Baumatic BWC600SS User Manual

BWC600SS 60 cm 46

Bottle dual

temperature wine

cooler

BWC600SS

60 cm 46 Bottle dual

temperature wine cooler

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference, for
you or any person not familiar with the operation of the appliance.

GS 17/08/10

2

Contents

Environmental note 4

Important safety information 5–6

Specifications of your wine cooler 7-10

Dimensions 7
Description of the appliance 8
Control panel 9
Description of the product features 9-10

Using your Baumatic wine cooler 10-15
Before switching on 10
During first use 10-11
Switching on the appliance and setting the temperature 11
Changing between Fahrenheit and Celsius 12
Loading the wine cooler 12-13

Storing your wines 13-14
Wine storage problems 15

Cleaning and maintenance 16-18
Defrosting 16-17
Removing the shelves for cleaning 17
Moving your wine cooler 17
Power failure 18
Vacation time 18

Installation 18-24
Electrical connection 19
Positioning 20
Built-in installation 21
Installing the handle 21-22
Reversing the door of your wine cooler 22-24

Troubleshooting 24-25

Contact details 26

3

Environmental note

Note

: Before discarding an old appliance, switch off and
disconnect it from the power supply. Cut off and render any plug
useless. Cut the cable off directly behind the appliance to prevent
misuse. This should be undertaken by a competent person. Disable
the door lock to make sure that children cannot get stuck inside
the appliance.

o The packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

o Please discard all packaging material with due regard for the

environment.

4

Important safety information

Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If
you are unsure of any of the information contained in
this booklet, please contact the Baumatic Advice Line.

IMPORTANT: Any installation work must be
carried out by a qualified electrician or
competent person.

Use of the appliance

o Your appliance is only designed to be used in the

home. It is suitable for storing and chilling wine.
NO food stuffs must be stored in the appliance. If it
is used for any other purpose or it is not used
correctly, then Baumatic Ltd. will accept no liability
for any damage that is caused.

o Altering the specification of the appliance must not be attempted

for reasons of safety.

Before using your appliance

o Check the appliance for any signs of transport damage. If you

notice any damage, then you should not connect your appliance
to your mains supply and should contact your retailer.

Refrigerant

o Your appliance contains R600a refrigerant, which is a natural gas

that does not contain CFCs that can damage the environment.
However it is a flammable substance, therefore care should be
taken:

 During the transportation and installation of the

appliance, make sure that the refrigeration pipework
does not get damaged.

 If it does become damaged then sources of ignition

and open flames should be avoided. Also the room
that the appliance is situated in should be thoroughly
ventilated.

o Do not place any objects on top of the appliance,

as this may damage the table top.

5

Child safety

o Packaging material should be kept away from

children.

o Children should not be allowed to touch the

controls or play with the appliance.

General safety

o Do not pull on the power supply cable to remove the plug from

your mains supply socket.

o Do not pull out or insert the plug with wet hands.

o Do not attempt to use your appliance outdoors or

any place where it is likely to come into contact
with the elements.

o Before cleaning the appliance or performing

maintenance work, ensure that the appliance has been
disconnected from your mains supply.

o Never allow the back coils of the appliance to come into contact

with the wall surface.

o Always ensure that the location where you are installing your

appliance is free of stored items such as papers and other
flammable materials.

o Never block the ventilation openings of the appliance, either on

the inside or its exterior.

o It is vital to keep your appliance well ventilated,

so that there is proper air flow between the
bottom of the unit and the plinth/kick plate
which it is sitting on.

o Do not place electrical devices inside of the appliance, such as

mixers or ice cream makers.

Service

You should not attempt to repair the appliance
yourself, as this could cause injury or a more serious
malfunction. If you require a service call then please
contact the Customer Care Department.

6

Specifications of your wine cooler

o Gross capacity: 145 litres
o Net capacity: 138 litres
o Bottle capacity: 46 x 0.75 litre wine bottles
o Electronic push button control operation
o LED display
o Celsius and Fahrenheit button
o 6 Adjustable wooden shelves
o Adjustable temperature
o Digital thermometer
o Internal light
o Black exterior
o Stainless steel door frame and handle
o Reversible door
o Adjustable feet
o Tempered door glass
o Designed to store wine at its optimum temperature between +

5°C - 22°C

Dimensions of appliance**

Height: 865 - 890 mm
Width: 595 mm
Depth: 570 mm

** Please refer to the installation instructions for more specific
information on the size of aperture that you will require.

IMPORTANT: When you install your appliance it is important to bear
in mind its climatic rating.

In order to find out the climatic rating of your appliance, you should
check the rating plate. The rating plate is located on the rear of the
appliance. The rating plate will indicate the ambient temperature range
that your appliance will function correctly within.
It is also advisable to make a note of the model number and the serial
number of the appliance before installing it.

Model number ………………………………………………

Serial number ………………………………………………

Date of purchase ……………………………………………..

7

Description of the appliance

1) Stainless steel door

2) Stainless steel handle

3) Digital control panel

4) Adjustable shelves

5) Adjustable foot

8

Control panel

The control panel is located in the middle of the appliance.

1) Light control button

2) Temperature control button

3) Upper zone display

4) Lower zone display

5) Temperature plus button

6) Temperature minus button

Description of the product features

1) Control panel

o The control panel is located in the middle of the appliance,

behind the glass door. This means it is easy to set the
temperature of the appliance and see what temperature the
appliance is set to.

2) Two cooling zones

o There are two cooling zones inside of your wine cooler; they are

separated by a partition that holds the control panel.

o Each cooling zone has an independent temperature control and

temperature display.

3) Interior light

o The wine cooler has an interior light. The light can be switched

on and off by using the light control button (1).

9
