it was on previously), then you have the correct code.

If nothing happens when you press the

TV button, start again from step 1 using a different code.

• Some manufacturers have several codes. Try each one until you find the one that works.

Preset code list

00, PIONEER1 01, RCA1 02, SHARP3 03, ZENITH1 04, SONY 05, TOSHIBA1 06, HITACHI1 07, PHILIPS 08, PANASONIC1 09, MITSUBISHI 10, GOLDSTAR1 11, GE1 12, MAGNAVOX1 13, JVC1 14, SANYO2 15, RCA2 16, RCA3 17, RCA4

18, RCA5 19, SHARP1 20, ZENITH12 21, SANYO1 22, PANASONIC2 23, GOLDSTAR2 24, HITACHI2 25, HITACHI3 26, TOSHIBA2 27, SHARP2 28, GE2 29, MAGNAVOX2 30, TOSHIBA3 31, HITACHI4 32, JVC2 33, FUJITSU 34, PIONEER2 35, GRANDIENTE

Page 15

Getting Started

Using the on-screen displays

For ease of use, this player makes extensive use of graphical on-screen displays (OSDs). You should get used to the way these work as you’ll need to use them when setting up the player, using some of the playback features, such as program play, and when making more advanced settings for audio and video.

All the screens are navigated in basically the same way, using the cursor buttons to change the highlighted item and pressing ENTER to select it.

• Throughout this manual, ‘Select’ means use the Joystick to highlight an item onscreen, then press ENTER.

DISPLAY AUDIO SUBTITLE ANGLE

SETUP

– MULTI SPEED +

TOP MENU

• Information at the bottom of every OSD screen explains the currently selected menu item and shows which buttons can be used for that screen.

Setting up with the Setup Navigator

Using the Setup Navigator you can make a number of other initial settings for this player. We recommend using the Setup Navigator, especially if you connected this player to an AV receiver for playing surround sound. To answer some of the questions about digital audio formats you may need to look at the instructions that came with your AV receiver.

1 If a disc is playing, press 7 (stop).

Also turn on your TV and make sure that it is set to the correct video input.

ENTER

VIDEO

JOG MODE

ADJUST DIMMER

RETURN

V.AD J

FL JOG

873

4¢ 1 ¡

PLAY MODESURROUND

Button What it does

SETUP Display/exit the on-screen

display Changes the highlighted

(Joystick)

menu item

ENTER Selects the highlighted menu

item (both ENTER buttons work in exactly the same way)

(RETURN) Returns to the previous menu

without saving changes

2 Press SETUP.

The on-screen display (OSD) appears.

Audio Settings

Play Mode

Initial Settings

Video Adjust

Disc Navigator

Setup Navigator

3 Select ‘Setup Navigator’.

Audio Settings

Play Mode

Initial Settings

Video Adjust

Disc Navigator

Setup Navigator

Page 16

Getting Started04

4 Select a DVD language.

Some DVD discs feature on-screen menus, soundtracks and subtitles in several languages. Set your preferred language here.

Setup Navigator

Audio Out Settings Speaker Settings AV Receiver Func.

DVD LanguageLanguage Settings

English French German Italian Spanish Dutch Other Language

• Note that the language you choose here may not be available on all discs.

• If you want to select a language other than those listed, select Other Lan-

guage. See Selecting languages using

the language code list for details.

5 Did you connect this player to an AV receiver?

Setup Navigator

Audio Out Settings

Speaker Settings AV Receiver Func.

AV ReceiverLanguage Settings

Connected Not Connected

• If you selected Not Connected here, that completes the setup. Press ENTER to leave the Setup Navigator.

7 Did you connect a digital output to your AV receiver? Select Connected or Not Connected.

Setup Navigator

Language Settings Audio Out Settings

Speaker Settings AV Receiver Func.

AV Receiver

5.1ch Audio Out Digital Audio Out

Connected Not Connected

• If you selected Not Connected in both steps 6 and 7, that completes the setup. Press ENTER to leave the Setup Navigator.

If you selected Connected in step 6, then answer the following questions about the speakers in your system, other wise jump to step 11.

8 Do you have a center speaker connected to your AV receiver? Select Connected or Not Connected.

Setup Navigator

Audio Out Settings Speaker Settings

AV Receiver Func.

Center SpeakerLanguage Settings

Connected Not Connected

6 Did you connect the 5.1 channel analog audio outputs to your AV receiver? Select Connected or Not Connected.

Setup Navigator

Language Settings Audio Out Settings

Speaker Settings AV Receiver Func.

AV Receiver

5.1ch Audio Out

Connected Not Connected

9 Do you have surround speakers connected to your AV receiver? Select Connected or Not Connected.

Setup Navigator

Language Settings Audio Out Settings Speaker Settings

AV Receiver Func.

Center Speaker Surround Speakers

Connected Not Connected

Page 17

Getting Started

10 Do you have a sub-woofer connected to your AV receiver? Select Connected or Not Connected.

Setup Navigator

Language Settings Audio Out Settings Speaker Settings

AV Receiver Func.

Center Speaker Surround Speakers Sub-woofer

Connected Not Connected

• If you selected Not Connected in step 7, that completes the setup. Press ENTER to leave the Setup Navigator.

Questions 11 through 14 are concerned with the digital decoding capabilities of your AV receiver.

11 Is your AV receiver Dolby Digital compatible? Select Compatible, Not Compatible or Don’t Know.

Setup Navigator

Audio Out Settings Speaker Settings AV Receiver Func.

Dolby DigitalLanguage Settings

Compatible Not Compatible Don't Know

13 Is your AV receiver compatible with 96kHz Linear PCM audio? Select Compatible, Not Compatible or Don’t Know.

Setup Navigator

Language Settings Audio Out Settings Speaker Settings AV Receiver Func.

Dolby Digital DTS 96kHz Linear PCM

Compatible Not Compatible Don't Know

14 Is your AV receiver MPEG compatible? Select Compatible, Not Compatible or Don’t Know.

Setup Navigator

Language Settings Audio Out Settings Speaker Settings AV Receiver Func.

Dolby Digital DTS 96kHz Linear PCM MPEG

Compatible Not Compatible Don't Know

15 Press ENTER to complete the setup, or press SETUP to quit the Setup Navigator without making any changes.

12 Is your AV receiver DTS compatible? Select Compatible, Not Compatible or Don’t Know.

Setup Navigator

Dolby Digital DTS

Compatible Not Compatible Don't Know

Language Settings Audio Out Settings Speaker Settings AV Receiver Func.

Setup Navigator

Language Settings Audio Out Settings Speaker Settings AV Receiver Func.

Dolby Digital DTS

Settings complete

96kHz Linear PCM

Press

MPEG

ENTER

Compatible Not Compatible Unknown

to exit

ENTER

Congratulations, setup is complete!

Page 18

Getting Started04

Playing discs

The basic playback controls for playing DVD, CD, SACD, Video CD and MP3 discs are covered here. Further functions are detailed in the next chapter.

Throughout this manual, the term ‘DVD’ means DVD-Video, DVD-Audio and DVD-R/RW. If a function is specific to a particular kind of DVD disc, it is specified.

OPEN / CLOSE

DISPLAY AUDIO SUBTITLE ANGLE

SETUP

4¢ 1 ¡

PLAY MODE SURROUND

– MULTI SPEED +

ENTER

VIDEO

ADJUST DIMMER

V.AD J

TV CONTROL

VOLUME

CHANNEL

–

FL JOG

654

–

TOP MENU

JOG MODE

CLEAR

ENTER

FUNC

873

C321

0987

1 If the player isn’t already on, press STANDBY/ON to switch it on.

If you’re playing a DVD or Video CD, also turn on your TV and make sure that it is set to the correct video input.

2 Press 0 OPEN/CLOSE to open the disc tray.

3 Load a disc.

Load a disc with the label side facing up, using the disc tray guide to align the disc.

Never load more than one disc at a time.

4 Press 3 (play) to start playback.

If you’re playing a DVD or Video CD, a menu may appear.

If you’re playing an MP3 disc, it may take a few seconds before playback starts, depending on the complexity of the file structure on the disc.

Basic playback controls

The table below shows the basic controls on the remote for playing discs. The folllowing chapter covers more playback features in more detail.

Page 19

Getting Started

composite video outputs.

For Other Controls See Front Panel Controls Page 9

Button What it does

3 Starts playback.

DVD and Video CD: if the display shows RESUME, playback starts from the resume point.

8 Pauses a disc that’s playing,

or restarts a paused disc.

7 Stops playback.

DVD and Video CD: Display shows RESUME. Press 7 (stop) again to cancel the resume function (The resume function is also cancelled when you eject the disc tray.).

1 Press to start fast reverse

scanning. Press 3 (play) to resume normal playback.

¡ Press to start fast forward

scanning. Press 3 (play) to resume normal playback.

4 Skips to the start of the

current track or chapter, then to previous tracks/chapters.

¢ Skips to the next track or

chapter.

Numbers Use to enter a title/group/track

number. Press ENTER to select (or wait a few seconds).

• If the disc is stopped, playback starts from the selected title/group (for DVD) or track number (for CD/SACD/Video CD/MP3).

• If the disc is playing, playback jumps to the start of the selected chapter or track (within the current group for DVD-Audio).

Front panel controls

The 3 (play), 7 (stop), and 8 (pause) buttons on the front panel work in exactly the same way as their remote control equivalents. The combined scan/skip buttons on the front panel (4 1 and ¡ ¢) work slightly differently from the remote buttons.

OPEN/CLOSE

41 ¡¢

3PLAY

Press and hold for fast scan; press for track/ chapter skip.

• You may find with some DVD discs that some playback controls don’t work in certain parts of the disc. This is not a malfunction.

DVD disc menus

Many DVD-Video and DVD-Audio discs contain menus from which you can select what you want to watch or listen to. They may give access to additional features, such as subtitle and audio language selection, or special features such as slideshows. See the disc packaging for details.

Sometimes menus are displayed automatically when you start playback; others only appear when you press MENU or TOP

MENU.

Page 20

Getting Started04

• Some DVD-Audio discs feature a ‘bonus group’. To access this group you have to input a password, which you can find on the disc’s packaging.

SETUP

RETURN

4¢ 1 ¡

PLAY MODE SURROUND

Button What it does

TOP MENU Displays the ‘top menu’ of a

disc—this varies with the disc.

MENU Displays a disc menu—this

varies with the disc and may be the same as the ‘top menu’.

Moves the cursor around the

(Joystick)

screen.

ENTER Selects the current menu

option.

(RETURN) Returns to the previously

displayed menu screen. On some DVD-Audio discs featuring browsable pictures, press to display the browser screen.

Numbers Highlights a numbered menu

option (some discs only). Press ENTER to select (or wait a few seconds).

– MULTI SPEED +

ENTER

VIDEO

ADJUST DIMMER

V.AD J

FL JOG

654

TOP MENU

JOG MODE

CLEAR

C321

ENTER

0987

873

Video CD PBC menus

Some Video CDs have menus from which you can choose what you want to watch. These are called PBC (Playback control) menus.

You can play a PBC Video CD/Super VCD without having to navigate the PBC menu by starting playback using a number button or track skip button (¢) to select a track, rather than the 3 (play) button.

SETUP

RETURN

4¢ 1 ¡

PLAY MODE SURROUND

Button What it does

(RETURN) Displays the PBC menu.

Numbers Use to enter a numbered

menu option. Press ENTER to select (or wait a few seconds).

4 Displays the previous menu

page (if there is one).

¢ Displays the next menu page

(if there is one).

– MULTI SPEED +

ENTER

VIDEO ADJUST DIMMER

V.AD J

TOP MENU

FL JOG

654

JOG MODE

873

CLEAR

C321

ENTER

0987

Page 21

Getting Started

• After I load a DVD disc, it ejects automatically after a few seconds!

Most likely, the disc is the wrong region for your player. The region number should be printed on the disc; check it against the region number of the player (which you can find on the rear panel).

If the region number is OK, it may be that the disc is damaged or dirty. Clean the disc and look for signs of damage. Check also that the disc is aligned properly in the disc tray and that it’s loaded label-side up.

• Why won’t the disc I loaded play?

First check that you loaded the disc the right way up (label side up), and that it’s clean and not damaged.

If a disc loaded correctly won’t play, it’s probably an incompatible format or disc type, such as DVD-ROM.

• There’s no pictur e!

Check the front panel and make sure that the VIDEO OFF indicator isn’t lit. If it is, press the VIDEO OFF button to switch the video output back on.

Also make sure that if your TV isn’t compatible with progressive scan video, that the PROGRESSIVE indicator isn’t lit. If it is, press the PROGRESSIVE button to switch the video output back to interlace. See also page 18.

• I have a widescreen TV so why are there black bars at the top and bottom of the screen when I play some discs?

Some movie formats are such that even when played on a widescreen TV, black bars are necessary at the top and bottom of the screen. This is not a malfunction.

• I have a standard (4:3) TV and set the player to show widescreen DVDs in pan & scan format, so why do I still get black bars top and bottom with some discs?

Some discs override the display preferences of the player, so even if you have 4:3 (Pan & Scan) selected, those discs will still be shown in letterbox format. This is not a malfunction.

• My AV receiver is definitely compatible with 96/88.2kHz Linear PCM audio, but it doesn’t seem to work with this player. What’s wrong?

For digital copy-protection purposes, some 96/88.2kHz DVD discs only output digital audio downsampled to 48/44.1kHz. This is not a malfunction. To fully take advantage of the high sampling rate audio, connect the analog audio outputs to your amplifier/receiver.

• Why can’t I hear SACD audio through the digital outputs?

SACD audio is only available through the analog outputs. This is not a malfunction. Some DVD-Audio discs too only output audio through the analog outputs.

Page 22

Getting Started04

• Is it better to listen to DVD-Audio discs through the analog outputs?

Some DVD-Audio discs do not output anything through the digital outputs, and multichannel discs are downmixed to stereo for the digital output. In addition, high sampling rate DVD-Audio discs (higher than 96kHz) automatically downsample audio output from the digital outputs.

Using the multichannel analog audio outputs for DVD-Audio have none of these limitations.

• My DVD-Audio disc starts playing, but then suddenly stops!

The disc may have been illegally copied.

• My CD with MP3 tracks won’t play!

Also make sure that the tracks are encoded in MPEG1 audio layer 3 format.

• Some MP3 tracks don’t show up. Where are they?

Filenames that don’t end with the extension “.mp3” won’t be recognized by this player. Also, if there are more than 250 folders or tracks on the disc, only the first 250 are recognized.

Page 23

Playing Discs

Introduction

Most of the features described in this chapter make use of on-screen displays. Fo

an explanation of how to navigate these

see - Using the on-screen displays.

Many of the functions covered in this chapter apply to DVD and SACD discs, Video CDs, CDs and MP3 discs, although the exact operation of some varies slightly with the kind of disc loaded.

Some DVD discs restrict the use of some functions (random or repeat, for example). This is not a malfunction.

When playing Video CDs, some of the functions are not available during PBC playback. If you want to use them, start the disc playing using a number button to select a track.

Using the Disc Navigator to browse the contents of a disc

Use the Disc Navigator to browse through the contents of a disc to find the part you want to play. You can use the Disc Navigator when a disc is playing or stopped.

1 Press SETUP and select ‘Disc Navigator’ from the on-screen display.

Alternatively, if a DVD-RW, CD, Video CD or MP3 disc is loaded, you can press MENU, which takes you straight to the Disc Navigator screen.

Audio Settings

Play Mode

Setup Navigator

Video Adjust

Disc Navigator

Initial Settings

2 Select what you want to play.

Depending on the type of disc you have loaded, the Disc Navigator looks slightly different.

For DVD-Video discs select a title, or a chapter within a title.

Disc Navigator

DVD

Title(1-03)

Title 01 Title 02 Title 03

Chapter(1-036)

Chapter 001 Chapter 002 Chapter 003 Chapter 004 Chapter 005 Chapter 006 Chapter 007 Chapter 008

• It’s not possible to use the Disc Navigator when playing a Video CD/Super VCD in PBC mode, or when a DVD disc menu is displayed.

For DVD-Audio discs select a group, or a track within a group.

Disc Navigator

DVD-Audio

Group(1-03)

Group 01 Group 02 Group 03

Track(1-14)

Track 01 Track 02 Track 03 Track 04 Track 05 Track 06 Track 07 Track 08

Page 24

Playing Discs05

For SACD discs select a track within the current playback area.

Disc Navigator

2ch Area

Track(1-009)

Track 001 Track 0 02 Track 0 03 Track 0 04 Track 0 05 Track 0 06 Track 0 07 Track 0 08

Total Time 40.31

For a VR mode DVD-RW disc select beween the Playlist and Original areas of the disc, or a title. Move the joystick right to preview the title.

• It’s not possible to switch between Original and Playlist during playback.

• Not all DVD-RW discs have a Playlist.

Disc Navigator

DVD-RW

Original

Play List

Title(1-03)

01. 3/31 FIRST LEAGUE

02. 4/28 SECOND LEAGUE

03. 4/29 FINAL ROUND

For MP3 discs select a folder, or a track within a folder. (Note that if a folder or track name contains accented or non-roman characters, they may show up with generic names – F_033, T_035, etc.).

Disc Navigator

MP3

Folder(1-017)

001. ACP

002. Nth Degree

003. Pfeuti

004. Live

005. Glitch music

006. CodHead

007. Thermo

008. Missing Man

Track(1-010)

001. Gravity deluxe

002. Tesla's patent

003. Border dispute

004. Delayed by rain

005. Accident incident

006. Pigeon post

007. Outernational

008. Vacuum tube

Playback starts after you press ENTER.

• The Disc Navigator is not available unless there is a disc loaded.

• Another way to find a particular place on a disc is to use one of the search modes. See Searching a disc.

For CDs and Video CDs select a track.

Disc Navigator

Track(1-13)

Track 0 1 Track 0 2 Track 0 3 Track 0 4 Track 0 5 Track 0 6 Track 0 7 Track 0 8

Total Time 58.27

Page 25

Playing Discs

Scanning discs

You can fast-scan discs forward or backward at various different speeds using the remote.

1 During playback, press 1 or ¡ to start scanning.

2 Press repeatedly to increase the scanning speed.

• MP3s can only be scanned at one speed.

• The scanning speed is shown on-screen.

3 To resume normal playback, press 3 (play).

• Sound can be heard while scanning SACDs, audio CDs, and MP3 discs.

• There is no sound while scanning DVDVideos and Video CDs, and no subtitles while scanning DVD-Video.

• Depending on the disc, normal playback may automatically resume when a new chapter is reached on a DVD-Video disc.

Using the Multi Dial

You can use the Multi Dial to control fast and slow motion scanning and frame advance of DVD-Video, DVD-R/RW and Video CDs.

When scanning, no audio is output, even when the scanning speed is 1/1 (normal playback speed).

To start scanning playback at 1/16 speed, turn the MULTI DIAL (clockwise for forward; anticlockwise for reverse) during playback.

• Turn the MULTI DIAL in the same direction to increase the scan speed— the speed is indicated at the top left of the screen.

• Turn in the opposite direction to slow the scan speed/reverse direction.

To start high-speed scanning, turn the MULTI DIAL quickly (clockwise for forward; anticlockwise for reverse) during playback.

• Change the speed/direction in the same way as above.

• To resume normal playback, press 3.

To start manual scanning, press JOG (JOG MODE), then use the MULTI DIAL to advance frames in either direction.

To switch off jog mode, press JOG (JOG MODE) again. The picture remains paused until you restart playback.

• To resume normal playback, press 3.

• You can scan Video CDs in the same

way as DVD-Video discs (see above). However, reverse slow-motion scanning is not possible, and there are just two fast scanning speeds.

Page 26

Playing Discs05

Playing in slow motion

You can play DVD-Videos, DVD-R/RW and Video CDs at four different forward slow motion speeds, and DVD-Videos, DVD-R/RW also at two reverse speeds.

1 During playback, press 8 (pause).

2 Press and hold slow motion playback starts.

• The slow motion speed is shown onscreen.

• There is no sound during slow motion playback.

3 Press repeatedly to change the slow motion speed.

• The slow motion speed is displayed onscreen.

4 To resume normal playback, press 3 (play).

• You can’t use slow motion playback with some titles on some DVDs.

• Video CD only supports forward slow motion playback.

• The picture quality during slow motion playback is not as good as during normal playback.

• Depending on the disc, normal playback may automatically resume when a new chapter is reached.

• For DVD-Audio discs featuring browsable pictures, press

/e/E/

picture.

to view the previous/next

until

Frame advance/frame reverse

You can advance or back up DVD-Video or DVD-RW discs frame-by-frame. With Video CDs, you can only use frame advance.

1 During playback, press 8 (pause).

2 Press advance a frame at a time.

3 To resume normal playback, press 3 (play).

• The picture quality when using frame reverse is not as good as frame advance.

• Depending on the disc, normal playback may automatically resume when a new chapter is reached.

• When changing direction of a DVDVideo disc, the picture may ‘move’ in an unexpected way. This is not a malfunction.

• For DVD-Audio discs featuring browsable pictures, press

/e/E/

picture.

to reverse or

to view the previous/next

Page 27

Playing Discs

Looping a section of a disc

The A-B Repeat function allows you to specify two points (A and B) within a track (DVD-Audio, CD and Video CD) or title (DVDVideo and DVD-RW) that form a loop which is played over and over.

• A-B Repeat is not available with SACDs, MP3s, Super VCDs, Video CD in PBC mode, or while a DVD disc menu is being displayed.

1 During playback, press PLAY MODE and select ‘A-B Repeat’ from the list of functions on the left.

Play Mode

A-B Repeat Repeat Random Program Search Mode

2 Press ENTER on ‘A(Start Point)’ to set the loop start point.

A(Start Point)

B(End Point) Off

3 Press ENTER on ‘B(End Point)’ to set the loop end point.

Play Mode

A-B Repeat Repeat Random Program Search Mode

A(Start Point)

B(End Point) Off

After pressing ENTER, playback jumps back to the start point and plays the loop.

4 To resume normal playback, press CLEAR or select ‘Off’ from the menu.

Play Mode

A-B Repeat Repeat Random Program Search Mode

A(Start Point)

B(End Point) Off

Page 28

Playing Discs05

Using repeat play

There are various repeat play options, depending on the kind of disc loaded. It’s also possible to use repeat play together with program play to repeat the tracks/chapters in the program list (see Creating a program list.

• Repeat play is not available with Video CDs/Super VCD in PBC mode, or while a DVD disc menu is being displayed.

1 During playback, press PLAY MODE and select ‘Repeat’ from the list of functions on the left.

Play Mode

A-B Repeat Repeat Random Program Search Mode

2 Select a repeat play option.

The repeat play options available depend on the type of disc loaded. The screen below appears when a DVD-Video disc is loaded.

Title Repeat Chapter Repeat

Repeat Off

DVD-Video and DVD-RW discs

• Title Repeat

• Chapter Repeat

• Repeat Off

DVD-Audio discs

• Group Repeat

• Track Repeat

• Repeat Off

SACD, CD and Video CD discs

• Disc Repeat

• Track Repeat

• Repeat Off

MP3 discs

• Disc Repeat

• Folder Repeat

• Track Repeat

• Repeat Off

• If you’ve made a program list, the

Program Repeat option also appears as a repeat option.

• To stop the disc and cancel repeat play, press 7 (stop).

• You can also cancel repeat play without stopping playback by pressing CLEAR. The disc will play to the end, then stop.

Play Mode

A-B Repeat Repeat Random Program Search Mode

Title Repeat Chapter Repeat

Repeat Off

• You can’t use repeat and random play at the same time.

• If you switch camera angle during repeat play, repeat play is canceled.

Page 29

Playing Discs

Using random play

Use the random play function to play titles or chapters (DVD-Video ), groups or tracks (DVD-Audio), or tracks (CD, Video CD and MP3 discs) in a random order.

You can set the random play option when a disc is playing or stopped.

• You can’t use random play with SACDs, DVD-RWs, Video CDs/Super VCDs playing in PBC mode, or while a DVD disc menu is being displayed.

1 Press PLAY MODE and select ‘Random’ from the list of functions on the left.

Play Mode

A-B Repeat Repeat Random Program Search Mode

2 Select a random play option.

The random play options available depend on the type of disc loaded. The screen below appears when a DVD-Video disc is loaded.

Random Title Random Chapter

Random Off

DVD-Video discs

• Random Title

• Random Chapter

• Random Off

DVD-Audio discs

• Random Group

• Random Track

• Random Off

MP3, CD and Video CD discs

• On

• Off

• To stop the disc and cancel random playback, press 7 (stop).

• You can also cancel random playback without stopping the disc by presssing CLEAR. The disc will play to the end, then stop.

• During random play, the 4 and ¢ buttons function a little differently to normal: 4 returns to the beginning of the current track/chapter. You can't go back further than this. ¢ selects another track/chapter at random from those remaining.

• You can't use random play together with program or repeat play.

Play Mode

A-B Repeat Repeat Random Program Search Mode

Random Title Random Chapter

Random Off

Page 30

Playing Discs05

Creating a program list

This feature lets you program the play order of titles/group/chapters/folders/tracks on a disc.

• Program play is not available with DVDRWs, Video CDs/Super VCDs playing in PBC mode, or while a DVD disc menu is being displayed.

1 Press PLAY MODE and select ‘Pro- gram’ from the list of functions on the left.

Play Mode

A-B Repeat Repeat Random Program Search Mode

2 Select ‘Create/Edit’ from the list of program options.

Play Mode

A-B Repeat Repeat Random Program Search Mode

Create/Edit

Playback Start Playback Stop Program Delete

Program Memory ‰ Off

Create/Edit

Playback Start Playback Stop Program Delete

Program Memory ‰ Off

3 Select a title, chapter, group, folder or track for the current step in the program list.

For a DVD-Video disc, you can add a whole title, or a chapter within a title to the program list.

• To add a title, select the title.

Program

Program Step

01. 01

02.

03.

04.

05.

06.

07.

08.

Title(1-03)

Title 01 Title 02 Title 03

Chapter(1-036)

Chapter 001 Chapter 002 Chapter 003 Chapter 004 Chapter 005 Chapter 006 Chapter 007 Chapter 008

• To add a chapter, first highlight the title, then move the cursor right and select a chapter from the list.

Program

Program Step

01. 01-003

02.

03.

04.

05.

06.

07.

08.

Title(1-03) Chapter(1-036)

Title 01 Title 02 Title 03

Chapter 001 Chapter 002 Chapter 003 Chapter 004 Chapter 005 Chapter 006 Chapter 007 Chapter 008

For a DVD-Audio disc, you can add a whole group, or a track within a group to the program list.

• To add a group, select the group.

The Program edit screen that appears depends on the kind of disc loaded.

On the left side is the program list, then to the right is a list of titles (if a DVD-Video disc is loaded), groups (for DVD-Audio), tracks (for SACDs, CDs and Video CDs/Super VCD), or folder names (for MP3 discs). On the far right is a list of chapters (for DVD-Video) or tracks (for DVD-Audio and MP3).

Program

Program Step

01. 01

02.

03.

04.

05.

06.

07.

08.

Group(1-03)

Group 01 Group 02 Group 03

Track(1-14)

Track 01 Track 02 Track 03 Track 04 Track 05 Track 06 Track 07 Track 08

Page 31

Playing Discs

• To add a track, first highlight the group, then move the cursor right and select a track from the list.

Program

Program Step

01. 01-03

02.

03.

04.

05.

06.

07.

08.

Group(1-03) Track(1-14)

Group 01 Group 02 Group 03

Track 0 1 Track 0 2 Track 0 3 Track 0 4 Track 0 5 Track 0 6 Track 0 7 Track 0 8

For SACD, CD or Video CD/Super VCD, select a track to add to the program list.

(The screen below shows a CD loaded.)

Program

Program Step

01. 04

02.

03.

04.

05.

06.

07.

08.

Track(1-12) Track 01 Track 02 Track 03 Track 04 Track 05 Track 06 Track 07 Track 08

Total Time 0.00

For an MP3 disc, you can add a whole folder, or a track within a folder to the program list.

• To add a folder, select the folder.

• To add a track, first find the folder, then

move the cursor right and select a track name from the list.

Program

Program Step

01. 001-003

02.

03.

04.

05.

06.

07.

08.

Folder(1-006)

001. ACP

002. Nth Degree

003. Pfeuti

004. Live

006. CodHead

Track(1-010)

001. Gravity deluxe

002. Tesla's patent

003. Border dispute

004. Delayed by rain

005. Accident incident

006. Pigeon post

007. Outernational

008. Vacuum tube

After pressing ENTER to select the title/ group/chapter/folder/track, the step number automatically moves down one.

4 Repeat step 3 to build up a program list.

A program list can contain up to 24 titles/ chapters/groups/folders/tracks.

5 To play the program list, press 3 (play).

Program play remains active until you turn off program play (see below), erase the program list (see below), eject the disc or switch off the player.

Program

Program Step

01. 001

02.

03.

04.

05.

06.

07.

08.

Folder(1-006)

001. ACP

002. Nth Degree

003. Pfeuti

004. Live

005. Glitch music

006. CodHead

Track(1-010)

001. Gravity deluxe

002. Tesla's patent

003. Border dispute

004. Delayed by rain

005. Accident incident

006. Pigeon post

007. Outernational

008. Vacuum tube

• To exit the program edit screen without starting playback, press PLAY MODE or SETUP. (Don’t press RETURN—your program list will be lost.)

• During program play, press ¢ to skip to the next program step.

• Press CLEAR during playback (though not if the program list OSD is displayed) to switch off program play. Press while stopped to erase the program list.

Page 32

Playing Discs05

Editing a program list

After creating a program list, you can add, delete and change steps.

1 Press PLAY MODE and select ‘Pro- gram’ from the list of functions on the left.

2 Select ‘Create/Edit’ from the list of program options.

3 To clear a step, highlight the step number and press CLEAR.

4 To insert a step in the middle of the program list, highlight the step where you want the new step to appear, then select a title/group/chapter/folder/track to add.

After pressing ENTER, the new step is inserted into the list.

5 To add a step to the end of the program list, highlight the next free step then select a title/group/chapter/folder/ track to add.

• To exit the program edit screen without starting playback, press PLAY MODE or SETUP.

• If you want to exit the program edit screen without saving the changes you made, press RETURN.

Other functions available from the program menu

As well as creating and editing a program list, you can start and stop program play, erase the program list, and memorize a DVD program list from the Program menu.

1 Press PLAY MODE and select ‘Pro- gram’ from the list of functions on the left.

Play Mode

A-B Repeat Repeat Random Program Search Mode

2 Select a program play function.

• Create/Edit – See Creating a program list.

• Playback Start – Starts playback of the program list

• Playback Stop – Turns off program play, but does not erase the program list

• Program Delete – Erases the program list and turns off program play

• Program Memory (DVD-Video only) – Select On to save the program list for the disc loaded. (Select Off to cancel the program memory for the disc loaded)

Create/Edit Playback Start Playback Stop Program Delete Program Memory ‰ Off

• After saving a program list using the Program Memory feature, whenever you load that disc, the program list is automatically recalled and program play switched on.

• You can save program lists for up to 24 discs. After that, the oldest one is replaced with the new one saved.

Page 33

Playing Discs

Searching a disc

Using the search mode function from the Play Mode menu you can quickly jump to a particular part of the disc that you’re watching or listening to.

1 Press PLAY MODE and select ‘Search Mode’ from the list of functions on the left.

The search options that appear depend on the kind of disc loaded. The screen below shows the DVD-Video search options.

Play Mode

A-B Repeat Repeat Random Program Search Mode

2 Select a search mode. 3 Use the number buttons to enter a

title, group, chapter, page, folder or track number, or a time.

Play Mode

A-B Repeat Repeat Random Program Search Mode

Title Search Chapter Search Time Search

Input Chapter

4 Press ENTER to start playback.

• You can only use time search with DVDVideo and Video CD discs.

• The disc must be playing in order to use time search.

• Search functions are not available with Video CDs/Super VCD in PBC mode (start non-PBC playback by stopping playback, then pressing ¢, then 3 (play)).

• You can often select what you want to watch from a DVD disc menu.

• For a time search, enter the number of minutes and seconds into the currently playing title (DVD-Video/DVD-RW) or track (Video CD) you want playback to resume from. For example, press 4, 5, 0, 0 to have playback start from 45 minutes into the disc. For 1 hour, 20 minutes and 30 seconds, press 8, 0, 3, 0.

• Some DVD-Audio discs feature pages of browsable pictures. Enter the page number you want.

Page 34

Playing Discs05

Switching subtitles

Some DVD-Video discs have subtitles in one or more languages; the disc box will usually tell you which subtitle languages are available. You can switch subtitle language during playback.

1 Press SUBTITLE repeatedly to select a subtitle option.

Subtitle 1 English

• While the above display is showing, you can also use the joystick (up/down) and ENTER to select a subtitle language from a drop-down menu.

Subtitle 1 English

Off

1. English

2. French

3. German

4. Italian

• Some discs only allow you to change subtitle language from the disc menu. Press TOP MENU to access.

• To set subtitle preferences, see Subtitle Language.

1/ 1

Switching DVD-Video audio language

When playing a DVD-Video disc recorded with dialog in two or more languages, you can switch audio language during playback.

1 Press AUDIO repeatedly to select an audio language option.

Audio Dolby Digital 3/2.1CH2 French

• With some discs, while the above display is showing, you can also use the joystick (up/down) and ENTER to select an audio language from a drop-down menu.

Audio Dolby Digital 3/2.1CH

2 French

1. English

2. French

3. German

4. Italian

• Some discs only allow you to change audio language from the disc menu. Press TOP MENU to access.

• To set audio language preferences, see

Audio Language.

Dolby Digital 3/2.1CH Dolby Digital 3/2.1CH Dolby Digital 2CH Dolby Digital 2CH

1/ 1

Page 35

Playing Discs

Switching DVD-RW audio channel

When playing a DVD-RW disc recorded with dual-mono audio, you can switch between the main, sub, and mixed channels during playback.

1 Press AUDIO repeatedly to select an audio channel option.

Audio Dolby Digital 1+1CH1L

Switching DVD-Audio audio channel

Depending on the disc, you may be able to switch channels when playing DVD-Audio discs—see the disc box for details.

1 Press AUDIO repeatly to select an audio channel option.

Audio

When you change the audio channel, playback restarts from the beginning of the current track.

Digital Out Converted Linear PCM 192kHz24bit

2CH

Switching CD/MP3/Video CD audio channel

You can switch between stereo, just the left channel or just the right channel of a CD/ MP3/Video CD/Super VCD. (To change the audio channel of a CD it must be playing.)

Some Super VCDs have two soundtracks. With these discs you can switch between the two soundtracks as well as individual channels in each.

1 Press AUDIO repeatly to select an audio channel option.

Audio

Stereo

Switching camera angles

Some DVD-Video discs feature scenes shot from two or more angles—check the disc box for details.

When a multi-angle scene is playing, a icon appears on screen to let you know that other angles are available (this can be switched off if you prefer).

¶ During playback press ANGLE to switch angle.

• Some discs only allow you to change audio channel from the disc menu. Press TOP MENU to access.

• To set audio language preferences, see

Audio Language.

Page 36

Playing Discs05

Displaying disc information

Various track, chapter and title information, as well as the video transmission rate for DVD discs, can be displayed on-screen.

1 During playback, press DISPLAY to show/switch the information displayed.

Keep pressing DISPLAY to change the displayed information.

• DVD-Video displays

Play DVD

Current / Total Elapsed

Title

1 English

Audio

Dolby Digital 3/2.1CH

Play DVD

Current / Total Elapsed

Chapter

# Tr. Rate : 6.0Mbps

The # mark displayed with some DVD-Video discs means that the video is playing at 24 frames/second, progressive.

Pause DVD

Current / Total Elapsed

Chapter

Tr. Rate : 6.0Mbps

When the disc is paused, the display also shows the frame number.

• DVD-Audio displays

Play DVD-Audio

Current / Total Elapsed

Trac k

1 Linear PCM

Audio

192kHz 24bit 2/0CH

Play DVD

Current / Total Elapsed

Group

Tr. Rate : 9.5Mbps

• DVD-RW displays

Play DVD-RW Original

Current / Total Elapsed

Title

Audio Dolby Digital 2/0CH

Play DVD-RW Original

Current / Total

Chapter

1/1

Tr. Rate 4.3Mbps

0.062/36

0.06 152/36

-Audio

2.231/3

3.201/14

3.211/3

0.081/32

Subtitle

Remain

138.36 1 English 1

Remain

1.40

Remain

1.40

Remain

2.41

- - 1

Remain

53.20

Remain

30.22

- -

Tota l

Total

6.01

30.30

Total

138.59

Tota l

56.41

• SACD displays

Play SACD

Current / Total Elapsed

Trac k

Remain

0.221/9

Total

3.38

4.00

(During multichannel playback only)

Play SACD

Current / Total Elapsed

Trac k

3/2.1CH

Audio

Play SACD

Disc

0.221/9

Elapsed

Remain

Tota l

3.38

4.00

Remain

40.07

Tota l

40.31

0.24

• CD and Video CD displays

AngleSubtitle

1.46

Play VCD

Disc

Play VCD

Current / Total Elapsed

Trac k

Elapsed

0.232/16

Remain

58.51

Remain

4.20

Tota l

Total

57.14

4.43

0.23

(During PBC playback only)

Play VCD

• MP3 disc displays

1.46

AngleSubtitle

Play MP3

Current / Total Elapsed Track Track Name Outernational

Play MP3

Current / Total Folder

2/7

Folder Name ACP

Remain

12.42

Tota l

13.00

0.181/17

• You can see disc information (number of titles/chapters, groups, tracks, folders and so on) from the Disc Navigator screen. See Using the Disc Navigator to

browse the contents of a disc.

Page 37

The Audio Settings Menu

Audio DRC

• Default setting: Off

When watching Dolby Digital DVDs at low volume, it’s easy to lose the quieter sounds completely—including some of the dialog. Switching Audio DRC (Dynamic Range Control) to On can help by bringing up the quieter sounds, while controlling loud peaks.

How much of a difference you hear depends on the material you’re listening to. If the material doesn’t have wide variations in volume, you may not notice much change.

1 Press SETUP and select ‘Audio Settings’ from the on-screen display.

• Audio DRC is only effective with Dolby Digital audio sources.

• Audio DRC is only effective through the digital output when Digital Out is set to

On, and Dolby Digital Out is set to Dolby Digital > PCM.

• The effect of Audio DRC depends on your speakers and AV receiver settings.

Audio Settings

Play Mode

Initial Settings

Video Adjust

Disc Navigator

Setup Navigator

2 Highlight Audio DRC, then use the Joystick (left/right) to change to ‘On’ or ‘Off’, as required.

Audio Settings 1/ 2

Audio DRC Virtual Surround Channel Level

Off Off Fix

3 Press ENTER to make the setting and exit the Audio Settings screen.

Page 38

The Audio Settings Menu

Virtual Surround

• Default setting: Off

Switch on Virtual surround to enjoy surround sound effects from just two speakers.

When you play a Dolby Digital soundtrack, Virtual Dolby Digital, which uses TruSurround technology from SRS, produces a deep, realistic 3D soundspace from a pair of stereo speakers.

1 Press SETUP and select ‘Audio Settings’ from the on-screen display.

Audio Settings

Play Mode

Initial Settings

Video Adjust

Disc Navigator

Setup Navigator

2 Highlight TruSurround, then use the Joystick (left/right) to change to ‘2V/ TruSurround’ or ‘Off’, as required.

Audio Settings

Audio DRC Virtual Surround Channel Level

1/ 2

Off Off

Fix

3 Press ENTER to make the setting and exit the Audio Settings screen.

• You can also use the SURROUND button on the remote control to switch Virtual Surround on (2V/ TruSurround)/Off.

• Virtual Surround does not work with CD, MP3, DVD-Audio or SACD discs, or 96kHz Linear PCM soundtracks.

• The Virtual Surround effect is output only through the analog AUDIO OUT jacks.

• Make sure that Audio Output Mode is set to 2 Channel.

• How good the surround effect is varies with the disc.

Page 39

composite video outputs.

This Menu is available by using

the joystick to move the cursor

one step below "Virtual Surround"

The Audio Settings Menu

Set the distance for each speaker.

Audio Settings 3/3

Speaker Distance L Speaker Distance C Speaker Distance R Speaker Distance LS Speaker Distance RS Speaker Distance SW

• Use the joystick (up/down) to select a speaker.

• Use the joystick (left/right) to adjust the distance from your listening position to that speaker.

Front left/right (L/R) speakers can be set from 1.0 ft. to 30 ft. in 0.5 ft. increments.

Center speaker (C) and subwoofer (SW) can be set from – 6.5 ft. to +6.5 ft. relative to the front left/right speakers

Surround left/right (LS/RS) speakers can be set from –20 ft. to +6.5 ft. relative to the front left/right speakers.

When you adjust the front left (L) or front right (R) speaker, all the other speaker distances are adjusted relative to that speaker.

10.0 ft.

6 Press ENTER to make the settings and exit the audio settings screen.

• The speaker distance settings have no effect on SACD playback.

• You can’t adjust the channel level for any speakers that are set to Off in the Speaker Installation menu screen (page 64).

• The Fix setting is equivalent to setting all the channel levels to +6 dB. There- fore, the Variable setting will usually sound quieter than the Fix setting.

Page 40

The Video Settings Menu

composite video outputs.

Video Adjust - Interlace Only

• Default setting: Standard

From the Video Adjust screen you can select the standard video presentation or define presets of your own.

1 Press SETUP and select ‘Video Adjust’ from the on-screen display.

You can also access these settings by pressing V.ADJ (VIDEO ADJUST).

Audio Settings

Play Mode

Initial Settings

2 Use the joystick (left/right) to select a preset.

Video Adjust

• Standard – Normal

• I. Memory1–2 Use for making your own

interlaced presets (see below)

3 Press ENTER to make the setting and exit the Video Adjust screen.

• Depending on the disc and the TV/ monitor, you may not see the effect clearly.

Creating your own interlace output presets

Video Adjust

Disc Navigator

Setup Navigator

Standard

1 Select one of the Memory presets (see above).

2 Move the joystick down to select ‘Detailed Settings’ then press ENTER.

Video Adjust

I.Memory1

Detailed Settings

3 Adjust the picture quality settings.

Interlace Memory 1 (I. Memory 1)

Recall Settings Fine Focus Contrast Sharpness Chroma Level Hue

I.Memory1

On min max soft fine min

green

max red

• Use the joystick (up/down) to select a setting.

• Use the joystick (left/right) to adjust the current setting.

• Press DISPLAY to switch between full and single view.

• You can change the preset number from the Recall Settings menu item.

You can adjust any or all of the following picture quality settings:

• Fine Focus – Switch On to reveal greater detail (high resolution) in the picture.

• Contrast – Adjusts the contrast between light and dark elements in the picture.

• Sharpness – Adjusts the sharpness of the mid-frequency (less detailed) elements in the picture. (This setting is only effective when Fine Focus is On.)

• Chroma Level – Adjusts how saturated colours appear.

• Hue – Adjusts the overall colour

balance between red and green. (This is

Page 41

The Video Settings Menu

4 Press ENTER to save the preset and exit the Video Adjust screen.

Creating your own progressive output presets

These presets are available when the video output is set to progressive. (Use the front panel PROGRESSIVE button to switch between interlace and progressive video output. See also page 18)

1 Select one of the Memory presets (see above).

2 Move the joystick down to select ‘Detailed Settings’ then press ENTER.

Video Adjust

P. Memory1

Detailed Settings

3 Ajust the picture quality settings.

Progressive Memory 1 (P. Memory 1)

green

P.M emo r y1

Auto soft soft

off

min

fine fine max max red

Recall Settings PureCinema Sharpness Contrast Brughtness Chroma Level Hue

• Use the joystick (up/down) to select a setting.

• Use the joystick (left/right) to adjust the current setting.

• Press DISPLAY to switch between full and single view.

• You can change the preset number from the Recall Settings menu item.

You can adjust any or all of the following

picture quality settings:

• PureCinema – When watching DVD movies, PureCinema optimizes the picture quality. The default setting is Auto, but if the picture appears unnatural, then set to On or Off, as appropriate.

• Sharpness – Adjusts the sharpness of the mid-frequency (less detailed) elements in the picture.

• Contrast – Adjusts the contrast between light and dark elements in the picture.

• Brightness – Adjusts the overall brightness of the picture.

• Chroma Level – Adjusts how saturated colours appear.

• Hue – Adjusts the overall colour balance between red and green.

3 Press ENTER to save the preset and exit the Video Adjust screen.

• Video on a DVD discs may be either video material (originally shot on video) or film material (originally shot on film). Video material has a frame rate of 30 frames/sec.(NTSC), compared with 24 frames/sec. for film. This player converts film material to 60 frames/sec. (in progressive scan mode). PureCinema adjusts the picture so that it matches more closely the picture quality of a cinema screen.

You can see whether video on a DVD disc is film or video material by displaying the video transmission rate (see If a hash mark (#) appears next to the transmission rate display, it is film material.

Page 42

The Initial Settings Menu

7417

Using the Initial Settings menu

The Initial Settings menu is where you can set preferences for language, audio and video output, and so on.

If a menu option is grayed out it means that it cannot be changed at the current time. This is usually because a disc is playing. Stop the disc, then change the setting.

1 Press SETUP and select ‘Initial Settings’ from the on-screen display.

Audio Settings

Play Mode

Initial Settings

Video Adjust

Disc Navigator

Setup Navigator

2 Select the setup category from the list on the left, then select an item from the menu list to the right.

3 Make the setting you want.

Digital Audio Out settings

Digital Out

• Default setting: On

You only need to make this setting if you connected this system to an AV receiver (or other component) using one of the digital outputs.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Digital Out Dolby Digital Out DTS Out Linear PCM Out MPEG Out

On Off

If at any time you need to switch off the digital audio output, set this to Off, otherwise leave it On.

• You can’t switch on/off the optical and coaxial outputs individually.

• There is no digital output when playing SACDs and some DVD-Audio discs regardless of this setting.

Dolby Digital Out

• Default setting: Dolby Digital

You only need to make this setting if you connected this system to an AV receiver (or other component) using one of the digital outputs.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

If your AV receiver (or other connected component) is Dolby Digital compatible, set to Dolby Digital, otherwise set to Dolby Digital > PCM.

Digital Out Dolby Digital Out DTS Out Linear PCM Out MPEG Out

Dolby Digital Dolby Digital > PCM

Page 43

Page 44

The Initial Settings Menu

If your AV receiver (or other connected component) is compatible with MPEG audio, set this to MPEG, otherwise set it to MPEG > PCM (MPEG audio is converted to more compatible PCM audio). Check the manual that came with the other component if you’re unsure whether it is MPEG audio compatible.

Video Output settings

TV Screen

• Default setting: 16:9 (Wide)

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

TV Screen Auto Progressive S-Video Out Still Picture

If you have a widescreen TV, select the 16:9 (Wide) setting—widescreen DVD software is

then shown using the full screen area. When playing software recorded in conventional (4:3) format, the settings on your TV will determine how the material is presented— see the manual that came with your TV for details on what options are available.

If you have a conventional TV, select either 4:3 (Letter Box) or 4:3 (Pan & Scan). In Letter Box mode, widescreen software is shown with black bars at the top and bottom of the screen. Pan & Scan chops the sides off widescreen material to make it fit the 4:3 screen (so even though the image looks larger on the screen, you’re actually seeing less of the picture).

4:3 (Letter Box) 4:3 (Pan&Scan) 16:9 (Wide)

S-Video Out

• Default setting: S2

You only need to make this setting if you connected this player to your TV using an S-Video cord.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

TV Screen Auto Progressive S-Video Out Still Picture

S1 S2

If you find that the picture is stretched or distorted on the default S2 setting, try changing it to S1. (See also S1 and S2 in the Glossary .)

experience this problem you can leave this setting as Off.

S-Video Out

• Default setting: S2

You only need to make this setting if you connected this player to your TV using an S-Video cord.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

If you find that the picture is stretched or distorted on the default S2 setting, try changing it to S1. (See also S1 and S2 in the Glossary .)

TV Screen Auto Progressive S-Video Out Still Picture

S1 S2

Page 45

The Initial Settings Menu08

Still Picture

• Default setting: Auto

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

This player uses one of two processes when displaying a still frame from a DVD disc. The default Auto setting automatically chooses the best setting each time.

• Field – produces a stable, generally shake-free image

• Frame – produces a sharper image, but more prone to shake than field stills

TV Screen Auto Progressive S-Video Out Still Picture

Field Frame Auto

Language settings

Audio Language

• Default setting: English

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

This setting is your preferred audio language for DVD-Video discs. If the language you specify here is recorded on a disc, the system automatically plays the disc in that language.

The DVD-Video format recognizes 136 different languages. Select Other Language if you want to specify a language other than those listed. See also Selecting languages

using the language code list.

• You can switch between the languages recorded on a DVD disc during playback using the AUDIO button. (This does not affect this setting.)

• Some DVD discs set the audio language automatically when loaded, overriding the audio language you set in the Initial Settings menu.

• Discs with two or more audio languages usually allow you to select the audio language from the disc menu. Press TOP MENU to access the disc menu.

Audio Language Subtitle Language Auto Language DVD Menu Lang. Subtitle Display

English French German Italian Spanish Dutch Other Language

Page 46

The Initial Settings Menu

Subtitle Language

• Default setting: English

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

This setting is your preferred subtitle language for DVD-Video discs. If the language you specify here is recorded on a disc, the system automatically plays the disc with those subtitles.

The DVD-Video format recognizes 136 different languages. Select Other Language if you want to specify a language other than those listed. See also Selecting languages

using the language code list.

• You can change or switch off the subtitles on a DVD disc during playback using the SUBTITLE button. (This does not affect this setting.)

• Some DVD discs set the subtitle language automatically when loaded, overriding the subtitle language you set in the Initial Settings menu.

• Discs with two or more subtitle languages usually allow you to select the subtitle language from the disc menu. Press TOP MENU to access the disc menu.

Audio Language Subtitle Language Auto Language DVD Menu Lang. Subtitle Display

English French German Italian Spanish Dutch Other Language

Auto Language

• Default setting: On

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

When set to On, the player always selects the default audio language on a DVD-Video disc (French dialog for a French movie, for example), and displays subtitles in your preferred subtitle language only if that is set to something different. In other words, movies in your native language won’t have any subtitles, while foreign language movies will be shown with subtitles.

Set to Off to have the player play discs strictly according to your Audio Language and Subtitle Language settings.

For Auto Language to work, the Audio Language and Subtitle Language settings must be the same.

• You can still switch audio and subtitle language on playback using the AUDIO and SUBTITLE buttons.

Audio Language Subtitle Language Auto Language DVD Menu Lang. Subtitle Display

On Off

Page 47

The Initial Settings Menu08

DVD Menu Language

• Default setting: w/Subtitle Lang.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Audio Language Subtitle Language Auto Language DVD Menu Lang. Subtitle Display

w/Subtitle Lang. Other Language

Some multilingual discs have disc menus in several languages. This setting specifies in which language the disc menus should appear. Leave on the default setting for menus to appear in the same language as your Subtitle Language.

The DVD-Video format recognizes 136 different languages. Select Other Language if you want to specify a language other than those listed. See also Selecting languages

using the language code list.

Subtitle Display

• Default setting: On

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Audio Language Subtitle Language Auto Language DVD Menu Lang. Subtitle Display

On Off Assist Subtitle

Display settings

OSD Language

• Default setting: English

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

This sets the language of this player’s onscreen displays.

On Screen Display

• Default setting: On

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

This sets whether operation displays are shown on-screen (Play, Resume, Scan and so on.)

OSD Language On Screen Display Angle Indicator Background Screen Saver

English français Deutsch Italiano Español Nederlands

On Off

When set to On, the player displays subtitles according to the Subtitle Language and Auto Language settings. Set to Assist Subtitle to have the player display the extra assistive subtitles recorded on to some DVD discs. Set to Off to switch subtitles off altogether.

Page 48

The Initial Settings Menu

Angle Indicator

• Default setting: On

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

OSD Language On Screen Display Angle Indicator Background Screen Saver

On Off

If you prefer not to see the camera icon onscreen during multi-angle scenes on DVD discs, change this setting to Off.

Background

• Default setting: Logo

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

This specifies what is displayed on-screen when the player is stopped.

OSD Language On Screen Display Angle Indicator Background Screen Saver

Logo Black

If a constant image is displayed on a conventional CRT-type TV, it can ‘burn in’ leaving a ghost image on the screen. Switch to On to make sure that a constant image is not displayed for a dangerously long time.

Options

Parental Lock

• Default level: Off

• Default password: none

• Default country code: us (2119)

Some DVD Video discs feature a Parental Lock level. If your player is set to a lower level than the disc, the disc won’t play. This gives you some control about what your children watch on your DVD player.

Some discs also support the Country Code feature. The player does not play certain scenes on these discs, depending on the country code you set.

Before you can set the Parental Lock level or the Country Code you must register a password. As the password owner, you can change the Parental Lock level or Country Code whenever you like. You can also change the password.

Screen Saver

• Default setting: On

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

OSD Language On Screen Display Angle Indicator Background Screen Saver

• Not all discs that you may consider inappropriate for your children use the Parental Lock feature. These discs will

On Off

always play without requiring the password first.

• If you forget your password, you’ll need to reset the player to it’s factory settings then register a new password.

Page 49

The Initial Settings Menu08

Registering a new password

You must register a password before you can change the Parental Lock level or enter a Country Code.

1 Select ‘Password’.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock Bonus Group Auto Disc Menu Group Playback DVD Playback Mode SACD Playback CD Playback

Password

Level Change Country Code

2 Use the number buttons to enter a 4digit password.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock: Register Code Number

The numbers you enter show up as asterisks (*) on-screen.

3 Press ENTER to register the password and return to the Options menu screen.

If you forget your password, you can reset the system then register a new one.

Changing your password

To change your password, confirm your existing password then enter a new one.

1 Select ‘Password Change’.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock Bonus Group Auto Disc Menu Group Playback DVD Playback Mode SACD Playback CD Playback

Password Change Level Change Country Code

2 Use the number buttons to enter your existing password, then press ENTER.

• The numbers appear as asterisks as you enter them.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock : Password Change

Password

New Password

3 Enter a new password.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock : Password Change

Password

New Password

****

4 Press ENTER to register the new password and return to the Options menu screen.

Page 50

The Initial Settings Menu

Setting/changing the Parental Lock level

1 Select ‘Level Change’.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock Bonus Group Auto Disc Menu Group Playback DVD Playback Mode SACD Playback CD Playback

Password Change Level Change Country Code

2 Use number buttons to enter your password, then press ENTER.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock : Level Change

Password

1 2 3 4 5 6 7 8 off

3 Select a new level.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock : Level Change

Password

1 2 3 4 5 6 7 8 off

****

Move the joystick left to lock more levels (more discs will require the password); move right to unlock levels. You can’t lock level 1.

Setting/changing the Country Code

You may also want to refer to the Country code list.

1 Select ‘Country Code’.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock Bonus Group Auto Disc Menu Group Playback DVD Playback Mode SACD Playback CD Playback

Password Change Level Change Country Code

2 Use number buttons to enter your password, then press ENTER.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock : Change Country Code

Password

Country Code List

Code

2 1 1 9

3 Select a country code.

There are two ways you can do this.

• Select by code letter: Use the joystick (up/down) to change the country code.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock : Change Country Code

Password

Country Code List

***

Code

2 1 1 9

4 Press ENTER to set the new level and return to the Options menu screen.

• Select by code number: Move the joystick right then use the number buttons to enter the 4-digit country code See Country code list).

Page 51

The Initial Settings Menu08

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock : Change Country Code

Password

Country Code List Code

****

2 1 1 9

4 Press ENTER to set the new Country Code and return to the Options menu screen.

• Changing the country code does not take effect until the next disc is loaded (or the current disc is reloaded).

Bonus Group

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock Bonus Group Auto Disc Menu Group Playback DVD Playback Mode SACD Playback CD Playback

Some DVD-Audio discs have an extra ‘bonus’ group that requires a 4-digit key number to access. See the disc packaging for details and the key number.

When you play a DVD-Audio disc that has a bonus group, the key number input screen appears automatically. You can also access the same screen here.

‰ Off (us)

‰ On ‰ Single ‰ DVD-Audio ‰ 2ch Area ‰ PCM Playback

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Bonus Group : Key Number Input

• If you eject the disc, switch the power off, or unplug the player, you will need to re-enter the key number.

Auto Disc Menu

• Default setting: On

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

This specifies whether the menu (Top menu) is automatically displayed after loading a disc. Set to On if you want the menu displayed automatically, or Off if you don’t want it displayed.

• Some DVD discs display a menu automatically regardless of this setting. If you press 3 while a disc is loading, this setting is ignored.

Parental Lock Bonus Group Auto Disc Menu Group Playback DVD Playback Mode SACD Playback CD Playback

On Off

Page 52

The Initial Settings Menu

Group Playback

• Default setting: Single

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

DVD-Audio discs can have up to 9 groups of tracks. When set to Single, the selected group plays and then the disc stops, or returns to the menu screen. Use Group Search to select the group to play. (You cannot use the track skip 4 / ¢ or scan buttons 1 / ¡ in this mode.)

Set to All if you want to play all the groups on a disc consecutively.

• Even if the players is set to All but you select a group to play from the disc menu, only that group will play. If you stop playback, all groups will play again when you restart playback.

Parental Lock Bonus Group Auto Disc Menu Group Playback DVD Playback Mode SACD Playback CD Playback

All Single

DVD Playback Mode

• Default setting: DVD-Audio

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Parental Lock Bonus Group Auto Disc Menu Group Playback DVD Playback Mode SACD Playback CD Playback

DVD-Audio DVD-Video

Some DVD-Audio discs contain DVD-Video content in addition to the DVD-Audio. Set to DVD-Video to play a DVD-Audio disc as if it were a DVD-Video disc. Note that in this case only the DVD-Video part of the disc will play.

SACD Playback

• Default setting: 2ch Area

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

SACD discs can be divided up into several different areas — stereo audio (2ch Area), multi-channel audio (Multi-ch Area) and, for hybrid SACDs, standard CD audio (CD Area). Select which you want to listen to.

Parental Lock Bonus Group Auto Disc Menu Group Playback DVD Playback Mode SACD Playback CD Playback

2ch Area Multi-ch Area CD Area

• If you select an area that isn’t on the disc loaded, a different area of the disc will play. For example, if you choose standard CD audio but the disc loaded is not a hybrid SACD, the stereo SACD audio will play.

Page 53

The Initial Settings Menu08

CD Playback

• Default setting: PCM Playback

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

When set to PCM Playback, playback is optimized for standard audio CDs. You can also play DTS CDs, however you may notice some noise when a DTS CD starts playing. Also, speakers which were set to Small in the Speaker Installation screen are automatically set to Large. This is not a malfunction.

When set to DTS CD Playback, playback is optimized for DTS CDs. In this mode you cannot play standard audio CDs through the analog outputs. Change the setting back to PCM Playback to play standard CDs.

Parental Lock Bonus Group Auto Disc Menu Group Playback DVD Playback Mode SACD Playback CD Playback

PCM Playback DTS CD Playback

• Even if you set Audio Output Mode to

5.1 Channel, you’ll only get sound from

all speakers when playing a multichannel DVD-Audio disc, SACD, or Dolby Digital or DTS encoded DVD disc.

• When set to 5.1 Channel, only the front left/right channels are output from the

AUDIO OUT (L/R) jacks. Change to 2 Channel if you want to listen to

downmixed stereo audio (for example, because you are listening through the TV’s built-in speakers).

• When set to 5.1 Channel there is no digital output when playing DVD-Audio.

• If you set to 2 Channel, Dolby Digital, DTS and MPEG audio is mixed down to two channels so you still hear all the audio recorded on the disc.

• Some DVD-Audio discs don’t allow down-mixing of audio. These discs always output multi-channel audio regardless of the setting made here.

Speakers

Audio Output Mode

• Set in Setup Navigator (Default: 2 Channel)

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

If you connected this player to your amplifier using the 5.1 channel analog outputs (front, surround, center and subwoofer outs), set this to 5.1 Channel; if you connected only the stereo outs, set to 2 Channel.

Audio Output Mode Speaker Installation Speaker Distance

2 Channel

5.1 Channel

Speaker Installation

• Set in Setup Navigator (default: L/R: Large | C: Large | LS/RS: Large| SW: On )

You only need to make this setting if you connected this player to your amplifier using the 5.1 channel analog outputs.

This setting does not affect digital audio output.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Audio Output Mode Speaker Installation Speaker Distance

‰ 2 Channel

Page 54

The Initial Settings Menu

Use the Speaker Installation screen to tell the player what kinds of speakers you have connected.

1 Use the joystick to move the cursor up/down to select a speaker.

• The L and R, and RS and LS speakers are paired; you can’t set them differently.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Large

2 Move the cursor right to modify the selected speaker.

3 Use the joystick (up/down) to change the current setting.

• You can see the effect of your changes in the room graphic on the right of the screen.

• Except for the subwoofer, you can set speaker size to Large or Small. If the main speaker cone in the speaker is 12cm or more, set to Large, otherwise set to Small (or Off if you don’t have that speaker).

• If you set the front L and R speakers to Small, the center and surround speak-

ers are automatically set to Small and the subwoofer to On.

• The subwoofer can only be set to On or Off.

Speaker Distance

• Default setting: all speakers 10 ft.

You only need to make this setting if you connected this player to your amplifier using the 5.1 channel analog outputs.

To get the best surround sound from your system, you should set up the speaker distances from your listening position.

Initial Settings

10.0 ft.

‰ 2 Channel

Digital Audio Out Video Output Language Display Options Speakers

Audio Output Mode Speaker Installation Speaker Distance

1 Use the joystick to move the cursor up/down to select a speaker.

• The L and R speakers are paired; you can’t set them differently.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

L C R RS LS SW

2 Move the cursor right to change the speaker distance for the highlighted speaker.

4 Move the joystick left to go back to the speaker list if you want to modify another speaker, or press ENTER to exit the Speaker Installation screen.

Page 55

The Initial Settings Menu08

3 Use the joystick (up/down) to change the distance.

• When you change the distance settings of the front left (L) or front right (R) speakers, all the other speaker distances change relative to it.

• Front left/right (L/R) speakers can be set from 1 ft. to 30 ft. in 0.5 ft. increments.

• Center speaker (C) and subwoofer (SW) can be set from – 6.5 ft. to +6.5 ft. relative to the front left/right speakers

• Surround left/right (LS/RS) speakers can be set from –20 ft. to +6.5 ft. relative to the front left/right speakers.

4 Move the cursor left to go back to the speaker list if you want to modify another speaker, or press ENTER to exit the Speaker Distance screen.

• Speaker Distance settings do not affect SACD playback.

Channel Level

• Default setting: Fix

You only need to make this setting if you the 5.1 channel analog outputs.

joystick (up/down) to adjust the channel

This setting does not affect digital audio output.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Audio Output Mode Speaker Installation Speaker Distance Channel Level

Fix Variable

When set to Fix, the level of each of the 5.1 channel analog outputs is fixed. Choose Variable if you want to adjust the relative levels to balance the surround sound better for your listening room.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

Auto

0.0dB

You can set the individual channel levels between –6dB and +6dB using the test tone output as a guide to set the correct levels. Adjust the levels until the output level from all channels sounds the same from your usual listening position.

Automatic: Select Auto to start the test tone output.

Initial Settings

Digital Audio Out Video Output Language Display Options Speakers

onnected this player to your amplifier using

As the test tone plays through each speaker

Auto

0.0dB

in turn, it is highlighted on-screen. Use the output level of the current speaker. Note that

the test tone is not output from the subwoofer. Move the joystick left to exit the test tone sequence, or ENTER to save the settings and exit the channel level setting screen.

Page 56

Additional Information09

Taking care of your player and discs

Handling discs

When holding discs of any type, take care not to leave fingerprints, dirt or scratches on the disc surface. Hold the disc by its edge or by the center hole and edge.

Damaged or dirty discs can affect playback performance. Take care also not to scratch the label side of the disc. Although not as fragile as the recorded side, scratches can still result in a disc becoming unusable.

Should a disc become marked with fingerprints, dust, etc., clean using a soft, dry cloth, wiping the disc lightly from the center to the outside edge as shown in the diagram below.

Wipe lightly from the center of the disc using straight strokes.

Storing discs

Although CDs and DVD discs are more durable than vinyl records, you should still take care to handle and store discs correctly. When you're not using a disc, return it to its case and store upright. Avoid leaving discs in excessively cold, humid, or hot environments (including under direct sunlight).

Don't glue paper or put stickers onto the disc, or use a pencil, ball-point pen or other sharp-tipped writing instrument. These could all damage the disc.

For more detailed care information see the instructions that come with discs.

Do not load more than one disc into the player at a time.

Discs to avoid

Discs spin at high speed inside the player. If you can see that a disc is cracked, chipped, warped, or otherwise damaged, don't risk using it in your player—you could end up damaging the unit.

Don’t wipe the disc surface using circular strokes.

If necessary, use a cloth soaked in alcohol, or a commercially available CD/DVD cleaning kit to clean a disc more thoroughly. Never use benzine, thinner or other cleaning agents, including products designed for cleaning vinyl records.

This unit is designed for use with conventional, fully circular discs only. Use of shaped discs is not recommended for this product. Bel Canto disclaims all liability arising in connection with the use of shaped discs.

Page 57

Additional Information

Cleaning the pickup lens

The DVD player’s lens should not become dirty in normal use, but if for some reason it should malfunction due to dust or dirt, consult your nearest authorized service center. Although lens cleaners for CD players are commercially available, we do not recommend using them since some may damage the lens.

Problems with condensation

Condensation may form inside the player if it is brought into a warm room from outside, or if the temperature of the room rises quickly. Although the condensation won’t damage the player, it may temporarily impair its performance. For this reason you should leave it to adjust to the warmer temperature for about an hour before switching on and using.

Hints on installation

We want you to enjoy using this unit for years to come, so please bear in mind the following points when choosing a suitable location for it:

Do...

✓ Use in a well-ventilated room. ✓ Place on a solid, flat, level surface, such

as a table, shelf or stereo rack.

Don’t...

✗ Use in a place exposed to high tempera-

tures or humidity, including near radiators and other heat-generating appliances.

✗ Place on a window sill or other place

where the player will be exposed to direct sunlight.

✗ Use in an excessively dusty or damp

environment.

✗ Place directly on top of an amplifier, or

other component in your stereo system that becomes hot in use.

✗ Use near a television or monitor as you

may experience interference—especially if the television uses an indoor antenna.

✗ Use in a kitchen or other room where

the player may be exposed to smoke or steam.

✗ Use on a thick rug or carpet, or cover

with cloth—this may prevent proper cooling of the unit.

✗ Place on an unstable surface, or one

that is not large enough to support all four of the unit’s feet.

Moving the player

If you need to move the player, first press

STANDBY/ON on the front panel to turn

the player off. Wait for --OFF-- to disappear from the display, then turn of the rear switch

or unplug the powcord. Never lift or move the unit during playback—discs rotate at a high speed and may be damaged.

Power cord caution

Handle the power cord by the plug part. Do not pull out the plug by tugging the cord, and never touch the power cord when your hands are wet, as this could cause a short circuit or electric shock. Do not place the unit, a piece of furniture, or other object on the power cord or pinch the cord in any other way. Never make a knot in the cord or tie it with other cords. The power cords should be routed so that they are not likely to be stepped on. A damaged power cord can cause a fire or give you an electric shock. Check the power cord once in a while. If you find it damaged, ask your nearest Bel Canto authorized service center or your dealer for a replacement.

Page 58

Additional Information09

Screen sizes and disc formats

DVD-Video discs come in several different screen aspect ratios, ranging from TV programs, which are generally 4:3, to CinemaScope widescreen movies, with an aspect ratio of up to about 7:3.

Televisions, too, come in different aspect ratios; ‘standard’ 4:3 and widescreen 16:9.

Widescreen TV users

If you have a widescreen TV, the TV Screen setting of this player should be set to 16:9(Wide).

When you watch discs recorded in 4:3 format, you can use the TV controls to select how the picture is presented. Your TV may offer various zoom and stretch options; see the instructions that came with your TV for details.

Please note that some movie aspect ratios are wider than 16:9, so even though you have a widescreen TV, these discs will still play in a ‘letterbox’ style with black bars at the top and bottom of the screen.

Standard TV users

If you have a standard TV, the TV Screen setting of this player should be set to 4:3 (Letter Box) or 4:3 (Pan&Scan), depending on which you prefer.

Set to 4:3 (Letter Box), widescreen discs are shown with black bars top and bottom.

Set to 4:3(Pan&Scan), widescreen discs are shown with the left and right sides cropped. Although the picture looks larger, you don’t actually see the whole picture.

Please note that many widescreen discs override the player’s settings so that the disc is shown in letterbox format regardless of the setting.

• Using the 16:9 (Wide) setting with a standard 4:3 TV, or either of the 4:3 settings with a widescreen TV, will result in a distorted picture.

Resetting the player

Use this procedure to reset all the player’s settings to the factory default.

1 Switch the player into standby. 2 Using the front panel buttons, hold

down the 7 (stop) button and press

STANDBY/ON to switch the player back

on.

All the player’s settings are now reset, and you should see the ‘Let’s Get Started’ screen.

Page 59

Additional Information

About the audio output settings

The table below shows how the audio settings you make in the Initial Settings menu affect the output from the 5.1 channel analog outputs, and from the digital outputs with various types of disc.

Disc audio format Player setting

Dolby Digital

Dolby Digital karaoke

Linear PCM DTS

DVD

MPEG DVD-Audio

DVD-RW

Super Audio CD

CD DTS CD

Video CD / Super VCD

2 Ch

5.1 Ch 2 Ch / 5.1 Ch

2 Ch / 5.1 Ch 2 Ch

5.1 Ch 2 Ch / 5.1 Ch 2 Ch

5.1 Ch 2 Ch / 5.1 Ch

2 Ch

5.1 Ch 2 Ch / 5.1 Ch 2 Ch

5.1 Ch 2 Ch / 5.1 Ch

Front L/R analog outputs

2ch downmix Front L / R Left / Right Left / Right

Left / Right Front L / R 2ch downmix Left / Right 2ch downmix Front L / R Left / Right

2ch downmix Front L / R Left / Right 2ch downmix Front L / R Left / Right

Surround L/R

Center, LFE, outputs

–

Surround L/R, Center, LFE

–

– –

Surround L/R, Center, LFE

–

Surround L/R, Center, LFE

–

Surround L/R, Center, LFE

– –

Surround L/R, Center, LFE

–

Digital outputs

PCM convert*2Bitstream

2ch downmix Dolby Digital

Left / Right Left / Right

2ch downmix

Left / Right

2ch downmix*52ch downmix

––

Left / Right

––

Left / Right Left / Right

Dolby Digital

DTS

MPEG

Dolby Digital MPEG or PCM

DTSDTS

When Audio Output Mode is set to 2 Channel, the AUDIO OUT (5.1ch) FRONT L / R

jacks act as a pair of stereo audio outputs.

*2 Dolby Digital > PCM, MPEG > PCM or DTS > PCM setting.

Dolby Digital, MPEG or DTS setting.

Discs that prohibit downmixing will be output as 5.1 channel even if 2 Channel is selected

as the Audio Output Mode setting.

Discs that prohibit downmixing also mute the digital output

If the sound is mono, the Left and Right channels will be the same

Page 60

Additional Information09

Language code list

Language (Language code letter), Language code

Japanese (ja), 1001 English (en), 0514 French (fr), 0618 German (de), 0405 Italian (it), 0920 Spanish (es), 0519 Chinese (zh), 2608 Dutch (nl), 1412 Portuguese (pt), 1620 Swedish (sv), 1922 Russian (ru), 1821 Korean (ko), 1115 Greek (el), 0512 Afar (aa), 0101 Abkhazian (ab), 0102 Afrikaans (af), 0106 Amharic (am), 0113 Arabic (ar), 0118 Assamese (as), 0119 Aymara (ay), 0125 Azerbaijani (az), 0126 Bashkir (ba), 0201 Byelorussian (be), 0205 Bulgarian (bg), 0207 Bihari (bh), 0208 Bislama (bi), 0209 Bengali (bn), 0214 Tibetan (bo), 0215 Breton (br), 0218 Catalan (ca), 0301 Corsican (co), 0315 Czech (cs), 0319 Welsh (cy), 0325 Danish (da), 0401

Bhutani (dz), 0426 Esperanto (eo), 0515 Estonian (et), 0520 Basque (eu), 0521 Persian (fa), 0601 Finnish (fi), 0609 Fiji (fj), 0610 Faroese (fo), 0615 Frisian (fy), 0625 Irish (ga), 0701 Scots-Gaelic (gd), 0704 Galician (gl), 0712 Guarani (gn), 0714 Gujarati (gu), 0721 Hausa (ha), 0801 Hindi (hi), 0809 Croatian (hr), 0818 Hungarian (hu), 0821 Armenian (hy), 0825 Interlingua (ia), 0901 Interlingue (ie), 0905 Inupiak (ik), 0911 Indonesian (in), 0914 Icelandic (is), 0919 Hebrew (iw), 0923 Yiddish (ji), 1009 Javanese (jw), 1023 Georgian (ka), 1101 Kazakh (kk), 1111 Greenlandic (kl), 1112 Cambodian (km), 1113 Kannada (kn), 1114 Kashmiri (ks), 1119 Kurdish (ku), 1121

Kirghiz (ky), 1125 Latin (la), 1201 Lingala (ln), 1214 Laothian (lo), 1215 Lithuanian (lt), 1220 Latvian (lv), 1222 Malagasy (mg), 1307 Maori (mi), 1309 Macedonian (mk), 1311 Malayalam (ml), 1312 Mongolian (mn), 1314 Moldavian (mo), 1315 Marathi (mr), 1318 Malay (ms), 1319 Maltese (mt), 1320 Burmese (my), 1325 Nauru (na), 1401 Nepali (ne), 1405 Norwegian (no), 1415 Occitan (oc), 1503 Oromo (om), 1513 Oriya (or), 1518 Panjabi (pa), 1601 Polish (pl), 1612 Pashto, Pushto (ps), 1619 Quechua (qu), 1721 Rhaeto-Romance (rm), 1813 Kirundi (rn), 1814 Romanian (ro), 1815 Kinyarwanda (rw), 1823 Sanskrit (sa), 1901 Sindhi (sd), 1904 Sangho (sg), 1907 Serbo-Croatian (sh), 1908

Sinhalese (si), 1909 Slovak (sk), 1911 Slovenian (sl), 1912 Samoan (sm), 1913 Shona (sn), 1914 Somali (so), 1915 Albanian (sq), 1917 Serbian (sr), 1918 Siswati (ss), 1919 Sesotho (st), 1920 Sundanese (su), 1921 Swahili (sw), 1923 Tamil (ta), 2001 Telugu (te), 2005 Tajik (tg), 2007 Thai (th), 2008 Tigrinya (ti), 2009 Turkmen (tk), 2011 Tagalog (tl), 2012 Setswana (tn), 2014 Tonga (to), 2015 Turkish (tr), 2018 Tsonga (ts), 2019 Tatar (tt), 2020 Twi (tw), 2023 Ukrainian (uk), 2111 Urdu (ur), 2118 Uzbek (uz), 2126 Vietnamese (vi), 2209 Volapük (vo), 2215 Wolof (wo), 2315 Xhosa (xh), 2408 Yoruba (yo), 2515 Zulu (zu), 2621

Country code list

Country, Country code, Country code letter

Argentina, 0118, ar Australia, 0121, au Austria, 0120, at Belgium, 0205, be Brazil, 0218, br Canada, 0301, ca Chile, 0312, cl China, 0314, cn Denmark, 0411, dk Finland, 0609, fi France, 0618, fr Germany, 0405, de

Hong Kong, 0811, hk India, 0914, in Indonesia, 0904, id Italy, 0920, it Japan, 1016, jp Korea, Republic of, 1118, kr Malaysia, 1325, my Mexico, 1324, mx Netherlands, 1412, nl New Zealand, 1426, nz Norway, 1415, no Pakistan, 1611, pk

Philippines, 1608, ph Portugal, 1620, pt Russian Federation, 1821, ru Singapore, 1907, sg Spain, 0519, es Sweden, 1905, se Switzerland, 0308, ch Taiwan, 2023, tw Thailand, 2008, th United Kingdom, 0702, gb United States of America, 2119, us

Page 61

Additional Information

Selecting languages using the language code list

Some of the language options (such as ‘DVD Language’ in the Setup Navigator) allow you to set your prefered language from any of the 136 languages listed in the language code list on the previous page.

1 Select ‘Other Language’. 2 Use the joystick (left/right) to high-

light either the language name or code number.

3 Use the joystick (up/down) to change the language or code number.

• You can also use the number buttons if you’re entering a language code.

See the language code list on the previous page for a complete list of langauges and codes.

Glossary

Analog audio

An electrical signal that directly represents sound. Compare this to digital audio which can be an electrical signal, but is an indirect representation of sound. See also Digital audio.

Aspect ratio

The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the screen is almost square); widescreen models are 16:9 (the screen is almost twice as wide as it is high).

Bonus Group (DVD-Audio only)

An ‘extra’ group on some DVD-Audio discs that requires a key number to access. Also see Group.

Dolby Digital 1

Using a maximum of 5.1 channels of audio, this high quality surround system is used in many of the finer movie theaters around the world.

The on-screen display shows which channels are active, for example showing 3/2.1. The 3 being the two front channels and the center channel; the 2 being the surround channels, and the .1 being the LFE channel.

DTS

DTS stands for Digital Theater System. DTS is a surround system different from Dolby Digital that has become a popular surround sound format for movies.

Dynamic range

The difference between the quietest and loudest sounds possible in an audio signal (without distorting or getting lost in noise). Dolby Digital and DTS soundtracks are capable of a very wide dynamic range, delivering dramatic cinema-like effects.

File extension

A tag added to the end of a filename to indicate the type of file. For example, “.mp3” indicates an MP3 file.

Interlaced video

A method of displaying a picture in which odd-numbered lines are updated in one pass, then even-numbered lines updated in the next. See also Progressive scan video.

MP3

MP3 (MPEG1 audio layer 3) is a compressed audio file format. Files are recognized by their file extension “.mp3” or “.MP3”.

Browsable pictures (DVD-Audio only)

A feature of some DVD-Audio discs in which the user can browse still pictures recorded on the disc as the audio is played. See also Slideshow.

Page 62

Additional Information09

MPEG audio

An audio format used on Video CDs and some DVD discs. This unit can convert MPEG audio to PCM format for wider compatibility with digital recorders and AV amplifiers. See also PCM.

MPEG video

The video format used for Video CDs and DVDs. Video CD uses the older MPEG-1 standard, while DVD uses the newer and much better quality MPEG-2 standard.

Packed PCM (DVD-Audio only)

A lossless compression system that enables more PCM audio to be stored on a DVDAudio disc than would otherwise be possible.

PCM (Pulse Code Modulation)

The most common system of encoding digital audio, found on CDs and DAT. Excellent quality, but requires a lot of data compared to formats such as Dolby Digital and MPEG audio. For compatibility with digital audio recorders (CD, MD and DAT) and AV amplifiers with digital inputs, this unit can convert Dolby Digital, DTS and MPEG audio to PCM. See also Digital audio.

PBC (PlayBack Control) (Video CD only)

A system of navigating a Video CD through on-screen menus recorded onto the disc. Especially good for discs that you would normally not watch from beginning to end all at once—karaoke discs, for example.

Progressive scan video

Also called non-interlaced video, this method of displaying a picture updates all the lines in one pass, resulting in a more stable, flicker-free image than interlaced video (for a given scanning rate). See also Interlaced video.

Regions (DVD-Video only)

These associate discs and players with particular areas of the world. This unit will only play discs that have compatible region codes. You can find the region code of your unit by looking on the rear panel. Some discs are compatible with more than one region (or all regions).

S1 S-video output

This S-video signal format includes aspect ratio information (4:3 or 16:9) within the video signal. TVs which are compatible with S1 S-video automatically switch aspect ratio according to the signal.

S2 S-video output

S2 is an enhanced version of S-video which, in addition to aspect ratio information, contains letterbox / pan & scan information. Widescreen TVs which are compatible with S2 S-video automatically switch aspect ratio according to the signal.

Sampling frequency

The rate at which sound is measured to be turned into digital audio data. The higher the rate, the better the sound quality, but the more digital information is generated. Standard CD audio has a sampling frequency of 44.1kHz, which means 44,100 samples (measurements) per second. See also Digital audio.

Slidshow (DVD, Video CD/Super VCD)

A feature of some DVD discs in which still pictures recorded on the disc cycle automatically as the audio is played. See also Browsable Picture.

Super Audio CD (SACD)

Super Audio CD is a high quality audio disc format that can accomodate high sampling rate stereo and multi-channel audio, as well as conventional CD audio all on the same disc.

Page 63

Additional Information

Troubleshooting

Incorrect operation is often mistaken for trouble or malfunction. If you think that there is something wrong with this component, check the points below. Sometimes the trouble may lie in another component. Inspect the other components and electrical appliances being used. If the trouble cannot be rectified after checking the items below, ask your nearest Bel Canto authorized service center or your dealer to carry out repair work.

Problem

The disc won’t play or is automatically ejected after loading.

DVD-Audio playback stops. Picture playback stops and the

operation buttons cannot be used.

New settings made in the Setup screen menus while a disc is playing are ineffective.

Settings are canceled.

The remote control doesn't seem to work.

Cause / Remedy

• Make sure the disc is free from dirt and dust and is not damaged.

• Make sure the disc is loaded with the label side face-up and aligned properly in the disc tray guide.

• Incompatible region number: If the region number on a DVDVideo disc does not match the number on the player, the disc cannot be used.

• Condensation inside the player: Allow time for condensation to evaporate. Avoid using the player near an air-conditioning unit.

• Disc is loaded upside down: Reload the disc with the label side face up.

• The disc may have been illegally copied.

• Press 7, then start playback again (3).

• Switch the power off once, unplug from the wall socket, then

plug back in and switch on again using the front panel STANDBY/ON button.

• Some settings can be changed while a disc is playing, but are not effective until the disc is stopped then restarted: Press 7, then start playback again (3).

• When the power is cut due to power failure or by unplugging the power cord, settings will be canceled: Press STANDBY/ON on the front panel to turn the player off. Wait for -OFF- to disappear from the display, then unplug the power cord.

• The CONTROL IN jack on the rear panel is connected: Point the remote control at the connected component to control this player.

• The remote control is too far from the player, or the angle with the remote sensor is too wide: Use the remote within its operating range.

• The batteries are exhausted: Put in new ones.

Page 64

Additional Information09

Problem

No picture/No color.

Screen is stretched or aspect does not change.

Picture disturbance during playback or the picture is dark.

No audio, or audio is distorted.

Cause / Remedy

• Check that the VIDEO OFF indicator is not lit. If it is, press the VIDEO OFF button.

• Incorrect video connections: Check that connections are correct and that plugs are inserted fully. Also check the video cable for damage.

• TV/monitor or AV amplifier settings are incorrect: Check the instruction manual of the connected equipment.

• The video ouput is progressive but your TV/monitor is not compatible with progressive scan.

• The TV Screen setting in the Initial Settings menu is incorrect.

• If your TV/monitor is connected using an S-video cable, try

changing the S-Video Out setting.

• This player is compatible with Macro-Vision System copy guard. Some discs include a copy prevention signal, and when this type of disc is played back, stripes etc., may appear on some sections of the picture depending on the TV. This is not a malfunction.

• Due to the player’s copy protection circuits, connection of this device through a VCR or an AV selector may prevent recording or cause picture problems. This is not a malfunction.

• No audio is output during slow motion playback or when scanning discs other than audio CDs

• Some DVD discs do not output digital audio: Switch your amplifier to the player's analog outputs.

• Check that the disc is free from dust and dirt, and that it is not damaged.

• Check that all interconnects are firmly inserted.

• Check that the plugs and terminals are free of dirt, oxide, etc.

and clean if necessary. Also check the cable for damage.

• Make sure the player's output is not connected to the amplifier's phono (turntable) inputs.

• Check your amplifier/receiver’s settings (volume, input function, speaker settings, etc.).

Page 65

Additional Information

Problem

The analog audio is OK, but there appears to be no digital audio signal.

Noticeable difference in DVD and CD volume.

Cannot play multi-channel audio.

Cannot listen to high-sampling rate audio through the digital output.

Cannot output 192kHz or

176.4kHz digital audio.

Cause / Remedy

• Make sure that the Digital Out setting is set to On.

• Check that the Dolby Digital, DTS and MPEG out settings

are suitable for your amplifier/receiver—check the instruction manual that came with your amplifier/receiver.

• SACDs and some DVD-Audio discs do not output digital audio. Listen through the player’s analog audio outputs.

• This is due to differences in the audio format and is not a malfunction.

•Make sure that Audio Output Mode is set to 5.1 Channel.

•Check that the Dolby Digital, DTS and MPEG Out settings

are suitable for your amplifier/receiver—check the instruction manual that came with your amplifier/receiver.

• DVD-Audio and SACDs do not output multichannel digital audio. Listen through the player’s analog outputs.

• Check that the settings in the Speaker Installation screen are correct.

• Check the audio options available from the disc menu.

• Make sure that Linear PCM Out is set to Down Sample Off.

• As a copy-protection measure, some DVDs do not output 96kHz

audio. In this case, even if set to Down Sample Off, the player automatically outputs the audio at 48 kHz. This is not a malfunction.

• The player does not output digital audio at these sampling rates. The digital output is automatically downsampled.

Cannot output 96kHz or

88.2kHz digital audio.

No DTS audio output.

• Check that Linear PCM Out is set to Down Sample Off.

• Some discs are digital copy protected and do not output high

sampling rate digital audio. In this case the output is automatically downsampled.

• If this unit is connected to a non-DTS compatible amplifier or decoder using a digital audio cable, set DTS Out to DTS 3 PCM. If you do not do this, noise will be output when you play a DTS disc.

• If this unit is connected to a DTS-compatible amplifier or decoder using a digital audio cable, check the amplifier settings, and that the cable is properly connected.

Page 66

Additional Information09

Problem

Audio mix does not sound right or sounds incomplete (for example, inaudible ).

Disc containing the MP3 tracks won’t play.

Can’t hear effect of TruSurround.

Cause / Remedy

• Make sure that Audio Output Mode is set to 2 Channel if you've connected to the stereo inputs on your amplifier or TV.

• This player is compatible with multi-session discs, but only plays sessions that are closed.

• If the message UNPLAYABLE MP3 FORMAT is displayed when you try to play a disc/track, check the audio file formats. For more information.

• TruSurround does not work with CD, MP3, DVD-Audio, SACD or 96kHz linear PCM DVD.

• The TruSurround effect is only output through the AUDIO OUT (LF/RF) analog audio outputs.

• Make sure that Audio Output Mode is set to 2 Channel.

• The effectiveness of TruSurround varies with the disc.

• Static electricity or other external

influences may cause malfunctioning of this unit. In this case, unplug the power cord and then plug back in. This will usually reset the unit for proper operation. If this does not correct the problem, please consult your dealer.

Page 67

Additional Information

RS-232 9-Pin Sub-D ............. (Single Direction)

PL-1 Progressive Scan 480p Output

RGB/Y,CrPr,Cb,Pb ........ 0.7Vp-p (75 ohm)

Hor/Vert Sync ................ 5.0Vp-p (75 ohm)

Output Connector .................15 Pin Sub-D

Balanced Digital Out AES/EBU .................. XLR

Control in ....................................Minijack (3.5 ø)

Other terminals

Specifications

General

System .............................................. DVD Player

Power requirements ....... AC 80-260V, 50/60 Hz

Power consumption .................................... 43 W

Power consumption (standby)

Weight ....................................................... (23 lb )

Dimensions ..... 17 1/2(W) x 5 1/4 (H) x 15 (D) in

Operating temperature.............. +5°C to +35°C

Operating humidity ............................ 5% to 85%

Component Video output (Y, PB, PR)

Output level ............................. Y: 1.0 Vp-p (75 Ω)

Jacks ................................................... RCA jacks

S-Video output

Y (luminance) - Output level..........1 Vp-p (75 Ω)

C (color) - Output level........... 286 mVp-p (75 Ω)

Jack .................................................. S-Video jack

Video output

Output level .................................... 1 Vp-p (75 Ω)

Jack ....................................................... RCA jack

Audio output (1 stereo pair)

Output level ....................... During audio output

Number of channels ..........................................2

Jacks .....................................................RCA jack

Audio output (multi-channel / L, R, C, SW, LS, RS)

Output level ....................... During audio output

Number of channels .......................................... 6

Jacks ..................................................... RCA jack

......................... 10 W

(+36°F to +96°F)

(no condensation)

PB, PR: 0.7 Vp-p (75 Ω)

200 mVrms (1 kHz, –20 dB)

Digital audio characteristics

Frequency response

...........................4 Hz to 44 kHz(DVD fs: 96 kHz)

.............4 Hz to 88 kHz (DVD-Audio fs: 192 kHz)

S/N ratio ....................................................118 dB

Dynamic range .........................................108 dB

Total harmonic distortion .......................0.001 %

Wow and flutter.............. Limit of measurement

(0.001% W. PEAK) or lower

Digital output

Optical digital output ........... Optical digital jack

Coaxial digital output ..................BNC, RCA jack

Accessories

Power cord ......................................................... 1

Remote control ................................................... 1

Operating Instructions........................................1

Warranty card ....................................................1

AA dry cell batteries .......................................... 2

• The specifications and design of this product are subject to change without notice, due to improvement.

Page 68

bel canto –

PLayer-1(A)

RS-232 Protocol and Control Details - Rev. 2

Configuration - The following settings should be used for RS-232 transmission:

Baud Rate – RS-232 baud rate is configured using jumpers on the internal RS-232 interface located on the upper 480p board or on the separate RS232 board. Available settings are 2400, 4800, 9600 and *19200. *Factory default is 19200.

Baud Rate Jumper 1 Jumper 2

2400 Jumped Jumped 4800 Open Jumped 9600 Jumped Open

19200 Open Open

Data Bits – Eight (8) data bits. Stop Bits – One (1) stop bit. Parity – No parity checking. Flow Control – None.

RS-232 Interface –

Commands are to be sent to the unit via RS-232 using the following format:

Arguments 1 through 3 are in decimal format.

<Header> = <CAh><FEh> = HEX or <202><254> = DECIMAL

<Command ID> = <Byte> <Argument 1> = <Byte> <Argument 2> = <Byte> <Argument 3> = <Byte> <Byte> = 0 – 255

EXAMPLE OF DECIMAL COMMAND: To send the command “ Note: Command 1 and 2 are for IR Equivalents only. Direct Commands are # 3 and higher. Any invalid command received via RS232 is ignored and will not affect normal operation.

Status Byte –

Upon receiving the command “Poll Status” command [CAh FEh 09h 00h 00h 00h], a single status byte will be transmitted. The format for the status byte is:

<Status Byte> = <R><R><R><R><Device><Power Status> <R> = 0b : Reserved <Device> = 000b : Reserved = 001b : Reserved = 010b : Reserved = 011b : Reserved = 100-111 : Reserved

<Power Status> = 0b : Unit is in standby. = 1b : Unit is not in standby.

Play

”, send

<202><254><3><1><0><0>

Page 69

Command Details and Explanation –

This section will outline basic functionality and usage of each command set within the RS232 interface protocol. Note: Command IDs one(1) and two(2) are implemented to provide provision for future expandability. Command IDs three (3) through nine(9) offer more flexible control solutions and should be used for most applications.

Command ID #1: Send Single-Byte IR Code Equivalent Command Format:

<CAh><FEh><1><Data Byte><00h><00h> Functional Description: This command will write the given data (<Data Byte>) to the unit’s IR data bus. Usage: This command can be used to effectively implement any other command, which has a one-byte equivalent IR code. Equivalent IR codes for commands can be found on RS-232 command listing. Note that not all commands have equivalent IR codes. Example: To send the

<202><254><1><121><0><0> DECIMAL Equiv.

Command ID #2: Send Three-Byte IR Code Equivalent Command Format:

<CAh><FEh><2><Data Byte 1><Data Byte 2><Data Byte 3> Functional Description: This command will write the given data (<Data Byte 1><Data Byte 2><Data Byte 3>) to the unit’s IR data bus. Usage: This command can be used to effectively implement any other command, which has a three-byte equivalent IR code. Equivalent IR codes for commands can be found on RS-232 command listing. Note that not all commands have equivalent IR codes. Example: To send the

<202><254><2><153><245><39> DECIMAL Equiv.

Command ID #3: Direct Disk Commands Function: These commands have a function when the unit is loaded with any Theta CD, CDV or DVD. However, the effect of a given command may vary depending on currently loaded media and state of unit.

Command ID #4: CDV/DVD Commands Function: These commands have a function when the unit is loaded with video media. However, the effect of a given command may vary depending on currently loaded media and state of unit.

Command ID #5: DVD Commands Function: These commands have an effect only when the unit is loaded with a DVD. Their function may vary depending on the current state of the unit.

Command ID #6: LD Commands Function: These commands have an effect only when the unit is loaded with a LD. Their function may vary depending of the current state of the unit.

single byte

three byte

command “

Play

”, send

Repeat

Not Used

”, send

Page 70

Command ID #7: Miscellaneous Commands Function: These commands have the same function regardless of media type. However, their effect is dependent on current state of the unit.

Command ID #8: Menu Navigation Commands Usage: These commands can be used to navigate the unit’s menus. Note that available menus are highly dependent on media type and state of the unit.

Command ID #9: Poll Status Command Function: This command will request the return of the status byte from the unit. See RS-232 specifications for format and meaning of the status byte. Usage: This command can be used to retrieve basic information about the current status of the unit.

RS232-Interface Usage Details –

The RS-232 interface has a first-in-first-out (FIFO) buffer which will allow 15 full-length commands to be received in direct succession. Commands are executed in the order in which they are received with approximately a After a command is executed, it is removed from the buffer, making room to receive another command. If the buffer is full, any command received is ignored. For consistent results, no more than 15 commands should be sent in direct succession. If a longer string of commands is necessary, added before sending additional commands.

Example for sending a long string of commands: [Command 1] [Command 2] [Command 3] . . [Command 15 ] [Delay ½ sec] [Command 16 ] [Delay ½ sec] [Command 17 ] [Delay ½ sec]

At most, it will take approximately 10 seconds for the RS-232 interface to execute all of the commands stored in a full command buffer. Overloaded buffers can cause the unit to freeze with respect to RS-232 commands. If this occurs the unit must be rebooted. Data errors can occur in asynchronous data transmission. Parity checking is not supported in the interface and unexpected operation can occur due to data errors. However, invalid commands are ignored. For this reason, using the IR equivalent command should be avoided if possible because the RS-232 interface will perform no error checking on the data to be sent via the IR data bus.

½ second delay

a minimum of ½ second delay

between each command.

should be

Page 71

Command Command Description Argument 1 Argument 1 Description Argument 2 Argument 3 IR Code equivalent

COMMAND AND ALL ARGUMENTS (ie.1, 2 AND 3 ARE TO BE INPUT AS DECIMAL NUMBERS Byte 1 Byte 2 Byte 3

Ex: Play

Ex: Repeat

Ex: Play

3 Pause 0 0 F9h -- - 4 Stop 0 0 19h -- - 5 Next 0 0 39h -- - 6 Step forward 0 0 99h F5h EDh 7 Step reverse 0 0 99h F5h 1Dh 9 Numeric keypad 0 0 0 99h F5h 05h 10 Numeric keypad 1 0 0 99h F5h 85h 11 Numeric keypad 2 0 0 99h F5h 45h 12 Numeric keypad 3 0 0 99h F5h C5h 13 Numeric keypad 4 0 0 99h F5h 25h 14 Numeric keypad 5 0 0 99h F5h A5h 15 Numeric keypad 6 0 0 99h F5h 65h 16 Numeric keypad 7 0 0 99h F5h E5h 17 Numeric keypad 8 0 0 99h F5h 15h 18 Numeric keypad 9 0 0 99h F5h 95h 19 Program 0 0 99h F5h 37h 21 Repeat 0 0 99h F5h 27h 22 Repeat A-B 0 0 99h F5h 17h 23 Random 0 0 99h F5h 7Fh 24 Clear 0 0 99h F5h A7h 25 Display 0 0 99h F5h C7h 26 Reverse 0 0 99h F5h 57h 27 Forward 0 0 99h F5h 97h

Send single byte IR code equivalent. <CAh><FEh><1><79h><00h><00h> **Send three byte IR code equivalent. **Note: Arguments 2 and 3 are IR Code equivalents Byte 2 and Byte 3 to be sent.

Direct disk commands

<202><254><3><1><0><0> (Decimal

0 - 255 First Byte to be sent (1) 0 0 -- -- --

0 - 255 First byte to be sent (2) 0 - 255 0 - 255 -- -- --

1 Play 0 0 79h -- --

)

2 Previous 0 0 B9h -- --

Page 72

Command Command Description Argument 1 Argument 1 Description Argument 2 Argument 3 IR Code equivalent

COMMAND AND ALL ARGUMENTS (ie.1, 2 AND 3) ARE TO BE INPUT AS DECIMAL NUMBERS Byte 1 Byte 2 Byte 3

4 Commands pertaining to CDV/DVD only 0 Jog reverse 0 0 99h F5h 24h

From remote control only From remote control o

nly

1 Jog reverse medium (IR ONLY) 0 0 99h F5h A4h 2 Jog reverse fast (IR ONLY) 0 0 99h F5h 64h

3 Jog forward 0 0 99h F5h 04h

From remote control only From remote control onl

4 Jog forward medium (IR ONLY) 0 0 99h F5h 84h

5 Jog forward fast (IR ONLY) 0 0 99h F5h 44h 6 Shuttle reverse 0 0 99h F5h 3Eh 7 Shuttle forward 0 0 99h F5h 5Eh 8 Play Mode 0 0 99h F5h FEh

5 Commands pertaining to DVD only 1 Audio 0 0 99h F5h 7Dh 2 Subtitle 0 0 99h F5h 6Ch 3 Angle 0 0 99h F5h ADh 4 Top menu (title) 0 0 99h F5h 2Dh 5 Video adjust 0 0 99h F5h 0Ch 6 Surround 0 0 99h F5h 86h 7 DVD menu 0 0 99h F5h 62h

7 Miscellaneous commands 0 Dimmer 0 0 99h F5h 9Fh 1 Open/Close 0 0 99h F5h 6Dh 2 Toggle standby 0 0 99h F5h 3Dh 3 Put unit in standby 0 0 -- -- - 4 Take unit out of standby 0 0 -- -- --

8 Menu navigation commands 0 Up 0 0 99h 99h 4Fh 1 Down 0 0 99h F5h CFh 2 Right 0 0 99h F5h 26h 3 Left 0 0 99h F5h C6h 4 Return 0 0 99h F5h 2Fh 5 Enter 0 0 99h F5h F7h 6 Setup menu 0 0 99h F5h 0Dh

9 Poll status 0 Return status byte 0 0 -- -- --

Page 73

RS232 Hardware Connections

Bel Canto Design PL-1, PL-1A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Specifications Page 66

RS-232 Protocol and Control Details - Rev. 2

RS-232 Interface –

Command Details and Explanation –
