Caution : You must read this before you proceed
___
CHAIR
CAUTION : This Chair is NOT a TOY.
Keep your child / children at bay during the assembly process.
For moving the Chair and to prevent damage to the Chair, two adults are needed
to execute this action.
1
Label Picture Description QTY
___
A Seat Frame 1
B Legs 2
C Cross Bar Of Legs 2
Label Picture Description QTY
①
②
③
Bolt (M6x45mm) 9
Washer 5
Screw (M6 x 55mm) 3
④
Allen key with a round
head
2
2
Before Beginning Assembly:
___
Before Beginning Assembly:
OVERVIEW
Seat Frame (A)
Cross bar of legs (C)
Leg (B)
FRONT FACING
This Chair has multiple parts and may require up to some 30 minutes to assemble. To give
you an overview of the Chair, the above picture is to assemble is to help you put the various
parts into perspective. Please read through the instructions here below to familiarise the
parts and steps before assembly.
3
Step 1
___
Unpack and place all parts on a clean, non-marring surface.
Step 2
Place Seat Frame (A) with its underside skywards onto a clean, soft surface to avoid any
scratch or damage to the product.
Attached Leg (B) with pre-fixed wooden dowel to the Seat Frame (A) as pictured above.
Secure by using Bolts (①), washer (②), and Allen Key (④)
DO NOT FULLY TIGHTEN THE BOLTS.
4
Step 3
___
Attach the cross bars of legs (C) to in assemble part by using Bolts (①) and Allen key (④)
DO NOT FULLY TIGHTEN THE BOLTS.
FULLY TIGHTENING COULD LEAD TO DAMAGE OF THE PRODUCT.
ONLY TIGHTEN UNTIL SECURE.
Step 4
Then place complete part in step 2 into the tenon of side rails and the leg (B).
4.1 Using Bolts (①), washer (②) and Allen Key (④) to attach the seat frame (A) to the
complete part in step 3.
4.2 Using Bolts (①) and Allen key (④) to attach the cross bar of leg (C) to the complete
part in step 4.1.
DO NOT FULLY TIGHTEN THE BOLTS.
5
Step 5
___
Finally, using Screw (③) and Allen key (④) to strengthen seat top Panel.
DO NOT FULLY TIGHTEN THE SCREW.
Step 6
If wobble
Test again
30cm-50cm
Place the Chair right side up on a LEVEL SURFACE to see if it wobbles.
If it wobbles, lift the Chair 30cm to 50cm high from the ground.
Keep your feet and toes well away from the drop zone.
Drop the Chair freely and vertically with all four legs, hitting the ground at the same time.
This Drop Test will help to ensure that all the Bolts and gaps reach full alignment status.
Test again for evenness on a LEVEL SURFACE.
If no wobbles are found, proceed to tighten all the Bolts.
When tightening the Bolts, tighten sequentially.
Do not tighten any Bolt, Screws fully and then move towards the next one.
This could cause the frame to warp.
If there are still wobbles, loosen the Bolts and execute the same drop tests.
If the Chair is not stable it could lead to damage to the product.
Your Chair is ready for use.
This Chair can only be used on a flat, level surface.
6
