Beko CSA 34023 User Manual

CSA34023S
GB Instruction for use
БГ Инструкции за употреба
LV Lietošanas instrukcija
SB Uputstvo za upotrebu HR Upute za uporabu
WARNING!
he R 600a (flammable only under certain conditions) you must observe
eškodljivu tvar za hlađenje
In order to ensure a normal operation of your refrigerating appliance, which uses a completely environmentally friendly refrigerant t the folloving rules:
Do not hinder the free circulation of the air around the appliance. Do not use mechanic devices in order to accelerate the defrosting, others than the ones recommended
by the manufacturer.
Do not destroy the refrigerating circuit. Do not use electric appliances inside the food beeping compartment, others than those that might have
been reccommended by the manufacturer.
ВНИМАНИЕ!
Вашия апарат съдържа хладилна течност R 600a (запалим само при определени условия) газ от естествен произход който е силно съвместим със изискванията за опазване на околната среда. За да осигурите нормална работа на Вашият уред моля спазвайте следните правила:
Осигурете нормална вентилация на уреда. Не използвайте механични устройства за размразяване на уреда, освен тези препоръчни от
производителя.
Не наранявайте хладилната верига.Не използвайте електрически уреди вътре в апарата.
UZMANĪBU!
Lai garantētu jūsu sasaldēšanas iekārtas (kura izmanto viedei nekaitīgu dzesēšanas vielu R 600a – uzliesmojošs tikai pie noteiktiem apstākļiem), ir nepieciešams ievērot sekojošo:
Netrauciet gaisa cirkulācijai ap iekārtu. Neizmantojiet nekādas mehāniskās iekārtas atkausēšanas paātrināšanai.
Nesabojājiet dzesēšanas ķēdi.
Nodalījumā pārtikas produktu glabāšanai neizmantojiet nekādas mehāniskās iekārtas, ja ražotājs to neiesaka.
UPOZORENJE!
Da biste obezbedili normalan rad Va.eg fri.idera, koji koristi ekolo.ki rashlađivač R600a (a koji je zapaljiv samo pod određenim okolnostima) morate po.tovati sledeća pravila:
Nemojte ometati slobodan protok vazduha oko uređaja. Nemojte koristiti druga mehanička sredstva osim onih koje predviđa proizvođač, da biste ubrzali
odmrzavanje.
Nemojte uni.titi jedinicu za hlađenje. Nemojte koristiti električne uređaje u odeljku za čuvanje hrane, osim onih koje preporučuje proizvođač.
UPOZORENJE!
Da biste osigurali normalan rad Vašeg hladnjaka, koji koristi potpuno po okoliš n R 600a (zapaljiv samo pod određenim uvjetima), morate se držati sljedećih pravila:
Nemojte sprječavati slobodan protok zraka oko uređaja. Nemojte koristiti mehaničke uređaje da biste ubrzali odmrzavanje, osim onih koje je preporučio proizvođač. Ne uništavajte sklop za zamrzavanje.
Ne koristite električne uređaje u odjeljku za hranu, osim onih koje je preporučio proizvođač.
Б
Г
GB
LV
SB
HR
Safety first /1 Electrical requirements /2 Transportation instructions /2 Installation instructions /2 Getting to know your appliance /3 Suggested arrangement of food in the appliance /3 Temperature control and adjustment /4 Before operating /4 Storing frozen food /4 Freezing fresh food /4 Making ice cubes /5 Defrosting /5 Replacing the interior light bulb /5 Cleaning and care /5 Repositioning the door /6 Do’s and don’ts /6 Information about operating noises /7 Trouble – shooting /8 Thechnical data /8
Безопасност преди всичко /9 Електрически изисквания /10 Tранспортнu uнструкции /10 Инструкции при инсталиране /10 Запознаване с вашия уред /11 Препоръки при подреждане на храната /11 Контрол на температурата и настройки /12 Преди работа /12 Съхранение на замразени храни /12 Замразяване на свежи продукти /13 Лед /13 Размразяване /13 Подмяна на лампичката от вътрешното осветление /14 Почистване и грижи /14 Промяна посоката на отваряне на вратата /14 Полезни съвети /15 Разрешение на проблеми /16 Технически характеристики /16
Drošības norādījumi! /17 Elektriskās prasības /18 Transportēšana /18 Uzstādīšana /18 Apraksts /19 Pārtikas produktu izvietošana /19 Temperatūras regulēšana /19 Pirms ekspluatācijas /19 Sasaldētu produktu glabāšana /19 Sasaldēšana /19 Ledus kubiņu gatavošana /19 Tirīšana un apkalpošana /20 Traucējumu meklēšana /20 Tehniskais apraksts /20
Index
Съдържание
Sadržaj
Bezbednost na prvom mestu /21 Neophodne električne instalacije /22 Uputstvo za transport /22 Uputstvo za instaliranje /22 Elementi uređaja /23 Regulacija temperature /23 Pre stavljanja aparata u upotrebu /23 Skladištenje zamrznute hrane /23 Zamrzavanje sveže hrane /23 Pravljenje leda /23 Odmrzavanje /24 Zamena sijalice u aparatu /24 Čćenje i održavanje /24 Smer otvaranja vrata /25 Problemi /25 Tehnički podaci o uređaju /25
Prvo sigurnost /26 Električni zahtjevi /27 Upute za prijevoz /27 Upute za ugradnju /27 Upoznavanje Vašeg uređaja /28 Predloženo slaganje hrane u uređaju /28 Kontrola i prilagođavanje temperature /28 Prije rada /29 Pohrana smrznute hrane /29 Pohrana svježe hrane /29 Pravljenje kockica leda /29 Odmrzavanje /30 Zamjena unutarnje žarulje /30 Čćenje i briga /30 Prebacivanje vrata /31 Što se smije a što se ne smije /31 Informacije o buci za vrijeme rada /32 Rješavanje problema /33 Tehnički podaci /33
Sadržaj
1
2
3 4
9
5
6
7
8
10
11
1
This appliance is not intended for use by person with reduced physical, sensory or
mental capabilities or lack of experience and knowledge unless they have been
concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do
GB Instruction for use
Congratulations on your choice of a Quality Appliance, designed to give you many years of service.
Safety first!
Do not connect your appliance to the electricity supply until all packing and transit protectors have been removed.
• Leave to stand for at least 4 hours before switching on, to allow compressor oil to settle, if transported horizontally.
• If you are discarding an old appliance with a lock or latch fitted to the door, ensure that it is left in a safe condition to prevent the entrapment of children.
• This appliance must only be used for its intended purpose.
• Do not dispose of the appliance on a fire. Your appliance contains non CFC substances in the insulation which are flammable. We suggest you contact your local authority for information on disposal and available facilities.
• We do not recommend use of this appliance in an unheated, cold room. (e.g. garage, conservatory, annex, shed, out-house etc.) To obtain the best possible performance and trouble free operation from your appliance it is very important to read these instructions carefully. Failure to observe these instructions may invalidate your right to free service during the guarantee period. Please keep these instructions in a safe place for easy reference.
given supervision or instruction
not play with the appliance.
Repairs to electrical equipment should only be
ATTENTION!
while.
1. The appliance should be transported only in
appliance, as this could cause injury to fingers
• Make sure that the mains cable is not caught
where the temperature is likely to
fall below 10
operate in ambient temperatures between +10
and +32 degrees C (50 and 90 degrees F). At
tion in the storage
GB Instruction for use
Electrical requirements
Before inserting the plug into the wall socket make sure that the voltage and the frequency shown in the rating plate inside the appliance corresponds to your electricity supply. We recommend that this appliance is connected to the mains supply via a suitably switched and fused socket in a readily accessible position.
Warning! This appliance must be earthed.
3. Failure to comply with the above instructions could result in damage to the appliance, for which the manufacturer will not be held liable.
4. The appliance must be protected against rain, moisture and other atmospheric influences.
Important!
• Care must be taken while cleaning/carrying the appliance not to touch the bottom of the condenser metal wires at the back of the
performed by a qualified technician. Incorrect repairs carried out by an unqualified person are carry risks that may have critical consequences for the user of the appliance.
This appliance operates with R 600a which is an environmental friendly but flammable gas. During the transportation and fixing of the product, care must be taken not to damage the cooling system. If the cooling system is damaged and there is a gas leakage from the system, keep the product away from open flame sources and ventilate the room for a
WARNING - Do not use mechanical devices or other means to accelerate the defrosting process, others than those recommended by the manufacturer. WARNING - Do not damage the refrigerant circuit. WARNING - Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
Transportation instructions
an upright position. The packing as supplied must be intact during transportation.
2. If during the transport the appliance, has been positioned horizontally, it must not be operated for at least 4 hours, to allow the system to settle.
and hands.
• Do not attempt to sit or stand on top of your appliance as it is not designed for such use. You could injure yourself or damage the appliance.
under the appliance during and after moving, as this could damage the cable.
• Do not allow children to play with the appliance or tamper with the controls.
Installation instructions
1. Do not keep your appliance in a room
degrees C (50 degrees F) at night and/or especially in winter, as it is designed to
lower temperatures the appliance may not operate, resulting in a reduc life of the food.
2. Do not place the appliance near cookers or radiators or in direct sunlight, as this will cause extra strain on the appliance's functions. If installed next to a source of heat or freezer, maintain the following minimum side clearances: From Cookers 30 mm From Radiators 300 mm From Freezers 25 mm
3. Make sure that sufficient room is provided around the appliance to ensure free air circulation (Item 2).
• Put the back airing lid to the back of your refrigerator to set the distance between the refrigerator and the wall (Item 3).
2
4. Cooked dishes should be stored in airtight
the shelf. Fresh fruit and vegetables should be
other materials to allow free circulation of cool
s to cool
wrap pineapples, melons, cucumbers,
GB Instruction for use
4. The appliance should be positioned on a smooth surface. The two front feet can be adjusted as required.To ensure that your appliance is standing upright adjust the two front feet by turning clockwise or anti­clockwise, until firm contact is secured with the floor. Correct adjustment of feet prevents excessive vibration and noise (Item 4).
5. Refer to "Cleaning and Care" section to prepare your appliance for use.
Getting to know your appliance
(Item 1)
1 - Thermostat and lamp housing 2 - Adjustable Cabinet shelves 3 - Wine bottles support 4 - Water collector 5 - Crisper cover 6 - Crispers
7 - Ice tray support & ice tray 8 - Compartment for quickly freezing 9 - Compartments for frozen froods keeping 10 - Adjustable foot 11 - Dairy Compartment 12 - Shelf for jars 13 - Keeping cup 14 - Shelf for bottles
Suggested arrangement of food in the appliance
Guidelines for obtaining optimum storage and hygiene:
1. The fridge compartment is for the short­term storage of fresh food and drinks.
2. The freezer compartment is rated and suitable for the freezing and storage of pre-frozen food. The recommendation for storage as stated on the food packaging should be observed at all times.
3. Dairy products should be stored in the special compartment provided in the door liner.
containers.
5. Fresh wrapped produce can be kept on
cleaned and stored in the crispers.
6. Bottles can be kept in the door section.
7. To store raw meat, wrap in polythene bags and place on the lowest shelf. Do not allow to come into contact with cooked food, to avoid contamination. For safety, only store raw meat for two to three days.
8. For maximum efficiency, the removable shelves should not be covered with paper or
air.
9. Do not keep vegetable oil on door shelves. Keep the food packed, wrapped or covered. Allow hot food and beverage before refrigerating. Leftover canned food should not be stored in the can.
10. Fizzy drinks should not be frozen and products such as flavoured water ices should not be consumed too cold.
11. Some fruit and vegetables suffer damage if kept at temperatures near 0°C. Therefore
tomatoes and similar produce in polythene bags.
12. High-proof alcohol must be stored upright in tightly closed containers. Never store products that contain an inflammable propellant gas (e.g. cream dispensers, spray cans, etc.) or explosive substances. These are an explosion hazard.
3
which is quite normal. We recommend that
thermometer to ensure that the cabinet is kept
And note that:
ion of the top of the cabinet is
7. We recommend setting the thermostat knob
recommend checking the temperature with an
storage of commercially frozen foods and also
ted if the
time. The quality of the food is best preserved
when it is frozen right through to the core as
GB Instruction for use
Temperature control and adjustment
Operating temperatures are controlled by the thermostat knob (Item 5) and may be set at any position between 1 and 5 (the coldest position). The average temperature inside the fridge should be around +5°C (+41°F). Therefore adjust the thermostat to obtain the desired temperature. Some sections of the fridge may be cooler or warmer (such as salad crisper and top part of the cabinet)
you check the temperature periodically with a
to this temperature. Frequent door openings cause internal temperatures to rise, so it is advisable to close the door as soon as possible after use.
Before operating
Final Check
Before you start using the appliance check that:
1. The feet have been adjusted for perfect levelling.
2. The interior is dry and air can circulate freely at the rear.
3. The interior is clean as recommended under "Cleaning and care.”
4. The plug has been inserted into the wall socket and the electricity is switched on. When the door is open the interior light will come on.
5. You will hear a noise as the compressor starts up. The liquid and gases sealed within the refrigeration system may also make some (noise), whether the compressor is running or not. This is quite normal.
6. Slight undulat quite normal due to the manufacturing process used; it is not a defect.
midway and monitor the temperature to ensure the appliance maintains desired storage temperatures (See section Temperature Control and Adjustment).
8. Do not load the appliance immediately it is switched on. Wait until the correct storage temperature has been reached. We
accurate thermometer (see; Temperature Control and Adjustment).
Storing frozen food
Your freezer is suitable for the long-term
can be used to freeze and store fresh food. If there is a power failure, do not open the door. Frozen food should not be affec failure lasts for less than 18 hrs. If the failure is longer, then the food should be checked and either eaten immediately or cooked and then re-frozen.
Freezing fresh food
Please observe the following instructions to obtain the best results. Do not freeze too large a quantity at any one
quickly as possible. Do not exceed the freezing capacity of your appliance in 24 h. Placing warm food into the freezer compartment causes the refrigeration machine to operate continously until the food is frozen solid. This can temporarily lead to excessive cooling of the refrigeration compartment. When freezing fresh food, keep the thermostat knob at medium position. Small quantities of food up to 1/2 kg. (1 lb) can be frozen without adjusting the temperature control knob. Take special care not to mix already frozen food and fresh food.
4
with a spoon handle or a similar implement;
A) Fridge compartment
when defrosting is completed. Do not use
no food particles have blocked the drain tube.
Check that the tube is permanently placed with
its end in the collecting tray on the compressor
All food should be wrapped in several layers
Do not use pointed or sharp
-
edged
arbonate of soda to one
6. If the appliance is not going to be used for
parts of the product (i.e. door exterior, cabinet
GB Instruction for use
Making ice cubes
Fill the ice - cube tray 3/4 full with water and place it in the freezer. Loosen frozen trays
never use sharp-edged objects such as knives or forks.
Defrosting
The fridge compartment defrosts automatically. The defrost water runs to the drain tube via a collection container at the back of the appliance (Item 6). During defrosting, water droplets may form at the back of the fridge compartment where a concealed evaporator is located. Some droplets may remain on the liner and refreeze
pointed or sharp-edged objects such as knives or forks to remove the droplets which have refrozen. If, at any time, the defrost water does not drain from the collection channel, check that
The drain tube can be cleared with a pipe­cleaner or similar implement.
to prevent the water spilling on the electric installation or on the floor (Item 7).
B) Freezer compartment
Defrosting is very straightforward and without mess, thanks to a special defrost collection basin. Defrost twice a year or when a frost layer of around 7 (1/4") mm has formed. To start the defrosting procedure, switch off the appliance at the socket outlet and pull out the mains plug.
of newspaper and stored in a cool place (e.g. fridge or larder). Containers of warm water may be placed carefully in the freezer to speed up the defrosting.
objects, such as knives or forks to remove the frost.
Never use hairdryers, electrical heaters or other such electrical appliances for defrosting. Sponge out the defrost water collected in the bottom of the freezer compartment. After defrosting, dry the interior thoroughly (Item 8 & 9). Insert the plug into the wall socket and switch on the electricity supply.
Replacing the interior light bulb
Should the light fail, switch off at the socket outlet and pull out the mains plug. Then ensure the bulb is screwed securely in the bulb holder. Replace the plug and switch on. If the light still fails, obtain a replacement E14 screw-cap type 15 Watt (Max) bulb from your local electrical store and then fit it (Item 10). Carefully dispose of the burnt-out light bulb immediately.
Cleaning and care
1. We recommend that you switch off the appliance at the socket outlet and pull out the mains plug before cleaning.
2. Never use any sharp instruments or abrasive substances, soap, household cleaner, detergent or wax polish for cleaning.
3. Use luke warm water to clean the cabinet of the appliance and wipe it dry.
4. Use a damp cloth wrung out in a solution of one teaspoon of bic pint of water to clean the interior and wipe it dry.
5. Make sure that no water enters the temperature control box.
a long period of time, switch it off, remove all food, clean it and leave the door ajar.
7. We recommend that you polish the metal
sides) with a silicone wax (car polish) to protect the high quality paint finish.
5
which is
• Clean the appliance with unsuitable material;
Wrap cheese firstly in greaseproof paper
as much air as possible. For best results,
Chill white wines, beer, lager and mineral
Keep food for as short a time as possible
accordance with the instructions given on
food in aluminium foil or freezer
GB Instruction for use
8. Any dust that gathers on the condenser,
should be removed once a year with a vacuum cleaner.
9. Check door seals regularly to ensure they areclean and free from food particles.
10. Never:
located at the back of the appliance,
eg petroleum based products.
• Subject it to high temperatures in any way,
• Scour, rub etc., with abrasive material.
11. Removal of dairy cover and door tray :
• To remove the dairy cover, first lift the cover up by about an inch and pull it off from the side where there is an opening on the cover.
• To remove a door tray, remove all the contents and then simply push the door tray upwards from the base.
12. Make sure that the special plastic container at the back of the appliance which collects defrost water is clean at all times. If you want to remove the tray to clean it, follow the instructions below:
• Switch off at the socket outlet and pull out the mains plug
• Gently uncrimp the stud on the compressor, using a pair of pliers, so that the tray can be removed
• Lift it up.
• Clean and wipe it dry
• Reassemble, reversing the sequence and operations
13. To remove a drawer, pull it as far as possible, tilt it upwards and then pull it out completely.
Repositioning the door
Proceed in numerical order (Item 11).
Do’s and don’ts
Do- Clean and defrost your appliance
regularly (See "Defrosting")
Do- Keep raw meat and poultry below
cooked food and dairy products.
Do- Take off any unusable leaves on
vegetables and wipe off any soil.
Do- Leave lettuce, cabbage, parsley and
cauliflower on the stem.
Do-
and then in a polythene bag, excluding
take out of the fridge compartment an hour before eating.
Do- Wrap raw meat and poultry loosely in
polythene or aluminium foil. This prevents drying.
Do- Wrap fish and offal in polythene bags. Do- Wrap food with a strong odour or which
may dry out, in polythene bags, or aluminium foil or place in airtight container.
Do- Wrap bread well to keep it fresh. Do-
water before serving.
Do- Check contents of the freezer every so
often.
Do-
and adhere to "Best Before" and "Use by" etc. dates.
Do- Store commercially frozen food in
the packets.
Do- Always choose high quality fresh food
and be sure it is thoroughly clean before you freeze it.
Do- Prepare fresh food for freezing in small
portions to ensure rapid freezing.
Do- Wrap all
quality polythene bags and make sure any air is excluded.
Do- Wrap frozen food immediately after
purchasing and put it in to the freezer as soon as possible.
Do- Defrost food in the fridge compartment.
6
Loading...
+ 28 hidden pages
