BW325SL/W
60 cm 6 kg Washer
dryer
USER MANUAL FOR YOUR BAUMATIC
BW325SL/W
60 cm 6 kg Washer dryer
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
DD 24/03/09
2
Contents
Environmental note 4
Important safety information 5 – 6
Specifications 7
Description of the appliance 8
Control panel 9
Program options 9
LCD display 10
Wash program selection knob 10
Spin speed selection knob 10
Detergent drawer 11
Preparing the wash cycle 12 - 14
Preparing your garments for washing 12
A selection of wash care symbols 13
Detergents and conditioners 14
Program tables 15 - 16
Wash program guidance 17
Selecting a wash program 18 – 19
Selecting a separate drying program 19
Selecting an automatic wash and dry program 20
Cancelling or pausing a wash program 20 – 21
Spin speed selection knob 21 – 22
Setting a program option 22
Maintenance and cleaning 23 - 25
In daily use 23
Control panel and washer dryer cabinet 23
Detergent drawer 23 – 24
The washer dryer drum 24
Door 24
90 degree maintainece wash 25
Error code failure system 26 – 27
General troubleshooting 27
Poor wash results 28
Cleaning the drain pump filter 29 – 30
Installation 30 - 36
Unpacking the machine and removing the transit bolts 30 - 31
Positioning and levelling the appliance 32
Connecting to the mains water supply 33
Water outlet 34
Power supply 34 - 35
Before first use maintenance wash 35 - 36
Contact details 37
3
ENVIRONMENTAL NOTE
Note
disconnect it from the power supply. Cut off and render any plug
useless. Cut the cable off directly behind the appliance to prevent
misuse. This should be undertaken by a competent person. Disable
the door lock to make sure that children cannot get stuck inside
the appliance.
: Before discarding an old appliance, switch off and
4
IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
booklet, please contact the Baumatic Advice Line.
General Safety
o Repairs to your appliance must only be carried out by a
Baumatic engineer or one of its authorised service agents. Any
attempt by an inexperienced person to repair the appliance,
could result in injury or damage to your washing machine.
o If you notice that the mains cable is damaged. The appliance
must not be used. The same applies if you notice that the
worktop, control panel or base area is damaged. As this could
allow access to the internal components of the machine.
o The appliance should be switched off and isolated from the
mains supply, before either cleaning or maintenance work is
attempted.
o The mains cable must not be used to pull the plug out of the
electrical socket.
o The machine should not be sprayed with water.
o The glass of the porthole door may become hot during the higher
temperature wash programs.
o The machine should be allowed to cool before carrying out an
emergency drain or cleaning the drain filter.
o It is possible for small animals to chew either mains cables or
water hoses, which could cause an electric shock hazard.
Installation
o The installation instructions contained within this user manual
should be followed.
o It is obligatory for the completed installation to comply with all
relevant building regulations and local water authority
requirements.
5
o Before the first use of the appliance, we advise that a
90°C cotton wash is completed. No garments should be
placed inside the machine; however a small amount of
detergent must be used.
During Use
o It is recommended that the appliance is unplugged and the
water supply is turned off after the machine is used.
o This appliance is only designed to wash normal domestic
washloads. If you use your washing machine in any other way or
it is incorrectly used, then Baumatic accepts no liability for any
damage that might be caused and any guarantee will be void.
o No attempt should be made to alter or modify the specifications
of this appliance.
o The detergents that you place in this appliance should be
suitable for automatic washing machines. With regards to dosage
levels, the detergent manufacturer’s recommendations should be
followed.
o You should not wash garments that have been in contact with
flammable materials.
o Your washing machine should not be used for dry cleaning.
o If you use either dyes or bleaching agents inside this machine,
then you should consult with the manufacturer of these products
to make sure they are suitable for use in your washing machine.
Baumatic cannot be held responsible for any damage that may
result.
Child Safety
o Your washing machine should only be used by adults. You should
not allow children in the area of the machine unsupervised. You
should not let them touch the controls or play with the appliance.
o It could be possible for a child or pet to gain access to the
washing machine through the porthole door. Therefore please
check the drum before using the appliance.
o Any packaging that is removed from the machine should be kept
away from children.
o All detergents should be kept out of children’s reach in a safe
place.
6
Specifications
9 13 wash programs/2 drying programs
9 6kg wash load/4kg drying load
9 1200 rpm maximum spin speed
9 LCD display
9 Electronic control
9 Spin speed regulation (via a control knob)
9 Remain time indicator
9 3 Option buttons: Easy iron
Extra rinse
Intensive wash
9 Unbalance control system
9 Suspend the clothes in water option
9 Door safety lock
9 Stainless steel drum
9 Adjustable feet
9 Error code failure system
Appliance dimensions:
Height: 850 mm
Width : 590 mm
Depth: 550 mm
Energy efficiency:
Energy rating (washing) A
Energy rating (drying) B
Wash performance A
Water extraction performance B
7
Description of the appliance
8
Control panel
Wash program selection knob
This control knob allows you to select the wash program of your
choice.
Start/Stop button
Once a wash program has been selected, this button should be
pressed to start the wash cycle.
Program option button
This button needs to be pressed after a wash program has been
selected, but before the wash program has been started. If you
select a different wash cycle after pressing a program option, it
will need to be reselected.
Intensive wash: This function should be selected if you are washing
heavily soiled, stained clothes. It achieves a better level of wash
performance by extending the wash program that you have selected.
Easy iron: This function helps to prevent garments from creasing by
carrying out a program where the rotation of the drum will fluff out the
garments, after the spin cycle has completed. This should make the
garments easier to iron.
Extra rinse: This function increases the level of the final rinse for the
selected wash program. This should be selected if large loads are being
washed or the garments belong to somebody who has sensitive skin.
This option will increase the amount of water the appliance uses.
9
LCD display
Wash program selection knob
Spin speed selection knob
10
Detergent drawer
Pre wash section
This compartment should have detergent placed in, if you are going to
select a wash program that has a pre wash as part of it.
Main wash section
This compartment should have detergent placed in it (you should also
put a water softening agent in this section, if you use one). The
detergent will be added to the drum at the start of the main wash
program.
Conditioner section
This compartment should be used for liquid conditioners (fabric
softener, starch). They will be added to the wash load during the final
rinse.
11
Preparing the wash cycle
Preparing your garments for washing
o Your washing should be sorted out, according to
the fabric type and the wash care symbol that is
printed on the garment’s wash care label. (see
separate section on wash care symbols).
o Your washing should also be sorted out
according to the degree of soiling.
o Check all pockets on a garment to make sure
that they are empty.
o Remove any detachable metal items (badges,
paperclips, safety pins etc).
o Zips should be closed, duvet covers and pillow cases should be
buttoned up and any loose straps should be tied up. This will
help to prevent other garments from getting damaged during the
wash.
o Woollens and knitted coloured fabrics should be turned inside out
before being washed in the appliance.
o Small delicate items (tights, baby socks) should be placed in
either a washing net or a zipped pillow case.
o Curtains should be handled with particular care. All plastic hooks
or metal strips must be removed before being washed in the
appliance.
o Coloured items and whites should be washed
in separate wash cycles.
o New garments often contain an excess of
dye, therefore it is advisable to wash them separately for their
first wash.
o Garments should be unfolded and shook out before being placed
inside the machine.
12
