Behavior Tech Computer KB9019URF Users manual

9019URF Wireless Kits

USB RF Keyboard With Build-in Mouse & Joystick

Manual

Version 1.0

封面內頁

FCC GUIDELINES

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

 Reorient or relocate the receiving antenna

 Increase the separation between the equipment and receiver

 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

 Consult the dealer or an experienced radio/TV technician for help.

The Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulation.

Cet appareil numerique de la class B respecte toutes les exigences du Règlement sur le materiel brouilleur du Canada.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.

This equipment is intended for use in the following countries EU 15 countries: Austria, Belgium, Denmark, Finland, France, Germany, Ireland, Italy, Luxembourg, Netherlands, Spain, Sweden, United Kingdom, Portugal, Greece. And other non-EU countries: Switzerland, Norway, and Iceland.

低功率電波輻射性電機管理辦法：

第十四條：經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計

第十七條：低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，英立即停用，並改善至無干擾時

Caution:

Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Shielded interface cable, if any, must be used in order to comply with emission limits.

The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor.

No warranty of representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organisation of such changes.

In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages.

IBM, PC/AT and PS/2 are registered trademarks of International Business Machines Corporation.

Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation in the United States of America and/or other countries.

All other trademarks are trademarks of their respective holders.

之特性及功能。

方得繼續使用。

前項合法通信，指依電信法規定作業之無線電信。

低功率射頻電機需忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。

Table of Contents

Important Information.................................................................................................. 1

Battery Installation ................................................................................................... 1

Receiver cable positioning......................................................................................2

1 Introduction ....................................................................................................... 3

2 System Requirements ......................................................................................4

3 Hardware Installation........................................................................................ 5

ID Setting...................................................................................................................6

4 Software Installation ......................................................................................... 8

5 Using the Keyboard, Mouse, and Joystick..................................................... 9

5.1 Using the Keyboard.......................................................................................9

5.2 Using the Mouse.......................................................................................... 14

5.3 Using the Joystick....................................................................................... 19

6 Troubleshooting..................................................................................................21

Battery Installation

Important Information

When battery power gets too low, the computer will display a battery low icon on the system tray or flash 10 seconds every minute on right upper screen as notification.

1. Open the battery compartment cover on the bottom of the keyboard and mouse.

2. Follow the indication inside to place in keyboard and mouse batteries.

3. Place the battery compartment cover back and proceed with ID setting of the devices.

Important:

1. We recommend using alkaline batteries for a

longer battery life.

lways change batteries when battery low icon

appears.

3. Install keyboard and mouse driver first to ensure

the battery power is monitored.

4. Don't mix different types of batteries or new and

old batteries together. Always replace old batteries with new and same type batteries.

5. Remove batteries after long periods of non-use.

Battery leakage or corrosion may damage the device quality and cause danger.

Receiver cable positioning

1. Don't warp receiver cable around monitor or LCD panel base.

2. Don't intertwine receiver cable with power cables.

3. Don't bundle or bind receiver cable with other signal cables.

4. Don't extend receiver cable unless absolutely necessary, and let receiver cable run free from other cables.

1 Introduction

Congratulations on your purchase of this wireless USB RF keyboard with marvelous build-in mouse & joystick. This keyboard kit will finally free you of the constraints of your desktop by providing a wireless connection between your keyboard and your PC. Pass around the keyboard during meetings without having to bother about a cable blocking your way or write e-mails and surf the Internet from the comfort of your living room couch!

This keyboard kit consists a keyboard with mouse & joystick, and a receiver. The receiver is connected to your PC through a cable with a keyboard connector. The keyboard can be operated freely within a radius of at least 6.56 feet (2 meter) from the receiver. Because the keyboard uses radio frequencies to transmit the wireless signal, it has no constrictions on viewing angles such as with infrared devices like your TV’s remote control, etc.

Moreover, the build-in mouse function on keyboard makes you access easily to Internet Menu, Multimedia Menu, and Office Menu by pressing the “mouse middle button” (Please Note: Please install the enclosed driver first to enjoy these amazing functions). When using the joystick in your exciting computer games, you immediately can enjoy the convenience and easy of operating that joystick. (Please Note: Joystick function can only be worked when playing computer games.)

Besides providing unprecedented freedom movement when operating the keyboard and joystick, it also has a row of hotkeys including Internet, Multimedia, and Sleep key (

Please note:

or later version). This package also provides a special driver, which provides unique shortcut functions.

In order to enjoy your keyboard of their full potential, we recommended you read this manual carefully prior to installation.

The Internet keys work only under Microsoft Internet Explorer 5.0

What's in this package?

 A wireless keyboard with mouse & joystick

 A receiver

 A driver disk

 A manual



A quick guide

 Batteries (2 pcs of AA alkaline batteries)

2 System Requirements

 Microsoft Windows 98, Windows ME, Windows 2000 or Windows XP

operating system

 Microsoft Internet Explorer 5.0 or later version (for the Internet keys)

 CD-ROM drive (for CD and Video operation)

 Standard sound card (for CD and Video operation)

 The system supporting ACPI or APM II (for power management buttons)

 ATX mother board and ATX power supply (for power management buttons)

 USB Spec 1.1 or its compatible

 Available USB port

Please refer to table below for the other system requirements for the features.

Function Description

Wireless Functionality

Extra Hot key Functions on Keyboard

Keyboard Extra ACPI Keys

Mouse Driver Function

Keyboard Battery Low Indication

Keyboard LED Indication

Operating System

Windows 98

Available immediately after hardware installation

Requires keyboard driver installation (see driver disk for details)

Requires enabling of system ACPI (Power Management) function

Requires installation of mouse driver (see driver disk for details)

Requires installation of keyboard driver (see driver disk for details)

Windows ME / Windows 2000 /

Windows XP

Available immediately after hardware installation

Requires keyboard driver installation (see driver disk for details)

Available immediately after hardware installation

Requires installation of mouse driver (see driver disk for details.)

Requires installation of keyboard driver (see driver disk for details)
