Beafon SL140 User Manual

User Manual EN

SL140

2

General Information

Congratulations on the purchase of your
Bea-fon SL140!

Please read this information before using
the phone to make a better use of your
phone. We are not responsible for any
damage due to your misunderstanding of
this information and misacting.

We are endeavouring to improve our
products and services. We reserve all the
rights to revise and change the
description of this product and its

software as well as this user’s manual

without obligation to notify any person of
such revisions and changes.
This user manual is for your better use of
this phone not an approval of any
accessories. All the pictures in this
manual are for reference only. There may
be slight difference between the
appearance of phone/ keys/ contents of
display used in this manual and those of
your phone. Please refer to your phone
for actuality. Some features introduced in
this manual are network or subscription-

3

supported features. Please contact your
network operator for further information.

Please check the package contents to
ensure that all components listed below
are included. If the product is defective or
if there is a component missing,
immediately contact the retailer where
you purchased this handset.

4

General Information

Your Bea-fon SL140 box contains:

• 1 mobile phone (SL140)

• 1 desktop charger (SL140)

• 1 travel charger (SL140)

• 1 battery (SL140)

• User manuals (SL140)

If you find the size of the script not easily
readable for you, you can also find this
manual on our website, where you will be
able to adjust the size of the script.
Go to: www.beafon.com/Products

Device Code:

This device code ensures that
unauthorized persons will not be able to
use your phone. The default code is 0000

PIN-Code:

The PIN-code was supplied to you by
your network operator together with your
SIM card and/or adjusted/set up by
yourself.

5

Directory

General Information ......................... 2

Device Code: ................................... 4

PIN-Code: ....................................... 4

Directory ............................................ 5

Your Phone ......................................... 8

Getting started.................................. 10

What is a SIM card? ....................... 10

Insert the SIM card ........................ 10

Insert the battery as follows: ........... 11

Charging the battery ...................... 12

Switching the telephone on or off ..... 14

Display (Standby mode) .................. 16

Screen icons:................................. 16

Menu Operation ............................. 18

Connect an optional headset ............ 19

Call function ..................................... 20

Make a call .................................... 20

Make a call using the phone book ..... 20

Answering a call: ........................... 21

Operations during a call .................. 21

Hands Free: .................................. 22

Menu ............................................... 22

Phonebook ....................................... 24

To access the phonebook: ............... 24

Add new contact: ........................... 24

To edit (change) a Phone Book entry:

................................................... 25

6

To delete all entries from the phone or

SIM card ....................................... 25

Store a Phonebook entry to a Speed

dial key (2-9) ................................ 26

Direct Number: .............................. 26

Favorite contacts ............................ 26

Messages ......................................... 27

Write message ............................... 27

Inbox: .......................................... 28

Outbox: ........................................ 28

Drafts: .......................................... 29

Sent messages .............................. 29

Settings ........................................ 29

SMS Settings ................................. 29

Voice mail: .................................... 30

Call history ....................................... 32

Missed Dialled and Received or All calls

................................................... 32

Delete call logs: ............................. 32

Organizer ......................................... 33

Alarm ........................................... 33

Tasks ............................................ 34

Calculator: .................................... 34

FM-radio .......................................... 35

FM-Radio....................................... 35

Settings ........................................... 37

Tone settings: ............................... 37

SOS ............................................. 37

SOS description: ............................ 38

7

SOS setting: .................................. 40

Phone settings: .............................. 40

Time and date: .............................. 40

Language: ..................................... 40

Pref. Input method: ........................ 40

Wallpaper: .................................... 41

Brightness: ................................... 41

Call settings .................................. 41

Caller ID: ...................................... 41

Call waiting: .................................. 41

Call divert: .................................... 42

Call barring: .................................. 42

Call time reminder: ........................ 42

Network settings ............................ 42

Network selection: ......................... 43

Security settings ............................ 43

Connectivity: ................................. 44

Bluetooth: ..................................... 44

Visibility: ....................................... 44

My device: .................................... 44

Search audio device: ...................... 44

My Name: ..................................... 45

Restore factory settings .................. 45

Basic Specifications ........................ 46

8

Your Phone

1

Direct dialing number M1

2

Main menu key | left menu key

3

Dialing | History Calls

4

* Key, Press this button on the idle
screen to enter the following
symbols : * /+ /P / W.

5

Loudspeaker

6

Write message key

7

Direct dialing number M2

8

Contact menu key | right menu key

9

Power on/off | End key

10

4 Navi key navigation:
Arrow key up: On the idle screen

this button takes you to the

9

Messages menu.

Arrow key right:

On the idle screen this button takes
you to the Alarm menu.

Arrow key down:

On the idle screen this button takes
you to the Favorite contacts.

Arrow key left:

On the idle screen this button takes
you to the Calendar menu.

11

# Key, Long press can switch
between in silent mode with general
modes; In edit mode, change the
input method.

12

SOS button

13

Polyphone loudspeaker

14

Microphon

15

Charger port

16

PIN Connection to Cradle charger

17

LED Flashlight

10

Getting started

What is a SIM card?

Every mobile phone has a SIM card
(Subscriber Identity Module). This is a
micro-chip that holds your personal
information such as names and phone
numbers. Your phone won’t work without
it. If you already have contacts on your
SIM card, they can be transferred in most
cases.
Keep the SIM card away from children.
The SIM card can easily be damaged or
bent. You should therefore handle the
SIM card with care during installation
and/or removal.

Insert the SIM card

1. Make sure that the phone is switched

off and the charger is disconnected
from the phone.

2. Turn the phone over and remove the

battery cover.

11

3. If the battery is already inside,

remove it.

4. Slide the SIM card carefully into the

SIM card slot. Make sure that the
gold-coloured connectors on the SIM
card are facing downwards and that
the bevelled corner is on the right.

12

Insert the battery as follows:

1. Insert the battery by aligning the gold

contacts in the battery compartment
on the phone.

2. Push down on the upper section of the

battery until it 'clicks' into place.

3. Close the battery compartment by

sliding the cover closed until you hear
a ‘click’.

Charging the battery

There are two ways of SL140 battery
charging:

A. Desktop charging
B. Travel charging

The lithium battery of the mobile phone
can be immediately used after unpacking.

13

A new battery, is not fully charged, and
performs best after performing a full
charge/discharge 3 times:

1. Plug the charger into the charger

connector.

2. Plug the other end into an electrical

outlet.

3. The phone may need several hours for

reaching a fully charge.
When your phone is power off, it
might take a few seconds to show

14

charging display and it shows charge
complete when finished.
When your phone is power on, the
battery icon flickers when it starting
charging and become still with full
bars in battery icon when finished.

4. The battery is fully charged when the

red LED is off. Disconnect the charger
from the phone and the AC outlet.

Note: Charge the battery for at least 12
hours before using the phone for the first
time.

Switching the telephone on or off

Make sure that you SIM card is in your
mobile phone and that the battery is
charged.

1. Press the red key to switch the phone

on.

2. If prompted, choose your language

and press OK.

3. If you have entered a PIN-code

before, the phone will ask for the code
now. Enter the PIN-code and confirm
by pressing OK.

4. To turn off your phone, press and hold

the red key for two seconds.

15

If you don’t insert a SIM card, your phone

shows Insert SIM. None of the functions
related to SIM
card can be used. You can make an
emergency call only.

Note: If you enter an incorrect PIN-code
3 times in succession, the phone will
require you to enter the PUK-code. You
received this PUK-code together with
your SIM card.

16

Display (Standby mode)

1 2 3

4

5

6

7

1. Signal status 5. Time

2. Pictograms 6. Date and day

3. Battery status 7. Menu

8. Names

Screen icons:

Signal Strength

The vertical bars show the
network connection strength. SIM
card has signals.

New messages

This icon shows when you receive
a new message.

SIM Card has an unread message

The inbox is full.
This icon flickers when the inbox
is full and you need to delete
messages to receive new
messages.

17

Earphone

This icon shows when you plug
the earphone in. Voice will be
heard from the earphone.

Missed Calls

This icon shows when you are
viewing the missed call. SIM card
has a missed call.

Alert Type

Ring
Silent mode on and Vibration only
Vibrate and ring

Call Divert

This icon shows when you divert
all calls unconditionally. SIM card
has been set up call divert.

Turn alarm on

This icon shows when you turn
alarm on.

Roaming

This icon shows when your phone
is in roaming state. SIM card is
roaming.

Bluetooth

This icon shows when the
Bluetooth is active.

Battery capacity

This icon’s colour changes

18

according to the status of battery

capacity: , , ,

Menu Operation

Menu lists are used for set up and
operation.
The left and right soft keys initially are

Menu ( ) and Phonebook( ). (Note:

symbols not displayed if the analogue
style clock is set for idle mode.)

Press Menu ( )and the display changes
and the soft keys become OK and Back.

Use Up or Down to move up or down
menu lists, and OK or Back for the next
or previous display.
When writing text, use the # key to
switch cases:
Upper case (ABC), Lower case (abc) or
Numerals (123). Use Up or Down to move
the cursor,

Clear to delete letters and the * key for

symbols/punctuation.

19

Connect an optional headset

You can use a headset (not supplied) with
the micro USB type, plugged into the
Headset socket on the bottom side of the
handset.
When using headsets, including Binatone
approved ones, pay attention to volume
levels and read its user guide for safety
instructions.

20

Call function

Make a call

1. To make a call, enter the phone

number with the prefix and press the

green key. For international calls,

enter ‘+’ by pressing  for 2 sec.
Then enter the country code followed
by the telephone number, in which
the 0 of the prefix must be dropped.

2. If you have entered a wrong number,

press the soft key ‘right’ Clear to
remove the number to the left of the
blinking cursor.

3. Press the green key to call the

number.

4. Press the red key to end the call or to

cancel the call attempt.

Make a call using the phone book

If you have saved a name and number in
the phone book, you can also use the
phonebook to make a call.
In standby mode, press the soft key
‘right’ to go to Phonebook.

1. Scroll with the up and down arrow key

to the name you want to call.

21

2. Press the green key to call the

number.

3. Press the red key to end the call or to

cancel the call attempt.

Answering a call:

When there is an incoming call, the
phone rings and/or vibrates and shows
the number or the corresponding name.

1. Press the green key or Answer if you

would like to answer a call.

2. Press the red key or silent if you

would like to reject a call, or for
ending the connection after the call.

Earphone/Bluetooth Mode): When

plugging the earphone (including
Bluetooth earphone), you can answer a
call by pressing the key on the earphone.

Operations during a call

Press the right Menu key for Hands free
Press left Menu key “Options” to perform
following operation during a call:

End: End this Call.
Hold: Hold this call.
Phonebook: To go to Phonebook.
History calls: To go to History calls

22

Message: To go to Messages.

Mute: de/activate the microphone

Hands Free:

During a call you can turn the hands free
equipment on (Loudspeaker on).or off
with the right Menu key.

Menu

Press the up arrow key to go to the
Menu. Scroll through the menu using the
arrow keys.

1. Phonebook

1. Contacts

2. Add new

contact

3. Speed dial

4. Direct

Number

5. Phonebook

settings

2. Message

1. Write SMS

4. FM-radio

5. Organizer

1. Alarm

2. Calendar

3. Tasks

4. Calculator

5. Torch

6. Services

7. Settings

1. Tone settings

2. SOS settings

23

2. Inbox

3. Outbox

4. Drafts

5. Sent

messages

6. Delete

messages

7. Settings

3. Call history

1. Missed call

2. Dialled calls

3. Received

calls

4. All calls

5. Delete call

logs

3. Phone

settings

4. Call settings

5. Network

settings

6. Security

settings

7. Connectivity

8. Restore

factory
setting

24

Phonebook

You can store names and phone numbers
in the Internal phone book (up to200)
and in the SIM phone book (SIM
dependent, but a maximum of 250).

To access the phonebook:

In idle mode, press Right soft key.
In idle mode, press Left soft key,

Phonebook and press OK
Note: Indicates entries in SIM phone
book, Indicates entries in the

Internal phone book.

Add new contact:

1. Press left soft key next press Down to

open the phonebook and select Add

new contact.

2. Select Preferred storage, To SIM or To

Phone, If you choose To phone: you

can edit Name and Number. Press

Options and Save if you want to save

the contact.

25

To edit (change) a Phone Book
entry:

1. Press Right soft key to phone book

search which one You want to change,
press Left soft key select Edit then
modify the name, press Down modify
the number.

2. Press Option and OK to save the

change(s).

To delete all entries from the phone
or SIM card

1. Select Menu, Phonebook and press

Left soft key.

2. Select a Contact and press Left soft

key

3. Select Mark several and press Left

soft key

4. Select Delete marked and press Left

soft key

5. Select the contacts

6. Press Left soft key and select Delete

marked

7. Press Left soft key (Yes) to confirm

26

Store a Phonebook entry to a Speed
dial key (2-9)

1. Select Menu, Phonebook and press

Left soft key.

2. Select Speed dial and Press OK

3. Set Status to On, press down to Set

numbers.

4. Press OK the display shows ,2-9

5. Press Up or Down to choose the key

to save to

6. Press OK to confirm the memory

entry.

Direct Number:

1. Select Menu, Phonebook and press

Left soft key.

2. Select Direct Number and press Left

soft key.

Add M1 and M2 dial numbers.
Press in Standby mode M1 or M2 for call

Favorite contacts

In standby mode press Arrow key down
You can save until 5 contacts in the

Favorite contacts.

The phone shows this contact on the
screen.

27

Messages

You can receive and send Messages.
Here you can also choose Voice Mail.
These services are net-based services.
Please contact your network operator
before using.

1. Select Menu, Messages and press OK

Write message

You can write and send text messages.
Invoicing is based upon how many
ordinary messages are needed for any
multi-part message.
Press the key marked with the letter that
you want repeatedly until the letter
appears.

1. Select Write message and press left

soft key.

2. Enter contents and press left soft key

to enter Options. (You can select Send
and Save.

3. Press left soft key, select Send and

press left soft key again.

4. Select Enter recipient or Contacts

(from Phonebook).

28

5. Select telephone numbers.

6. Press left soft key to enter Options

and press left soft key to Send

Inbox:

The Inbox is for storing received SMS
messages. Depending on the selected
mode, the phone vibrates or rings when
you receive a new message. And in the

standby mode you see this icon until
you have read the new SMS message.

You can choose the following options
while reading your received SMS:

Delete, Reply, Forward and Advanced.

In the Advanced option: Call sender and

Use Number.

Note: The new message icon keeps

flickering in the standby mode when your
inbox is full. Please delete some
messages for receiving new messages.

Outbox:

The Outbox to view the messages you

don’t sent but saved.

29

Drafts:

By Drafts you can view the draft SMS
messages you have saved.

Sent messages

The Sent messages to view the

messages you sent.

You can choose the following options
while reading your sent SMS:

Forward, Delete and Advanced.

In the Advanced option: Call sender and

Use Number.

Settings

1. Select Menu, Messages and press OK

2. Select Settings and press OK

You can choose the following options:

SMS Settings

You can choose the following options:

Profile settings:

This setting is needed to use the SMS
function. The SMSC number can be
obtained.

30

Common settings:

Set on/off the Delivery report, Reply path
and Save Sent messages.

Preferred storage:

Select SIM or Phone to store messages

Memory Status:

Check the capacity of messages storages.

Voice mail:

Voicemail is a service supplied by your
network operator. For more information
and for the voice mailbox number,
contact your network operator. When you
have a new voice mail message, your
phone will receive a message.

1. Select Menu, Messages and press OK

2. Select Settings and press OK

3. Select Voice mail and press OK

4. Select <Empty> and press Option.

5. Select Call or Edit

6. If you select Edit, enter a name and

the number of your voice mailbox
number.

7. On the default screen: Press and hold

the number 1 and your telephone will

31

call the corresponding number saved
in the Voicemail server.

Note: This service must be supported by
the network operator.

In standby mode:

Press and hold key number 1 for directly
calling the Voice mail. Only the number
saved under voice mail address 1 is
called.

32

Call history

Missed Dialled and Received or
All calls

1. Select Menu, Call history and press

OK

The phone registers the phone numbers
of Missed, Received, Dialled and All calls.

When you press OK by Missed, Dialled or

Received, you can view the calls you
Missed, Dialled, Received or All Calls. If

you press Option you can choose the
following options:

Call, View, Send message, Save and
Delete.

Delete call logs:

You can delete all the records of the

Dialled, Missed and Received calls, you

can also choose delete All calls to delete
all the records of the above-mentioned
calls logs.

33

Organizer

Alarm

1. Select Menu, Extras and press OK

2. Select Alarm and press OK

You can set a maximum of 5 different
alarms.
To set an alarm clock:

1. Select one alarm and press Edit.

2. Edit alarm: set On or Off, Time,

Snooze, Repeat, Alarm volume, Alarm
tone and Alert type.

3. Press Save to save the Alarm.

When alarm sounds, you can stop the
alarm by pressing Stop. If you press

Snooze, the alarm stops and rings after

10 minutes again.

Calendar

1. Select Menu, Extras and press OK

2. Select Calendar and press OK

On the calendar interface, press the Navi
keys to browse through different days.

34

Tasks

1. Select Menu, Extras and press OK

2. Select Task and press OK

If there are some existed event in the
task list, press the up / down key to
select a event to get into the options:

View, Add, Edit, Delete, Delete overdue,
Delete all and View uncompleted

Calculator:

3. Select Menu, Extras and press OK

4. Select Calendar and press OK

The phone is provided with a calculator.
This calculator has limited accuracy and
rounding errors may occur, especially in
long divisions.

Function:

 The keys 1 to 0 insert a digit.
 To insert a decimal, press #.
 Press the up and down arrow key for

+, -

 Press let and right key for x and ÷.

To get the result, press left menu key.
Press and hold right menu key to clear
the display for a new calculation.

35

FM-radio

FM-Radio

1. Select Menu, Multimedia and press OK

2. Select FM-Radio and press OK

Key

Function

Key right

0,1 frequency forward

Key left

0,1 frequency back

Arrow key up

Volume high

Arrow key down

Volume low

Number keys

Recalling the memorized
channels

Enter Options, you can make the
following operations:

Exit:

End the Radio mode

Channel List:

There are 30 channels for you to store.

Preset Auto Search:

Makes auto search for channels available
and add them into the channel list for you
to select.

36

Tune (Manual Input):

Inputs the FM frequency you prefer.

Settings:

Turn on Background Play and

Loudspeaker.
Note: Auto search needs some time, so
please be patient.
For better radio reception, connect a
micro USB headset to the headset socket.

37

Settings

Tone settings:

1. Select Menu, Settings and press OK

2. Select Tone Settings and press OK

You can choose the following options:

Ring tone, Alert type, Ringtone volume,
Ring type, Message tone, Message
volume, Keypad tone and Keypad
volume.

SOS

1. Select Menu, Settings and press OK

2. Select SOS settings and press OK

The SOS function is a simple function
which can save lives at the deciding
moment. In all, you can save 5 SOS
numbers (relatives, neighbours, friends
and rescue). These numbers, previously
saved in order of sequence, will be
automatically dialled in an SOS by
pressing the SOS button on the back of
the mobile phone. During the SOS call, a
warning tone sounds so the person that
you rang knows that it is an emergency!
If you cannot get through on the first

38

number, the second number will be called
automatically. If you cannot get through
on the second number, the third number
will be called etc.
If no emergency number is saved or your
phone card has run out, or you are not
allowed under a foreign network (e.g.
Roaming not activated), you can dial 112
or another emergency number on the
numerical keypad.

SOS description:

Press the SOS button on the back of the
mobile phone for 3 seconds. If you want
to stop or cancel the SOS call, press the

SOS button again.

Functionality:

By pressing the SOS button, the phone
will send an SOS SMS person (in case
mobile number or telephones with SMS
function is available for emergency
contact) to the emergency numbers you
have previously saved and will be
automatically dialled in the given
sequence. (The emergency button also
functions when the phone is closed). The
mobile phone switches on the hands free
function at full volume and at the same

39

time, if the SOS call is not answered
within 25 seconds the next number is
dialled etc.

Note:

 If you want to stop or cancel the SOS

call, press the right menu key or SOS

Key.

 As a rule, the international emergency

call 112 can still be called outside of
the regional network of your network
operator.

 When changing a phone card: Always

make sure that there is sufficient
credit on your phone card because
private emergency numbers cannot be
dialled without sufficient credit.

Attention: If the SOS call is forwarded to
the voicemail, the SOS mode will end.
Attention: If you want to save SOS

numbers such as the ambulance service,
the police, fire brigade etc. as an SOS
number, you must gain permission from
each of these institutions beforehand.
There will be no liability for possible costs
arising from calling them by accident.

40

SOS setting:

SOS alarm: Set On or Off the

SOS alarm tone function.

SOS numbers:

There you can edit and save at most five
SOS number in your phone.

SOS message:

Edit the content of the SOS message
which will be sent out automatically when
the SOS function is using.

Phone settings:

1. Select Menu, Settings and press OK

2. Select SOS Settings and press OK

The following menu items are available:

Time and date:

Set Home city and time and date

Language:

Here you can choose the language you
want in your display.

Pref. Input method:

Here you can choose the Input method
you want for write.

41

Auto. Keypad lock

You can set the telephone such that the
keypad automatically locks after a
present time period.

Wallpaper:

Select your favourite picture as the
wallpaper of the standby window.

Brightness:

LCD backlight for setting up the
brightness

Call settings

1. Select Menu, Settings and press OK

2. Select Call settings and press OK

Depending on the network operator, you
can use the following services:

Caller ID:

Set the function of caller ID:

Set by network
Hide ID
Send ID

Call waiting:

When this network service is activated,
the network notifies you of a new

42

incoming call while you have a call in
progress. Press OK to answer the waiting
call. The first call is put on hold or press
the red key to reject the call.

Call divert:

To divert your incoming calls to your
voice mailbox or some other phone
number (network service). Select the
divert option you want. Several divert
options may be active at the same time.

Call barring:

With this network service you can restrict
the making and receiving of calls with
your phone.

Call time reminder:

Choose to remind you Periodic (30-60
seconds) or select Single (1-3000
Seconds) or select Off.

Network settings

1. Select Menu, Settings and press OK

2. Select Network settings and press OK

This menu has connection with the
network suppliers, so please get in touch
with them when you use this function. If

43

you want to get into one network which

doesn’t have the roaming protocol with

the original network you have been in,
the phone will display the content that
you can make an emergency call.

Network selection:

Depending on network operator support ,
you can choose the following options:

Set automatic or manual mode

Security settings

1. Select Menu, Settings and press OK

2. Select Phone settings and press OK.

You can choose the following options:

SIM security:

To turn your SIM PIN code On or Off,

change PIN and change PIN2.

Phone security:

To lock your phone with a password. The
default password is: 0000.

Change password:

Here you can change your password.

44

Connectivity:

1. Select Menu, Settings and press OK

2. Select Connectivity and press OK

You can connect wirelessly to other
Bluetooth compatible devices.

Bluetooth:

You can choose the following options:

Power:

Here you can choose to turn Bluetooth On
or Off.

Visibility:

you can set the visibility on or off.

My device:

List of saved devices and enables you to
add new devices; Search new device.

Search audio device:

Search for available Bluetooth audio
devices. If Bluetooth is not enabled you
can enable it now by pressing Yes.

45

Search audio device:

1. Press OK, the phone is going to

search for new devices.

2. Select the devices you want to

connect with and press Pair.

3. When connecting with another

Bluetooth device you need a shared
passcode. Enter the passcode and
press OK.

4. Select the device from the list and

press Option. Can choose the
following options: Connect, Rename,

Delete and Delete all.

My Name:

Here you can set the Bluetooth device
Name.

Advanced:

Here you can set your: Audio path,

Storage and check the My address.

Restore factory settings

1. Select Menu, Settings and press OK

2. Select Restore factory settings and

press OK

To reset some of the menu settings to
their original values. The password is:

0000

46

Basic Specifications

Network–Dual­Band

GSM 900/DCS1800
Dimension：

120 x 54 x 12,9 mm

Battery：

Li-ion 3.7V – 800mAh
Standby time:

up to 250 hours*

Talk time:

Up to 480 minutes*

*Variation in operation times may occur
depending on SIM card, network, and
usage settings, usage style and
environments.

47

FAQ

If your phone appears the questions
frequently, please refer to the answers as
follows. After that, you cannot solve the
questions, please contact with the mobile
phone dealers or network operator.

Can’t turn the phone on:

 Check battery installation, please

install battery correctly.

 Check if battery level is low, try to

charging the battery 24h.

 Change the battery (6 Month

warranty)

 Check if entered incorrect PIN code 3

times in a row.
If yes, the phone is locked, then you
should enter your PUK code (please
contact your network operator for
your PUK code).

SIM error:

 Is the SIM card dirty? Please clean it.
 Try and reinstall the SIM card.
 Is the SIM card damaged? Please

contact your network operator.

Weak signal or no signal:

48

 You may be in a location where the

reception is bad, such as tunnel or
cellar, please relocate and try again.

 You can try turning around slightly or

get near the window if you are in a
room.

 Please contact your network operator,

if you still have a weak signal or no
signal.

Bad talking quality:

 Weak signal? See: Weak signal or no

signal.

 Check if battery if battery is low.

Charge the battery or change the
battery.

 Use the up volume key to adjust the

microphone volume during a call.

Can’t make a call:

 Check if you enter the correct number

and press green key.

 Check if you set call barring, if yes,

please cancel it.

 Check if the SIM card is registered in

the network.

 If your SIM card is a prepaid card,

please make sure there is enough
money on the card.

Can’t receive calls:

49

 Is the SIM card registered in the

network?

 Check if your phone is turned on.
 Check if screens shows no signal, if

yes, see: Weak signal or no signal.

 Check if you set call barring, if yes,

please cancel it.

Screen is dark:

 Check if battery if battery is low.

Charge the battery or change the
battery.

 Adjust the wallpaper.
 Your phone may be affected with

damp, keep it dry.

PIN locked:

 Check if entered incorrect PIN code 3

times in a row.
If yes, the phone is locked, then you
should enter your PUK code (please
contact your network operator for
your PUK code).

Tips: if all suggests and solutions can’t

solve your problem, please check
Customer Service on www.beafon.com.
Please do not disassembly or repair your
phone without professional guide.

50

Battery

 Your phone is powered by a

rechargeable battery.

 Note that a new battery's full

performance is achieved only after
two or three complete charge and
discharge cycles! The battery can be
charged and discharged hundreds of
times but it will eventually wear out.

 When the operating time (talk-time

and standby time) is noticeably
shorter than normal, it is time to buy
a new battery. Use only batteries
approved by the phone manufacturer
and recharge your battery only with
the chargers approved by the
manufacturer.

 Unplug the charger when not in use.

Do not leave the battery connected to
a charger for longer than 10 days,
since overcharging may shorten its
lifetime. If left unused a fully charged
battery will discharge itself over time.

 Temperature extremes can affect the

ability of your battery to charge.

 Use the battery only for its intended

purpose.

51

 Never use any charger or battery

which is damaged.

 Do not short-circuit the battery.

Accidental short-circuiting can occur
when a metallic object (coin, clip or
pen) causes direct connection of the +
and - terminals of the battery (metal
strips on the battery) for example
when you carry a spare battery in
your pocket or purse. Short-circuiting
the terminals may damage the
battery or the connecting object.

 Leaving the battery in hot or cold

places, such as in a closed car in
summer or winter conditions, will
reduce the capacity and lifetime of the
battery. Always try to keep the
battery between 15°C and 25°C. A
phone with a hot or cold battery may
temporarily not work, even when the
battery is fully charged. Batteries
performance is particularly limited in
temperatures well below freezing.

 Do not dispose of batteries in a fire!
 Dispose of batteries according to local

regulations (e.g. recycling).

 Do not dispose as household waste.
 Do not charge your mobile phone if

the battery is not installed.

52

Phone

Your phone is a product of superior
design and craftsmanship and should be
treated with care.
The suggestions below will help you to
fulfil any warranty obligations and to
enjoy this product for many years.

 Keep the phone and all its parts and

accessories out of the reach of small
children.

 Keep the phone dry. Precipitation,

humidity and all types of liquids or
moisture can contain minerals that
will corrode electronic circuits.

 Do not use or store the phone in

dusty, dirty areas. Its moving parts
can be damaged.

 Do not store the phone in hot areas.

High temperatures can shorten the
life of electronic devices, damage
batteries, and warp or melt certain
plastics.

 Do not store the phone in cold areas.

When it warms up (to its normal
temperature), moisture can form

53

inside, which may damage electronic
circuit boards.

 Do not attempt to open the phone.

Non-expert handling may damage it.

 Do not drop, knock or shake the

phone. Rough handling can break
internal circuit boards.

 Do not use harsh chemicals, cleaning

solvents, or strong detergents to
clean the phone. Do not paint the
phone. Paint can clog the moving
parts and prevent proper operation.

 Use only the supplied or an approved

replacement antenna. Unauthorised
antennas, modifications or
attachments could damage the

 phone and may violate regulations

governing radio devices.

All of the above suggestions apply equally
to your phone, battery, charger or any
accessory. If any of them is not working
properly, take it to your nearest qualified
service facility.

54

For your safety

Read these simple guidelines. Breaking
the rules may be dangerous or illegal.

Do not switch on the phone when
wireless phone use is prohibited or
when it may cause interference or
danger.

Road safety comes first
Do not use a hand-held phone
while driving.

Switch off in aircraft
Wireless devices can cause
interference in aircraft.

Switch off in hospitals
Follow any regulations or rules.
Switch the phone off near medical
equipment.

Switch off when refuelling
Do not use the phone at a
refuelling point. Do not use near
fuel or chemicals.

Interference
All wireless phones may get
interference, which could affect
performance.

55

Traffic Safety:

Do not use a hand-held telephone while
driving a vehicle. Always secure the
phone in its holder; do not place the
phone on the passenger seat or where it
can break loose in a collision or sudden
stop. Remember road safety always
comes first!

Operating environment:

Remember to follow any special
regulations in force in any area and
always switch off your phone whenever it
is forbidden to use it, or when it may
cause interference or danger.
Use the phone only in its normal
operating positions.
Parts of the phone are magnetic. Metallic
materials may be attracted to the phone,
and persons with a hearing aid should not
hold the phone to the ear with the
hearing aid. Always secure the phone in
its holder, because metallic materials
may be attracted by the earpiece.
Do not place credit cards or other
magnetic storage media near the phone,
because information stored on them may
be erased.

56

Electronic devices:

Most modern electronic equipment is
shielded from radio frequency (RF)
signals. However, certain electronic
equipment may not be shielded against
the RF signals from your wireless phone.

Pacemakers:

Pacemaker manufacturers recommend
that a minimum separation of 20 cm (6
inches) be maintained between a
handheld wireless phone and a
pacemaker to avoid potential interference
with the pacemaker. These
recommendations are consistent with the
independent research by and
recommendations of Wireless Technology
Research.
Persons with pacemakers:

 Should always keep the phone more

than 20 cm (6 inches) from their
pacemaker when the phone is
switched on.

 Should not carry the phone in a

breast pocket.

 Should use the ear opposite the

pacemaker to minimise the potential
for interference.

57

 If you have any reason to suspect

that interference is taking place,
switch off your phone immediately.

Hearing aids:

Some digital wireless phones may
interfere with some hearing aids. In the
event of such interference, you may want
to consult your network operator.

Other medical devices:

Operation of any radio transmitting
equipment, including cellular phones,
may interfere with the functionality of
inadequately protected medical devices.
Consult a physician or the manufacturer
of the medical device to determine if they
are adequately shielded from external RF
energy or if you have any questions.
Switch off your phone in health care
facilities when any regulations posted in
these areas instruct you to do so.
Hospitals or health care facilities may be
using equipment that could be sensitive
to external RF energy.

Posted facilities:

Switch your phone off in any facility
where posted notices so require.

58

Potentially explosive atmospheres:
Switch off your phone when in any area
with a potentially explosive atmosphere
and obey all signs and instructions.
Sparks in such areas could cause an
explosion or fire resulting in bodily injury
or even death.
Users are advised to switch off the phone
when at a refuelling point (service
station). Users are reminded of the need
to observe restrictions on the use of radio
equipment in fuel depots (fuel storage
and distribution areas), chemical plants
or where blasting operations are in
progress.
Areas with a potentially explosive
atmosphere are often but not always
clearly marked. They include below deck
on boats; chemical transfer or storage
facilities; vehicles using liquefied
petroleum gas (such as propane or
butane); areas where the air contains
chemicals or particles, such as grain, dust
or metal powders; and any other area
where you would normally be advised to
turn off your vehicle engine.

Vehicles:

59

RF signals may affect improperly installed
or inadequately shielded electronic
systems in motor vehicles (e.g. electronic
fuel injection systems, electronic anti-skid
(anti-lock) braking systems, electronic
speed control systems, air bag systems).
Check with the manufacturer or its
representative regarding your vehicle.
You should also consult the manufacturer
of any equipment that has been added to
your vehicle.

60

For your safety

Certification information (SAR):

This model phone meets the EU
requirements for exposure to radio
waves.
The exposure standard for mobile phones
employs a unit of measurement known as
the Specific Absorption Rate, or SAR. The
SAR limit recommended by The Council of
the European Union is 2.0 W/kg. Tests for
SAR have been conducted using standard
operating positions with the phone
transmitting at its highest certified power
level in all tested frequency bands.
The highest SAR value for this device
when tested at the ear was 0,598W/Kg.

If you want a copy of the Declaration of
Conformity, please contact us:

[email protected]

While there may be differences between
the SAR levels of various phones and at
various positions, they all meet the EU
requirements for RF exposure.

61

Information

Liability Disclaimer:

 Bea-fon Mobile GmbH shall not bear

any liability for any relevant, indirect,
special, incidental, or inevitable
injuries caused by using of this
product, including injuries which have
been considered, or unconsidered,
likely to happen.

 For any losses caused by natural

disasters (such as earthquake, flood,
etc.) or any acts or accidents
(including deliberate or accidental
misuses by the user under these
accidents or other unusual
circumstances) which are beyond our
liability scope, non-responsibility
should be accounted on us.

62

Information:

SL140 distributed by Beafon
For more Information, please visit the
Bea-fon Homepage: www.beafon.com or
contact us: [email protected]

Address:

BEAFON MOBILE GmbH
4722 Peuerbach
Enzing 4
Austria

V1.0
