Cordless Pole Chainsaw
Safety
General Safety Precautions
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions
may result in electric shock, fire and/or serio us injury.
•
Save all warnings and instructions for future reference.
•
The term "power tool" i n the warnings refers t o your m ains-operated (corded) power tool or Battery-operated
power tool.
•
Work area safety
− Keep work area clean and well lit . Cluttered or dark areas invite accidents.
− Do not operate power tools in explosive atmospheres , such as in the presence of flammable liquids,
gases or dust. Power tools create sparks which may ignite the dust or fumes.
− Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
•
Electrical safety
− Power tool plugs must m atch the outlet. Never modify the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. U nm odifie d plugs and matching outlet s will reduce risk of elec tric
shock.
− Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
− Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of
elect ri c shock.
− Do not abuse the cord. N ever use the cord for carrying, pulling or unplugging t he power tool. K eep cord
away from heat, oil, sharp edges or moving parts. D amaged or entangled cords increase the risk of
elect ri c shock.
− When operating a power t ool outdoor s, use an extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
− If operating a power t ool in a damp location is unavoid able, use a residual c urrent device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock. NOTE: The term “resid ual c urr ent
device (RCD)” may be replaced by the term “ground fault circuit interrupter (GFCI)” or “eart h leakage
circ uit br eaker (ELCB)”.
•
Personal safet y
− Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a
power tool while you are tired or under the influe nce of drugs, alcohol or m edication. A moment of
inattention whil e oper ating power tools may result in serious personal i njury.
− Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, har d hat, or hearing pr otection used for appropriate conditions will reduce
personal injuries.
− Prevent unintentional starting. Ensure the switch is i n the off-position befor e connecting to power source
and/or battery pack, picking up or carrying t he tool. Carrying power tools with your finger on the switc h or
energising power tools that have the switch on invites accidents.
− Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal injury.
− Do not overreac h. Keep proper footing and balance at all t imes. This enables better control of the power
tool in unexpected situations.
1
Cordless Pole Chainsaw
− Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and glov es awa y from
moving parts. Loose clothes, jewellery or lo ng hair can be caught in moving parts.
− If devices are provided for the connection of dust extraction and collection facilities, ensure these ar e
connected and properly used. Use of dust collec tion can reduce dust-related hazards.
•
Power tool use and care
− Do not force the power tool. U se the correct power tool for your appl ication. The cor rect power tool will
do the job better and saf er at the rate for which it was desig ned.
− Do not use the power tool if t he switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
− Disconnect t he plug f rom the power source and/or the battery pack from t he power tool before making
any adjustme nts , changing a ccessori es, or storing power tools. Such preventive safet y measures reduce
the risk of starting the power tool accidenta lly.
− Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool
or these instruct ions to operate the power tool.
− Power tools are dangerous in the hands of untrained users.
− Maintain power tools. Check for misalig nm ent or binding of moving parts, breakage of parts and any
other condition t hat may affect the power tool’s operation. If dam aged, have the power tool repaired
before use. Many accidents are caused by poorly m aintained power tools .
− Keep cutting tools sharp and clean. Properly m aintained cutting tools with sharp cutt ing edges are less
likely to bind and are eas ier to control.
− Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into
account the working conditions and the work to be performed. Use of t he power tool f or operations
different fr om those intended could result in a hazardous situation.
•
Battery tool use and care
− Recharge only wit h the charger specified by the manufact urer. A charger that is suitable for one type of
battery pack may cr eate a risk of fire when used with anot her battery pack.
− Use power tools only with specifically designated battery pack s. Use of any other battery packs may
create a risk of injury and fire.
− When battery pack is not in use, keep it away from other metal objects, like paper c lips, coins, keys,
nails, screws or other small metal objects that can make a connection fr om one terminal to another.
Shorting the batter y ter minals together may cause burns or a fire.
− Under abusive conditions, liquid may be ej ected from the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected fr om the
battery may cause irritation or burns.
•
Service
− Have your power tool serviced by a qualified repair person using only identical replacement parts. This
will ensure that t he safety of the power tool is maintai ned.
•
Storage
− Use transport guard duri ng transport and stor age.
− Clean and maintain before s torage.
− Secure the unit during transport to prev ent los s of fuel, damage or injury.
2
Cordless Pole Chainsaw
Trimming Precautions
Never stand directly under the limb you are trimm ing. A lways position
yourself out of t he path of f alling debris.
Never stand on a ladder or other type of unstable support while using
the Pole saw.
Always use both hands to operate pole saw. Keep a f irm, steady
pressure on the pole s aw while cutting but do not try to force the saw
through the wood.
Do not use the pole saw to cut limbs larger in diameter than the leng th
of the guide bar.
Keep other persons away from cutting end of pole saw and at a safe
distance from work area.
Do not use pole saw near cable, electric power or telephone lines.
Maintain a minimum clearance of 10 feet from all power lines.
3
Cordless Pole Chainsaw
Components
No. Part No. Part
1. Saw chai n 9. Grip area
2. Guide bar 10. Buckle
3. Scabbard 11. Strap
4. Cap 12. Trigger loc k out
5. Power he ad 13. Handle
6. Top tube 14. Trigger
7. Locking knob 15. Battery
8. Under tube 16.
Battery r elease
button
4
Cordless Pole Chainsaw
Set-Up
Charging the Battery
Before attempting to charge the battery
pack, thoroughly read all Safety Instructions.
The battery needs to be charged before first use
and whenever it fails to produce sufficient p ower
on jobs that were easily done before. The
battery may become warm while charging; this
is normal and does not indicat e a problem.
NOTE: After several charge and discharge
cycles, the battery will attain full capacity.
WARNING! DO NOT CHARGE THE BATTERY
AT AMBIENT TEPERATURES BELOW 4ºC OR ABOVE 40ºC
1. Plug charger c ord into c harger base.
IMPORTANT: Do not use any other charger, only use the charger that com es w ith the product.
(BELOW 40ºF OR ABOVE 104ºF).
2. Plug the charger into an electrical outlet. The charge LED will light up green.
IMPORTANT: Do not charge via an engine gener ator or DC power sourc e.
3. Slide the charger into the battery pack. The charge LED will light up red indicating that the battery is
charging. NOTE: It may take 2 – 5 mins to turn red.
4. When the LED turns green again, it indicates that t he battery is fully-charged. After the initial charge, under
normal usage, your battery pack should be fully charged in 4 hours.
5. Unplug charger. Remove the batter y fr om the cha rger.
Important Charging Information
•
After normal usage, your battery pack shoul d be fully charged in about 4 hours. Allow the battery to cool
down before charging after using the saw. (NOTE: A hot battery placed in the charger will not charge).
•
The battery norm ally provides 15 minutes continuous run time depending on size of branches bei ng cut. This
equates to approx. 30 x 6cm cuts. Time may vary depending on hardness and diameter of timber.
•
Battery may drain slowly if connected to the unit w hen in storage. A lways disconnect between uses.
•
When battery has expired, chainsaw will immediately cease operating and will require a full charge.
•
If storing your chainsaw for a period of more than 30 days, fully charge your battery beforehand. Once
charged, remove from charger and do not reinsert into saw.
•
DO NOT charge the battery pack in an air temperature below 4°C or above 40°C. This is im portant and will
prevent ser ious damage to the battery pack.
•
While charging, the charger may hum and become warm to touch. This is a normal condition and does not
indicate a problem.
•
To prolong battery life, avoid leaving the battery pack on charger for extended periods of time (over 30 days
without us e). Although overcharging is no t a safety concern, it ca n signif icantly reduce overall battery life.
•
The battery pack will reach optimum performance after being cycled 5 times during normal usage. There is
no need to run the batteries down completely before recharging. Normal usage is the best method of
discharging and recharging the batteries.
5
Cordless Pole Chainsaw
Pole Chainsaw Assembly
IMPORTANT! The chainsaw may come with plastic spacers over or around the bar st uds - the spacer is for
shipping purposes only and must be removed before mounting the chain bar. Af ter removing the chain brak e
cover, remove any spacers, then mount the chain bar as described. Failure to remove any spacers before
assembling and usi ng the chainsaw will pres ent an injury hazard, damage the unit and will void the warranty.
WARNING! Cutting edges on chain are sharp. Use protective gloves when handling chain.
1. Remove battery from chain sa w .
2. Attach chain saw to the head of the pole plug in the u nder pole with a handle.
IMPORTANT: When inserted, #1 would have to be in line with #2, and must be inser ted in the end (see
image below).
3. Lock the pole joints together.
6
Cordless Pole Chainsaw
4. Insert the strap into the buckle.
5. Add high-quality bar oil into the pole saw's bar oil tank.
IMPORTANT: After filling the bar oil tank up, close t he cap tightly.
6. To insert the batter y pack, inser t it in the handle’s groove until the Battery Release Butt on (#16 in the image
below) bounces back to its normal position.
To remove the battery pack, pus h and hold t he Battery Release Button (#16 in the im age below) and pull it
out gently. NOTE: Fully charg e the battery first before us ing it for the first time.)
7
Cordless Pole Chainsaw
Saw Chain Tension
WARNING!
•
Remove battery fr om pole saw before servicing. Severe injury or death could occur from body contact wit h
moving chain.
•
Cutting edges on chain are sharp. Use protective gloves when handling chain.
•
When cleaning the saw body:
− Do not submerge saw in any liq uids.
− Do not use products that contain ammonia, chlori ne, or abrasives.
− Do not use chlorinated cleaning solvents, carbon tetrachloride, kerosene, or gasoline.
NOTE: The saw cha in tension is properly s et a t the factory. A new cha in will stretch. Check new chain tension
fr equently (a fter d isconnect ing bat tery) during the f irst 2 hours of operation. Allow chain to cool down. Fol low
steps below to check saw chain tension.
1. Remove battery from chain sa w .
2. Place chain saw on a firm surface to check chain tension.
3. Pull chain with lig ht f orce 1/8" away from bottom of guide bar and release (see image below). If chain light ly
snaps back into place, t ension is correct. A slight sag (1/16" or less) between chain and bottom of guide bar
is acceptable.
Saw Chain Tension Adjustment
1. Loosen the guide bar screw before adjusting the chain (see image below).
8
Cordless Pole Chainsaw
2. Turn the adj usting screw on the front of the power head clockwise until slack has been removed from the
chain (see image below).
3. While weari ng protective gloves, pull down on the chain to check the chain tension.
4. Do not overdo the chain’s tensio n. Over-tensioning will cause excessive wear and will red uce the life of the
guide bar and chain. Over-tensioning also reduces the amount of cuts per battery charge.
5. After adjusting for the correct chain tens ion, t ighten the guide bar screw firm ly (see image below).
9
Cordless Pole Chainsaw
Operation
Cutting with the Cordless Pole Chainsaw
It is important you read and understand
the instruction manual before first use
and keep the manual in a safe place for
future reference.
Safety precauti ons must be observed to
reduce the risk of per son al injury when
operating this machine.
DANGER! Keep clear of power lines,
contact can cause death.
It is strongly recom m end ed that a
comprehensive t raining course on
machine use, fuel handling safety and
engine operation be completed before
attempting to use this machine.
Never allow children to access the
machine.
Always wear ear prot ection. Loud noises
for an extended period of t ime may
damage your hearing.
Total face and head protection must be
worn to reduce injury fr om falling
branches.
We ar no-slip heavy duty work gloves to
impro ve your grip on the saw handle.
Gloves also reduce the transmission of
machine vibration to your hands.
The dust produced during operation may
be dangerous to health. I f the work area
is very dusty or sm oky, wear a respirator.
1. Fill up the pole saw's bar oil tank with high-quality bar oil.
2. Attach the battery to the saw.
3. Use both hands to grip the pole saw. Always use the des ignated grip
areas and strap when operating the pole saw (see image below). Use a
firm grip. Thumbs and fingers must wrap around the pole saw handle and
pole.
4. Make sure your footing is secure. Keep feet reasonably apart. Divide your
weight evenly on both feet.
5. When ready to make a cut, press the trigger loc kout and squeeze the
tr igger. This will t urn the pole saw on. Releasing the t rigger will turn the
pole saw off. Make s ure that the saw is running before starting a cut.
6. W hen starting a c ut, plac e the moving chain against the wood. Hold the
pole saw firmly in place t o avoid possible bouncing or skating (sideways movement) of the saw.
7. Remove the pole saw from a cut with the saw still runni ng at full speed. Stop the pole saw by releasing the
trigger. Make sure that the chain has stopped before setting the pole saw down.
10
Cordless Pole Chainsaw
Maintenance
Cleaning the Saw Body
Keep the saw body clean. Use a soft cloth dampened with a mixture of mild soap and water, then wipe saw body
clean.
Guide Bar Maintenance
Uneven bar wear causes m ost guide bar problems. Incorrect sharpening of chain cutter and depth gauge
settings often cause this. When bar wears unevenl y, it w idens the guide bar groove (see im age below). This
causes chain clatter and rivet popping. Saw will not cut straight. Replace guide bar if thi s occurs.
Inspect the guide bar first before sharpening the chain. A worn or damaged guide bar is unsafe. A worn or
damaged guide bar will dam age the chain. It will also make cutting harder.
1. Remove the guide bar from the chainsaw.
2. Periodically remove any sawdust from the guide bar gr oove. Use a putty knife or wire (see image below).
3. Clean oil slots e a ch time after use.
4. Remove the burrs fro m the sides of the guide bar. Use a flat file to make the side edges square.
5. Replace the guide bar when:
− The bar is bent or cracked.
− The inside groove of the bar is badly worn down.
11
Cordless Pole Chainsaw
Sharpening the Saw Chain
Keep the chain sharp at all times. Your saw will cut f aster and more safely. A dull chain will cause undue wear
on the sprocket, guide bar, chain, and motor. If you force the chain into the wood and cutting creates only
sawdust with a f ew large chips, the chain is dull.
Items Needed to Shar pen the Chain
Purchase these item s from your local dealer , hardware store, or pole saw supp lies outlet.
•
5/32" round file
•
Depth gauge tool
•
File guide
•
Vise
•
Medium sized flat file
Sharpening Cutters
Use a file guide for 30° filing.
1. Adjust the chain for proper tension.
2. Clamp down the guide bar in a vise to hold the saw steady (NOTE: Do not clamp down the chain).
3. Press the 5/32" round file (attached to file guide) into the groove between the top plate and depth gauge on
the chain. The file guide sho uld rest on both top plate and depth gauge (see image below).
NOTE: File should be at midpoint of guide bar.
NOTE: This il lus tration shows the file guide placement and filing direction for sharpening the cutters on the
left side of the chain.
4. Hold the file guide level. Make sure that the 30° mark on the file guide is parallel to the centre of the guide
bar (see image below). This will ensure that you file the cutters at a 30° angle.
5. Fil e from the inside, then m ake your w ay towards the outside of the cutter unt il it is sharp. Only file in this
one direction (see image below).
NOTE: Two or three strokes with the file should sufficiently sharpen the cutter.
12
Cordless Pole Chainsaw
Filing Cutter Depth Gauges
The cutter depth gauge clearance is reduced as cutters are sharpened. After every second or third sharpening,
reset the cutter depth gauges.
1. Place the depth gauge tool (.025") firmly across the top of the two cutter s. Make sure that the depth gauge
enters the slot in the depth gauge tool (see image below).
2. Use a medium flat file . File the depth gauge level with a depth gauge tool.
3. Remove the depth gauge tool. With a flat file, round off the front corner of the cutter depth gauge (see image
below).
.
After several hand fi li ng s, have an authorised service or sharpening centre machine-sharpen the c hai n. This will
ensure an ev en filing.
13
Cordless Pole Chainsaw
Replacing the Saw Chain
IMPORTANT: Do not clamp down the chainsaw i n a vise to replace the saw chain or guide bar.
Replace the chain w hen the cutter s are too worn out to sharpen or when the chain breaks . Only use a c hai n that
is approved by the manufacturer. Always inc lude a new drive sprocket when replacing the chain. This will
maintain proper driving of t he chain.
Refer to the imag e above while completing the following st eps:
1. Loosen and remove the guide bar screw.
2. Remove the sprocket cover.
3. Remove the s aw chain.
4. Place the new chain around t he drive sprocket, which is along the top groove of the guide bar, and around
the guide bar nose. NOTE: Make sure that the cutting edges of the chain are facing in the right dir e ction.
Position the chain so that the cutting edges on top of the guide bar face the guide bar nose (see image
below and the indicator on the side the cover of the saw).
14
Cordless Pole Chainsaw
5. Before placing the sprocket cover into the positioning groove, verif y that t he adjusting nib is in the adj usting
hole on the guide bar.
6. Place the sprock et cover into the positioning groove.
7. Lock the sprock et cover with a guide bar screw. IMPORTANT: Tighten with fingers only.
8. Adjust the chain tensio n.
9. Secure ly tighten the guide bar scr ew with a Hexagon wrench.
CAUTION! Do not place the chain on the saw backwards. If the chain is backwards, the saw will vibrate
badly and will not cut.
Storage
If the saw is being stored for more than 30 days, follow the steps below:
1. Remove the battery from the chain saw.
2. Charge the battery fully.
NOTE: It could take up to 7 hours to c om pletely charge the battery.
3. When the battery is completely charged, remove it from the charger and put the protective cap on the battery
terminals.
IMPORTANT: To prolong the battery lif e, avoid leaving the battery in the charger for extended periods of
time (over 30 days without use).
4. Remove and clean the guide bar a nd chain. Clean the guide bar a nd chain by soaking them in a petroleumbased solvent or a mild soap and water mixture.
5. Dry out the guide bar and chain.
6. Place the chain in a container filled with oil. This will p revent rust from forming on the chain.
7. Wipe a thin coating of oil over the surfa ce of the guide bar.
8. Wipe off the outside of the saw body. Do this with a soft cloth dampened with a mixture of m ild s oap and
water.
9. Store the c hain saw and battery:
− In a high or locked place, out of children’s reach.
− In a dry place.
− In a carrying cas e or with the s cabbard over the guide bar.
Battery Disposal and Recycling
This product uses nickel-cadmium batteries. Local, state, or federal laws
may prohibit disposal of nickel-cadmium batt eries in ordinary trash.
To help protect the envir onment and conserv e natural resources, please
dispose of batteries properly. You may contact your local recycling centre
for information on where to drop off the batteries.
15
Cordless Pole Chainsaw
Technical Specifications
Model
Battery
Chainsaw
Shaft
Chain Speed
Bar and Chain Lubrication
Oil Pot Capacity
Throttle Control Handle
Charger
Length
Note: Minimal Ass embly required
MC2
20V 1300mA h Lithi u m
8 Inch
Aluminium
2.9 metres per second
Automatic
80ml
Rubber Over Moulded
240V
1.9-2.7m
16
Some experts believe the incorrect or prolonged use of almost any
product could cause
serious injur
y or de
a
th.
F
or in
f
orm
a
tion th
at
may reduce your risk of serious injury or death consult thepoints
below and additionally, the information available at
www.datastreamserver.com/safety
- Consult all docume ntation, packaging and
product labelling before use. Note that some
products feature online documentation which
should be printed and kept with the p roduct.
- Check product for loose / broken / damaged /
missing parts, wear or leaks (if applicable) before
each use. Never use a product with loose / b roken
/ damaged / missing pa rts, wear or leaks (if
applicable).
- Products must be inspected and serviced (if
applicable) by a qualified specialist every 6
months assuming average residential use by a
person of average weight and strength, ab ove
average technical aptitude, on a property
matching average metropolitan specification.
Intended use outside these guidelines could
indicate the product is not suitable for intended
use or may require more regular inspection or
servicing.
- Ensure all possible users of the p roduct have
completed an industry recognised training course
before being given access to the product.
- The product has been supplied by a general merchandise
retailer that may not be familiar with your specific applic ation or
your description of the applic ation. Be sure to attain third party
approval for your application from a qualified specialist before use
regardless of prior assurances by the retailer or its representatives.
- This product is not intended for use where fail-safe operation is
required. As with any product (take an au tomobile, aircraft,
computer or ball poi nt pen for example) there is always a small
chance of a technical issue that needs to be repaired or may
require replacement of the product or a part. If the possibility of
such failure and the associated time it takes to rectify could in any
situation inconvenience the user, business or employee or could
financially affect the user, business or employee then the product
is not suitable for your requirements. This p roduct is not for use
where incorrect operation or a failure of any kind, including but
not limited to a condition requiring product return, replacement,
service by a technician or replacement of parts could cause a
financial loss, loss of employee time or an in c
onvenience
requiring compensation.
- If this item has been purchased in error considering the points
above simply contact the retailer directly for details of their
returns policies if required.
Loading...
