2. Router Description
2.1 Description
The SPECTRE industrial router series is used to connect Ethernet equipment and devices to
the Internet or intranet. The SPECTRE 3G cellular router adds wireless connectivity. Thanks
to the high data transfer speed of up to 14.4 Mbit/s (download) and 5.7 Mbit/s (upload),
SPECTRE 3G router is an ideal wireless solution for traffic and security camera systems,
individual computers, LAN networks, automatic teller machines (ATM) and other self-service
terminals.
The standard configuration includes one 10/100 Ethernet port, one USB Host port, one
binary Input/output (I/O) port and dual SIM card holders. Network redundancy is provided by
the second SIM card holder. It also contains 2 auxiliary ports for connecting to other types of
networks such as RS-232, RS-485/422, Digital/Analog I/O, or they can be configured to
provide additional switched Ethernet ports. The function of each port is dependent upon the
specific router model.
Configuration of the router may be done via a password-protected Web interface. The router
supports the creation of VPN tunnels using IPsec, OpenVPN and L2TP to ensure safe
communication. The Web interface provides detailed statistics about the router’s activities,
signal strength, etc. The router supports DHCP, NAT, NAT-T, DynDNS, NTP, VRRP, control
by SMS, and many other functions.
The router provides diagnostic functions which include automatically monitoring the PPP
connection, automatic restart in case of connection losses, and a hardware watchdog that
monitors the router status. The user may insert Linux scripts to control various router
functions and create up to four different configurations for the same router. These
configuration files can include different SMS functionality and binary input configurations.
You may switch between different configurations whenever necessary. The router can
automatically upgrade its configuration and firmware from your central server. This allows for
mass reconfiguration of numerous routers at the same time. Additional software like
SmartCluster VPN Server and R-SeeNet for router monitoring are also supported.
2.2 Examples of possible applications:
Mobile office
Fleet management
Security system
Telematics
Telemetrics
Remote monitoring
Vending and dispatcher machines
B&B Electronics, Inc. SPECTRE User Manual
9
SPECTRE_User_Manual_2912m
www.bb-elec.com
www.bb-europe.com
2.3 Package Contents
The basic router package includes:
Router
Power supply (3G models only)
Crossover Ethernet cable
External antenna (3G models only)
DIN rail adapter
Installation CD
Quick Start Guide
Fig. 1: Contents of package
B&B Electronics, Inc. SPECTRE User Manual
10
SPECTRE_User_Manual_2912m
www.bb-elec.com
www.bb-europe.com
2.4 Model Numbers
Standard Features on Spectre Routers: 10/100 Ethernet, USB Host Port, Binary I/O Port, Dual SIM
Card slots
Auxiliary Port Functions (Model Dependent):
The router can be connected as follows.
PORT 1
RS232, RS485/422, ETHERNET, CNT, XC-SW (in combination with PORT 2)
PORT 2
RS232, RS485/422, XC-SW (together with PORT 1)
Table 1: Auxiliary port possibilities
Spectre 3G Wireless Routers
Auxiliary Ports
Model No.
Port 1
Port 2
RT3G-300
No connect
No connect
RT3G-302
No connect
RS-232
RT3G-310
Ethernet
No connect
RT3G-311
Ethernet
Ethernet
RT3G-322
RS-232
RS-232
RT3G-324
RS-232
RS-422/485
RT3G-330
12-bit I/O (AI, DI, DO)
No connect
Spectre RT Wired Routers
Auxiliary Ports
Model No.
Port 1
Port 2
ERT311
Ethernet
Ethernet
ERT312
Ethernet
RS-232
Table 2: Model numbers
Note: On routers with 2 auxiliary Ethernet ports (RT3G-311, ERT311), Ports 1 and 2 are
internally bridged together.
B&B Electronics, Inc. SPECTRE User Manual
11
SPECTRE_User_Manual_2912m
www.bb-elec.com
www.bb-europe.com
2.5 Dimensions
Fig. 2: Basic dimensions, metal box
B&B Electronics, Inc. SPECTRE User Manual
12
SPECTRE_User_Manual_2912m
www.bb-elec.com
www.bb-europe.com
3. Mounting Recommendations
For best performance, please consider the following:
The router should be mounted on a flat solid work surface.
The DIN rail adapter is included for DIN rail mounting.
Whip antennas should be kept at least 6 cm from cables and metal surfaces on all
sides. When using an external antenna in an exposed area, a lightning surge
suppressor should be used.
An external antenna should be used when mounting the router on a metal surface or
inside a metal enclosure.
Fig. 3: Recommended clearance around antennas
B&B Electronics, Inc. SPECTRE User Manual
13
SPECTRE_User_Manual_2912m
www.bb-elec.com
www.bb-europe.com
The cables should be bundled together and kept as far away from the antennas as
possible.
1. Length: The combination of power supply and data cables can be a maximum of 1.5
meters.
2. If the length of the data cables exceeds 1.5 meters, overvoltage protectors (surge
suppressors) should be used.
3. Do not bundle the data cables with the 120/230 VAC power cable.
4. All wiring to sensors should use shielded twisted pairs.
Fig. 4: Cable routing
Leave enough space around the connectors for the cable wiring.
B&B Electronics, Inc. SPECTRE User Manual
14
SPECTRE_User_Manual_2912m
www.bb-elec.com
www.bb-europe.com
Fig. 5: Space in front connectors
The router must be securely grounded to earth ground for proper operation.
B&B Electronics, Inc. SPECTRE User Manual
15
SPECTRE_User_Manual_2912m
www.bb-elec.com
www.bb-europe.com
4. User Interfaces
4.1 Connectors
FRONT PANEL
Label
Connector
Description
PWR
2-pin
Power supply.
ETH
RJ45
Connection to the local computer network.
PORT 1
RJ45
RS-232/422/485, ETHERNET, or I/O
PORT 2
RJ45
RS-232/422/485 or ETHERNET
ANT*
SMA
Main antenna
DIV*
SMA
Diversity antenna
USB
USB-A Host
USB connector.
I/O
3-pin
Binary input and output.
SIM1*
-
SIM card holder 1
SIM2*
-
SIM card holder 2
* 3G models only
Table 3: Front panel description
Fig. 6: Front panel SPECTRE 3G
Loading...
