Beijing Visual World Technology D801 User Manual

Model: D801

Manufacturer's Name: Beijing Visual World Technology Co., Ltd.
Product Name: 15th Floor and 17th Floor 1701-10A, Building 3, No. 10, Jiuxianqiao Road Jia, Chaoyang
District, Beijing, China
Trade Mark: +360
Model number: D801
Operating Temperature: -20° C to 55° C
This device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/
EU. All essential radio test suites have been carried out.
Detailed DOC file please visit our website:
http://www.genrace.com/enindex.php
1 The device complies with RF specifications when the device used at 20mm from your
body.

1. Adapter shall be installed near the equipment and shall be easily accessible.

1. The plug considered as disconnect device of adapter.
MODEL:TEKA012-1201000XX
INPUT:100-240V-50/60Hz 0.35A MAX
OUTPUT: 12V 1A
Care for the environment! Must not be discarded with household waste!
RF Secification:

Function Operation Frequency Max RF outputpower: Limit

802.11b 2412-2472MHz 15.1dBm (e.r.i.p.) 20.0dBm

802.11g 2412-2472MHz

802.11n20 2412-2472MHz 13.5dBm (e.r.i.p.) 20.0dBm

802.11n40 2422-2462MHz 12.3dBm (e.r.i.p.) 20.0dBm

This product can be used across EU member states.

14.7dBm (e.r.i.p.) 20.0dBm
