Page 1
2
www.baxi.co.uk
Install warmth, efciency & peace of mind
The Baxi GA Combi & System Boiler Range
www.baxi.co.uk
Page 2
For technical enquiries e-mail [email protected]
2
The GA range of combi and system boilers from Baxi
When your customers buy a new boiler, it’s an investment they don’t take lightly.
We understand that you need to supply a boiler that guarantees comfortable living temperatures and ample hot water as well as delivering energy savings and reliability – year in, year out. A boiler
that ts perfectly in your customers’ homes and
their lifestyles and saves them money throughout its lifetime.
Baxi boilers tick all the boxes.
They tick all your boxes too. They’re easy to t because they have many common features and components, aid you in the commissioning process and congure automatically to natural gas or LPG. They also include compact, cupboard-t* models. These features can help you nish the installation faster and move on to
the next one. Their reliability also saves you hassle and protects your reputation. We’ve put together this guide to help you select the best Baxi boiler for your
customers’ needs. Check out the innovative features, compare the specications,
read why our support is second-to-none, and you’ll soon see why Baxi is the brand of choice for so many installers.
2
For technical enquiries e-mail [email protected]
*Standard cupboard dimensions of 900mm x 500mm x 300mm, with control panel ap removed, excluding 32kW model of Baxi Megao System
Compact GA
Page 3
3
www.baxi.co.uk
Contents
Contents
A history of quality and innovation 4
Baxi boiler efciency calculator 5
Accessories and controls 20
Other heating solutions from Baxi 26 heateam and aftersales support 28
Baxi training 29
works business support scheme 30 Local events and literature 31
At a glance 6 Baxi Duo-tec Combi GA 8 Baxi Neta-tec Combi GA 12
Baxi Megao System Compact GA 16
Introduction
Information about the new range
Accessories and controls
Flue options
Our support for you
Flues 22
Page 4
For technical enquiries e-mail [email protected]
4
The brand that stands for quality and innovation
1866 1966 2001 2006 2010 2011
There’s much more to Baxi than our great range of boilers.
We’ve had experience in the heating industry since 1866. We’ve earned an unparalleled reputation
over the years because we are always striving to create highly efcient, cost effective and reliable
heating and hot water solutions for every installation, it’s what we do best.
We’re very proud of our long heritage of quality and innovation, and that we continue to manufacture here in the UK. All Baxi GA boilers are Energy Saving Trust Recommended to give your customer added peace of mind.
The company is founded by Richard Baxendale in Chorley, Lancashire
The original Baxi Bermuda back boiler revolutionises home heating and hot water
The Baxi 105 E becomes the biggest selling combination boiler in the UK
The Baxi Duo-tec HE is launched and is awarded the UK’s 2007 ‘Best Buy’ by Which? and wins 2008 CORGI Boiler of the Year
The Baxi Ecogen becomes the UK’s
rst domestic micro-
CHP unit, winning multiple awards
Baxi launches
the rst range
of Gas Adaptive boilers, setting new standards in boiler reliability and
efciency
Made in the UK
Page 5
5
www.baxi.co.uk
Discover fantastic fuel bill savings with
the Baxi boiler efciency calculator!
Baxi boiler efciency calculator
The Baxi boiler efciency calculator will help you and your customers to discover how much could be saved on fuel bills by tting a new A rated boiler in comparison to an
existing boiler.
Quick and easy to use, the calculator can show the potential savings made possible by
installing an energy efcient, A rated boiler. This also includes details of the Baxi GA boilers, the most fuel efcient boilers we’ve ever made.
Key features and benets of Baxi A rated boilers:
• Supremely efcient and reliable
• Nationwide support from heateam - our award-winning, dedicated support service
• Variety of boiler types and numerous outputs available for different size properties
and requirements, all with the same great quality
• Compatible with a wide range of accessories
The Baxi boiler efciency calculator will ask
for general information about the property in question and the current heating system.
It takes just a few minutes to answer the questions that will help us to predict fuel usage and calculate potential savings.
www.baxi.co.uk/compare
If you need any help or support with your calculation, or if you are an installer looking for our printed version, please call 0800 138 3142.
Page 6
At a glance
An at a glance guide to our GA boilers, the key features available with
each model and their benets to you and your customers
Features and benets
Baxi Duo-tec Combi GA
Gas Adaptive Control
Automatic set-up for faster and easier installation
Wide modulation range
Reduces wear and tear, and gas usage
Front component access
For quicker and easier servicing
Up to ve years parts and labour warranty*
For peace of mind
Pre-plumbing jig
For faster and easier installation
Cupboard t
†
For more exible and discreet siting
Low lift weight
For easier installation and transportation
Natural gas and LPG ready
No conversion kit required
Multit GasSaver compatible
Saves up to 37% of gas used to heat hot water and cold water consumption by up to 7%**
User-friendly controls
Easy and intuitive, for greater heating and hot water comfort
Anti-cycling function/pump overrun
Protects against overheating and prevents boiler cycling
Frost protection
Enables exibility of siting
Anti-sticking function
Extends life by preventing pump and 3-way valve sticking
Auto-system bypass
Protects against overheating without external bypass
Filling loop
For easier installation
6
*Subject to registration and annual service by any Gas Safe registered installer. Neta-tec Plus Combi GA has a ve year parts and labour warranty, all other GA models have a two year parts and labour warranty. **Test conducted by independent scientic test house, TNO. Calculation based on an average household’s consumption of 100 litres of hot water per day. Results were based on a comparison of a SEDBUK (2005) > 91% rated high efciency boiler versus a high efciency boiler and GasSaver. † Standard cupboard dimensions of 900mm x 500mm x 300mm, with control panel ap removed.
For technical enquiries e-mail [email protected]
Page 7
7
At a glance
Baxi Duo-tec Combi GA
Baxi Neta-tec Combi GA
and Plus Combi GA
Baxi Megao System
Compact GA
1:7 1:5 1:7
www.baxi.co.uk
Page 8
For technical enquiries e-mail [email protected]
8
Baxi Duo-tec Combi GA
The Baxi Duo-tec Combi GA is one of our best selling boilers, and understandably so. It uses the THINK combustion management system incorporating our unique Gas Adaptive Control. This, together with a wide 1:7 modulation range, contributes to smoother operation,
higher energy efciency, reduced wear and tear and
extended boiler life
There’s a model for every home, with the powerful 40kW model ensuring exceptional hot water ow rates in larger properties.
Always listening to our installers, we’ve included popular features such as front access for easy servicing, brass hydraulics, and a service-due function to remind your customer when the boiler is in need of a service, providing you with repeat business.
Key features
Gas Adaptive Control reduces fuel consumption and improves boiler reliability
Natural gas and LPG ready - no need for conversion kit
Wide modulation range of 1:7 helps to reduce fuel bills and cut carbon emissions
Front access to all components makes the Baxi Duo-tec Combi GA quick and easy to service
One piece pre-plumbing jig for faster and easier installation
Filling loop as standard for ease of lling
Anti sticking function - extends appliance life by preventing pump and 3-way valve sticking
Anti cycling/pump overrun protects against boiler cycling and overheating
Frost protection gives greater siting exibility
Extensive ue options with lengths up to 20m enables more exible siting
Wide range of outputs up to 40kW to suit
different sizes and styles of property
Class leading hot water ow rates
for increased homeowner comfort and convenience
Complete with a two year parts and labour warranty for added peace of mind
Subject to registration and annual service by any Gas Safe registered installer
Page 9
www.baxi.co.uk
Baxi Duo-tec 24 hour digital timer and fascia kit
Compatible accessories
Baxi wireless 24 hour programmer and room sensors
Baxi wired weather sensor Multit GasSaver GS1
Is it for my customer?
A boiler that reduces CO
2
by 9.2% and delivers a SAP benet of up to 2.7%.
†
†
Baxi laboratory testing & analysis has shown these reductions when
measuring a Baxi Duo-tec 28 GA compared to a Baxi Duo-tec 28 HE A boiler
See page 20 for further information
9
Baxi Duo-tec Combi GA
Baxi room thermostatBaxi electro-mechanical
24 hour timer kit
Page 10
For technical enquiries e-mail [email protected]
10
Baxi Duo-tec Combi GA
Key components and tting dimensions
PCB with ‘THINK Intelligence’ within
Gas valve
Brass hydraulics
2 Speed Grundfos pump
Servicing space
The THINK combustion management system utilises key components in the boiler to manage the combustion process, delivering lower carbon emissions, reduced wear and tear and lower fuel bills.
1 4
2 5
3
150mm Mi
n
7
63mm
450
mm
5
mm Mi
n
5mm Mi
162mm
mm
i
n175
mm
M
(
300mm if
in
mm
12
5
using 80
/
ste
m
flueing s
y
5mm Min
450mm Min
For servicing
purposes
In operation
At least 1.5°
345mm*
1
2
3
4
5
*355mm with control panel ap
Page 11
11
www.baxi.co.uk
Technical specications
Baxi Duo-tec Combi GA
Duo-tec
Combi 24 GA
Duo-tec
Combi 28 GA
Duo-tec
Combi 33 GA
Duo-tec
Combi 40 GA
Sales Code
Boiler only 720117801 720118001 720118201 720118401
Std. Flue 720598701 720598701 720598701 720598701
Controls
Concealed User Controls Yes Yes Yes Yes User adjustable DHW temperature Yes Yes Yes Yes User adjustable CH temperature Yes Yes Yes Yes LCD Control Panel Temp/Status/Fault Diagnosis Display Yes Yes Yes Yes
Performance
Heat Output CH
kW (Max) 20 24 28 33
kW (Min) 3.4 3.8 4.7 5.7 Heat Output DHW Output - kW (Max) 24 28 33 40 Maximum DHW Flow Rate (Delta T @ 35
o
Max) l/min 9.8 11.5 13.5 16.4 Minimum DHW Flow Rate Required l/min 2 2 2 2 Minimum Operating DHW Pressure Required bar 0.15 0.15 0.15 0.15
SEDBUK 2005 Seasonal Efciency NG/LPG % 91.1/93.2 91.1/93.2 91.1/93.2 91.1/93.2 SEDBUK 2009 Seasonal Efciency NG/LPG % 88.9/91.0 89.0/91.0 89.0/90.9 88.9/90.9 NOx Class (5 being lowest) 1 - 5 5 5 5 5 NOx Emission mg/kW/h 16.1 19.3 17 26.5
CO Emission mg/kW/h 5.1 8 7.5 22.8
Gas
Gas Supply Pipe Size (mm) 22 22 22 22 NG & LPG (Propane) Compatible (single product) Yes Yes Yes Yes Nominal Gas Inlet Pressure NG/LPG (mbar) 20/37 20/37 20/37
20/37
Maximum Gas Rate (NG/Propane) after 10 mins m
3
/hr 2.5/1.92 3.0/2.25 3.5/2.64 4.2/3.06
Electrical
Electrical Supply Volts/Hz 230V/50Hz 230V/50Hz 230V/50Hz 230V/50Hz Permanent Live Required Yes Ye s Ye s Ye s Electrical Cable Required (Core) 3 x 0.75 3 x 0.75 3 x 0.75 3 x 0.75 Power Consumption Watts 104 116 133 142 External Fuse Rating Amps 3 3 3 3 Boiler IP Rating Approval Category IPX5D IPX5D IPX5D IPX5D
Mechanical & Hydraulic Connections
CH Flow/Return Pipe Size (mm) 22 22 22 22 DHW Flow/Inlet/PRV Size (mm) 15 15 15 15 Condensate Discharge Pipe Size (mm) 21.5 21.5 21.5 21.5
Installation
24 hr Pump Exercise Yes Yes Yes Yes Pump Overrun Yes Yes Yes Yes System Filling Loop Standard Standard Standard Standard Integral System Pump 2 Speed 2 Speed 2 Speed 2 Speed Integral ‘Boiler Only’ Frost Thermostat Yes Yes Yes Yes Pre-plumb Jig Available Yes Yes Yes Yes Stand off Bracket (Optional) Yes Yes Yes Yes Installer Lift Weight Max (kg) 36 36 38 39
Flue Systems
Max Horizontal Ø60/100 m 10 10 10 10 Max Vertical Ø60/100 m 10 10 10 10 Max Horizontal Ø80/125 m
20 20 20 20
Max Vertical Ø80/125 m 20 20 20 20 Twin-pipe Horizontal Ø80/80 m 15 15 15 15 Twin-pipe Vertical Ø80/80 m 15 15 15 15
Plume Management Kit (Max length) m 8 8 8 8
Page 12
For technical enquiries e-mail [email protected]
12
Baxi Neta-tec Combi GA and Baxi Neta-tec Plus Combi GA
The Baxi Neta-tec Combi and Neta-tec Plus Combi GA
models efciency makes them very economical for your
customers to run year-in, year-out. Baxi’s innovative THINK combustion management system incorporating Gas Adaptive Control – together with a wide modulation range – contributes to reduced wear and tear and extended boiler life.
The space-saving design of both models offer more options for locating it in the home and easier installation for you. This also makes it the perfect solution where space is at a premium.
What’s more, despite its innovative design and high quality range of features, both the Baxi Neta-tec Combi and Neta-tec Plus Combi GA will probably cost less than you think.
Key features
Gas Adaptive Control reduces fuel consumption and improves boiler reliability
Natural gas and LPG ready - no need for conversion kit
Wide modulation range of 1:5 helps to reduce fuel bills and cut carbon emissions
Front access to all components makes the Baxi Neta-tec Combi GA quick and easy to service
One piece pre-plumbing jig for faster and easier installation
Filling loop as standard for ease of lling
Anti sticking function - extends appliance life by preventing pump and 3-way valve sticking
Low lift weight for easy handling and installation
Anti cycling/pump overrun protects against boiler cycling and overheating
Frost protection gives greater siting exibility
Extensive ue options with lengths up to 20m enables more exible siting
Wide range of outputs up to 32kW to suit
different sizes and styles of property
Compact dimensions for discreet and exible
siting
Complete with a two year parts and labour warranty as standard on the Neta-tec Combi GA
and ve years on the Neta-tec Plus Combi GA
Subject to registration and annual service by any Gas Safe registered installer
Page 13
Compatible accessories
13
Baxi Neta-tec Combi GA
Baxi Neta-tec Plus Combi GA
Is it for my customer?
Savings can be made by replacing an old, inefficient boiler with a Band A model.
Visit www.baxi.co.uk/compare to try the Baxi Boiler Efficiency Calculator.
Baxi Neta-tec 24 hour digital timer and fascia kit
Baxi wireless 24 hour programmer and room sensors
Baxi wired weather sensor Multit (Compact) GasSaver GS1c
See page 20 for further information
Baxi room thermostatBaxi electro-mechanical
24 hour timer kit
Page 14
For technical enquiries e-mail [email protected]
14
i
n
mm
162mm
106mm
i
n
n if
i
(
300mm M
mm
sing 80/12
5
em
)
f
lueing sys
t
mm Mi
n
mm Mi
n
m
m
5mm Min
450mm Min
For servicing
purposes
In operation
At least 1.5°
290mm
*
Baxi Neta-tec Combi GA and Baxi Neta-tec Plus Combi GA
Key components and tting dimensions
PCB with ‘THINK Intelligence’ within
Gas valve
2 Speed Grundfos pump
Cupboard t dimensions
Low lift weight - from 34kg
1 4
2 5
3
1
2
3
4
5
The THINK combustion management system utilises key components in the boiler to manage the combustion process, delivering lower carbon emissions, reduced wear and tear and lower fuel bills.
*300mm with control panel ap
Page 15
15
www.baxi.co.uk
Neta-tec
Combi
& Plus Combi
24 GA
Neta-tec
Combi
& Plus Combi
28 GA
Neta-tec
Combi
& Plus Combi
33 GA
Sales Code
Boiler only
720023001 720023101 720023201
Plus 7210899 Plus 7210901 Plus 7210903
Std. Flue
720870201 720870201 720870201
Plus 720870201 Plus 720870201 Plus 720870201
Boiler with Std. Flue 720861201 720861301 720861401
Plus 7210905 Plus 7210906 Plus 7210907
Controls
Concealed User Controls Yes Yes Ye s User adjustable DHW temperature Yes Yes Ye s User adjustable CH temperature Yes Ye s Yes LCD Control Panel Temp/Status/Fault Diagnosis Display Yes Ye s Yes
Performance
Heat Output CH
kW (Max) 20 24 28
kW (Min) 3.4 3.8 4.7 Heat Output DHW Output - kW (Max) 24 28 33 Maximum DHW Flow Rate (Delta T @ 35
o
Max) l/min 9.8 11.5 13.5 Minimum DHW Flow Rate Required l/min 2 2 2 Minimum Operating DHW Pressure Required bar 0.15 0.15 0.15
SEDBUK 2005 Seasonal Efciency NG/LPG % 91.1/93.2 91.1/93.2 91.1/93.2 SEDBUK 2009 Seasonal Efciency NG/LPG % 88.9/91.0 89.0/91.0 89.0/90.9 NOx Class (5 being lowest) 1 - 5 5 5 5 NOx Emission mg/kW/h 16.1 19.3 17
CO Emission mg/kW/h 5.1 8 7.5
Gas
Gas Supply Pipe Size (mm) 22 22 22 NG & LPG (Propane) Compatible (single product) Yes Yes
Yes
Nominal Gas Inlet Pressure NG/LPG (mbar) 20/37 20/37 20/37 Maximum Gas Rate (NG/Propane) after 10 mins m
3
/hr 2.5/1.92 3.0/2.25 3.5/2.64
Electrical
Electrical Supply Volts/Hz 230V/50Hz 230V/50Hz 230V/50Hz Permanent Live Required Yes Ye s Yes Electrical Cable Required (Core) 3 x 0.75 3 x 0.75 3 x 0.75 Power Consumption Watts 104 116 133 External Fuse Rating Amps 3 3 3 Boiler IP Rating Approval Category IPX5D IPX5D IPX5D
Mechanical & Hydraulic Connections
CH Flow/Return Pipe Size (mm) 22 22 22 DHW Flow/Inlet/PRV Size (mm) 15 15 15 Condensate Discharge Pipe Size (mm) 21.5 21.5 21.5
Installation
24 hr Pump Exercise Yes Ye s Yes Pump Overrun Yes Ye s Yes System Filling Loop Standard Standard Standard Integral System Pump 2 Speed 2 Speed 2 Speed Integral ‘Boiler Only’ Frost Thermostat Yes Ye s Yes Pre-plumb Jig Available Yes Yes Ye s Stand off Bracket (Optional) Yes Ye s Yes Installer Lift Weight Max (kg) 34 34 36
Flue Systems
Max Horizontal Ø60/100 m 10 10 10 Max Vertical Ø60/100 m 10 10 10 Max Horizontal Ø80/125 m 20 20 20 Max Vertical Ø80/125 m 20 20 20 Twin-pipe Horizontal Ø80/80 m 15 15 15 Twin-pipe Vertical Ø80/80 m 15 15 15
Plume Management Kit (Max length) m 8 8 8
Technical specications
Baxi Neta-tec Combi GA
Baxi Neta-tec Plus Combi GA
Page 16
For technical enquiries e-mail [email protected]
16
Baxi Megao System Compact GA
Your customers will love the Baxi Megao System Compact GA because of its efciency. You’ll love it
because it’s fast and easy to install. Being designed for fully-pumped sealed systems, the pump and expansion tank are already built in, yet the space­saving design means that it can be located discreetly
into a kitchen cupboard*.
The THINK combustion management system incorporates our unique Gas Adaptive Control, together with a wide modulation range, contributing to reduced wear and tear and extended boiler life.
We’ve also added a 12kW model – perfect for well insulated, modern homes.
The Baxi Megao System Compact GA is compatible with the Megao Eco hot water and solar cylinders and Baxi Solaro solar thermal range.
Key features
Gas Adaptive Control reduces fuel consumption and improves boiler reliability
Wide modulation range of 1:7 helps to reduce fuel bills and cut carbon emissions
Front access to all components makes the
Baxi Megao System Compact GA quick
and easy to service
One piece pre-plumbing jig for faster and easier installation
Low lift weight for easy handling and installation
Pump and expansion tank are built in for faster, easier installation
Extensive ue options with lengths up to 20m enables more exible siting
Wide range of outputs up to 32kW to suit
different sizes and styles of property
Compact cupboard t dimensions for discreet siting*
Complete with a two year parts and labour warranty for added peace of mind
Subject to registration and annual service by any Gas Safe registered installer
*Standard cupboard dimensions of 900mm x 500mm x 300mm, with
control panel ap removed, excluding 32kW model
Page 17
Baxi Solaro solar thermal range
Compatible accessories
Megao Eco Solar cylinder
Multit (Compact) GasSaver GS1c
See page 21 for further information on the Multi GasSaver
See page 27 for further information on the
Solaro solar thermal range
17
Baxi Megao System Compact GA
Is it for my customer?
A Baxi GA boiler is 8.7% more
efcient than our other high efciency boilers.
†
†
Baxi laboratory testing & analysis has shown these reductions when
measuring a Baxi Duo-tec 28 GA compared to a Baxi Duo-tec 28 HE A boiler
Baxi room thermostat
Page 18
For technical enquiries e-mail [email protected]
18
Baxi Megao System Compact GA
Key components and tting dimensions
150mm Min
700mm
390mm
175mm Min
(300mm Min if
using 80/125mm
flueing system)
5mm Min
5mm Min
162mm
106mm
(450mm - 32kW model)
(763mm -
32kW model)
5mm Mi
n
450
mm Mi
n
or servicing
u
rposes
n operation
t 1.5
°
At leas
(
345mm - 32kW model
)
PCB with ‘THINK Intelligence’ within
Gas valve
2 Speed Grundfos pump
Cupboard t dimensions
Low lift weight - from 32.5kg
1 4
2 5
3
1
2
3
4
5
The THINK combustion management system utilises key components in the boiler to manage the combustion process, delivering lower carbon emissions, reduced wear and tear and lower fuel bills.
*300mm and 355mm (32kW) with control panel ap
Page 19
19
www.baxi.co.uk
Megao
System
Compact
12 GA
Megao
System
Compact
15 GA
Megao
System
Compact
18 GA
Megao
System
Compact
24 GA
Megao
System
Compact
28 GA
Megao
System
32 GA
Sales Code
Boiler only 720118501 720118601 720118701 720118901 720119101 720119201
Std. Flue 720598701 720598701 720598701 720598701 720598701 720598701
Controls
Concealed User Controls Yes Yes Yes Yes Yes Yes User adjustable CH temperature Ye s Yes Yes Yes Ye s Ye s
LCD Control Panel Temp/Status/Fault Diagnosis Display
Yes Ye s Ye s Yes Ye s Ye s
Performance
Heat Output CH
kW (Max) 12 15 18 24 28 32
kW (Min) 2 2.1 2.5 3.4 4 4.6
SEDBUK 2005 Seasonal Efciency NG/LPG
% 91.1/93.2 91.1/93.2 91.1/93.2 91.1/93.2 91.1/93.2 91.1/93.2
SEDBUK 2009 Seasonal Efciency NG/LPG
% 89.1/91.1 89.0/91.0 89.0/91.0 89.0/91.0 89.0/91.0 89.0/91.0
NOx Class (5 being lowest) 1 - 5 5 5 5 5 5 5 NOx Emission mg/kW/h 23.6 15.2 29.2 16.1 17.9 30.7
CO Emission mg/kW/h 1.7 2.3 5.9 5.1 8.4 22.8
Gas
Gas Supply Pipe Size (mm) 22 22 22 22 22 22 NG & LPG (Propane) Compatible
(single product)
Yes Ye s
Yes Yes Yes Yes
Nominal Gas Inlet Pressure
NG/LPG
(mbar)
20/37 20/37 20/37 20/37 20/37 20/37
Maximum Gas Rate (NG/Propane)
after 10 mins
m3/hr 1.3/0.93 1.6/1.17 1.9/1.4 2.5/1.86 3.0/2.18 3.4/2.49
Electrical
Electrical Supply Volts/Hz 230V/50Hz 230V/50Hz 230V/50Hz 230V/50Hz 230V/50Hz 230V/50Hz Permanent Live Required Yes Ye s Ye s Yes Ye s Ye s Electrical Cable Required (Core) 3 x 0.75 3 x 0.75 3 x 0.75 3 x 0.75 3 x 0.75 3 x 0.75 Power Consumption Watts 110 108 125 104 135 132 External Fuse Rating Amps 3 3 3 3 3 3
Boiler IPX Rating
Approval Category
IPX5D IPX5D IPX5D IPX5D IPX5D IPX5D
Mechanical & Hydraulic Connections
CH Flow/Return Pipe Size (mm) 22 22 22 22 22 22 Condensate Discharge Pipe Size (mm) 21.5 21.5 21.5 21.5 21.5 21.5
Installation
24 hr Pump Exercise Yes Ye s Ye s Yes Ye s Ye s Pump Overrun Yes Yes Yes Yes Ye s Ye s Integral System Pump 2 Speed 2 Speed 2 Speed 2 Speed 2 Speed 2 Speed Integral ‘Boiler Only’ Frost Thermostat Yes Yes Yes Yes Yes Ye s Pre-plumb Jig Available Ye s
Yes Yes Yes Ye s Ye s Stand off Bracket (Optional) Yes Ye s Ye s Yes Ye s Ye s Installer Lift Weight Max (kg) 32.5 32.5 32.5 32.5 34.5 37.5
Flue Systems
Max Horizontal Ø60/100 m 10 10 10 10 10 10 Max Vertical Ø60/100 m 10 10 10 10 10 10 Max Horizontal Ø80/125 m 20 20 20 20 20 20 Max Vertical Ø80/125 m 20 20 20 20 20 20 Twin-pipe Horizontal Ø80/80 m 15 15 15 15 15 15 Twin-pipe Vertical Ø80/80 m 15 15 15 15 15 15
Plume Management Kit (Max length) m 8 8 8 8 8 8
Technical specications
Baxi Megao System Compact GA
Page 20
For technical enquiries e-mail [email protected]
20
Accessories and controls
Baxi plug-in 24 hour timer – standard (#720645201) & compact (#720818201)
We supply a comprehensive range of easy-to-t accessories to ensure that your customers reap the maximum benets of economy and efciency from their Baxi boiler.
• Compatible with Baxi Neta-tec Combi GA and Baxi Duo-tec Combi GA
• Plugs into boiler fascia for simple timer option
• Easy-to-read backlit LCD display
• The usability of our mechanical timer with digital features
Baxi electro-mechanical 24 hour timer kit (#720971401)
• To be sited remotely from the boiler
• Simple-to-use tappet time clock in 15min adjustable time segments
• On/Off/Auto functionality
Baxi room thermostat (#720971601)
• Easy to use dial
• Temperature range 5˚C to 35˚C adjustment
• Additional savings of £71 can be achieved by installing a room thermostat
†
Item description Compatible range Sales Code
Baxi plug-in 24 hour timer - standard (Duo-tec) Baxi Duo-tec Combi GA 720645201
Baxi plug-in 24 hour timer - compact (Neta-tec) Baxi Neta-tec Combi GA 720818201
Baxi electro-mechanical 24 hour timer kit
Baxi Neta-tec Combi GA, Baxi Duo-tec Combi GA & Baxi Megao System Compact GA
720971401
Baxi room thermostat
Baxi Neta-tec Combi GA, Baxi Duo-tec Combi GA & Baxi Megao System Compact GA
720971601
Baxi wireless 7 day programmable room thermostat
Baxi Neta-tec Combi GA, Baxi Duo-tec Combi GA & Baxi Megao System Compact GA
720030501
Baxi programmable 24 hour wireless sensor (single channel) Baxi Neta-tec Combi & Baxi Duo-tec Combi GA 720644901
Baxi programmable 7 day wired sensor (2 channel) Baxi Neta-tec Combi GA & Baxi Duo-tec Combi GA 720644701
Baxi programmable 7 day wireless sensor (2 channel) Baxi Neta-tec Combi GA & Baxi Duo-tec Combi GA 720644801
Baxi wired weather sensor Baxi Neta-tec Combi GA & Baxi Duo-tec Combi GA 720103001
Multit HeatSaver & GS1 GasSaver Kit Baxi Neta-tec Combi GA & Baxi Duo-tec Combi GA 72072001
Multit (Compact) GasSaver GS1c Baxi Neta-tec Combi GA & Baxi Megao System Compact GA 720855201
Multit GasSaver GS1 Baxi Duo-tec Combi GA & Baxi Megao System 32 GA 720056901
Multit external boiler discharge pump (PRV & condensate)
5m Vertical head
Baxi Neta-tec Combi GA & Baxi Megao System Compact GA 720648301
Multit stand off kit - standard Baxi Duo-tec Combi GA 720648101
Multit stand off kit - compact Baxi Neta-tec Combi GA & Baxi Megao System Compact GA 720648201
Remote PRV Kit Baxi Neta-tec Combi GA & Baxi Megao System Compact GA 5121379
Page 21
21
www.baxi.co.uk
Multit external boiler discharge pump (PRV & condensate) (#720648301)
Accessories and controls
• External pump solution
• Stores and discharges high temperature waste from boiler pressure relief valve avoiding the need for
external pipework
• Manages condensate line waste allowing pump to discharge into soil pipe
• 5 metre vertical head
Baxi programmable 24 hour wireless sensor (#720644901)
• Compatible with Baxi Neta-tec Combi GA and Baxi Duo-tec Combi GA
• Single channel timer and room sensor
• Easy to read backlit LCD display
• Energy-saving night set-back function lowers night time room temperature
• Enhanced load compensation up to 3% SAP benet
Multit GasSaver – GS1 (#720056901) & GS1c (#720855201)
• Standard (GS1) for use with Baxi Duo-tec Combi GA and Baxi Megao System 32 GA
• Compact (GS1c) for use with Baxi Neta-tec Combi GA and Baxi Megao System Compact GA
• Saves up to 37% of the gas used to heat hot water annually**
• Reduces cold water consumption by up to 7%**
• No servicing or maintenance required
*Based on SAP 2005 and Building Regulations Part L 2006. In independent tests conducted by TUV and TNO this one simple device was proven to deliver domestic hot
water savings of up to 7% and reduce the gas used to heat hot water by up to 37% compared to a SEDBUK (2005) Band A combination boiler.
**Test conducted by independent scientic test house, TNO. Calculation based on an average household’s consumption of 100 litres of hot water per day. Results were based on a comparison of a SEDBUK (2005) >91% rated high efciency boiler versus a high efciency boiler and GasSaver.
†
Source: Energy Saving Trust
Baxi wired weather sensor (#720103001)
• Monitors outside temperature and optimises boiler performance for efciency, economy and comfort
• Recognised SAP benet up to 3%
• No servicing or maintenance
Baxi wireless 7 day programmable room thermostat (#720030501)
• Portable room thermostat for ease of use and greater comfort
• 7 day programmable timer
• Additional savings of £71 can be achieved by installing a room thermostat
†
Multit HeatSaver and GS1 GasSaver kit (#72072001)
• SAP benet up to 7.5%*
• Increases boiler efciency – saves up to 37%** of the gas used to heat hot water annually, compared to a SEDBUK (2005) >90% band A boiler
• Low carbon solution, offering up to 700kg carbon emissions saving
• Reduces cold water consumption by up to 7%** compared to a SEDBUK (2005) >90% band A boiler
• Maintenance free – no moving parts and no annual servicing required
• Simple to install – designed for easy and fast tting such as a standard airing cupboard
Page 22
Flue options
Multit ue kits now come with positive screw xings for all connections and are available in a
choice of lengths to reduce the need for onsite cutting. By popular demand we offer a choice of colours for the terminals to match existing rainwater systems.
Maximum permissible equivalent ue lengths for Baxi Duo-tec Combi GA , Baxi Neta-tec Combi GA and Baxi Megao System Compact GA are:
Where inline bends are required in a ue system,
the overall length must be reduced by the
following amounts:
Horizontal Concentric Flues Ø 60/100mm - Multit Flue Group A
Plume Displacement Kits Ø 60/100mm - Multit Flue Group A
Horizontal Concentric 10m 20m
Vertical Concentric 10m 20m
Horizontal Twin pipe 15m
Vertical Twin Pipe 15m Vertical Ridge Termination 8m
Concentric Pipes 135° bend 0.5m 93° bend 1m Twin Flue Pipe 135° bend 0.25m
91.5° bend 0.50m
Item Description (Multit) Flue System Colour Specication
Key & OD Dimensions
Sales Code
1 STD Horizontal Telescopic Flue inc. Low Prole
Elbow & Fixing Screws
White pipe/White terminal
315mm - 500mm 60/100mm 720599401
2 STD Horizontal Telescopic Flue inc. Low Prole
Elbow & Fixing Screws
White pipe/ Black terminal
315mm - 500mm 60/100mm 720598701
3 STD Horizontal Telescopic Flue inc. Low Prole
Elbow & Fixing Screws
White pipe/Brown terminal
315mm - 500mm 60/100mm 720642701
4 Neta-tec Combi GA Horizontal Telescopic Flue Kit White pipe/
Black terminal
315mm - 500mm 60/100mm 720870201
5 Flue Terminal Deector White 60mm 720644201 6 Flue Terminal Deector Black 60mm 5111068 7 Flue Terminal Deector Brown 60mm 720644301 8 1m Flue Extension inc. Fixing Screws White 1000mm 100mm 720648801 9 0.5m Flue Extension inc. Fixing Screws White 500mm 100mm 720643001 10 0.25m Flue Extension inc. Fixing Screws White 250mm 100mm 720643101 11
93
° Flue Bend inc. Fixing Screws
White
93°
100mm 720648401
12
135
° Flue Bend inc. Fixing Screws
White
135°
100mm 720648501
13
135
° Flue Bend inc. Fixing Screws (pair)
White
135°
100mm 720647901 14 Offset Adaptor Elbow White Duo-tec GA only 100mm 720635501 15
93
° Low Prole Boiler Elbow
White
93°
100mm 720550801 16 Stainless Steel Terminal Guard - Ø 60/100 S/S Stainless Steel 100mm 720627901
Item Description (Multit) Flue System Colour Specication
Key & OD
Dimensions
Sales Code
17 Plume Displacement Terminal Kit inc.1m Extension
& Brackets
White 100mm 720627001
18 Plume Displacement Kit Extension & Brackets White 1000mm 60mm 720643401 19 Plume Displacement Kit Bend White
93
°
60mm 5121369 20 Plume Displacement Kit Bend - Pair White
135
°
60mm 5121370 21 Plume Displacement Terminal Kit inc.1m Extension
& Brackets
Black 100mm 720622901
22 Plume Displacement Kit Extension & Brackets Black 1000mm 60mm 720643301 23 Plume Displacement Kit Bend Black
93
°
60mm 720648701 24 Plume Displacement Kit Bend - Pair Black
135
°
60mm 720648601 25 Stainless Steel PDK Guard Ø 60/100 - Air Intake S/S 720644601
Group A Group G Group NFlue type
22
For technical enquiries e-mail [email protected]
Page 23
23
Vertical Concentric Flues Ø 60/100mm – Multit Flue Group A
Item Description (Multit) Flue System Colour Specication
Key & OD
Dimensions
Sales Code
26 Vertical Ridge Flue Terminal Brown 100mm 720647101 27 Vertical Flue Terminal Black 100mm 5118576 28 Roof Cover Plate 125mm 246143 8 1m Flue Extension inc. Fixing Screws White 1000mm 100mm 720648801 9 0.5m Flue Extension inc. Fixing Screws White 500mm 100mm 720643001 10 0.25m Flue Extension inc. Fixing Screws White 250mm 100mm 720643101 11
93
° Flue Bend inc. Fixing Screws
White
93°
100mm 720648401 12
135
° Flue Bend inc. Fixing Screws
White
135°
100mm 720648501 13
135
° Flue Bend (Pair) inc. Fixing Screws
White
135°
100mm 720647901 29 Pitched Roof Flashing
25
°/50°
125mm 5122151 30 Flat Roof Flashing 125mm 246144
Flue options
1
20
28 29 30
25 26 27
12
16 17 18 19
13 14 15
5 8 112
24
6
21 22 23
93 7 104
(x2)
(x2)
www.baxi.co.uk
Page 24
Flue options
Horizontal Concentric Flues Ø 80/125mm - Multit Flue Group G
Vertical Concentric Flues Ø 80/125mm - Multit Flue Group G
Item Description (Multit) Flue System Colour Specication
Key & OD Dimensions
Sales Code
31 Horizontal Flue inc. boiler and terminal adaptors Black 125mm 5118580
32 1m Flue Extension White 1000mm 125mm 5118584
33 Flue Bend White
91.5
°
100mm 5118588
34 Flue Bend (Pair) White
135
°
100mm 5118597
35 Pipe Support Bracket White 125mm Flue Pipes 100mm 5118610
Item Description (Multit) Flue System Colour Specication
Key & OD Dimensions
Sales Code
36 Vertical Flue Terminal Black 125mm 5111078
32 1m Flue Extension White 1000mm 125mm 5118584
33 Flue Bend White
91.5
°
125mm 5118588
34 Flue Bend (Pair) White
135
°
125mm 5118597
28 Roof Cover Plate (see page 23 for image) 125mm 246143
37 Flue Vertical Adaptor White 100/125mm 5111070
29 Pitched Roof Flashing (see page 23 for image)
25
°/55°
125mm 5122151
30 Flat Roof Flashing (see page 23 for image) 125mm 246144
35 Pipe Support Brackets White 125mm Flue Pipes 125mm 5118610
31
35
39
43
47
40
44
41
45
42
46
32
36
33
37
34
38
(x2)(x2)(x2)
(x2)
(x2)
24
For technical enquiries e-mail [email protected]
Page 25
25
www.baxi.co.uk
Twin Pipe Flues 80/80mm – Multit Flue Group N
Item Description (Multit) Flue System Colour Specication
Key & OD Dimensions
Sales Code
36 Vertical Flue Terminal Black 125mm 5111078
38 Twin Pipe Extension (Pair inc. Brackets) White 1000mm 80mm 5111087
39 Twin Pipe Flue Bend (Pair) White
90
°
80mm 5111072
40 Twin Pipe Flue Bend (Pair) White
135
°
80mm 5111086
28 Roof Cover Plate (see page 23 for image) 125mm 246143
41 Twin Pipe Flue Horizontal Terminal Kit (Air & Exhaust) Stainless steel 575mm 80mm 5120172
42 Twin Pipe Flue Adaptor (Boiler) White 80/80mm 720089801
43 Twin Pipe Support (Pair) White 80mm 5111081
44 Twin to Concentric Adaptor 80/80 - 80/125 White 80/125mm 5111084
29 Pitched Roof Flashing (see page 23 for image)
25
°/50°
125mm 5122151
30 Flat Roof Flashing (see page 23 for image) 125mm 246144
45 Pitch Roof Flue Terminal Black
25
°/50°
60mm 720576301
46 Pitched Roof Terminal Adaptor Kit White 60-80mm 5121792
47 Single Flue Terminal (Air Only) 80mm 5121791
Terminal Position with Minimum Distance (mm)
A
1
Directly below an opening, air brick, opening
cte ,swodniw
B
1
Above an opening, air brick, opening window etc 300
C
1
Horizontally to an opening, air brick, opening window etc 300
D
2
52epip niard ro sepip lios ,srettug woleB
E
2
52evae woleB
F
2
52oor trop rac ro seinoclab woleB
G
2
52epip lios ro epip niard lacitrev a morF
H
2
52renroc lanretxe ro lanretni na morF
003level ynoclab ro foor ,dnuorg evobAI
From a surface or boundary line facing a terminal K From a terminal facing a terminal (Horizontal flue) K
From a terminal facing a terminal (Vertical flue)
L From an opening in carport (e.g. door, window)
gnillewd eht otni
1.
In addition, the terminal should be no nearer than 150mm to an opening in the building fabric formed for the purpose of accommodating a built-in element such as a window frame.
2.
Only ONE 25mm clearance is allowed per installation. If one of the dimensions D, E, F, G or H is 25mm then the remainder MUST be as B.S.5440-1.
M Vertically from a terminal on the same wall 1500 N Horizontally from a terminal on the same wall 300
) 300ylno lacitrev( eulf ot llaw tnecajda morFR S From an adjacent opening window (vertical only) T Adjacent to windows or openings on pitched and flat roofs U Below windows or openings on pitched roofs
300
1200
600
1200
s
s
f
1000 600 2000
600
600
N
I
I
G
F
M
I
A
A
F
H
J,K
D E
H
C
R
A
I
J,K
I
L
S
B
T
U
Likely flue positions requiring
a flue terminal guard
Terminal Assembly
Top View Rear Flue
Property Boundar y Line
300mm min
Opening Window or Door
150mm min.
Plume Displacement Kit
Air Inlet
IMPORTANT: If tting a
Plume Displacement Flue
Kit, the air inlet must be a
minimum of 150mm from any opening windows or doors
NOTE: The distance from a fanned draught appliance terminal installed parallel to a boundary may not be less than 300mm in accordance with the diagram.
Flue options
Page 26
For technical enquiries e-mail [email protected]
26
For technical enquiries e-mail [email protected]
Other heating solutions from Baxi
Baxi Platinum Combi HE A
*
Baxi Duo-tec Combi HE A
*
Whatever heating solution is the most suitable for your customer, we have
a range of highly efcient and innovative products to choose from
The Baxi Platinum Combi HE A is a favourite with homeowners and installers alike.
Homeowners love the assured peace of mind from its ve year parts and labour warranty as well as its high efciency. It is an Energy Saving Trust Recommended product. The
integral 24 hour electro-mechanical timer is also very easy to use. Installers appreciate
the features which make the boiler so fast and easy to t: a pre-plumbing jig, 1m ying lead for easy electrical connection and extensive ue options with lengths up to 20m. The
Baxi Platinum Combi HE A is available in 24kW, 28kW, 33kW and 40kW outputs, offering
exceptional hot water ow rates for most sizes of property.
The Baxi Duo-tec Combi HE
A boiler combines our passion for technology with our
commitment to the environment. Stylish and simple to use, the Baxi Duo-tec Combi HE A has straightforward controls, an easy-to-read pressure gauge, a modern chrome strip and
beautiful gloss white nish. Because the Baxi Duo-tec Combi HE A turns more than 90% of the fuel to heat, it has the highest SEDBUK (2005) Band ‘A’ rating for efciency, saving you money
on your heating bills. It also helps the environment by using less fuel and therefore producing fewer emissions. The Baxi Duo-tec Combi HE LRG model is available in outputs of 24kW, 28kW and 33kW.
26
Baxi Solo HE A
The Baxi Solo HE A is our highly advanced heat only boiler and is Energy Saving Trust Recommended. Fitting effortlessly into any modern interior, including homes with limited space due to its compact dimensions and stylish design. The Baxi Solo HE A is available in ve
outputs, 12kW, 15kW, 18kW, 24kW and 30kW to t most sized properties, has a lightweight, compact design for exible siting and can be installed on a fully TRV system. It is also
suitable for use with vented or sealed heating systems and comes with simple controls for easy operation. No pump overrun is required removing the need for re-wiring and reducing disruption to the property, meaning this boiler will directly replace any existing heat only boiler.
Baxi Bermuda BBU HE
The Baxi Bermuda BBU HE is the only direct replacement high efciency back boiler on the market. It provides the most cost effective alternative for existing standard efciency back
boiler units and complies with all legislative and building regulations.
* Seven year parts and labour warranty applies to the Baxi Duo-tec Combi HE A only, for boilers purchased between 1st February 2013 and 31st
December 2013. Ten year parts and labour warranty applies to the Baxi Platinum Combi HE A only, for boilers purchased between 1st March 2013 and 31st December 2013. Offers do not apply to other Baxi boilers, including the Baxi GA range. Registration must be completed within 30 days of installation. The warranty is subject to registration by the installer at www.baxi.co.uk/warranty and completion of an annual service. Additionally, the Benchmark log book needs to have been completed correctly on installation. The warranty is available for all one-off installers. The offer excludes contract sales and any contract supported sales. Please see www.baxi.co.uk/warranty for more details. Errors and omissions excepted.
Page 27
27
www.baxi.co.uk
27
www.baxi.co.uk
Other heating solutions
Baxi Ecogen™
Baxi Solaro™
The Baxi Ecogen is a dual energy micro-CHP boiler, delivering highly efcient heating and hot water and generating up to 1kW/h of low cost, low carbon electricity. It is also MCS certied
making it eligible for the Government’s Feed-in Tariff.
The Baxi Solaro provides hot water using free solar energy and can signicantly reduce
fuel bills and carbon emissions. The range includes on-roof and in-roof collector panels and
evacuated tubes, and is MCS certied.
The Baxi Solargen is a complete PV kit which uses energy from daylight to produce clean,
sustainable electricity. The range includes a number of outputs with both pitched roof & at
roof mountings available. The kit includes all components required for installation and is
MCS Certied.
Baxi Bioo™
Baxi Solargen™
Baxi Geoo™
The Baxi Bioo is the ideal solution for homeowners who wish to take a proactive role in environmental protection. The 94% efcient wood pellet biomass boiler provides a steady supply of clean, sustainable, carbon neutral heating and hot water. It is MCS certied.
The Baxi Geoo ground source heat pump exploits the latent heat from the earth. It is
particularly effective for use in the UK as our ground temperature below a certain depth
remains constant throughout the year. The Baxi Geoo is particularly suitable for well insulated, off mains gas homes with underoor heating or low temperature radiators.
Page 28
For technical enquiries e-mail [email protected]
Technical support
If you need additional information to complete an installation while on site, our technical support team made up of experienced heateam and gas engineers are always available on the end of the phone with direct access to our boilers to provide all the backup you need to
get the job nished quickly and easily.
Warranties
Once you’ve installed your customer’s new Baxi boiler they will be covered by our two years
parts and labour warranty*. They can register
their warranty either online or by post, giving them complete peace of mind. Once this initial warranty has expired, they have the option of
extending it.
Aftersales service
heateam, our award-winning
customer service division, is our team of 270 Gas Safe registered engineers working across the UK to ensure your customers are happy with their investment in their Baxi boiler. In fact, it’s like having your very own
aftersales team. Any problems encountered with a Baxi product within two years of installation will be resolved quickly and
efciently by one of our engineers.
If you’re a member of our business support scheme works we will guarantee to be with
your customer the very next day**.
Our aftersales support is on hand whenever you need it, even if you
haven’t nished the installation yet
Supporting the best, with the best
28
“If you need some support during an installation it’s great to know that heateam are at the end of the phone. It’s clear that their guys have been on the tools and know how we work, which is reassuring” .
Call us on 0844 871 1525
www.heateam.co.uk
heateam opening hours are: Monday - Friday 8am - 6pm
Saturday/Sunday 8.30am - 2pm
*Subject to registration and an annual service by any Gas Safe registered installer **Calls booked before 3pm
Page 29
29
www.baxi.co.uk
So that you’re happy and condent in installing our
great products, we provide a range of high quality courses on electrics, diagnostics, controls and every other aspect of installation. Our courses are held at dedicated, fully equipped UK training centres and delivered by trainers with many years’ experience of Baxi products. They’re designed to help you understand the THINK combustion management system and boiler components and make installation, service and maintenance easier and simpler. We also offer free training days on our new range of boilers.
Our support for you
After sales support
Our free product training courses are available throughout the UK and are a great way to learn about Baxi boilers
“Baxi puts together programmes that are thorough and professional and keep me up to date with new technology which helps me do
my job with condence”
For more information and to
book a course, visit
www.bdrthermeatraining.co.uk
Page 30
For technical enquiries e-mail [email protected]
30
Running a business of any size isn’t easy, especially in the
current economic climate. That’s why we’ve set up works, our great new business support scheme. Far more than a loyalty programme, works rewards genuine two-way communication between you and Baxi.
Rewards
Earn points to spend on a range of gifts and business support
Free Gas Safe notication
Save time and money on Gas Safe notications with works’
easy online process
Next day call out
We’ll support you with next day call out* from heateam, our award-winning customer service division
Annual service reminder
We prompt your customers to call you when their annual
service is due**
‘Find an installer’
We’ll help you grow your business by adding a listing on to ‘Find an installer’ on the Baxi website
works - you’ve earned it
Here are just a few of the benets that works can offer:
* calls booked before 3pm **Available for registered boilers only. See website for details
•
We want to thank you for your business and help you grow it
www.works2gether.co.uk
Page 31
31
www.baxi.co.uk
Baxi literature
Local events
At Baxi we know that buying a new boiler is a big decision. With this in mind we aim to provide as much relevant information as possible for you and your customers.
We understand that trying a new boiler is a decision you will not take lightly, which is why our team of experienced Area Sales Managers are on hand to discuss our new range of products. Visiting us at your local merchant is a great opportunity to get your hands on our Baxi GA boilers as well as discussing the latest developments in the industry.
For more information and to join us at a local merchant near you visit www.baxievents.co.uk
If you would like to order any brochures please call our literature hotline on 0844 871 1525 or contact your local Baxi Area Sales Manager.
All our brochures, instructions, leaets and guides are available free of charge.
To download our brochures electronically visit www.baxi.co.uk
Introducing the Baxi Duo-tec Combi GA Boiler
www.baxi.co.uk
28/02/2012 17:03
2
www.baxi.co.uk
Install warmth, efciency & peace of mind
The Baxi GA Combi & System Boiler Range
www.baxi.co.uk
Combi and system boilers
TECHNICAL GUIDE
Technical Helpline: 0844 871 1525
Local events & Literature guide
Supporting you out on the road as well as providing great back ofce
support is what Baxi is all about
Page 32
For technical enquiries e-mail [email protected]
1
For all enquiries, please call
0844 871 1525
Email: [email protected] Visit: www.baxi.co.uk
Open Monday - Friday, 8am - 6pm Saturdays & Bank Holidays, 8.30am - 2pm We are closed on Christmas Day & New Year’s Day
To book a training course please call 0845 600 7402 Open Monday - Thursday, 8.30am - 5pm Friday, 8.30am - 4.30pm or visit www.bdrthermeatraining.co.uk
Please note calls may be monitored or recorded
Contact us
Baxi, Brooks House, Coventry Road, Warwick CV34 4LL
www.baxi.co.uk
This Brochure is printed on paper sourced from well managed forests, controlled sources. This Brochure is printed using vegetable based
inks. Please recycle this Brochure when you have nished with it.
Baxi policy is one of continual improvement and development. The
right to change specication and appearance without prior notice is
reserved. The reproduction of colours is as accurate as photographic and printing processes allow. The consumer’s statutory rights are not affected. e&oe
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
