Congratulations on the purchase of your Interval Console from BDI. Your console has

been designed to provide a lifetime of enjoyment. This manual will provide you with

assembly instructions and other helpful information to ensure that you get the most out

of your product. Please save it for future reference.

Your Interval Console has been engineered for simple assembly. Please follow these

directions carefully to prevent any damage.

Should you need further assistance, contact BDI at [e-mail].

ENJOY!

BDIUSA.COM | 3NEED ASSISTANCE? [e-mail]

HARDWARE AND COMPONENTSHARDWARE AND COMPONENTS

Unpack and identify the parts listed below. The assembly workspace should be a non-marring
surface such as carpet. Do not use power tools for the assembly of this product.

For missing hardware pieces, please contact BDI Customer Service at [e-mail].

PART #

DESCRIPTION

QUANTITY

PART #

DESCRIPTION

QUANTITY

T1

Hex Wrench

1

H2

M6 x 65mm Screw

8

PART #

DESCRIPTION

QUANTITY

PART #

DESCRIPTION

QUANTITY

T2

Leveler Wrench

1

H3

Shelf Pin

6

PART #

DESCRIPTION

QUANTITY

PART #

DESCRIPTION

QUANTITY

H1

M6 x 20mm Screw

8

H4

Wood Screw

4

PART #

DESCRIPTION

QUANTITY

TOOL REQUIRED (NOT INCLUDED)

Phillips Screwdriver

4 | BDIUSA.COM INTERVAL 7246

H5

KLEET

2

PART #

DESCRIPTION

QUANTITY

H6

M6 x 16mm Screw

1

PART #

DESCRIPTION

QUANTITY

H7

TV Safety Strap

1

HARDWARE AND COMPONENTS HARDWARE AND COMPONENTS

PART #

DESCRIPTION

QUANTITY

PART #

DESCRIPTION

QUANTITY

C1

Base Leg

2

PART #

DESCRIPTION

QUANTITY

C2

Base Spanner

2

C3

Cabinet

1

PART #

DESCRIPTION

QUANTITY

C4

Glass Shelf

1

BDIUSA.COM | 5NEED ASSISTANCE? [e-mail]

ASSEMBLY

STEP 1. ASSEMBLE BASE

Attach (C1) Base Legs to (C2) Base Spanners
using 8 (H1) Screws. Tighten with (T1) Hex

Wrench.

C1

H1

PART/DESCRIPTION QTY

T1-HEX WRENCH 1

H1-SCREW 8

C2

C2

C1

H1

H1

6 | BDIUSA.COM INTERVAL 7246

2 PERSON TASK

STEP 2. ATTACH BASE TO CABINET

With help from another person, carefully rotate
the (C3) Cabinet backwards onto its top panel.

Be careful not to rest the cabinet on its door.

Attach the Base to the (C3) Cabinet using

8 (H2) Screws. Tighten with (T1) Hex Wrench.

H2

H2

H2

ASSEMBLY

PART/DESCRIPTION QTY

T1-HEX WRENCH 1

H2-SCREW 8

H2

H2

H2

H2

C3

BDIUSA.COM | 7NEED ASSISTANCE? [e-mail]

ASSEMBLY STEP 3. INSTALL SHELF PINS

2 PERSON TASK

With help from another person, carefully position
the Cabinet onto its base as shown.

PART/DESCRIPTION QTY

Install the 6 (H3) Shelf Pins by screwing them
into the threaded inserts on the inside of the

H3-PINS 6

(C3) Cabinet.

NOTE: Install the Shelf Pins for the (C4) Glass Shelf in the threaded inserts that correspond with the desired
position of the shelf.

C3

H3 H3

H3 H3

8 | BDIUSA.COM INTERVAL 7246

STEP 4. INSTALL GLASS SHELF

ASSEMBLY

Carefully place the (C4) Glass Shelf into the (C3) Cabinet. Lift the shelf over the winch mechanism
and gently lower it into position, resting on the shelf pins.

C4

C4

C3

C4

BDIUSA.COM | 9NEED ASSISTANCE? [e-mail]

STEP 5. INSTALL KLEET CORD WRAPS (IF NEEDED)ASSEMBLY

Your Interval Media Console comes with
2 (H5) KLEET Cord Wraps which can be used for
cord management.

Attach the (H5) KLEET Cord Wraps using the

(H4) Wood Screws. Tighten with Phillips
Screwdriver (not included).

H5

H4

PART/DESCRIPTION QTY

NOT INCLUDED

Phillips Screwdriver

H4-SCREW 4

H5-KLEET 2

H5

H4

1

H5

Use the KLEET for

wire management

10 | BDIUSA.COM INTERVAL 7246

STEP 6. INSTALL TV SAFETY STRAP (IF NEEDED)

ASSEMBLY

If you intend to place a TV on your Interval
Media Console, it is strongly recommended
that you use the TV Safety Strap. Attach the
(H7) TV Safety Strap to the insert in the
back panel of the media console using the
(H6) Screw using the (T1) Hex Wrench. Unravel
the bundle and follow the instructions on the
hang tag to attach the 2 free ends of the strap
to your TV.

PART/DESCRIPTION QTY

T1-HEX WRENCH 1

H6-SCREW 1

H7-TV SAFETY STRAP 1

H6

H7

BDIUSA.COM | 11NEED ASSISTANCE? [e-mail]

FINE TUNING

LEVEL CONSOLE

Make sure the console is level. Adjust one or
more of the levelers using (T2) Leveler Wrench.

PART/DESCRIPTION QTY

T2-LEVELER WRENCH 1

Your Interval Media Console features a push-to-open, drop-down soft open door. It is intended to
be opened by gently pushing on the top of the door in the center 2" section of the door.

12 | BDIUSA.COM INTERVAL 7246

FINE TUNING

The hinges should not require adjusting. If the gap between the door and cabinet is uneven the
hinges can be adjusted. Remove the cover using a slotted screwdriver (not included) to access the
adjustment screws (see below).

Your door should come pre-adjusted to open completely level. If you need to adjust the door
opening angle, do so by inserting a 5mm Hex Wrench (not included) into the hole above the cable
on the mechanism. Turn the wrench clockwise to lift the door up, turn the wrench counter­clockwise to lower the door. Adjust the mechanism until the open door is level with the ground.

If you wish to adjust the push latch, twist the plunger while it's in the extended position. Turning it
clockwise will adjust the push latch in, and turning it counter-clockwise will adjust the push latch
out. This will adjust the closed position of the door.

DOOR OPENING

Clockwise = lift door up

Counter-clockwise = lower door

HINGES

The back screw adjusts the door

forward or back.

The front screw adjusts the door

up or down.

PUSH LATCH

Clockwise = latch in

Counter-clockwise = latch out

BDIUSA.COM | 13NEED ASSISTANCE? [e-mail]

CARE & MAINTENANCE

Your BDI furniture has been constructed with the finest materials, manufactured with care and is
designed to last a lifetime. Regular care of your furniture will prolong your enjoyment and keep it
looking its best. Here are some general tips for taking care of BDI furniture. Your surfaces may vary.

GLASS

The glass surface is maintained using household glass cleaner and a paper towel or cloth.

SATIN-ETCHED GLASS

This uniquely smooth-to-the-touch glass surface can be regularly maintained using household glass
cleaner and a paper towel or cloth. Minor scratches or scuffs not eliminated using paper towel or
cloth can usually be removed by using a ‘Magic Eraser’. Magic Eraser is a melamine foam product
available at any grocery store or home improvement center. Dampen the entire glass surface and the
Magic Eraser, then rub the entire glass surface in broad, even strokes using moderate pressure. Clean
and dry the surface with a paper towel. Check for results and repeat as necessary.

Any scratches or scuffing not eliminated by one of the above methods can often be addressed by
‘refreshing’ the glass. This is a process that should not be required more than once per 6-12 months.
See this brief video for the simple method: www.bdiusa.com/glass

WOOD

Wood surfaces should be cleaned with a slightly damp (not saturated) cloth or paper towel. Do not
use glass cleaner on wood. If moisture remains, dry the surface with another cloth. If needed, a
gentle non-abrasive cleanser may be used, but be sure to wipe away all cleaner residue and dry the
surface with a cloth.

BDI’s wood finishes feature natural hardwood solids and veneers. Wood is a product of nature and—
unlike man-made materials that can be manufactured to strict and consistent specifications—has
natural imperfections that are part of its appeal and character. Every piece of wood differs from
every other, even when coming from the very same tree. As such, variation in grain, texture and tone
should be expected from one panel or piece of furniture to the next.

While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some
degree of discoloration with prolonged exposure to direct sunlight. Please take care to avoid
positioning your BDI cabinet in any area with extensive direct sunlight. To learn more about the
features of natural wood, visit www.bdiusa.com/wood

METAL, PORCELAIN, & PAINTED SURFACES

Surfaces should be cleaned with a slightly damp (not saturated) cloth or paper towel. If moisture
remains, dry the surface with another cloth. If needed, a gentle non-abrasive cleanser may be used,
but be sure to wipe away all cleaner residue and dry the surface with a cloth.

14 | BDIUSA.COM INTERVAL 7246

WARRANTY

BDI warrants to the original purchaser that for the below-stated warranty term, BDI will repair or
replace any product, part, or component covered by this warranty that fails under normal use as a
result of a defect in material or workmanship. BDI will repair or replace the aforementioned product,
part or component with a comparable product, part or component. The decision to repair or replace
will be at BDI’s sole discretion.

BDI Home Theater Furniture, Office Furniture, Modular Systems, Tables, and other furniture pieces are
warranted for three (3) years from the date of purchase as shown on your sales receipt. The warranty
period starts from the date of purchase. This warranty extends only to the original purchasers who
acquire new products from BDI Authorized Resellers. Any product, part, or component must have
been assembled, installed, used, and maintained according to BDI’s published instructions to be
eligible for warranty coverage. Any modification to the original product voids the warranty.

To view BDI’s complete warranty information, visit www.bdiusa.com/warranty

PRODUCT REGISTRATION

Registering your new BDI product allows us to send you important product updates, service
information, and helpful hints related to your BDI products. Register today, and you will be entered
to win free a BINK table from BDI: www.bdiusa.com/register

WARNING

SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM FURNITURE TIP-OVER. TO HELP
PREVENT TIP-OVER:

nInstall tip-over restraint.
n Place heaviest items in lower compartments.
nNever allow children to climb or hang on drawers, doors, or shelves.
nNever open more than one drawer at a time.

USE OF TIP-OVER RESTRAINT MAY REDUCE—BUT NOT ELIMINATE—THE RISK OF TIP-OVER.
