Bayliner 245 Cruiser Owner's Manual Supplement

Engine Serial Number: _____________________________________________
Hull Identification Number:__________________________________________
Hull Identification Number
The Hull Identification Number (HIN) is located just below the deck gunnel at the starboard aft corner of the boat.
Record the HIN (and the engine serial number) in the space provided above.
Include the HIN with any correspon­dence or orders.
© 2011 Bayliner Technical Publications. All rights reserved.
No part of this publication may be reproduced, stored in any retrieval system, or transmitted in any form by any means, electronic, mechanical, photocopying, recording or otherwise, without prior written permission of Bayliner.
Printed in the United States of America.
General Notes
The material in this document is for information only and is subject to change without notice. While reasonable efforts have been made in the preparation of this document to assure its accuracy, Bayliner assumes no liability resulting from errors or omissions in this document, or from the use of information contained herein.
Due to our commitment to product improvement, Bayliner reserve s t he right to make changes in the product design, specifications , and equipment at any time without notice or obligation. Illustrations and/or photos may show optional equipment.
All Bayliner products meet or exceed USCG (United States Coast Guard) and /or NMMA (National Marine Manufacturer’s Association) construction standards. Manufactured with 1,1,1 Trichloroethane, a substance which harms public health and environment durin g the manufacturing process by destroying ozone in the upper atmosphere.
Proprietary Rights
This document discloses subject matter in which Bayliner has proprietary rights. The information and design disclosed herein were originated by and are the prop­erty of Bayliner. Neither receipt nor possession thereof confers or transfers any right to reproduce, copy, alter or disclose the document or any part thereof, any information contained therein, or to const ruct boats or any i tem from it, e xcept by writt en permis sion from or writt en agr eement with Bayliner. This document is to be returned upon request to Bayliner.
CONTENTS
Chapter 1: Welcome Aboard! 1
Dimensions and Tank Capacities 1 Dealer Service 1 Warranty Information 1 Boating Experience 2 Qualified Maintenance 2 Special Care for Moored Boats 2 Engine & Accessory Guidelines & Literature 3
Propeller
3
Safety Standards 4 Boat Lifting 5 Carbon Monoxide (CO) 6
CO Facts Factors that Increase the Effects of CO Poisoning Where & How CO Can Accumulate How to Protect Yourself & Others From CO CO Checklists CO Monitor End of Life Signal More Information
6
6
7
8
8
9
9
9
Chapter 2: Locations 10
Exterior Views 10
Hull Views Deck Views Helm
10
11
12
Component Locations 13
Chapter 3: Propulsion & Related Systems 22
Engine 22 Bilge Blower System 22 Fuel System 23
Fuel Fill & Vent Anti-siphon Valve Fuel Filters
24
24
24
Chapter 4: Controls & Gauges 25
Steering 25 Shift/Throttle Controls 25 Power Trim & Tilt 25 Trim Tabs 25 Gauges 26
Cleaning the Gauges Gauge Fogging Radio Transmission Interference Fuel Gauge
26
26
26
26
Chapter 5: Plumbing 27
Bilge Pumps 27
Bilge Pump Testing Built-in Autofloat Switch Testing
Seawater Systems 29
Seacocks Seawater Strainers
29
Freshwater System 30
Transom Shower Freshwater System Winterization
Water Heater (If Equipped) 32
Winterizing the Water Heater Preparing the Water Heater for Use After Winterizing
Drain Systems 35
Deck Drains Sink Drains Shower Drain System (If Equipped)
35
35
Portable Toilet (If Equipped) 36 Marine Head & Holding Tank (If Equipped) 36 Air Conditioner (If Equipped) 37
28
28
29
30
31
33
34
35
Chapter 6: Deck Equipment 38
Cleats & Bow/Stern Eyes 38 Canvas & Vinyl Tops & Enclosures 38
Installing the Bimini Top & Enclosure Curtains Canvas Care Clear Vinyl Care
40
41
39
Chapter 7: Appliances & Entertainment Systems 42
Alcohol/110-Volt Electric Stove (If Equipped) 42 Refrigerator (If Equipped) 43 Audio Equipment 43
Chapter 8: Convertible Seats, Beds, & Tables 44
Dinette To V-Berth Conversion 44
Chapter 9: Lights 45
Care & Maintenance 45 Interior & Exterior Lights 45 Navigation Lights 45 Spotlight (If Equipped) 45
Chapter 10: Electrical System 46
12-Volt DC System 47
Batteries Battery Switch (If Equipped with One Battery) Battery Switch (If Equipped with Two Batteries) Battery Switch Positions Fuses & Circuit Breakers 12-Volt DC Accessory Outlets Alternator Battery Charger (If Equipped)
47
48
49
49
49
49
110-Volt AC System (If Equipped) 50
Shore Power Connecting to Shore Power
51
52
Electrical Routings 53
Deck 12-Volt Electrical Harness Hull 12-Volt Electrical Harness 120-Volt AC System (If Equipped)
53
53
54
Important Records 55
Float Plan 56
47
48
Hazard Boxes & Symbols
This box alerts you to immediate hazards whi ch WILL cause severe personal injury or death if the warning is ignored.
DANGER!
!
This box alerts you to hazards or unsafe pract ice s whic h COULD r esul t i n seve re personal injury or death if the warning is ig nored.
WARNING!
!
This box alerts you to hazards or unsafe pract ice s whic h COULD r esul t i n minor pe rsonal injury or cause product or property damage if the warning i s ig nored.
CAUTION
!
This box calls attention to inst all ati on, ope rati on or m ai ntena nce i nform at ion, whi ch is im por­tant to proper operation but is no t hazard related.
NOTICE
CO POISONING
HAZARD!
EXPLOSION
HAZARD!
NO OPEN
FLAME!
HOT
HAZARD!
ROTATING
PROPELLER HAZARD!
FALLING
HAZARD!
ELECTRICAL
HAZARD!
FIRE
HAZARD!
RUN BILGE BLOWERS
FOR 4 MINUTES!
The hazard boxes and symbols shown below are used throughout this supplement to call attention to potentially dan­gerous situations which could lead to either personal injury or product damage. Read all warnings carefully and fol­low all safety instructions.
245 Cruiser Owner’s Manual Supplement
Chapter 1: Welcome Aboard!
This Owner’s Manual Supplement provides specifi c infor mation about your boa t that is not covered in the Cruiser & Yacht Owner’s Manual.
The Cruiser & Yacht Owner’s Manual contains general information about safe operating practices, general boat- ing regulations, and general maintenance techniques. Information that is more specific to your particular boat is found in this Owner’s Manual Supplement.
Before using your bo a t , study this Owner’s Manual Supplement, the Cruiser & Yacht Owner’s Manual, and all engine and accessory literature carefully . If similar instructions are found in more than one manual, always refer to the specific manufacturer’s manual (such as the engine manual) for the most complete and accurate information.
Keep this Owner’s Manual Supplement and the Cruiser & Yacht Owner’s Manual on your boat in a secure, yet readily available place.
Dimensions and Tank Capacities
Overall Length
24' 1" 25' 7" 6' 9" 8' 5" 1' 5" 2' 9" 65 Gallons 20 Gallons 20 Gallons
Length Rigged
Bridge
Clearance
Beam
Draft
(Hull)
Draft
(Maximum)
Fuel
Capacity
Freshwater
Capacity
Waste Holding
Tank Capacity*
Dealer Service
Your dealer is your key to service.
Ask your dealer to explain all systems before taking delivery of your boat.
Contact your dealer if you have any problems with your new boat.
If your dealer cannot help, call our customer service hotline: 360-435-8957 or send us a FAX: 360-403-4235.
Buy replacement parts from any authorized Bayliner dealer.
You can access on-line parts catalogs, links to vendor websites, and other helpful features by logging on
to http://www.baylinercustomercare.com
.
Warranty Information
Bayliner offers a Limited Warranty on each new Bayliner purchased through an authorized Bayliner dealer.
A copy of the Limited Warranty was included in your owner’s packet.
If you did not get a copy of the Limited Warranty, please contact your Bayliner dealer or call 360-435-8957 for
a copy.
1
Chapter 1: Welcome Aboard! 245 Cruiser Owner’s Manual Supplement
CONTROL HAZARD!
An experienced operator MUST be in contr ol of your boat at ALL t imes. Do NOT operate your boat while under the influence of al cohol or drugs .
WARNING!
!
To maintain the safe ty of your bo at, al low ONLY trained personnel to work on, or cha nge, in any way, the:
Steering sys tem
Propulsion system
Engine control system
Fuel system
Environmental contr ol sys tem
Electrical system
Navigation system
WARNING!
!
This Owner’s Manual Supplement
The Cruiser & Yacht Owner’s Manual
The engine owner’s manual, and;
All accessory literature.
Applying an epoxy barrier coating to the hull bot tom wil l hel p prevent gel coat blisteri ng
while your boat is moored.
Cover the barrier coating with several coats of anti-fouling paint.
Many states regulate the chemical co ntent of bottom paints in order to meet env ironmental
standards. Your local dealer can recommend bottom paints, a nd about t he l aws in e ffect in your area.
NOTICE
Boating Experience
If this is your first boat or if you are changing to a type of boat you are not familiar with, for your own comfort and safety, get handling and operating experience before assuming command of your boat.
Take one of the boating safety classes offered by the U.S. Power Squadrons or the U.S. Coast Guard Auxiliary. For more course information, including dates and locations of upcoming classes, contact the organizations directly:
U.S. Power Squadrons: 1-888-FOR-USPS (1-888-367-8777) or on the Internet at: http://www.usps.org
In Canada, for the CPS courses call 1-888-CPS-BOAT.
U.S. Coast Guard Auxiliary: 1-800-368-5647 or on the Internet at: http://www.cgaux.org
Outside the United States, your selling dealer, national sailing federation, or local boat club can advise you of local sea school s or competent instructors.
Qualified Maintenance
Failure to maintain your boat’s systems (listed i n the warning above) as designed could violate the laws in your juris­diction and could expose yourself and others to the danger of bodily injury or accidental death.
Follow the maintenance instruction s in:
Special Care for Moored Boats
While moored, your boat’s hull bottom will collect marine gro wth that not onl y looks bad, but als o reduc es perf or­mance, and could damage the gelcoat.
As often as needed for you r area, haul your boat out of the water and scrub t he hull bott om with a bris tle brush and soap and water.
2
245 Cruiser Owner’s Manual Supplement Chapter 1: Welcome Aboard!
BEFORE starting or working on your engine(s), r e ad the engine manual.
NOTICE
BEFORE using the accessories on your boat, r ead t h e ac cess ory manual s.
NOTICE
BEFORE storing your boat, refer to your e ngine and accessory manuals for storage/wi nter iza ­tion instructions.
NOTICE
Certain modifications to your boat WILL result in cancellation of your warra nty protection. ALWAYS check with your dealer BEFORE making any modifications to your boat.
NOTICE
Engine Break-in Procedure
Engine Starting and Stopping
Gear Shifting
Fuel and Oil Recommendations
Engine Maintenance
Engine Storage/Winterization
ENGINE DAMAGE HAZARD!
The factory standard propell er may not be the best for your par ti cular boat a nd load condi­tions. Refer to the engine manual for e ngine RPM rat ings . The engi ne shoul d reach, but not exceed its full rated RPM when full-t hrottle is applied.
Immediately contact your local Bayliner dealer if:
The engine cannot reach its full ra ted RPM when ful l-throttle is applie d, or;
The engine exceeds its full rated RPM when full-t hrottle is applied.
CAUTION
!
Engine & Accessory Guidelines & Literature
Your boat’s engine and accessories were selected to provide optimum performance and service.
Installing a different engine or adding accessories may affect your boat’s running trim.
If you choose to install a different engine or add accessories that may affect your boat’s running trim, have a
trained marine technician perform a safety inspection and handling test before using your boat again.
The engine and accessorie s on your b oat have their own manuals. Read these manual s before using the engine and
accessories.
Unless noted otherw ise , all engine and accessory literature referred to in this supplement is included in your owner’s packet.
While the topics listed below may be included in this supplement and in the Cruiser & Yacht Owner’s Manual, always refer to the engine manual first for specific inform ation on these importan t subjects:
Propeller
Keep the propeller in good repair and at the correct pitch for your particular situation.
A slightly bent or nicked propeller will adversely affect the performance of your boat.
3
Chapter 1: Welcome Aboard! 245 Cruiser Owner’s Manual Supplement
FALLING and ROTATING PROPELLER HAZARD!
NEVER allow anyone to ride on parts of your boat NOT designed for such use.
Sitting on seat-backs, lounging on the forward deck, bow riding, gun-
wale riding or occupying the transom plat form while underway is e speciall y hazardous and WILL cause personal injury or death.
DANGER!
!
FALLING, ROTATING PROPELLER and CARBON MONOXIDE POISONING HAZARD!
NEVER allow anyone to occupy , or ha ng from, the back deck or transom platform while t he eng ine is running.
Teak surfing, draggi ng, or wate r skiing within 20 feet of a moving watercraft can be fatal.
DANGER!
!
DANGER
PERSONAL SAFETY HAZARD!
ALWAYS secure the anchor and other loose objects BEFORE getting underway.
The anchor and other items that are NOT properly secured can come l oose when your boat
is moving and cause personal injury or death.
DANGER!
!
A wide variety of components used on this vessel cont ain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm.
Examples Include:
Engine and generator exhaust
Engine and generator fuel, and other liquids such as cool ants and oi l, especially used
motor oi l
Cooking fuels
Cleaners, paints, and substances used for vesse l repair
Waste material s t hat result from wear of ves sel component s
Lead from battery terminals and from other sources such as ballast or fishing sinkers
To Avoid Harm:
Keep away from engine, generator, and cooking fuel exhaust fumes.
Wash exposed skin t horoughly with soap and water after handli ng t he subst ances above.
WARNING!
!
Safety Standards
Your boat’s mechanical and electrical systems were designed to meet all safety standards in effect at the time it was built. These standards help insure your safety and the safety of other people, vessels and property.
Read this supplement, the Cruiser & Yacht Owner’s Manual, the engine owner’s manual, and all accessory instruc- tions for important safety standards and hazar d information.
4
245 Cruiser Owner’s Manual Supplement Chapter 1: Welcome Aboard!
PERSONAL INJURY and/or PRODUCT or PROPERTY DAMAGE HAZARD!
Lifting slings can slip on the hull, which c ould ca use se rious injury or death.
ALWAYS secure the forward li ft ing s ling to the aft lifting sli ng BEFORE lifting. Thi s wil l
reduce the risk of sling sl ippage.
WARNING!
!
PERSONAL INJURY and/or PRODUCT or PROPERTY DAMAGE HAZARD!
NEVER lift any boat using the cleats, or th e bow/s ter n eyes .
WARNING!
!
PERSONAL INJURY and/or PRODUCT or PROPERTY DAMAGE HAZARD!
Water in the bi lge can shi ft and change the balance of the load.
If water is present in the bilg e, pump or drai n the water out of the bilge ar eas BEFORE lift-
ing your boat.
WARNING!
!
PRODUCT or PROPERTY DAMAGE HAZARD!
When lifting any boat, ALWAYS use a sprea der bar.
The spreader bar MUST be equal to the width of the boat at each lifting point.
Make sure your boat remains level during lifting. The engine can be damaged by water
ingestion if the stern is lif te d higher than the bow.
CAUTION
!
Boat Lifting
Always follow the lift equipment’s instructions and requirements.
When lifting your boat, always position the lifting slin gs at the foreward and aft lifting sling label positions.
5
Chapter 1: Welcome Aboard! 245 Cruiser Owner’s Manual Supplement
Carbon monoxide gas (CO) is colorless, odorless, t ast eless, and extremely danger ous.
ALL engines, generators, and fuel burning appliances produce CO as exhaust.
Prolonged exposur e to low conc entr ati ons or very qui ck exposure to high concentrations WILL cause BRAIN DAMAGE or DEATH.
Teak surfing, dragging , or wate r ski ing wi thi n 20 fe et of a moving wa ter ­craft can be fatal.
DANGER!
!
CARBON MONOXIDE POISONING HAZARD!
NEVER use full canvas and vinyl enclosures when the engine or generator is running.
For proper fresh air circulation, remove for ward, aft , and bot h side encl o­sure curtains BEFORE starting the en gine o r gene rato r.
Read the Carbon Monoxide (CO) section in Chapter 1 of this supplement.
DANGER!
!
Carbon Monoxide (CO)
CO Facts
CO poisoning causes a significant number of boating deaths each year.
Called the "silent killer", CO is an extremely toxic, colorless, odorless and tasteless gas.
CO can harm or even kill you inside or outside your boat.
CO can affect you whether you’re underway, moored, or anchored.
CO symptoms are similar to seasickness or alcohol intoxication.
CO can make you sick in seconds. In high enough concentrations, even a few breaths can be fatal.
Breathing CO blocks the ability of your blood to carry oxygen.
The effects are cumulative. Even low levels of exposure can result in injury or death.
Factors that Increase the Effects of CO Poisoning
Age
Smokers or people exposed to high concentrations of cigarette smoke
Consumption of alcohol
Lung disorders
Heart problems
Pregnancy
6
245 Cruiser Owner’s Manual Supplement Chapter 1: Welcome Aboard!
Using engine, generato r , or other fuel burnin g device when boat is moored in a confined space.
Mooring too close to another boat that is using its engine, generator, or other fuel burning device.
Running your engne or generator with full canvas and vinyl enclosures installed.
Running boat with trim angle of bow too high. Running boat without through ventilation
(station wagon effect).
Where & How CO Can Accumulate
Stationary conditions that increase CO accumulations include:
To correct these stationary situations:
Close all windows, portlights and hatches.
If possible, move your boat away from source of CO.
Remove forward, aft, and both side enclosure curtains BEFORE starting the engine or generator.
Running conditions that increase CO accumulations include:
To correct these running situations:
Trim bow down.
Open windows and canvas.
When possible, run boat so that prevailing winds help dissipate exhaust.
7
Chapter 1: Welcome Aboard! 245 Cruiser Owner’s Manual Supplement
How to Protect Yourself & Others From CO
Know where and how CO may accumulate in and around your boat (see previous page).
Stay away from the transom while the vessel is idling or underway – The transom is where carbon monoxide col-
lects while idling or underway.
Avoid Other Idling Vessels – Idling vessels produce concentrated levels of carbon monoxide.
Always maintain fresh air circulation throughout your boat.
Know where your engine and generator exhaust outlets are located and keep everyone away from these areas.
Never sit on, or hang onto, the back deck or transom platform while the engine is running.
Never enter the areas under transom platforms where exhaust outlets are located.
Although CO can be present without the smell of exhaust fumes, if exhaust fumes are detected on your boat, take
immediate action to dissipate these fumes.
Treat sympt oms of se asick ness as possib le CO pois oning. Get the pe rson into f resh a ir immediately. Seek medical attention—unless you’re sure it’s not CO.
Maintain the CO monitors that were installed inside your boat. Never ignore any alarm. Replace monitors as recommended by the monitor manufacturer.
Follow the CO checklists provided below.
Get a Vessel Safety Check.
For information on how to get a free VESSEL SAFETY CHECK, visit www.vesselsafetycheck.org or contact your local U.S. Coast Guard Auxiliary or United States Power Squadrons®.
U.S. Coast Guard Auxiliary: 800-368-5647 or online at: http://www.cgaux.org U.S. Power Squadrons: 888-367-8777 or online at: http://www.usps.org
CO Checklists
Trip Checklist
Make sure you know where the exhaust outlets are located on your boat. Educate all passengers about the symptoms of CO poisoning and where CO may accumulate. When docked, or rafted with another boat, be aware of exhaust emissions from the other boat. Listen for any change in exhaust sound, which could mean an exhaust component failure. Test the operation of each CO monitor by pressing the test button.
Monthly Checklist
Make sure all exhaust clamps are in place and secure. Look for exhaust leaking from exhaust system components. Signs include rust and/or black streaking, water
leaks, or corroded or cracked fittings. Inspect rubber e xhaust hoses fo r bur ned, cr acked, or dete rior ated s ec tions. All rubber hoses shoul d be pli able and
free of kinks.
Annual Checklist
Have a Trained Marine Technician:
Replace exhaust hoses if cracking, charring, or deterioration is found. Ensure that your engines and generators are properly tuned, and well maintained.
Inspect each water pump impeller and the water pump housing. Replace if worn. Make sure cooling systems are in working condition.
Inspect all metallic exhaust components for cracking, rusting, leaking, or loosening. Make sure they check the cylinder head gasket, exhaust manifold, water injection elbow, and the threaded adapter nipple between the manifold and the elbow.
Clean, inspect, and confirm proper operation of the generator cooling water anti-siphon valve (if equipped).
8
245 Cruiser Owner’s Manual Supplement Chapter 1: Welcome Aboard!
CARBON MONOXIDE POISONING HAZARD!
CO monitor installation or repl acement shall be done by qual ifi ed personnel ONLY.
NEVER disconnect your CO monitor.
DANGER!
!
The stereo memory and the CO monitor place small but c onst ant drains on the battery.
If equipped, plug into shore po we r wit h t he bat te ry c harger tur ned On whenever your boat
will be unattended for an extended amount of time.
NOTICE
United States Coast Guard Office of Boating Safe ty ( G -OPB-3 )
2100 Second Street SW Washington, DC 20593 www.uscgboating.org 1-800-368-5647
National Marine Manufacture rs Association (NMMA)
200 East Randolph Drive Suite 5100 Chicago, IL 60601-9301 www.nmma.org 312-946-6200
American Boat & Yacht Council, Inc. (ABYC)
613 Third Street Suite 10 Annapolis, MD 21403 www.abycinc.org 410-990-4460
CO Monitor
Read the manufacturer’s instructions for your CO monitor. If you did not receive the manufacturer’s instruc- tions, call (800) 383-0269 and they will be mailed to you.
End of Life Signal
Your CO monitor may be equipped with an End Of Life (EOL) signal to alert you when the monitor has reached the end of its service life and must be replaced.
The EOL signal will be activated by a timer set for 4 years, 11 months from the date of manufacture.
The alert signal may vary depend ing on the type of CO monitor you have , so check the uni t's opera tion manual f or
further in formation an d instructions.
NOTE: If the EOL signal activates, and it is not possible to immediately acquire a replacement unit; you can tempo­rarily reset the EOL sig nal for 72 hours at a time (3 days) for a total of u p to 30 days. After this time, the unit will
continuously signal EOL and wi ll no l onger detect CO and MUST BE REPLACED! DO NOT DISCONNECT THE MONITOR UNTIL YOU HAVE A REPLACEMENT MONITOR READY TO INSTALL! REMOV­ING THE LITHIUM BATTERY WILL CAUSE THE UNIT TO SIGNAL EOL PERMANENTLY!
If your CO monitor is not equipped with an EOL signal:
Replace your CO monitor by the "REPLACE BY DATE" printed on the monitor.
If no "REPLACE BY DATE" can be found, immediately replace the unit.
Replacement CO monitors can be purchased from your local Bayliner dealer.
More Information
For more information about preventing carbon monoxide poisoning on recreational boats and other boating safety tips, contact:
For information on how to get a free VESSEL SAFETY CHECK, visit www.vesselsafetycheck.org or contact your
local U.S. Coast Guard Auxiliary or United States Power Squadrons®.
U.S. Coast Guard Auxiliary: 800-368-5647 or online at: http://www.cgaux.org U.S. Power Squadrons: 888-367-8777 or online at: http://www.usps.org
9
Chapter 2: Locations
Exterior Views
Hull Views
245 Cruiser Owner’s Manual Supplement
10
245 Cruiser Owner’s Manual Supplement Chapter 2: Locations
Deck Views
11
Chapter 2: Locations 245 Cruiser Owner’s Manual Supplement
ACTUAL LAYOUT MAY VARY DEPENDING ON ENGINE AND ACCESSORY OPTIONS.
NOTE: TYPICAL HELM LAYOUT SHOWN.
Helm
12
245 Cruiser Owner’s Manual Supplement Chapter 2: Locations
Component Locations
12-Volt DC Accessory Outlets (2 Total):
One is located at the forward end of the galley assembly.
One is located at the helm.
12- Volt DC Push-to-Reset Circuit Bre akers: Locat ed at the helm, under the dash.
11 0-V olt AC Panel (If Equipped): Located in the cabin, next to the galley sink.
13
Chapter 2: Locations 245 Cruiser Owner’s Manual Supplement
Battery or Batteries: Located on the port side of the engine room.
Battery Charger (If Equipped): Located on the port side of the engine room, on the forward wall.
Battery Switches: Located in the storage hatch under the helm seat.
Bilge Blower Switch: Located on the helm switch panel.
14
245 Cruiser Owner’s Manual Supplement Chapter 2: Locations
Bilge Pumps (2 Total):
The aft bilge pump is located in the engine room bilge.
If your cabin entry steps are removeable; access to the for­ward bilge pump is through the hatch in the bottom step.
If your cabin entry steps are not remove­able; access to the forward bilge pump is through a floor hatch at the bottom of the forward wall in the aft berth.
15
Chapter 2: Locations 245 Cruiser Owner’s Manual Supplement
CO Monitor: Located on the starboard side of the cabin, on the aft wall.
Depth Sounder Tranducer: Located in the engine room bilge.
Freshwater Fill Deck Fitting: Located on
the starboard aft deck.
16
245 Cruiser Owner’s Manual Supplement Chapter 2: Locations
Freshwater Pump: Located above the tran­som, on the port side of the engine room.
Freshwater Pump Switch: Lo cated at the forwa rd end of th e galley.
Freshwater Tank: Located on the star­board side of the engine room.
17
Chapter 2: Locations 245 Cruiser Owner’s Manual Supplement
Fuel Fill Deck Fitting: Located on the starboard aft corner of the deck.
Fuel Tank: Acc ess to the fu el tank fittin gs is in the forward area of the engine room bilge.
Macerator Underwater Discharge Seacock (If Equipped): Located in
the engine room.
18
245 Cruiser Owner’s Manual Supplement Chapter 2: Locations
Marine Head Seawater Pickup Valve:
If your cabin entry steps are removeable; access to the marine head seawater pickup valve is through the hatch in the bottom step.
If your cabin entry steps are not remove­able; access to the marine head seawater pickup valve is through a floor hatch at the bot­tom of the forward wall in the aft berth.
Marine Head Waste Hold­ing Tank (If Equipped):
Located on the sta rboard side of the engine room.
19
Chapter 2: Locations 245 Cruiser Owner’s Manual Supplement
Marine Head Waste Pump-out Deck Fitting (If Equipped): Located
on the starboard aft corner of the deck.
Navigation Lights:
The red and green bow lights are located on the forward deck.
The white all-round light is located on the transom.
Shore Power Inlet (If Equipped): Located on the
port side of the deck, above the louvers.
20
245 Cruiser Owner’s Manual Supplement Chapter 2: Locations
Transom Shower (If Equipped):
Located on the port side of the cockpit.
Trim Tab Hydraulic Fluid Reservoir: Located on the aft
wall in the engine room.
21
245 Cruiser Owner’s Manual Supplement
Read the engine manual BEFORE starting or working on your engi ne.
NOTICE
Engine Break-in Procedure
Engine Starting and Stopping
Gear Shifting
Fuel and Oil Recommendations
Engine Maintenance
Engine Storage/Winterization
FIRE and EXPLOSION HAZARD!
Fuel vapors can explode! BEFORE starting the engi ne:
1. Check the bilge areas for fuel vapors or leaking fuel. If you see leaking fuel or smell fuel vapors:
a. Do NOT start the engine, do NOT turn On any electrical devices, put out ALL cigarettes,
cigars, and other source s of f la me o r ig niti on. b. Get everyone off your boat. c. Get trained help to find and fix the probl em.
2. Run the bilge blowers for at least four minutes BEFORE engine starting, elect ric al s yst em work, or turning on electrical devi ces .
If you smell fuel vapors and the engine is already running; a. Shut Off the engine and turn Off ALL electrical devices. b. Put out ALL cigarettes, cigars, and ot her s ources of flame or ignition. c. Get trained help to find and fix the probl em.
NEVER obstruct or change the bilge blower system.
WARNING!
!
Chapter 3: Propulsion & Related Systems
Engine
While the topics listed below may be included in this supplement and in the Cruiser & Yacht Owner’s Manual, always refer to the engine manual first for specific inform ation on these importan t subjects:
Bilge Blower System
The bilge blower system:
Removes explosive vapors from engine and bilge a reas.
Draws fresh air into engine and bilge areas through the vents.
To make sure engine and bilge areas are properly ventilated:
Use the "sniff test " to check the engine
and bilge areas for fuel vapors before starting the engine.
Run the bilge blower for at least four minutes before starting the engine.
Keep the blower On until your boat has reached planing speed.
Always run the blower when running your boat below planing speed.
22
245 Cruiser Owner’s Manual Supplement Chapter 3: Propulsion & Related Systems
FIRE, EXPLOSION, and OPEN FLAME HAZARD!
Thoroughly inspect the fuel sy ste m for l eaks e very t ime you t ake o n fuel.
Fueling instructions are pr ov ided i n the Cruiser & Yacht Owner’s Manual, and fuel recom-
mendations are prov ided i n the engine operation manual. Carefully read this information.
WARNING!
!
Avoid the storage or handling of ge ar near the f uel lines, fittings and tank.
CAUTION
!
On diesel engine models, air in the diesel suppl y sys tem ca n stop a n engi ne or s everely restrict performance.
If you suspect air in the fuel lines, refer to your engine operation manual fo r det ail ed instructions on how to bleed the syste m.
NOTICE
Fuel System
23
Chapter 3: Propulsion & Related Systems 245 Cruiser Owner’s Manual Supplement
If an engine running problem is diagnosed a s fuel starvat ion, check the anti-siphon valve.
If the valve is stuck or clogged, ONLY change or replace it whi le the e ngine i s Off.
NEVER run the engine with the anti-siphon valve removed, except in an emergency.
NOTICE
Fuel Fill & Vent
The fuel fill deck fitti ng is marked " GAS".
If you have problems filling the fuel tank, see if the fuel fill hose or fuel tank vent hose is kinked or collapsed.
If there are no visible signs of a problem, contact your local dealer.
Anti-siphon Valve
The anti-siphon valve is a vital fuel system part.
If the fuel line ruptures, this valve prevents the siphoning of fuel from the tank.
The valve is located on the fuel tank, where the fuel feed line attaches to the tank.
This spring-loaded valve is opened by fuel pump vacuum.
Fuel Filters
The fuel pickup tube, located inside the fuel tank, is equipped with a fine mesh screen filter.
Also, when supplied by the engine manufacturer, a fuel filter is installed on the engine.
Periodically replace the fuel filter to make sure it remains clean and free of debri s.
Talk to your selling dealer or local marina about fuel additives that help prevent fungus or other buildup in your
fuel tank.
24
245 Cruiser Owner’s Manual Supplement
LOSS OF CONTROL HAZARD!
Improper maintenance of the shif t/ throttle hardware may cause a sudden l oss o f cont rol!
WARNING!
!
TRIM TAB (TYPICAL)
TRANSOM
TYPICAL TRIM TAB
Chapter 4: Controls & Gauges
Steering
Your boat features a power-assisted rack-and-pinion steering system.
For information about the power-assist fluid reservoir, refer to the engine operation and maintenance manual.
Boat steering is not self-centering.
Refer to the engine man ual for more steering system details.
Shift/Throttle Controls
Read all of the information about the shift/throttle controls in the shift/throttle manual, the engine operation manual, and the Cruiser & Yacht Owner’s Manual.
Power Trim & Tilt
The stern drive on your boat is equipped with power trim and tilt.
Trim and tilt instructions are provided in the engine operation manual and the shift/throttle manual.
Trim Tabs
Before using the trim tabs, read the trim tabs’ owner’s manual.
The trim tabs are controlled by two rocker switches at the helm.
Check and refill the trim tab hydraulic fluid reservoir as directed
in the trim tabs’ owner’s manual.
For the location of the fluid reservoir, see the Component Locations section in Chapter 2 of this supplement.
25
Chapter 4: Controls & Gauges 245 Cruiser Owner’s Manual Supplement
PRODUCT or PROPERTY DAMAGE HAZARD!
Use only mild soap and water to clean the gauge lenses and bez els .
Use of other cleaners, including common window cleaning solutions, may cause the lenses
to crack.
Lenses cracked in this manner will NOT be covered by our warranty.
CAUTION
!
Gauges
Cleaning the Gauges
Gauge Fogging
Moisture may occasionally find its way into the gauges causing lens fogging.
Turning On the gauge lights will help dry the lenses.
Fogging will not harm the gauges.
Radio Transmission Interference
VHF or other radio transmissions may cause brief erratic readings on the tachometer. This will not damage the tachometer gauge or affect its accuracy when not transmitting.
Fuel Gauge
It is normal for the pointer on your fuel gauge to bounce as fuel sloshes back and forth in the fuel tank.
26
245 Cruiser Owner’s Manual Supplement
NOTICE
Discharge of oil, oil waste, or fue l i nto nav igabl e wate rs i s prohibited by law. Violators are sub­ject to legal action by the lo cal authorities.
Chapter 5: Plumbing
Bilge Pumps
Y our boat has two bilge pumps for pumping water out of the bilge.
Built-in autofloat switches turn On the bilge pumps if bilge water rise s above a preset lev el.
You can also turn On the bilge pumps using the switches at the helm.
The bilge pumps are wired directly to the batteries. Unless the batteries are dead, the bilge pump system should keep working even when your boat is unattended.
27
Chapter 5: Plumbing 245 Cruiser Owner’s Manual Supplement
Bilge Pump Testing
The bilge pump is vital to the safety of your boat.
Test the bilge pump often.
1. Turn On the bilge pump switch at the helm.
2. Make sure that water in t he bilge is pum ped overboard .
If there is water i n the bi lge and t he pum p motor is ru nning but not pumpi ng, inspe ct the discha r ge h ose for a ki nk
or collapsed area.
If the discharge hose looks okay, check the bilge pump and strainer for clogging debris.
Inspecting and clearing debris from the bilge pump:
1. Squeeze the holding tabs on each side of the strainer and pull the pump hous ing out of the strainer.
2. Remove debris from the strainer and the bottom of the pump housing.
PUMP HOUSING
FLOAT SWITCH
TEST KNOB
3. Remove the impeller guard screw and the impeller guard.
4. Remove all debris from the pump cham­ber, from around the impeller, and from the tab slots on the sides.
5. Make sure the impeller is firmly attached
IMPELLER
GUARD SCREW
STRAINER
IMPELLER GUARD
HOLDING TABS
to the shaft and is not cracked or broken.
6. Reinstall the impeller guard and screw, and the pump housing on the strainer. Make sure both tabs lock into the slots.
Built-in Autofloat Switch Testing
The autofloat switch turns the bilge pump On when water rises above a preset level.
Test the autofloat switch often as follows:
Autofloat switch testing:
Twist the float switch test button to turn On the bilge pump.
If the pump does not turn On, check the fuse on the fuse block.
If the fuse is good, but the switch still does not work, it may mean the switch is bad, or the battery is dead.
28
245 Cruiser Owner’s Manual Supplement Chapter 5: Plumbing
FLOODING and SWAMPING HAZARD!
Close the seacock(s) when leaving your boat unattended for any leng th of ti me.
If a seacock is left open, a hose failure could flood the bilge, swamp the bat te rie s and th e
engine, and even sink your boat.
WARNING!
!
SYSTEM DAMAGE HAZARD!
BEFORE using any system that has a seacock, make sure that the s yst em’s seacock is Open.
Inspect and lubricate all seacocks annuall y.
CAUTION
!
THRU-HULL INTAKE
HULL
SEACOCK GASKET
SEACOCK
SEACOCK
LEVER
SECTION
SEACOCK & THRU-HULL
COMPONENTS (TYPICAL)
90 DEGREE
STRAINER
FLOODING HAZARD!
BEFORE taking apart a seawater strainer for cleaning or other work, Close the seacock that sends seawater to that strainer.
Failure to close the seacock before taking apart the seawater strainer may allow large amounts of water to flood the bilge, which c ould s wamp th e batt eri es a nd the e ngine, and even sink your boat.
Keep the seacock Closed until the s eawate r st raine r i s com ple tel y reassembled.
SYSTEM DAMAGE HAZARD!
After putting the seawater strainer back t oget her, make sure that the seacock v alve is Open BEFORE using the component/system.
CAUTION
!
Seawater Systems
Seacocks
Thru-hull inlet or outle t fittings located near or below the water­line feature seacoc k va lves. You can close a seaco ck to st op water entry:
If the hose connected to the seacock fails, or;
To work on equipment served by the seacock.
Seacocks are used on your boat in seawater intake or liquid-dis­charge systems including, but not limited to:
Air conditioner (if equipped)
Marine head (toilet)
Before using any system with a seacock, make sure the seacock is Open and stays Open until the system is shut Off.
Seawater Strainers
Seawater strainers are used to filter incoming seawater in some seawater intake systems. NOTE: Not all seawater
intake sys t ems have seawater strainers.
If equipped, the seawater strain er is located near the seawater intake system’s seacock.
Check the strainers for leaks and/or debris every time you use your boat.
Refer to the seawater strainer inst ruction sheet for cleaning and maintenance information.
29
Chapter 5: Plumbing 245 Cruiser Owner’s Manual Supplement
ONLY use safe drinking (potable) water in y our boat ’s freshwater system.
ONLY use FDA approved "drinking water safe" hos es when f il li ng the f reshwater tank.
NEVER use common garden hoses for drinking water.
WARNING!
!
Freshwater System
Read the Freshwater System section in the Cruiser & Yacht Owner’s Manual.
The freshwater fill deck fitting is marked WATER.
Pressurize the freshwater system by either turning On the freshwater pump switch (the batter y switch must also
be On).
For the location of the freshwater pump switch, see the Component Locations section in Chapter 2 of this supplement.
Turn Off the freshwater pump switch when your boat is not in use or when the freshwater tank is empty.
Inspect an d clean the freshwater filter often (the filter is located on the freshwater pump).
If your boat is to be left unatt ended for a lo ng period of ti me, pump the fresh water ta nk dry to preven t stored water
from becoming stagnant and distasteful.
If the freshwater s ystem nee ds to be di sinf ected , ask your deal er abou t tre atments avail able fo r your bo at’s system.
Transom Shower
Read the ma nufacturer’s instructions before using the transom shower for the first time.
The freshwater pump s witch must be turned On before using the transom shower.
30
245 Cruiser Owner’s Manual Supplement Chapter 5: Plumbing
FRESHWATER SYSTEM DAMAGE HAZARD!
A faucet MUST be Open when compressed air is blown t hrough the freshwater syst em.
NEVER blow compressed air thr ough t he wate r sys tem when ALL of the faucets are Closed.
CAUTION
!
TYPICAL VIEW
NOTE: LOCATION OF TEE FITTING & DRAIN PLUG MAY VARY
Freshwater System Winterization
1. Turn On the freshwater pump switch.
2. Open all of the faucets and showers and let the freshwater system drain completely.
3. Turn Off the freshwater pump switch. All of the remaining water must be removed from the water lines. The re are two ways to remov e the r emaini ng water
from the lines:
Compressed Air
Gravity Draining
Compressed Air
You must have an air compressor with an air hose and an air nozzle.
1. Remove the water line from the outlet side of the freshwater pump (opposite side from filter).
2. Open the faucet that is furthest away from the fresh­water pump.
3. Place th e air nozzl e against th e end of the just removed water line and blow air t hrough the sys tem.
4. When water stops coming out of the faucet , stop the air and Close the faucet.
5. One at a time, repeat this process on all faucets and showers.
Gravity Draining
1. Open all faucets and showers.
2. Remove the drain plug from the tee fitting on the freshwater tank.
3. When the water has stopped draining from the freshwater tank and the water lines, replace the drain plug.
31
Chapter 5: Plumbing 245 Cruiser Owner’s Manual Supplement
SCALDING HAZARD!
Water heated by the water heater can be hot e nough to scal d the skin.
WARNING!
!
WATER HEATER DAMAGE HAZARD!
Do NOT turn On the water heater ci r cuit br eaker on the 110-volt AC master panel until the water heater tank is COMPLETELY filled with water.
The tank is full if water flows from the tap when the hot water is turned On in the galley.
Even brief water heater operation with a dry tank WILL damage the he ati n g el ements .
Warranty replacements will NOT be made on elements damaged in this manner.
Turn the power Off and drai n the water heater when the chance of freezing exists (see the
winterizing instructions on th e nex t page ).
CAUTION
!
If 1 10- volt AC power i s bei ng provided by shore power, but the water heater is not working:
Make sure the water heater ci rcuit breaker on t he 110-volt AC master panel is switched On.
If the circuit br eaker is On, but the water heater is still no t w ork in g, ask your dealer how
to check the push-to-re set circuit breaker lo cat ed on t he wate r heat er.
NOTICE
Water Heater (If Equipped)
Read the water heater instruction manual and heed the warnings above.
The water heater is connected to the 110-volt AC power system.
To heat the water, turn On the water heater circuit breaker on the 110-volt AC master panel.
32
245 Cruiser Owner’s Manual Supplement Chapter 5: Plumbing
WATER HEATER DAMAGE HAZARD!
NEVER turn On the water heater br eake r on t h e 110-volt AC master panel while the water heater tank is empty.
Even brief water heater operation with a dry tank WILL damage the he ati n g el ements .
Warranty replacements will NOT be made on elements damaged in this manner.
T o pr event damage to t he water heater aft er winterizing, always label the br eaker switch on
the 11 0-vol t AC mast er panel as ’winterized’.
CAUTION
!
NOTICE
The freshwater system MUST be drained BEFORE winterizing the water heater (se e the Freshwater System W int eri zat ion I nstr uctions on the previous page).
A
B
C
"WATER HEATER IS EMPTY"
TAG ATTACHED TO WATER
HEATER CIRCUIT BREAKER
BY BRAND AND MODEL.
NOTE: TYPICAL WATER HEATER SHOWN. LOCATIONS OF FITTINGS MAY VARY
Winterizing the Water Heater
1. Turn Off the water
heater breaker.
2. Disconnect the hose (A) attached to the pressure relief valv e (B), and drain any water from the hose int o the bilge or into a bucket.
3. Open the pressure relief valve (B).
4. Open the drain valve (C).
5. Attach a tag to the water heater breaker to indicate that the tank is empty.
NOTE: Your boat came
with a tag attached to the water heater breaker. It is suggested that you keep this tag and re-use it when winterizing.
Leave the pressure rel ief
and drain valves Open until you fit out your boat after storage.
33
Chapter 5: Plumbing 245 Cruiser Owner’s Manual Supplement
WATER HEATER DAMAGE HAZARD!
Fill the water heater tank BEFORE turning On the wate r heat er c ircuit breaker on th e 110- volt AC master panel.
NEVER turn On the water heater circuit br eaker on the 110-volt AC master panel while the water heater tank is empty.
To make sure the tank is ful l, turn On a hot water f aucet. If water flows from the tap, t he water heater tank is full.
Even brief water heater operation with a dry tank WILL damage the he ati n g el ements .
Warranty replacements will NOT be made on elements damaged in this manner.
CAUTION
!
C
B
A
"WATER HEATER IS EMPTY"
TAG ATTACHED TO WATER
HEATER CIRCUIT BREAKER
BY BRAND AND MODEL.
NOTE: TYPICAL WATER HEATER SHOWN. LOCATIONS OF FITTINGS MAY VARY
Preparing the Water Heater for Use After Winterizing
Perform the following steps to put your winterized water heater back in service:
1. Close the drain valve
(A).
2. Close the pressure relief
valve (B).
3. Connect the hose (C) to the pressure relief valve (B).
4. Fill the water heater tank with fre shwater.
5. Remove the ‘winter­ized’ tag on th e water heater breaker on the 110-volt AC master panel after the water heater tank is com- pletely filled with fresh­water.
6. Turn On the water heater breaker.
34
245 Cruiser Owner’s Manual Supplement Chapter 5: Plumbing
Drain Systems
Deck Drains
Water on the deck is gravity drained overboard through the deck drains.
Keep the deck drains free of debris.
Sink Drains
The sinks are above the waterline and are gravity drained overboard.
Shower Drain System (If Equipped)
Shower water drains i nto a sump pump box.
An autofloat switch turns On the sump pump when the drain water rises to a preset level, and the drain water is pumped overboard.
Read the s ump system instruction sheet, paying special at tention to the maintenance and cold weather instructions.
35
Chapter 5: Plumbing 245 Cruiser Owner’s Manual Supplement
Check with local authorities for regulations regard ing t he legal use of marine head systems.
NOTICE
FLOODING and SWAMPING HAZARD!
Close the seawater int ake s eacoc k when leaving your boat unattended for any length of time.
If the seacock is left open, a hose fail ure could flood the bilge, swamp the batt eri es a nd engine, and even sink your boat.
WARNING!
!
Check with local authorities about t he l egal use of marine head systems.
NOTICE
Portable Toilet (If Equipped)
Read the manufacturer’s operating instructions before using the portable toilet.
Marine Head & Holding Tank (If Equipped)
Before using this system, read the
marine head’s operation and maintenance manual.
Look at the side of the holding tank to check the content level.
The dockside pump-out deck fitting is marked WASTE.
Empty the holding tank at every opportunity.
Using the Marine Head
1. Open the head’s seawater intake
seacock (the location of this seacock is described in the Component Locations section of Chapter 2).
2. Before using the head, pump
water into the bowl to wet the sides.
3. After use, pump until the bowl
is clean.
4. Pump a few more times to clean
the lines.
5. If excess waste causes the water to rise in the bowl, stop pumping until the water recedes.
Close the intake seacock when the system will not be used for long periods of time.
Winterizing the System
Read the marine head’s operation and maintenance manual for winterizing instructions.
36
245 Cruiser Owner’s Manual Supplement Chapter 5: Plumbing
CARBON MONOXIDE POISONING HAZARD!
Dangerous carbon monoxide gas (CO) can be brought into your boat through the air conditi oni ng syst em.
Read the Carbon Monoxide (CO) section in Chapter 1 of this supplement.
DANGER!
!
FLOODING and SWAMPING HAZARD!
Close the seawater int ake seacock before leaving yo ur boat unatt ended.
If the seacock is left open, a hose failure could flood the bilge, swamp the batte ry and engine,
and even sink your boat.
WARNING!
!
SYSTEM DAMAGE HAZARD!
Open the air c onditioner system’s seawater intake seacock BEFORE turning On the air con- ditioner.
This seacock MUST stay Open until the air conditioner is turned off.
CAUTION
!
Air Conditioner (If Equipped)
Read the air conditioner manual before using the air co nditioning system for the first time.
Before Each Use
Turn On the air cond itioner
breaker on the 110-volt AC mas­ter panel.
Open the seawater intake sea- cock. This seacock must remain Open while you’re running the air conditioner.
Check the seawater strainer for debris. If needed, clean the strainer as described in the Sea- water Systems section of this chapter.
37
Chapter 6: Deck Equipment
PERSONAL INJURY and/or PRODUCT or PROPERTY DAMAGE HAZARD!
NEVER lift your boat using the bow/stern eyes or t he cl eat s.
WARNING!
!
CARBON MONOXIDE POISONING HAZARD!
NEVER use full canvas and vinyl enclosures when the engine or generator is running..
For proper fresh air circulation, remove for ward, aft , and bot h side encl o­sure curtains BEFORE starting the en gine o r gene rato r.
Read the Carbon Monoxide (CO) section in Chapter 1 of this supplement.
DANGER!
!
PRODUCT or PROPERTY DAMAGE HAZARD!
Take down and secur ely stow ALL ca nvas & viny l BEFORE your boat is t ranspo rte d by road.
CAUTION
!
BEFORE cleaning and/or stowing your canvas or vinyl , r e ad the sections later in this chapter, Canvas Care and Clear Vinyl Care.
NOTICE
Two people are needed fo r most of the tasks listed in this sect io n.
NOTICE
Some canvas and vinyl options may not be descri bed. Make sure your dealer explains how to install all canvas and vinyl.
NOTICE
Cleats & Bow/Stern Eyes
Read the section on towing in the Cruiser & Yacht Owner’s Manual before:
Towing anything behind your boat.
Being towed by another vessel.
Canvas & Vinyl Tops & Enclosures
245 Cruiser Owner’s Manual Supplement
38
245 Cruiser Owner’s Manual Supplement Chapter 6: Deck Equipment
DECK
PIN
EYE
HINGE
END
SWIVEL END
EYE END
Installing the Bimini Top & Enclosure Curtains
1. Slide the wind­shield hinges (A) of the main bow (B) onto the wind­shield frame and secure with the pins.
2. Slide the eye ends of the aft legs (C) into the deck hinge s (D) and secure with the pins.
3. Unfold th e canvas top (E) and slide the windshield hinges (F) of the forward legs (G) onto the wind­shield frame and secure with the pins.
4. If equipped, zip the front curtain (H) and the side cur­tains (I) to the top (E) first and then snap the curtains to the windshield frame.
The jaw slides (J)
should not need to be adjusted.
If you decide to
adjust the jaw slide positions, obtain the correct measure­ments from your selling dealer.
39
Chapter 6: Deck Equipment 245 Cruiser Owner’s Manual Supplement
NEVER use detergents when washin g t he canvas . Detergents can destr oy t h e water repellency, and mildew/UV resistant fini sh of your ca nvas.
CAUTION
!
Soaking in bleach solutions may remove the waterproof finish of the fabric and may also decrease the life of the polyester thread used in the canvas .
If needed, a water repellent treatment should be reapplie d to your canvas. Ask your dealer about the treatments availabl e f or your boat’s canvas.
CAUTION
!
Canvas Care (see also ‘Clear Vinyl Care’ on next page)
After each use, especially in saltwater, rinse the canvas with cold freshw ater.
Before stowing, let the canvas air-dry completely.
The canvas can be rolled or folded for stowage.
Cleaning the Canvas
Regularly clean the canvas to prevent dirt, pollen, and etc. from embedding in the fabric. Generally, it is easiest to wash the canvas while it is installed on your boat.
Use a soft-bristled brush to remove all dust and loose dirt.
1. Hose down the canvas with freshwater.
2. Gently wash the canvas with a solution of lukewarm water (no more than 100° F) and non-detergent mild soap, such as Ivory Snow®, Dreft®, or Woolite®.
3. Rinse thoroughly to remove the soap.
4. Before stowing, let the canvas dry completely.
Stubborn Stains
Some stubborn stains may resist normal washing and you can try the methods below. However, these methods may remove the waterproof finish of the fabric and may also decrease the life of the polyester thread used in the canvas. Reapply a water repellent treatment as needed.
Method 1
1. Add 1/8 cup (1 oz.) of non-chlorine bleach to one gallon of water and mix thoroughly.
2. Thoroughly wet the canvas and then gently scrub the stained area with the weak bleach solution.
3. Rinse with cold water to remove all of the solution.
Method 2
1. Add 1/2 cup (4 oz.) of non-chlorine bleach and 1/2 cup (4 o z.) Ivo ry Snow®, Dr eft®, or Woolite® to one gallon
of water and mix thoroughly.
2. Soak the canvas in this solution for about 20 minutes.
3. Rinse with cold water to remove all of the solution.
40
245 Cruiser Owner’s Manual Supplement Chapter 6: Deck Equipment
NEVER store the clear vinyl piece s wet, a s thi s wil l c ause a mi lky f il m to deve lop.
NEVER fold or crease the clear vinyl pieces as cracking will occur.
Clear vinyl is NOT intended for use when yo ur boat is i n st orage or bei ng moored.
Clear vinyl does NOT hold up well against ultraviolet rays.
Under direct sunlight conditions, do NOT let the clear vinyl touch the framework. The
framework radiates heat and can burn the clear vinyl .
CAUTION
!
FOLDING OR OTHERWISE CREASING
CLEAR VINYL WILL CAUSE DAMAGE
SUCH AS CRACKING TO OCCUR
AFTER CLEAR VINYL PARTS HAVE
COMPLETELY AIR DRIED THEY CAN BE
ROLLED OR SIMPLY LAID FLAT FOR STOWAGE
NEVER FOLD OR CREASE CLEAR VINYL!
Clear Vinyl Care
After each use, especially in saltwater, rinse the clear vinyl with cold freshwater.
Before stowing, the clear vinyl must be completely dry. Air-drying is best, but you can also car efully dry the vinyl
with a chamois or soft cotton cloth.
The clear vinyl can be rolled or laid out flat for stowage.
Never fold or crease the clear vinyl parts as cracking will occur.
Cleaning Clear Vinyl
Regularly clean the clear vinyl to prevent dirt, pollen, and etc. from marrin g the sur­face. Generally, it is easiest to clean the clear vinyl while it is installed on your boat.
1. Hose down the
clear vinyl with freshwater.
2. Using a soft cot-
ton cloth (paper
towels are abra ­sive and must never be used on clear vinyl), gen-
tly wash the clear vinyl with soap and water.
3. Rinse thoroughly to remove the soap.
4. Before stowing, the clear vinyl must be completely dry. Air-drying is best, but you can also carefully dry the
vinyl with a chamois or soft cotton cloth.
Ask your dealer about products available to keep the clear vinyl polished and looking new.
41
245 Cruiser Owner’s Manual Supplement
NOTICE
ALWAYS keep an approved ABC-type fir e extinguisher in galley ar ea.
CARBON MONOXIDE POISONING HAZARD!
The alcohol stove is a sourc e of dangerous carbon monoxide gas (CO).
BEFORE using the alcohol stove, Open doors and windows to make sure
there is enough fresh air for ventilation.
Read the Carbon Monoxide (CO) section in Chapter 1 of this supplement.
DANGER!
!
Open flame cooking appliances consume oxygen. This can caus e asphyxiation or death.
Maintain open ventilation.
WARNING!
!
BURN/SCALDING and/or FIRE HAZARD!
Read the stove’s ins truc ti on manual BEFORE using.
ALWAYS keep an approved ABC-type fir e ex tinguisher in the galley ar ea.
Do NOT use the s tove whil e underway.
Any non-cooking devices on or near your stove dur ing use are potential fire hazards !
Do NOT touch the burners, grates or nearby surfaces as they may be hot even when they ar e
dark in color.
Areas near the burners and grates may become hot enough t o cause burns.
During and after use, do NOT touch or let clothi ng or ot her f lammable materi al come in
contact with the heated units or the areas near the units (burner tops, main fra me sides and back, sea rails and pot holders) until they ha ve had sufficient time to cool.
WARNING!
!
PRODUCT DAMAGE HAZARD!
NEVER use alcohol and electric burners at t he same t ime. To do so will cause overheating, which can destroy the el ect ric ele me nts.
CAUTION
!
Chapter 7: Appliances & Entertainment Systems
All appliances and entertainment systems have their own instruction sheets and/or manuals that contain detailed
information and important safeguards.
Read these instruction sheets and manuals before using your boat’s appliances and entertainment systems.
If applicable, make sure the 110-volt AC bre aker is turned On for the applia nce or ent ertai nment sys tem you wish
to use.
Alcohol/110-Volt Electric Stove (If Equipped)
42
245 Cruiser Owner’s Manual Supplement Chapter 7: Appliances & Entertainment Systems
AM radio reception may be impaired anytime the engine is running.
NOTICE
Refrigerator (If Equipped)
The refrigerator runs on 12-volt DC power unless 110-volt AC power is being supplied by shore power and the refrigerator’s 110-volt AC master panel circuit breaker is On.
Audio Equipment
43
245 Cruiser Owner’s Manual Supplement
Chapter 8: Convertible Seats, Beds, & Tables
Dinette To V-Berth Conversion
The dinette table can be removed and the dinette area can be converted into a berth.
1. Remove the table (A) and the table leg (B).
2. Place the filler boards (C) so that they fit securely into the recessed edges (D) at the edge of the dinette seats.
3. Place the filler cus hions (E) on top of the filler boards (C).
44
245 Cruiser Owner’s Manual Supplement
Be conservative in the use of battery power.
Prolonged use of cabin interior light s (ov erni ght) WILL result in a drained battery.
CAUTION
!
Avoid the storage of gear where it would block navigation li ghts from view.
CAUTION
!
Running lights are leg all y required to show boat direction and right-of-way at nig ht.
NOTICE
Chapter 9: Lights
Care & Maintenance
Although all lights installed on your boat are of top quality, they will occassionally fail. Always carry spare bulbs of the correct size and wattage, but before replacing non functioning lights, check for other common causes, such as:
There may be a blown fuse - replace the fuse.
A wire may be damaged or may have come loose - repair as required.
The bulb base may be corroded - clean the base and coat it with non-conductive electrical lubricant.
Interior & Exterior Lights
The lights are powered by your boat’s 12-volt DC system.
The battery switch must be turned On for the lights to work.
Navigation Lights
Spotlight (If Equipped)
Read the spotlight operating instructions before using the spotlight.
45
Chapter 10: Electrical System
EXTREME FIRE, SHOCK and EXPLOSION HAZARD!
NEVER install non-ignition prote cte d swit ches o r other arcing devices in t he fuel compartment.
NEVER substitute automotive parts for marine par ts. Mari ne el ect ric al, i gnit ion, and fuel system parts were designed and manufac tur ed to comply with rules and laws that minimize the risks of fire and explo sion.
NEVER change the electrical systems or r e lev ant drawings.
Allow ONLY trained personnel to i nsta ll batteries and/or do electrical syst em work.
Make sure that ALL battery switches are turned Of f BEFORE working in the engine spaces.
DANGER!
!
FIRE and EXPLOSION HAZARD!
Fuel vapors can explode! BEFORE turning on electri cal devic es or working on the electrical system:
1. Check the bilge areas for fuel vapors or leaking fuel. If you see leaking fuel or smell fuel vapors:
a. Do NOT start the engine or generator (if equipped), do NOT turn On any electrica l
devices, put out ALL cigarette s, ci gars , and othe r sources of flame or ignition. b. Get everyone off your boat. c. Get trained help to find and fix the probl em.
2. Run the bilge blower (s) fo r at lea st four minutes BEFORE engine star ting, el ectric al s ystem work, or turning on electrical devi ces .
WARNING!
!
SHOCK and ELECTRICAL SYSTEM DAMAGE HAZARD!
When the engine is running, NEVER turn Off the batte ry switch or disconnect the bat­tery cables. Doing either could caus e damage t o your boat’s engine and/or electrical system.
CAUTION
!
Electrical connections ar e prone to corros ion. To reduce corrosi on- caused electrical proble ms:
Keep ALL electrical connections clean.
Apply a spray-on protectant that is designed to protect conne cti ons f rom corrosion.
NOTICE
245 Cruiser Owner’s Manual Supplement
46
245 Cruiser Owner’s Manual Supplement Chapter 10: Electrical System
SHOCK and ELECTRICAL SYSTEM DAMAGE HAZARD!
When the engine is running, NEVER turn Off the batte ry switch or disconnect the bat­tery cables. Doing either could caus e damage t o your boat’s engine and/or electrical system.
CAUTION
!
Make sure your selling dea ler ful ly ex plai ns how to use the battery switch.
NOTICE
12-Volt DC System
Batteries
The batteries supply electricity for lights, 12-volt accessories and engine starting.
The Electrical section in Chapter 8 of the Cruiser & Yacht Owner’s Manual provides battery care and
maintenance instructions.
Battery Switch (If Equipped with One Battery)
Standby-loads, such as the automatic bilge pumps and the stereo memory, are not affected by the bat tery switch becaus e they are wired directly to the battery.
Turn the battery switch to the Off position whenever your boat will be unoccupied for long periods of time.
47
Chapter 10: Electrical System 245 Cruiser Owner’s Manual Supplement
SHOCK and ELECTRICAL SYSTEM DAMAGE HAZARD!
When the engine is running, NEVER turn Off the batte ry switch or disconnect the bat­tery cables. Doing either could caus e damage t o your boat’s engine and/or electrical system components.
CAUTION
!
Since your boat’s batteries were inst all ed by your deal er, the battery switch positions listed below may vary . Make sure your selling deal er f ully explains how to use the battery switches.
NOTICE
Battery Switch (If Equipped with Two Batteries)
Standby-loads, such as the automatic bilge pumps and the stereo memory, are not affected by the battery switch since they are wired directly to the batteries.
Turn the battery switch to the Off position whenever your boat will be unoccupied for long periods of time.
Battery Switch Positions
BATTERY SWITCH
POSITIONS
POSITION
1
POSITION
2
POSITION BOTH or
1 & 2
ENGINE
STARTING
Battery 1
provides start-
ing power
Battery 2
provides start-
ing power
BOTH batteries
Provide starting
power
ACCESSORIES & LIGHTS
Battery 1
provides power for
accessories and lights
Battery 2
provides power for
accessories and lights
BOTH batteries provide
power for accessories and
lights (not advised unless
engine is running)
ENGINE
ALTERNATOR
Charges
battery 1
Charges
battery 2
Charges BOTH
batteries
48
BATTERY
CHARGER
Charges BOTH
batteries
Charges BOTH
batteries
Charges BOTH
batteries
245 Cruiser Owner’s Manual Supplement Chapter 10: Electrical System
Do NOT use the 12-volt DC accessory outlet with a c igarette or cigar lighter. High tempera­tures may melt the outlet.
CAUTION
!
ENGINE and ELECTRICAL SYSTEM DAMAGE HAZARD!
NEVER run your boat’s engine and t he bat ter y char ger at the same time.
CAUTION
!
The battery charging systems (alternator and ba tte ry charger) installed on your boat are designed to charge conventional l ead- acid ba tte ries.
BEFORE installing gel-cell or other new technol ogy batter ies, consu lt with t he battery man- ufacturer about charging syst em requirements.
CAUTION
!
Fuses & Circuit Breakers
Circuit breakers for the engine and main accessory power are on the 12-volt DC push-to-reset circuit breaker panel and on the battery switch panel.
See the Component Locatio ns section in Chapter 2 for the locations of the b attery s witch panel and the 12-vo lt DC push-to-reset circuit breakers.
NOTE: Some equipment may have secondary fuse protection at the unit, or behind the battery switch panel, or at the batterie s.
12-Volt DC Accessory Outlets
These accessory outlets can be used with any 12-volt device that draws 15-amps or less.
The 12-volt DC accessory outlets are protected by a 15-amp breaker on the 12-volt DC push-to-reset circuit
breaker panel.
See the Component Locations section in Chapter 2 for the location of the 12-volt DC accessory outlets.
Alternator
The alternator charges the battery when the engine is running at, or above, cruising speeds.
Battery Charger (If Equipped)
Before using the battery char ger , read all instruct ions and wa rnings: (1) on the battery char ger , (2) on the batteries , and (3) in the battery charger manual.
The battery charger will automaticall y charge your boat ’s batteries when 1 10- vol t AC power is being provided by shore power, and the battery charger circuit breaker on the 110-volt AC master panel is On.
The battery switch(es) can be in any position during charging.
During battery charging you may use 12-volt accessories, such as the lights and stereo, but battery charging will
take longer.
49
Chapter 10: Electrical System 245 Cruiser Owner’s Manual Supplement
WATER HEATER DAMAGE HAZARD!
Do NOT turn On the water heater ci r cuit br eaker on the 110-volt AC master panel until the water heater tank is COMPLETELY filled with water.
The tank is full if water flows from the tap when the hot water is turned On in the galley.
Even brief water heater operation with a dry tank WILL damage the he ati n g el ements .
Warranty replacements will NOT be made on elements damaged in this manner.
CAUTION
!
When using shore power, the use of several 110-volt AC accessories at the same ti me can result in an overloaded circuit.
You may have to turn Off one or more accessor ies to use another accessory.
NOTICE
110-Volt AC System (If Equipped)
To gain a basic understanding of your boat’s 110-volt AC system, read the handbook, A Boater’s Guide To AC Electrica l Systems. If this handbook is not in your owner’s packet, call 360-435-8957 and the handbook will be
mailed to you.
The 110-volt AC system is energized by shore power.
Individual breakers on the 110-volt AC master panel must be turned On to supply power to the accessories you
wish to us e.
The 110-volt AC master panel may contain circuit breakers for accessories that are not available for your boat.
50
245 Cruiser Owner’s Manual Supplement Chapter 10: Electrical System
FIRE, EXPLOSION and SHOCK HAZARD!
Use ONLY compatible shore power conne ctor s and NEVER alt er t he conne ctors.
Turn Off ALL br eakers and swit ches on t he 110-volt AC master panel BEFORE plugging in
or unplugging the shore power cord.
To prevent shock or i njury from drop
p
ing a "hot" cord into the water:
a. ALWAYS plug the shor e po we r cor d int o the boat i nlet first, and then into the
dockside outlet.
b. When unplugging from shore power, ALWAYS unplug the shore power cord from the
dockside outlet first.
NEVER leave the shore power cord plugge d int o the docksi de out let ONLY.
ONLY use shore power cords appr o ved fo r ma rine use. NEVER use or dinary indoor or out-
door extension cords.
DANGER!
!
SHOCK and ELECTRICAL SYSTEM DAMAGE HAZARD!
Monitor the polarity indicator lig hts EVER Y TI ME you c onnect to s hore power.
If a reversed polarity light turns On when you ar e co nnect ing t o shore power, do NOT turn
On the main bre aker s witc hes.
Instead, IMMEDIATELY unplug the shor e po wer cor d (ALWAYS from the dockside outlet first) and alert marina management.
WARNING!
!
SHOCK and ELECTRICAL SYSTEM DAMAGE HAZARD!
BEFORE each use, check the shore power cord for defec ts or damage.
NEVER use a damaged or faulty cord since the danger of f ire and electrical shock exis ts.
Do NOT pinch the shore power cord in doors or ha tches , or c oil the s hore power cord too
tightly, since these situations can generate enough heat to re sult in a f ire.
If a shore power cord is dropped into the water, COMPLETELY dry the blades and contact slots BEFORE using.
WARNING!
!
ELECTRICAL SYSTEM DAMAGE HAZARD!
NEVER connect to dockside power outside of North America unles s you hav e the inte r- national electrical conversi on opti on.
Using several 1 10 -vol t AC acc essories at the same time can r esul t i n an over loade d ci rcuit. You may have to turn Off one or more acce ssor ies to use another accessory.
Use double insulated or three-wire protected el ect ric al appl iances whenever possible.
CAUTION
!
Shore Power
51
Chapter 10: Electrical System 245 Cruiser Owner’s Manual Supplement
SHOCK and ELECTRICAL SYSTEM DAMAGE HAZARD!
Monitor the polarity indicator lig hts EVER Y TI ME you c onnect to s hore power.
If a reversed polarity light turns On when you connect to shore power, do NOT turn On the
main breaker switches.
Instead, IMMEDIATELY unplug the shore power cord (ALWAYS from the dockside outlet first) and alert marina management.
WARNING!
!
Connecting to Shore Power
1. Review all hazard information
on the previous page.
2. Turn Off all breakers and
switches on the 110-volt AC master panel.
3. Attach the shore power cord to the boat inlet first, then to the dockside outlet.
4. Turn the SHORE POWER mas­ter breaker On .
5. As needed, turn On the individ­ual component breakers on the 110-volt AC master panel.
52
245 Cruiser Owner’s Manual Supplement Chapter 10: Electrical System
Electrical Routings
Deck 12-Volt Electrical Harness
Hull 12-Volt Electrical Harness
53
Chapter 10: Electrical System 245 Cruiser Owner’s Manual Supplement
120-Volt AC System (If Equipped)
54
245 Cruiser Owner’s Manual Supplement
Important Records
Selling Dealer
Name Of Dealership
Address
Phone/FAX/E-mail
Sales Manager
Service Manager
Engine
Manufacturer Model Name/Number
Engine Serial Number
Oil Type/SAE Quarts per Engine Filter Type
Key Numbers
Ignition Other
Electronics
Manufacturer Model Name/Number
Serial Number
Manufacturer Model Name/Number
Serial Number
Manufacturer Model Name/Number
Serial Number
Propeller
Manufacturer Pitch
Manufacturer Model Name/Number
Serial Number
Model Number
Manufacturer Model Name/Number
Serial Number
Manufacturer Model Name/Number
Serial Number
Manufacturer Model Name/Number
Serial Number
55
245 Cruiser Owner’s Manual Supplement
Float Plan
Before going boating, fill out a copy of this float plan (or similar) and leave it with a reliable person whom you can depend on to contact the Coast Guard or other rescue organization, if you do not return as scheduled.
Description of Boat
Registration/Documentation Number
Length Make Type
Hull Color Trim Color
Fuel Capacity Engine Type Number of Engines
Distinguishing Features
Distinguishing Features
Operator of Boat
Full Name
Male or Female Age Health
Address
Full Name
Age Health Phone Number
Full Name
Age Health Phone Number
Full Name
Age Health Phone Number
Full Name
Age Health Phone Number
Full Name
Address
Phone/FAX/E-mail
Operator’s Experience
Persons Onboard
Full Name
Age Health Phone Number
Full Name
Age Health Phone Number
Age Health Phone Number
Full Name
Age Health Phone Number
Full Name
Age Health Phone Number
Full Name
Age Health Phone Number
56
245 Cruiser Owner’s Manual Supplement Float Plan
Survival Equipment
Marine Radio (Yes/No) Type Frequencies
Number of PFDs Flares (Yes/No) Mirror (Yes/No)
Smoke Signals (Yes/No) Flashlight (Yes/No) Food (Yes/No)
Water (Yes/No) Anchor (Yes/No) Raft/Dinghy (Yes/No)
Paddles (Yes/No) EPIRB (Yes/No) Other
Other Other Other
Vehicle Description
Make Model
Color License Number
Trip Expectations
Departing From
Departure Date Departure Time
Stopover 1
Arrive No Later Than: Date Arrive No Later Than: Time
Stopover 2
Arrive No Later Than: Date Arrive No Later Than: Time
Stopover 3
Arrive No Later Than: Date Arrive No Later Than: Time
Where is the Vehicle Parked?
Stopover 4
Arrive No Later Than: Date Arrive No Later Than: Time
Stopover 5
Arrive No Later Than: Date Arrive No Later Than: Time
Stopover 6
Arrive No Later Than: Date Arrive No Later Than: Time
Final Destination Port (If Different Than Home Port)
Arrive No Later Than: Date Arrive No Later Than: Time
If not returned by t he date and ti me listed ab ove, call the Coast Guard or other local authority.
Coast Guard Phone Number
Local Authority Phone Number
57
Owner’s Notes
Owner’s Notes
Owner’s Notes
Bayliner • 17825 59th Ave NE • Arlington, WA 98223 • 360-435-5571
Part Number 2016133 (r1)
Loading...
