Beko KCHA300K20XP User manual
Safety first /1
Electrical requirements /2
Transportation instructions
Installation instructions /2
Getting to know your appliance /2
Suggested arrangement of food in
the appliance /2
Temperature control and adjustment /3
Before operating; Storing frozen food /3
Freezing fresh food /4
Making ice cubes; Defrosting /4
Replacing the interior light bulb /4
Cleaning and care /4
Repositioning the door; Do’s and don’ts /5
Energy Consumption /6
Information about operating noises /6
Troubleshooting /6
Wichtige Hinweise für Ihre Sicherheit /7
Elektrischer Anschluss; Transporthinweise /8
Aufstellen; Geräteübersicht /8
Allgemeine Einlagerungsempfehlungen /9
Temperaturkontrolle und – einstellung /9
Bevor der Inbetriebnahme /9
Lagern von tiefgefrorenen Lebensmitteln /9
Einfrieren von frischen Lebensmitteln /10
Abtauen des Gerätes /10
Wechseln des türanschlags /10
Wechsel der Glühlampe /10
Reinigung und Pflege /10
Was Sie tun sollten und was auf keinen
fall-einige Hinweise /11
Energieverbrauch /12
Hinweise zu Geräuschen und Vibrationen /12
Massnahmen bei Betriebstőrunger /12
WARNING!
In order to ensure a normal operation of your refrigerating appliance, which uses a completely environmentally friendly refrigerant the R600a
(flammable only under certain conditions) you must observe the following rules:
Do not hinder the free circulation of the air around the appliance.
Do not use mechanical devices in order to accelerate the defrosting, others than the ones recommended by the manufacturer.
Do not destroy the refrigerating circuit.
Do not use electric appliances inside the food keeping compartment, other than those that might have been recommended by the manufacturer.
WARNUNG!
Ihr Gerät verwendet ein umweltverträgliches Kältemittel, R600a (nur unter bestimmten Umständen brennbar). Um einen einwandfreien Betrieb Ihres
Gerätes sicherzustellen, beachten Sie bitte folgende Vorschriften:
Die Luftzirkulation um das Gerät darf nicht behindert sein.
Verwenden Sie außer der vom Hersteller empfohlenen, keine mechanischen Hilfsmittel, um den Abtauprozess zu beschleunigen.
Der Kältemittelkreislauf darf nicht beschädigt werden.
Verwenden Sie im Lebensmittelaufbewahrungsbereich Ihres Gerätes keine elektrischen Geräte, es sei denn, sie sind vom Hersteller empfohlen.
WAARSCHUWING!
U moet de volgende regels in acht nemen om de normale werking van uw koelkast, die het volledig milieuvriendelijke koelmiddel R600a gebruikt, te
verzekeren:
Hinder de vrije luchtcirculatie rond het toestel niet.
Gebruik geen andere mechanische toestellen om het ontdooien te versnellen dan de toestellen die door de fabrikant worden aangeraden.
Vernietig het koelcircuit niet.
Gebruik geen andere elektrische toestellen in de bewaarlade voor etenswaren dan de toestellen die eventueel door de fabrikant worden
aangeraden.
AVERTISSEMENT!
Afin de s’assurer du fonctionnement normal de votre réfrigérateur, contenant le réfrigérant R600a qui contribue à la protection de l’environnement
(inflammable dans certaines conditions seulement), il convient de respecter les règles suivantes:
Ne pas empêcher la circulation d’air autour de l'appareil.
Ne pas utiliser d'outils mécaniques ou autres dispositifs pour accélérer le processus de décongélation autres que ceux qui sont recommandés
par le fabricant.
Ne pas abîmer le circuit réfrigérant.
Ne pas utiliser d’appareils électriques à l'intérieur des compartiments de conservation de denrées, à moins qu’ils soient conformes au type
d'appareils recommandés par le fabricant.
EN Index
DE Inhalt
Veiligheid eerst /13
Elektriciteitsvereisten; Transportinstructies /14
Installatie-instructies; Uw toestel leren
kennen /14
Voorstel voor de schikking van de etenswaren
in het toestel /14
Temperatuurmeting en -regeling /15
Alvorens de inwerkstelling /15
Diepvriesproducten bewaren /16
Verse etenswaren invriezen /16
IJsblokjes maken; Ontdooien /16
Het binnenlichtje vervangen; Schoonmaak en
onderhoud /16
De deur verplaatsen; Wel en niet doen /17
Energieverbruik; Informatie over de
functiegeluiden /18
Problemen oplossen /18
La sécurité d'abord /19
Conditions électriques /20
Instructions de transport /20
Instructions d’installation /20
Apprendre à connaître votre appareil /20
Suggestion d’agencement des denrées dans
l’appareil /21
Commande de température et réglage /21
Avant l’utilisation; Conservation des denrées
surgelées /21
Congélation des produits frais /22
Fabrication de glaçons; Dégivrage /22
Remplacement de l'ampoule intérieure /22
Nettoyage et entretien /22
Repositionnement de la porte /23
A faire / A ne pas faire /23
Remarques sur les bruits de fonctionnement /24
Diagnostic /24
NL Index
FR Sommaire
1
Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If
the subject parts are not included in the product you have purchased, then it is valid for other models.
Abbildungen und Angaben in dieser Anleitung sind schematisch und können etwas von Ihrem Produkt abweichen.
Falls Teile nicht zum Lieferumfang des erworbenen Gerätes zählen, gelten sie für andere Modelle.
De afbeeldingen in deze gebruiksaanwijzing zijn schematisch en hoeven niet exact met uw product overeen te
komen. Wanneer onderdelen niet tot het product behoren dat u hebt gekocht, gelden deze voor andere modellen.
Les illustrations présentées dans cette notice d’utilisation sont schématiques et peuvent ne pas correspondre
exactement à votre produit. Si des pièces présentées ne sont pas comprises dans le produit que vous avez acheté,
elles sont valables pour d’autres modèles.
2 3 4 9 5
7 6 8
10
11
Congratulations on your choice of a Beko Quality
Appliance, designed to give you many years of service.
Safety first!
Do not connect your appliance to the electricity supply
until all packing and transit protectors have been
removed.
• Leave to stand for at least 4 hours before switching
on, to allow compressor oil to settle, if transported
horizontally.
• If you are discarding an old appliance with a lock or
latch fitted to the door, ensure that it is left in a safe
condition to prevent the entrapment of children.
• This appliance must only be used for its intended
purpose.
• Do not dispose of the appliance on a fire. Your
appliance contains non CFC substances in the
insulation which are flammable. We suggest you
contact your local authority for information on disposal
and available facilities.
• We do not recommend use of this appliance in an
unheated, cold room. (e.g. garage, conservatory,
annex, shed, out-house etc.)
To obtain the best possible performance and trouble
free operation from your appliance it is very important to
read these instructions carefully. Failure to observe
these instructions may invalidate your right to free
service during the guarantee period.
Please keep these instructions in a safe place for easy
reference.
Original Spare parts will be provided for 10 years,
following the product purchasing date.
EN Instruction for use
1
This appliance is not intended for use by person with reduced physical, sensory or mental
capabilities or lack of experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
The symbol on the product or on packaging indicates that this product may not be treated as
household waste. Instead it shall be handed over to the applicable collection point for the recycling of
electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human health, which could
otherwise be otherwise be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city office, you household waste
disposal service or the shop where you purchased the product.
2
EN Instruction for use
Electrical requirements
Before inserting the plug into the wall socket
make sure that the voltage and the frequency
shown in the rating plate inside the appliance
corresponds to your electricity supply.
We recommend that this appliance is connected
to the mains supply via a suitably switched and
fused socket in a readily accessible position.
Warning! This appliance must be earthed.
Repairs to electrical equipment should only be
performed by a qualified technician. Incorrect
repairs carried out by an unqualified person are
carry risks that may have critical consequences
for the user of the appliance.
ATTENTION!
This appliance operates with R600a which is an
environmental friendly but flammable gas. During
the transportation and fixing of the product, care
must be taken not to damage the cooling
system. If the cooling system is damaged and
there is a gas leakage from the system, keep the
product away from open flame sources and
ventilate the room for a while.
WARNING - Do not use mechanical devices or
other means to accelerate the defrosting
process, others than those recommended by the
manufacturer.
WARNING - Do not damage the refrigerant circuit.
WARNING - Do not use electrical appliances
inside the food storage compartments of the
appliance, unless they are of the type
recommended by the manufacturer.
WARNING - If the supply cord is damaged, it
must be replaced by the manufacturer, its
service agent or similarly qualified persons in
order to avoid a hazard.
Transportation instructions
1. The appliance should be transported only in
an upright position. The packing as supplied
must be intact during transportation.
2. If during the transport the appliance, has been
positioned horizontally, it must not be operated
for at least 4 hours, to allow the system to settle.
3. Failure to comply with the above instructions
could result in damage to the appliance, for
which the manufacturer will not be held liable.
4. The appliance must be protected against rain,
moisture and other atmospheric influences.
Important!
• Care must be taken while cleaning/carrying the
appliance not to touch the bottom of the condenser
metal wires at the back of the appliance, as this
could cause injury to fingers and hands.
• Do not attempt to sit or stand on top of your
appliance as it is not designed for such use. You
could injure yourself or damage the appliance.
• Make sure that the mains cable is not caught
under the appliance during and after moving, as
this could damage the cable.
• Do not allow children to play with the appliance
or tamper with the controls.
Installation instructions
1. Do not keep your appliance in a room where
the temperature is likely to fall below -15 degrees
C (5 degrees F) at night and/or especially in
winter.
2. Do not place the appliance near cookers or
radiators or in direct sunlight, as this will cause
extra strain on the appliance's functions. If
installed next to a source of heat or freezer,
maintain the following minimum side clearances:
From Cookers 30 mm
From Radiators 300 mm
From Freezers 25 mm
3. Make sure that sufficient room is provided
around the appliance to ensure free air
circulation (Item 2).
• Put the back airing lid to the back of your
refrigerator to set the distance between the
refrigerator and the wall (Item 3).
4. The appliance should be positioned on a
smooth surface. The two front feet can be
adjusted as required. To ensure that your
appliance is standing upright adjust the two front
feet by turning clockwise or anti-clockwise, until
firm contact is secured with the floor. Correct
adjustment of feet prevents excessive vibration
and noise (Item 4).
5. Refer to "Cleaning and Care" section to
prepare your appliance for use.
Getting to know your appliance (Item 1)
1 - Setting knob and interior light
2 - Adjustable Cabinet shelves
3 - Wine rack
4 - Water collector
5 - Crisper cover
6 - Crisper
7 - Compartment for quickly freezing
8 - Ice tray support & ice tray
9 - Compartments for frozen foods keeping
10 - Adjustable foot
11 - Shelf for jars
12 - Shelf for bottles
13 - Freezer fan
The timer is a device for automatic defrost. After
a certain time him activate the heaters who
produce the defrost of your refrigerator.
Suggested arrangement of food in the
appliance
Guidelines for obtaining optimum storage and
hygiene:
EN Instruction for use
1. The fridge compartment is for the short-term
storage of fresh food and drinks.
2. The freezer compartment is rated
and suitable for the freezing and storage of prefrozen food. The recommendation for
storage as stated on the food packaging should
be observed at all times.
3. Dairy products should be stored in the
special compartment provided in the door liner.
4. Cooked dishes should be stored in airtight
containers.
5. Fresh wrapped produce can be kept on the
shelf. Fresh fruit and vegetables should be
cleaned and stored in the crispers.
6. Bottles can be kept in the door section.
7. To store raw meat, wrap in polythene bags
and place on the lowest shelf. Do not allow to
come into contact with cooked food, to avoid
contamination. For safety, only store raw meat
for two to three days.
8. For maximum efficiency, the removable
shelves should not be covered with paper or other
materials to allow free circulation of cool air.
9. Do not keep vegetable oil on door shelves.
Keep the food packed, wrapped or covered.
Allow hot food and beverages to cool before
refrigerating. Leftover canned food should not be
stored in the can.
10. Fizzy drinks should not be frozen and
products such as flavoured water ices should not
be consumed too cold.
11. Some fruit and vegetables suffer damage if
kept at temperatures near 0°C. Therefore wrap
pineapples, melons, cucumbers, tomatoes and
similar produce in polythene bags.
12. High-proof alcohol must be stored upright in
tightly closed containers. Never store products
that contain an inflammable propellant gas (e.g.
cream dispensers, spray cans, etc.) or explosive
substances. These are an explosion hazard.
Temperature control and adjustment
Operating temperatures are controlled by the
setting knob (Item 5) located on the ceiling of
fridge compartment. Settings may be made from
MIN, 1 ... 4, MAX, MAX being the coldest
position. When the appliance is switched on for
the first time, the setting knob should be adjusted
so that after 24 hours, the average fridge
temperature is no higher than +5°C (+41°F). We
recommend you set the knob half way between
the MIN and MAX setting and monitor to obtain
the desired temperature i.e. towards Max you will
obtain a colder fridge temperature and vice
versa. Some sections of the fridge may be cooler
or warmer (such as the salad crisper and the top
part of the cabinet) which is quite normal.
The normal storage temperature of the freezer
should be -18°C (0°F). Lower temperatures may
be obtained by adjusting setting knob towards Max
position. We recommend that you check the
temperature with an accurate thermometer to
ensure that the storage compartments are kept to
the desired temperature. Remember you must
take your reading very quickly since the
thermometer temperature will rise very rapidly after
you remove it from the freezer. Please remember
each time the door is opened cold air escapes and
the internal temperature rises. Therefore never
leave the door open and ensure it is closed
immediately after food is put in or removed. In case
of a temporary ice build up in the fridge
compartment, reduce the setting to Min, monitoring
at the same time, that the fridge temperature is
maximum +5 degrees C [41 degrees F]. Once the
ice build up disappears and the appliance starts
auto defrosting again as normal, then you may
increase the setting, if required.
Before operating
Final Check
Before you start using the appliance check that:
1. The feet have been adjusted for perfect levelling.
2. The interior is dry and air can circulate freely at
the rear.
3. The interior is clean as recommended under
"Cleaning and care.”
4. The plug has been inserted into the wall
socket and the electricity is switched on. When
the door is open the interior light will come on.
And note that:
5. You will hear a noise as the compressor starts
up. The liquid and gases sealed within the
refrigeration system may also make some
(noise), whether the compressor is running or
not. This is quite normal.
6. Slight undulation of the top of the cabinet is
quite normal due to the manufacturing process
used; it is not a defect.
7. We recommend setting the knob midway and
monitor the temperature to ensure the appliance
maintains desired storage temperatures (See
section Temperature Control and Adjustment).
8. Do not load the appliance immediately it is
switched on. Wait until the correct storage
temperature has been reached. We recommend
checking the temperature with an accurate
thermometer (see; Temperature Control and
Adjustment).
Storing frozen food
Your freezer is suitable for the long-term storage
of commercially frozen foods and also can be
used to freeze and store fresh food.
3
EN Instruction for use
If there is a power failure, do not open the door.
Frozen food should not be affected if the failure
lasts for less than 16 hrs. If the failure is longer,
then the food should be checked and either
eaten immediately or cooked and then re-frozen.
Freezing fresh food
Please observe the following instructions to
obtain the best results. Do not freeze too large a
quantity at any one time. The quality of the food
is best preserved when it is frozen right through
to the core as quickly as possible. Do not exceed
the freezing capacity of your appliance in 24 h.
Placing warm food into the freezer compartment
causes the refrigeration machine to operate
continuously until the food is frozen solid. This
can temporarily lead to excessive cooling of the
refrigeration compartment. When freezing fresh
food, keep the setting knob at medium position.
Small quantities of food up to 1/2 kg. (1 lb.) can
be frozen without adjusting the temperature
control knob. Take special care not to mix
already frozen food and fresh food.
Making ice cubes
Fill the ice - cube tray 3/4 full with water and
place it in the freezer. Loosen frozen trays with a
spoon handle or a similar implement; never use
sharp-edged objects such as knives or forks.
Defrosting
A) Fridge compartment
The fridge compartment defrosts automatically.
The defrost water runs to the drain tube via a
collection container at the back of the appliance
(Item 6). During defrosting, water droplets may
form at the back of the fridge compartment where
a concealed evaporator is located. Some droplets
may remain on the liner and refreeze when
defrosting is completed. Do not use pointed or
sharp-edged objects such as knives or forks to
remove the droplets which have refrozen. If, at
any time, the defrost water does not drain from
the collection channel, check that no food
particles have blocked the drain tube. The drain
tube can be cleared with a pipe-cleaner or similar
implement. Check that the tube is permanently
placed with its end in the collecting tray on the
compressor to prevent the water spilling on the
electric installation or on the floor (Item 7).
B) Freezer compartment
The NO FROST type defrost is completely
automatic. No intervention from your side is
required. The water is collected on the
compressor tray. Due the heat of the
compressor the water is evaporated
Never use hairdryers, electrical heaters or other
such electrical appliances for defrosting.
Sponge out the defrost water collected in the
bottom of the freezer compartment. After
defrosting, dry the interior thoroughly (Item 8 &
9). Insert the plug into the wall socket and switch
on the electricity supply.
Warnings!
The fan inside the freezer compartment circulates
cold air. Never insert any object through the
guard. Do not allow children to play with the
freezer fan. Never store products that contain
inflammable propellant gas (e.g. dispensers,
spray cans etc.) or explosive substances. Don’t
cover the shelves with any protective materials,
which may obstruct air circulation. Do not allow
children to play with the appliance or tamper with
the controls. Do not obstruct the freezer fan
guard to ensure that you obtain the best possible
performance from your appliance (Item 10).
Warning!
Your appliance is fitted with a circulating fan
which is essential for the performance of the
freezer. Please ensure the fan is not blocked
(stopped) or impaired by food or packaging.
Blocking (stopping) or impairing the fan can
result in an increase of the internal freezer
temperature (Thawing).
Replacing the interior light bulb
To change the Bulb/LED used for illumination of
your refrigerator, call your Authorised Service.
The lamp(s) used in this appliance is not suitable
for household room illumination. The intended
purpose of this lamp is to assist the user to place
foodstuffs in the refrigerator/freezer in a safe and
comfortable way. The lamps used in this
appliance have to withstand extreme physical
conditions such as temperatures below -20°C.
Cleaning and care
1. We recommend that you switch off the
appliance at the socket outlet and pull out the
mains plug before cleaning.
2. Never use any sharp instruments or abrasive
substances, soap, household cleaner, detergent
or wax polish for cleaning.
3. Use lukewarm water to clean the cabinet of
the appliance and wipe it dry.
4. Use a damp cloth wrung out in a solution of
one teaspoon of bicarbonate of soda to one pint
of water to clean the interior and wipe it dry.
5. Make sure that no water enters the
temperature control box.
6. If the appliance is not going to be used for a
long period of time, switch it off, remove all food,
clean it and leave the door ajar.
7. We recommend that you polish the metal
parts of the product (i.e. door exterior, cabinet
sides) with a silicone wax (car polish) to protect
the high quality paint finish.
4
Loading...
