USER
MANUAL
COMPRESSOR WINE COOLER: FREE STANDING
BWC694 / BWC6166
CONTENTS
IMPORTANT SAFETY INFORMATION ...................................................1
DESCRIPTION OF APPLIANCE AND INSTALLATION ............................3
270L (BWC694) .......................................................................................................................................... 3
428L (BWC6166) ........................................................................................................................................ 4
ACCESSORY INSTALLATION BEFORE OPERATING...............................5
UNPACKING AND CLEANING THE WINE COOLER .......................................................................... 5
LOCK & UNLOCK THE DOOR (FOR OPTION) ..................................................................................... 5
OPERATING THE WINE COOLER ............................................................5
WORKING CLIMATE .................................................................................................................................. 5
WINE STORAGE .......................................................................................................................................... 6
CONTROL PANEL ...................................................................................................................................... 7
POWER ON/OFF CONTROL .................................................................................................................... 7
UNLOCKING THE CONTROL PANEL ..................................................................................................... 7
INTERIOR LIGHTING ON/OFF CONTROL ........................................................................................... 7
TEMPERATURE DISPLAY WINDOW ...................................................................................................... 8
TEMPERATURE SETTING ......................................................................................................................... 8
SELECTING FAHRENHEIT(ºF) & CELSIUS (ºC) DISPLAY ................................................................. 8
CARE AND MAINTENANCE ...................................................................9
CLEANING THE WINE COOLER .............................................................................................................. 9
POWER FAILURE......................................................................................................................................... 9
MOVING THE WINE COOLER ................................................................................................................. 9
ENERGY SAVING TIPS ............................................................................................................................... 9
TROUBLESHOOTING ..........................................................................10
REVERSE THE DOOR SWING ...............................................................11
INSTRUCTION MANUAL
●Please remove all packaging, stickers and films from the products surface and clean the
product’s surfaces with a damp cloth and mild detergent before using for the rst time.
●Let the appliance stand upright for approximately
24
hours before connecting it to the
power
source, which helps to reduce the possibility of a cooling-system malfunction from
handling
during transportation.
IMPORTANT SAFETY INFORMATION
Before using the appliance, please properly position and install it as described in this
manual. To avoid the risk of re, electrical shock, or injury when using the appliance,
follow these basic precautions:
●This appliance is for domestic purposes only and is intended to be used exclusively
for the storage of sealed bottled wines and beverages.
●The appliance must be positioned so that the plug is accessible.
●Make sure the voltage/current marked on the rating label corresponds with your
supply voltage. Plug into a grounded 3-pin outlet, do not remove grounding pin, do
not use an adapter, and do not use an extension cord.
●Do not connect or disconnect the electric plug with wet hands.
●To disconnect the appliance, grip the plug and pull it from the wall outlet. Never pull
out by the cord.
●It is recommended that a separate circuit, serving only your appliance be provided.
●Unplug the appliance or disconnect power before cleaning, maintenance or servicing.
Failure to do so can result in electrical shock or death.
●If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualied person in order to avoid a hazard.
●The fuse (or circuit breaker) size should be 10 amps or higher.
●This appliance can be used by children aged from 8 years and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
●This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
●Children should be supervised to ensure that they do not play with the appliance.
INSTRUCTION MANUAL
●To ensure proper ventilation for the appliance, the front of the unit must be
completely unobstructed. Locate the unit away from direct sunlight and sources of
heat (stove, heater, radiator, etc.).
●Do not attempt to repair or replace any part of the appliance unless it is specically
recommended in this manual. All other servicing should be referred to a qualified
technician.
●Ensure there are enough people to move and install the appliance to avoid any
damage to the appliance or injury to the any person.
●It is important for the appliance to be levelled in order to work properly. You may
adjust the appliance’s feet to level it.
●Never clean the appliance parts with ammable uids which may create a re hazard
or explosion. And do not store or use gasoline or other flammable vapours and
liquids in the vicinity of the appliance.
●Do not use solvent-based cleaning agents of abrasives on the interior. These cleaners
may damage or discolour the interior.
●Do not use this appliance for other than its intended purpose.
●Do not use electrical appliance inside the appliance.
●The use of attachments not recommended by the manufacturer may be hazardous.
●Please keep the products away from the re or similar glowing substance before you
dispose the appliance.
●GWP (Global Warming Potential): R600a=3
●When you dispose the appliance, take off the door and leave the shelves in place
so that children may not easily climb inside. And make sure the coolant circuit,
particularly the heat exchanger at the back/bottom of the unit is not be damaged.
●
The recycle symbol on the product or its packaging indicates that this
product is not to be handled as normal household waste and it is to be taken
to a recycling collection point for electrical and electronic goods.
INSTRUCTION MANUAL
DESCRIPTION OF APPLIANCE AND INSTALLATION
The following pictures only show description of appliance. The dimension and shelf
quantity may dier among the models of the same series.
270L – Model BWC694
Control Panel
Dual Zone
Deep Shelf
Shallow Shelf
Front Louvre
Outside Cabinet
Handle
Door
Gasket
Foot
Adjustable
≥1215mm
(47 ¾”)
≥
635mm
(25”)
1215mm
(47 ¾”)
595mm
(23 ½”)
≥
730mm
(28 ¾”)
680mm
26 ¾”
