SKY4450 + SKY4451
Ver. 2
INSTRUCTION
MANUAL
Metal Canopy
Queen Bed Frame
Thank you for choosing us! Since 2002, Best
Choice Products has been bringing customers
high-quality products at the absolute lowest
price. With everything ranging from instruments
and toys to furniture and outdoor, we’ve got
your everyday living essentials covered. We’re
centered around a customer-first philosophy –
with free shipping, exceptional customer
service, and a catalog sourced with you in mind.
Pg. 3
HARDWARE
1
28 PCS
M6 x 16mm SCREW M8 x 20mm SCREW M6 x 35mm BOLT
2
8 PCS
3
14 PCS
TOOLS REQUIRED
APPROXIMATELY
30 MIN.
ASSEMBLY
2 PERSON
ASSEMBLY
660 LBS
CAPACITY
LBS
M4/M5
ALLEN WRENCH
(2) (PROVIDED)
WRENCH
(PROVIDED)
M6 NUT
4
8 PCS
• Please do not exceed the weight limitations of this item.
• Do not stand on or use any part of this product as a step ladder.
• Firmly secure all bolts, screws and knobs before use.
• Reconfirm that all bolts, screws, and knobs are secure every 90 days.
• Fasten screws loosely during initial assembly. Do not firmly tighten the screws until the item is
completely assembled.
• If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made
and/or factory replacement parts are installed.
• Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
NOTICE
Please retain these instructions for future reference.
Pg. 4
1 SET
HEADBOARD FRAME
(L/R)
1 SET
FOOTBOARD FRAME
(L/R)
2 PCS
TOP FRAME
D
2 PCS
SIDE FRAME
PARTS
A
B
F
E
2 PCS
TOP SIDE FRAME
BOARD
C
2 PCS
DOUBLE HOLE SLAT
G
1 PC
BOTTOM FRAME
I
H
2 PCS
SINGLE HOLE SLAT
J
6 PCS
LEG
2 PCS
HOLES
HOLES
L
R
R
L
PRODUCT ASSEMBLY
2
1
Attach a F top frame, part C board,
and part G bottom frame to the
part A headboard frame set (L/R)
with twelve part 1 screws, six
screws per headboard frame.
Attach a F top frame and part C
board to the part B footboard
frame set (L/R) with eight part 1
screws, four screws per
footboard frame.
1
x12
1
x8
A
F
C
G
F
C
B
Pg. 5
PRODUCT ASSEMBLY
3
Attach two part D side frames to the head/footboards with eight part 2 screws. Attach two
part E top side frames with eight part 1 screws.
4
Attach two part J legs to two part H
single hole slats with two part 3 bolts.
Attach one leg per slat.
5
Attach four part J legs to two part I
double hole slats with four part 3 bolts.
Attach two legs per slat.
2
x8
3
x2
3
x4
D
x2
E
x2
J
x2
H
x2
I
x2
J
x4
1
x8
Pg. 6
3
x8
4
x8
H
I
I
H
PRODUCT ASSEMBLY
6
Attach the four part H and I slats to the frame with eight part 3 bolts and eight part 4 nuts, two
nuts/bolts per slat.
Pg. 7
All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the
item is returned in its original product packaging and all accessories from its original shipment are included. All
returned items will receive a full refund back to the original payment method. All returned items will not be charged
a re-stocking fee.
All returned items require an RA (Return Authorization) number, which can only be provided by a Best Choice
Products Customer Service Representative when the return request is submitted. Items received without an RA
may not be accepted or may increase your return processing time. Once an item has been received by Best Choice
Products, refunds or replacements will be processed within 5 business days.
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If the
reason for return is a result of an error by Best Choice Products then Best Choice Products will provide a pre-paid
shipping label via email. Boxes for return shipping will not be provided by Best Choice Products, and is the
customer’s responsibility to either use the original shipping boxes or purchase new boxes.
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items returned are
not considered undamaged until they are received by Best Choice Products and verified as such. All damages to
items are the customer’s responsibility until the item has been received by and acknowledge by Best Choice
Products as undamaged.
CONTACT US; WE’RE HERE 7 DAYS A WEEK TO HELP YOU!
WARNING
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, or neglect of this product.
PRODUCT WARRANTY INFORMATION
bestchoiceproducts.com customerservice@
bestchoiceproducts.com
844.948.8400
LEARN MORE!
ENJOY YOUR PRODUCT!
