Beko DNE 68720 DT, DNE 68720 DE, DN 162720 D, DNE 68720 H, DNE 68720 T User manual [EN,FR,RU,AR,FA,IT,NL,DE,HR,BG,SL,EL,HU,ES,UK,BO]

...

0 (0)

Refrigerator

Réfrigérateur

Холодильник

یخچال

Frigorifero

Koelkast Kühlschrank

Hladnjak

Хладилник

Hladilnik

Ψυγείο

Hűtőszekrény

Frigorífico

Холодильники

Frižider

DNE 68720 DT DNE 68720 DE DN 162720 D DNE 68720 H DNE 68720 T DNE 68720 G DNE 68720 WG DNE 62020 DPX DNE 62220 DPX DN162720DX

Please read this user manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service.

Therefore, read this entire user manual carefully before using the product and keep it as a reference. If you handover the product to someone else, give the user manual as well.

The user manual will help you use the product in a fast and safe way.

•Read the manual before installing and operating the product.

•Make sure you read the safety instructions.

•Keep the manual in an easily accessible place as you may need it later.

•Read the other documents given with the product.

Remember that this user manual is also applicable for several other models. Differences between models will be identified in the manual.

Explanation of symbols

Throughout this user manual the following symbols are used:

CImportant information or useful tips.

AWarning against dangerous conditions for life and property. BWarning against electric voltage.

CONTENTS

1 Your Refrigerator	3
2 Important Safety
Warnings	4
Intended use......................................	4
General safety...................................	4
For products with a water dispenser;. 6
Child safety........................................	6
Compliance with the AEEE Regulation
and Disposing of the Waste Product.	. 6
Package information..........................	6
HCA warning......................................	7
Recommendations for the fresh food
compartment.....................................	7
Things to be done for energy saving...	8
3 Installation	9
Points to be paid attention to when the
relocation of the refrigerator................	9
Before you start the refrigerator,......... 9
Electrical connection..........................	9
Disposing of the packaging..............	10
Disposing of your old refrigerator......	10
Placing and Installation.....................	10
Adjusting the legs.............................	11

5 Using your refrigerator 13
Indicator Panel.................................	13
Door Open Warning.........................	15
Humidity control in the crisper..........	16
Egg section......................................	16
Sliding Body Shelves........................	16
Blue light..........................................	17
Chiller compartment.........................	17
Description and cleaning of odor
filter:.................................................	17
Icematic and ice storage container	.. 18
Water dispenser ..............................	19
Water tray .......................................	20
6 Maintenance and
cleaning	21
Protection of plastic surfaces ..........	21
7 Troubleshooting	22

4 Preparation

2 EN

1 Your Refrigerator
	20
21	*19				1
21	*19
	*18
					4
					*2
					*3
	17				6
22	14				6
22	*16
	15
	14				5
	*13				*
	*13				6
	12				6
					6
	7	*9	1110 *9	8	7

1- Freezer compartment door shelves

2- Water dispenser tank filler cap

3- Water dispenser tank

4- Egg holder

5- Bottle holder

6- Fridge compartment door shelves

7- Adjustable front legs

8- Crisper or chiller compartment adjustment slider

9- Blue light

10- Ventilation lid

* OPTIONAL

11- Crispers

12- Crisper cover

13- Chiller compartment

14- Fridge compartment glass shelves

15- Fridge compartment interior light

16- Wine rack

17- Odor filter (Carbon)

18- Icematic or Ice cupe tray

19- Fresh Freeze compartment

20- Freezer compartment interior light

21- Freezer compartment

22- Fridge compartment

C Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.

3 EN

2 Important Safety Warnings

Please review the following information. Failure to observe this information may cause injuries or material damage. Otherwise, all warranty and reliability commitments will become invalid.

The service life of your product is 10 years. During this period, original spare parts will be available to operate the product properly.

Intended use

This product is intended to be used

•indoors and in closed areas such as homes;

•in closed working environments such as stores and offices;

•in closed accommodation areas such as farm houses, hotels, pensions.

•It should not be used outdoors.

General safety

•When you want to dispose/scrap the product, we recommend you to consult the authorized service in

order to learn the required information and authorized bodies.

•Consult your authorized service for all your questions and problems related to the refrigerator. Do not intervene or let someone intervene to the refrigerator without notifying the authorised services.

•For products with a freezer compartment; Do not eat cone ice cream and ice cubes immediately after you take them out of the freezer compartment! (This may cause frostbite in your mouth.)

•For products with a freezer compartment; Do not put bottled and canned liquid beverages in the freezer compartment. Otherwise, these may burst.

•Do not touch frozen food by hand; they may stick to your hand.

•Unplug your refrigerator before cleaning or defrosting.

•Vapor and vaporized cleaning materials should never be used in cleaning and defrosting processes of your refrigerator. In such cases, the vapor may get in contact with the electrical parts and cause short circuit or electric shock.

•Never use the parts on your refrigerator such as the door as a means of support or step.

•Do not use electrical devices inside the refrigerator.

•Do not damage the parts, where the refrigerant is circulating, with

drilling or cutting tools. The refrigerant that might blow out when the gas channels of the evaporator, pipe extensions or surface coatings are punctured causes skin irritations and eye injuries.

•Do not cover or block the ventilation holes on your refrigerator with any material.

•Electrical devices must be repaired by only authorised persons. Repairs performed by incompetent persons create a risk for the user.

•In case of any failure or during a maintenance or repair work,

disconnect your refrigerator’s mains supply by either turning off the relevant fuse or unplugging your appliance.

4 EN

•Do not pull by the cable when pulling off the plug.

•Place the beverage with higher proofs tightly closed and vertically.

•Never store spray cans containing flammable and explosive substances in the refrigerator.

•Do not use mechanical devices or other means to accelerate the

defrosting process, other than those recommended by the manufacturer.

•This product is not intended to be used by persons with physical, sensory or mental disorders or unlearned or inexperienced people (including children) unless they are attended by a person who will be responsible for their safety or who will instruct them accordingly for use of the product

•Do not operate a damaged refrigerator. Consult with the service agent if you have any concerns.

•Electrical safety of your refrigerator shall be guaranteed only if the earth system in your house complies with standards.

•Exposing the product to rain, snow, sun and wind is dangerous with respect to electrical safety.

•Contact authorized service when there is a power cable damage to avoid danger.

•Never plug the refrigerator into the wall outlet during installation. Otherwise, risk of death or serious injury may arise.

•This refrigerator is intended for only storing food items. It must not be used for any other purpose.

•Label of technical specifications is located on the left wall inside the refrigerator.

•Never connect your refrigerator to electricity-saving systems; they may damage the refrigerator.

•If there is a blue light on the refrigerator, do not look at the blue light with optical tools.

•For manually controlled refrigerators, wait for at least 5 minutes to start the refrigerator after power failure.

•This operation manual should be handed in to the new owner of the product when it is given to others.

•Avoid causing damage on power cable when transporting the refrigerator. Bending cable may cause fire. Never place heavy objects on power cable.

•Do not touch the plug with wet hands when plugging the product.

•Do not plug the refrigerator if the wall outlet is loose.

•Water should not be sprayed on inner or outer parts of the product for safety purposes.

•Do not spray substances containing inflammable gases such as propane gas near the refrigerator to avoid fire and explosion risk.

•Never place containers filled with water on top of the refrigerator; in the event of spillages, this may cause electric shock or fire.

5 EN

•Do not overload the refrigerator with food. If overloaded, the food items may fall down and hurt you and damage refrigerator when you open the door.

•Never place objects on top of the refrigerator; otherwise, these objects may fall down when you open or close the refrigerator's door.

•As they require a precise temperature, vaccines, heat-sensitive medicine and scientific materials and etc. should not be kept in the refrigerator.

•If not to be used for a long time, refrigerator should be unplugged. A possible problem in power cable may cause fire.

•The plug's tip should be cleaned regularly with a dry cloth; otherwise, it may cause fire.

•Refrigerator may move if adjustable legs are not properly secured on the floor. Properly securing adjustable legs on the floor can prevent the refrigerator to move.

•When carrying the refrigerator, do not hold it from door handle. Otherwise, it may be snapped.

•When you have to place your product next to another refrigerator or freezer, the distance between devices should be at least 8cm. Otherwise, adjacent side walls may be humidified.

For products with a water dispenser;

Pressure of water mains should be minimum 1 bar. Pressure of water mains should be maximum 8 bars.

• Use only potable water.

Child safety

•If the door has a lock, the key should be kept away from reach of children.

•Children must be supervised to prevent them from tampering with the product.

Compliance with the AEEE Regulation and Disposing of the Waste Product

This product does not contain harmful and forbidden materials described

in the "Regulation on the Control of the Waste Electrical and Electronic Equipment" issued by the T.R. Ministry of Environment and City Planning. Complies with the AEEE Regulation.

This product has been

manufactured with high quality parts and materials

which can be reused and are suitable for recycling.

Therefore, do not dispose the product with normal

domestic waste at the end of its service life. Take it to a collection point for the recycling of electrical and electronic equipment. Please consult your local authorities to learn the nearest collection point. Help protect the environment and natural resources by recycling used products. For children's safety, cut the power cable and break the locking mechanism of the door, if any, so that it will be nonfunctional before disposing of the product.

Package information

Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities.

6 EN

Do not forget...

Any recycled substance is an indispensable matter for nature and our national asset wealth.

If you want to contribute to the re-evaluation of the packaging materials, you can consult to your environmentalist organizations or the municipalities where you are located.

HCA warning

If your product's cooling system contains R600a:

This gas is flammable. Therefore, pay attention to not damaging the cooling system and piping during usage and transportation. In the event of damage, keep your product away from potential fire sources that can cause the product catch a fire and ventilate the room in which the unit is placed.

Ignore this warning if your product's cooling system contains R134a.

Type of gas used in the product is stated in the type label which is on the left wall inside the refrigerator.

Never throw the product in fire for disposal.

Recommendations for the fresh food compartment

*optional

•Do not allow the food to touch the temperature sensor in fresh food compartment. To allow the fresh food compartment keep its ideal storage temperature, sensor must not be hindered by food.

•Do not place hot foods in the product.

	MILK
	juice	temperature
	etc.	temperature
	etc.	sensor
		sensor

food	temperature
	sensor

7 EN

Things to be done for energy saving

•Do not leave the doors of your refrigerator open for a long time.

•Do not put hot food or drinks in your refrigerator.

•Do not overload your refrigerator so that the air circulation inside of it is not prevented.

•Do not install your refrigerator under direct sunlight or near heat emitting appliances such as ovens, dishwashers or radiators. Keep your refrigerator at least 30cm away from heat emitting sources and at least 5cm from electrical ovens.

•Pay attention to keep your food in closed containers.

•For products with a freezer compartment; You can store maximum amount of food items in the freezer when you remove the shelf or drawer of the freezer. Energy consumption value stated for your refrigerator has been determined

by removing freezer shelf or drawer and under maximum load. There is no harm to use a shelf or drawer

according to the shapes and size of food to be frozen.

•Thawing frozen food in fridge compartment will both provide energy saving and preserve the food quality.

8 EN

3 Installation

B In case the information which are given in the user manual are not taken into account, manufacturer will

not assume any liability for this.

Points to be paid attention to when the relocation of the refrigerator

1.Your refrigerator should be unplugged.Before transportation of your refrigerator, it should be emptied and cleaned.

2.Before it is re-packaged, shelves, accessories, crisper, etc. inside your refrigerator should be fixed with adhesive tape and secured against impacts. Package should be bound with a thick tape or sound ropes and the transportation rules on the package should be strictly observed.

3.Original packaging and foam materials should be kept for future transportations or moving.

Before you start the refrigerator,

Check the following before you start to use your refrigerator:

1.Attach 2 plastic wedges as illustrated below. Plastic wedges are intended to keep the distance which will ensure the air circulation between your refrigerator and the wall. (The picture is drawn up as a representation and it is not identical with your product.)

2.Clean the interior of the refrigerator as recommended in the “Maintenance and cleaning” section.

3.Connect the plug of the refrigerator to the wall socket. When the fridge door is opened, fridge internal lamp will turn on.

4.When the compressor starts to operate, a sound will be heard. The liquid and gases sealed within the refrigeration system may also give rise to noise, even if the compressor is not running and this is quite normal.

5.Front edges of the refrigerator may feel warm. This is normal. These areas are designed to be warm to avoid condensation.

Electrical connection

Connect your product to a grounded socket which is being protected by a fuse with the appropriate capacity.

Important:

The connection must be in compliance with national regulations.

9 EN

•The power plug must be easily accessible after installation.

•Electrical safety of your refrigerator shall be guaranteed only if the earth system in your house complies with standards.

•The voltage stated on the label located at left inner side of your product should be equal to your network voltage.

•Extension cables and multi plugs must not be used for connection.

B A damaged power cable must be replaced by a qualified electrician.

B Product must not be operated before it is repaired! There is the risk of

electric shock!

Disposing of the packaging

The packing materials may be dangerous for children. Keep the packing materials out of the reach of children or dispose of them by classifying them in accordance with the waste instructions stated by your local authorities. Do not throw away with regular house waste, throw away on packaging pick up spots designated by the local authorities.

The packing of your refrigerator is produced from recyclable materials.

Disposing of your old refrigerator

Dispose of your old refrigerator without giving any harm to the environment.

•You may consult your authorized dealer or waste collection center of your municipality about the disposal of your refrigerator.

Before disposing of your refrigerator, cut out the electric plug and, if there are any locks on the door, make them inoperable in order to protect children against any danger.

Placing and Installation

A If the entrance door of the room where the refrigerator will be installed is not wide enough for the refrigerator to pass through, then call the authorized service to have them remove the doors of your refrigerator and pass it sideways through the door.

1.Install your refrigerator to a place that allows ease of use.

2.Keep your refrigerator away from heat sources, humid places and direct sunlight.

3.There must be appropriate air ventilation around your refrigerator in order to achieve an efficient operation. If the refrigerator is to be placed in a recess in the wall, there must be at least 5 cm distance with the ceiling and at least 5 cm with the wall. Do not place your product on the materials such as rug or carpet.

4.Place your refrigerator on an even floor surface to prevent jolts.

10 EN

Dimensions of your refrigerator

80 cm

84 cm

Adjusting the legs

If your refrigerator is unbalanced;

You can balance your refrigerator by turning its front legs as illustrated in the figure. The corner where the leg exists is lowered when you turn in the direction of black arrow and raised when you turn in the opposite

direction. Taking help from someone to slightly lift the refrigerator will facilitate this process.

Usage area measures

Following figure shows the required place to allow

you use your refrigerator most efficiently.

143.5 cm

134 cm

154 cm

142 cm

11 EN

4 Preparation

•Your refrigerator should be installed at least 30 cm away from heat sources such as hobs, ovens, central heater and stoves and at least 5 cm away from electrical ovens and should not be located under direct sunlight.

•The ambient temperature of the room where you install your refrigerator should at least be 10°C. Operating your refrigerator under cooler conditions is not recommended with regard to its efficiency.

•Please make sure that the interior of your refrigerator is cleaned thoroughly.

•If two refrigerators are to be installed side by side, there should be at least 2 cm distance between them.

•When you operate your refrigerator for the first time, please observe the following instructions during the initial six hours.

•The door should not be opened frequently.

•It must be operated empty without any food in it.

•Do not unplug your refrigerator. If a power failure occurs out of your control, please see the warnings in

the “Recommended solutions for the problems” section.

•Original packaging and foam materials should be kept for future transportations or moving.

12 EN

5 Using your refrigerator

Indicator Panel

This touch-control indicator panel allows you to set the temperature without opening the door of your refrigerator. Just touch the relevant button with your finger to set the temperature.

*16

1	6
2	5
3	4
8	15

1.	Fast Freeze Button	8. Eco Extra Function Indicator
2.	Freezer Compartment Temperature	9. Freezer Compartment Temperature
	Setting Button	Indicator
3.	Eko-Ekstra Button	10.Quick Cool Function Indicator
4.	Vacation Button	11. Vacation Function Indicator
5.	Fridge Compartment Temperature	12.Quick Freeze Function Indicator
	Setting Button	13.Economy Mode Indicator
6.	Quick Cool Button	14.Error Status Indicator
7.	Fridge Compartment Temperature	15.Key Lock Indicator
	Indicator	16.Ionizer Indicator Light
* OPTIONAL		17.Humidity Indicator

13 EN

1- Fast Freeze Button

Press this button briefly to activate the Fast Freeze function. Press this

button again to deactivate the selected function.

2- Freezer Compartment Temperature Setting Button

Press this button to set the temperature of the freezer compartment to -18, -20, -22, -24, -18... respectively. Press this button to set the desired temperature for the Freezer Compartment.

3- Eko-Ekstra Button

Press this button briefly to activate the Eco Extra function.

4- Vacation Button

Press this button briefly to activate the Vacation function. To stop ice formation, press the same button for 3 seconds.

5- Fridge Compartment Temperature Setting Button

Press this button to set the temperature of the fridge compartment to 8, 6, 4, 2, 8... respectively.

Press this button to set the desired temperature for the Fridge Compartment.

6. Quick CoolButton

Press this button briefly to activate the Quick Cool function. Press this

button again to deactivate the selected function.

7- Fridge Compartment

Temperature Indicator

Indicates the temperature set for Fridge Compartment.

8- Eco Extra Function Indicator

Indicates that the Eco Extra function is active. If this function is active, your refrigerator will automatically detect the least usage periods and energyefficient cooling will be performed during those times. Economy indicator will be active while energy-efficient cooling is performed.

9- Freezer Compartment

Temperature Indicator

It indicates the temperature set for Freezer Compartment.

10Quick Cool Function Indicator

Indicates that the Quick Cool function is active. Use this function when

you place fresh food into the fridge compartment or when you need to cool your food quickly. When this function is active, your refrigerator will run for 2 hours without stopping.

Press the relevant button again to deactivate this function.

11Vacation Function Indicator

Indicates that the vacation function is active. If this function is active,

“- -” appears on the indicator of the fridge compartment and no cooling is performed in the fridge compartment. Other compartments will be cooled in accordance with the temperature set for them.

Press the relevant button again to deactivate this function.

14 EN

12Quick Freeze Function Indicator

Indicates that the Quick Freezer function is active. Use this function when you place fresh food into the freezer compartment or when you need ice. When this function is active, your refrigerator will run for 6 hours without stopping.

Press the relevant button again to deactivate this function.

13Economy Mode Indicator

Indicates that the refrigerator is running in energy-efficient mode. This indicator will be active if the Freezer Compartment temperature is set to -18 or the energy efficient cooling is being performed due to Eco-Extra function.

14Error Status Indicator

If your refrigerator does not cool adequately or if there is a sensor failure, this indicator will be activated. When this indicator is active, Freezer Compartment Temperature indicator will display “E” and Fridge Compartment Temperature Indicator

will display numbers such as “1,2,3…”. These numbers on the indicator provides information about the error to the service personnel.

15Key Lock Indicator

Use this function if you do not want your refrigerator temperature setting changed. Press Eco Extra Button and Freezer Compartment Temperature Setting Button simultaneously for

a long time (3 sec) to activate this feature.

Press the relevant buttons again to deactivate this function.

16Ionizer Indicator Light

Indicator light lights up continuously. This light indicates that your refrigerator is protected against the bacteria.

17Humidity Indicator

Indicator light lights up continuously. This light indicates that the food kept in the refrigerator is preserved for a

long time under ideal humidity.

Door Open Warning

(This feature is optional)

An audio warning signal will be given when the door of your product is left open for at least 1 minute. This

warning will be muted when the door is closed or any of the display buttons (if any) are pressed.

15 EN

Humidity control in the crisper

Humidity level can be adjusted by sliding the humidity adjustment slider to the right or left.

•If you want to maintain humidity in this compartment, set the humidity adjustment slider to the closed position. (Right)

•If you want to eliminate humidity in this compartment, set the humidity adjustment slider to the open position. (Left)

Egg section

You can place the egg section in any of the door shelves. If it is going to be placed in the body, the lower shelves are recommended due them being cooler.

Never store eggs in the freezer compartment.

Avoid direct contact between eggs and other foods.

Sliding Body Shelves

Sliding body shelves can be pulled by slightly lifting up from the front and moved back and forth. They come to

a stop point when pulled towards front to allow you reach the foods placed at the back of the shelf; when it is pulled after slightly lifted upwards at the second stop point, the body shelf will be released.

The shelf should be hold tightly from the bottom as well in order to prevent it from tipping over. The body shelf is placed on the rails at the sides of the refrigerator body by bringing it to one lower or one upper level.

The body shelf should be pushed backwards to seat it completely.

1 2

16 EN

Beko DNE 68720 DT, DNE 68720 DE, DN 162720 D, DNE 68720 H, DNE 68720 T User manual

Blue light

*optional

Foodstuff stored in the crispers that are enlightened with a blue light continue their photosynthesis by

means of the wavelength effect of blue light and thus, preserve their freshness and increase their vitamin content.

Description and cleaning of odor filter:

Odor filter prevents unpleasant odor build-up in your refrigerator.

Pull the cover into which the odor filter is installed downwards from the front section and remove as illustrated. Leave the filter under sunlight for one day. Filter will be cleaned during this time. Install the filter back to its place.

Odor filter must be cleaned once in a year.

Chiller compartment

(OPTIONAL)

Chiller compartments enable the foods to be frozen become ready for freezing. You can also use these

compartments to store your food at a temperature a few degrees below the fridge compartment.

You can increase the inner volume of your refrigerator by removing any of the chiller compartments. To do this, pull the compartment towards yourself; the compartment will lean against the stopper and stop. This compartment will be released when you lift it about 1 cm and pull it towards yourself.

17 EN

Icematic and ice storage container

(OPTIONAL) Using the Icematic

Fill the Icematic with water and place it into its seat. Your ice will be ready approximately in two hours. Do not remove the Icematic from its seating to take ice.

Turn the knobs on it clockwise by 90 degrees.

Ice cubes in the cells will fall down into the ice storage container below.

You may take out the ice storage container and serve the ice cubes.

If you wish, you may keep the ice cubes in the ice storage container.

Ice storage container

Ice storage container is only intended for accumulating the ice cubes. Do not put water in it. Otherwise, it will break.

Making ice (OPTIONAL)

Fill the ice container with water and place it into its seat. Your ice will be ready approximately in two hours.

You can easily remove your ice by slightly twisting the ice container.

18 EN

Water dispenser

(OPTIONAL)

Water dispenser is a very useful feature to obtain chilled water without opening the door of your fridge. Since you do not have to open the door of your fridge frequently, you also save on electricitiy.

Using the water dispenser

Push in the lever of the water dispenser with your glass. By releasing the lever, you cut off the dispensing.

When operating the water dispenser, maximum flow is achieved by fully depressing the lever. Please note, how much water flows from the dispenser depends on how far you depress the lever. As the level of water in your

cup / glass rises, gently reduce the amount of pressure on the lever to avoid overflow. If you depress the lever a small amount, then water will trickle; this is perfectly normal and is not a fault.

Filling in the water tank of water dispenser

Open the cap of the water tank as illustrated in the figure. Fill in with pure and clean drinking water. Close the cap.

Caution!

•Do not fill water tank with any liquid other than drinking water; beverages such as fruit juice, carbonated fizzy soda drinks, alcoholic drinks are not suitable for use with water dispenser. If such liquids are used, the water dispenser will malfunction and may be damaged beyond repair. The guarantee does not cover such uses. Some chemical ingredients and additives in such drinks / beverages may also attack and damage water tank material.

•Only use clean pure drinking water.

•Capacity of water dispenser tank is 3 litres [6.4 pints], do not overfill.

•Push the water dispenser lever with

a rigid cup. If you are using a plastic disposable cup, then push the lever with your fingers from behind the cup.

Cleaning the water tank

Remove the water tank,and detach the top cover mechanism from the water tank. Clean the water tank with warm clean water, reinstall the top cover.

When installing the water tank, make sure that hooks it fits securely into the hangers on the door. Make sure that parts removed during cleaning (if any) are installed correctly into their original locations. Otherwise, water may leak.

Important:

Water tank and components of water dispenser are not dishwasher-proof.

Water tray

(OPTIONAL)

Water that drips while using the water dispenser accumulates in the drip tray. Remove the drip tray by pulling it towards yourself and empty it from time to time.

Remove the plastic drainer part as shown in the diagram by pressing down on the edge.

20 EN

6 Maintenance and cleaning

A Never use gasoline, benzene or similar substances for cleaning purposes.

B We recommend that you unplug the appliance before cleaning.

B Never use any sharp abrasive instrument, soap, household cleaner, detergent and wax polish for cleaning.

CUse lukewarm water to clean the cabinet of your refrigerator and wipe it dry.

CUse a damp cloth wrung out in a solution of one teaspoon of

bicarbonate of soda to one pint of water to clean the interior and wipe it dry.

B Make sure that no water enters the lamp housing and other electrical items.

B If your refrigerator is not going to be used for a long period of time, unplug the power cable, remove all food, clean it and leave the door ajar.

CCheck door seals regularly to ensure they are clean and free from food particles.

A To remove door racks, remove all the contents and then simply push the door rack upwards from the base.

ANever use cleaning agents or water that contain chlorine to clean the outer surfaces and chromium coated parts of the product. Chlorine causes

corrosion on such metal surfaces.

Protection of plastic surfaces

CDo not put the liquid oils or oil-cooked meals in your refrigerator in unsealed containers as they damage the plastic surfaces of your refrigerator. In case of spilling or smearing oil on the plastic surfaces, clean and rinse the relevant part of the surface at once with warm water.

21 EN

7 Troubleshooting

Please review this list before calling the service. It will save your time and money. This list includes frequent complaints that are not arising from defective workmanship or material usage. Some of the features described here may not exist in your product.

The refrigerator does not operate.

•The plug is not inserted into the socket correctly. >>>Insert the plug into the socket securely.

•The fuse of the socket which your refrigerator is connected to or the main fuse have blown out. >>>Check the fuse.

Condensation on the side wall of the fridge compartment (MULTIZONE, COOL CONTROL and FLEXI ZONE).

•Ambient is very cold. >>>Do not install the refrigerator in places where the temperature falls below 10 °C.

•Door has been opened frequently. >>>Do not open and close the door of refrigerator frequently.

•Ambient is very humid. >>>Do not install your refrigerator into highly humid places.

•Food containing liquid is stored in open containers. >>>Do not store food with liquid content in open containers.

•Door of the refrigerator is left ajar. >>>Close the door of the refrigerator.

•Thermostat is set to a very cold level. >>>Set the thermostat to a suitable level.

•Compressor is not running

•Protective thermic of the compressor will blow out during sudden power failures or plug-out plug-ins as the refrigerant pressure in the cooling system of the refrigerator has not been balanced yet. The refrigerator will start running

approximately after 6 minutes. Please call the service if the refrigerator does not startup at the end of this period.

•The fridge is in defrost cycle. >>>This is normal for a full-automatically defrosting refrigerator. Defrosting cycle occurs periodically.

•The refrigerator is not plugged into the socket. >>>Make sure that the plug is fit into the socket.

•Temperature settings are not made correctly. >>>Select the suitable temperature value.

•There is a power outage. >>>Refrigerator returns to normal operation when the power restores.

The operation noise increases when the refrigerator is running.

•The operating performance of the refrigerator may change due to the changes in the ambient temperature. It is normal and not a fault.

The refrigerator is running frequently or for a long time.

22 EN

•New product may be wider than the previous one. Larger refrigerators operate for a longer period of time.

•The room temperature may be high. >>>It is normal that the product operates for longer periods in hot ambient.

•The refrigerator might be plugged in recently or might be loaded with food.

>>>When the refrigerator is plugged in or loaded with food recently, it will take longer for it to attain the set temperature. This is normal.

•Large amounts of hot food might be put in the refrigerator recently. >>>Do not put hot food into the refrigerator.

•Doors might be opened frequently or left ajar for a long time. >>>The warm air that has entered into the refrigerator causes the refrigerator to run for longer periods. Do not open the doors frequently.

•Freezer or fridge compartment door might be left ajar. >>>Check if the doors are closed completely.

•The refrigerator is adjusted to a very low temperature. >>>Adjust the refrigerator temperature to a warmer degree and wait until the temperature is achieved.

•Door seal of the fridge or freezer may be soiled, worn out, broken or not properly seated. >>>Clean or replace the seal. Damaged/broken seal causes the refrigerator to run for a longer period of time in order to maintain the current temperature.

Freezer temperature is very low while the fridge temperature is sufficient.

•The freezer temperature is adjusted to a very low value. >>>Adjust the freezer temperature to a warmer degree and check.

Fridge temperature is very low while the freezer temperature is sufficient.

•The fridge temperature is adjusted to a very low value. >>>Adjust the fridge temperature to a warmer degree and check.

Food kept in the fridge compartment drawers is frozen.

•The fridge temperature is adjusted to a very high value. >>>Adjust the fridge temperature to a lower value and check.

Temperature in the fridge or freezer is very high.

•The fridge temperature is adjusted to a very high value. >>>Fridge compartment temperature setting has an effect on the temperature of the freezer. Change the temperatures of the fridge or freezer and wait until the relevant compartments attain a sufficient temperature.

•Doors are opened frequently or left ajar for a long time. >>>Do not open the doors frequently.

•Door is ajar. >>>Close the door completely.

•The refrigerator is plugged in or loaded with food recently. >>>This is normal. When the refrigerator is plugged in or loaded with food recently, it will take longer for it to attain the set temperature.

•Large amounts of hot food might be put in the refrigerator recently. >>>Do not put hot food into the refrigerator.

23 EN

•Vibrations or noise.

•The floor is not level or stable. >>> If the refrigerator rocks when moved slowly, balance it by adjusting its feet. Also make sure that the floor is strong enough to carry the refrigerator, and level.

•The items put onto the refrigerator may cause noise. >>>Remove the items on top of the refrigerator.

There are noises coming from the refrigerator like liquid flowing, spraying, etc.

•Liquid and gas flows occur in accordance with the operating principles of your refrigerator. It is normal and not a fault.

Whistle comes from the refrigerator.

•Fans are used in order to cool the refrigerator. It is normal and not a fault. Condensation on the inner walls of refrigerator.

•Hot and humid weather increases icing and condensation. It is normal and not a fault.

•Doors are opened frequently or left ajar for a long time. >>>Do not open the doors frequently. Close them if they are open.

•Door is ajar. >>>Close the door completely.

Humidity occurs on the outside of the refrigerator or between the doors.

•There might be humidity in the air; this is quite normal in humid weather. When the humidity is less, condensation will disappear.

Bad odour inside the refrigerator.

•No regular cleaning is performed. >>>Clean the inside of the refrigerator regularly with a sponge, lukewarm water or carbonate dissolved in water.

•Some containers or package materials may cause the smell. >>>Use a different container or different brand packaging material.

•Food is put into the refrigerator in uncovered containers. >>>Keep the food in closed containers. Microorganisms spreading out from uncovered containers can cause unpleasant odours.

•Remove the foods that have expired best before dates and spoiled from the refrigerator.

The door is not closing.

•Food packages are preventing the door from closing. >>>Replace the packages that are obstructing the door.

•The refrigerator is not completely even on the floor. >>>Adjust the feet to balance the refrigerator.

•The floor is not level or strong. >>>Make sure that the floor is level and capable to carry the refrigerator.

Crispers are stuck.

• The food is touching the ceiling of the drawer. >>>Rearrange food in the drawer.

24 EN

Veuillez d’abord lire la notice d’utilisation !

Chère cliente, cher client,

Nous espérons que votre produit, qui a été fabriqué dans des usines modernes et vérifié au terme des procédures de contrôle de qualité les plus méticuleuses, vous aidera efficacement.

Pour cette raison, nous vous conseillons de lire attentivement tout le manuel d’utilisation de votre produit avant de vous en servir, et de le conserver ensuite pour une utilisation ultérieure.

Le présent manuel

•Vous aidera à utiliser votre produit avec rapidité et sécurité.

•Lisez le manuel avant d’installer et de faire fonctionner votre produit.

•Respectez les instructions, notamment celles relatives à la sécurité.

•Conservez ce manuel dans un endroit facilement accessible car vous pouvez en avoir besoin ultérieurement.

•En plus, lisez également les autres documents fournis avec votre produit.

Veuillez noter que ce manuel peut également être valide pour d’autres modèles.

Symboles et descriptions

Vous retrouverez les symboles suivants dans le présent manuel :

C A B

Informations importantes ou astuces.

Avertissement relatif aux conditions dangereuses pour la vie et la propriété.

Avertissement relatif à la tension électrique.

TABLE DES MATIÈRES

1 Votre réfrigérateur	3
2 Précautions de sécurité
importantes	4
Utilisation préconisée........................................	4
Sécurité générale.............................................	4
Pour les appareils dotés d'une fontaine à eau ;. 6
Sécurité enfants................................................	6
Conformité avec la règlementation DEEE et mise
au rebut des déchets........................................	6
Informations relatives à l'emballage...................	6
Avertissement HCA...........................................	6
Mesures d’économie d’énergie.........................	7
Recommandations relatives au compartiment
des produits frais...............................................	8
3 Installation	9
Points à prendre en compte lorsque vous
transportez à nouveau votre produit..................	9
Avant de faire fonctionner votre réfrigérateur......	9
Mise au rebut de l’emballage...........................	10
Mise au rebut de votre ancien réfrigérateur......	10
Disposition et Installation.................................	10
Réglage des pieds..........................................	11

5 Utilisation du
réfrigérateur	13
Bandeau indicateur.........................................	13
Avertissement - Porte ouverte.........................	15
Contrôle de l’humidité dans le bac à légumes. 16
Casier à œufs..................................................	16
Etagères coulissantes......................................	16
Compartiment Zone fraîche.............................	17
Éclairage bleu .................................................	17
Description et nettoyage du filtre à odeurs:......	17
Distributeur et récipient de conservation de
glaçons ..........................................................	18
Fontaine Frigorifique .......................................	19
Bac à eau ......................................................	20
6 Entretien et nettoyage	21
Protection des surfaces en plastique. .............	21
7 Solutions recommandées
aux problèmes	22

4 Préparation

2 FR

1	Votre réfrigérateur
		20
	21	*19	1
	21	*19
		*18
			4
			*2
			*3
		17	6
	22	14	6
	22	*16
		15
		14	5
		*13	*
		*13	6
		12	6
			6

	7	*9		8

			1110 *9		7
1-	Etagères de la porte du compartiment réfrigérant					12Couvercle du bac à légumes
2-	Bouchon de remplissage de la fontaine à eau					13-	Compartiment Zone fraîche
3-	Réservoir de la fontaine frigorifique					14Clayettes en verre du compartiment de
4-	Support à œufs						réfrigération
5-	Range-bouteilles					15Éclairage intérieur du compartiment réfrigérateur
6-	Balconnets de la porte du compartiment de					16-	Clayette support bouteille
	réfrigération					17Filtre à odeurs (carbone)
7-	Pieds avant réglables					18Machine à glaçons ou bac à glaçons
8-	Curseur de réglage bac à légumes ou					19-	Compartiment Ultra Congélation
	compartiment fraîcheur					20Éclairage intérieur du compartiment congélateur
9-	Éclairage bleu					21-	Compartiment congélateur
10-	Plinthe					22-	Compartiment réfrigérateur
11-	Bac à légumes

* EN OPTION

C Les illustrations présentées dans cette notice d’utilisation sont schématiques et peuvent ne pas correspondre exactement à votre produit. Si des pièces présentées ne sont pas comprises dans le produit que vous avez acheté, elles sont valables pour d’autres modèles.

3 FR

2 Précautions de sécurité importantes

Veuillez examiner les informations suivantes : Le non respect de ces consignes peut entraîner des blessures ou dommages matériels. Sinon, tout engagement lié à la garantie et à la fiabilité du produit devient invalide.

Votre appareil a une durée de vie de 10 ans. Pendant cette période, les pièces de rechange d'origine seront disponibles afin que l'appareil fonctionne comme il se doit.

Utilisation préconisée

Ce produit est prévu pour une utilisation

•en intérieur et dans des zones fermées telles que les maisons ;

•dans les environnements de travail fermées, tels que les magasins et les bureaux ;

•dans les lieux d'hébergement fermés, tels que les fermes, hôtels, pensions.

•Il ne doit pas être utilisé en extérieur.

Sécurité générale

•Avant de vous débarrasser de votre appareil, veuillez consulter les autorités locales ou votre revendeur pour connaître le mode opératoire et les organismes de collecte agréés.

•Consultez le service après-vente agréé concernant toutes questions ou problèmes relatifs au réfrigérateur. N’intervenez pas ou ne laissez personne intervenir sur le réfrigérateur sans le communiquer au service après-vente agréé.

•Pour les produits équipés d'un compartiment congélateur : ne mangez pas de cônes de crème glacée ou des glaçons immédiatement après les avoir sortis du compartiment de congélation ! (Cela pourrait provoquer des engelures dans votre bouche).

•Pour les produits équipés d'un compartiment congélateur : ne placez pas de boissons en bouteille ou en cannette dans le compartiment de congélation. Cela peut entraîner leur

éclatement.

•Ne touchez pas des produits congelés avec les mains, ils pourraient se coller à celles-ci.

•Débranchez votre réfrigérateur avant de le nettoyer ou de le dégivrer.

•La vapeur et des matériaux de nettoyage pulvérisés ne doivent jamais être utilisés pour les processus de nettoyage ou de dégivrage de votre réfrigérateur. La vapeur pourrait pénétrer dans les pièces électriques et provoquer des courts-circuits ou des électrocutions.

•Ne jamais utiliser les pièces de votre réfrigérateur telles que la porte, comme un support ou une marche.

•N’utilisez pas d’appareils électriques à l’intérieur du réfrigérateur.

•N’endommagez pas les pièces où circule le liquide réfrigérant avec des outils de forage ou coupants. Le liquide réfrigérant qui pourrait s’échapper si les canalisations de gaz de l’évaporateur, les rallonges de tuyau ou les revêtements de surface étaient percés, peut irriter la peau et provoquer des blessures aux yeux.

•Ne pas couvrir ou obstruer les orifices de ventilation du réfrigérateur.

•Les appareils électriques peuvent être réparés seulement par des personnes autorisées.

Les réparations réalisées par des personnes ne présentant pas les compétences requises peuvent présenter un risque pour l’utilisateur.

•En cas de dysfonctionnement ou lors d'opérations d’entretien ou de réparation, débranchez l’alimentation électrique du réfrigérateur soit en désactivant le fusible correspondant, soit en débranchant l’appareil.

•Ne tirez pas sur le câble lorsque vous débranchez la prise.

•Placez les boissons alcoolisées verticalement, dans des récipients convenablement fermés.

•Ne conservez jamais des aérosols contenant des substances inflammables et explosives dans le réfrigérateur.

•N’utilisez pas d'outils mécaniques ou autres dispositifs pour accélérer le processus de décongélation autres que ceux qui sont recommandés par le fabricant.

•Ce produit n'est pas conçu pour être utilisé par des personnes (enfants compris) souffrant de déficience physique, sensorielle, mentale, ou inexpérimentées, à moins d’avoir obtenu une autorisation auprès des personnes responsables de leur sécurité.

•Ne faites pas fonctionner un réfrigérateur endommagé. Consultez le service agréé en cas de problème.

•La sécurité électrique du réfrigérateur n’est assurée que si le système de mise à la terre de votre domicile est conforme aux normes en vigueur.

•L’exposition du produit à la pluie, la neige, au soleil ou au vent présente des risques concernant la sécurité électrique.

•Contactez le service agréé quand un câble d'alimentation est endommagé pour éviter tout danger.

•Ne branchez jamais le réfrigérateur à la prise murale au cours de l’installation. Vous vous exposeriez à un risque de mort ou à de blessures graves.

•Ce réfrigérateur est conçu seulement pour conserver des aliments. Par conséquent, il ne doit pas être utilisé à d'autres fins.

•L'étiquette avec les caractéristiques techniques est située sur le mur gauche à l'intérieur du réfrigérateur.

•Ne branchez jamais votre réfrigérateur à des systèmes d'économie d'énergie, cela peut l'endommager.

•S'il y a une lumière bleue sur le réfrigérateur, ne la regardez pas avec des outils optiques.

•Pour les réfrigérateurs contrôlés manuellement, attendez au moins 5 minutes pour allumer le réfrigérateur après une coupure de courant.

•Si cet appareil venait à changer de propriétaire, n'oubliez pas de remettre la présente notice d’utilisation au nouveau bénéficiaire.

•Evitez d'endommager le câble d'alimentation quand vous transportez le réfrigérateur. Tordre le câble peut entraîner un incendie. Ne placez jamais d'objets lourds sur le câble d'alimentation.

•Évitez de toucher à la prise avec des mains mouillées au moment de brancher l'appareil.

•Évitez de brancher le réfrigérateur lorsque la prise de courant électrique a lâché.

•Pour des raisons de sécurité, évitez de pulvériser directement de l'eau sur les parties externes et internes du réfrigérateur.

•Ne pulvérisez pas de substances contenant des gaz inflammables comme du propane près du réfrigérateur pour éviter tout risque d'incendie et d'explosion.

•Ne placez jamais de récipients contenant de l'eau sur votre réfrigérateur, ils pourraient causer des chocs électriques ou un incendie.

•Évitez de surcharger le réfrigérateur avec une quantité excessive d'aliments. S'il est surchargé, les aliments peuvent tomber, vous blesser et endommager le réfrigérateur quand vous ouvrez la porte.

•Ne placez jamais d'objets au-dessus du réfrigérateur, ils pourraient tomber quand vous ouvrez ou fermez la porte du réfrigérateur.

•Les produits qui nécessitent un contrôle de température précis (vaccin, médicament sensible à la chaleur, matériels scientifiques, etc.) ne doivent pas être conservés dans le réfrigérateur.

+ 352 hidden pages
