CAUTION : This Table is NOT a TOY.
Keep your child / children at bay in the process of assembly.
For turning the Table and to prevent damage to the Table 02 persons may be
needed to execute this action
1 OF 8
Label
Label
Legs Frame
Bolts
(M8 x 20mm)
Washers
(M8/18 x 2mm)
Bolts
(M6 x60mm)
Sleeve Nuts
2
25
25
5
5
Allen Keys
x 25
x 5
2
x 25
x 5
2 OF 8
This Table has multiple parts and may require up to some 30 minutes to assemble.
To give you an overview of the table, the above picture is to help you put the various
parts into perspective. Please read through the instructions here below to familiarise
the parts and steps before assembly.
3 OF 8
A
With the help from your partner
2.1: Place the Table Top (A) on one side as picture above. Slightly open the
table top as the arrow.
2.2: Place the Table Top (A) with its underside skywards onto a clean, soft surface to
avoid any scratches or damages to the product.
4 OF 8
A
4
3
5
Secure Table Top (A) using the Bolt (③), Sleeve Nut (④) and Allen Key (⑤)
as shown in the picture.
Do not fully tighten the Bolts.
5
Place Support Bar (C) underside of long apron of Table Top (A) as show in picture
above.
5 OF 8
Step 5
C
A
5
1
1
1
1
2
2
2
Secure the Support Bar (C) to the Table Top (A) by using the Bolts (①), Washer (②)
and Allen Key (⑤) as shown in the picture.
Do not fully tighten the Bolts.
Step 6
B
B
5
A
1
2
1
2
Attach the Legs Frame (B) to the Table Top (A) using the Bolts (①) with Washers
(②) and Allen Key (⑤) as shown in the picture.
Do not fully tighten the Bolts.
6 OF 8
With assistance from your adult parners, Turn the Table right side up.
Inspect it and make sure all parts are adequately connected.
Check to ensure there is NO WOBBLINESS.
In a sequential manner, ensure all bolts are fully locked into position and
secured.
CAUTION: When tightening these Bolts, tighten sequentially.
DO NOT tighten any Bolts fully and then towards the next one. This would
cause the frame to warp.
If there is still wobbles, loosen the bolts and execute this same drop tests.
WARNING !! IF TABLE IS NOT STABLE, IT COULD LEAD TO DAMAGING THE
PRODUCT.
Ensure all screws are fully locked into position.
The Table is ready to be used.
Caution: This Table can only be used on flat, level surface.
7 OF 8
Care & Maintenance
Do not put hot items directly on furniture surface.
Do not clean furniture with harsh cleansers or polish.
ü
ü
To obtain the longest lifespan of your outdoor products, minimizing
exposure to direct sunlight is recommended.
Children should not climb or jump on the furniture.
Do not write on furniture without a padded barrier to protect the surface.
To obtain the longest lifespan of your outdoor products, avoid extended
and lengthy exposure to rain, snow , and direct sunshine. Whenever
possible cover the product and /or place under patio or awnings.
Not for commercial use. For residential use only.
Stains may be removed with mild soap soution and damp cloth.
Dust and pick-up spills using a clean, non-colored, lint-free cloth.
