MICROWAVE OVEN

INSTRUCTION MANUAL

MODEL:GEM252TK

Please read this booklet carefully before installation and using, and save it for future
reference.

1

Welcome to Think Appliances

Thank you for selecting a quality product from Think Appliances. We have taken the time to ensure
that your appliance is of the highest possible standard and will give you years of use in your home.

Please take the time to call our Customer Care centre on our free call number

1800 444 357

to register your 2 year parts and labour warranty (some conditions apply – please refer to your warranty
card for more details).

Our Customer Care centre is there to ensure you get the most out of your appliance. For example,
should you want to learn more about recommended cooking temperatures, the various cooking
functions available, how to set and program your LED clock, and importantly taking care of your
appliance when cleaning, please call us because we are here to help you.

It is important that you read through the following use and care manual thoroughly to familiarise
yourself with the installation and operation requirements of your appliance to ensure optimum
performance. Should you have any queries regarding this information, please don’t hesitate to contact
our Customer Care centre.

We also carry a complete range of spare parts for all Think products. Please contact our team at
Pronto Parts on 1300 306 973 for all your spare parts requirements.

Again, thank you for choosing an appliance brought to you by Think Appliances and we look forward
to being of service to you.

Kind regards,
Ruud Jona
Managing Director Think Appliances

2

This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.

IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR
FUTURE REFERENCE

– WARNING: If the door or door seals are damaged, the oven must not be operated until it has been
repaired by a competent person;
– WARNING: It is hazardous for anyone other than a competent person to carry out any service or

repair operation that involves the removal of a cover which gives protection against exposure to
microwave energy;

– WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to

explode;

– WARNING When the appliance is operated in the combination mode, children should only use the

oven under adult supervision due to the temperatures generated.
– WARNING: Only allow children to use the oven without supervision when adequate instructions
have been given so that the child is able to use the oven in a safe way and understands the hazards of
improper use;

– only use utensils that are suitable for use in microwave ovens;
– when heating food in plastic or paper containers, keep an eye on the oven due to the possibility of

ignition;
– if smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any
flames;
– microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken
when handling the container;
– the contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature
checked before consumption, in order to avoid burns;
– eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they
may explode, even after microwave heating has ended;

– refer to “Cleaning and maintenance” details for cleaning door seals, cavities and adjacent parts;
– the oven should be cleaned regularly and any food deposits removed;
– failure to maintain the oven in a clean condition could lead to deterioration of the surface that could

adversely affect the life of the appliance and possibly result in a hazardous situation;
– only use the temperature probe recommended for this oven (for appliances having a facility to use a
temperature-sensing probe);

3

OPERATION THEORY OF MICROWAVE OVEN

1. Microwave is a form of high frequency electromagnetic wave, which is commonly distributed in the
nature. 53507Microwaves are dispersed in nature so that they cannot be concentrated for heating
purpose. The magnetron microwave generator in the oven transforms the energy of electricity to
microwave and the energy of microwave field is concentrated inside the closed cavity. Food molecules
are caused to vibrate at very high speed and the friction heat produced cooks the food quickly.

2. There are 3 properties of microwave:
a) Absorbability: the microwave can cause the excess vibration of molecule of various food so as to
obtain the heating purpose. But the infiltration ability is largely depend on the size, thickness and
properties of the food.
b) Penetrability: microwave can penetrate through ceramics, glass, temperature-resistant plastics. It is
required to use the containers whose material have good microwave penetrability to achieve best
heating result. See the below utensils guide.
c) Reflectivity: microwave would be reflected by the metal wall of interior cavity so as to establish an
even magnetic field, thus can prevent the overheating of partial area.

INSTALLATION OF MICROWAVE OVEN

1) The position of the oven shall be such that it is far from the TV, Radio or antenna as picture
disturbance or noise may occur.

2) The appliance must be positioned so that the plug is accessible.

3) This is a cabinet microwave oven, which is subject to PRECAUTIONS and INSTALLATION
below .

① PRECAUTIONS:

To ensure THIS microwave oven against a poor ventilation work, fires as well as an undue life, a
possible cabinet shall follow:

a) Intake and exhaust port on back surface, as shown in Fig.4.
b) Net depth≥550mm, as shown in Fig.3.
c) Reference plate thickness between 18 and 20mm.

② INSTALLATION:

a) Secure top air guide onto housing while outer-back baffle onto outer-back plate with self-lock

screws, as shown in Fig.1.

b) Secure holders onto each side housing with self-lock screws, as shown in Fig.2.

4

c) Place microwave oven into cabinet, then fix it with wood screws, as shown in Fig.3.
Cabinet details:

Cavity: (L)560mm*(H)360mm*(D)550mm;
Intake: (L)≥272mm*(W)≥72mm
Exhaust Port: (L)≥272mm*(W)≥72mm

5

d) Secure ornamental trim to holders, as shown in Fig.4.

e) Final assembly as shown in Fig.5.
