Beddit B3 Users Manual

SOLVING

SLEEP

USER GUIDE

Mobile device compatibility

What this package contains

iPhone 5 and above,
iPod (5th generation),
iPad 2 and above.

List of compatible Android
devices at www.beddit.com

1. The Beddit Sleep Tracker

2. Power adapter

3. User Guide

2

1

3

Beddit is not a medical device and should not
be used to diagnose or treat medical condi­tions. Consult your doctor for prevention, di­agnosis and treatment.

Beddit should only be used with the included
power adapter.

Beddit® is a registered trademark of Beddit
Ltd.

iPhone and iPod touch are trademarks of Ap­ple Inc., registered in the U.S. and other coun­tries. All other trademarks are the property of
their respective owners.

Patented, patents pending.
Designed and engineered in Finland.
Made in China.

Beddit Ltd., © 2016.

QUICK GUIDE

Follow these steps to install the Beddit Sleep Tracker in your bed.

1

2

3

1. Tuck it in

The positioning of your Beddit Sleep Tracker de­pends on your bed setup. To achieve the best
results place your Beddit Sleep Tracker under
your top bed sheet at right under your heart
on the part of the bed where you’ll be sleeping,
be it on the side if you sleep with someone, or
in the middle of a big bed in which you sleep

alone. It is recommended you rst try out the

optimal positioning before placing the Beddit
Sleep Tracker under the sheet:

•

If you sleep alone in the bed, place the Beddit
Sleep Tracker so that it extends fully (about

31.5 inch in, 80 cm) onto the mattress

•

If you sleep alone in a wide bed, place the
Beddit Sleep Tracker so that it covers the area
where you normally sleep.

•

If two people sleep in the bed, place the Bed­dit Sleep Tracker so that there is a 6-inch gap
(15 cm) between the midline of the bed and
the Tracker’s end. With beds over 63-inch wide
(160 cm), the gap may be wider

You can later re-adjust the placement to nd

the optimal spot in your bed.

2. Plug it in

Aer you have planed the Beddit Sleep Tracker

onto your mattress, fold the bed sheet back into
its original place. Plug the Beddit Sleep Track­er into the USB-power plug provided. Beddit
must be plugged into this power source in or­der to work.

3. Download the app

Download the Beddit app for your smartphone
from the App Store or Google Play. Launch the
application and follow the on-screen instruc-

tions to start your rst sleep measurement.

Additional resources and services

For troubleshooting and frequently asked ques­tions, you can browse our extensive Help Center
at support.beddit.com

If you have further questions about anything
related to Beddit, its use, results and so forth,
contact us at [e-mail]

Care instructions

Instructions for how to properly take care of
your Beddit Sleep Tracker and maximize its life.

1. Clean the topside of the Sleep Tracker with a
damp cloth if needed.

2. Do not wash the Sleep Tracker in a washing
machine or dry it in a dryer. Doing so will ruin
it and void your warranty.

3. Do not try to repair the sensor, cable or power
adapter. There are no parts that can be safely
repaired at home. Contact us if you need help
with your Beddit Sleep Tracker. If there is a de­fect covered by the warranty, we will replace
the defective part or refund your money. See
the warranty terms and limitations.

5. When making your bed, be careful with the
Sleep Tracker and the power cable to avoid
damaging them. If you have an adjustable
mattress or rollaway bed, do not fold the Sleep
Tracker and cable into the bed. Do not allow the
Sleep Tracker or cable to be folded up or tan­gled in your bedding.

6. Your Beddit Sleep Tracker includes a power
adapter. Use it for powering the Sleep Tracker.
Using the USB port on a laptop or other elec­tronics could result in power variation or dam­age to the Sleep Tracker or your electronics or
data. Plugging the power cable into your elec­tronics is at your own risk.

Visit support.beddit.com for latest updates
and information.

Important safety information

Read and understand these warnings. Failure
to follow them could result in death or serious
injury.

1. The Beddit Sleep Tracker is not a medical de­vice. It is not designed or intended to diagnose
or treat any medical conditions, and you should
not use it for these purposes. Consult your doc­tor for prevention, diagnosis, and treatment of
sleep disorders and other medical issues.

2. Be careful when placing the cable of the
Sleep Tracker to avoid trip hazards.

3. Do not use the Beddit Sleep Tracker with in­fants or children. Death or injury could result
from the sensor or power cable getting around
an infant’s or child’s neck during their sleep.

4. Similarly, if your sleeping habits put you
at risk of entangling a bedside cord or an un­der-sheet sleep tracker around your neck while
sleeping, do not use a Beddit Sleep Tracker.

5. The Beddit Sleep Tracker is not a baby mon­itor. It will not warn you of any sleeping prob­lems your infant may have. It will not warn you
if your infant stops breathing. It will not warn
of or prevent sudden infant death syndrome.

6. Do not use the Beddit Sleep Tracker around
water or other liquids. Like any electrical device,
there is an electrocution hazard if you get the
Beddit Sleep Tracker wet while it is plugged in.

7. Do not disassemble the Beddit Sleep Track­er or power adapter. There are no repairs that
you can safely do on them. See use and care in
structions on how to replace the adhesive tape.

-

Limited warranty

This Limited Warranty is applicable globally ex­cept in the United States of America.

Your Beddit Sleep Tracker consists of a Blue­tooth-enabled sensor, a USB power adapter
and a mobile app, which you must download
separately. This Limited Warranty covers only
the sensor and power adapter.

You have legal rights under applicable nation­al legislation governing the sale of consumer

goods. Those mandatory rights are not aected

by this Limited Warranty. See translations of the
warranty terms in your language and the war­ranty terms for the United States of America at
www.beddit.com

DECLARATION OF CONFORMITY

We, Beddit Ltd.
Of Kimmeltie 3, 2110, ESPOO, FINLAND
Declare under sole responsibility that the product /equipment we manufacture:
Brand name: Beddit
Model Name B3
To which this declaration relates, is in conformity with the following standard(s) or other
normative document(s)
EN 301 489-1 V1.9.2 Electromagnetic compatibility and Radio spectrum Matters (ERM);

ElectroMagnetic Compatibility (EMC) standard for radio equipment and
services; Part 1: Common technical requirements

EN 301 489-17 V2.1.1 Electromagnetic compatibility and Radio spectrum Matters (ERM);

ElectroMagnetic Compatibility (EMC) standard for radio equipment; Part

17: Specic conditions for Broadband Data Transmission Systems

EN 300 328 V1.9.1 Electromagnetic compatibility and Radio spectrum Matters (ERM);

Wideband transmission systems; Data transmission equipment
operating in the 2,4 GHz ISM band and using wide band modulation
techniques; Harmonized EN covering the essential requirements of
article 3.2 of the R&TTE Directive

IEC 60950-1:2006 Information technology equipment - Safety - Part 1: General

requirements
FCC part 2 v 10-1-13 FCC, General rules and regulations
FCC part 15 v 10-1-13 FCC, Radio Frequency device

The Technical Construction File is maintained at:
Company: Beddit Ltd.
Company address: Kimmeltie 3, 02110 ESPOO, Finland
The authorized representative located within the Community is:
Name: Henry Rimminen
Title: Hardware Lead
Date of issue: 27.06.2016
Place of issue: ESPOO, FINLAND
Legal signature:

The following sections present the compliance

statements for dierent geographical areas:

NORTH AMERICA

United States: Federal Communications
Commission (FCC)

FCC COMPLIANCE STATEMENT:
This device complies with part 15 of

Operation is subject to the following two con­ditions:
(1) This device may not cause harmful interfer­ence, and (2) this device must accept any in­terference received, including interference that
may cause undesired operation.
INFORMATION TO USER:
This equipment has been tested and found to
comply with the limits for a Class B digital de­vice, pursuant to Part 15 of FCC Rules. These
limits are designed to provide reasonable pro­tection against harmful interference in a resi­dential installation. This equipment generates,
uses, and can radiate radio frequency energy. If
not installed and used in accordance with the
instructions, it may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by tuning
the equipment o and on, the user is encour­aged to try and correct the interference by one
or more of the following measures:

• Reorient or relocate the receiving antenna

•

the FCC Rules.

Increase the distance between the equipment
and the receiver.

•

Connect the equipment to outlet on a cir­cuit dierent from that to which the receiv­er is connected.

•

Consult the dealer or an experienced radio/

TV technician for help.
WARNING:
The changes or modications not expressly ap­proved by the party responsibl
could void the user’s authority to operate the
equipment.
FCC ID: 2AI4U-B3

e for compliance

Canada: Industry Canada (IC)

IC COMPLIANCE STATEMENT:
This device complies with Industry Canada li­cense-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this
device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired opera­tion of the device.
This Class B digital apparatus complies with Ca­nadian ICES-003.
Cet appareil est conforme avec Industrie Cana­da exempts de licence standard RSS (s). L‘utili­sation de ce dispositif est autorisée seulement
aux conditions suivantes: (1) il ne doit pas pro­duire de brouillage et (2) l’utilisateur du disposi­tif doit étre prêt à accepter tout brouillage ra­dioélectrique reçu, même si ce brouillage est
susceptible de compromettre le fonctionne­ment du dispositif.
Cet appareil numérique de la classe B est con­forme à la norme NMB-003 du Canada.
IC ID: 21700-B3

EUROPEAN UNION

European Union (CE)

CE COMPLIANCE STATEMENT:

Hereby, Beddit Oy, declares that

with the essential requirements and other
relevant provisions of Directives 2004/108/EC
(EMC), 2006/95/EC (LVD), 2011/65/EU (RoHS)
and 1999/5/EC (R&TTE).

Test Report: pending

this product is in compliance

AUSTRALIA + NEW ZEALAND

ACMA:

N1246 (R-NZ)

www.beddit.com

[e-mail]
