Bay Isle Home™ BAYI4457 Installation & Assembly

ASSEMBLING & INSTALLATION INSTRUCTIONS
The drawing shown may not exactly match the product enclosed.
However, the installation instructions do apply to this product.
WARNING! SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER. ATTENTION! COUPER LE COURANT AU FUSIBLE OU UN DISJONCTEUR.
ASSEMBLING THE FIXTURE (Fig.2, See the Page 2)
Shut off the power at the circuit breaker box. Remove old fixture and all
2. Carefully unpack your new fixture and lay out all the parts on a clear area. Take care not to lose any small parts necessary for installation.
3. Thread the two mounting screws about 1/4” into the pre-drilled holes in the single bar spaced the same distance apart as the holes in the fixture canopy (A).
4. Install the single bar to the Junction Box with the two Junction Box Screws as shown. The side of junction box is not includ Attach the pipe thread(C) to top coupling of the lamp holder(F
5. until tigh tight.
6. Place the candle sleeve (E) onto the lamp holder(F).
7. Install the light bulbsNot includedin accordance with the fixture specifications. NOTE: DO NOT EXCEED THE SPECIFIED WATTAGE!
8. Note: att arm’s screw hole with the ring’s hole, lock it securely with the screws. The assembled is ring “G”. Attach the bell glass(H) insert to the big ring(G). While holding the big ring(G) and canopy(A), hanging at both hooks of the pipe(D).
9. While holding the fixture body assembly towards the ceiling, connect the electrical wires as Shown in Fig.2, making sure that all wire nuts are secured. You may have to wrap the connections with electrical tape. If your outlet has a ground wire (green or bare copper), connect the fixture ground wire to it. Otherwise connect fixture’s gr Mounting str tuck them carefully insid Attach the canopy(A) to the Junction box, aligning screws on single ba
10. with mounting holes in canopy and lock it securely with ball nut (B).
the single bar marked "GND" must face out. The
ed.
) and lock it
t. Attach the canopy(A) onto the pipe thread(C) and lock it until
ach the small arm to the side hole of the big ring, aligning the
ound wire directly to the
ap with the green screw provided. After wires are
connected,
e the Junction Box.
FIG.2
JunctionBox
(Notincluded)
Singlebar
(GND)
BoxScrew
A
B
C
D
E
F
G
G
Thefigureis
onlyfor
reference.
FIG.3
r
FIXTURE WIRES Black or Smooth
HOUSE WIRES Black(Hot)
FIXTURE WIRES White or Ribbed
H
HOUSE WIRES White (Neutral)
(Screwdriver) (Notincluded)
FIXTURE WIRES Bare Copper (Ground)
HOUSE
WIRES
Green or Bare
Copper(Ground)
Y
our installation is now complete. Return power to the junction box and
test the fixture.
