INSTRUCTION
MANUAL
Ride-On Convertible
SKY907 + SKY908 + SKY2308Ver. 3
SAFETY
This vehicle must be assembled by an adult who has read and understood the instructions in this manual.
Keep the packaging and bags away from children and dispose of all packaging before use. Always use
common sense and safe practices when operating this vehicle. This product contains or emits chemicals
known in the state of California to cause cancer or birth defects or other reproductive harm.
NOTE: For best performance, only use this vehicle on flat and hard surfaces.
Age Range: 3 to 7 years old
Weight Capacity: 77 lbs.
The following safety hazards may result in serious injury or death:
• This product contains small parts. Keep children away during assembly. Make sure to remove all
packaging material and parts from underneath the vehicle body.
• Never open the battery. Batteries contain lead and lead compounds (acids) that are toxic and corrosive,
and known to the state of California to cause cancer and reproductive harm.
• Limbs, hair, and clothing can get caught in moving parts. Always wear shoes, keep limbs away from
moving parts, and do not wear loose clothing while operating this vehicle.
• This vehicle does not have brakes or braking capability. Do not leave a child unattended during
operation. Do not use this in a location that may require braking capability, as this could result in loss of
control, which may cause serious injury or death.
• Use of this vehicle near streets, motor vehicles, steps, bodies of water, sloped surfaces, hills, wet areas,
flammable vapors, in alleys, at night, or in the dark could result in an unexpected accident.
• Use of this vehicle in unsafe conditions such as snow, rain, loose dirt, mud, sand, or gravel may result in
an unexpected accident such as tipping over, and could damage the electrical system or battery.
• Do not operate this vehicle in an unsafe manner. Examples include but are not limited to:
- Pulling the vehicle with another vehicle or similar device
- Allowing more than one rider
- Pushing the user
- Traveling at an unsafe speed
Please retain these instructions for future reference.
BATTERY WARNINGS
The following safety hazards may result in serious injury or death:
• Use of a battery or charger other than the supplied rechargeable battery and charger may cause a fire or
explosion. Only use the supplied battery and charger.
• Use of the rechargeable battery and charger for any other product may result in overheating, fire, or
explosion. Never use the supplied rechargeable battery and charger with another product.
• Explosive gases are created during charging. Charge the battery in a well-ventilated area. Do not charge
the battery near heat or flammable materials.
• Contact between the positive and negative terminals may result in fire or explosion. Avoid direct contact
between the terminals. Picking up the battery by the wires or charger can cause damage to the battery
and may result in a fire. Always pick up the battery by its case or handles.
• Liquids on the battery may cause fire or electric shock. Always keep all liquids away from the battery and
keep the battery dry. Contact or exposure to battery leakage (lead acid) may cause serious injury. If
contact or exposure occurs immediately call your physician. If the chemical is on the skin or in the eyes,
flush with cool water for 15 minutes. If the chemical was swallowed, immediately give the person water or
milk. Do not give water or milk if the patient is vomiting or has a decreased level of alertness. Do not
induce vomiting.
• Battery posts, terminals, and related accessories contain lead and lead compounds (acid) – chemicals
known to the State of California to cause cancer, reproductive harm, and are toxic and corrosive. Never
open the battery.
• Tampering or modifying the electric circuit system may cause a shock, fire or explosion and permanently
damage the system. Exposed wiring and circuitry in the charger may cause electric shock. Always keep
the charger housing closed.
Pg. 2
USER WARNINGS
The following safety hazards may result in serious injury or death:
• Never leave a child unattended.
• Always sit in the seat when using this vehicle.
• Keep your hands, hair, and clothes away from moving parts.
• Always wear shoes when operating this vehicle.
• Only one rider is allowed on the vehicle at a time.
• Children under 3 years of age cannot use the vehicle.
• Only drive on level ground.
• Do not go near swimming pools or other bodies of water, drop-os, or up and down steep inclines.
• Do not drive the vehicle on loose dirt, mud, sand, fine gravel, or wet surfaces.
• Do not drive the vehicle on streets or near cars.
SPECIFICATIONS
Overall Dimensions
Weight
Weight Capacity
Age Range
Max Speed
Initial Charge Time 18 hours
Charging Time
Run Time
Battery Type
Fuse
Electric Motor
Charger
47"(L) x 25"(W) x 21"(H)
45.5 lbs.
77 lbs.
3 – 7 years old
2 mph.
8 – 12 hours
1 – 2 hours
12V 7AH
13A
Double-drive 12V
DC 6V/12V
Materials
Plastic, Metal
Pg. 3
TOOLS REQUIRED
PHILLIPS
SCREWDRIVER
SMALL
WRENCH
HARDWARE
SCREW WASHER COTTER PIN
1
2
3
LBS
77 LBS
CAPACITY
2 PERSON
ASSEMBLY
APPROXIMATELY
45 MIN.
ASSEMBLY
PARTS
A
CENTER FRAME
E
REAR WHEEL
I
SEAT
16 PCS
2 PCS
2 PC
1 PC
B
F
J
6 PCS
REAR FRAME
2 PC
HUB CAP
4 PC
SIDE MIRROR
2 PC
C
G
K
4 PCS
REAR AXLE
2 PC
GEAR BOX
2 PC
WINDSHIELD
1 PC
D
FRONT WHEEL
H
STEERING WHEEL
L
SEAT FRAME
2 PC
1 PC
1 PC
M
Pg. 4
CHARGER
1 PC
PRODUCT ASSEMBLY
1
B
Please retain these instructions for future reference.
A
B
A
1
Flip the vehicle over and lay it on a level surface. Attach the part A center frame pieces with twelve part 1
screws. Attach the part B rear frame pieces with four part 1 screws.
Pg. 5
PRODUCT ASSEMBLY
2
DF
3
2
Slide on a part 2 washer, part D front wheel, and another part 2 washer onto a front wheel axle and secure
it with a part 3 pin. Repeat on the other side. Snap a part F hub cap onto each wheel.
D F
3
2
3
Slide the part C rear axle through the body of the vehicle.
EF
2
C
E
2
F
3
G
Insert a part G gear box into one side of the axle. Route the wires from the gear box through the body of
the vehicle and into the seat. Slide on a part E rear wheel, and part 2 washer onto the rear axle and secure
it with a part 3 pin. Repeat on the other side. Snap a part F hub cap onto each wheel.
Pg. 6
G
3
PRODUCT ASSEMBLY
4
Join the connector from the part H steering wheel to the connector from the steering mount. Remove the
nut and bolt from the steering wheel, slide on the steering wheel, and then replace the nut and bolt to
secure the steering wheel to the mount.
H
5
L
K
Snap on the part K windshield and part L seat frame.
Pg. 7
PRODUCT ASSEMBLY
6
Within the seat, join the connectors from the gear boxes to the corresponding connectors leading from the
front of the car. Insert the connector from the battery into the designated terminal on the circuit board.
Pg. 8
PRODUCT ASSEMBLY
7
I
J
Snap on the part J side mirrors. Install the part I seat and secure the latch to lock it in place.
Pg. 9
CHARGING INSTRUCTIONS & WARNINGS:
• Charging socket is located in the center of the vehicle behind the seat. Insert one end of the part M
charger into the charging socket and plug the other end into a wall outlet.
• Charge the battery at least 18 hours before initial use.
• On average, you will need to charge the battery between 8 and 12 hours. Do not charge the battery for
more than 20 hours. Failure to charge the battery as directed could cause permanent damage to the
battery and void the warranty.
• Damage to the battery may occur if it is allowed to drain completely. Do not allow the battery to drain
completely.
• Check the battery and charger (supply cord, connector) for wear and damage before charging. Do not
charge the battery if damage has occurred.
• Only an adult who has read and understood the safety warnings should handle, charge and recharge the
battery.
CARING FOR YOUR RIDE-ON
•
Park the vehicle indoors or cover it with a tarp to protect it from wet weather.
• Do not leave the vehicle in the sun for long periods of time or fading may occur. Store in shade or cover with tarp.
• Do not wash the vehicle with a hose.
• Do not wash the vehicle with soap.
DASHBOARD DIAGRAM
• Push down on the pedal to drive forward/reverse.
• Release the pedal to slow down and stop.
Pg. 10
HORN
PEDAL
POWER SWITCH
VOLUME
AUX INPUT -
plug in a music player
to play your own music
FORWARD/REVERSE
REMOTE/MANUAL
CONTROL
HIGH/LOW
SPEED
REMOTE CONTROL DIAGRAM
TROUBLESHOOTING
• Insert 2 AAA batteries into the remote control.
• On the vehicle dashboard, press the
remote/manual control switch to change from
manual control to remote control.
TURN LEFT/TURN RIGHT FORWARD/REVERSE
Problem
Vehicle does not move
Battery does not recharge
Battery does not last
Battery is warm and
makes a slight noise while
charging
Slow speed
Vehicles shakes while
driving
Vehicle is silent
Forward and reverse
switch is flipped (forward
goes in reverse, reverse
goes forward)
Reason
Low battery
Electrical protection
Switch not in the correct position
Battery connectors disconnected
Battery connectors disconnected
Charger not connected to socket
or outlet
Battery does not have a full charge
Normal
Low battery
Overloaded vehicle
Uneven or sloped road
Loose connection to motor
Steering wheel is not properly
connected
Gear boxes are installed
incorrectly
Solution
Fully charge the battery
Stop use for several minutes and restart
Completely press in switches
Plug in battery connectors
Plug in battery connectors
Completely plug in the charger
Fully charge the battery
Normal
Fully charge the battery
Reduce the weight on the vehicle
Drive on flat pavement
Ensure the motor is properly connected to
the battery
Properly connect the steering wheel
connector
Make sure the L gear box is on the left and
R gear box is on the right
Pg. 11
ASSEMBLY IS COMPLETE!
PRODUCT WARRANTY INFORMATION
All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the
item is returned in its original product packaging and all accessories from its original shipment are included. All
returned items will receive a full refund back to the original payment method. All returned items will not be charged
a re-stocking fee.
All returned items require an RA (Return Authorization) number, which can only be provided by a Best Choice
Products Customer Service Representative when the return request is submitted. Items received without an RA
may not be accepted or may increase your return processing time. Once an item has been received by Best Choice
Products, refunds or replacements will be processed within 5 business days.
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If the
reason for return is a result of an error by Best Choice Products then Best Choice Products will provide a pre-paid
shipping label via email. Boxes for return shipping will not be provided by Best Choice Products, and is the
customer’s responsibility to either use the original shipping boxes or purchase new boxes.
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items returned are
not considered undamaged until they are received by Best Choice Products and verified as such. All damages to
items are the customer’s responsibility until the item has been received by and acknowledge by Best Choice
Products as undamaged.
CONTACT US; WE’RE HERE 7 DAYS A WEEK TO HELP YOU!
bestchoiceproducts.com customerservice@
bestchoiceproducts.com
844.948.8400
LEARN MORE!
WARNING
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, or neglect of this product.
