SL160

General Information

Congratulations on your purchase of Bea-fon SL160!

Please read this information for better handling of the telephone. We do not assume any liability due to improper use.

We are constantly striving to improve our products and our service. Therefore, Bea-fon reserves the right to make modifications and improvements to any of the products described in this documentation without prior notice.

The content of this User Manual is presented as it is. Bea-fon does not assume any responsibility for the accuracy and completeness of the content of this user manual. There may be slight differences between the images in the user guide and the phone; these are examples, please refer to the phone. Some functions are dependent on a network operator; for further information, contact your network operator.

Please check the supplied accessories to ensure that the accessories are all there. Should one of the components be missing or defective, please contact the dealer where you purchased the telephone.

Bea-fon SL160 includes:

 1 Phone (SL160)  1 Charging station (SL160)  1 Charger (SL160)  1 Battery (SL160)  User manual (SL160)

General Information

Should the font be too small and hardly legible for you, you may view a larger version of the user manual on our website. Go to Products on our website:

www.beafon.com

Device Code:

The use of this code can prevent unauthorized persons from using this telephone. The factory default code is:

0000

PIN Code:

The code from the network operator that is provided with the SIM card prevents the use of the card by unauthorized persons. You can activate/deactivate or change the PIN code.

Table of Contents

General Information ............................ 2

Device Code: ................................... 4

PIN Code: ....................................... 4

Table of Contents ................................ 5

My Telephone ..................................... 9

Getting Started ................................. 12

What is a SIM card? ....................... 12

Inserting the SIM card and Micro SD

card ............................................. 12

Inserting the Battery ...................... 14

Charging the Battery ...................... 14

Switching the telephone on/off: ....... 16

Standby ........................................ 17

Display (Home screen) .................... 17

Display symbols ............................. 18

Headset/Bluetooth mode ................. 19

Menu function ................................ 19

Lock screen ................................... 20

Call functions .................................... 21

Call .............................................. 21

Making a call using the phonebook ... 21

Making calls using the Photo

Contacts ....................................... 22

Create photo contacts ..................... 22

Answering a call ............................. 24

Functions during a conversation ....... 24

Hands-free .................................... 25

Menu ............................................... 26

Phonebook ....................................... 27

Accessing your telephone numbers ... 27

New contact .................................. 27

Editing a contact ............................ 28

Speed dial ..................................... 28

Direct dial numbers M1 M2 .............. 29

Messages ......................................... 30

Write SMS ..................................... 30

Text input ..................................... 30

Inbox ........................................... 31

Outbox ......................................... 32

Drafts ........................................... 32

Sent messages .............................. 32

Settings ........................................ 33

SMS setting ................................... 33

Voicemail server ............................ 34

Call history ....................................... 35

Call history .................................... 35

Delete call logs: ............................. 35

Extras .............................................. 36

Alarm ........................................... 36

Calendar ....................................... 37

Reminders ..................................... 37

Calculator...................................... 37

Flashlight ...................................... 38

Services ........................................ 38

Multimedia ....................................... 39

Camera ......................................... 39

Taking photographs ........................ 39

Image viewer ................................ 40

FM radio........................................ 40

File manager ................................. 42

Copy pictures to the computer ......... 43

Settings ........................................... 44

Tone Settings ................................ 44

Silent mode ................................... 44

SOS ............................................. 45

SOS ............................................. 47

SOS alarm..................................... 47

SOS number .................................. 47

SOS SMS ...................................... 47

Phone settings ............................... 47

Time and Date ............................... 48

Language ...................................... 48

Preferred input method ................... 48

LCD illumination ............................. 48

Call settings .................................. 48

Caller ID ....................................... 49

Network settings ............................ 49

Network selection: ......................... 50

Security settings ............................ 50

SIM security .................................. 50

Telephone lock ............................... 50

Connections .................................. 51

Bluetooth ...................................... 51

Restore factory settings .................. 53

Specifications: ............................... 53

Troubleshooting ................................ 54

Information ...................................... 58

Certification information (SAR): ....... 68

Declaration of Conformity: .............. 69

Limitation of liability: ...................... 69

More information ............................ 70

Address ........................................ 70

My Telephone

Menu button, left In standby

mode, press to enter the main menu

Green Call key/Call logs

In order to access the call logs in standby mode

One touch key M1

Additional function: Navigate to the left

* Key

In standby mode, press long this button to de/activate the key lock

Press this key in standby mode in order to enter the following characters: */+/P/W.

Speaker

2-way navigation key: Arrow key (upwards), press to

enter the SMS menu in standby mode;

Arrow key (downwards)

In standby mode, enter the photo contacts;

Right menu key in standby mode,

enter the phonebook

Red button Turn on/off, end a call,

decline a call

One touch key M2

Additional function: Navigate to the right

Camera quick access button

Additional function: During the call, toggle to the hands-free mode

# Pound key

Press and hold in standby mode to activate/deactivate the silent mode.

In Edit mode; change the input

method.

LED - torch,

Press and hold down the 0 key to turn on/off

Polyphonic speakers

Camera lens

Emergency call key

Volume up key

Volume down key

Micro USB charging port

Getting Started

What is a SIM card?

Every mobile telephone requires an SIM card (Subscriber Identity Module); without the SIM card, you cannot make phone calls. The SIM card is a microprocessor that saves your data and contacts. Therefore, handle the card with care and exercise caution when inserting or removing the card. Keep the SIM cards out of reach of small children.

Inserting the SIM card and Micro SD card

1. The telephone must be switched off

and disconnected from the charger.

2. To remove the battery cover on the

back, use your thumb nail to press the battery cover on the lower left-hand side

Should the battery be in the device, please remove it.

1. Two card holders are available: the

left one for the SIM card and the right one for the Micro SD card

2. Slide the SIM card carefully into the

SIM card slot.

3. Make sure that the gold-colored

contacts on the card are facing downwards and the tapered corner is facing left.

4. Slide the holder down to unlock it.

5. Open the holder and gently insert the

Micro SD card into the Micro SD card holder.

6. Close the holder and push it up to lock

in place.

Inserting the Battery

1. Align the gold-colored contacts of the

battery with the corresponding contacts of the phone.

2. Press the other end of the battery

until it snaps into place.

3. Push the battery cover up on the

device until it clicks into place.

Charging the Battery

You have two options to charge the

SL160 battery:

A. Charging station B. Charger

SD card

SIM card

1. Insert the charger connector into the

telephone.

2. Connect the charger to a power

outlet.

3. The battery can take

several hours to charge. If the telephone is charged while it is switched off, it takes a few seconds before the charging indicator appears in the display.

4. If the telephone is charged while

switched on, the battery indicator begins to go up. The battery is fully charged when the battery indicator no longer goes up.

5. Disconnect the charger from the

network and from the device when it is no longer needed!

Note: The initial charging of the battery should take at least 12 hours.

Switching the telephone on/off:

Make sure that the SIM card is in the telephone and that the battery is charged.

1. Press and hold the red key for

2-3 seconds in order to switch on the telephone.

2. If the PIN code is active, the phone

will now ask for your PIN code, please enter it and confirm with

OK (left menu key).

3. Please select your language and

confirm with OK (left menu key). Press and hold the red key for 2-3 seconds in order to switch off the telephone.

Without the SIM card, only the emergency call number can be dialed. Note: If you enter the PIN code incorrectly 3 times, the phone will ask for the PUK code that you have received together with the SIM card.

Standby

If you do not use the telephone for a short time period, the telephone automatically switches to standby mode. Press any key to exit this mode. Calls can be answered in standby mode.

Display (Home screen)

1 2 3

1. Reception

strength

2. Symbols

3. Battery status

4. Time

5. Date

6. Main menu

7. Phonebook

Display symbols

Reception strength:

The vertical bars show the strength of the reception of your network operator.

New Messages

This symbol is displayed when you receive a new message. SIM card has an unread

message. This symbol blinks when the Inbox folder is full. You have to delete some messages in order to be able to receive new messages.

Headphones

This symbol is displayed when headphones are plugged in.

Missed calls

This symbol is displayed when you did not answer a call.

Call signal

Only ring

Silent mode and vibrate

Vibrate and ring

Call forwarding

This symbol is displayed when all calls are being forwarded.

Alarm

This symbol is displayed when alarm clock is switched on.

Bluetooth

This symbol is displayed when the Bluetooth is switched on.

Roaming

This icon is displayed if your SIM card is in a foreign network (also for virtual carriers) Note: Additional cost may apply when using your phone abroad.

Battery indicator

These symbols change depending on the battery status:

, , ,

Headset/Bluetooth mode

If a headset is connected (also a Bluetooth headset), you can answer the call using the button on the headset.

Note: The phone requires a 3.5mm jack plug - not included!

Menu function

On the default screen, press the left menu key ( ) to enter the Main menu

and the right menu key ( ) to enter the

Contacts.

Press the “Up arrow key” to enter the

Messages and press the “Down arrow

key” to enter the Photo contacts. In some menus, you can use the M1 and

M2 to navigate to the right and left.

Lock screen

To avoid accidental key press, press and hold down the “*” star key on the default screen to enable and disable the keypad lock. To receive a call with key lock activated, press the green dialling key. When you end or reject the call, the keypad automatically locks again.

Additional functions:

Auto keypad lock; see menu item:

Settings - Phone settings - Auto. Lock screen

Call functions

Call

1. Enter the telephone number including

the area code and press the green

key. International Calls: Prior to

entering the area code, enter a + symbol by pressing  twice as well as the country (or regional) code. (If necessary, omit 0 before the area code).

2. Press the right menu button Delete to

delete the number to the left of the cursor.

3. Press the green key to call the

number.

Making a call using the phonebook

If there are contacts saved in the Phonebook, you can make a call using the Phonebook.

1. To enter the phonebook, press the

‘right’ menu key on the default screen.
