BEC-Technologies BEC-7800TN User Manual
BEC
7800
Dual
W
AN ADSL2+
Firewall Router
User Manual
Version rekease 1.01 Last revised date 11-11-2008
Table of Contents
Chapter 1: Introduction ..................................................................... 1
Features ............................................................................................ 2
Chapter 2: Installing the Router ....................................................... 4
Introduction to your Router
Important note for using this router
Package Contents
................................................................................. 5
The Front LEDs. ................................................................................ 6
Cabling................................................................................................ 8
Chapter 3: Basic Installation ........................................................... 9
Connecting Your Router
Network Configuration
........................................................................ 11
Factory Default Settings
Information from your ISP
Chapter 4: Configuration ................................................................ 19
Quick Start
Status (Basic Mode)
............................................................................................ 20
............................................................................ 27
Cofiguration (Basic Mode)
WAN – Main Port (ADSL).................................................................. 28
WAN Profile – Main Port (EWAN) ..................................................... 33
Status (Advanced Mode)
ADSL................................................................................................. 36
ARP................................................................................................... 37
DHCP ................................................................................................ 37
System Log ....................................................................................... 38
Configuration (Advanced Mode)
LAN ................................................................................................... 39
Ethernet
.......................................................................................... 39
.................................................................. 1
.................................................... 4
..................................................................... 10
..................................................................... 17
................................................................ 18
................................................................. 28
.................................................................... 35
....................................................... 39
IP Alias
DHCP Server
............................................................................................ 39
................................................................................... 40
WAN Profile – Main Port (EWAN)
WAN Profile (ADSL)
ADSL Mode
..................................................................................... 49
.......................................................................... 41
......................................................... 47
System .............................................................................................. 50
WAN.................................................................................................. 41
Time Zone
Firmware Upgrade
Backup / Restore
Restart
User Management
....................................................................................... 50
............................................................................ 50
.............................................................................. 51
............................................................................................ 52
............................................................................. 52
Firewall.............................................................................................. 53
Packet Filter
MAC Filter
Block WAN Ping
..................................................................................... 53
....................................................................................... 54
............................................................................... 54
Virtual Server .................................................................................... 55
Port Mapping
DMZ
............................................................................................... 57
.................................................................................... 56
Advanced .......................................................................................... 58
Dynamic DNS
Static Route
VLAN
.............................................................................................. 59
Device Management
IGMP
.............................................................................................. 68
TR-069 Client
Remote Access
..................................................................................... 58
................................................................................... 58
.......................................................................... 60
................................................................................... 68
................................................................................. 69
Appendix: Product Support & Contact .......................................... 70
Chapter 1: Introduction
Introduction to your Router
Thank you for purchasing BEC 7800 Router. Your new router is an all-in-one unit that combines an
ADSL modem, ADSL2/2+ router and Ethernet network switch to provide everything you need to
get the machines on your network connected to the Internet over an ADSL broadband connection.
The BEC 7800 router complies with ADSL2+ standards for deployment worldwide and supports
downstream rates of up to 24 Mbps and upstream rates of up to 1 Mbps. Designed for small office,
home office and residential users, the router enables even faster Internet connections. You can
enjoy ADSL services and broadband multimedia applications such as interactive gaming, video
streaming and real-time audio much easier and faster than ever before.
The BEC 7800 supports PPPoA (RFC 2364 – PPP (Point-to-Point Protocol) over ATM Adaptation
Layer 5), RFC 1483 encapsulation over ATM (bridged or routed), PPP over Ethernet (RFC 2516)
to establish a connection with your ISP. Your new router also supports VC-based and LLC-based
multiplexing.
The perfect solution for connecting a small group of PCs to a high-speed broadband Internet
connection, the BEC 7800 allows multiple users to have high-speed Internet access
simultaneously.
Your new router also serves as an Internet firewall, protecting your network from access by
outside users. Not only does it provide a natural firewall function with Network Address Translation
(NAT), it also provides rich firewall features to secure your network. All incoming data packets
are monitored and filtered. You can also configure your new router to block internal users from
accessing the Internet.
The BEC 7800 provides two levels of security support. First, it masks LAN IP addresses making
them invisible to outside users on the Internet, so it is much more difficult for a hacker to target a
machine on your network. Second, it can block and redirect certain ports to limit the services that
outside users can access. To ensure that games and other Internet applications run properly, you
can open specific ports for outside users to access internal services on your network.
The Integrated DHCP (Dynamic Host Control Protocol) client and server services allow multiple
users to get IP addresses automatically when the router boots up. Simply set local machines as
a DHCP client to accept a dynamically assigned IP address from the DHCP server and reboot.
Each time a local machine is powered up; the router recognizes it and assigns an IP address to
instantly connect it to the LAN.
For advanced users, Virtual Service (port mapping) functions allow the product to provide limited
visibility to local machines with specific services for outside users. For instance, a dedicated web
server can be connected to the Internet via the router and then incoming requests for web pages
that are received by the router can be rerouted to your dedicated local web server, even though
the server now has a different IP address.
Virtual Server can also be used to re-task services to multiple servers. For instance, you can set the
router to allow separated FTP, Web, and Multiplayer game servers to share the same Internet-visible
IP address while still protecting the servers and LAN users from hackers.
1
Features
Express Internet Access
The router complies with ADSL worldwide standards. It supports downstream rate up to 12/24
Mbps with ADSL2/2+, 8Mbps with ADSL. Users enjoy not only high-speed ADSL services but also
broadband multimedia applications such as interactive gaming, video streaming and real-time audio
much easier and faster than ever. It is compliant with Multi-Mode standard (ANSI T1.413, Issue 2;
G.dmt (ITU G.992.1); G.lite (ITU G.992.2); G.hs (ITU G994.1); G.dmt.bis (ITU G.992.3); G.dmt.bis.
plus (ITU G.992.5)).
EWAN
Besides using ADSL to get connected to the Internet, BEC 7800 offers its Ethernet port 5 as a WAN
port to be used to connect to Cable Modems, VDSL, fiber optic lines and PON. This alternative, yet
faster method to connect to the internet will provide users more flexibility to get online.
Fast Ethernet Switch
A 4-port 1000Mbps fast Ethernet switch is built in with automatic switching between MDI and MDI-X.
An Ethernet straight or crossover cable can be used directly for auto detection.
Multi-Protocol to Establish a Connection
It supports PPPoA (RFC 2364 - PPP over ATM Adaptation Layer 5), RFC 1483 encapsulation
overATM (bridged or routed), PPP over Ethernet (RFC 2516), and IPoA (RFC1577) to establish a
connection with the ISP. The product also supports VC-based and LLC-based multiplexing.
PPP over Ethernet (PPPoE)
The BEC 7800 provides an embedded PPPoE client function to establish a connection. You get
greater access speed without changing the operation concept, while sharing the same ISP
account and paying for one access account. No PPPoE client software is required for the local
computer. Automatic Reconnect and Disconnect Timeout (Idle Timer) functions are also provided.
Universal Plug and Play (UPnP) and UPnP NAT Traversal
This protocol is used to enable simple and robust connectivity among stand-alone devices and PCs
from many different vendors. It makes network simple and affordable for users. UPnP architecture
leverages TCP/IP and the Web to enable seamless proximity networking in addition to control and
data transfer among networked devices. With this feature enabled, users can now connect to Net
meeting or MSN Messenger seamlessly.
Network Address Translation (NAT)
2
Allows multi-users to access outside resources such as the Internet simultaneously with one IP
address/one Internet access account. Many application layer gateway (ALG) are supported such as
web browser, ICQ, FTP, Telnet, E-mail, News, Net2phone, Ping, NetMeeting, IP phone and others.
Dynamic Domain Name System (DDNS)
The Dynamic DNS service allows you to alias a dynamic IP address to a static hostname. This
dynamic IP address is the WAN IP address. For example, to use the service, you must first apply
for an account from a DDNS service like http://www.dyndns.org/. More than 5 DDNS servers are
supported.
Virtual Server
Users can specify some services to be visible from outside users. The router can detect incoming
service requests and forward either a single port or a range of ports to the specific local computer
to handle it. For example, a user can assign a PC in the LAN acting as a WEB server inside and
expose it to the outside network. Outside users can browse inside web servers directly while it is
protected by NAT. A DMZ host setting is also provided to a local computer exposed to the outside
network, Internet.
Rich Packet Filtering
Not only filters the packet based on IP address, but also based on Port numbers. It will filter packets
from and to the Internet, and also provides a higher level of security control.
Dynamic Host Configuration Protocol (DHCP) Client and Server
In the WAN site, the DHCP client can get an IP address from the Internet Service Provider (ISP)
automatically. In the LAN site, the DHCP server can allocate a range of client IP addresses and
distribute them including IP address, subnet mask as well as DNS IP address to local computers. It
provides an easy way to manage the local IP network.
Web based GUI
It supports web based GUI for configuration and management. It is user-friendly and comes with online help. It also supports remote management capability for remote users to configure and manage
this product.
Firmware Upgradeable
Device can be upgraded to the latest firmware through the WEB based GUI.
3
Chapter 2: Installing the Router
Important note for using this router
4
Package Contents
BEC 7800 Dual WAN ADSL2+ Firewall Router
CD containing the online manual
RJ-11 ADSL/Telephone cable
Ethernet (RJ-45) cable
Power adapter
Quick Start Guide
Splitter / Microfilter (Optional)
5
L
it red when
W
AN port fails to get IP
address.
data is transmitted.
The Front LEDs.
LED
1
2
3
Internet
DSL
EWAN
Ethernet port
4
1X — 4X
(RJ-45 connector)
5
Power
Meaning
Flash green when WAN port gets IP address successfully and when
Lit Green when the device is successfully connected to an ADSL
DSLAM. (“line sync”).
Lit when connected to a broadband connection device.
Lit orange for 10/100Mbps.
Blinking when data is Transmitted / Received.
Lit when one of LAN ports is connected to an Ethernet device.
Lit green when the speed of transmission hits 1000Mbps; Lit orange
when the speed of transmission hits 10/100Mbps.
Blink when data is being Transmitted / Received.
When the power is plugged in, it will lit Red. When the system is
ready, it will lit Green. While the system is rebooting or during
firmware upgrade, the LED light will flash.
6
The Rear Ports
1 Power Switch
2 Power
3
RESET
4
Giga Ethernet
5
EWAN
6
DSL
Port
Power ON/OFF switch.
Connect it with the supplied power adapter.
Meaning
Press more than 1 second to restore the device to its default
mode.
Connect to a PC or an office/home network of 10Mbps,
100Mbps or 1000Mbps using the provided RJ-45 Ethernet
cables.
WAN 10/100Mbps Ethernet port (with auto crossover
support). Connect Cable Modem, VDSL, and Fiber Modem
or PON optic lines with your RJ-45 cable.
Connect this port to the ADSL/telephone network with the
RJ-11 cable (telephone) provided.
7
Cabling
One of the most common causes of problem is bad cabling or ADSL line(s). Make sure that all
connected devices are turned on. On the front panel of your router is a bank of LEDs. Verify that the
LAN Link and ADSL line LEDs are lit. If they are not, verify if you are using the proper cables.
Make sure that all devices (e.g. telephones, fax machines, analogue modems) connected to the same
telephone line as your router have a line filter connected between them and the wall outlet (unless
you are using a Central Splitter or Central Filter installed by a qualified and licensed electrician),
and that all line filters are correctly installed in a right way. If line filter is not installed and connected
properly, it may cause problem to your ADSL connection or may result in frequent disconnections.
8
Chapter 3: Basic Installation
The router can be configured through your web browser. A web browser is included as a standard
application in the following operating systems: Linux, Mac OS, Windows 98/NT/2000/XP/Me/Vista,
etc. The product provides an easy and user-friendly interface for configuration.
Please check your PC network components. The TCP/IP protocol stack and Ethernet network
adapter must be installed. If not, please refer to your Windows-related or other operating system
manuals.
There are ways to connect the router, either through an external repeater hub or connect directly to
your PCs. However, make sure that your PCs have an Ethernet interface installed properly prior to
connecting the router device. You ought to configure your PCs to obtain an IP address through a
DHCP server or a fixed IP address that must be in the same subnet as the router. The default IP
address of the router is 192.168.1.254 and the subnet mask is 255.255.255.0 (i.e. any attached PC
must be in the same subnet, and have an IP address in the range of 192.168.1.1 to 192.168.1.253).
The best and easiest way is to configure the PC to get an IP address automatically from the router
using DHCP. If you encounter any problem accessing the router web interface it is advisable to
uninstall your firewall program on your PCs, as they can cause problems accessing the IP address of
the router. Users should make their own decisions on what is best to protect their network.
Please follow the following steps to configure your PC network environment.
9
Connecting Your Router
Users will not be able to connect to the internet through EWAN if DSL is already connected to the
internet. Only one connection type (EWAN or DSL) is allowed to connect to the internet at one
time.
ADSL Router Mode
Broadband Router Mode
10
Network Configuration
Configuring PC in Windows Vista
1. Go to Start. Click on Network.
2. Then click on Network and Sharing
Center at the top bar.
3. When the Network and Sharing
Center window pops up, select and
click on Manage network connections on the left window column.
4. Select the Local Area Connection,
and right click the icon to select
Properties.
11
5. Select Internet Protocol Version 4
(TCP/IPv4) then click Properties.
6. In the TCP/IPv4 properties window,
select the Obtain an IP address automatically and Obtain DNS Server
address automatically radio buttons. Then click OK to exit the setting.
7. Click OK again in the Local Area
Connection Properties window to
apply the new configuration.
12
Configuring PC in Windows XP
1. Go to Start > Control Panel (in Classic
View). In the Control Panel, double-click
on Network Connections
2. Double-click Local Area Connection.
3. In the Local Area Connection Status
window, click Properties.
4. Select Internet Protocol (TCP/IP) and
click Properties.
5. Select the Obtain an IP address automatically and the Obtain DNS server
address automatically radio buttons.
6. Click OK to finish the configuration.
13
Configuring PC in Windows 2000
1. Go to Start > Settings > Control Panel.
In the Control Panel, double-click on
Network and Dial-up Connections.
2. Double-click Local Area Connection.
3. In the Local Area Connection Status
window click Properties.
4. Select Internet Protocol (TCP/IP) and
click Properties.
5. Select the Obtain an IP address automatically and the Obtain DNS server
address automatically radio buttons.
6. Click OK to finish the configuration.
14
Configuring PC in Windows 95/98/Me
1. Go to Start > Settings > Control Panel.
In the Control Panel, double-click on
Network and choose the Configuration
tab.
2. Select TCP/IP > NE2000 Compatible,
or the name of your Network Interface
Card (NIC) in your PC.
3. Select the Obtain an IP address automatically radio button.
4. Then select the DNS Configurationtab.
5. Select the Disable DNS radio button
and click OK to finish the configuration.
15
Configuring PC in Windows NT4.0
1. Go to Start > Settings > Control Panel.
In the Control Panel, double-click on
Network and choose the Protocols tab.
2. Select TCP/IP Protocol and click Properties.
3. Select the Obtain an IP address from
a DHCP server radio button and click
OK.
16
Factory Default Settings
Before configuring your router, you need to know the following default settings.
Web Interface (Username and Password)
Username: admin
Password: admin
The default username and password are “admin” and “admin” respectively.
Device LAN IP settings
IP Address: 192.168.1.254
Subnet Mask: 255.255.255.0
ISP setting in WAN site
PPPoE
DHCP server
DHCP server is enabled.
Start IP Address: 192.168.1.100
LAN and WAN Port Addresses
The parameters of LAN and WAN ports are pre-set in the factory. The default values are shown in
the tale.
IP address
Subnet Mask
DHCP server function
IP addresses for
distribution to PCs
IP pool counts: 100
LAN Port
192.168.1.254
255.255.255.0
Enabled
100 IP addresses continuing
from 192.168.1.100 through
192.168.1.199
WAN Port
The PPPoE function is
enabled to automatically get
the WAN port configuration
from the ISP.
17
Service
be
Information from your ISP
Before configuring this device, you have to check with your ISP (Internet Service Provider) to find
out what kind of service is provided such as DHCP (Obtain an IP Address Automatically, Static IP
(Fixed IP Address) or PPPoE.
Gather the information as illustrated in the following table and keep it for reference.
PPPoE(RFC2516)
VPI/VCI, VC / LLC-based multiplexing, Username, Password,
Name, and Domain Name System (DNS) IP address (it can
automatically assigned by your ISP when you connect or be set manually).
PPPoA(RFC2684)
MPoA(RFC1483/
RFC2684)
IPoA(RFC1577)
Pure Bridge
VPI/VCI, VC / LLC-based multiplexing, Username, Password and
Domain Name System (DNS) IP address (it can be automatically
assigned by your ISP when you connect or be set manually).
VPI/VCI, VC / LLC-based multiplexing, IP address, Subnet mask,
Gateway address, and Domain Name System (DNS) IP address (it is a
fixed IP address).
VPI/VCI, VC / LLC-based multiplexing, IP address, Subnet mask,
Gateway address, and Domain Name System (DNS) IP address (it is a
fixed IP address).
VPI/VCI, VC / LLC-based multiplexing to use Bridged Mode.
18
Chapter 4: Configuration
Open your web browser, enter the IP address of your router, which by default is 192.168.1.254, and
click “Go”, a login window prompt will appear. The default username and password are “admin” and
“admin” respectively.
Congratulations! You are now successfully logon to the BEC 7800 Firewall Router!
If the authentication succeeds, the homepage “Device Info - Summary” will appear on the screen.
19
Loading...
