Page 1
User Manual
English
Bea-fon SL205
Page 2
2
General Information
Congratulations on the purchase of your Bea-fon SL205!
Please read this information before using the phone to
make a better use of your phone. We are not responsible
for any damage due to your misunderstanding of this
information and misacting.
We are endeavoring to improve our products and services.
We reserve all the rights to revise and change the
description of this product and its software as well as this
user’s manual without obligation to notify any person of
such revisions and changes.
This user manual is for your better use of this phone not an
approval of any accessories. All the pictures in this manual
are for reference only. There may be slight difference
between the appearance of phone/ keys/ contents of
display used in this manual and those of your phone. Please
refer to your phone for actuality. Some features introduced
in this manual are network or subscription-supported
features. Please contact your network operator for further
information.
Please check the package contents to ensure that all
components listed below are included. If the product is
defective or if there is a component missing, immediately
contact the retailer where you purchased this handset.
Page 3
3
General Information
Your Bea-fon SL205 box contains:
• 1 mobile phone (SL205)
• 1 desktop charger (SL205)
• 1 travel charger (SL205)
• 1 battery (SL205)
• User manuals (SL205)
If you find the size of the script not easily readable for you,
you can also find this manual on our website, where you
will be able to adjust the size of the script.
Go to: www.beafon.com
Device Code:
This device code ensures that unauthorized persons will not
be able to use your phone. The default code is 1234
PIN-Code:
The PIN-code was supplied to you by your network operator
together with your SIM card and/or adjusted/set up by
yourself.
Page 4
4
Directory
General Information ............................................................. 1
Device Code: .................................................................... 3
PIN-Code: ......................................................................... 3
Directory ............................................................................. 4
Your Phone ......................................................................... 8
Getting started ................................................................. 10
What is a SIM card? ....................................................... 10
Insert the SIM card and Micro SD card as follows: ......... 10
Insert the battery as follows: ......................................... 11
Charging the battery: ...................................................... 11
Switching the telephone on or off:.................................. 12
To lock the handset keypad ............................................ 13
Standby: ......................................................................... 13
Display (Standby mode): ................................................ 14
Screen icons:................................................................... 14
Menu Operation .............................................................. 16
Connect an optional headset ........................................... 17
Call function .......................................................................18
Make a call: ....................................................................18
Make a call using the phone book: ..................................18
Answering a call: ............................................................ 19
Operations during a call: ................................................. 19
Hands Free: ..................................................................... 19
Menu ................................................................................. 20
Phonebook ......................................................................... 21
To access the phonebook: ............................................... 21
Add new contact: ............................................................ 21
To edit (change) a Phone Book entry: ............................. 21
To delete all entries from the phone or SIM card ........... 22
Page 5
5
Directory
To copy all entries from the phone or SIM card ............. 22
Store a Phonebook entry to a Speed dial key (2-9) ....... 22
Messages .......................................................................... 23
Write SMS ...................................................................... 23
Inbox: ............................................................................ 24
Write messages ........ Fehler! Textmarke nicht definiert.
Outbox: .......................................................................... 25
Drafts: ........................................................................... 24
Write MMS ................ Fehler! Textmarke nicht definiert.
Voice mail: ..................................................................... 25
Message Settings ..... Fehler! Textmarke nicht definiert.
SMS ............................................................................... 25
MMS ......................... Fehler! Textmarke nicht definiert.
Data account: ............ Fehler! Textmarke nicht definiert.
MMS settings: ........... Fehler! Textmarke nicht definiert.
Call center ......................................................................... 27
Call history .................................................................... 27
Missed Dialled, , and Received: ...................................... 27
Delete call logs: ............................................................. 27
Call settings: .................................................................. 27
Organizer .......................................................................... 29
Alarm: ............................................................................ 29
Tasks ............................................................................. 29
Calendar: ....................................................................... 30
Calculator: ..................................................................... 30
Stopwatch: ..................................................................... 30
File Manager: ................................................................. 30
Camera ......................... Fehler! Textmarke nicht definiert.
Take a picture: .......... Fehler! Textmarke nicht definiert.
Page 6
6
Directory
Image viewer: ........... Fehler! Textmarke nicht definiert.
Settings ............................................................................. 31
Tone settings: ................................................................. 31
Display: ........................................................................... 31
Time and date: ................................................................ 31
Direct Number: ............................................................... 31
SOS ................................................................................. 31
SOS description: ............................................................ 32
SOS setting: ................................................................... 34
Language: ................. Fehler! Textmarke nicht definiert.
Pref. Input method: .. Fehler! Textmarke nicht definiert.
Connectivity: .................................................................. 35
Bluetooth: ...................................................................... 35
Data account ............. Fehler! Textmarke nicht definiert.
Network settings: .......................................................... 34
Security settings:...... Fehler! Textmarke nicht definiert.
Restore factory settings: ............................................... 36
Basic Specifications: ...................................................... 36
FAQ ................................................................................... 37
Battery .............................................................................. 39
Phone ................................................................................ 40
For your safety.................................................................. 42
Traffic Safety: ................................................................ 43
Operating environment: ................................................. 43
Electronic devices: ......................................................... 43
Pacemakers: .................................................................. 43
Hearing aids: .................................................................. 44
Other medical devices: .................................................. 44
Posted facilities: ............................................................ 44
Page 7
7
Directory
Vehicles: ........................................................................ 45
Certification information (SAR): .................................... 46
Information ....................................................................... 47
Liability Disclaimer: ....................................................... 47
Information: .................................................................. 47
Address: ........................................................................ 47
Page 8
8
Your Phone
1
Headset
2
Keylock
3
Torch key
4
Volumen key
5
Arrow key (up)
On the starting screen this button takes you to the Message
menu.
6
Menu key (left).
On the starting screen, this button takes you to the main
menu.
7
Dial key
Green button on the starting screen, this button takes you to
the call list.
Page 9
9
Your Phone
8
* Key
Press this button on the starting screen to enter the following
symbols : * /+ /P / W.
9
Torch (Power LED light)
10
Loudspeaker
11
Menu key (right).
On the starting screen this button takes you to the
Phonebook.
12
On/Off button
Hang-up button
Ends a call or rejects an incoming call.
13
Direct dialing numbers (M1,M2,M3)
14
Arrow key (down)
On the starting screen this button takes you to the Bluetooth
menu
15
# Key
On the starting screen, by holding this button you activate /
deactivate silent mode. In edit mode, change the input
method.
16
Cradle port
17
SOS button
18
Polyphone speaker
19
Charger port
Page 10
10
Getting started
What is a SIM card?
Every mobile phone has a SIM card (Subscriber Identity
Module). This is a micro-chip that holds your personal
information such as names and phone numbers. Your phone
won’t work without it. If you already have contacts on your
SIM card, they can be transferred in most cases.
Keep the SIM card away from children. The SIM card can
easily be damaged or bent. You should therefore handle the
SIM card with care during installation and/or removal.
Insert the SIM card and Micro SD card as
follows:
1. Make sure that the phone is switched off and the
charger is disconnected from the phone.
2. Turn the phone over and remove the battery cover.
3. If the battery is already inside, remove it.
4. You can see two card slots (upside: SIM, downside:
Micro SD).
5. Slide the SIM card carefully into the SIM card slot. Make
sure that the gold-colored connectors on the SIM card
are facing downwards and that the beveled corner is on
the right.
6. Memory Card: Slide the Micro SD card into the Micro SD
card slot.
Page 11
11
Getting started
Insert the battery as follows:
1. Insert the battery by aligning the gold contacts in the
battery compartment on the phone.
2. Push down on the upper section of the battery until it
'clicks' into place.
3. Close the battery compartment by sliding the cover
closed until you hear a ‘click’.
Charging the battery:
There are two ways of SL215 battery charging:
A. Desktop charging
B. Travel charging
The lithium battery of the mobile phone can be
immediately used after unpacking. A new battery, is not
fully charged, and performs best after performing a full
charge/discharge 3 times:
1. Plug the charger into the charger connector.
2. Plug the other end into an electrical outlet.
Page 12
12
Getting started
3. The phone may need several hours for reaching a fully
charge.
When your phone is power off, it might take a few
seconds to show charging display and it shows charge
complete when finished.
When your phone is power on, the battery icon flickers
when it starting charging and become still with full bars
in battery icon when finished.
4. The battery is fully charged when “Charger finish”
displays on. Disconnect the charger from the phone and
the AC outlet.
Note: Charge the battery for at least 12 hours before using the
phone for the first time.
Switching the telephone on or off:
Make sure that you SIM card is in your mobile phone and
that the battery is charged.
1. Press the red key to switch the phone on.
2. If prompted, choose your language and press OK.
3. If you have entered a PIN-code before, the phone will
ask for the code now. Enter the PIN-code and confirm by
pressing OK.
4. To turn off your phone, press and hold the red key for
two seconds.
If you don’t insert a SIM card, your phone shows Insert SIM.
None of the functions related to SIM
Card can be used. You can make an emergency call only.
Page 13
13
Getting started
Note: If you enter an incorrect PIN-code 3 times in succession, the
phone will require you to enter the PUK-code. You received this
PUK-code together with your SIM card.
To lock the handset keypad
In the idle screen, press End Key
to enter the locked state. On the locked state, press End
Key to bright the phone, and press to unlock.
Note:
When the keypad is locked, you can answer, end or reject a
call in the normal way, and use the emergency SOS button or dial
the European emergency services number 112. During a call, you
can operate the phone as usual.
Standby:
The phone will be activated again by
pressing any key. Calls can be
received as usual while in standby
mode.
Page 14
14
Getting started
Display (Standby mode):
1 2 3
4
5
6
7 8 9
1. Signal status 5. Time
2. Pictograms 6. Date and day
3. Battery status 7. Menu
4. Network operator 8. SMS
9. Names
Screen icons:
Signal Strength
The vertical bars show the network connection
strength. SIM card has signals.
New messages
This icon shows when you receive a new
message.
SIM Card has an unread message
The inbox is full.
This icon flickers when the inbox is full and you
need to delete messages to receive new
messages.
Page 15
15
Getting started
Earphone
This icon shows when you plug the earphone
in. Voice will be heard from the earphone.
Missed Calls
This icon shows when you are viewing the
missed call. SIM card has a missed call.
Alert Type
Ring
Silent mode on and Vibration only
Vibrate and ring
Call Divert
This icon shows when you divert all calls
unconditionally. SIM card has been set up call
divert.
GPRS
This icon shows when the GPRS connection is
available or active.
Turn alarm on
This icon shows when you turn alarm on.
Roaming
This icon shows when your phone is in roaming
state. SIM card is roaming.
Bluetooth
This icon shows when the Bluetooth is active.
Page 16
16
Getting started
Battery capacity
This icon’s color changes according to the
status of battery capacity: , , ,
Menu Operation
Menu lists are used for set up and operation.
The left and right soft keys initially are Menu ( ) and
Phonebook( ). (Note: symbols not displayed if the
analogue style clock is set for idle mode.)
Press Menu ( )and the display changes and the soft keys
become OK and Back.
Use Up or Down to move up or down menu lists, and Select
or Back for the next or previous display.
When writing text, use the # key to switch cases:
Upper case (ABC), Lower case (abc) or Numerals (123). Use
Up or Down to move the cursor,
Clear to delete letters and the * key for
symbols/punctuation.
Page 17
17
Getting started
Connect an optional headset
You can use a headset (not supplied) with the 3.5 mm type,
plugged into the Headset socket on the top side of the
handset.
When using headsets, including Binatone approved ones,
pay attention to volume levels and read its user guide for
safety instructions. Do not connect incompatible products.
When correctly inserted the headset icon is shown.
Headset Connector:
Plug in headset accessory for headset use.
Page 18
18
Call function
Make a call:
1. To make a call, enter the phone number with the prefix
and press the green key. For international calls, enter
‘+’ by pressing for 2 sec. Then enter the country code
followed by the telephone number, in which the 0 of the
prefix must be dropped.
2. If you have entered a wrong number, press the soft key
‘right’ Clear to remove the number to the left of the
blinking cursor.
3. Press the green key to call the number.
4. Press the red key to end the call or to cancel the call
attempt.
Make a call using the phone book:
If you have saved a name and number in the phone book,
you can also use the phonebook to make a call.
In standby mode, press the soft key ‘right’ to go to
Phonebook.
1. Scroll with the up and down arrow key to the name you
want to call.
2. Press the green key to call the number.
3. Press the red key to end the call or to cancel the call
attempt.
Page 19
19
Call function
Answering a call:
When there is an incoming call, the phone rings and/or
vibrates and shows the number or the corresponding name.
1. Press the green key or Answer if you would like to
answer a call.
2. Press the red key or silent if you would like to reject a
call, or for ending the connection after the call.
Earphone/Bluetooth Mode): When plugging the earphone
(including Bluetooth earphone), you can answer a call by
pressing the key on the earphone.
Operations during a call:
Press the right Menu key for Hands free
Press left Menu key “Options” to perform following
operation during a call:
Hold: Hold this call.
End single Call: End this Call.
New Call: To dial the number
Phonebook: To go to Phonebook.
Message: To go to Messages.
Mute: de/activate the microphone
DTMF: de/activate the DTMF tone
Hands Free:
During a call you can turn the hands free equipment on
(Loudspeaker on).or off with the right Menu key.
Page 20
20
Menu
Press the up arrow key to go to the Menu. Scroll through
the menu using the arrow keys.
1. Phonebook
2. Message
1. Write SMS
2. Inbox
3. Drafts
4. Outbox
5. Sent messages
6. SMS settings
7. Voice Mail server
3. Call center
1. Call history
2. Call settings
4. Organizer
1. Alarm
2. Tasks
3. Calculator
4. Calendar
5. Stopwatch
6. File Manager
5. Settings
1. Tone settings
2. Phone settings
3. Direct Number
4. SOS setting
5. Network settings
6. Security settings
7. Bluetooth
8. Restore factory setting
Page 21
21
Phonebook
You can store names and phone numbers in the Internal
phone book (up to300) and in the SIM phone book (SIM
dependent, but a maximum of 200).
To access the phonebook:
In idle mode, press Right soft key.
In idle mode, press Left soft key, Phonebook and press OK
Note
:
Indicates entries in SIM phone book,
Indicates entries in the internal phone book.
Add new contact:
1. Press left soft key next press Down to open the
phonebook and select Add new contact.
2. Select Preferred storage, To SIM or To Phone, If you
choose To phone: you can edit Name, Number and
Associate ringtone. This ringtone you hear when you
receive a call from this contact.
3. Press Options and Save if you want to save the contact.
To edit (change) a Phone Book entry:
1. Press Right soft key to phone book search which one
You want to change, press Left soft key select Edit then
modify the name, press Down modify the number.
2. Press Option and OK to save the change(s).
Page 22
22
Phonebook
To delete all entries from the phone or SIM card
1. Select Menu, Phonebook and press Left soft key.
2. Press Options and select Phonebook settings and press
Left soft key
3. Select Delete all Contacts and press Left soft key
4. Select From Phone or From SIM Delete all
5. Press OK again to confirm
To copy all entries from the phone or SIM card
1. Select Menu, Phonebook and press Left soft key.
2. Press Options and select Phonebook settings and press
Left soft key
3. Select Copy Contacts and press Left soft key
4. Select From Phone or From SIM To SIM/Phone
5. Press OK again to confirm
Store a Phonebook entry to a Speed dial key (2-9)
1. Select Menu, Phonebook and press Left soft key.
2. Press Options and select Phonebook settings and press
Left soft key
3. Select Speed dial and Press OK
4. Set Status to On, press down to Set numbers.
5. Press OK the display shows ,2-9
6. Press Up or Down to choose the key to save to
7. Press OK to confirm the memory entry.
Page 23
23
Messages
You can receive and send SMS. Here you can also choose
Voice Mail and Broadcast. These services are web-based
services. Please contact your network operator before
using.
Write SMS
You can write and send text messages. Invoicing is based
upon how many ordinary messages are needed for any
multi-part message.
Press the key marked with the letter that you want
repeatedly until the letter appears.
1. Press left soft key to enter Write SMS
2. Enter contents and press left soft key to enter Options.
(You can select Send to, Input Method, Advanced:
(Insert number and name) and Save to Draft.
3. Press left soft key, select Send to and press left soft key
again.
4. Select Enter Number or Add from Phonebook.
5. Select telephone numbers.
6. Press left soft key to enter Options and press left soft
key to Send
Page 24
24
Messages
Inbox:
The Inbox is for storing received SMS messages. Depending
on the selected mode, the phone vibrates or rings when you
receive a new message. And in the standby mode you see
this icon until you have read the new SMS message.
You can choose the following options while reading your
received SMS:
View, Reply, Forward, Delete, Delete all, Save to Phonebook
in the Advanced option: Copy to Phone* Move to Phone*,
Copy all and Move all.
*These options may not appear according to the storage location.
Note: The new message icon keeps flickering in the standby mode
when your inbox is full. Please delete some messages for receiving
new messages.
Drafts:
By Drafts you can view the draft SMS messages you have
saved.
You can choose the following options while reading your
draft:
In the Advanced option: Copy to Phone* Move to Phone*,
Copy all and Move all.
Page 25
25
Messages
Outbox:
The Outbox to view the messages you don’t sent but saved.
You can choose the following options while reading you’re
sent SMS:
View, Resend, Edit, Delete, Message status and Advanced.
Sent messages
Here you can see the messages which you have sent.
SMS Settings
You can choose the following options:
SIM: This setting is needed to use the SMS
function. The SMSC number can be
obtained
Memory Status:
Check the capacity of messages
storages.
Save sent message: Select Off or On to save the sent
messages
Preferred storage: Select SIM or Phone to store messages
Broadcast: Broadcast messages are messages that
your network operator broadcasts to all
users within a particular area, such as
weather forecast and transportation
conditions. The new broadcast message
covers the old one if they are from the
same channel.
Page 26
26
Messages
Voice mail:
Voicemail is a service supplied by your network operator.
For more information and for the voice mailbox number,
contact your network operator. When you have a new voice
mail message, your phone will receive a message.
The phone offers you 2 voice mail addresses.
1. Select address 1 or 2 and press Option.
2. Choose Call or Edit.
3. If you choose Edit, edit the name and number of the
voice mail. After enter the number press OK.
In standby mode: Press and hold key number 1 for directly
calling the Voice mail. Only the number saved under voice
mail address 1 is called.
Compose: Here you can compose the
Creation mode, Auto signature and
Signature of your MMS.
Page 27
27
Call center
Call history
Missed, Dialled, and Received:
The phone registers the phone numbers of Missed,
Received, Dialled and All calls.
When you press OK by Missed, Dialled or Received, you can
view the calls you Missed, Dialled or Received. If you press
Option you can choose the following options:
Call, View, Sent text message, Save to Phonebook, Delete,
and Edit before call.
Delete call logs:
You can delete all the records of the Dialled, Missed and
Received calls, you can also choose delete All calls to delete
all the records of the above-mentioned calls logs.
Call settings:
Depending on network operator support and subscription,
you can choose the following options:
Caller ID: Some functions require support from the
network operator. Such functions are Set
by network, Hide ID and Send ID.
Call waiting: When this network service is activated, the
network notifies you of a new incoming call
while you have a call in progress. Press OK
to answer the waiting call. The first call is
Page 28
28
Call center
put on hold or press the red key to reject
the call.
Call divert: To divert your incoming calls to your voice
mailbox or some other phone number
(network service). Select the divert option
you want. Several divert options may be
active at the same time.
Call barring: With this network service you can restrict
the making and receiving of calls with your
phone.
Call time reminder:
Choose to remind you Periodic (30-60
seconds) or select Single (1-3000 Seconds)
or select Off.
Answer Mode: If Any Key is selected, you can press any
key to answer a call.
If Auto answer when headset mode
selected, the phone answer the call
automatically.
Page 29
29
Organizer
Alarm:
You can set a maximum of 5 different alarms.
To set an alarm clock:
1. Select one alarm and press Edit.
2. Edit alarm: set On or Off (M1/M3 key), Time, Repeat,
alarm tone, and Alert type.
3. Press Save to save the Alarm.
When alarm sounds, you can stop the alarm by pressing
Stop. If you press Snooze, the alarm stops and rings after
10 minutes again.
Tasks
If there are some existed event in the task list, press the
up / down key to select an event to get into the options:
View, Add, Edit, Delete, Delete overdue, Delete all, Jump do
date, View uncompleted, Send vCalendar and Save as file.
Calculator:
The phone is provided with a calculator. This calculator has
limited accuracy and rounding errors may occur, especially
in long divisions.
Function:
The keys 1 to 0 insert a digit.
To insert a decimal, press #.
Press the up and down arrow key for +, -
Press M1, M2 and M3 key for x, =, ÷.
Page 30
30
Organizer
To get the result, press OK. Press and hold Clear to clear
the display for a new calculation.
Calendar:
Enter submenu of Calendar and you can see the interface of
date.
Press the direction keys to select date and month; press
Options
to access submenus:
View, View all, Add event,
Delete event, Jump to date
and
Go to today.
Stopwatch:
Typical stopwatch
This menu allows you to use the phone as a stopwatch. You
can check a maximum of 9 intervals.
Split/Lap timing
1. Press the Start soft key to start the stopwatch.
2. Press the
Split/Lap
soft key to check an interval.
3. Repeat this step as desired.
4. When you finish, press the
Stop
soft key.
5. To reset the stopwatch, press
Options
, Reset.
File Manager:
Here you can View all your file in Memory card or Format
your Memory card.
Page 31
31
Settings
Tone settings:
You can choose the following options:
Incoming call, Ringtone volume, Message tone, Message
volume, Alarm tone, Alarm volume, Keypad
tone, Keypad volume, Power on, Power off,
System alert, alert type and Ring type.
Phone settings:
Time and date: Set time and date
Language: Here you can choose the language you
want in your display.
Pref. Input method:Here you can choose the Input method
you want for write.
Display: Here can set your Wallpaper
LCD backlight: Here can you set the Brightness and
Time
Direct Number:
Add M1, M2, M3 direct numbers
SOS settings
The SOS function is a simple function which can save lives
at the deciding moment. In all, you can save 5 SOS numbers
(relatives, neighbors, friends and rescue). These numbers,
previously saved in order of sequence, will be automatically
Page 32
32
Settings
dialled in an SOS by pressing the
SOS button
on the back of
the mobile phone. During the SOS call, a warning tone
sounds so the person that you rang knows that it is an
emergency! If you cannot get through on the first number,
the second number will be called automatically.
If no emergency number is saved or your phone card has
run out, or you are not allowed under a foreign network
(e.g. Roaming not activated), you can dial 112 or another
emergency number on the numerical keypad.
SOS description:
Press the SOS button on the back of the mobile phone for 3
seconds. If you want to stop or cancel the SOS call, press
the SOS button again.
Functionality:
By pressing the SOS button, the SL205 will send an SOS
SMS person (in case mobile number or telephones with
SMS function is available for emergency contact) to the
emergency numbers you have previously saved and will be
automatically dialled in the given sequence. (The SOS
button also functions when the key lock is on). The mobile
phone switches on the hands free function at full volume
and at the same time, if the call answered, the prerecorded voice will be heard first, the content is as follows
“This is an emergency call, accept this call press 0”.
Page 33
33
Settings
The conversation will begin after pressing 0; otherwise, it
will hang up automatically in 30 seconds; and then begin to
dial the next number, until each number has been dialed for
2 times.
Note:
If you want to stop or cancel the SOS call, press the
right menu key.
If answered the call the recipient have to press the key
‘0’ within 30 seconds. After that the next number will
be called automatically.
As a rule, the international emergency call 112 can still
be called outside of the regional network of your
network operator.
When changing a phone card: Always make sure that
there is sufficient credit on your phone card because
private emergency numbers cannot be dialled without
sufficient credit.
Attention: If you want to save SOS numbers such as the ambulance
service, the police, fire brigade etc. as an SOS number, you must
gain permission from each of these institutions beforehand. There
will be no liability for possible costs arising from calling them by
accident.
Page 34
34
Settings
SOS setting:
SOS Mode settings: Set On or Off the SOS function.
Set SOS numbers:
There you can edit and save at most
five SOS number in your phone.
SOS message:
Edit the content of the SOS message
which will be sent out automatically
when the SOS function is using.
Network settings:
This menu has connection with the network suppliers, so
please get in touch with them when you use this function.
If you want to get into one network which doesn’t have the
roaming protocol with the original network you have been
in, the phone will display the content that you can make an
emergency call.
Network selection:
Depending on network operator support , you can choose
the following options: New search, and Select Network,
Selection mode.
Page 35
35
Settings
Security settings:
You can choose the following options:
SIM security: To turn your SIM PIN code On or Off,
change PIN and change PIN2.
Phone lock: To lock your phone with a password.
The default password is: 1234.
Change password: Here you can change your password of:
Phone password.
Bluetooth:
In standby mode: Press the down arrow key to go directly
to Bluetooth.
You can choose the following options:
Power: Here you can choose to turn
Bluetooth On or Off.
Visibility:
you can set the visibility
on
or
off
.
My device: List of saved devices and enables
you to add new devices; Search new
device.
Search audio device: Search for available Bluetooth audio
devices. If Bluetooth is not enabled
you can enable it now by pressing
Yes.
Page 36
36
Settings
Search audio device:
1. Press OK, the phone is going to search for new devices.
2. Select the devices you want to connect with and press
Pair.
3. When connecting with another Bluetooth device you
need a shared passcode. Enter the passcode and press
OK.
4. Select the device from the list and press Option. Can
choose the following options: Connect, Rename, Delete
and Delete all.
My Name: Here you can set the Bluetooth
device Name.
Advanced: Here you can set your: Audio path,
and check the My address.
Restore factory settings:
To reset some of the menu settings to their original values.
The password is: 1234.
Basic Specifications:
Network – Dual-Band：GSM 900/DCS1800
Dimension：118x54,8x12,5mm
Battery：Li-ion 3.7V - 1200mAh
Standby time: <320 hours*
Talk time: <420 minutes*
*Variation in operation times may occur depending on SIM
card, network, and usage settings, usage style and
environments.
Page 37
37
FAQ
If your phone appears the questions frequently, please
refer to the answers as follows. After that, you cannot
solve the questions, please contact with the mobile phone
dealers or network operator.
Can’t turn the phone on:
Check battery installation, please install battery
correctly.
Check if battery level is low, change a battery or charge
the battery.
Check if entered incorrect PIN code 3 times in a row.
If yes, the phone is locked, then you should enter your
PUK code (please contact your network operator for
your PUK code).
SIM error:
Is the SIM card dirty? Please clean it.
Try and reinstall the SIM card.
Is the SIM card damaged? Please contact your network
operator.
Weak signal or no signal:
You may be in a location where the reception is bad,
such as tunnel or cellar, please relocate and try again.
You can try turning around slightly or get near the
window if you are in a room.
Please contact your network operator, if you still have a
weak signal or no signal.
Page 38
38
FAQ
Bad talking quality:
Weak signal? See: Weak signal or no signal.
Check if battery if battery is low. Charge the battery or
change the battery.
Use the up volume key to adjust the microphone volume
during a call.
Can’t make a call:
Check if you enter the correct number and press green
key.
Check if you set call barring, if yes, please cancel it.
Check if the SIM card is registered in the network.
If your SIM card is a prepaid card, please make sure
there is enough money on the card.
Can’t receive calls:
Is the SIM card registered in the network?
Check if your phone is turned on.
Check if screens shows no signal, if yes, see: Weak
signal or no signal.
Check if you set call barring, if yes, please cancel it.
Screen is dark:
Check if battery if battery is low. Charge the battery or
change the battery.
Adjust the wallpaper.
Your phone may be affected with damp, keep it dry.
Page 39
39
FAQ
PIN locked:
Check if entered incorrect PIN code 3 times in a row.
If yes, the phone is locked, then you should enter your
PUK code (please contact your network operator for
your PUK code).
Tips: if all suggests and solutions can’t solve your problem, please
check Customer Service on www.beafon.com. Please do not
disassembly or repair your phone without professional guide.
Battery
Your phone is powered by a rechargeable battery.
Note that a new battery's full performance is achieved only
after two or three complete charge and discharge cycles! The
battery can be charged and discharged hundreds of times but it
will eventually wear out.
When the operating time (talk-time and standby time) is
noticeably shorter than normal, it is time to buy a new battery.
Use only batteries approved by the phone manufacturer and
recharge your battery only with the chargers approved by the
manufacturer.
Unplug the charger when not in use. Do not leave the battery
connected to a charger for longer than 10 days, since
overcharging may shorten its lifetime. If left unused a fully
charged battery will discharge itself over time.
Temperature extremes can affect the ability of your battery to
charge.
Use the battery only for its intended purpose.
Never use any charger or battery which is damaged.
Page 40
40
Do not short-circuit the battery. Accidental short-circuiting can
occur when a metallic object (coin, clip or pen) causes direct
connection of the + and - terminals of the battery (metal strips
on the battery) for example when you carry a spare battery in
your pocket or purse. Short-circuiting the terminals may
damage the battery or the connecting object.
Leaving the battery in hot or cold places, such as in a closed car
in summer or winter conditions, will reduce the capacity and
lifetime of the battery. Always try to keep the battery between
15°C and 25°C. A phone with a hot or cold battery may
temporarily not work, even when the battery is fully charged.
Batteries performance is particularly limited in temperatures
well below freezing.
Do not dispose of batteries in a fire!
Dispose of batteries according to local regulations (e.g.
recycling).
Do not dispose as household waste.
Do not charge your mobile phone if the battery is not
installed.
Phone
Your phone is a product of superior design and craftsmanship and
should be treated with care.
The suggestions below will help you to fulfil any warranty
obligations and to enjoy this product for many years.
Keep the phone and all its parts and accessories out of the
reach of small children.
Keep the phone dry. Precipitation, humidity and all types of
liquids or moisture can contain minerals that will corrode
electronic circuits.
Do not use or store the phone in dusty, dirty areas. Its moving
parts can be damaged.
Page 41
41
Phone
Do not store the phone in hot areas. High temperatures can
shorten the life of electronic devices, damage batteries, and
warp or melt certain plastics.
Do not store the phone in cold areas. When it warms up (to its
normal temperature), moisture can form inside, which may
damage electronic circuit boards.
Do not attempt to open the phone. Non-expert handling may
damage it.
Do not drop, knock or shake the phone. Rough handling can
break internal circuit boards.
Do not use harsh chemicals, cleaning solvents, or strong
detergents to clean the phone. Do not paint the phone.
Paint can clog the moving parts and prevent proper
operation.
Use only the supplied or an approved replacement
antenna. Unauthorised antennas, modifications or
attachments could damage the
phone and may violate regulations governing radio
devices.
All of the above suggestions apply equally to your phone,
battery, charger or any accessory. If any of them is not
working properly, take it to your nearest qualified service
facility.
Page 42
42
For your safety
Read these simple guidelines. Breaking the rules may be
dangerous or illegal.
Do not switch on the phone when wireless phone
use is prohibited or when it may cause
interference or danger.
Road safety comes first
Do not use a hand-held phone while driving.
Switch off in aircraft
Wireless devices can cause interference in
aircraft.
Switch off in hospitals
Follow any regulations or rules. Switch the phone
off near medical equipment.
Switch off when refuelling
Do not use the phone at a refuelling point. Do not
use near fuel or chemicals.
Interference
All wireless phones may get interference, which
could affect performance.
Page 43
43
For your safety
Traffic Safety:
Do not use a hand-held telephone while driving a vehicle. Always
secure the phone in its holder; do not place the phone on the
passenger seat or where it can break loose in a collision or sudden
stop. Remember road safety always comes first!
Operating environment:
Remember to follow any special regulations in force in any area
and always switch off your phone whenever it is forbidden to use
it, or when it may cause interference or danger.
Use the phone only in its normal operating positions.
Parts of the phone are magnetic. Metallic materials may be
attracted to the phone, and persons with a hearing aid should not
hold the phone to the ear with the hearing aid. Always secure the
phone in its holder, because metallic materials may be attracted by
the earpiece.
Do not place credit cards or other magnetic storage media near the
phone, because information stored on them may be erased.
Electronic devices:
Most modern electronic equipment is shielded from radio
frequency (RF) signals. However, certain electronic equipment may
not be shielded against the RF signals from your wireless phone.
Pacemakers:
Pacemaker manufacturers recommend that a minimum separation
of 20 cm (6 inches) be maintained between a handheld wireless
phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with the
independent
Page 44
44
For your safety
research by and recommendations of Wireless Technology
Research.
Persons with pacemakers:
Should always keep the phone more than 20 cm (6 inches)
from their pacemaker when the phone is switched on.
Should not carry the phone in a breast pocket.
Should use the ear opposite the pacemaker to minimise the
potential for interference.
If you have any reason to suspect that interference is taking
place, switch off your phone immediately.
Hearing aids:
Some digital wireless phones may interfere with some hearing
aids. In the event of such interference, you may want to consult
your network operator.
Other medical devices:
Operation of any radio transmitting equipment, including cellular
phones, may interfere with the functionality of inadequately
protected medical devices. Consult a physician or the manufacturer
of the medical device to determine if they are adequately shielded
from external RF energy or if you have any questions. Switch off
your phone in health care facilities when any regulations posted in
these areas instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to external RF
energy.
Posted facilities:
Switch your phone off in any facility where posted notices so
require.
Page 45
45
For your safety
Potentially explosive atmospheres:
Switch off your phone when in any area with a potentially
explosive atmosphere and obey all signs and instructions. Sparks
in such areas could cause an explosion or fire resulting in bodily
injury or even death.
Users are advised to switch off the phone when at a refuelling
point (service station). Users are reminded of the need to observe
restrictions on the use of radio equipment in fuel depots (fuel
storage and distribution areas), chemical plants or where blasting
operations are in progress.
Areas with a potentially explosive atmosphere are often but not
always clearly marked. They include below deck on boats; chemical
transfer or storage facilities; vehicles using liquefied petroleum
gas (such as propane or butane); areas where the air contains
chemicals or particles, such as grain, dust or metal powders; and
any other area where you would normally be advised to turn off
your vehicle engine.
Vehicles:
RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles (e.g. electronic fuel injection
systems, electronic anti-skid (anti-lock) braking systems,
electronic speed control systems, air bag systems). Check with the
manufacturer or its representative regarding your vehicle. You
should also consult the manufacturer of any equipment that has
been added to your vehicle.
Page 46
46
For your safety
Certification information (SAR):
This model phone meets the EU requirements for exposure
to radio waves.
The exposure standard for mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or
SAR. The SAR limit recommended by The Council of the
European Union is 2.0 W/kg. Tests for SAR have been
conducted using standard operating positions with the
phone transmitting at its highest certified power level in all
tested frequency bands.
The highest SAR value for this device when tested at the
ear was 0.240W/Kg.
If you want a copy of the Declaration of Conformity, please
contact us: [email protected]
While there may be differences between the SAR levels of
various phones and at various positions, they all meet the
EU requirements for RF exposure.
Page 47
47
Information
Liability Disclaimer:
Bea-fon Mobile GmbH shall not bear any liability for any
relevant, indirect, special, incidental, or inevitable
injuries caused by using of this product, including
injuries which have been considered, or unconsidered,
likely to happen.
For any losses caused by natural disasters (such as
earthquake, flood, etc.) or any acts or accidents
(including deliberate or accidental misuses by the user
under these accidents or other unusual circumstances)
which are beyond our liability scope, non-responsibility
should be accounted on us.
Information:
SL205 distributed by Beafon
For more Information, please visit the Bea-fon Homepage:
www.beafon.com or contact us: [email protected]
Address:
BEAFON MOBILE GmbH
4722 Peuerbach
Enzing 4
Austria
Loading...
