B&B Electronics ES1AWB User Manual

MMooddeell EESS11AAWWBB
880022..1111bb WWiirreelleessss SSeerriiaall SSeerrvveerr
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Manual Documentation Number: ES1AWB-2907m pn6908-rev003
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Manual Documentation Number: ES1AWB-2907m pn6908-rev003
International Headquarters
B&B Electronics Mfg. Co. Inc.
707 Dayton Road
Ottawa, IL 61350 USA
Phone (815) 433-5100 -- General Fax (815) 433-5105
Website: www.bb-elec.com
Sales e-mail: orders@bb-elec.com
Technical Support e-mail: support@bb.elec.com
European Headquarters
B&B Electronics Ltd.
Westlink Commercial Park
Oranmore, Co. Galway, Ireland
Phone +353 91-792444 -- Fax +353 91-792445
Website: www.bb-europe.com
Sales e-mail: sales@bb-europe.com
Technical Support e-mail: support@bb-europe.com
© B&B Electronics – November 2005
-- Fax (815) 433-5109
-- Fax (815) 433-5104
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Manual Documentation Number: ES1AWB-2907m pn6908-rev003
©
2005 B&B Electronics. No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photography, recording, or any information storage and retrieval system without written consent. Information in this manual is subject to change without notice, and does not represent a commitment on the part of B&B Electronics.
B&B Electronics shall not be liable for incidental or consequential damages resulting from the furnishing, performance, or use of this manual.
All brand names used in this manual are the registered trademarks of their respective owners. The use of trademarks or other designations in this publication is for reference purposes only and does not constitute an endorsement by the trademark holder.
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Manual Documentation Number: ES1AWB-2907m pn6908-rev003
TTaabbllee ooff CCoonntteennttss
CHAPTER 1: INTRODUCTION............................................................................. 1
ABOUT YOUR ES1AWB WIRELESS SERIAL SERVER................................................. 1
FEATURES..................................................................................................................1
COMMUNICATION MODES ......................................................................................... 1
Direct IP ............................................................................................................... 1
Virtual COM Port................................................................................................. 1
Paired Mode ......................................................................................................... 2
Other Communications Modes.............................................................................. 2
802.11 WIRELESS NETWORKING BASICS................................................................... 2
802.11 Wireless Networking................................................................................. 3
CHAPTER 2: HARDWARE OVERVIEW............................................................. 6
PACKAGE CHECKLIST ................................................................................................ 6
INDICATORS, SWITCHES AND CONNECTORS............................................................... 7
Link Integrity LED................................................................................................ 7
Network Activity LED........................................................................................... 7
Reset Switch.......................................................................................................... 7
Antenna Connector ............................................................................................... 7
Power Connector.................................................................................................. 7
CONNECTING THE HARDWARE .................................................................................. 8
OTHER HARDWARE CONNECTIONS............................................................................ 9
CHAPTER 3: GETTING STARTED.................................................................... 10
1. Check the contents of your ES1AWB package. It should contain…........... 10
2. Set up the Hardware ................................................................................... 10
3. Power it Up................................................................................................. 10
4. Get the IP Address...................................................................................... 11
5. Login........................................................................................................... 11
6. Configure the ES1AWB............................................................................... 11
7. Set up VCOM (if using the RealPort profile).............................................. 11
8. Communicate .............................................................................................. 11
CHAPTER 4: CONFIGURING THE IP ADDRESS............................................12
USING THE DISCOVERY SOFTWARE ......................................................................... 12
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Table of Contents i
Documentation Number: ES1AWB-2907m pn6908-rev003
CHAPTER 5: USING THE WEB CONFIGURATION AND MANAGEMENT
INTERFACE ............................................................................................................. 14
LOGGING IN............................................................................................................. 14
LOGGING OUT ......................................................................................................... 14
USING TUTORIAL AND HELP.................................................................................... 15
CONFIGURING NETWORK SETTINGS ........................................................................ 15
IP Settings........................................................................................................... 16
Wireless LAN Settings......................................................................................... 16
Wireless Security Settings................................................................................... 18
Wireless 802.1x Authentication Settings............................................................. 18
Network Services Settings................................................................................... 18
Advanced Network Settings................................................................................. 18
CONFIGURING THE SERIAL PORT ............................................................................. 19
Port Profile Settings............................................................................................ 19
Basic Serial Settings ........................................................................................... 24
Advanced Serial Settings..................................................................................... 24
CONFIGURING ALARMS AND NOTIFICATION............................................................ 25
Alarm Notification Settings................................................................................. 25
Alarm Conditions................................................................................................ 25
Alarm Destinations............................................................................................. 26
CHAPTER 6: MANAGING THE ES1AWB......................................................... 28
SYSTEM SETTINGS ................................................................................................... 28
Device Identity Settings....................................................................................... 28
Simple Network Management Protocol (SNMP) Settings................................... 28
USING REMOTE MANAGEMENT ............................................................................... 28
MANAGING USERS AND PERMISSIONS ..................................................................... 28
Changing the Root Username and Password ..................................................... 29
Adding New Users............................................................................................... 29
Configuring User Access and Permissions......................................................... 29
MANAGING SERIAL PORTS AND CONNECTIONS ....................................................... 30
Serial Ports......................................................................................................... 30
Connections ........................................................................................................ 30
CHAPTER 7: USING ADMINISTRATIVE FEATURES................................... 32
FILE MANAGEMENT................................................................................................. 32
BACKUP/RESTORE ................................................................................................... 32
UPDATE FIRMWARE................................................................................................. 32
FACTORY DEFAULT SETTINGS ................................................................................. 32
SYSTEM INFORMATION ............................................................................................ 33
General............................................................................................................... 33
GPIO ................................................................................................................... 33
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
ii Table of Contents
Manual Documentation Number: ES1AWB-2907m pn6908-rev003
Serial ................................................................................................................... 33
Network............................................................................................................... 34
REBOOT................................................................................................................... 35
CHAPTER 8: USING REALPORT....................................................................... 36
Configuring the IP Address................................................................................. 36
Configuring the Serial Port for RealPort............................................................ 36
Adding a Virtual COM Port using RealPort....................................................... 37
Removing a Virtual COM Port using RealPort.................................................. 37
Updating RealPort.............................................................................................. 38
APPENDIX A: DEFAULT CONFIGURATION SETTINGS.............................. 40
APPENDIX B: PRODUCT SPECIFICATIONS ..................................................42
APPENDIX C: ES1AWB DIMENSIONAL DIAGRAM...................................... 44
APPENDIX D: RS-232 CONNECTIONS.............................................................. 46
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Table of Contents iii
Documentation Number: ES1AWB-2907m pn6908-rev003
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Manual Documentation Number: ES1AWB-2907m pn6908-rev003
iv
Introduction
CChhaapptteerr 11:: IInnttrroodduuccttiioonn
Thank you for purchasing an ES1AWB Wireless Serial Server. Like all B&B Electronics products, your serial server has been manufactured to high standards of quality and performance to ensure your complete satisfaction. Please read this manual and carefully follow the instructions to achieve best results. For additional information on this and other products and for technical support, contact B&B Electronics.
About Your ES1AWB Wireless Serial Server
ES1AWB Wireless Serial Servers are part of B&B Electronics’ growing
family of device servers, products that allow you to connect equipment with available serial connections into existing networks. ES1AWB wireless serial servers connect RS-232 devices to a wireless network via wireless access points, eliminating the need for network cabling. Based on the 802.11b wireless standard, ES1AWB servers operate at up to 11 Mbps over the 2.4 GHz band, which does not require licensing.
A serial device connected to the serial port on your ES1AWB can be accessed from any node on the LAN using virtual COM port, console
management, TCP and UDP socket, serial bridge, modem emulation and custom connections. Network addresses can be obtained dynamically or
manually. Simple Network Management Protocol (SNMP) is supported. Configuration is accomplished through a web-based user interface.
Features
Wireless networking at up to 11 Mbps on the 2.4 GHz band, as
specified by the 802.11b standard
Serial port supports RS-232 using a standard DB-M connector
Supports TD, RD, TRS, CTS, DTR, DCD, DSR and GND RS-2 32 lines
LAN and WAN Communications via wireless access point
TCP or UDP Client or Server operation - configurable
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Chapter 1 1
Manual Documentation Number: ES1AWB-2907m pn6908-rev003
Introduction
Software Support - Windows 98/ME/ 2 0 00/XP/NT 4.0 or Vista
Firmware upload for future revisions/upgrades
Small compact case
LEDs indicate link integrity and data transfer activity
Web Configuration and Management user interface
Email event notification
Communication Modes
ES1AWB Wireless Serial Servers allow you to connect serial devices over
a wireless network. The connection can be configured in several modes.
Direct IP
Direct IP Mode allows applications using TCP/IP or UDP/IP socket programs to communicate with the asynchronous serial ports on the serial server. In this mode the ES1AWB is configured as a TCP or UDP server. The socket program running on the PC establishes a communication connection. The data is sent directly to and from the serial port on the server.
TCP Server Mode allows network devices to initiate a TCP connection
to the serial device connected to the serial port on the ES1AWB. This is also referred to as reverse telnet.
UDP Server Mode allows network devices to initiate a UDP connection
to the serial device attached to the serial port of the ES1AWB. When using UDP protocol the ES1AWB can be configured to broadcast data to and receive data from multiple IP addresses.
Virtual COM Port
Virtual COM Port mode (also called COM port redirection) allows you to map a COM port on your PC to the serial port on your ES1AWB. Using the RealPort software (included with the ES1AWB) you create virtual COM ports on your PC. When your application sends data to this port, RealPort redirects the data across the network to serial device connected to the ES1AWB serial port. The network is transparent to the user application and the serial device connected to the ES1AWB.
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Chapter 1 1
Manual Documentation Number: ES1AWB-2907m pn6908-rev003
Introduction
Paired Mode
Paired Mode (also called Serial Tunneling or Serial Bridge mode) allows serial devices connected to two ES1AWB serial servers to communicate across a network. The two ES1AWB serial servers automatically connect to each other.
In Paired Mode the heartbeat feature ensures reliable communications by restoring the connection if communications are temporarily lost at either end due to loss of power or Ethernet connection.
Other Communications Modes
ES1AWB Wireless Serial Servers also feature the following communications profiles:
Modem Emulation Mode allows you to configure the serial port to operate as if it is a modem. For legacy applications where a serial device is set up to communicate through a modem, the serial device can now be connected to the ES1AWB and communication occurs over the network. The ES1AWB emulates modem responses to and from the serial device.
In Console Management Mode the ES1AWB can be configured for connection to the management port typically found on network devices such as routers, switches and servers. This allows remote management of the network device. Communication can be accomplished using telnet to a specific port in the serial server.
Custom Mode allows you to custom configure the ES1AWB serial port and is used if your application does not fit into any other predefined modes.
802.11 Wireless Networking Basics
ES1AWB wireless serial servers allow you to connect non-network-enabled
serial devices into a wireless network, giving you the capability to gather more data and implement remote programming and management. Serial devices no longer are limited to a physical connection to a PC. The serial device can be connected to an ES1AWB wireless serial server anywhere within range of an 802.11b-compatible wireless access point. Communication occurs transparently using TCP/IP or UDP/IP over a wireless link. This allows traditional Windows PC software access to serial devices anywhere on the wireless network.
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
2 Chapter 1
Manual Documentation Number: ES1AWB-2907m pn6908-rev003
Introduction
The enabling technology for ES1AWB wireless serial servers is based on the IEEE 802 standard. Some background on the standard follows.
802.11 Wireless Networking
IEEE 802.11 is a set of standards that defines how multiple devices can communicate on a wireless network. The standard has grown into a set of several standards that define various features and functions. The 802.11b standard defines the physical and data link layers for a wireless network using the 2.4 GHz frequency band, a band that does not require licensing. As a part of the IEEE family of standards, 802.11 WLANs are easily connected to 802.3 (Ethernet) LANs. Higher layer LAN protocols, network operating systems and internetworking protocols such as TCP/IP integrate seamlessly.
Under the IEEE 802.11 standard there can be two different types of devices on the wireless network: stations and access points (AP). A station may be a PC equipped with a wireless network adapter or it can be a wireless serial server such as the ES1AWB. An 802.11 access point is a radio with an interface that allows connection to a wired LAN. Access points run bridging software to facilitate the connection from wireless to wired network. The access point becomes the base station for the WLAN. It aggregates access to the wired network for multiple wireless stations. An access point may be a standalone device, such as a wireless router or switch, or a card in a PC.
Wireless Network Configurations
The 802.11 standard defines two modes of operation: infrastructure mode and ad hoc mode. Infrastructure mode makes use of one or more access points connected to a wired LAN. Wireless stations communicate with access points to gain access to each other and/or the LAN. In the Basic Service Set (BSS) several stations communicate with one access point, which is connected to a wired LAN. In the Extended Service Set (ESS) two or more access points connect to the LAN creating a sub network.
In ad hoc mode, also called Independent Basic Service Set (IBSS), access points are not used. Wireless stations communicate directly with each other in a peer-to-peer fashion. This mode allows individual computers to set up a network where wireless infrastructure does not exist.
ES1AWB wireless serial servers can be configured to operate in infrastructure or ad hoc mode. From the Web Configuration and Management Interface you can set up the type of network, naming the network (specifying the SSID, or service set identifier) and other parameters.
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Chapter 1 3
Manual Documentation Number: ES1AWB-2907m pn6908-rev003
Introduction
IEEE 802.11b
IEEE 802.11b standard specifies a WLAN that operates on the 2.4 GHz band at data rates up to 11 Mbps. Equipment that conforms to the 802.11b standard can interoperate with equipment conforming to faster (up to 54 Mbps) 802.11g equipment and they will interoperate. However, when connected into the same network the 802.11g equipment will operate at the 11 Mbps limitation of the 802.11b equipment.
For media access, 802.11 wireless networks use CSMA/CA, a scheme in which a station that intends to transmit ‘listens’ for traffic on the radio carrier frequency and sends data packets if the frequency is clear. If the receiving station receives the packet intact it sends an acknowledgement (ACK) to confirm the packet has been received. If the transmitting station does not receive an ACK it assumes a collision occurred and transmits again after a random delay period.
Communication distances vary depending on the type and thickness of material around a wireless node. The transmitter power output, the type of antenna used and the amount of attenuation through materials also affects the useable range. Electromagnetic noise, reflections, the amount of network traffic, other radio devices operating in the same frequency band also affect range and overall performance. In an infrastructure network the number of access points and their coverage pattern also affect how well the system operates. Typically an 802.11 device operating indoors will have a range from 100 feet minimum to about 500 feet maximum. Outdoors, some products, using high gain antennae may achieve line-of-sight ranges of five miles or more.
Security is a significant concern for WLAN users. Whether security threats originate intentionally or unintentionally, wireless systems are more susceptible than wired systems. ES1AWB serial servers offer several security options including WEP (Wired Equivalent Privacy), WPA (Wi-Fi Protected Access), PEAP (Protected EAP) w/EAP-MS-CHAPv2 and others.
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
4 Chapter 1
Manual Documentation Number: ES1AWB-2907m pn6908-rev003
Introduction
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Chapter 1 5
Manual Documentation Number: ES1AWB-2907m pn6908-rev003
Hardware Overview
CChhaapptteerr 22:: HHaarrddwwaarree OOvveerrvviieeww
Package Checklist
ES1AWB Wireless Serial Servers are shipped with the following
items included:
9 The ES1AWB module 9 A printed version of this user manual 9 A printed version of the ES1AWB Quick Start Guide 9 CD-ROM disc with
o B&B discovery software o RealPort drivers for Windows 98/ME/2000/XP/
NT 4.0 /Vista
o This manual in PDF format o The ES1AWB Quick Start Guide in PDF format
Figure 1. Front View of the ES1AWB Serial server
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
6 Chapter 2
Manual Documentation Number: ES1AWB-2907m pn6908-rev003
Loading...
+ 40 hidden pages
