Class ll
Barcode Scan
for Pocket PC series
Pocket PC software include!
Use Pocket PC as an
Personal Digital Terminal
Ideal for CompactFlash Slot
Pocket PC and Handheld PC
CompactFlash Laser barcode Scan
1. Copyright
All rights reserved. No part of this publication may be reproduced in any
form or by any means without permission in writing from Beinteractive
Co., Ltd.
Specifications, Bundle program and user’s guide are subject to change
without prior notice to upgrade.
All products and company names mentioned are trademarks or
registered trademarks of their respective holders.
Copyright ⓒBeinteractive Co., Ltd,
2. Warranty
This warranty period for this product is one(1) year from the date of
product purchase. During the warranty period, Beinteractive will repair
or replace the defective product at no charge when furnished with proof
of retail purchase, provided that you deliver the product to Beinteractive
or to an authorized Beinteractive Agent or distributor.
This warranty does not cover the replacement of products, damaged by
abuse, accident, misuse or misapplication, nor as a result of service or
modification other than by Beinteractive.
** On this guide, Pocket PC, Windows CE are trademark of Microsoft and ActiveScan is trademark
of Beinteractive Co., Ltd.
All rights reserved. No part of this publication may be reproduced in any form or by any means
without permission in writing from Beinteractive Co., Ltd.
Information to user : Part 15, Paragraph 15.21 and 15.105(b)
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment
FCC Notice
NOTE : This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interferenc e
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
----------------------------------------------This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1)this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
1. Introduction
ActiveScan is an ultra-lightweight, low power module, CompactFlash type
scan card that enables standard barcode scanning using a Pocket PC.
ActiveScan can be not only adapted Notebook but also mobile devices
such as Pocket PC, Palm Size PC, handheld PC and Pen Tablet which
support Windows CE 3.0. It can be widely used in various industries such
as physical distribution, delivery, and automation.
- Provides an excellent compatibility and program environment
- Reads a barcode in a fast and precise way using a laser
- Streamlined waterproof and insect-proof design
- Competent price and excellent development environment
3
2. Package contents
ActiveScan is composed of an ActiveScan Card, User’s guide and
Installation CD. Please check the contents. If there is any missing or
damages, please contact to purchasing place.
ActiveScan User’s guide Installation CD
3. Installation of ActiveScan
Before install⋯.
Please delete any barcode scanning software you may already have
installed on your computer. Also delete the PocketScan task tray icon on
the right bottom of Task bar.
This guide explains based on the Pocket PC 2003 of Microsoft.
There is little bit difference compare to Windows CE 2..1X Palmsize PC
and Handheld PC but basic procedure is almost the same. We supply
drivers file for Windows CE 3.0, Windows CE.net, HPC 2000 and if you
want to know the applications. We”ll supply SDK .
If you make an easy to develop application program, please contact us.
(SDK is included in the CD, but you’ll need S/N)
** webmaster@beinteractive.co.kr
※
PocketScan Task Tray Icons
No card Detected
ActiveScan card Detected (Active icon)
4
3-1. S/W Installation
1. To install driver, you must synchronize
Pocket PC and your Desktop PC in
a d v a n c e
2. After synchronization between two
devices, insert CD
3. If you double click setup.exe then
“PocketScan” will be started to install.
4.With message of “Application
downloading Complete”, ActiveScan
program will be installed automatically.
5. You can find that ActiveScan is installed
on the “P r o g r a m”with PocketScan
i c o n.
3-2 Getting started
1. If PockectScan program is already
started then click the PocketScan task
tray icon on the right bottom of Task bar.
5
2. First, plug-in the ActiveScan card into
the CompactFlash slot on your mobile
c o m p u t e r .
3. With sound of card recognition, “Pocket
S c a n”logo will display and PocketScan
task tray icon will be replaced into the
active icon on the Task bar.
4. If you click the PocketScan task tray icon (active icon) on the Task
bar “About” and “Prefix/Suffix/Sound...” menu will display to set the
propetty of the ActiveScan.
6
5. Properties menu If you click the PocketScan task tray icon (active
icon) on the Task bar, Properties menu and program menu will be
displayed. You can set “P r e f i x / S u f f i x”and scanner “sound”.
Prefix/Suffix Option Sound Option
If you choose “Prefix/Suffix/Sound.”
menu then Dialog window will be
displayed. On this menu, you can
set a prefix and suffix of scan data.
You can also choose sound on the
menu of “sound on/off.” After
finished setting, please push “O.K”
b u t t o n .
6. You can execute laser beam without virtual button so PocketScan
program include H/W button function.
Button Mapping
To make a button mapping, select “S t a r t
→S e t t i n g→B u t t o n”Choose any button
that you want to set.
Select “PocketScan” on the “Button
assignment” field and push “O.K” button.
** You are ready to scan then open
new notes and push assigned
button to scan.
Laser beam will be disappeared
in 2 ~ 3 second.
7
3-3. Test of ActiveScan
1. Open the Windows application you want to receive
the data. (note, Excel, etc...)
2. Press the button and scan the code.
3. After a successful scan, data should appear in your
d o c u m e n t .
4. Specification
4-1. Specification of ActiveScan
Physical Characteristics CompactFlash Type I Ext
Interface Type Laser Barcode scan
Barcode Symbologies Code 39, UPC, EAN, Other standard
b a r c o d e
Scan Repetition Rate 39 (± 3) scans/sec (bi-directional)
Decode Distances 2.2 to 60.0 inch
Scan Angle 5 3°( t y p i c a l )
Laser class Intended use in CDRH/IEC Class 2 devices
Power Consumption Idle: 11.4 mA, Typical: 97 mA
CompactFlash card size 43x 43 x 3.3 mm
Scanner size 34 x 49 x 18.5 mm
Humidity Operating 10% to 90%, non-condensing
Humidity Non-operating 10% to 95%, non-condensing
Weight Approx. 32.5 g
Operating System Windows CE 3.0 or Higher
Windows CE Software P o c k e t S c a n™software with keyboard
e m u l a t i o n
W a r r a n t y 1 year
8
4-2. Specification of Scanner Engine
Power Requirements 3.3 - 5.0 V DC ±1 0 %
Input Voltage 68 mA @ 3.3V DC
Input Current 78 mA @ 5.0V DC
Standby Current < 35 mA typical; 50 mA max. @ 5VDC
Surge Current <200 mA typical
Vcc Noise Level 100 mV pk - pk (30 Hz - 50 kHz)
Scan Repetition Rate 39 (± 3) scans/sec (bi-directional)
Laser Power 1.2 mW nominal - Scanning Mode0.8 mW
nominal - Aim Mode
Laser Class Intended use in CDRH/IEC Class 2 devices
Print Contrast Minimum 25% absolute dark/light reflectance
measured at 650 nm
Scan Angle 5 3°( t y p i c a l )
Pitch Angle ± 6 5°from normal
Skew Tolerance ± 6 0°from normal
Roll ± 1 0°from vertical
Ambient Light Immunity
S u n l i g h t 10,000 ft. candles (107,640 lux)
Artificial Light 450 ft. candles (4,844 lux)
4-3. Decoding Zone
** Source : Symbol technologies, Inc.
9
5. If you have trouble...
5-1. Does not recognize the PocketScan (driver) on your mobile
computer...
▶ Please check your processor and OS with the driver. Sometimes,
They are different each other.
▶Please reset the PocketScan on your mobile computer and retry
s a n n i n g .
5-2. When you press the trigger button, nothing happens...
▶ Please see “3-2 getting started → 5. button mapping”
5-3. Does not read the barcode on your mobile computer with ActiveScan.
▶Please check your barcode. If it has damaged print it can not work
c o r r e c t l y .
▶ please see the SDK/Symbol-Parameter and print a this parameter.
You can set all defaults bar code and enable or disale resetting the
d e c o d e .
▶ For best results, the scanner should we held at an angle of at least
is degress form perpendicular to the surface of the bar cade label.
5-4. When you plug-in ActiveScan, it is not working with message of
“Unknown card in Socket”
▶Please contat us
6. Technical Support
6-1. If you have a technical problem while installing or using the
ActiveScan card. Please feel free to contact us.
- The Driver
- Windows version of your mobile computer
- SDK
6-2. If you are missed the CD. You can download the driver by
www.beinteractive.co.kr/eng →click “support”
1 0
You can contact Beinteractive the follwing ways ;
Web w w w . b e i n t e r a c t i v e . c o . k r
e-mail w e b m a s t e r @ b e i n t e r a c t i v e . c o . k r
Phone 8 2 - 2 - 3 4 7 2 - 6 7 1 5
Fax 8 2 - 2 - 3 4 7 2 - 7 1 3 3
“ActiveScan”Power saving Barcode scan card for Pocket PC
Support various environment for trans,logistics.
Ideal for CompactFlash Slot
Pocket PC and Handheld PC
5FL. Hanseo Bldg., 1582-6, Seocho-Dong, Seocho-Gu, Seoul 137-875, Korea
www.beinteractive.co.kr
