Hello there,
Thanks for getting the BearDevil BLACK! You’ve done yourself a big favor. The BearDevil BLACK is the most advanced and durable mountable sports camera out there today, so get ready to roar!
This manual contains important information about your BearDevil; please read it carefully and then put it in a drawer somewhere.
|
Table of Contents |
|
|
06 |
What’s In This Devilishly Little Box? |
|
|
EN |
|||
08 |
Your BearDevil’s Anatomy |
||
|
09Setting Up Your BearDevil
10Charging the Battery (Refilling the Bearjuice)
10Turning Your BearDevil On and Off
11Setting the Date and Time
12Recording HD Video
12Taking Pictures
13Removing the Battery
13Going Under Water?
14LED Status Table
15Playback On Your Computer
15The Webcam Function
16Technical Specifications
What’s In This Devilishly
Little Box?
1The camcorder and a nifty water-resistant sound cap
2A base to... base your camcorder on a mount
3A universal mount, for all your universal mounting needs
4A handlebar mount, for mounting your camera on tube-shaped stuff
5A battery, providing your BearDevil with the bearjuice it needs to work
6Two stickers that you can stick to basically anything, except things like liquids
7A USB cable to charge the battery
8A handy hand safety strap
9This user manual
10A waterproof cap. Also beerproof.
11Six rubber O-rings: lay ‘em out and spell: O! O! O! O! O! O!
12Some delicious silicon grease (THAT’S A JOKE! DON’T EAT IT!)
Base
EN
Universal mount
Handlebar mount
06 |
07 |
Your BearDevil’s Anatomy
1 |
2 |
3 |
4 |
8 |
|
1 |
LED |
9 |
|
2 |
Power / Shutter |
||
|
|||
3 |
Rear Cap |
|
|
4 |
Mode Switch |
|
|
5 |
USB |
10 |
|
6 |
MicroSD Card Slot |
|
7Battery
8Microphone
9 |
1080P / 720P Mode Switch |
7 |
10 |
Stabilizer / Firmware |
|
5
6
Setting Up
Your BearDevil
1 |
If you’re using your BearDevil for the first time, you should charge |
EN |
|
the battery for at least ten hours.
2Make sure your BearDevil is turned off before inserting or removing a memory card.
3Screw off the rear cap at the back of your BearDevil.
4Insert an empty, formatted MicroSD memory card (up to 32GB, Class 6 or higher) into the rear slot with the label facing down. The MicroSD card will click into place when inserted correctly.
5Replace the rear cap.
6Boom! You’re ready to start recording your awesome life!
08 |
09 |
Charging the Battery |
Setting the |
(Refilling the Bearjuice) |
Date and Time |
Screw off the rear cap and plug the USB charger to the camera. A green light will show when your BearDevil is charging, and turn off when it’s done. If you’re charging the battery for the first time, let it charge for ten hours. A fully charged battery will allow for up to 90 minutes of recording time.
To set the correct time and date for your BearDevil, open a simple
text editor and write the date and time as follows: |
EN |
|
Turning Your BearDevil On and Off
We’ve equipped your BearDevil with a state-of-the-art “Power Button”. (It’s also the record button!) This button will allow you to take full control over whether your
BearDevil is in Roar Mode (“on”) or in Hibernation Mode (“off”). Push and hold the button for a couple of seconds and a blue LED will light up. Upon release of the button your BearDevil will vibrate once to let you know it’s ready for action.
To turn off your BearDevil, push and hold the Power Button until it vibrates twice.
YYYY-MM-DD hh:mm:ss
Save this file on your MicroSD memory card as “time.txt”, insert it into your BearDevil and turn it on.
Remember that, to make recordings, your BearDevil needs to have a MicroSD memory card (class 6 or higher) inserted.
10 |
11 |
Recording HD Video
To record HD video with your BearDevil, flick the Video/ Photo Switch to Video Mode and turn the BearDevil on. Shortly press the Power/Shutter Button to start and stop recording. The red light will flash while the BearDevil is
recording. Your BearDevil will vibrate once when the recording is starting and three times when it stops.
Taking Pictures
To take pictures with your BearDevil, flick the Video/ Photo Switch to Photo Mode and turn the BearDevil on. Shortly press the Power/Shutter Button to start and stop
taking photos. The BearDevil will take a photo every 3 seconds, the red light flashing to indicate it is doing so. Your BearDevil will vibrate once when the recording is starting and three times when it stops.
12
Removing the Battery
The battery in your BearDevil is designed to fit tightly in order to maximize reliability during rough activities. To remove the battery, pull it out with the battery holder.
It is intentionally not easy to do, but the battery will come out. Have faith! Additional batteries and accessories are available at
* www.BearDevil.com |
EN |
|
This guy represents your BearDevil Red
Going Under Water?
To keep your BearDevil waterproof, make sure the O-rings are always sufficiently greased with the silicon grease, and the rear cap is screwed on tight.
Rubber O-ring with silicon grease
This cow represents the Rear Cap
13
LED Status Table
Standby
Battery charging
Taking video
Taking photo
No micro SD card
Micro SD card fill up
Data transfer
Green LED
Off
On
Off
Off
Off
Off
Off
Red LED |
Blue LED |
Off |
On |
Off |
Off |
Flashing |
On |
Flashing |
On |
Asynchronous Flashing |
|
On |
On |
Off |
On |
Playback On Your Computer
To watch your footage on your computer, plug one end of the USB cable into the back of your BearDevil (after screwing off the rear cap) and the other end in
your computer’s USB port. The BearDevil will be automatically recognized. Alternatively, you can insert your MicroSD card into your computer’s
MicroSD card slot. |
EN |
|
Caution! Keep your BearDevil switched on and don’t remove the battery when downloading your data; it will upset the bear greatly! He could even take a bite out of your footage if he feels particularly malicious.
The Webcam Function
To use your BearDevil as a webcam (Windows OS only), download the driver from our website: www.BearDevil.com > Support
14 |
15 |
Technical
Specifications
Optics
*SUPER WIDE ANGLE view @1080p Mode
*FISHEYE view @720p Mode
*f/2.4, fixed focus glass lens
Video
*Full HD Resolution Settings: 1080p: 1920x 1080 @ 30fps
*HD Resolution Settings: 720p: 1280x 720 @ 60fps
*Digital Video Motion Stabilization Technology
*Sensor Sensitivity: 960mV/(Lux-sec)
*Video Format: H.264(avc1) / MOV
*Exposure Control: Auto
*White Balance: Auto
Audio
* Built-in microphone
*Resolution: 5296 x 3968
*Camera: 20.0 Mega Pixels
*Format: JPEG
*Capture mode: Auto snapshot every 3 seconds
Storage
* |
Memory: MicroSD card, up to 32GB capacity (not included) |
EN |
|
||
|
(recommended Class 6 or above) |
|
* Avg. Record Time: 10 min. / per GB
Dimensions
*Product size: 1.30 x 4.41 inch (33 x 112 mm)
*Weight: 3.67oz (104g) (without MicroSD card)
*Waterproof up to 10m (when using the waterproof cap)
Operating System (for USB drive)
*Microsoft Windows ME, 2000, XP, Vista, 7
*Mac OS X 10.6+
BearDevil® and the BearDevil logo are trademarks of BearDevil International, registered in Europe and other countries. All rights reserved. Specifications are subject to change without notice.
16 |
17 |
Hallo daar,
Bedankt voor het kiezen voor de BearDevil BLACK! Je hebt jezelf een groot plezier gedaan. De BearDevil BLACK is de meest geavanceerde
en duurzame sport camera die er is, ben je klaar om los te gaan?
Deze handleiding bevat belangrijke informatie over je BearDevil; lees het dus goed door en berg hem veilig op.
Inhoudsopgave
20 Wat zit er in dit duivelse doosje?
22De anatomie van je BearDevil
23Je BearDevil installeren
24 |
De batterij opladen |
NL |
|
24Je BearDevil aanen uitzetten
25Datum en tijd instellen
26HD Video opnemen
26Foto’s nemen
27De batterij verwijderen
27Ga je onder water?
28LED status overzicht
29Afspelen op je computer
29Je BearDevil als webcam gebruiken
30Technische specificaties
Wat Zit Er In Dit
Duivelse Doosje?
1De camera met een handige geluids-dop
2Een houder om je camera op een voet te houden
3Een universele voet, dat is altijd goed
4Een handlebar voet, om je camera goed te behandelen
5Een batterij, voorziet je BearDevil van de bearjuice die het nodig heeft om te werken
6Twee stickers die je op vrijwel alles kan plakken, behalve dingen zoals vloeistoffen
7Een USB kabel om je batterij mee op te laden
8Een veilig veiligheidskoord
9Deze handleiding
10Een waterdichte dop. Ook bierdicht
11Zes rubber O-ringen: leg ze neer en spel: O! O! O! O! O! O!
12Overheerlijk siliconen vet (GEINTJE! NIET OPETEN!)
Houder
NL
Universele voet
Handlebar voet
20 |
21 |
De Anatomie van Je BearDevil |
|
Je BearDevil |
|
1 |
2 |
3 |
Installeren |
1LED
2Aan/Uit
3Dop
4Opname modus
5 USB |
10 |
6MicroSD Card poort
7Batterij
8Microfoon
91080P/720P mode
10Stabilisatie / Firmware upgrade
1Als je je BearDevil voor de eerste keer gaat gebruiken, zorg dan dat je de batterij minimaal 10 uur hebt opgeladen.
NL
4 |
8 |
2 |
Zorg dat je BearDevil is uitgeschakeld voordat je een MicroSD kaart |
installeert of verwijdert.
9 |
3 |
Verwijder de dop aan de achterkant van je BearDevil. |
|
||
5 |
4 |
Installeer een lege, geformatteerde MicroSD kaart (tot 32GB, klasse 6 |
6 |
|
of hoger) in het MicroSD poort met de label naar beneden. De MicroSD |
|
kaart zal op zijn plaats klikken als deze goed wordt ingestoken. |
|
|
|
|
|
5 |
Plaats de dop terug. |
7 |
|
|
|
6 |
BOOM! Je bent klaar om je geweldige leven op te nemen! |
22 |
23 |
De Batterij Opladen |
Datum en Tijd Instellen |
Verwijder de dop en plug de USB kabel in de camera. Een groene LED laat zien dat je BearDevil aan het opladen
is. Als deze uit gaat is je batterij weer vol. Als je de batterij voor de eerste keer oplaadt, laat deze dan minimaal 10 uur doorladen. Een volledige volle batterij berekent dat je tot wel 90 minuten kan opnemen.
Je BearDevil Aan en Uitzetten
We hebben je BearDevil voorzien van een state-of-the-art “Aanen uitknop” (het is ook je opname knop!). Deze
knop zorgt ervoor dat je de volledige controle hebt over je BearDevil, of deze klaar is voor aanval (“aan”) of in zijn winterslaap is (“uit”). Druk de knop een aantal seconden in en een blauwe LED zal aan gaan. Na het loslaten van de knop zal je BearDevil twee maal trillen om je te laten weten dat hij klaar is voor actie!
Om je BearDevil uit te zetten druk je de knop in tot dat hij twee maal trilt.
Om de correcte datum en tijd op je BearDevil in te stellen open je een standaard tekstverwerker en schrijf je datum en tijd als volgt:
JJJJ-MM-DD uu:mm:ss |
NL |
|
|
Sla dit bestand op je MicroSD kaart op als “time.txt”, plaats die in je BearDevil en zet hem aan.
Houd er rekening mee dat je voor het opnemen van video
gebruik dient te maken van een MicroSD kaart (klasse 6 of hoger)
24 |
25 |
HD Video opnemen
Om video op te nemen met je BearDevil: zorg ervoor dat je een MicroSD kaart (klasse 6 of hoger) hebt
geïnstalleerd en zet de Video/Foto-knop op Video modus. Zet je BearDevil aan en druk kort op de knop om de
opname te starten of te stoppen. Een rode LED zal knipperen als je BearDevil aan het opnemen is. Je BearDevil zal één keer trillen als de opname start en drie keer als de opname stopt.
Foto’s nemen
Om foto’s te maken met je BearDevil: zorg ervoor dat je een MicroSD kaart (klasse 6 of hoger) hebt geïnstalleerd en zet de Video/Foto-knop op Foto modus. Zet je
BearDevil aan en druk kort op de knop om de foto opname te starten of te stoppen. Je BearDevil zal elke 3 seconden een foto nemen, een knipperende rode LED geeft aan dat er foto’s genomen worden. Je BearDevil zal één keer trillen als de opname start en drie keer als de opname stopt.
26
De batterij verwijderen
De batterij in je BearDevil is ontworpen om strak te zitten zodat de betrouwbaarheid niet in het geding komt bij het uitoefenen van de meest ruige activiteiten. Om de batterij
te verwijderen, trek aan de batterijhouder. Het is bewust lastig om te doen, |
|
maar de batterij komt er zeker uit. Maak je geen zorgen! |
|
Extra batterijen en accessoires zijn te krijgen via |
|
* www.BearDevil.com |
NL |
Deze gast stelt je BearDevil Red voor
Ga je onder water?
Om je BearDevil waterdicht te houden zorg je dat de rubber ringen altijd goed ingevet zijn en de dop goed dicht zit.
Rubber O-ring met siliconen vet
Deze koe stelt de waterdichte dop voor
27
